2BH7FT150Smart Presence Sensor

TP-Link Systems Inc. 10 Mauchly, Irvine, CA 92618 092723-17 rev 10 Certification Application Attestation Statements Date: July 29, 2025 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) ______TP-Link Systems Inc. certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) ______TP-Link Systems Inc.______ (“the applicant”) certifies that, as of the date of the filing of this application, the applicant ☐ - is / ☑- is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates – see KDB 986446 Question 5) as an entity producing “covered” equipment. The applicant also certifies that the device does not have cybersecurity and/or anti-virus software produced by Kaspersky Lab, Inc or any of its successors and assignees identified on the covered list installed on the device, nor will it be installed by the applicant at any time after certification. Thank you, By: __________________________ Sarah Wang (Signature 2 ) (Print name) Title: Compliance manager Company: ___TP-Link Systems Inc. Telephone: (626)333-0234 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . 2 - Letters must be placed on appropriate letterhead.

TP-Link Systems Inc. U.S. Agent Designation for Service of Process TO: American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information This letter is to confirm that the Applicant will also serve as the U.S. Agent for Service of Process as required by 47 CFR 2.911(d)(7). The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The Applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information changes. Applicant Company name: TP-Link Systems Inc. FRN #: 0035788017 Grantee Code: 2BH7F FCC ID: 2BH7FT150 Contact Name: Sarah Wang Street Address: 10 Mauchly, Irvine, CA 92618 City/Province/Zip: 92618 Telephone No: (626) 333-0234 Email: [email protected] Applicant Signature 1 : Date: 2025-12-24 Signed by (Printed Name/Title): Sarah Wang/ Product Compliance Manager 1 - Letters must be placed on appropriate letterhead. The signee for the applicant must be one of the following: Applicant (grantee) contact of record in the FCC’s authorization system, or authorized officers or employee of the applicant (grantee).

Confidentiality Request Letter Federal Communications Commission Authorization and Evaluation Division FCC ID: 2BH7FT150 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: 1. Block Diagram 2. Schematics 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, _________________ Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2025-12-24

Declaration of Authorization We Name: TP-Link Systems Inc. Address: 10 Mauchly, Irvine, CA 92618 Declare that: Name Representative of agent: Marlin Chen Agent Company name: MRT Technology (Suzhou) Co., Ltd Address: D8 Building, Youxin Industrial Park, No.2 Tian'edang Rd., Wuzhong Economic Development Zone City: Suzhou Country: China is authorized to apply for Certification of the following product(s): Product: Smart Presence Sensor FCC ID: 2BH7FT150 Model: Tapo T150 Brand: tp-link, tapo Sincerely, _________________ Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2025-12-24

Declaration of Conformity We Name: TP-Link Systems Inc. Address: 10 Mauchly, Irvine, CA 92618 Declare that: Product: Smart Presence Sensor FCC ID: 2BH7FT150 Model: Tapo T150 Brand: tp-link, tapo Product which bears the above FCC ID is also compliant with the FCC requirements for sDOC. And the sDOC procedure shall be carried out prior to marketing the device in the US. Sincerely, _________________ Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2025-12-24

Report No.: R25S1013128-CE 1 of 9 EUT External Photograph (1) EUT Photo (2) EUT Photo Report No.: R25S1013128-CE 2 of 9 (3) EUT Photo (4) EUT Photo Report No.: R25S1013128-CE 3 of 9 (5) EUT Photo (6) EUT Photo Report No.: R25S1013128-CE 4 of 9 (7) EUT Photo

EU/1.0 S/N:XXXXXXXXXXXXX M AC : X X-X X-X X-X X-X X-X X 2.17±0.3mm 10.44±0.5mm RoHS Batteries: 2x 1.5V SIZE AAA/LR03 TP-Link Systems Inc. 10 Mauchly, Irvine, CA 92618 201-250973 Smart Presence Sensor Model: Tapo T150

1.60±0.3mm 2.6±0.3mm 이 기기는 사용중 전파혼신 가능성이 있으며, 타 기기로부터 유해한 혼신을 받을 수 있음 R-R-TPG-TapoT150 Smart Presence Sensor Model: Tapo T150 FCC ID: 2BH7FT150 IP55 IC: 32876-T150

Report No.: R25S1013128-CE 5 of 9 EUT Internal Photograph (1) EUT Photo (2) EUT Photo Report No.: R25S1013128-CE 6 of 9 (3) EUT Photo (4) EUT Photo Report No.: R25S1013128-CE 7 of 9 (5) EUT Photo (6) EUT Photo Report No.: R25S1013128-CE 8 of 9 (7) EUT Photo (8) EUT Photo Report No.: R25S1013128-CE 9 of 9 (9) EUT Photo

MRT Technology (Suzhou) Co., Ltd. Report No.: R25S1013128-U401 Phone: +86-512-66308358 R epor t Ver s i on: V 01 Web: www.mrt-cert.com Issue Date: 20 26-01-16 Template Version: 2.1 1 of 10 RF Exposure Evaluation Declaration FCC ID: 2BH7FT150 Applicant: TP-Link Systems Inc. Product: Smart Presence Sensor Model No.: Tapo T150 Brand Name: tp-link, tapo FCC Rule Part(s): FCC Part 2.1091 Result: Complies Evaluation Date: 2025-12-23 Reviewed By: Yuri Li Approved By: Robin Wu The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report. Testing was performed in accordance with the applicable measurement procedures. The test results reported herein apply only to the specific item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: R25S1013128-U401 2 of 10 Revision History Report No. Version Description Issue Date Note R25S1013128-U401 V01 Initial Report 2026-01-16 Valid Report No.: R25S1013128-U401 3 of 10 CONTENTS Description Page 1. General Information ............................................................................................................................... 4 1.1. Applicant ........................................................................................................................................4 1.2. Manufacturer .................................................................................................................................4 1.3. Testing Facility ...............................................................................................................................4 1.4. Product Information .......................................................................................................................5 1.5. Antenna Details .............................................................................................................................5 1.6. Device Classification .....................................................................................................................5 1.7. Applied Standards .........................................................................................................................5 2. RF Exposure Evaluation ........................................................................................................................ 6 2.1. Limits .............................................................................................................................................6 2.2. MPE Exemptions ...........................................................................................................................7 2.3. Calculated Result ....................................................................................................................... 10 Report No.: R25S1013128-U401 4 of 10 1. General Information 1.1. Applicant TP-Link Systems Inc. 10 Mauchly, Irvine, CA 92618 1.2. Manufacturer TP-Link Systems Inc. 10 Mauchly, Irvine, CA 92618 1.3. Testing Facility Test Site - MRT Suzhou Laboratory Laboratory Location (Suzhou - Wuzhong) D8 Building, No.2 Tian’edang Rd., Wuzhong Economic Development Zone, Suzhou, China Laboratory Location (Suzhou - SIP) 4b Building, Liando U Valley, No.200 Xingpu Rd., Shengpu Town, Suzhou Industrial Park, China Laboratory Location (Suzhou - Wujiang) Building 1, No.1 Xingdong Road, Wujiang, Suzhou, Jiangsu, People’s Republic of China Laboratory Accreditations A2LA: 3628.01 CNAS: L10551 FCC: CN1166 ISED: CN0001 Test Site - MRT Shenzhen Laboratory Laboratory Location (Shenzhen) 1G, Building A, Junxiangda Building, Zhongshanyuan Road West, Nanshan District, Shenzhen, China Laboratory Accreditations A2LA: 3628.02 CNAS: L10551 FCC: CN1284 ISED: CN0105 Test Site - MRT Taiwan Laboratory Laboratory Location (Taiwan) No. 38, Fuxing 2nd Rd., Guishan Dist., Taoyuan City 333, Taiwan (R.O.C.) Laboratory Accreditations TAF: 3261 FCC: 291082, TW3261 ISED: TW3261 Report No.: R25S1013128-U401 5 of 10 1.4. Product Information Product Smart Presence Sensor Model No. Tapo T150 Brand Name tp-link, tapo Sub 1G Specification 920 ~ 924MHz Radar Specification 24.00 ~ 24.25GHz Radar Antenna Information Refer to section 1.5 Operating Temperature 0~50 °C Power Type By Battery Note: The information of the EUT (Equipment Under Test) was provided by the manufacturer. The accuracy, completeness, and validity of the information are solely the responsibility of the manufacturer. 1.5. Antenna Details Technology Frequency Range (MHz) Antenna Type Max Peak Gain (dBi) Sub 1G 920 ~ 924 Monopole Antenna -3.17 24G Radar 24000 ~ 24250 Patch Antenna 3.90 Note: The antenna gain is from antenna data sheet provided by the manufacturer. 1.6. Device Classification According to the user manual, this device is classified as a Mobile Device. So, the RF exposure evaluation requirements of § 2.1091 for mobile device exposure conditions subject to MPE limits. 1.7. Applied Standards According to the specifications of the manufacturer, the EUT must comply with the requirements of the following standards: ⚫ FCC Part 2.1091 ⚫ KDB 447498 D04 Interim General RF Exposure Guidance v01 Report No.: R25S1013128-U401 6 of 10 2. RF Exposure Evaluation 2.1. Limits According to FCC §1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in §1.1307(b) Limits For Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 0.3 ~ 3.0 614 1.63 *(100) ≤6 3.0 ~ 30 1842/f 4.89/f *(900/f 2 ) <6 30 ~ 300 61.4 0.163 1.0 <6 300 ~ 1500 -- -- f/300 <6 1500 ~ 100000 -- -- 5 <6 (B) Limits for General Population/ Uncontrolled Exposures 0.3 ~ 1.34…

Text truncated - open the document above for the full version.

MRT Technology (Taiwan) Co., Ltd Report No.: 2511TW0112-U2 Phone: +886-3-3288388 Report Version: 1.0 Fax: +886-3-3288918 Issue Date: 2026-01-16 Web: www.mrt-cert.com Page Number: 1 of 54 FCC ID : 2BH7FT150 APPLICANT : TP-Link Systems Inc. Application Type : Certification Product : Smart Presence Sensor Model No. : Tapo T150 Brand Name : tp-link,tapo FCC Classification : (DTS) Digital Transmission System FCC Rule Part(s) : Part 15.247 Test Procedure(s) : ANSI C63.10-2020+Cor 1-2023+C63.10a-2024 + Errata to C63.10a-2024 Received Date : November 21, 2025 Test Date : November 27, 2025~November 28, 2025 MEASUREMENT REPORT Tested By : ( Peter Syu ) Reviewed By : ( Paddy Chen ) Approved By : ( Chenz Ker) The test results only relate to the tested sample. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.10. Test results reported herein relate only to the item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Taiwan) Co., Ltd. Report No.: 2511TW0112-U2 Page Number: 2 of 54 Revision History Report No. Version Description Issue Date Note 2511TW0112-U2 1.0 Original Report 2026-01-16 Report No.: 2511TW0112-U2 Page Number: 3 of 54 CONTENTS Description Page 1. INTRODUCTION ..................................................................................................................... 6 1.1. Scope .................................................................................................................................... 6 1.2. MRT Test Location ................................................................................................................ 6 2. PRODUCT INFORMATION ..................................................................................................... 7 2.1. Equipment Description .......................................................................................................... 7 2.2. Product Specification Subjective to this Standard .................................................................. 8 2.3. Test Mode ............................................................................................................................. 8 2.4. Operation Frequency / Channel List ...................................................................................... 9 2.5. Test Configuration ............................................................................................................... 10 2.6. Test Software ...................................................................................................................... 10 2.7. EMI Suppression Device(s)/Modifications ........................................................................... 10 2.8. Labeling Requirements ....................................................................................................... 10 3. DESCRIPTION of TEST ......................................................................................................... 11 3.1. Evaluation Procedure .......................................................................................................... 11 3.2. AC Line Conducted Emissions ............................................................................................ 11 3.3. Radiated Emissions ............................................................................................................ 12 4. ANTENNA REQUIREMENTS ................................................................................................ 13 5. TEST EQUIPMENT CALIBRATION DATE ............................................................................ 14 6. MEASUREMENT UNCERTAINTY ......................................................................................... 15 7. TEST RESULT ...................................................................................................................... 16 7.1. Summary ............................................................................................................................. 16 7.2. 6dB Bandwidth Measurement ............................................................................................. 17 7.2.1. Test Limit ......................................................................................................................... 17 7.2.2. Test Procedure used ....................................................................................................... 17 7.2.3. Test Setting ..................................................................................................................... 17 7.2.4. Test Setup ....................................................................................................................... 17 7.2.5. Test Result ...................................................................................................................... 18 7.3. Output Power Measurement ................................................................................................ 19 7.3.1. Test Limit ......................................................................................................................... 19 7.3.2. Test Procedure Used ....................................................................................................... 19 7.3.3. Test Setting ..................................................................................................................... 19 7.3.4. Test Setup ....................................................................................................................... 19 7.3.5. Test Result of Output Power ............................................................................................ 20 7.4. Power Spectral Density Measurement ................................................................................ 21 7.4.1. Test Limit ..........................…

Text truncated - open the document above for the full version.

Product Model： Tapo T150(US)1.0 Manufacturer： TP-Link Systems Inc. Test Date： 2025.7.30 Tested By： Yin shufen TP-Link Systems Inc. 10 Mauchly, Irvine, CA 92618 Index 1. Antenna Distribution ........................................................................................ 3 2. Electrical Characteristics ................................................................................ 3 3. Gain and Radiation Pattern ............................................................................. 3 3.1 Measurement Procedure ......................................................................................... 3 3.2 Test Setup ............................................................................................................... 5 3.3 S Parameter Test Data ............................................................................................ 5 3.4 Antenna Peak Gain ................................................................................................. 6 3.5 Antenna Radiation Pattern ....................................................................................... 6 Page 3 1. Antenna Distribution Tapo T150(US)1.0 2. Electrical Characteristics Ant1(BLE) Frequency 2400 ~ 2500MHz Impedance 50Ohm Antenna Type IFA Antenna Gain 3.62dBi@2400~2500MHz Radiation pattern Omni-Directional P/N T150_BLE Ant2(sub1G) Frequency 920~924MHz Impedance 50Ohm Antenna Type monopole Antenna Gain -3.17dBi@920~924MHz Radiation pattern Omni-Directional P/N T150_sub1G 3. Gain and Radiation Pattern 3.1 Measurement Procedure This measurement experiment adopted an antenna near-field measurement system, and the diagram of the measurement system was shown in Figure 3-1. The excitation signal was generated by the Keysight E5071C (300kHz-20GHz). Under the control of the central computer, the probe rotated in the θ direction, and the EUT rotated in the φ direction with the turntable. The probe sampling frame received and collected signals in the near-field range of the EUT. The software system which was controlled by the central computer completed the processing, output and display of the test data. Page 4 Figure 3-1 The test site was a full anechoic chamber with a size of 3.0m×3.1m×2.97m, which was built by GTS Rayzone2800. All six surfaces of the anechoic chamber were pasted with absorbing materials. And the chamber was calibrated by the authoritative third-party lab every year. The antenna anechoic chamber measurement system adopted a 13-probe multi-probe system. The probe antennas were evenly distributed on the spherical surface surrounding the EUT, and theirs operating frequency was 600MHz~8.5GHz. During the measurement, the probe antennas were rotated in the θ direction under the control of the probe holder to sample the near-field data at the θ angle. At the same time, the EUT rotated with the turntable in the φ direction to sample the near field data at the φ angle. The sampling accuracy was 15°. The system diagram was shown in Figure 3-2. From the sampling results, the EUT's near-field test data of θ component, φ component and total component could be obtained. Figure 3-2 Before the measurement, calibrated the vector network analyzer, and then connected the input end of each antenna to the output end of the vector network analyzer, and evenly the antennas to be measured. Test Equipment listed below: Equipments Model Manufacturer S/N Cali. Interval Cali. Due Date Chamber Rayzone2800 GTS(General Test System) MY5347043 5 12months 2026/01/15 Vector Network Analyzer E5071C Keysight MY46315238 24months 2026/03/13 Page 5 GTS MaxSign100 Software V2.1 GTS(General Test System) / / / 3.2 Test Setup The test setup was shown in Figure 3-3, 3-4: Figure 3-3 Figure 3-4 3.3 S Parameter Test Data Ant1 Page 6 Ant2 3.4 Antenna Peak Gain Frequency 2.45GHz 2400~2500MHz Ant1 MaxGain(dBi) 3.62 Ant1 Polarization/Φ (°)/θ(°) Phi/150/45 Max Gain(dBi) 3.62 Frequency 922MHz 920~924MHz Ant2 MaxGain(dBi) -3.17 Ant2 Polarization/Φ (°)/θ(°) Theta/180/150 Max Gain(dBi) -3.17 3.5 Antenna Radiation Pattern Ant1 Page 7 Ant2

Copyright © Possumic Technology Co., Ltd. 2022. All rights reserved. 1 MRS261L ANTENNA SPECIFICATION 2025/12/3 V1.1 Copyright © Possumic Technology Co., Ltd. 2022. All rights reserved. 2 Company: Possumic Technology Co.,Ltd Model Name: MRS261L Production Specification Addr: Room 603, Building B, Creative Cloud, No. 1 Gangwan, Tangjiawan Model Size: 12mm(Length)X8mm(Width)X1.3mm(Thickness) Antenna Type: Patch Antenna ANTENNA TEST DESCRIPTION Copyright © Possumic Technology Co., Ltd. 2022. All rights reserved. 3 MRS261L 1T1R(Tx→Rx) Gain and Radiation Pattern TxRx MRS261L ANTENNA TEST PRINCIPLE AND METHOD Copyright © Possumic Technology Co., Ltd. 2022. All rights reserved. 4 Principle: Conservation, that is, the signal power received by Rx is equal to the power lost in the energy space when the Tx transmit power is lost. Gain test method: Comparison method, using the equal power loss in space, replacing the Rx antenna with a horn antenna for reception to obtain the Rx antenna gain. Directional pattern test method: Use angular reflection to collect level values in different directions, and then obtain a normalized pattern. ANT GAIN RESULTS Copyright © Possumic Technology Co., Ltd. 2022. All rights reserved. 5 ANT Gain = EIRP - Tx Output Power FrequencyEIRPTx Output PowerANT Gain 24.00GHz12.9dBm9.0dBm3.9dBi 24.25GHz12.6dBm8.8dBm3.8dBi MRS261L RADIATION PATTERN Copyright © Possumic Technology Co., Ltd. 2022. All rights reserved. 6 Tx -Rx Loop Gain -12dB half distance FOV 140° -12dB half distance FOV 126°

Report No.: 2511TW0112-UT 1 of 2 RF Test Photograph Description: Radiated Emission Test Setup for below 1GHz Description: Radiated Emission Test Setup for above 1GHz Report No.: 2511TW0112-UT 2 of 2 Description: Radiated Emission Test Setup for 9kHz~30MHz Description: Conducted Measurement Test Setup
