2BH7FFUSM2POEFusion 2.5G PoE Gateway

Fusion Gateway Quick Installation Guide Note: Fusion gateways are for enterprise installation and use. Fusion 2.5G is used as an example throughout the guide. Images may differ from your actual product. Fusion Gateway 2.5G PoE SwitchPoE Gigabit Switch Wall Plate AP Celling Mount AP Outdoor AP Management PC Managed Switch Non-PoE Gigabit Switch Office Area, Meeting Room Celling Mount AP Office Area, Meeting Room PC PC PC PC Department A Department B Open a web browser and type the default management address https://omada.local or https://192.168.188.1 in the address field of the browser, then press the Enter ke y. 4. Make sure the management PC is configured to Obtain an IP address automatically. 3. Follow the setup wizard to configure the internet settings, bind the gateway to your TP-Link ID, set up the controller, and add devices. 5. After the setup wizard is complete, you will be directed to the management page. And you can configure more settings and manage your network. 6. For detailed information and configuration, refer to the gateway's user guide. The guide can be found on the Documents page of our official website: https://support.omadanetworks.com/document/. Initial Setup The Fusion gateway delivers an all-in-one solution for networking and centralized management on a single device, featuring a built-in controller for the entire Omada ecosystem. It is ideal for small businesses across single or multiple sites. This Quick Installation Guide is for qualified IT staff and professional installers. It covers typical network topology, basic software configuration, and descriptions of enterprise-dedicated features. For detailed instructions, refer to the user guide. Enterprise Solution Connect the Internet port (Port 1) of the gateway to the internet using the provided Ethernet cable. 1. Connect the gateway to a grounded power outlet using the provided power adapter. The touchscreen on the front panel will light up. 2. Via Omada Cloud Portal a. Enable Cloud Access on the Settings page on the gateway and bind a TP-Link ID to your gateway. If you have configured this in the setup wizard, skip the step. b. Launch a web browser and enter https://omada.tplinkcloud.com in the address bar. c. Enter your TP-Link ID and password to log in. A list of Fusion gateways that have been bound with your TP-Link ID will appear in the Fusion Systems page. Then you can launch your device to further configure the gateway. With the TP-Link Omada app, you can access and manage your Omada devices at a local site or remotely. More Management Methods Via Omada App Typical Network Topology Software Configuration Safety PrecautionsPreface ©2026 TP-Link 7100003112 REV1.0.0 Internet • Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us. • Do not use damaged charger or USB cable to charge the device. • Do not use any other chargers than those recommended. • Adapter shall be installed near the equipment and shall be easily accessible. • Keep the device away from water, fire, humidity or hot environments. • For enterprise installation and use only. Flip Over to Explore More More Resources Main Sitehttps://www.omadanetworks.com/ https://support.omadanetworks.com/video/ https://support.omadanetworks.com/document/ https://support.omadanetworks.com/product/ https://support.omadanetworks.com/contact-support/ Video Center Product Support Documents Technical Support EU Declaration of Conformity TP-Link hereby declares that the gateway is in compliance with the essential requirements and other relevant provisions of directives (EU)2015/863, 2014/53/EU and 2011/65/EU. The original EU declaration of conformity may be found at https://www.tp-link.com/en/support/ce/. UK Declaration of Conformity TP-Link hereby declares that [product name] is in compliance with the essential requirements and other relevant provisions of the Radio Equipment Regulations 2017. The original UK declaration of conformity may be found at https://www.tp-link.com/support/ukca/ Frequently Asked Questions (FAQ) Q1. Why were no APs or switches found during the initial setup? A: During initial setup, only devices in factory mode can be detected. Otherwise, they can only be detected and adopted after setup using their original account and password. Q2. How do I reset the Fusion gateway? A: • Via the physical Reset button With the device powered on, use a pin to press and hold the Reset button on the front panel for about 5 seconds until a reset prompt appears, then release. The device will restore to its factory default settings. • Via the web management page Go to Settings > System Settings > OS Settings. In the Action drop-down list, click Reset to reset the device to its factory default settings. Q3. How do I adopt APs and switches? A: 1. Connect the APs/switches to the same network as the gateway. 2. Access the gateway's management page at https://omada.local or https://192.168.188.1. 3. Go to Devices, you will find the devices displayed in the Device List. 4. Click Adopt and wait until the device’s S TAT U S changes to CONNECTED. *These features refer to functions supported by the switches adopted by the Fusion gateway and can be configured through it. Appendix Enterprise-Dedicated Features Fusion gateways are FCC Class A certified products with various advanced software capabilities, primarily used in business, industrial, or office environments. ■ Multi-Site Networking and Management: Features an enterprise-grade SD-WAN for multi-site networking in business scenarios (e.g., chain supermarkets and chain restaurants) and Cloud Portal for managing multiple sites. • Sites are interconnected via encrypted tunnels, forming a unified enterprise WAN and ensuring secure and reliable communication across geographically distributed locations. All network configuration, site onboarding, and policy management are performed exclusively through a cloud management portal. Local or on-premises controllers are not supported…

Text truncated - open the document above for the full version.

Regulatory Compliance Omada Fusion 2.5G PoE Gateway © 2026 TP-Link 1900002835 REV1.0.0 FCC compliance information statement Product Name: Omada Fusion 2.5G PoE Gateway Model Number: Fusion 2.5G PoE Component NameModel I.T.E. PowerT540243-4-DT Responsible party: TP-Link Systems Inc. Address: 10 Mauchly, Irvine, CA 92618 Website: https://www.tp-link.com/us/ Tel: +1 626 333 0234 Fax: +1 909 527 6804 E-mail: [email protected] This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. FCC RF Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. “To comply with FCC RF exposure compliance requirements, this grant is applicable to only Mobile Configurations. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.” We,TP-Link Systems Inc., has determined that the equipment shown as above has been shown to comply with the applicable technical standards, FCC part 15. There is no unauthorized change is made in the equipment and the equipment is properly maintained and operated. Issue Date: 2026.04.15 FCC compliance information statement Product Name: I.T.E. Power Supply Model Number: T540243-4-DT Responsible party: TP-Link Systems Inc. Address: 10 Mauchly, Irvine, CA 92618 Website: https://www.tp-link.com/us/ Tel: +1 626 333 0234 Fax: +1 909 527 6804 E-mail: [email protected] This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/ TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. We, TP-Link Systems Inc., has determined that the equipment shown as above has been shown to comply with the applicable technical standards, FCC part 15. There is no unauthorized change is made in the equipment and the equipment is properly maintained and operated. Issue Date: 2026.04.15 CE Mark Warning This is a class A product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. OPERATING FREQUENCY (the maximum transmitted power) 2400 MHz -2483.5 MHz(20dBm) EU declaration of conformity TP-Link hereby declares that the gateway is in compliance with the essential requirements and other relevant provisions of directives 2014/53/EU, 2009/125/EC, 2011/65/EU and (EU)2015/863. The original EU declaration of conformity may be found at https://www.tp-link.com/en/ce RF Exposure Information The device complies with RF specifications when the device used at 20 cm from your body. UKCA Mark UK Declaration of Conformity TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of the Radio Equipment Regulations 2017. The original UK Declaration of Conformity may be found at https://www.tp-link.com/support/ukca Canadian Compliance Statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may c…

Text truncated - open the document above for the full version.

TP-Link Systems Inc. 092723-17 rev 10 Certification Application Attestation Statements Date: May 22, 2026 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) ____ TP-Link Systems Inc. _____ certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) _____ TP-Link Systems Inc.____ (“the applicant”) certifies that, as of the date of the filing of this application, the applicant ☐ - is / ☑ - is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates – see KDB 986446 Question 5) as an entity producing “covered” equipment. The applicant also certifies that the device does not have cybersecurity and/or anti-virus software produced by Kaspersky Lab, Inc or any of its successors and assignees identified on the covered list installed on the device, nor will it be installed by the applicant at any time after certification. Thank you, By: __________________________ _______ Sarah Wang _____ (Signature 2 ) (Print name) Title: __ Compliance Manager _ Company: _ TP-Link Systems Inc._ Telephone: (626)333-0234 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . 2 - Letters must be placed on appropriate letterhead.

TP-Link Systems Inc. U.S. Agent Designation for Service of Process TO: American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information This letter is to confirm that the Applicant will also serve as the U.S. Agent for Service of Process as required by 47 CFR 2.911(d)(7). The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The Applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information changes. Applicant Company name: TP-Link Systems Inc. FRN #: 0035788017 Grantee Code: 2BH7F FCC ID: 2BH7FFUSM2POE Contact Name: Sarah Wang Street Address: 10 Mauchly, Irvine, CA 92618 City/Province/Zip: 92618 Telephone No: (626) 333-0234 Email: [email protected] Applicant Signature 1 : Date: 2026-04-22 Signed by (Printed Name/Title): Sarah Wang/ Product Compliance Manager 1 - Letters must be placed on appropriate letterhead. The signee for the applicant must be one of the following: Applicant (grantee) contact of record in the FCC’s authorization system, or authorized officers or employee of the applicant (grantee).

TP-Link Systems Inc. Declaration Letter – Enterprise-Grade Commercial Gateway Date: May 22, 2026 Name: TP-Link Systems Inc. Address: 10 Mauchly, Irvine, CA 92618 Product: Fusion 2.5G PoE Gateway FCC ID: 2BH7FFUSM2POE Model: Fusion 2.5G PoE Brand: Omada To Whom It May Concern, This letter serves as an official statement to formally confirm and clarify the product nature, positioning, core functions of the Fusion 2.5G PoE Gateway from the Omada Fusion Gateway Series. The Fusion 2.5G PoE is designed, developed, and marketed exclusively as an enterprise-grade networking device, intended solely for enterprise environments, and is not intended for household or consumer use. The Product’s positioning and features are as follows: 1. Product Positioning and Target Customers The Fusion Gateway is positioned as an enterprise-grade gateway dedicated to enterprise networking scenarios. Primary customers include professional installers, managed service providers (MSPs), and enterprise- level users. Detailed information about the Omada enterprise networking solution portfolio is available on the official website: https://www.omadanetworks.com/ https://www.omadanetworks.com/us/business-networking/solution/small-sized-chain- restaurants-stores/ 2. Product Packaging and Color Box The product outer packaging is clearly and prominently labeled with “Enterprise Solution” to identify its enterprise-level purpose. 3. Product Manual The product includes a detailed user manual with “Enterprise Solution” clearly marked on the cover.The manual states that the device is a sophisticated system eng TP-Link Systems Inc. ineered for enterprise scenarios, with these enterprise-grade software features: • Multi-Site Networking and Management: Commercial-grade SD-WAN for multi- site deployment in chain retail, restaurants, and other enterprise environments; cloud portal for centralized multi-site management. • Centralized Management Functionality: Unified management of all network devices including enterprise-grade L3 switches, EAPs, and other equipment. • Enterprise Network Stability Assurance: Multiple WAN connections and WAN failover functionality to ensure reliable network operation. • Enterprise-Grade Configuration & Management: Professional CLI configuration, batch port configuration across switches, and support for the SNMP management protocol. • Enterprise-Grade Operations & Maintenance: Enterprise- level packet capture, network traffic statistical report export, and audit log support. • Enterprise-Grade Access Authentication: External RADIUS / External Portal / Voucher, PPSK(Private Pre-Shared Key), and 802.1x / MAC-Based Authentication. 4. Enterprise-Grade L3 Network Feature Management The Fusion 2.5G PoE Gateway supports full management of professional enterprise- grade Layer 3 switches, enabling end-to-end enterprise network control. 5. FCC Certification Classification This product is classified under FCC Class A, a certification intended for digital equipment used in enterprise environments, consistent with its enterprise-grade positioning. We greatly appreciate your professional guidance and assistance regarding the FCC certification clarification process. We confirm that all design, features, labeling, and certifications of the Fusion 2.5G Gateway strictly comply with enterprise and commercial device requirements. Sincerely, Sarah Wang TP-Link Systems Inc. Product Compliance Manager

Confidentiality Request Letter Federal Communications Commission Authorization and Evaluation Division FCC ID: 2BH7FFUSM2POE Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: 1. Block Diagram 2. Schematics 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, _________________ Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2026-04-22

Declaration of Authorization We Name: TP-Link Systems Inc. Address: 10 Mauchly, Irvine, CA 92618 Declare that: Name Representative of agent: Marlin Chen Agent Company name: MRT Technology (Suzhou) Co., Ltd. Address: D8 Building, Youxin Industrial Park, No.2 Tian'edang Rd., Wuzhong Economic Development Zone City: Suzhou Country: China is authorized to apply for Certification of the following product(s): Product: Fusion 2.5G PoE Gateway FCC ID: 2BH7FFUSM2POE Model: Fusion 2.5G PoE Brand: Omada Sincerely, _________________ Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2026-04-22

Declaration of Conformity We Name: TP-Link Systems Inc. Address: 10 Mauchly, Irvine, CA 92618 Declare that: Product: Fusion 2.5G PoE Gateway FCC ID: 2BH7FFUSM2POE Model: Fusion 2.5G PoE Brand: Omada Product which bears the above FCC ID is also compliant with the FCC requirements for sDOC. And the sDOC procedure shall be carried out prior to marketing the device in the US. Sincerely, _________________ Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2026-04-22

Non-SDR (Software Defined Radio) Cover Letter Refer to KDB 442812 D01 SDR apps Guide v02r03. The following six questions can be used for determining if a radio can elect to be, or must be an SDR. 1. Can the RF parameters of the device be altered through software? Ye s - go to 2. No, not an SDR No 2. Can third parties not permitted by the Commission through specific filings modify, configure, or load different software, or make configuration settings to operate the device or host hardware radio frequency parameters (frequency range, modulation type, maximum output power or other radio parameters) in any other way than granted (or expected to be granted)? Yes, must be an SDR. No - go to 3. No 3. Is the device capable of operating in any other in any other way than granted, or will be, granted? Ye s , - go to 4. No - go to 5. No 4. Is this a Part 15 client Device as defined in Section 15.202 (as opposed to a master device)? Yes, qualifies as a part 15 client devices - go to 5. No, must be an SDR. 5. Does the manufacturer elect SDR? Yes, elects to be an SDR. No, Not an SDR No Conclusion: According to the above questions reply, we can confirm this device (FCC ID: 2BH7FFUSM2POE & IC: 32876-FUSM2POE) must be a Non-SDR device. __________________ Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2026-04-22

Report No.: 2604TW0108-UE 1 of 3 External Photograph (1) EUT Photo (2) EUT Photo Report No.: 2604TW0108-UE 2 of 3 (3) EUT Photo (4) EUT Photo Report No.: 2604TW0108-UE 3 of 3 (5) EUT Photo (6) EUT Photo

C B A 12 C 345678 B E D D A 9 12345 E 6789 IC: 32876-FUSM2POE Model: Fusion 2.5G PoE Fusion 2.5G PoE Gateway S/N:XXXXXXXXXXXXXUN/1.0 M AC : X X-X X-X X-X X-X X-X X Device Key:XXXX-XXXX-XXXX-XXXX-XXXX TP-Link Systems Inc. 10 Mauchly, Irvine, CA 92618 Power: 54V 2.43A PoE Ports: 2-9 Output: 54V 0.56A per port Pins 1/2(-),3/6(+) Total 110W(Max) 40.76±0.5mm 70.845±0.5mm This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: 2BH7FFUSM2POE Enterprise Solution

Report No.: 2604TW0108-UI 1 of 13 Internal Photograph (1) EUT Photo (2) EUT Photo Report No.: 2604TW0108-UI 2 of 13 (3) EUT Photo (4) EUT Photo Report No.: 2604TW0108-UI 3 of 13 (5) EUT Photo (6) EUT Photo Report No.: 2604TW0108-UI 4 of 13 (7) EUT Photo (8) EUT Photo Report No.: 2604TW0108-UI 5 of 13 (9) EUT Photo (10) EUT Photo Report No.: 2604TW0108-UI 6 of 13 (11) EUT Photo (12) EUT Photo Report No.: 2604TW0108-UI 7 of 13 (13) EUT Photo (14) EUT Photo Report No.: 2604TW0108-UI 8 of 13 (15) EUT Photo (16) EUT Photo Report No.: 2604TW0108-UI 9 of 13 (17) EUT Photo (18) EUT Photo Report No.: 2604TW0108-UI 10 of 13 (19) EUT Photo (20) EUT Photo Report No.: 2604TW0108-UI 11 of 13 (21) EUT Photo (22) EUT Photo Report No.: 2604TW0108-UI 12 of 13 (23) EUT Photo (24) EUT Photo Report No.: 2604TW0108-UI 13 of 13 (25) EUT Photo (26) EUT Photo

MRT Technology (Taiwan) Co., Ltd. Report No.: 2604TW0108-U3 Phone: +886-3-3288388 Report Version: 1.0 Web: www.mrt-cert.com Issue Date: 2026-05-13 Template Version: 2.1 1 of 11 RF Exposure Evaluation Declaration FCC ID: 2BH7FFUSM2POE Applicant: TP-Link Systems Inc. Product: Fusion 2.5G PoE Gateway Model No.: Fusion 2.5G PoE FCC Rule Part(s): FCC Part 2.1091 Result: Complies Evaluation Date: 2026-05-12 Reviewed By: Paddy Chen Approved By: Chenz Ker The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report. Testing was performed in accordance with the applicable measurement procedures. The test results reported herein apply only to the specific item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Taiwan) Co., Ltd. Report No.: 2604TW0108-U3 2 of 11 Revision History Report No. Version Description Issue Date Note 2604TW0108-U3 1.0 Original Reportt 2026-05-13 Report No.: 2604TW0108-U3 3 of 11 CONTENTS Description Page 1. General Information ................................................................................................................................4 1.1. Applicant ........................................................................................................................................4 1.2. Manufacturer .................................................................................................................................4 1.3. Testing Facility ...............................................................................................................................4 1.4. Product Information .......................................................................................................................5 1.5. Antenna Details .............................................................................................................................6 1.6. Device Classification .....................................................................................................................6 1.7. Applied Standards .........................................................................................................................6 2. RF Exposure Evaluation .........................................................................................................................7 2.1. Limits .............................................................................................................................................7 2.2. SAR Exemptions ...........................................................................................................................8 2.3. Calculated Result ........................................................................................................................ 11 Report No.: 2604TW0108-U3 4 of 11 1. General Information 1.1. Applicant TP-Link Systems Inc. 10 Mauchly, Irvine, CA 92618 1.2. Manufacturer TP-Link Systems Inc. 10 Mauchly, Irvine, CA 92618 1.3. Testing Facility Test Site - MRT Suzhou Laboratory Laboratory Location (Suzhou - Wuzhong) D8 Building, No.2 Tian’edang Rd., Wuzhong Economic Development Zone, Suzhou, China Laboratory Location (Suzhou - SIP) 4b Building, Liando U Valley, No.200 Xingpu Rd., Shengpu Town, Suzhou Industrial Park, China Laboratory Location (Suzhou - Wujiang) Building 1, No.1 Xingdong Road, Wujiang, Suzhou, Jiangsu, People’s Republic of China Laboratory Accreditations A2LA: 3628.01 CNAS: L10551 FCC: CN1166 ISED: CN0001 Test Site - MRT Shenzhen Laboratory Laboratory Location (Shenzhen) 1G, Building A, Junxiangda Building, Zhongshanyuan Road West, Nanshan District, Shenzhen, China Laboratory Accreditations A2LA: 3628.02 FCC: CN1284 ISED: CN0105 Test Site - MRT Taiwan Laboratory Laboratory Location (Taiwan) No. 38, Fuxing 2nd Rd., Guishan Dist., Taoyuan City 333, Taiwan (R.O.C.) Laboratory Accreditations TAF: 3261 FCC: 291082, TW3261 ISED: TW3261 Report No.: 2604TW0108-U3 5 of 11 1.4. Product Information Product Name Fusion 2.5G PoE Gateway Model No. Fusion 2.5G PoE Specification Bluetooth Single Mode Antenna Information Refer to section 1.5 Operating Temperature -10 ~ 40 °C Operating Environment Indoor Use Power Type AC/DC Adapter Accessory Adapter Model No.: T540243-4-DT Input Power: 100 - 240 V ~ 50/60 Hz, 2.0A Output Power: 54.0V ⎓ 2.43A 131.2W Note: The information of the EUT (Equipment Under Test) was provided by the manufacturer. The accuracy, completeness, and validity of the information are solely the responsibility of the manufacturer. Report No.: 2604TW0108-U3 6 of 11 1.5. Antenna Details Antenna Type Frequency Band (MHz) T X Paths Directional Gain (dBi) IFA Antenna 2400 ~ 2483.5 1 4.41 Note: The antenna gain is from antenna data sheet provided by the manufacturer. 1.6. Device Classification According to the user manual, this device is classified as a Mobile Device. So, the RF exposure evaluation requirements of § 2.1091 for portable device exposure conditions subject to SAR limits. 1.7. Applied Standards According to the specifications of the manufacturer, the EUT must comply with the requirements of the following standards: ⚫ FCC Part 2.1091 ⚫ KDB 447498 D04 Interim General RF Exposure Guidance v01 Report No.: 2604TW0108-U3 7 of 11 2. RF Exposure Evaluation 2.1. Limits According to FCC §1.1310: (a) Specific absorption rate (SAR) shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in § 1.1307(b) of this part within the frequency range of 100 kHz to 6 GHz (inclusive). (b) The SAR limits for occupational/controlled exposure are 0.4 W/kg, as averaged over the whole body, and a peak spatial-average SAR of 8 W/kg, averaged over any 1 gram of tissue (defined as a tissue volume in the shape of a cube). Exceptions are the parts of the human body treated as extremities, such as hands, wrists, feet, ank…

Text truncated - open the document above for the full version.

MRT Technology (Taiwan) Co., Ltd. Report No.: 2604TW0108-U2 Phone: +886-3-3288388 Report Version: 1.0 Web: www.mrt-cert.com Issue Date: 2…

Text truncated - open the document above for the full version.
