2BH7FTBE400UPLUSBE6500 Tri-Band Wi-Fi 7 High Gain Wireless USB Adapter

Quick Installation Guide Wireless USB Adapter Images are for demonstration only. ©2025 TP-Link 7100002253 REV1.0.0 1 Connect to a Computer Note: • It is recommended to connect the adapter to a USB 3.0 port. • If you are experiencing an unstable wireless connection with your adapter, try a different USB port on your computer. a. Ensure that your operating system meets the compatibility requirements: • Supported operating system: Windows 10/11 • Supported MLO operating system: Windows 11 (Version 24H2 and later) b. Ensure that your Router or Access Point supports the Wi-Fi 7 standard, and the network is using WPA3 encryption. Before You Start Option 1: Directly . . . . . . Option 2: Via the USB Cradle (if provided) Note: For optimal performance, it is recommended to use the provided USB extension cable. For technical support, replacement services, user guides, and other information, please visit https://www.tp-link.com/support, or simply scan the QR code. Support If you have problems during the installation, please refer to the following online FAQs. T1. Can’t find the hardware version of the adapter: https://www.tp-link.com/support/faq/46/ T2. Can’t find or connect to the wireless networks: https://www.tp-link.com/support/faq/2253/ T3. Can’t install the driver: https://www.tp-link.com/support/faq/2252/ T4. Using Windows 11 version 22H2 or earlier and the adapter can’t function properly: https://www.tp-link.com/support/faq/4367/ 2 Install Driver a. Go to My Computer or This PC. b. Double-click the TP-Link CD Drive then run SetupInstall.exe to install driver. Note: • If you cannot find the setup program, please download the driver at www.tp-link.com/support. You can also check for new releases and download the latest drivers on this website. • If an unknown publisher message pops up, select Ye s to continue. • If Windows User Account Control requires admin credentials, type user name and password of your Windows administrator account. SetupInstall.exe 3 Join a Wireless Network a. Click the network icon on the taskbar (the icon might look like one of these: , , , or ). b. Select your Wi-Fi network, click Connect and enter the password when prompted. Network 6 Connected Network settings Connect automatically Connect √ TP-Link_XXXX TP-Link hereby declares that the Wireless USB Adapter is in compliance with the essential requirements and other relevant provisions of directives 2014/53/EU, 2011 /65/EU and (EU) 2015/863. The original EU Declaration of Conformity may be found at https://www.tp-link.com/en/support/ce TP-Link hereby declares that the Wireless USB Adapter is in compliance with the essential requirements and other relevant provisions of the Radio Equipment Regulations 2017. The original UK Declaration of Conformity may be found at https://www.tp-link.com/support/ukca Safety Information · Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us. · Do not use the device where wireless devices are not allowed. · Keep the device away from water, fire, humidity or hot environments. · This equipment can be powered only by equipments that comply with Power Source Class 2 (PS2) or Limited Power Source (LPS) defined in the standard of IEC 62368-1. Troubleshooting ?

FCC compliance information statement Product Name: BE6500 Tri-Band Wi-Fi 7 High Gain Wireless USB Adapter Model Number: Archer TBE400U Plus Responsible Party: TP-Link Systems Inc. Address: 10 Mauchly, Irvine, CA 92618 Website: http://www.tp-link.com/us/ Tel: +1 626 333 0234 Fax: +1 909 527 6804 E-mail: [email protected] This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/ TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. FCC RF Radiation Exposure StatementThis equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment has been SAR-evaluated for use in hand. SAR measurements are based on a 5mm spacing from the body and that compliance is achieved at that distance. FCC regulations restrict the operation of this device to indoor use only. Operation of transmitters in the 5.925-7.125 GHz band is prohibited for control of or communications with unmanned aircraft systems. We, TP-Link Systems Inc., has determined that the equipment shown as above has been shown to comply with the applicable technical standards, FCC part 15. There is no unauthorized change is made in the equipment and the equipment is properly maintained and operated. Issue Date: 2025-09-15 Canadian Compliance Statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1) L’appareil ne doit pas produire de brouillage; 2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Caution: 1） The device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems; DFS (Dynamic Frequency Selection) products that operate in the bands 5250- 5350 MHz, 5470-5725MHz. Avertissement: 1） Le dispositif fonctionnant dans la bande 5150-5250 MHz est réservé uniquement pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux; Les produits utilisant la technique d'atténuation DFS (sélection dynamique des fréquences) sur les bandes 5250- 5350 MHz, 5470-5725MHz.  Devices shall not be used for control of or communications with unmanned aircraft systems.  Les appareils ne doivent pas être utilisés pour le contrôle ou la communication avec des systèmes d'aéronefs sans pilote.  Radiation Exposure Statement:  This EUT is compliance with SAR for general population/uncontrolled exposure limits in RSS-102 and had been tested in accordance with the measurement methods and procedures specified in IEEE 1528 and IEC 62209. This equipment should be installed and operated with minimum distance 0.5 cm between the radiator and your body. This device  and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter.   Déclaration d'exposition aux radiations :  Cet adaptateur est conforme au SAR pour la population générale/limites d'exposition non contrôlées dans RSS-102 et a été testé conformément aux méthodes et procédures de mesure spécifiées dans IEEE 1528 et CEI 62209. Cet équipement doit être installé et ut ilisé avec une distance minimale de 5 mm entre le radiateur et votre corps. Cet appareil et ses antennes ne doivent pas être situés ou fonctionner en conjonction avec une autre antenne ou un autre émetteur. CE Mark Warning OPERATING FREQUENCY (the maximum transmitted power) 2400 MHz -2483.5 MHz (20dBm) 5150 MHz -5250 MHz (23dBm) 5250 MHz -5350 MHz (23dBm) 5470 MHz -5725 MHz (23dBm) 5945MHz -6425 MHz (23dBm) EU Declaration of Conformity TP-Link hereby declares that the BE6500 Tri Band Wi-Fi 7 Mini Wireles…
