2BH7FWR1502XV2AX1500 Wi-Fi 6 Portable Router

© 2024 TP-Link REV1.0.0 1910013612 User Guide Wi-Fi 6 Portable Router TL-WR1502X Contents About This Guide .........................................................................................................1 Chapter 1. Get to Know About Your Router . . . . . . . . . . . . . . . . . . . . . . . . . . .3 1. 1. Product Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 1. 2. Appearance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Chapter 2. Connect the Hardware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 2. 1. Position Your Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 2. 2. Connect Your Router. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 2. 2. 1. Router Mode (Default) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 2. 2. 2. 3G/4G USB Modem / USB Tethering Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 2. 2. 3. Hotspot Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 2. 2. 4. Access Point Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 2. 2. 5. Range Extender Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 2. 2. 6. Client Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 Chapter 3. Set Up Internet Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 3. 1. Set up via Tether . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 3. 2. Set up via the Web Management Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 3. 2. 1. Log in to the Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 3. 2. 2. Configure the Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14 Chapter 4. Configure the Router in Router/USB Internet Mode. . . . . . 19 4. 1. Operation Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 4. 2. Network Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 4. 3. Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 4. 3. 1. Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 4. 3. 2. Internet Settings for Router Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 4. 3. 3. NAT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34 4. 3. 4. Internet Port Negotiation Speed Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35 4. 3. 5. Internet Settings for 3G/4G USB Modem Mode . . . . . . . . . . . . . . . . . . . . . . .35 4. 3. 6. Internet Settings for USB Tethering Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . .37 4. 3. 7. LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38 4. 3. 8. IGMP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39 4. 3. 9. DHCP Server. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40 4. 3. 10. Dynamic DNS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42 4. 3. 11. Static Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43 4. 3. 12. Multi-WAN Backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46 4. 4. TP-Link Cloud Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48 4. 4. 1. Register a TP-Link ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49 4. 4. 2. Change Your TP-Link ID Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50 4. 4. 3. Manage the User TP-Link IDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52 4. 4. 4. Manage the Router via the TP-Link Tether App. . . . . . . . . . . . . . . . . . . . . . . .53 4. 5. Wireless. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54 4. 5. 1. Wireless Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54 4. 5. 2. Guest Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55 4. 5. 3. Wireless Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57 4. 5. 4. WPS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57 4. 5. 5. Additional Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59 4. 6. USB Storage Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

TP-Link Systems Inc. 092723-17 rev 10 Certification Application Attestation Statements Date: December 10, 2025 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) ______TP-Link Systems Inc._____ certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) ______TP-Link Systems Inc._____ (“the applicant”) certifies that, as of the date of the filing of this application, the applicant ☐ - is / - is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates – see KDB 986446 Question 5) as an entity producing “covered” equipment. The applicant also certifies that the device does not have cybersecurity and/or anti-virus software produced by Kaspersky Lab, Inc or any of its successors and assignees identified on the covered list installed on the device, nor will it be installed by the applicant at any time after certification. Thank you, By: __________________________ _______ Sarah Wang _________________ (Signature 2 ) (Print name) Title: _____ Regulatory Compliance Manager _____________________ Company: ___ TP-Link Systems Inc. ______ Telephone: __+86 755 21534921_______________________ 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . 2 - Letters must be placed on appropriate letterhead.

TP-Link Systems Inc. U.S. Agent Designation for Service of Process TO: American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information This letter is to confirm that the Applicant will also serve as the U.S. Agent for Service of Process as required by 47 CFR 2.911(d)(7). The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The Applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information changes. Applicant Company name: TP-Link Systems Inc. FRN #: 0035788017 Grantee Code: 2BH7F FCC ID: 2BH7FDL105 Contact Name: Sarah Wang Street Address: 10 Mauchly, Irvine, CA 92618 City/Province/Zip: Irvine, CA 92618 Telephone No: (626) 333-0234 Email: [email protected] Applicant Signature: Date:2025-08-13 Signed by (Printed Name/Title): Sarah Wang/ Product Compliance Manager

TP-Link Systems Inc. 030122-15 Authority to Act as Agent Date: December 10, 2025 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: BTL Inc./Rose Liu is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) with regard to certified equipment. Thank you, Agency Agreement Expiration Date: 2026.12.10 By: __________________________ Sarah Wang (Signature 1 ) (Print name) Title: Regulatory Compliance Manager On behalf of: TP-Link Systems Inc. (Company Name) Telephone: 6263330234 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

TP-Link Systems Inc. 030122-15 Request for Confidentiality Date: December 10, 2025 Subject: Confidentiality Request for: 2BH7FWR1502XV2 Pursuant to FCC 47 CFR 0.457(d) and 0.459 and IC RSP-100, Section 12.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☒ Permanent Block Diagrams ☐ Short Term External Photos ☐ Short Term ☐ Permanent * 1 Internal Photos ☐ Short Term ☒ Permanent Operation Description/Theory of Operation ☐ Short Term ☐ Permanent Parts List & Placement/BOM ☐ Short Term ☐ Permanent Tune-Up Procedure ☐ Short Term ☒ Permanent Schematics ☐ Short Term Test Setup Photos ☐ Short Term ☐ Permanent * 3 User’s Manual TP-Link Systems Inc. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: IC currently only distinguishes Permanent Confidentiality exhibits as shown above. Short Term confidentiality is not considered applicable to IC applications. Sincerely, By: Regulatory Compliance Manager Sarah Wang (Signature/Title 3 ) (Print name) 1 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. 2 - Please refer to https://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

TP-Link Systems Inc. Wi-Fi Channel 12 and 13 Declaration Letter Date: 2025-12-10 We, the undersigned company Company Name: TP-Link Systems Inc. Address: 10 Mauchly, Irvine, CA 92618 Irvine California United States 92618 Declare that: Product description: AX1500 Wi-Fi 6 Portable Router Type designation: TL-WR1502X Brand: tp-link FCC ID: 2BH7FWR1502XV2 Only channels 1~11 will be used in USA. Country code selection is disabled. If you have any questions regarding the authorization, please do not hesitate to contact us, thank you~ Sincerely, Signature: ________________________ Name: Sarah Wang Tel: 6263330234 Email: [email protected]

Declaration of Conformity We Name: TP-Link Systems Inc. Address: 10 Mauchly, Irvine, CA 92618 Irvine California United States 92618 Declare that: Product: AX1500 Wi-Fi 6 Portable Router FCC ID: 2BH7FWR1502XV2 Model: TL-WR1502X Brand: tp-link Product which bears the above FCC ID is also compliant with the FCC requirements for sDOC. And the sDOC procedure shall be carried out prior to marketing the device in the US. Sincerely, Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2025-12-10

Project No.: 2508C642 Page 2 of 14 Project No.: 2508C642 Page 3 of 14 Project No.: 2508C642 Page 4 of 14 Project No.: 2508C642 Page 5 of 14 Project No.: 2508C642 Page 6 of 14 Project No.: 2508C642 Page 7 of 14

28.2 mm 5.7 mm Model: TL-WR1502X AX1500 Wi-Fi 6 Portable Router Power: 5V 3A Default Access: http://tplinkwifi.net JOIN PRESET WI-FI Model:TL-WR1502X S/N:XXXXXXXXXXXXX US/2.0 MAC: XX-XX-XX-XX-XX-XX Wireless Password/PIN : XXXXXXXX SSID:TP-Link_XXXX SSID:TP-Link_XXXX_5G MADE IN CHINA FCC ID: 2BH7FWR1502XV2 IC: 32876-WR1502XV2 HVIN: TL-WR1502XV2 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Project No.: 2508C642 Page 1 of 14 ATTACHMENT PHOTOGRAPHS OF EUT Project No.: 2508C642 Page 8 of 14 Ant.1 Ant.2 Project No.: 2508C642 Page 9 of 14 Project No.: 2508C642 Page 10 of 14 Project No.: 2508C642 Page 11 of 14

Project No.: 2508C642 Page 12 of 14 Project No.: 2508C642 Page 13 of 14 Project No.: 2508C642 Page 14 of 14

Report No.: BTL-FCCP-4-2508C642 Report Version: R00 Page 1 of 4 FCC RF EXPOSURE REPORT FCC ID: 2BH7FWR1502XV2 Project No. : 2508C642 Equipment : AX1500 Wi-Fi 6 Portable Router Brand Name : tp-link Test Model : TL-WR1502X Model Name : TL-WR1502X Hardware Version : 2.0 Software Version : 2.0 Applicant : TP-Link Systems Inc. Address : 10 Mauchly, Irvine, CA 92618 Manufacturer : TP-Link Systems Inc. Address : 10 Mauchly, Irvine, CA 92618 Date of Receipt : Aug. 22, 2025 Date of Test : Aug. 26, 2025 ~ Nov. 10, 2025 Issued Date : Dec. 09, 2025 Test Sample : Engineering Sample No.: DG920250821198 Standard(s) : FCC Guidelines for Human Exposure IEEE C95.1 & FCC Part 2.1091 FCC Title 47 Part 2.1091 & KDB 447498 D01 v06 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. (Dongguan) Prepared by : Terry Deng Approved by : Chay Cai No.3, Jinshagang 1st Road, Dalang, Dongguan, Guangdong People’s Republic of China. Te l : + 8 6-769-8318-3000 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-4-2508C642 Report Version: R00 Page 2 of 4 REVISION HISTORY Report No. Version Description Issued Date Note BTL-FCCP-4-2508C642 R00 Original Report. Dec. 09, 2025 Valid Report No.: BTL-FCCP-4-2508C642 Report Version: R00 Page 3 of 4 1. MPE CALCULATION METHOD Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna 2. ANTENNA SPECIFICATION For 2.4GHz: Ant. Manufacturer P/N Antenna Type Connector Gain (dBi) 1 tp -link N/A Dipole IPEX 3.35 2 tp -link N/A Dipole IPEX 3.18 Note: 1) This EUT supports CDD, and all antenna gains are not equal, Directional gain = G ANT +Array Gain. For power measurements, Array Gain=0dB (N ANT ≤4), so the Directional gain=3.35. 2) The antenna gain is provided by the manufacturer For 5GHz: Ant. Brand Model Name Antenna Type Connector Gain (dBi) Note 1 tp -link N/A Dipole IPEX 2.78 UNII-1 3.15 UNII-2A 3.02 UNII-2C 3.48 UNII-3 2 tp -link N/A Dipole IPEX 4.21 UNII-1 4.17 UNII-2A 4.84 UNII-2C 3.92 UNII-3 Note: 1) This EUT supports CDD, and all antenna gains are not equal, Directional gain = G ANT +Array Gain. For power measurements, Array Gain=0dB (N ANT ≤4), so the UNII-1 Directional gain=4.21, the UNII-2A Directional gain=4.17, the UNII-2C Directional gain=4.84, the UNII-3 Directional gain=3.92. 2) Beamfroming Gain is 3dB. 3) The antenna gain and beamforming gain are provided by the manufacturer. Report No.: BTL-FCCP-4-2508C642 Report Version: R00 Page 4 of 4 3. CALCULATED RESULT For 2.4GHz: Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 3.35 2.1627 26.85 484.1724 0.2084 1 Complies For 5GHz: Band Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result UNII-1 4.21 2.6363 26.87 486.4072 0.2552 1 Complies UNII-2A 4.17 2.6122 23.87 243.7811 0.1268 1 Complies UNII-2C 4.84 3.0479 23.57 227.5097 0.1380 1 Complies UNII-3 3.92 2.4660 25.85 384.5918 0.1888 1 Complies For the max simultaneous transmission MPE: Ratio Total Limit of Ratio Test Result 2.4GHz 5GHz 0.2084 0.2552 0.4636 1 Complies Note: (1) The calculated distance is 20 cm. (2) Ratio=Power Density (S) (mW/cm 2 )/Limit of Power Density (S) (mW/cm 2 ) End of Test Report
