dsdevices.com Model DSDX5 User Manual Thank you for choosing DSDevices DSDX5 Media Player. This manual provides instructions to help you get the most out of your device. Please read it carefully before using it and retain it for your reference. We have made every effort to provide the most current information about the device. The information contained here is an instruction intended to enable the correct usage and maintenance of the device. We reserve the right to introduce amendments, changes, or translations of the user manual without prior notification. For this reason, we recommend you regularly visit our website to obtain the latest information dsdevices.com Contents Chapter 1 System Introduction 1.1 - Key Features 1.2 - Environment for Device 1.3 - Package Contents Chapter 2 Remote Controller 2.1 - Introduction of Remote Chapter 3 System Connection 3.1 - AV Connection 3.2 - HDMI Connection dsdevices.com Chapter 1 System Introduction 1.1 - Key Features The device is a cost effective Android digital signage player Support for 4K@60fps video playback with AV1, HDR10/10+, H.265, VP9 and HLG formats Support SD/SDHC/MMC cards Supports 2 x USB 2.2 host connectors with maximum output current of 1.5A/5V Support standard RJ45 cable network connection and wireless network connection Support infrared remote controller operation 1.2 - Environment for Device Operating Temperature: -10°C to 75°C 1.3 - Package Contents 1 x DSDX5 Media Player 1 x Power Adapter 1 x HDMI Cable 1 x IR Remote Controller dsdevices.com Chapter 2 Remote Controller 2.1 - Introduction of Remote dsdevices.com Chapter 3 System Connection 3.1 - AV Connection 3.2 - HDMI Connection FCC Caution. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. *RF warning for Mobile device: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

Page 1 of 32 Report No.: AiTSZ-250919106FW4 Note: This device has been tested and found to comply with the standard(s) listed, this test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. This report shall not be reproduced except in full, without the written approval of Dongguan Yaxu (AiT) Technology Limited. If there is a need to alter or revise this document, the right belongs to Dongguan Yaxu (AiT) Technology Limited, and it should give a prior written notice of the revision document. This test report must not be used by the client to claim product endorsement.. Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang,Dongguan, Guangdong, China TEST REPORT Product Name : Mini PC Media Player Brand Name : DSDevices, World TV Model : DSDX5 Series Model : WTVX5 FCC ID : 2BH9J-DSDX5 Applicant : EV4 Ltd Address : KAD HOUSE PORTSMOUTH ROAD ESHER SURREY KT10 9AD UK Manufacturer : Shenzhen Tomato Technology Co., Ltd Address : 1106, Huatong Building, Sungang East Rd, Guiyuan Street, Luohu District, Shenzhen, Guangdong, China Standard(s) : FCC CFR Title 47 Part 15 Subpart E Section 15.407 Date of Receipt : Sep.19, 2025 Date of Test : Sep.19, 2025~ Nov.04, 2025 Issued Date : Dec.04, 2025 Issued By: Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang,Dongguan, Guangdong, China Tel.: +86-769-8202 0499 Fax.: +86-769-8202 0495 Reviewed by: Approved by: Emiya Lin Simba Huang Page 2 of 32 Report No.: AiTSZ-250919106FW4 Report Revise Record Report Version Issued Date Notes M0 Dec.04, 2025 Initial Release Page 3 of 32 Report No.: AiTSZ-250919106FW4 Contents 1 TEST SUMMARY ....................................................................................................................................................... 4 1.1 TEST STANDARDS ......................................................................................................................................................... 4 1.2 TEST SUMMARY ........................................................................................................................................................... 4 1.3 TEST FACILITY .............................................................................................................................................................. 5 1.4 MEASUREMENT UNCERTAINTY ........................................................................................................................................ 5 2 GENERAL INFORMATION .......................................................................................................................................... 6 2.1 ENVIRONMENTAL CONDITIONS ........................................................................................................................................ 6 2.2 GENERAL DESCRIPTION OF EUT ...................................................................................................................................... 6 2.3 DESCRIPTION OF TEST MODES AND TEST FREQUENCY .......................................................................................................... 7 2.4 SPECIAL ACCESSORIES ................................................................................................................................................... 7 2.5 EQUIPMENT LIST FOR THE TEST ....................................................................................................................................... 8 3 TEST CONDITIONS AND RESULTS .............................................................................................................................. 9 3.1 CONDUCTED EMISSIONS TEST ......................................................................................................................................... 9 3.2 RADIATED EMISSIONS AND BAND EDGE .......................................................................................................................... 12 3.3 MAXIMUM CONDUCTED AVERAGE OUTPUT POWER ......................................................................................................... 23 3.4 POWER SPECTRAL DENSITY .......................................................................................................................................... 25 3.5 EMISSION BANDWIDTH (26DBM BANDWIDTH) ................................................................................................................ 27 3.6 MINIMUM EMISSION BANDWIDTH (6DBM BANDWIDTH) .................................................................................................. 28 3.7 FREQUENCY STABILITY ................................................................................................................................................. 29 3.8 ANTENNA REQUIREMENT ............................................................................................................................................. 30 4 TEST SETUP PHOTOGRAPHS OF EUT ....................................................................................................................... 31 5 PHOTOS OF EUT ..................................................................................................................................................... 32 Page 4 of 32 Report No.: AiTSZ-250919106FW4 1 TEST SUMMARY 1.1 Test Standards The tests were performed according to following standards: FCC Rules Part 15 Subpart E—Unlicensed National Information Infrastructure Devices. ANSI C63.10: 2020: American National Standard for Testing Unlicensed Wireless Devices KDB789033 D02: General UNII Test Procedures New Rules v02r01. 1.2 Test Summary FCC Requirement FCC Part 15.207 AC Power Conducted Emission PASS FCC Part 15.407(a) Emission Bandwidth(26dB Bandwidth) PASS Note1 FCC Part 15.407(e) Minimum Emission Bandwidth(6dB Bandwidth) PASS Note2 FCC Part 15…
