MagneticRowingMachine 5303DUserManual Notice!Pleasereadthismanualcarefullybeforeassemblingand usingthisproduct;theproductappearanceissubjecttotheactual productandissubjecttochangewithoutpriornotice. TABLEOFCONTENTS WarrantyInformation&After-SalesService....................................1 WhatYouNeedtoKnowaboutSafeUse........................................2 ProductSpecifications......................................................................6 PackingList......................................................................................7 ProductExplodedView....................................................................9 PartsList.........................................................................................10 InstallationSteps............................................................................12 Features..........................................................................................18 AdjustmentGuidelines...................................................................19 1 WarrantyInformation&After-SalesService WelcometousingMagneticRowingMachineseriesproducts.Thisproduct comeswith12monthsFREEWARRANTYfornormaluse,providedthatitis notdamagedbyhumanintervention.Pleasenotethatourcompanyisnot responsibleforanyfailurescausedbyincorrectinstallation,incorrectuse,or replacementofparts,andthewarrantydoesnotapplytounauthorizedrepairs, includingresultingwhicharetheresponsibilityofthecustomer. Pleasenotethatthisproductisintendedforhomeuseonly,andourcompany isnotresponsibleforanyproblemscausedbycommercialuse. After-salesService Ifyouencounteranyproductproblemsorhavelosttheremotecontrol,please contactusthroughthefollowingmethods.Weprovide24/7customerservice andsupport. HartwaresServiceTeamcontactinformation: ServiceEmail:[email protected] WhatsAppQRcode： 2 WhatYouNeedtoKnowAboutSafeUse Thankyouforpurchasingourproducts.Properuseofthisequipmentisa guaranteeofyoursafetyandhealth.Itisveryimportanttoreadthemanual carefullybeforeusingthisequipment!Exercisecanonlybesafeandeffective ifthisequipmentisproperlyinstalled,maintainedandused. 1.Duringexercise,yourhandsshouldbefirmlyonthemovablehandlebars, andyourfeetshouldbeplacedonthefootpedalsandtiedtightlywithstraps. 2.Thisequipmentisonlysuitableforindoorandhouseholduse.The maximumuserweightandloadis265LBS. 3.ThisdeviceisclassifiedasHCandisnotsuitableformedicaluse. 4.Beforeassembly,youneedtofullyunderstandandcheckthepartslist providedwiththisequipment,andinstallitinfullaccordancewiththe instructionmanual. 5.Applicabletoolsmustbeusedduringinstallation.Ifnecessary,aska secondpersontoassistyouintheinstallation. 6.Fitnessequipmentneedstobeplacedonaflat,non-slipfloor.Ifplacedina humidspace,thelong-termuseoftheequipmentwillbeaffectedbycorrosion. 7.Beforeuse,pleasecheckwhethereachscrewcomponentislocked,and ensurethatthereisa0.6-meterspacearoundtheequipment,andthere shouldbenoprotrudingadjustabledevices. 8.Onlybyregularlycheckingwhethereachconnectionpartoftheequipment istightandinnormalconditioncanthesafetyleveloftheequipmentbe ensured. 9.Donotusecorrosivecleanersduringmaintenanceandcleaningtoprevent liquidfromenteringtheequipmentthroughthetailorgaps. 10.Thisequipmentisforadultsonly.Childrenandpetsshouldstayaway fromthisequipment.Itcanonlybeoperatedundertheguidanceofadults. 11.Thisequipmentcanonlybeusedbyonepersonatatime.Pleasepoint 3 outpossibledangerstothosearoundyou,suchasthedangerscausedby movingpartsduringexercise. 12.Wearwell-fittingclothingwhenexercisingtopreventlooseclothingfrom catchingonequipmentorrestrictingmovement. 13.Pleasedonotexercisebeforeoraftermeals. 14.Pleasepayattentiontotheexercisemethodsandresistanceadjustments intheinstructions. 15.Theresistanceofthisequipmenthasnothingtodowithspeed.The resistancehasnothingtodowiththerotationspeedduringtheprocessof drivingtheequipmentandremainsconstant. 16.Pleaseconsultyourfamilydoctorbeforeexercising.Hewilltellyouwhat kindofexerciseandexerciseloadaresuitable.Wrongexercisewilldamage yourhealth.Overtrainingcanleadtoseriousinjuryordeath.Ifyoufeeldizzy, pleasestopimmediately.train. 17.Theelectronicwatchhasmultiplefunctiondisplays.Itwillreflectthe correspondingvaluesaccordingtothedifferentdegreesofhumanmovement. Iwouldliketoremindyouthattheheartbeatvalueoftheelectronicwatchmay beinaccurateandcanonlygiveyousomereferto. 18.Pleasekeepthismanualandinstallationtoolsproperly. Importantadvice 1.Followtheinstallationinstructionsanduseonlythepartsconfiguredwith thisequipment. 2.Inprinciple,wedonotregardsportsequipmentastoysandcanonlybe usedbypeoplewhohaverelevantknowledgeorhavereceivedguidance. 3.Ifyouexperiencedizziness,nausea,chestpain,orotherunusual symptoms,stopexercisingimmediatelyandconsultyourdoctor. 4.Peoplesuchaschildrenanddisabledpeopleshouldonlyusethis equipmentundertheguidanceofaskilledperson. 4 5.Pleasenotethatyouandothersmustneverputanypartofyourbodyinto thesportsarea. 6.Intheadjustablepartsoftheequipment,payspecialattentiontothe markedmaximumlimitposition. 7.Onlyregularinspectionsforwearandloosepartscanensurethatthe equipmentisinhighquality. AssemblyInstructions 1.Theproductmustbeinstalledcarefullybyanadultandincaseof uncertaintyaskforhelpfromtechnicallyexperiencedpersonnel. 2.Unwrapallpackagingmaterialsandarrangethevariouscomponentsso thatitisclearerandeasiertounderstandforassembly.Usepadstoprotect themountingsurfacefromdirtorscratches. 3.Thencheckwhetherallcomponentsarecompleteaccordingtothepartslist, andthepackagingmaterialscanbediscardedonlyafterinstallationis completed. 4.Beforestartingassembly,pleasereadtheinstallationinstructionscarefully andunderstandthecorrespondingschematicdiagram. 5.Pleasenotethatthereisalwaysariskofinjurywhenusingtoolsand performingmanualoperations,sobecarefulwheninstallingtheproduct. 6.Afterassemblingtheproductaccordingtotheinstructions,pleasecarefully checkwhetherthescrews,nuts,andknobsareinstalledcorrectlyand tightenedinplace. 7.Afterinstallation,pleasedonotplacethetoolsrandomly. 8.Itisrecommendedthatyoufindaprotectivepad(notinclud…
