2BH9O-MIJICRemote control

Product User Manual Product Name: Intelligent Toilet Model: K1 Thank you for purchasing our product . Please read this manual before installation and use to ensure that your product will function at peak performance . Read this manual thoroughly and store in a safe place for future references . Smart Toilet IMPORTANT SAFEGUARDS When using electrical products ,especially when children are present , basic safety precautions should always be followed , including the following READ ALL INSTRUCTIONS BEFORE USING DANGER - To reduce the risk of electrocution 1.Do not use while bathing 2.Do not place or store product where it can fall or be pulled into a tub or sink 3.Do not place in or drop into water or other liquid 4.Do not reach for a product that has fallen into water . Unplug immediately WARNING- To reduce the risk of burns , electrocution ,fire or injury to persons 1.Close supervision is necessary when this product is used by ,on ,or near children or invalids 2.Use this product only for its intended use as described in this manual . Do not use attachments not recommended by the manufacturer. 3.Never operate this product if it has a damaged cord or plug , if it is not working properly , if it has been dropped or damaged , or dropped into water . Return the product to a service center for examination and repair . 4.Keep the cord away from heated surfaces 5.Never block the air openings of the product or place it on a soft surface , such as a bed or couch ,where the air openings may be blocked. Keep the air openings free of lint, hair , and the like. 6.Never use while sleeping or drowsy 7.Never drop or insert any object into any opening or hose 8.Do not use outdoors or operate where aerosol(spray)products are being used or where oxygen is being administered 9.Connect this product to a properly grounded outlet only . See grounding Instructions 10.Do not use while bathing 11.Risk of Electric shock. Connect only to a grounding type receptacle protected by a ground-fault circuit-interrupter(GFCI) 12.CAUTION- Risk of electric shock , do not remove cover (or back).Refer servicing to qualified service personnel . SAVE THESE INSTRUCTIONS GROUNDING INSTRUCTIONS This product should be grounded . In the event of an electrical short circuit , grounding reduces the risk of electric shock by providing an escape wire for the electric current . This product is equipped with a cord having a grounding wire with a grounding plug . This plug must be plugged into an outlet that is properly installed and grounded . DANGER-Improper use of the grounding plug can result in a risk of electric shock If repair or replacement of the cord or plug is necessary ,do not connect the grounding wire to either flat blade terminal . The wire with insulation having an outer surface that is green with or without yellow stripes is the grounding wire. Check with a qualified electrician or serviceman if the grounding instructions are not completely understood , or if in doubt as to whether the product is properly grounded . The functions may vary from different part no Category Functions Female Washing Hip Cleaning Massage Washing Moving Washing Self-cleaning nozzle One key stop Position Adjustment Water heated instantly Seat Induction Seat Heating Warm air drying Wind temperature adjustment Water temperature adjustment Water pressure adjustment Automatic flushing Flush during power failure Mute slow down Night light Leakage protection Energy saving Double filtration One key side knob Anti-fouling glaze Flame retardant material 12V safety voltage Remote control Anti bacterium seating Digital desplay screen Foot sensor flushing Decorated light Baby mode Foot sensor open seat Foot sensor open cover Auto open cover Baby seating Convenience Safety User Friendly design New features to offer you an enjoyable experience Contents Parts information Overview Rotated switch Remote control Warnings and safety Warming Attention Installation Before you install Installing your product Function explanations Maintenance Surface cleaning Nozzle maintenance Troubleshooting Power button Wash functions Dryer Heated seat Remote control Toilet unit Soft-closing feature Specifications ------- 1 ------------- 2 --------- 1 -------- 2 ----- 1 ------------- 2 ------------- 1 ------------ 1 ------- 2 ---- 1 ---- 2 ---------- 1 ------- 2 ----- 1 -------- 1 ---------- 2 -------- 1 --------------- 2 ---------- 1 -------- 2 ------------ 1 ----- 1 --------- 2 Rotated Switch Caution Label Rotated Switch Power plug T-valve Water valve Hose Lid Warm Dryer Cleaner(Hip & Female wash) The heating seat Toilet Part Information Smart Toilet Hip Cleaning Female washing D N20 D N15 Pressure stabilizing valve Remote control / 4 degrees can adjust the wind tempature the tempature can be set as , one degree: the enviroment tempature, second degree:about 35,°C Third degree :about 45,°C Forth degree : about 55.°C Wind temperature You can stop the "Hip cleaning' "Female cleaning", "brying"and other operaation when operation Power/Stop Press this button to start drying when you are seated. Warm air drying will stop automatically affer 3 minutes. Warm air drying Press this button and will start flushing. Flush After the baby is seated then press the baby wash button ,it will start the hip cleaning automaticly , and the washing pressure will be adjust to the lowest level automaticly ,it will change to mobile cleaning when press one more time , and auto close the baby washing when you press the " stop " button Baby wash Press this button when you are seated, the Hip wash cleaning nozzle will spray at the fixed position for 2 minutes and then stop spraying automatically. Hip Cleaning Press this button during the "hip" or. "female" cleaning and adjust the nozzle position without the use of the removable cleaning function. Adjustment Nozzle extended and water out for nozzle washing Self-cleaning 4 degrees can adjust the water tempature , the tempature can be set as, one degree : the envirom…

Text truncated - open the document above for the full version.

Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room101/301/401/102/202/302/402/502/602/702/802, No. 7-2, Caipin Road, Huangpu District, Guangzhou, Guangdong, China Job No.: 240725107GZU FCC ID: 2BH9O-MIJIC RF Exposure Compliance Requirement Calculation formula： E (V/m) = (30*P*G) 0.5/d E = Electric Field (V/m) P = Peak RF output Power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between EUT and antenna (m) Remark: E(V/m)=10 X (dBUV/m) /20 ×10 -6 P=(E*d) 2 /30G in the formula above, d=3m, field strength= 77.2dBuV/m (max described by client), So P=0.016mW The worst case test separation distance is 5mm. The product belongs to standalone portable device base the FCC rule part 2.1091&2.1093. The transmission frequencies of the device are between 100 MHz and 6 GHz. In KDB 447498 D01 v06: 4.3.1 Standalone SAR test exclusion considerations: The SAR Test Exclusion Threshold is calculated from: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR ⚫ f(GHz) is the RF channel transmit frequency in GHz ⚫ Power and distance are rounded to the nearest mW and mm before calculation 17 ⚫ The result is rounded to one decimal place for comparison The Max Conducted Output Power and SAR Test Exclusion Threshold (mW) are listed below: Transmit Frequency (MHz) Output power (mW) SAR Test Exclusion Threshold (mW) 315 0.016 26.73 According to SAR Exclusion Threshold in KDB 447498 (D01) General RF Exposure Guidance v06, the SAR report is not required. Test Location: Intertek Testing Services Shenzhen Ltd. Guangzhou Branch All tests were performed at: Room102/104, No 203, KeZhu Road, Science City, GETDD Guangzhou, China

Guangdong Minjie Sanitary Ware Co., Ltd. TEST REPORT SCOPE OF WORK EMC TESTING–HW01 REPORT NUMBER 240725107GZU-001 ISSUE DATE [REVISED DATE] 02-September-2024 [--------------------] PAGES 20 DOCUMENT CONTROL NUMBER FCC Part 15.231 © 2017 INTERTEK TEST REPORT Room101/301/401/102/202/302/ 402/502/602/702/802, No. 7-2, Caipin Road, Huangpu District, Guangzhou, Guangdong, China Telephone: +86 20 8213 9688 Facsimile: +86 20 3205 7538 www.intertek.com.cn This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room101/301/401/102/202/302/402/502/602/702/802, No. 7-2, Caipin Road, Huangpu District, Guangzhou, Guangdong, China Version: 26 August 2024 Page 2 of 20 FCC Part 15.231 Applicant Name & Address : Guangdong Minjie Sanitary Ware Co., Ltd. Chengongwei, Nanmen Village, FengTang, Chaoan District, Chaozhou City,Guangdong,China, Manufacturing Site : Same as applicant Intertek Report No: FCC ID: 240725107GZU-001 2BH9O-MIJIC Test standards FCC PART 15 Subpart C: 2023 section 15.231 Sample Description Product : Remote control Model No. : HW01 Electrical Rating : DC4.5V Serial No. : Not Labeled Date Received : 25 July 2024 Date Test Conducted : 21 August 2024 Prepared and Checked By Elena Lei Project Engineer Approved By: Dean Liu Sr. Project Engineer TEST REPORT Intertek Report No.: 240725107GZU-001 Version: 26 August 2024 Page 3 of 20 FCC Part 15.231 CONTENT TEST REPORT ........................................................................................................................... 1 CONTENT ............................................................................................................................. 3 1.0 TEST RESULT SUMMARY ............................................................................................ 4 2.0 GENERAL DESCRIPTION ............................................................................................. 5 2.1 PRODUCT DESCRIPTION ........................................................................................................ 5 2.2 RELATED SUBMITTAL(S) GRANTS ........................................................................................... 5 2.3 TEST METHODOLOGY .......................................................................................................... 5 2.4 TEST FACILITY ..................................................................................................................... 5 3.0 SYSTEM TEST CONFIGURATION ................................................................................. 6 3.1 JUSTIFICATION .................................................................................................................... 6 3.2 EUT EXERCISING SOFTWARE ................................................................................................. 7 3.3 SPECIAL ACCESSORIES .......................................................................................................... 7 3.4 MEASUREMENT UNCERTAINTY .............................................................................................. 7 3.5 EQUIPMENT MODIFICATION ................................................................................................. 7 3.6 SUPPORT EQUIPMENT LIST AND DESCRIPTION .......................................................................... 8 4.0 MEASUREMENT RESULTS ..................................................................................................... 9 4.1 ANTENNA REQUIREMENT ..................................................................................................... 9 4.2 RADIATED EMISSIONS ........................................................................................................ 10 4.3 OCCUPIED BANDWIDTH ..................................................................................................... 17 4.4 DWELL TIME .................................................................................................................... 18 4.5 CONDUCTED EMISSION TEST ............................................................................................... 19 5.0 TEST EQUIPMENT LIST ............................................................................................. 20 TEST REPORT Intertek Report No.: 240725107GZU-001 Version: 26 August 2024 Page 4 of 20 FCC Part 15.231 1.0 TEST RESULT SUMMARY Test Item Test Requirement Test Method Result Radiated Emission FCC PART 15 section 15.231(b) ANSI C 63.10: Clause 6.4, 6.5 and 6.6 PASS Occupied Bandwidth FCC PART 15 section 15.231(c) ANSI C 63.10: Clause 6.9 PASS Dwell Time FCC PART 15 section 15.231(a) FCC PART 15: Section 15.231(a) PASS Conducted Emission FCC PART 15 section 15.207 ANSI C 63.10: Clause 6.2 N/A Remark: N/A: not applicable. Refer to the relative section for the details. EUT: In this whole report EUT means Equipment Under Test. Tx: In this whole report Tx (or tx) means Transmitter. Rx: In this whole report Rx (or rx) means Receiver. RF: In this whole report RF means Radio Frequency. ANSI C63.10: the detail version is ANSI C63.10:2013 in the whole report TEST REPORT Intertek Report No.: 240725…

Text truncated - open the document above for the full version.

Radiated Emission (30MHz-1GHz) Radiated Emission (Above 1GHz) Remark: The EUT is center on the turntable, due to the edge of desk placed on the diameter of the turntable.
