Wireless HDMI Transmitter & Receiver kit User manual Ver. B 1 .1 presenta�on. But not recommended for playing games that have high requirement for low latency, may have a li�le influence on some games. *Note: lf the above QA does not solve your problem, please contact our customer service. Preface Thank you for purchasing the products, For optimum operation, please read this manual carefully before use. Computer video output status indication HD Signal strength indication Function Button 1.Single press to Pause/ Start screen projection 2.Press and hold for 6 seconds to pair the Transmitter and Receiver. Strong: three LEDs light Good: Two LEDs light Weak: One LED light The following are common alarm states: 1.The power supply current of computer graphics card HDMI output is insufficient. 2.Poor contact with computer HDMI port Blinking: No video output is displayed Light on: Video Detected RX connection status indication Blinking: Not connected Light on: Connection Successful Transmitter-TX Power Supply Port Product Overview Common States for No Video Output: 1.Computer enters screensaver 2.Computer output set to “Computer Screen Only” 3.Poor contact with computer HDMI port Insufficient power alarm indication Red light on:the power supply is insufficient. You need to plug in a Type-C to provide power supply. Light off:The power supply is normal Q:Why does the image appear to shake/disconnect? A:Please make sure you are using a 5V/2A power supply. Unstable currents from power banks and some computers can lead to image shaking issues. Switch to a 5V/2A power supply before use. Q:What is the usage of the LED display on transmi�er? A:You can view Power Status, Connec�on Status, Signal Strength, Video Output Status on the LED display. Q:How to restore and repair the device? A:1.When the product fails, Receiver func�on bu�on, long press for 6 seconds. A�er a black screen appears and restart, the factory se�ngs will be restored. 2.Transmi�er func�on bu�on, long press for 6 seconds, un�l the indicator lights off for 1second, then the indicator will flash for pairing, wait for the transmi�er indicator to be always on, indica�ng that the connec�on is successful. Q:How to enter privacy mode? A:Tap the transmi�er func�on bu�on to disconnect or reconnect. Q:Incompa�bility with my smartphone/tablet? Does it support cameras/DV? A:This product only supports usage with computers, laptops, TV boxes, cameras, DV and other devices with HDMI interfaces. It does not support most smartphones/tablets or iPads, unless the smartphone/tablet Type-C Q:Unable to connect, con�nuously searching for signal sources? A:Please ensure correct product connec�ons. TX and RX should be connected appropriately. If the playback device displays a black screen or con�nuously shows an HDMI signal connec�on, note that TX is the signal transmi�ng end for connec�ng output devices (such as computers and laptops), while RX is the signal receiving end for connec�ng playback devices. Q:How should the connec�on be setup? A:During the product connec�on process, the signal light will flash.Once successfully connected, the signal light will stop flashing. Do not press the bu�ons on the transmi�er during the connec�on process. Holding down the transmi�er bu�on for an extended period without releasing it will caused pairing failure with the receiver and preven�ng screen mirroring. Q:Why is the connec�on not stable some�mes? A:Please make sure the power supply for each transmi�er and receiver is both 5V/2A, because if the power supply from either side is not sufficient, the HDMI transmi�er & receiver will disconnect. Problem Solving support DisplayPort(DP) protocol. Please use cameras/DV HDMI converters to connect cameras & DV. Q:Unclear video quality and inability to play 4K videos? A:The product supports 4K decoding but outputs at 1080P. The op�mal transmission effect is 4K, but the actual video quality is influenced by the hardware of your devices. Q:Can devices without HD interface be used? A:Yes,please use the device with an HD interface converter. Q:Maximum transmission distance and latency effects? A:The product's maximum transmission distance is 100 feet/30 meters. With a latency of less than 0.1 second. A stable 5V/2A power supply is required during use to ensure consistent signal transmission. Q:Does the wireless HDMI transmi�er and receiver have latency? A:All wireless transmi�ers have some slight delay, the latency is lower than 0.1s which is hard to feel. There is not influence for watching movies/ business The product has been paired out of the factory. In case of pairing failure due to improper operation or other circumstances during use, it is necessary to restore and repair the device as follows: *Note: An RX can be paired with up to seven TXS. *Please make sure that the power of the computer is suffcient. If the power supply of the computer is insuffcient or HD is unable to supply power , please connect the transmitter to the power adapter or power supply port ( Voltage above 5V , current above 2A ) Pairing Instructions Transmitter [TX] - Function Button Receiver [RX] Function Button 1.Receiver RX-Function Button, long press for more than 6 seconds, after a black screen appears and restart, enter pairing mode. 2.Transmitter TX-Function Button, long press for 6 seconds, until the indicator lights off for 1second, then the indicator will flash for pairing, wait for the transmitter indicator to be always on, indicating that the connection is successful. Combination of receiver and transmitter, plug and play 1. Connect the HD port of the receiver to the video input port of the display device such as the monitor or TV. 2. Connect the power supply port of the receiver to the charging cable and plug it into the power adapter ( Voltage above 5V, current above 2A) 3. Adjust the HD Signal source of the monitor or TV to the corresponding HD port until the boot screen is displayed. 4. Connect the transmitter to the computer or other devices …

Text truncated - open the document above for the full version.

LexiangzheTechnology(Shenzhen)Co.,LTD Address：Room301,Building6,2013ChuangyeValley,HenggangStreet,LonggangDistrict, Shenzhen FRN:0035614783 Date:2024-07-15 FederalCommunicationsCommission AuthorizationandEvaluationDivision 1435OaklandMillsRoad Columbia,MD21046 Ref:AttestationStatementsPart2.911(d)(7)Filing SUBJECT:FCCApplicationforFCCID:2BHAZ-WTR21 (“LexiangzheTechnology(Shenzhen)Co.,LTD”)certifiesthat,asofthedateofthefilingof theapplication,(JOCAustraliaInc)isourdesignatedU.S.agentforserviceofprocessfor the abovereferencedFCCID.(“LexiangzheTechnology(Shenzhen)Co.,LTD”)acceptsto maintainanagentfornolessthanoneyearafterthegranteehasterminatedallmarketing andimportationorthe conclusionofanyCommission-relatedproceedinginvolvingtheequipment. ( JOCAustraliaInc )accepts,asofthedateofthefilingoftheapplication,theobligationofthe designatedU.S.agentforserviceofprocessfortheabovereferencedFCCID. DesignatedU.S.AgentInformation: Name:JOCAustraliaInc FRN:0033379421 Address:CASTLETONSTSTE665,CITYOFINDUSTRYCA,CA91748United States ContactPerson:Benjamin.Smith/VicePresident Tel.:+1(626)341-3408 Email:[email protected]/[email protected] Sincerely, LexiangzheTechnology(Shenzhen)Co.,LTDJOCAustraliaInc Name:LiChihwenName:Benjamin.Smith Title:ViceGeneralManagerTitle:VicePresident Date:2024-07-15Date:2024-07-15

LexiangzheTechnology(Shenzhen)Co.,LTD To:QAILABORATORIESLTD. DECLARATIONOFIDENTITY Herebywe: LexiangzheTechnology(Shenzhen)Co.,LTD (NameofManufacturer) BasicModelNumber:WTR21 BasicBrandName:N/A BasicProductName:WirelessTransmitter&Receiverkit BasicTestReportApplication Number:TH2406287-C01 DeclaretheCircuit,PCBLayout;ThesemodelsofPCBboards,structures, andinteriorsarethesame,JusttheDifferentmodels: WTR221,WTR231,WTR2X1,EP311,EP321,EP331,EP3X（XRepresenting numbers） Exceptthefollowing(s):ThesemodelsofPCBboards,structures,and interiorsarethesame,JusttheDifferentmodels SignaturewithCompanyChop: PrintedName:LiZhihwen DATE:2024.07.15

产品规格书 PRODUCT SPECIFICATION Customer:ShenZhen Actionsmicro Technology Co., Ltd. 1、产品技术指标（PRODUCT TECHNICAL SPECIFICATION Customer’s part number: ANT000088 Product description: 5G Frequency Antenna Manufacturer：Shenzhen RedbirdTek Technology Co., Ltd. ） 电性能指标Electrical Specifications 频率范围Frequency Range (MHz) 5150-5850 频带宽度Bandwidth (MHz) 5G：700 输入阻抗Input Impendence (Ω) 50 电压驻波比V.S.W.R ≤2.0 增益Gain (dBi) 2.0dBi 极化形式Polarization Type 垂直Vertical 机械指标Mechanical Specifications 天线长度Antenna Length (mm) 6.6*3.9*0.5mm 辐射体Radiator Copper 连接器Connect Type PCB 外壳颜色Radome Color Silver 重量Weight (g) 0.02 Address ：7F, Yutian Building, 196 Dongyuan Road, Binjiang Community, Nanyuan Street, Futian District, Shenzhen 产品简介Product introduction: 该天线是专为无线内置天线设备设计生产的，天线具有外形美观，结 构小巧，一致性高，成本低廉。 The antenna is specially designed and produced for wireless built-in antenna equipment. The antenna has beautiful appearance, small structure, high consistency and low cost. 2、产品图片（PRODUCT PICTURE） 3、产品规格图(PRODUCT SPECIFICATION CHART) 4、驻波图（STATIONARY WAVE PATTERN） 5.增益效率值Gain and Efficiency： 6.场型图Field Pattern： 5.25G 5.8G

ExternalPhotograph

LabelLocation

InternalPhotograph W I F I TXANT W I F I W I F I RXANT

FCCMPEReport ReportNo.:TH2406287-C01-R03FCCID:2BHAZ-WTR21Page 1 of 8 RFEXPOSUREREPORT ApplicantLexiangzheTechnology(Shenzhen)Co.,LTD Address Room301,Building6,2013ChuangyeValley,HenggangStreet,Longgang District,Shenzhen Manufactureror Supplier LexiangzheTechnology(Shenzhen)Co.,LTD Address Room301,Building6,2013ChuangyeValley,HenggangStreet,Longgang District,Shenzhen Product WirelessTransmitter&Receiverkit TradeMarkN/A Model WTR21,WTR22,WTR23,WTR2X,EP31,EP32,EP33,EP3X （XRepresentingnumbers） AdditionalModel& ModelDifference ThesemodelsofPCBboards,structures,andinteriorsarethesame,Justthe Differentmodels DateoftestsJune19~July15,2024 FCCPart2(Section2.1093) KDB447498D01V06 IEEEC95.1 CONCLUSION:ThesubmittedsamplewasfoundtoCOMPLYwiththetestrequirement Testedby : (SunyZhuo) Reviewedby : (BlueHu) Approved&AuthorizedSigner: FCCMPEReport ReportNo.:TH2406287-C01-R03FCCID:2BHAZ-WTR21Page 2 of 8 TableofContents 1.STANDALONESARTESTEXCLUSIONCONSIDERATIONS....................3 2.PORTABLEDEVICEEVALUATIONMETHODANDLIMIT..........................5 3.MOBILEDEVICEEVALUATIONMETHODANDLIMIT...............................6 4.SARTESTEXCLUCSIONTHRESHOLDS..................................................7 5.CONCLUSION:............................................................................................8 FCCMPEReport ReportNo.:TH2406287-C01-R03FCCID:2BHAZ-WTR21Page 3 of 8 1.StandaloneSARtestexclusionconsiderations UnlessspecificallyrequiredbythepublishedRFexposureKDBprocedures, standalone1-gheadorbodyand10-gextremitySARevaluationforgeneral populationexposureconditions,bymeasurementornumericalsimulation,isnot requiredwhenthecorrespondingSARTestExclusionThresholdcondition(s),listed below,is(are)satisfied. Thesetestexclusionconditionsarebasedonsource-basedtime-averagedmaximum conductedoutputpoweroftheRFchannelrequiringevaluation,adjustedfortune-up tolerance,andtheminimumtestseparationdistancerequiredfortheexposure conditions. Theminimumtestseparationdistancedefinedin4.1f)isdeterminedbythesmallest distancefromtheantennaandradiatingstructuresoroutersurfaceofthedevice, accordingtothehostformfactor,exposureconditionsandplatformrequirements,to anypartofthebodyorextremityofauserorbystander. ToqualifyforSARtestexclusion,thetestseparationdistancesappliedmustbefully explainedandjustified,typicallyintheSARmeasurementorSARanalysisreport,by theoperatingconfigurationsandexposureconditionsofthetransmitterand applicablehostplatformrequirements,accordingtotherequiredpublishedRF exposureKDBprocedures. WhennootherRFexposuretestingorreportingarerequired,astatementof justificationandcompliancemustbeincludedintheequipmentapproval,inlieuof theSARreport,toqualifyforSARtestexclusion. Whenrequired,thedevicespecificconditionsdescribedintheotherpublishedRF exposureKDBproceduresmustbesatisfiedbeforeapplyingtheseSARtest exclusionprovisions. a)For100MHzto6GHzandtestseparationdistances≤50mm,the1-gand10-g SARtestexclusionthresholdsaredeterminedbythefollowing: [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparation distance,mm)]·[√f(GHz)]≤3.0for1-gSAR,and≤7.5for10-gextremitySAR, where f (GHz) istheRFchanneltransmitfrequencyinGHz  PoweranddistanceareroundedtothenearestmWandmmbeforecalculation Theresultisroundedtoonedecimalplaceforcomparison Thevalues3.0and7.5arereferredtoasnumericthresholdsinstepb)below Thetestexclusionsareapplicableonlywhentheminimumtestseparationdistanceis ≤50mm,andfortransmissionfrequenciesbetween100MHzand6GHz.Whenthe minimumtestseparationdistanceis<5mm,adistanceof5mmaccordingto4.1f) isappliedtodetermineSARtestexclusion. b)For100MHzto6GHzandtestseparationdistances>50mm,the1-gand10-g SARtestexclusionthresholdsaredeterminedbythefollowing(alsoillustratedin AppendixB): 1){[Powerallowedatnumericthresholdfor50mminstepa)]+[(test separationdistance–50mm)·(f(MHz)/150)]}mW,for100MHzto1500 MHz FCCMPEReport ReportNo.:TH2406287-C01-R03FCCID:2BHAZ-WTR21Page 4 of 8 2){[Powerallowedatnumericthresholdfor50mminstepa)]+[(test separationdistance–50mm)·10]}mW,for>1500MHzand≤6GHz c)Forfrequenciesbelow100MHz,thefollowingmaybeconsideredforSARtest exclusion(alsoillustratedinAppendixC): 1)Fortestseparationdistances>50mmand<200mm,thepowerthreshold atthecorrespondingtestseparationdistanceat100MHzinstepb)is multipliedby[1+log(100/f(MHz))] 2)Fortestseparationdistances≤50mm,thepowerthresholddeterminedby theequationinc)1)for50mmand100MHzismultipliedby½ 3)SARmeasurementproceduresarenotestablishedbelow100MHz. WhenSARtestexclusioncannotbeapplied,aKDBinquiryisrequiredtodetermine SARevaluationrequirementsforanySARtestresultsbelow100MHztobe acceptable. FCCMPEReport ReportNo.:TH2406287-C01-R03FCCID:2BHAZ-WTR21Page 5 of 8 2.PORTABLEDEVICEEVALUATIONMETHODANDLIMIT FollowingFCCKDB447498D01"GeneralSARtestexclusionguidance"The correspondingSARExclusionThresholdcondition,listedbelow: 1)The1-gand10-gSARtestexclusionthresholdsfor100MHzto6GHzattest separationdistances<50mmaredeteminedby: [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparation distance,mm)](if(GHz)]s3.0for1-gSARand ≤ 7.5for10-gextremitySAR,where f(GHz)istheRFchanneltransmitfrequencyinGHz. PoweranddistanceareroundedtothenearestmWandmmbeforecalculation. TheresultisroundedtoonedecimalplaceforcomparisonThetestexclusions areapplicableonlywhentheminimumtestseparationdistanceis50mmandfor transmissionfrequenciesbetween100MHzand6GHz.Whentheminimumtest separationdistanceis<5mm,adistanceof5mmisappliedtodetermineSARtest exclusion. 2)At100MHzto6GHzandfortestseparationdistances>50mm,theSARtest exclusionthresholdisdeterminedaccordingtothefollowing: a)[Thresholdat50mminstep1)+(testseparaiondistance-50mm) (f(MH2)/150)]mW,at100MHzto1500MHz; b)[Thresholdat50mminstep1)+(testseparationdistance-50mm) -10]mWat>1500MHzand<6GHz; 3)Atfrequenciesbelow100MHz,thefollowingmaybeconsideredforSARtest exclusion. a)Thethresholdatthecorrespondingtestseparationdistanceat100MHzin step2)ismultipliedby(1+log(100/f(MHz))]fortestseparationdistances>50mm and<200mm. b)Thethresholddeterminedbytheequationina)for50mmand1…

Text truncated - open the document above for the full version.

Applicant:Lexiangzhe Technology (Shenzhen) Co., LTD CaseNo.:TH2406287-C01 EUT:WirelessTransmitter&Receiverkit M/N:WTR21 TestPowerSupply:NA AmbientCondition:24.8°C,41%RH,101.325kPa AccordingStandard:■;☐other: TestDate:2024.07.10TestEngineer:Blue AppendixA1:EmissionBandwidth TestResult TestModeAntennaChannel 26dbEBW[MHz] FL[MHz]FH[MHz]Limit[MHz]Verdict 11AAnt1 574520.2405734.9605755.200------ 578520.1205774.8805795.000------ 582520.5205814.6005835.120------ 11N20SISOAnt1 574521.1205734.3605755.480------ 578520.9605774.4805795.440------ 582520.8405814.4405835.280------ TestGraphs 11A_Ant1_5745 11A_Ant1_5785 11A_Ant1_5825 11N20SISO_Ant1_5745 11N20SISO_Ant1_5785 11N20SISO_Ant1_5825 AppendixA2:Occupiedchannelbandwidth TestResult TestModeAntennaChannel OCB[MHz] FL[MHz]FH[MHz]Limit[MHz]Verdict 11AAnt1 574516.4175736.84815753.2651------ 578516.4105776.86835793.2783------ 582516.4485816.84535833.2933------ 11N20SISOAnt1 574517.5345736.26715753.8011------ 578517.5625776.26435793.8263------ 582517.5335816.31545833.8484------ TestGraphs 11A_Ant1_5745 11A_Ant1_5785 11A_Ant1_5825 11N20SISO_Ant1_5745 11N20SISO_Ant1_5785 11N20SISO_Ant1_5825 AppendixA3:Minemissionbandwidth TestResultB4 TestModeAntennaChannel 6dbEBW [MHz] FL[MHz]FH[MHz]Limit[MHz]Verdict 11AAnt1 574513.8405738.7205752.5600.5PASS 578515.0405777.4805792.5200.5PASS 582515.0805817.4805832.5600.5PASS 11N20SISOAnt1 574515.2805737.4805752.7600.5PASS 578514.0405777.4805791.5200.5PASS 582515.0405817.4805832.5200.5PASS TestGraphsB4 11A_Ant1_5745 11A_Ant1_5785 11A_Ant1_5825 11N20SISO_Ant1_5745 11N20SISO_Ant1_5785 11N20SISO_Ant1_5825 AppendixB:DutyCycle TestResult TestModeAntennaChannel Transmission Duration[ms] Transmission Period[ms] DutyCycle [%] Limit DC Factor [dBm] 11AAnt1 57451.361.8673.12---1.36 57851.351.8672.58---1.39 58251.351.8672.58---1.39 11N20SISOAnt1 57451.271.7871.35---1.47 57851.271.7771.75---1.44 58251.281.7871.91---1.43 TestGraphs 11A_Ant1_5745 11A_Ant1_5785 11A_Ant1_5825 11N20SISO_Ant1_5745 11N20SISO_Ant1_5785 11N20SISO_Ant1_5825 AppendixC:Maximumconductedoutputpower TestResultChannelPower Test Mode AntennaChannel Set Power Channel Powert [dBm] Duty Cycle [%] DC Factor [dBm] Result [dBm] Limit [dBm] Verdict 11AAnt1 5745---4.9773.121.366.33≤30.00PASS 5785---4.4872.581.395.87≤30.00PASS 5825---5.2272.581.396.61≤30.00PASS 11N20SI SO Ant1 5745---3.8171.351.475.28≤30.00PASS 5785---4.3171.751.445.75≤30.00PASS 5825---5.0371.911.436.46≤30.00PASS TestGraphsChannelPower 11A_Ant1_5745 11A_Ant1_5785 11A_Ant1_5825 11N20SISO_Ant1_5745 11N20SISO_Ant1_5785 11N20SISO_Ant1_5825 AppendixD:Maximumpowerspectraldensity TestResult TestModeAntennaChannelResult[dBm/MHz]Limit[dBm/MHz]Verdict 11AAnt1 5745-8.07≤30.00PASS 5785-8.57≤30.00PASS 5825-7.8≤30.00PASS 11N20SISOAnt1 5745-8.68≤30.00PASS 5785-8.89≤30.00PASS 5825-8.17≤30.00PASS Note：1.TheResultandLimitUnitisdBm/500kHzintheband5.725  5.85GHz. 2.TheDutyCycleFactorandRBWFactoriscompensatedinthegraph. TestGraphs 11A_Ant1_5745 11A_Ant1_5785 11A_Ant1_5825 11N20SISO_Ant1_5745 11N20SISO_Ant1_5785 11N20SISO_Ant1_5825 AppendixE:Bandedgemeasurements TestResultB4 TestModeAntennaChNameChannel FreqRange [MHz] Result [dBm] Limit [dBm] Verdict 11AAnt1 Low5745 5650~5700-34.45≤-26.53PASS 5700~5720-35.37≤12.05PASS 5720~5725-36.41≤23.16PASS 5760~5650-34.45≤-27PASS High5825 5850~5855-35.66≤22.26PASS 5855~5875-34.5≤12.52PASS 5875~5925-35.24≤5.71PASS 5925~5935-36.07≤-27PASS 11N20SIS O Ant1 Low5745 5650~5700-34.25≤-21.25PASS 5700~5720-35.64≤11.67PASS 5720~5725-36.19≤16.60PASS 5760~5650-34.13≤-27PASS High5825 5850~5855-36.25≤22.57PASS 5855~5875-35.13≤14.33PASS 5875~5925-35≤-7.18PASS 5925~5935-35.86≤-27PASS TestGraphsB4 11A_Ant1_Low_5745 11A_Ant1_High_5825 11N20SISO_Ant1_Low_5745 11N20SISO_Ant1_High_5825 AppendixF:ConductedSpuriousEmission TestResult TestModeAntennaChannel FreqRange [MHz] Max.Fre [MHz] Max.Level [dBm] Limit [dBm] Verdict 11AAnt1 5745 30~56503697.05-35.48≤-27PASS 5925~4000036556.15-28.74≤-27PASS 5785 30~56503714.47-35.1≤-27PASS 5925~4000036079.1-29.72≤-27PASS 5825 30~56503720.09-34.9≤-27PASS 5925~4000036133.62-29.52≤-27PASS 11N20SISOAnt1 5745 30~56503634.29-35≤-27PASS 5925~4000036204.05-28.35≤-27PASS 5785 30~56503690.31-34.45≤-27PASS 5925~4000039911.41-29.06≤-27PASS 5825 30~56503638.04-35.73≤-27PASS 5925~4000036146.12-28.11≤-27PASS TestGraphs 11A_Ant1_5745_30~5650 11A_Ant1_5745_5925~40000 11A_Ant1_5785_30~5650 11A_Ant1_5785_5925~40000 11A_Ant1_5825_30~5650 11A_Ant1_5825_5925~40000 11N20SISO_Ant1_5745_30~5650 11N20SISO_Ant1_5745_5925~40000 11N20SISO_Ant1_5785_30~5650 11N20SISO_Ant1_5785_5925~40000 11N20SISO_Ant1_5825_30~5650 11N20SISO_Ant1_5825_5925~40000
