2BHBS-KHG005Fisget Steer Grip IoT

Fidget Steer Grip IoT sound user manual Page 1 ■How to mount Page 2 Google Play Store : Search ⇨Install ‘Fidget Steer Grip’ Fidget Steer Grip App Install Install Page 3 ■App introduction 1) This app is a dedicated app for Fidget Steer Grip IoT Sound devices, The device is connected to the user's mobile phone through Bluetooth (BLE) communication. When the connection is completeTry pressing the device button . the appActivates to play pre-stored sound effects ( or songs ) . 3) Description of device button operation Press the device button to play sounds saved in the app [] How to operate sound effect mode ( driving stress relief function ) -Press and hold the button for 2 seconds : sound effect is played -Press the button only once : stop playing the sound effect or play the next song -Press the button twice : Switch mode ( sound effect mode ⇄music mode ) [] How to organize music mode ( listen to your favorite songs while driving ) - Just press the button once : play song or play next song - Press and hold the button for 3 seconds : stop playing the sound effect - Press the button twice : Switch mode ( sound effect mode ⇄music mode ) 2) This app has 2 modes . ①Sound effect mode : Play sound effects ( Sound effect sources are not provided by the developer and must be saved directly in the app by the user . Refer to manual P6 ) ②Music ( song ) mode : Song playback ( Music sound source is not provided by the developer and must be saved in the app by the user . Refer to manual P8 ) ※ For reference, to switch modes, press the device button twice in succession Page 4 ■Menu screen introduction BLEscanning,theBLEfunction oftheuser'sphonemustfirstbe activated. ※ Sound effect mode Music mode Home Menu Ble scanning Amodethathelpsrelievedriving stress,gunsounds,StarWars laserguns,machinegunsounds Playsoundeffects,etc. ※ Userssavetheirfavoritesongsin theappYoucanselectand listentosongsaccordingtoyour mood. ※ Page 5 1) Bluetooth settings and connection method (BLE scanning) Bluetooth (BLE) scanningConnects to the ( If automatic connection is not possible , use the BLE connection (SCANNING..) button directly or the BLEPlease click the ICON to connect .) ‘SCAN’ button to connect BLE ⇨It goes into 'SCANNING...' state. BLE is connected, you can check FIDGET device information. Connected indicator Ble icon Disconnected indicator Ble icon BLE connection completion screen Page 6 2) Save the sound effect file ‘Add play list’ button Select ‘play list’ 1 2 3 4 5 Select a music file ⇨select the ‘playlist’ you want to save ⇨save 6 ※ Sound effect sound files are not provided by the developer . Users must secure the sound file themselves and save it on their mobile phone in advance. Page 7 ( Create a list of music files to play ) ( Select the created music file list ) ( Select a music file saved in advance on your phone ) 'New' button 3) Play sound effect Plays the sound effect saved in the selected 'playlist 3' . Page 8 ①In sound effect mode ⇨press and hold the device button for 3 seconds. ⇨Plays from the first sound effect saved in the Playlist . ②Stop playing sound effects ⇨Just press the device button once ③Play the next sound effect ⇨Just press once more when the sound effect is stopped playing. ⓐMusic files saved on your phoneYou can create multiple ‘play lists’ that are categorized and organized . ⓑAmong several ‘play lists’, only one ‘play list’ is connected to the device . ⓒTo select and play a ‘play list’ other than the ‘play list ’ that is being played, touch the button in front of When the device and app are connected via Bluetooth, the sound effect mode is autom atically selected first . ( Music mode selection must be selected by the user : see page 3 ) ※ Note that 4) Music mode : Saving / playing music ( song ) files Music mode also saves music (song) files in the same way as sound effect mode. ※ Music ( song ) sound files are not provided by the developer. The user must secure the sound source file and store it in advance on the mobile phone. ①In music mode ⇨press the device button only once ⇨the song will play ②When the song finishes playing, ⇨the next song is automatically played . ③To stop playing a song ⇨Press and hold the device button for 3 seconds . ④When the song is stopped ( completed ) , press the device button only once ⇨The next song will be played . Page 9 ■Others 1) To switch between sound effect mode and music mode, press the device button twice in succession . sound effect modemusic mode 2) DeviceThe power source is a coin (CR1632) battery . Please use a standard battery . ※ If the BLE connection is frequently disconnected, it is because the coin battery has reached the end of its life replace with new onePlease . Page 10 To replace the coin battery, separate the top and bottom of the case through this part. ※ IoTSound Spec •Size : 10 ( short width )​​ •BLE: 5.X •Power : CR1632 (3V, genuine recommended ) back of device module - Coin (CR1632) battery installed - front of device module FIDGET STEER GRIP IoT soundMODEL NO: KHG005 FCC ID : 2BHBS-KHG005POWER : DC 3VMANUFACTURE: Samilbnc Co., Ltd. This device complies with part 15 of the FCC Rules. Operation i s subject to the following two conditions:(1) This device may not cause harmful interference, and (2) thi s device must accept any interference received, including interference t hat may cause undesired operation. Label Information to user. The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. In cases where the manual is provided only in a form other than paper, such as on a computer disk or over the Internet, the information required by this section may be included in the manual in that alternative form, provided the user can reasonably be expected to have the capability to access information in that form. For a Class B digital devic…

Text truncated - open the document above for the full version.

Rev 1/26/2023 Samilbnc Co., Ltd. 616, 6F, 111, Sinnaeyeok-ro, Jungnang-gu, Seoul, Republic of Korea Tel: +82-2-2272-0464 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: July 16, 2024 . Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2BHBS-KHG005 Samilbnc Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Chief Executive Officer / Hyun-Ju, Lee Samilbnc Co., Ltd. Rev 1/26/2023 Samilbnc Co., Ltd. 616, 6F, 111, Sinnaeyeok-ro, Jungnang-gu, Seoul, Republic of Korea Tel: +82-2-2272-0464 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: July 16, 2024 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2BHBS-KHG005 Samilbnc Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Chief Executive Officer / Hyun-Ju, Lee Samilbnc Co., Ltd.

Rev 1/26 / Federal C o Authorizat 7435 Oakl Columbia , USA Date: Jun e Ref: Atte FCC ID or G Applicant [Samilbn c AGENT, LL [Samilbnc terminate involving t FCC US A G designated Designate Company FRN: 003 3 Address: 3 Contact Pe Phone: 70 Email: Sup Sincerely, [Samilbnc [Hyun‐Ju, [Insert Ap /2023 ommunicatio tion and Eval and Mills Ro a , MD 21046 e 28, 2024 station State Grantee Code FRN: [003562 c Co., Ltd. (“th LC is our desig c Co., Ltd.] acc d all marketin the equipmen GENT, LLC acc d U.S. agent f d U.S. Agent Name: FCC U 3402884 3722 Illinois A erson: Tim Pa 08‐571‐3148 pport@FCCUS Co., Ltd.] Lee] plicant signat ns Commissio uation Divisio ad ments Part 2 e:[2BHBS‐KHG 24576] he applicant” gnated U.S. a cepts to main ng and impor nt. cepts, as of th for service of Information: US Agent, LLC Avenue, Saint ayne SAgent.com ture] 616, 6 on on .911(d)(7) Fil i G005] ) certifies th a gent for serv ntain an agen rtation or the he date of the process for t Charles, IL, 6 6F, 111, Si ing at, as of the d ice of proces s t for no less t conclusion o e filing of the the above ref 60174, USA FCC US A Tim Payn [U.S. Age innaeyeok- ate of the fili s for the abov than one year of any Commi application, t erenced FCC AGENT, LLC ne ent signature] Samil -ro, Jungna Repu Tel: +8 ng of the app ve referenced r after the gra ssion‐related the obligation ID. ] lbnc Co., L ang-gu, Se ublic of Ko 82-2-2272-0 plication, FCC d FCC ID. antee has d proceeding n of the Ltd. eoul, orea 0464 US

Samilbnc Co., Ltd. 616, 6F, 111, Sinnaeyeok-ro, Jungnang-gu, Seoul, Republic of Korea Tel: +82-2-2272-0464 Date: June 28, 2024 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID : 2BHBS-KHG005 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules and IC regulation, we hereby request confidential treatment of information accompanying this application as outlined below: PERMANENT Exhibit Type File Name Part List Part List.pdf Schematics Diagram(s) Schematic.pdf Operation description Operation description.pdf Block diagram Block diagram.pdf And the above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Chief Executive Officer / Hyun-Ju, Lee Samilbnc Co., Ltd.

Samilbnc Co., Ltd. 616, 6F, 111, Sinnaeyeok-ro, Jungnang-gu, Seoul, Republic of Korea Tel: +82-2-2272-0464 Date: June 28, 2024 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 FCC ID : 2BHBS-KHG005 To whom it may concern: I, the undersigned, hereby authorize Young-Jin, Lee of KES Co., Ltd. and hereafter referred to as KES Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Young-Jin, Lee of KES Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing KES Co., Ltd. as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Chief Executive Officer / Hyun-Ju, Lee Samilbnc Co., Ltd. REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.

Model No.: KHG005 Page 1 of 1 External photos

Model No.: KHG005 Page 1 of 1 Label photo FCC ID : 2BHBS-KHG005 The product is small in size so a label is attached in the user manual FIDGET STEER GRIP IoT sound MODEL NO: KHG005 FCC ID : 2BHBS-KHG005 POWER : DC 3V MANUFACTURE: Samilbnc Co., Ltd. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Model No.: KHG005 Page 1 of 1 Internal photos N/A N/A PCB Antenna

Model Name : KHG005 Page 1 of 1 RF exposure FCC ID : 2BHBS-KHG005 According to 447498 D01 General RF Exposure Guidance v06 The 1-g and 10-g SAR test exclusion thresholds for 100 ㎒ to 6 ㎓ at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ꞏ[√f(㎓)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, Where; f(㎓) is the RF channel transmit frequency in ㎓ Power and distance are rounded to the nearest ㎽ and mm before calculation The result is rounded to one decimal place for comparison Results Tune-up Operation mode Frequency (㎒) Average output power (㏈m) Maximum Average output power (㏈m) BLE 1 Mbps 2 402 -3.80㏈m (±1.00dB) Max: -2.80 ㏈m 2 442 -3.80 ㏈m (±1.00dB) Max: -2.80 ㏈m 2 480 -3.80㏈m (±1.00dB) Max: -2.80 ㏈m Frequency (㎓) Distance (mm) Max Average tune-up power (㏈m) Calculation Value Exclusion Threshold (㏈m) (㎽) 2.402 5 -2.80 0.525 0.163 ≤3.0 2 442 5 -2.80 0.525 0.164 2 480 5 -2.80 0.525 0.165

APPROVAL SHEET MODEL : FIDGET Antenna layout Review Consent Approval RadiNa Co. ,Ltd 1. Product Information 1.1 General Features Antenna Type PCB Pattern Antenna Applications Bluetooth 1.2 Electrical Specifications Frequency Range (TX) 2400MHz ~ 2485MHz Frequency Range (RX) 2400MHz ~ 2485MHz Impedance 50 Ω VSWR TX 2400MHz 2485MHz 3↓ 3↓ RX 2400MHz 2485MHz 3↓ 3↓ Radiation Pattern Omni-directional Polarization Linear 1.3 Pattern Specifications 2. Electrical Characteristics 2.1 VSWR 2.2 Smith Chart 2.3 Radiation Pattern Azimuth Plane Phi 0 Degree Plane Product Specification for Pattern Antenna Features Single band operation 2.4GHz Specification Parameter Performance Antenna Type Omnidirectional Frequency 2.4 ~ 2.5GHz Gain -1.54dBi Polarization Linear Vertical Size 13x5.5mm Material Copper/FR-4 3. Measurement Process 3.1 SWR / Return loss Set Condition Network Analyzer Agilent 8753ES Cable Semi-ridid (40mm, 60mm) Test Condition 3.2 Gain Antenna gain is measured in the anechoic chamber of this company 3.3 Gain test block diagram Active test System - TRP, NHPRP, UHRP - TIS, NHPIS, UHIS - Relative Sensitivity Passive test System - Efficiency - Peak Gain, Avg Gain - Min/Max Power

The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). Report No. : KES-RF240308 Page 20 / 35 KES-QP16-F01(00-23-01-01) KES Co., Ltd. Test results (Below 30 ㎒) Mode: LE 1 Mbps Distance of measurement: 3 meter Channel: 39 (Worst case) Parallel The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). Report No. : KES-RF240308 Page 21 / 35 KES-QP16-F01(00-23-01-01) KES Co., Ltd. Test results (Below 1 000 ㎒) Mode: LE 1 Mbps Distance of measurement: 3 meter Channel: 39 (Worst case) Horizontal // Vertical The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). Report No. : KES-RF240308 Page 22 / 35 KES-QP16-F01(00-23-01-01) KES Co., Ltd. Test results (Above 1 000 ㎒) Mode: LE 1 Mbps Distance of measurement: 3 meter Channel: 00 - Spurious Frequenc y (㎒) Level (㏈㎶) Detect mode Ant. Pol. (H/V) CF (㏈) DCF (㏈) Field strength (㏈㎶/m) Limit (㏈㎶/m) Margin (㏈) 1 399.14 50.13 Peak V -6.91 - 43.22 74.00 30.78 1 592.95 50.74 Peak V -5.41 - 45.33 74.00 28.67 1 595.89 45.67 Peak H -5.38 - 40.29 74.00 33.71 1 946.50 51.21 Peak V -1.85 - 49.36 74.00 24.64 1 993.56 49.07 Peak H -1.35 - 47.72 74.00 26.28 4 803.93 48.21 Peak V 6.31 - 54.52 74.00 19.48 4 804.40 42.88 Average V 6.31 2.02 51.21 54.00 2.79 4 804.87 52.00 Peak H 6.32 - 58.32 74.00 15.68 4 804.40 44.45 Average H 6.31 2.02 52.78 54.00 1.22 7 205.73 35.04 Average H 12.42 2.02 49.48 54.00 4.52 7 206.20 40.70 Peak V 12.42 - 53.12 74.00 20.88 7 207.13 43.94 Peak H 12.42 - 56.36 74.00 17.64 - Band edge Frequenc y (㎒) Level (㏈㎶) Detect mode Ant. Pol. (H/V) CF (㏈) DCF (㏈) Field strength (㏈㎶/m) Limit (㏈㎶/m) Margin (㏈) 2 337.76 44.41 Peak V -0.52 - 43.89 74.00 30.11 2 338.24 46.62 Peak H -0.51 - 46.11 74.00 27.89 The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). Report No. : KES-RF240308 Page 23 / 35 KES-QP16-F01(00-23-01-01) KES Co., Ltd. Restricted band // Horizontal // Peak Restricted band // Vertical // Peak Horizontal // Peak for 1 ㎓ to 3 ㎓ Vertical // Peak for 1 ㎓ to 3 ㎓ Horizontal // Average for 1 ㎓ to 3 ㎓ Vertical // Peak for 3 ㎓ to 18 ㎓ The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). Report No. : KES-RF240308 Page 24 / 35 KES-QP16-F01(00-23-01-01) KES Co., Ltd. Horizontal // Peak for 3 ㎓ to 18 ㎓ Vertical // Peak for 3 ㎓ to 18 ㎓ Horizontal // Average for 3 ㎓ to 18 ㎓ Vertical // Average for 3 ㎓ to 18 ㎓ Note. 1. Average test would be performed if the peak result were greater than the average limit. The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). Report No. : KES-RF240308 Page 25 / 35 KES-QP16-F01(00-23-01-01) KES Co., Ltd. Mode: LE 1 Mbps Distance of measurement: 3 meter Channel: 20 - Spurious Frequenc y (㎒) Level (㏈㎶) Detect mode Ant. Pol. (H/V) CF (㏈) DCF (㏈) Field strength (㏈㎶/m) Limit (㏈㎶/m) Margin (㏈) 1 397.21 50.64 Peak V -6.92 - 43.72 74.00 30.28 1 596.20 47.28 Peak H -5.38 - 41.90 74.00 32.10 1 596.76 50.23 Peak V -5.37 - 44.86 74.00 29.14 1 793.01 47.64 Peak V -3.49 - 44.15 74.00 29.85 1 997.19 45.66 Peak H -1.31 - 44.35 74.00 29.65 4 884.08 49.64 Peak H 6.90 - 56.54 74.00 17.46 4 884.08 41.88 Average H 6.90 2.02 50.80 54.00 3.20 4 884.08 46.36 Peak V 6.90 - 53.26 74.00 20.74 4 884.08 36.48 Average V 6.90 2.02 45.40 54.00 8.60 7 326.19 39.52 Peak V 12.85 - 52.37 74.00 21.63 7 326.19 27.86 Average H 12.85 2.02 42.73 54.00 11.27 7 327.13 42.64 Peak H 12.86 - 55.50 74.00 18.50 The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). Report No. : KES-RF240308 Page 26 / 35 KES-QP16-F01(00-23-01-01) KES Co., Ltd. Horizontal // Peak for 1 ㎓ to 3 ㎓ Vertical // Peak for 1 ㎓ to 3 ㎓ Horizontal // Peak for 3 ㎓ to 18 ㎓ Vertical // Peak for 3 ㎓ to 18 ㎓ Horizontal // Average for 3 ㎓ to 18 ㎓ Vertical // Average for 3 ㎓ to 18 ㎓ Note. 1. Average test would be performed if the peak result were greater than the average limit. The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). Report No. : KES-RF240308 Page 27 / 35 KES-QP16-F01(00-23-01-01) KES Co., Ltd. Mode: LE 1 Mbps Distance of measurement: 3 meter Channel: 39 - Spurious Frequenc y (㎒) Level (㏈㎶) Detect mode Ant. Pol. (H/V) CF (㏈) DCF (㏈) Field strength (㏈㎶/m) Limit (㏈㎶/m) Margin (㏈) 1 399.08 53.25 Peak V -6.91 - 46.34 74.00 27.66 1 598.58 47.61 Peak H -5.36 - 42.25 74.00 31.75 1 599.89 47.80 Peak V -5.34 - 42.46 74.00 31.54 2 196.68 46.89 Peak V -0.97 - 45.92 74.00 28.08 2 607.98 48.54 Peak H -0.02 - 48.52 74.00 25.48 4 960.02 46.22 Peak H 7.46 - 53.68 74.00 20.32 4 960.02 44.50 Peak V 7.46 - 51.96 74.00 22.04 7 439.63 41.04 Peak H 13.41 - 54.45 74.00 19.55 7 439.63 32.56 Average H 13.41 2.02 47.99 54.00 6.01 7 439.63 42.50 Peak V 13.41 - 55.91 74.00 18.09 7 440.10 29.15 Average V 13.41 2.02 44.58 54.00 9.42 - Band edge Frequenc y (㎒) Level (㏈㎶) Detect mode Ant. Pol. (H/V) CF (㏈) DCF (㏈) Field strength (㏈㎶/m) Limit (㏈㎶/m) Margin (㏈) 2 483.50 45.56 Peak V -0.27 - 45.29 74.00 28.71 2 483.50 48.82 Peak H -0.27 - 48.55 74.00 25.45 Restricted band // Horizontal // Peak Restricted band // Vertical // Peak The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). Report No. : KES-RF240308 Page 28 / 35 KES-QP16-F01(00-23-01-01) KES Co., Ltd. Horizontal // Peak for 1 ㎓ to 3 ㎓ Vertical // Peak for 1 ㎓ to 3 ㎓ Horizontal // Peak for 3 ㎓ to 18 ㎓ Vertical // Peak for 3 ㎓ to 18 ㎓ Horizontal // Average for 3 ㎓ to 18 ㎓ Vertical // Average for 3 ㎓ to 18 ㎓ Note. 1. Average test would be performed if the peak result were greater than the average limit. The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). Report No. : KES-RF240308 Page 29 / 35 KES-QP16-F01(00-23-01-01) KES Co., Ltd. Test results (18 ㎓ to 30 …

Text truncated - open the document above for the full version.

TEST REPORT Report No. : KES-RF240308 Page 1 / 35 KES Co., Ltd. #3002, #3503, #3701, 40, Simin-daero365beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do, 14057, Republic of Korea Tel : +82-31-425-6200, Fax : +82-31-341-383 8 The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). KES-QP16-F01(00-23-01-01) KES Co., Ltd.  FCC TEST REPORT 1. Client ○Name : Samilbnc Co., Ltd. ○Address : 616, 6F, 111, Sinnaeyeok-ro, Jungnang-gu, Seoul, Republic of Korea 2. Sample Description ○Product item : Fisget Steer Grip IoT ○Model name : KH G005 ○ Manufacturer etc. : Samilbnc Co., Ltd. 3. Date of test : 2024.05.29 ~ 2024.06.07 4. Location of Test :  Permanent Testing LabOn Site Testing ○ Adress : 4 73-21, Gaye o-ro, Yeoju-si, Gyeonggi-do, Korea 5. T est method used : Part 15 Subpart C 15.247 6. T est result : PASS The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This laboratory is not accredited for the test results marked*. This test report is not related to KOLAS accreditation. Affirmation Tested by Technical Manager Name : Do-won Ahn (Signature) Name : Young-Jin Lee (Signature) 2024. 07. 12. KES Co., Ltd. Accredited by KOLAS, Republic of KOREA The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). Report No. : KES-RF24 0308 Page 2 / 35 KES-QP16-F01(00-23-01-01) KES Co., Ltd. REPORT REVISION HISTORY DateTest Report No.Revision History 2024.07.12. KES-RF240308Initial This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. This document may be altered or revised by KES Co., Ltd. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by KES Co., Ltd. will constitute fraud and shall nullify the document. Use of uncertainty of measurement for decisions on conformity (decision rule): No decision rule is specified by the standard, when comparing the measurement result with the appli cable limit according to the specification in that standard. The decisions on confor mity are made without ap plying the measurement uncertainty(“simple acceptance” decision rule, previously known as “accuracy method”). ☐Oth er (to be specified, for example when required by the standard or client) The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). Report No. : KES-RF240308 Page 3 / 35 KES-QP16-F01(00-23-01-01) KES Co., Ltd. TABLE OF CONTENTS 1. General information ................................................................................................................................... 4 1.1. EUT description .......................................................................................................................... 4 1.2. Test configuration ....................................................................................................................... 5 1.3. Information about derivative model ............................................................................................ 5 1.4. Accessory information ................................................................................................................ 5 1.5. Sample calculation ..................................................................................................................... 5 1.6. Measurement Uncertainty .......................................................................................................... 5 1.7. Frequency/channel operations ................................................................................................... 6 2. Summary of tests ....................................................................................................................................... 7 3. Test results ................................................................................................................................................. 8 3.1. 6 ㏈ bandwidth .......................................................................................................................... 8 3.2. Output power ............................................................................................................................ 10 3.3. Power spectral density ............................................................................................................. 12 3.4. Radiated restricted band and emissions .................................................................................. 14 3.5. Conducted spurious emissions & band edge ........................................................................... 30 3.6. Antenna Requirement ............................................................................................................... 34 Appendix A. Measurement equipment .......................................................................................................... 35 The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). Report No. : KES-RF240308 Page 4 / 35 KES-QP16-F01(00-23-01-01) KES Co., Ltd. 1. General information Applicant: Samilbnc Co., Ltd. Applicant address: 616, 6F, 111, Sinnaeyeok-ro, Jungnang-gu, Seoul, Republic of Korea Test site: KES Co., Ltd. Test site address: #3002, #3503, #3701, 40, Simin-daero 365beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do,14057,Republic of Korea 473-21, Gayeo-ro, Yeoju-si, Gyeonggi-do, Korea Test Facility FCC Accreditation Designation No.: KR0100, Registration No.: 444148 FCC rule part(s): 15.247 FCC ID: 2BHBS-KHG005 Test device serial No.: Production Pre-production Engineering 1.1. EUT description Equipment under test Fisget Steer Grip IoT Frequency range 2 402 ㎒ ~ 2 480 ㎒ (LE 1 Mbps) Model KHG005 Modulation technique GFSK Number of channels 2 402 ㎒ ~ 2 480 ㎒ (LE 1 Mbps) : 40 ch Antenna specification PCB Antenna // Peak gain: -1.54 dBi Power source DC 3.0 V (Battery…

Text truncated - open the document above for the full version.

Report No. : KES-EM241685 Page 21 / 23 KES-QP16-F01(00-23-01-01) KES Co., Ltd. The authenticity of the test report, contact [email protected] APPENDIX B - Test Setup Photos and Configuration Conducted Emissions at Mains Power Ports N/A Report No. : KES-EM241685 Page 22 / 23 KES-QP16-F01(00-23-01-01) KES Co., Ltd. The authenticity of the test report, contact [email protected] Radiated Electric Field Emissions(Below 1 ㎓) Report No. : KES-EM241685 Page 23 / 23 KES-QP16-F01(00-23-01-01) KES Co., Ltd. The authenticity of the test report, contact [email protected] Radiated Electric Field Emissions(Above 1 ㎓)

Model No.: KHG005 Page 1 of 1 Test Setup Photo
