2BHDN-LSC-V5Robot Vacuum Cleaner

LSC-V5 Robot Vacuum Cleaner Operating Manual Please read this user manual carefully. If you have any questions, please contact our customer service staff. Terms of Use l This product is for indoor use only. Do not place this product or the base station outdoors or in places where it is easily wetted by rain. l This product involves some precision parts. Please do not let children use it as a toy. When the product is in operation, please keep it away from children as much as possible. l For this product, please use the fragrance liquid that comes with the box. You can buy a new one in the mall after using it up. Please do not use corrosive liquids as a substitute. It is strictly forbidden to use liquids such as disinfectant. l Please install this product according to the installation instructions. Do not place the host and base station upside down, and do not lift the laser sensor protection cover and the upper cover of the body by hand. l Do not use this product to clean burning objects. Do not clean explosive, corrosive or toxic liquids. l Do not use in an environment where the temperature is above 40°C or below 0°C or there is any liquid or sticky substance on the ground. l Do not use this product in the room where infants or young children are sleeping. l Do not put your hands into the gap of the base station or place other debris in front of the base station while the product is running. l Do not use the main unit to absorb stones, waste paper and other items that may easily clog the air duct. If there is any blockage, please clean it up in time. l Do not dismantle the body and base station components at will. If necessary, please contact dedicated personnel for repair guidance. l Please use this product according to the instructions in the manual. Any losses and damages caused by improper use shall be borne by the user. Battery and Charging l Do not use any third-party batteries and base stations. l Do not use any type of third-party power adapter to charge the console. l Do not disassemble, repair or modify the battery and base station without permission. l Do not wipe the charging dome with a damp cloth or wet hands. l Please dispose the battery properly and have them recycled by professional organizations. l If the battery or power supply is damaged in any way, stop using it immediately and contact after-sales personnel for processing. l If you need to transport this product, please turn off the host and use the original packaging box for packaging. l If you do not use this product for a long time, please turn off the host after fully charging it and place it in a cool and dry place. Fully charge it at least once every 3 months to avoid battery damage. Parts List Robot Station Mopping Pads Mopping Pad Plates Robot Unit Auto Station Cleaning Tool Bottle Filter Side Brushes Dust Bag Note: Figures and illustrations are for reference only and may differ from actual product appearance, Product design and specifications are subject to changes without notice. Product Description Power Home Laser distance sensor Bumper Reset Aromatherapy Filling Port To p Cover Water Filling Port Wi-Fi Indicator Dust Bin Dual Side Brushes Universal Wheel Mopping Pad Plates Install Axis Charging Contacts Floating Roller Brush Air Outlet Port Microphone Hole Dust Collection Port Anti-drop Sensors Mopping Pad Plates Floating Rubber Brushes Release Button Mounting Slots for Mopping Pad Assembly Washable Mopping Pads Water Outlet Port Mounting Slots for Mopping Pad Assembly Charging Contacts Pet Laser To p Cover Cleaning Brush Dust Bag Handle Dust Bag Recharge Sensor Limiting wheel Air Outlet Port Recharge Sensor Panel Dust Collection Port Pet Laser Button 盒 Wire Winding Board Preparation before use Place the auto station against a wall and connect it to a power source. Place the base station against a wall on a flat surface. Do not place objects within 0.5 cm to the left and right and 1.5 cm in front. Install the side brush: Press the left and right side brushes into the side brush slots respectively. When you hear a "click", they are installed in place. Install the mop: first soak the left and right mops completely, then stick them on the two mop plates, and then press them into the mop slots. Note: If you use dry mopping, you do not need to soak the mop. Add water: Fill the matching water bottle with water and pour it into the water tank from the water inlet. Add aromatherapy liquid: inject the aromatherapy liquid into the aromatherapy box from the aromatherapy injection port . Remove the anti-collision foam strip: Open the top cover of the main unit and take out the anti-collision foam strip. Charge Turn on the robot , with the front bumper facing outwards, align it with the charging spring and push it into the base station to start charging. In daily use, you can start charging by pressing the recharge button on the host or clicking the " recharge " button on the APP, or you can manually place the robot in the base station to charge. Tips : For the first charge, it is recommended to fully charge before use to protect the battery performance. When the battery is low, it may not be able to start up. Please place the robot on the base station to charge. Download the app Search for "Extravis" in the App Store and follow the prompts to download and install the APP; or scan the QR code below to download and install the APP. After the installation is complete, please follow the instructions on the APP page to complete the registration, login and network configuration. Add a device Open the top cover of the host, press and hold the recharge button for 5 seconds, and when you hear "Enter WiFi network configuration mode" , it means the host has entered network configuration mode . Click Add Device on the APP homepage and complete the connection according to the APP prompts. If the network configuration problem occurs, you can restart the machine by pressing the "reset" button and configure the network again. Netwo…

Text truncated - open the document above for the full version.

Covered Equipment Identification Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(5)(ii) of the Commission’s Rules (47 C.F.R.) we attest as follows: We, applicant Company Name: Linksmart Technology (Zhongshan) Co., Ltd. Address: No. 11 Yingbin Avenue, Banfu Town, Zhongshan, Guangdong, China Phone: +86-13928437756 certify that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. FCC ID: 2BHDN-LSC-V5 If you have any questions, please feel free to contact us at the address shown below. Sincerely, Signature Date:2024-07-08 Name / Title: Mao Lin Li / R&D Director Company: Linksmart Technology (Zhongshan) Co., Ltd. Address: No. 11 Yingbin Avenue, Banfu Town, Zhongshan, Guangdong, China Phone: +86-13928437756 Fax: +86-760-86138999-88859 E-Mail: [email protected]

Covered Equipment Attestation Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(5)(i)-(ii) of the Commission’s Rules (47 C.F.R.) we attest as follows for the product listed below: FCC ID Model name 2BHDN-LSC-V5 LSC-V5, LSC-V5-X, LSC-V5X (X=A-Z, 0-9 or blank) We, applicant Company Name: Linksmart Technology (Zhongshan) Co., Ltd. Address: No. 11 Yingbin Avenue, Banfu Town, Zhongshan, Guangdong, China Phone: 0086-13928437756 certify that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If you have any questions, please feel free to contact us at the address shown below. Sincerely, Signature Date:2024-07-08 Name / Title: Mao Lin Li / R&D Director Company: Linksmart Technology (Zhongshan) Co., Ltd. Address: No. 11 Yingbin Avenue, Banfu Town, Zhongshan, Guangdong, China Phone: +86-13928437756 Fax: +86-760-86138999-88859 E-Mail: [email protected]

Confidentiality Request Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request confidentiality for the documentation of the following products: FCC ID Model name 2BHDN-LSC-V5 LSC-V5, LSC-V5-X, LSC-V5X (X=A-Z, 0-9 or blank) For the products listed above, we request permanent confidentiality for all applicable exhibits as there are: • the Operational Description • the Block Diagram • the Schematics • the Part List • the Tune up Information The above listed exhibits contain trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact us at the address shown below. Sincerely, Signature Date:2024-07-08 Name / Title: Mao Lin Li / R&D Director Company: Linksmart Technology (Zhongshan) Co., Ltd. Address: No. 11 Yingbin Avenue, Banfu Town, Zhongshan, Guangdong, China Phone: +86-13928437756 Fax: +86-760-86138999-88859 E-Mail: [email protected]

Page 1 of 1 Rev.2.0 Linksmart Technology (Zhongshan) Co., Ltd. WIFI Channel 12 and 13 Declaration Letter We declare the equipment identified below with regards to Channel 12 and 13 capabilities for FCC ID: 2BHDN-LSC-V5 Declaration Product hardware does not have the capability to operate on Channel 12 and 13. Product hardware has the capability to operate on Channel 12 and 13. However, these two channels will be disabled via software and will not be accessible to user. Product hardware has the capability to operate on Channel 12 and 13. However, all the operated channels can’t be changed in the RF parameter via software. All channels have complied with all of the requirements sets out in FCC Part 15.247. Product hardware has the capability to operate on WiFi Channel 12 and 13, and meets the requirements of KDB 594280 D01 v02r01. Please note: 1.) By default, this device operates in a mode that is compliant with the U.S. requirements. 2.) This device will also use supplemental information such as geo- location data to determine that it is operating outside the U.S., if necessary, to change its power. Such supplemental data will be derived from the following: Global Navigation Satellite System (GNSS)7 sensors in the device Mobile Country Code (MCC),8 or MCC with a Mobile Network code (MNC), received from a CMRS9 carrier and received directly by a receiver on the device Country information derived from multiple adjacent access points (for example using IEEE Std 802.11d provisions) may be permitted on case-by-case basis Other suitable geo-location data based on IP addresses or other reliable source. Name / Title: Mao Lin Li / R&D Director Signature: Phone: +86-13928437756 Email: [email protected] Date: 2024-07-08

Linksmart Technology (Zhongshan) Co., Ltd. No. 11 Yingbin Avenue, Banfu Town, Zhongshan, Guangdong, China Date: July. 08, 2024 FCC ID: 2BHDN-LSC-V5 Model Number: LSC-V5, LSC-V5-X, LSC-V5X (X=A-Z, 0-9 or blank) To: Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21048 To Whom It May Concern, We, Linksmart Technology (Zhongshan) Co., Ltd. hereby declare that our product (Robot Vacuum Cleaner) Model Number: LSC-V5, LSC-V5-X, LSC-V5X (X=A-Z, 0-9 or blank) board, Schematic, Hardware version, Software version, structure and internal photos are same, named and appearance differently due to marketing purposes. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, (Signed) Name / Title: Mao Lin Li / R&D Director Company: Linksmart Technology (Zhongshan) Co., Ltd. Address: No. 11 Yingbin Avenue, Banfu Town, Zhongshan, Guangdong, China Phone: +86-13928437756 Fax: +86-760-86138999-88859 E-Mail: [email protected]

FCC ID: 2BHDN-LSC-V5 Fig. 1 Fig. 2 FCC ID: 2BHDN-LSC-V5 Fig. 3 Fig. 4 FCC ID: 2BHDN-LSC-V5 Fig. 5 Fig. 6 FCC ID: 2BHDN-LSC-V5 Fig. 7

_____________________________________________________________________________________________________ LABEL AND LOCATION (Size: L10.0cm x 2.73cm) Label Location

FCC ID: 2BHDN-LSC-V5 Fig. 1 Fig. 2 FCC ID: 2BHDN-LSC-V5 Fig. 3 Fig. 4 FCC ID: 2BHDN-LSC-V5 Fig. 5 Fig. 6 FCC ID: 2BHDN-LSC-V5 Fig. 7 Fig. 8 FCC ID: 2BHDN-LSC-V5 Fig. 9 Fig. 10 Antenna FCC ID: 2BHDN-LSC-V5 Fig. 11

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‟an District, Shenzhen, China RF Exposure evaluation Report Reference No. ................. : FCC ID. ......................................... : CTA24061300902 2BHDN-LSC-V5 Compiled by ( position+printed name+signature): File administrators Jinghua Xiao Supervised by ( position+printed name+signature): Test Engineer Lushan Kong Approved by ( position+printed name+signature) . : Manager Eric Wang Date of issue .................................... : Jul. 03, 2024 Representative Laboratory Name ....................................................... : Shenzhen CTA Testing Technology Co., Ltd. Address ......................................... : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao„an District, Shenzhen, China Applicant’s name ............................ : Linksmart Technology(Zhongshan) Co.,Ltd. Address ............................................ : No. 11 Yingbin Avenue,Banfu Town,Zhongshan,Guangdong, China Test specification ........................ : Standard ........................................ : 47CFR §1.1310 Basis and purpose 47CFR §2.1091 Radiofrequency radiation exposure evaluation: mobile devices TRF Originator .............................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ................................... : Dated 2014-12 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................. : Robot Vacuum Cleaner Trade Mark .................................... : N/A Manufacturer ................................. : Linksmart Technology(Zhongshan) Co.,Ltd. Model/Type reference ................... : LSC-V5 Listed Models .............................. : LSC-V5-X, LSC-V5X (X=A-Z, 0-9 or blank) Hardware Version ........................ : N/A Software Version ........................... : N/A Rating ............................................ : DC 14.4V by Battery Recharged by DC 19.4V Result ............................................ : PASS Report No.: CTA24061300902 Page 2 of 10 T E S T R E P O R T Test Report No. : CTA24061300902 Jul. 03, 2024 ______________________________________________________________________________________________ Date of issue Equipment under Test : Robot Vacuum Cleaner Model /Type : LSC-V5 Listed model : LSC-V5-X, LSC-V5X (X=A-Z, 0-9 or blank) Applicant : Linksmart Technology(Zhongshan) Co.,Ltd. Address : No. 11 Yingbin Avenue,Banfu Town,Zhongshan,Guangdong, China Manufacturer : Linksmart Technology(Zhongshan) Co.,Ltd. Address : No. 11 Yingbin Avenue,Banfu Town,Zhongshan,Guangdong, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA24061300902 Page 3 of 10 Contents 1. SUMMARY .................................................................................................................................................... 4 1.1 EUT CONFIGURATION .................................................................................................................................... 4 1.2 PRODUCT DESCRIPTION ................................................................................................................................ 4 2. TEST ENVIRONMENT .................................................................................................................................. 5 2.1 ADDRESS OF THE TEST LABORATORY .............................................................................................................. 5 2.2 TEST FACILITY ............................................................................................................................................... 5 2.3 ENVIRONMENTAL CONDITIONS ........................................................................................................................ 5 2.4 STATEMENT OF THE MEASUREMENT UNCERTAINTY .......................................................................................... 5 3. METHOD OF MEASUREMENT ................................................................................................................... 6 3.1 APPLICABLE STANDARD ................................................................................................................................. 6 3.2 REQUIREMENT .............................................................................................................................................. 6 3.3 LIMIT ............................................................................................................................................................. 6 3.4 MPE CALCULATION METHOD ......................................................................................................................... 7 3.5 ANTENNA INFORMATION ................................................................................................................................. 7 4. CONDUCTED POWER RESULTS ............................................................................................................... 8 5. MANUFACTURING TOLERANCE ............................................................................................................... 9 6. MEASUREMENT RESULTS ........................................................................................................................ 9 6.1 STANDALONE MPE EVALUATION ...........................…

Text truncated - open the document above for the full version.

address：401A, Building A1, No. 528, Huarong Road, Dalang Street, Longhua New District, Shenzhen 电话: 86-755-29361726传真: 86-755-85268343 保密要求 深圳市天威讯无线技术有限公司已拥有专有技术所提供的资料，未经本公司事先书面同意不允许透露给任何公司或个人。 深圳市天威讯无线技术有限公司 shenzhen shenzhen Tian Tian wei wei xun xun wireless wireless technology technology co.,ltd. co.,ltd. Product Product P P erformance erformance & & S S pecification pecification Tian Tian W W ei ei X X un un A A ntenna ntenna T T he he R R esearch esearch & & D D evelopment evelopment D D epartment epartment CustomerName: 深圳市垚海智能有限公司 ProductName: LSC-V5 Board Model : V1 Tian Wei Xun P/N: TWX-151-002 PCB Model : CustomerP/N: ClientAdmitmanufacturingparty Customers confirmation Quality department R&DApproval ME: RF: Date ： Date ： Thursday,June 13, 2024 CustomerName：LSC-V5ConfidentialInformationProduct：Sweeper 深 深 圳 圳 市 市 天 天 威 威 讯 讯 无 无 线 线 技 技 术 术 有 有 限 限 公 公 司 司 DraftLiaoXianming Performance& Specification VersionV1 DepartmentR&DData2024-06-13 保密要求 深圳市天威讯无线技术有限公司已拥有专有技术所提供的资料，未经本公司事先书面同意不允许透露给任何公司或个人。 第 1 页 Index 1.1PROJECTDIAGRAM.......................................................................................................................2 1.1.1A NTENNAMATCHINGDIAGRAM .............................................................................................................2 2.1OBJECTIVE..................................................................................................................................3 3.1MAINANTENNA............................................................................................................................3 3.1.1E LECTRICALSPECIFICATIONSANDMATERIALS ............................................................................................3 3.1.2A NTENNAFORM .................................................................................................................................3 3.1.3F REQUENCYBAND ...............................................................................................................................3 3.1.4M EASUREMENTDATAINTHE ETS-SG24SYSTEM3D............................................................................4 3.1.5S TANDINGWAVE & RETURNLOSS ..........................................................................................................5 3.1.6OTATESTWIFIDATA......................................................................................................................6 4.1PRODUCTDRAWINGS.............................................................................................................6 5.1PRODUCTASSEMBLYDIAGRAM....................................................................................................8 5.1.1A NTENNACOMPOSITION ......................................................................................................................8 5.1.2A NTENNAASSEMBLY ............................................................................................................................8 5.1.3T HEANTENNAASSEMBLYISSHOWNINTHEDIAGRAMOFTHEENTIREMACHINE ............................................8 5.1.4E NVIRONMENTALTREATMENT ......................................................................................................8 CustomerName：LSC-V5ConfidentialInformationProduct：Sweeper 深 深 圳 圳 市 市 天 天 威 威 讯 讯 无 无 线 线 技 技 术 术 有 有 限 限 公 公 司 司 DraftLiaoXianming Performance& Specification VersionV1 DepartmentR&DData2024-06-13 保密要求 深圳市天威讯无线技术有限公司已拥有专有技术所提供的资料，未经本公司事先书面同意不允许透露给任何公司或个人。 第 2 页 1.1ProjectDiagram LSC-V5 1.1.1AntennaMatchingDiagram ElementCapacitanceInductance E1(0402) E2(0402) E3(0402) E4(0402) Matchinginstructions:invariant CustomerName：LSC-V5ConfidentialInformationProduct：Sweeper 深 深 圳 圳 市 市 天 天 威 威 讯 讯 无 无 线 线 技 技 术 术 有 有 限 限 公 公 司 司 DraftLiaoXianming Performance& Specification VersionV1 DepartmentR&DData2024-06-13 保密要求 深圳市天威讯无线技术有限公司已拥有专有技术所提供的资料，未经本公司事先书面同意不允许透露给任何公司或个人。 第 3 页 2.1Objective Standardizethespecificationsandtestingmethodsofmobilecommunicationterminal antennasproducedbyShenzhenTianweixunWirelessTechnologyCo.,Ltd.toavoiderrors causedbydifferenttestingconditionsandmethods. 3.1MainAntenna 3.1.1ElectricalSpecifications&Materials Thisreportmainlyprovidesthetestingstatusofthestructuralperformance parametersoftheantennaLSC-V5. AntennaPhysicalImage 3.1.2AntennaForm Type:PIFAAntenna 3.1.3FrequencyDand Thefrequencybandis2412MHz~2472MHz; CustomerName：LSC-V5ConfidentialInformationProduct：Sweeper 深 深 圳 圳 市 市 天 天 威 威 讯 讯 无 无 线 线 技 技 术 术 有 有 限 限 公 公 司 司 DraftLiaoXianming Performance& Specification VersionV1 DepartmentR&DData2024-06-13 保密要求 深圳市天威讯无线技术有限公司已拥有专有技术所提供的资料，未经本公司事先书面同意不允许透露给任何公司或个人。 第 4 页 3.1.4MeasurementDataInTheETS-SG24SYSTEM3D ETSTestingSystemThreedimensionalpositioningdeviceinthedarkroom Passiveperformanceindicatorsofmass-producedantennas: CustomerName：LSC-V5ConfidentialInformationProduct：Sweeper 深 深 圳 圳 市 市 天 天 威 威 讯 讯 无 无 线 线 技 技 术 术 有 有 限 限 公 公 司 司 DraftLiaoXianming Performance& Specification VersionV1 DepartmentR&DData2024-06-13 保密要求 深圳市天威讯无线技术有限公司已拥有专有技术所提供的资料，未经本公司事先书面同意不允许透露给任何公司或个人。 第 5 页 3.1.5StandingWave&ReturnLoss CustomerName：LSC-V5ConfidentialInformationProduct：Sweeper 深 深 圳 圳 市 市 天 天 威 威 讯 讯 无 无 线 线 技 技 术 术 有 有 限 限 公 公 司 司 DraftLiaoXianming Performance& Specification VersionV1 DepartmentR&DData2024-06-13 保密要求 深圳市天威讯无线技术有限公司已拥有专有技术所提供的资料，未经本公司事先书面同意不允许透露给任何公司或个人。 第 6 页 SWR SWR Return Return loss loss 3.1.6OTATest WIFIData 4.1ProductDrawings CustomerName：LSC-V5ConfidentialInformationProduct：Sweeper 深 深 圳 圳 市 市 天 天 威 威 讯 讯 无 无 线 线 技 技 术 术 有 有 限 限 公 公 司 司 DraftLiaoXianming Performance& Specification VersionV1 DepartmentR&DData2024-06-13 保密要求 深圳市天威讯无线技术有限公司已拥有专有技术所提供的资料，未经本公司事先书面同意不允许透露给任何公司或个人。 第 7 页 CustomerName：LSC-V5ConfidentialInformationProduct：Sweeper 深 深 圳 圳 市 市 天 天 威 威 讯 讯 无 无 线 线 技 技 术 术 有 有 限 限 公 公 司 司 DraftLiaoXianming Performance& Specification VersionV1 DepartmentR&DData2024-06-13 保密要求 深圳市天威讯无线技术有限公司已拥有专有技术所提供的资料，未经本公司事先书面同意不允许透露给任何公司或个人。 第 8 页 5.1ProductAssemblyDiagram 5.1.1Antennacomposition Theantennaisac…

Text truncated - open the document above for the full version.

FCC ID: 2BHDN-LSC-V5 1 Case No. : CTA24061300901 Ambient Condition: 23 °C, 49 %RH, Test Date: 2024.6.13 Test Engineer: Evan ouyang Appendix A.1: DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 8.680 2407.640 2416.320 0.5 PASS 2437 8.680 2432.640 2441.320 0.5 PASS 2462 8.640 2457.640 2466.280 0.5 PASS 11G Ant1 2412 16.480 2403.760 2420.240 0.5 PASS 2437 16.480 2428.760 2445.240 0.5 PASS 2462 16.480 2453.760 2470.240 0.5 PASS 11N20SISO Ant1 2412 17.720 2403.120 2420.840 0.5 PASS 2437 17.760 2428.120 2445.880 0.5 PASS 2462 17.720 2453.120 2470.840 0.5 PASS 11N40SISO Ant1 2422 36.400 2403.840 2440.240 0.5 PASS 2437 36.400 2418.840 2455.240 0.5 PASS 2452 36.320 2433.840 2470.160 0.5 PASS FCC ID: 2BHDN-LSC-V5 2 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 FCC ID: 2BHDN-LSC-V5 3 11G_Ant1_2412 11G_Ant1_2437 FCC ID: 2BHDN-LSC-V5 4 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 FCC ID: 2BHDN-LSC-V5 5 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 FCC ID: 2BHDN-LSC-V5 6 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 FCC ID: 2BHDN-LSC-V5 7 Appendix A.2: Occupied Channel Bandwidth Test Result TestMode Antenna Channel Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] 11B Ant1 2412 14.550 2404.7395 2419.2895 2437 14.636 2429.7448 2444.3808 2462 14.524 2454.7635 2469.2875 11G Ant1 2412 16.871 2403.5146 2420.3856 2437 16.876 2428.5233 2445.3993 2462 16.960 2453.4929 2470.4529 11N20SISO Ant1 2412 17.893 2403.0449 2420.9379 2437 17.996 2428.0109 2446.0069 2462 17.927 2453.0462 2470.9732 11N40SISO Ant1 2422 36.131 2403.9790 2440.1100 2437 36.092 2419.0405 2455.1325 2452 35.996 2434.0607 2470.0567 FCC ID: 2BHDN-LSC-V5 8 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 FCC ID: 2BHDN-LSC-V5 9 11G_Ant1_2412 11G_Ant1_2437 FCC ID: 2BHDN-LSC-V5 10 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 FCC ID: 2BHDN-LSC-V5 11 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 FCC ID: 2BHDN-LSC-V5 12 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 FCC ID: 2BHDN-LSC-V5 13 Appendix A.3: Maximum conducted output power Test Result -CHP Test Mode Antenna Frequency[MHz] Peak power [dBm] Limit [dBm] Verdict 11B Ant1 2412 20.26 ≤30.00 PASS 2437 23.96 ≤30.00 PASS 2462 20.42 ≤30.00 PASS 11G Ant1 2412 21.12 ≤30.00 PASS 2437 19.25 ≤30.00 PASS 2462 22.27 ≤30.00 PASS 11N20SISO Ant1 2412 20.67 ≤30.00 PASS 2437 20.92 ≤30.00 PASS 2462 21.77 ≤30.00 PASS 11N40SISO Ant1 2422 20.74 ≤30.00 PASS 2437 21.11 ≤30.00 PASS 2452 18.42 ≤30.00 PASS FCC ID: 2BHDN-LSC-V5 14 Appendix A.4: Maximum power spectral density Test Result TestMode Antenna Frequency[MHz] Result[dBm/3-100kHz] Limit[dBm/3kHz] Verdict 11B Ant1 2412 -8.95 ≤8.00 PASS 2437 -4.99 ≤8.00 PASS 2462 -8.65 ≤8.00 PASS 11G Ant1 2412 -13.06 ≤8.00 PASS 2437 -14.83 ≤8.00 PASS 2462 -11.80 ≤8.00 PASS 11N20SISO Ant1 2412 -13.49 ≤8.00 PASS 2437 -13.28 ≤8.00 PASS 2462 -11.93 ≤8.00 PASS 11N40SISO Ant1 2422 -15.52 ≤8.00 PASS 2437 -15.06 ≤8.00 PASS 2452 -17.72 ≤8.00 PASS Note： 1. The Duty Cycle Factor and RBW Factor is compensated in the graph. FCC ID: 2BHDN-LSC-V5 15 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 FCC ID: 2BHDN-LSC-V5 16 11G_Ant1_2412 11G_Ant1_2437 FCC ID: 2BHDN-LSC-V5 17 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 FCC ID: 2BHDN-LSC-V5 18 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 FCC ID: 2BHDN-LSC-V5 19 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 FCC ID: 2BHDN-LSC-V5 20 Appendix A.5: Band edge measurements Test Result TestMode Antenna ChName Frequency[MHz] RefLevel[dBm] Result[dBm] Limit[dBm] Verdict 11B Ant1 Low 2412 5.11 -38.25 ≤-14.89 PASS High 2462 5.42 -48.1 ≤-14.58 PASS 11G Ant1 Low 2412 0.87 -33.52 ≤-19.13 PASS High 2462 2.20 -36.57 ≤-17.8 PASS 11N20SISO Ant1 Low 2412 0.37 -34.24 ≤-19.63 PASS High 2462 1.63 -35.27 ≤-18.37 PASS 11N40SISO Ant1 Low 2422 -2.88 -38.99 ≤-22.88 PASS High 2452 -4.35 -47.51 ≤-24.35 PASS FCC ID: 2BHDN-LSC-V5 21 Test Graphs 11B_Ant1_Low_2412 11B_Ant1_High_2462 11G_Ant1_Low_2412 FCC ID: 2BHDN-LSC-V5 22 11G_Ant1_High_2462 11N20SISO_Ant1_Low_2412 FCC ID: 2BHDN-LSC-V5 23 11N20SISO_Ant1_High_2462 11N40SISO_Ant1_Low_2422 11N40SISO_Ant1_High_2452 FCC ID: 2BHDN-LSC-V5 24 FCC ID: 2BHDN-LSC-V5 25 Appendix A.6: Conducted Spurious Emission Test Result TestMode Antenna Frequency[MHz] FreqRange [Mhz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict 11B Ant1 2412 Reference 4.73 4.73 --- PASS 30~1000 4.73 -60.64 ≤-15.27 PASS 1000~26500 4.73 -47.4 ≤-15.27 PASS 2437 Reference 7.91 7.91 --- PASS 30~1000 7.91 -60.32 ≤-12.09 PASS 1000~26500 7.91 -47.38 ≤-12.09 PASS 2462 Reference 4.23 4.23 --- PASS 30~1000 4.23 -59.66 ≤-15.77 PASS 1000~26500 4.23 -47.89 ≤-15.77 PASS 11G Ant1 2412 Reference 0.82 0.82 --- PASS 30~1000 0.82 -57.89 ≤-19.18 PASS 1000~26500 0.82 -48 ≤-19.18 PASS 2437 Reference -0.93 -0.93 --- PASS 30~1000 -0.93 -58.69 ≤-20.93 PASS 1000~26500 -0.93 -46.9 ≤-20.93 PASS 2462 Reference 0.91 0.91 --- PASS 30~1000 0.91 -57.4 ≤-19.09 PASS 1000~26500 0.91 -46.96 ≤-19.09 PASS 11N20SISO Ant1 2412 Reference -0.11 -0.11 --- PASS 30~1000 -0.11 -58.92 ≤-20.11 PASS 1000~26500 -0.11 -48.1 ≤-20.11 PASS 2437 Reference -0.42 -0.42 --- PASS 30~1000 -0.42 -60.46 ≤-20.42 PASS 1000~26500 -0.42 -47.3 ≤-20.42 PASS 2462 Reference 0.90 0.90 --- PASS 30~1000 0.90 -60.12 ≤-19.1 PASS 1000~26500 0.90 -48.09 ≤-19.1…
