2BHEM-X8SHelmet Headset

USER GUIDE AND MANUAL ENDEIT ES FR Motorcycle Helmet Headset -X8S CONTENTS English ------- Deutsch ------- Italiano ------- Español ------- Français ------- CAUTION 1. Please use a standard USB charger with 5V/1A power for charging. (This product does not include a charging AC adapter.) Do not charge in wet areas. 2. Before installing the Headset, please connect your phone according to the instructions and test the volume and sound. If there is a significant difference in volume when installed on the helmet, adjust the position of the helmet's internal speakers. 3.This product is an electronic product for motorcycles. When using this product on the road, please comply with local traffic laws. 4.Please turn off the product near medical equipment. Do not use near medical devices such as pacemakers. 5.Please pay attention to the volume while driving. When using this product for calls, pay attention to your surroundings and keep the call time as short as possible. 6.When driving, do not turn the volume up louder than the surrounding environment to avoid causing harm to others and yourself. 7. Please do not attempt to disassemble this product without authorization. There are many electronic components inside the product, and non-professionals should not attempt to do so. 8.Do not put metal, liquids, flammable substances, medicines, etc., inside this product. [email protected] Customer Support *If you encounter any issues during use, please contact our support email. Installation ②. For adhesive-type mounting brackets, 1.Wipe off any dirt or oil stains from the helmet installation area. 2.Peel off the film on the back of the mounting bracket. 3.Stick it firmly to the installation area of the helmet and press firmly. Note: Do not apply pressure to the bracket within 24 hours after sticking. Damage, loss, or malfunction due to detachment is not covered by the warranty, so please install carefully. ※ Installation and removal of the main unit Installation ① Insert the rear of the main unit into the rear of the base. ② Press the main unit down firmly until you hear a click. Removal ① Press the button on the front to detach the main unit. ① Select the installation position inside the helmet and stick The fluffy Velcro sticker at that position. ② Stick the speaker to the position of the fluffy Velcro sticker. ※ Installation of speakers and microphone ※Before installing the bracket, please select a suitable position. ①. For the clip-on mounting bracket: insert the clip into the base and attach the anti-slip silicone pad to the bottom; position the clip near the edge of the helmet, spread it open, a nd slide it onto the side of the helmet. Note: Damage, loss, or malfunction due to detachment is Not covered by the warranty, so please install carefully. Button Instruction ※Microphone installation Full-face helmet microphone Stick the microphone near the inner side of the helmet's mouth area. Note: For flip-face helmet microphones, please ensure the white arrow faces your mouth. Please do not remove the foam windscreen from The microphone. Flip-face helmet microphone Please point the raised part Of the microphone towards your mouth. Power/Phone Button Volume + Volume - Intercom Button Charging port Note: Even a slight adjustment in speaker placement can significantly affect the audio experience. We recommend connecting to your phone and testing the volume to find the most comfortable position before final installation. Power ON Power OFF Long press the Power button for 3 seconds to power on (blue light flashing, voice prompt indicating the battery power remaining). Long press the Power button for 4 seconds to power off (red light flashing for 1 second) Phone Pairing When the device is powered off, long press the phone button for 5 seconds to enter Bluetooth pairing mode (red and blue lights flashing). Open your phone's Bluetooth settings, Tap on the Bluetooth name: WAYXIN X8S Successfully connected if the blue light is flashing (If your phone prompts you to enable Bluetooth permissions, please grant Bluetooth permissions). Reconnect to your phone When the device and phone are disconnected, single-click the phone button to reconnect. Factory Reset After powering on the device, Press and hold both the Volume + and Volume - buttons simultaneously for 4 seconds; The purple indicator light will flash, And the device will power off. Bluetooth Pairing WAYXIN X8S Make a call / Answer a call Start Call: Press the power button once End call: Press the power button once Reject call: Press the power button twice Play music from your smartphone Phone calls on a smartphone Listen to music Play/Pause: Press the power button once Adjusting the music volume: Press the volume button once. Next track: Press the volume button twice. Previous track: Press the volume button twice. ·Voice assistant function If the device is already paired with your smartphone, press the power button twice. (Launch Siri or Google Assistant) Once Once Twice Once Once Twice Twice Twice FM Radio Radio On/Off: Press the [Phone button] and [Volume -] simultaneously Next channel: Double-click the [volume+] Previous channel: Double-click the [volume-] Volume: Single-click the [volume+]/[volume-] EQ Sound Effects In addition, you can switch between four sound effects whilst playing music: Direct (default), Bass, Rock and Pop. While playing music, press and hold the [Phone Button] and [Volume -] for 4 seconds. but this may be drowned out if the music is too loud. ·Auto-answer On/Off (This feature is disabled by default) With the device powered off, Press and hold both the [Phone Button] and [Volume -] simultaneously for 4 seconds to enable or disable the auto-answer function. (On: Blue light constant for 2 seconds; Off: Red light constant for 2 seconds) press and hold the for 4 seconds. 4S 4S Once Once Music Sharing (Note: This feature works between two units of the same model.） Create a Sharing Link: On both devices, simultaneously press and hold t…

Text truncated - open the document above for the full version.

Local Representative Letter For Certification Service in the USA Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(7), of the Commission’s Rules (47 C.F.R.) we attest as follows for the product listed below: FCC ID Model name 2BHEM-X8S X8S, X6S, X6S Lite, M910, R19, R20, R6S, X5, X6, X8, X8 Lite, X8S Lite We hereby acknowledge as follows: i. both signees confirm that the point of contact accepts responsibility to act as a US- American Representative on behalf of the applicant ii. the point of contact provides the physical U.S. address and email as listed below iii. both parties maintain the requirements of this agreement without expiration date US-American Point of Contact Applicant/Approval Holder Signature Date: 2026-08-11 Signature Date: 2026-08-11 Company Name: WeFa Selection Trade Technology Co., LTD ShenZhen City Xingyaoda Technology Co., Limited FRN: 0033767856 0035640218 Contact Name: Joson Ye Jiabin Liu Address: 30 N. GOULD ST. STE N SHERIDAN WY, SHERIDAN, WY 82801, United States Room 303, 3rd Floor, Xuchong Industrial Park, No. 8, Road 7, Yangyong Industrial Zone, Songgang Street, Bao'an District, Shenzhen, China Phone: (302) 371 9847 +86-15007054895 Email: [email protected] [email protected]

Covered Equipment Attestation Letter For Certification Service in the USA Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(5)(i)-(ii) of the Commission’s Rules (47 C.F.R.) we attest as follows for the product listed below: FCC ID Model name 2BHEM-X8S X8S, X6S, X6S Lite, M910, R19, R20, R6S, X5, X6, X8, X8 Lite, X8S Lite We, Applicant Company Name: ShenZhen City Xingyaoda Technology Co., Limited Address: Room 303, 3rd Floor, Xuchong Industrial Park, No. 8, Road 7, Yangyong Industrial Zone, Songgang Street, Bao'an District, Shenzhen, China Phone: +86-15007054895 certify that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. This includes the cybersecurity and anti-virus software produced or provided by Kaspersky Lab, Inc. or any of ist successors and assignees. We certify that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2026-08-11 Signature Date Name / Title: Jiabin Liu / Manager Company: ShenZhen City Xingyaoda Technology Co., Limited Address: Room 303, 3rd Floor, Xuchong Industrial Park, No. 8, Road 7, Yangyong Industrial Zone, Songgang Street, Bao'an District, Shenzhen, China Phone: +86-15007054895 Fax: N/A E-Mail: [email protected]

Due Diligence Letter For Certification Service in the USA Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern FCC ID Model name 2BHEM-X8S X8S, X6S, X6S Lite, M910, R19, R20, R6S, X5, X6, X8, X8 Lite, X8S Lite Pursuant to KDB 986446 D01 Covered Equipment Guidance the evaluation of the product above shows compliance for the following reasons: Compliance Evaluation process Results Inherent compliance The chipset(s) used is not capable of running the cybersecurity and/or anti-virus software Compliance The memory used does not allow the running the cybersecurity and/or anti-virus software Compliance The storage capacity does not allow the running the cybersecurity and/or anti-virus software Compliance The operating system used is not capable of running the cybersecurity and/or anti-virus software Compliance No inherent compliance Based on software bill of material Based on scan for running software on the device Based on filesystem scan for cybersecurity and/or anti-virus software The equipment for which authorization is sought complies with the rules and fulfils the requirements as detailed in the above mentioned KDB. Evaluation performed by Company Name: Shenzhen Haiyun Standard Technical CO., Ltd. Contact Name: Tim Zhang Address: No. 110-113, 115, 116, Block B, Jinyuan Business Building, Bao'an District, Shenzhen, China Phone: +86-18824863674 Email: [email protected] Signature: Date: 2026-08-05

Confidentiality Request Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request confidentiality for the documentation of the following products: FCC ID Model name 2BHEM-X8S X8S, X6S, X6S Lite, M910, R19, R20, R6S, X5, X6, X8, X8 Lite, X8S Lite For the products listed above, we request permanent confidentiality for all applicable exhibits as there are: • the Operational Description • the Block Diagram • the Schematics • the Part List • the Tune up Information The above listed exhibits contain trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2026-08-11 Signature Date Name / Title: Jiabin Liu / Manager Company: ShenZhen City Xingyaoda Technology Co., Limited Address: Room 303, 3rd Floor, Xuchong Industrial Park, No. 8, Road 7, Yangyong Industrial Zone, Songgang Street, Bao'an District, Shenzhen, China Phone: +86-15007054895 Fax: N/A E-Mail: [email protected]

ShenZhen City Xingyaoda Technology Co., Limited Room 303, 3rd Floor, Xuchong Industrial Park, No. 8, Road 7, Yangyong Industrial Zone, Songgang Street, Bao'an District, Shenzhen, China Date: August 11, 2026 FCC ID: 2BHEM-X8S Model Number: X8S, X6S, X6S Lite, M910, R19, R20, R6S, X5, X6, X8, X8 Lite, X8S Lite To: Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21048 To Whom It May Concern, We, ShenZhen City Xingyaoda Technology Co., Limited hereby declare that our product (Helmet Headset) Model Number: X8S, X6S, X6S Lite, M910, R19, R20, R6S, X5, X6, X8, X8 Lite, X8S Lite, Schematic, Hardware version, Software version, structure and internal photos are same, Model named differently due to marketing purposes. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, (Signed) Name / Title: Jiabin Liu / Manager Company: ShenZhen City Xingyaoda Technology Co., Limited Address: Room 303, 3rd Floor, Xuchong Industrial Park, No. 8, Road 7, Yangyong Industrial Zone, Songgang Street, Bao'an District, Shenzhen, China Phone: +86-15007054895 Fax: N/A E-Mail: [email protected]

External Photos FCC ID: 2BHEM-X8S

X8S标贴 21.4x16.6mm Model:X8S S/N:X8S2026080001 219-268186 FCC ID: 2BHEM-X8S

Internal Photos FCC ID: 2BHEM-X8S BT antenna

HY-FCC 2.1093 Ver.1.1 Page 1 of 5 Report No.: RF260617002-01-003 FCC RF EXPOSURE REPORT FCC ID: 2BHEM-X8S Test Report No...........: RF260709006-01-005 Product(s) Name.........: Helmet Headset Model(s)....................: X8S, X6S, X6S Lite, M910, R19, R20, R6S, X5, X6, X8, X8 Lite, X8S Lite Applicant...................: ShenZhen City Xingyaoda Technology Co., Limited Address....................: Room 303, 3rd Floor, Xuchong Industrial Park, No. 8, Road 7, Yangyong Industrial Zone, Songgang Street, Bao'an District, Shenzhen, China. Receipt Date..............: 2026.07.10 Test Date...................: 2026.07.11 ~ 2026.08.04 Issued Date................: 2026.08.05 Standards..................: CFR47 FCC Part 1: Section 1.1310; CFR47 FCC Part 2: Section 2.1093; FCC KDB Publication 447498 D01; FCC KDB Publication 865664 D02 v01r02 Testing Laboratory......: Shenzhen Haiyun Standard Technical Co., Ltd. Prepared By: Checked By: Approved By: Jason Huang Black Ding Tim Zhang HY-FCC 2.1093 Ver.1.1 Page 2 of 5 Report No.: RF260709006-01-005 History of this test report Original Report Issue Date: 2026.08.05 ● No additional attachment ○ Additional attachments were issued following record Attachment No. Issue Date Description HY-FCC 2.1093 Ver.1.1 Page 3 of 5 Report No.: RF260709006-01-005 1. MPE CALCULATION METHOD Limit Table for Filed Antenna For BLE Antenna gain Antenna Type 2.66dBi Multilayer Ceramic Antenna For BT Antenna gain Antenna Type 2.25dBi Metal Antenna HY-FCC 2.1093 Ver.1.1 Page 4 of 5 Report No.: RF260709006-01-005 2. TEST RESULTS Worst case as below Mode Output power (dBm) Output power (mW) Ant gain (dBi) EIRP (dBm) Distance (cm) Pth (mW) BLE 3.61 2.296 2.66 6.27 0.5 10 Mode Output power (dBm) Output power (mW) Ant gain (dBi) EIRP (dBm) Distance (cm) Pth (mW) BT 3.77 2.382 2.25 6.02 0.5 10 Note: The minimum distance for the EUT is less than 5mm. Since maximum peak output power of the transmitter is 3.77 dBm ≈ 2.382mW < 10 mW. simultaneous transmission operations: 3.77/10+3.61/10=0.738<1 Hence the EUT is excluded from SAR evaluation according to FCC KDB Publication 447498 D01 General RF Exposure Guidance v06.  Conclusion The SAR evaluation is not required HY-FCC 2.1093 Ver.1.1 Page 5 of 5 Report No.: RF260709006-01-005 Statement 1. The report is invalid without the official seal or special seal of Shenzhen Haiyun Standard Technical Co., Ltd. (hereinafter referred to as the unit). 2. The report is invalid without the signature of the approver. 3. The report is invalid if altered arbitrarily. 4. The report shall not be partially copied without the written approval of the unit. 5. The reported test results are only valid for the tested samples. 6. If there is any objection to the test report, it shall be submitted to the test unit within 15 days from the date of receiving the report, and the overdue shall not be accepted. Shenzhen Haiyun Standard Technical Co., Ltd. Address: Room 110, 111, 112, 113, 115, 116, Block B, Jinyuan Business Building, No. 302, Xixiang Avenue, Labor Community, Xixiang Street, Baoan District, Shenzhen, China （END OF REPORT）

Shenzhen Fengrui Communication Technology Co., Ltd. 1 CUSTOMER NAME CUSTOMER P/N PART NAME 2.4G built-in antenna P/ N XYD-B220 APPROVAL REV. A0 DELIVERY DATE 2026.5.6 PREPARED BY Lee CHECKED BY Jack APPROVED BY Customer Approved Approved By Checked By Prepared By Address: Unit 603, Building 2, Huatian Garden, No. 214 Jian'an 1st Road, Xin'an Street, Bao'an District, Shenzhen, China Shenzhen Fengrui Communication Technology Co., Ltd. 2 Directory 1、 The cover。。。。。。。。。。。。。。。。。。。。。。。。。。1 2、 Directory。。。。。。。。。。。。。。。。。。。。。。。。。。2 3、 The antenna's floor plan。。。。。。。。。。。。。。。。。。3 4、 Antenna technical parameters and environmental performance test 。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。4 5、 Physical picture of antenna。。。。。。。。。。。。。。。。5 6、 Antenna performance test chart。。。。。。。。。。。。。。。5 7、 2D .3D(2.4G)test data。。。。。。。。。。。。。。。。。。。6-8 8、 RoHS material control report。。。。。。。。。。。。。。。。9 Shenzhen Fengrui Communication Technology Co., Ltd. 3 Antenna plan： Shenzhen Fengrui Communication Technology Co., Ltd. 4 Antenna technical parameters and environmental testing: Electrical parameters of electrical apparatus Electrical Specifications Mechanical Specifications Frequency Range 2400-2500MHz Antenna material copper VSWR ＜1.92 Working Temperature -20°C~+70°C Input Impedance 50 Ω Working Humidity 20%~80% Direction All Gain 2.25 dBi Environmental performance test: project test condition standard Storage Conditions In the absence of specified test temperature, humidity, air pressure is as follows: 1. Temperature is - 20 °C ~ + 70 °C 2. Relative humidity of 45% to 45% 3. Air pressure is 86 kpa to 106 kpa Electrical and mechanical properties is normal high and low temperature test Between 70 °C and -20 °C for 5 loops, then 1-2 h under normal conditions, check the appearance quality. Size should meet the requirements and should satisfy the content with the electrical and mechanical properties Constant damp and hot resistance test 95 + / - 3% relative humidity, temperature test: 40 °C . Lasts 2 h after, try to take out the determination of electrical properties, within 5 min after try 1-2 h under article normal thing, check the appearance quality Size should meet the requirements and should satisfy the content with the electrical and mechanical properties vibration test 10-55 hz, vibration frequency range of displacement amplitude: 0.35 MM, acceleration amplitude: 50.0 M/S, sweep cycles: 30 times Electrical and mechanical properties is normal fall down test 1 m high altitude in accordance with the perpendicular axis free drop 3 times Electrical and mechanical properties is normal Shenzhen Fengrui Communication Technology Co., Ltd. 5 Physical picture of antenna： Antenna performance test chart： Shenzhen Fengrui Communication Technology Co., Ltd. 6 2D .3Dtest data: （2.4Gtest data） Frequency Efficiency (%) Gain.(dBi) 2400MHz 51.17 1.84 2410MHz 51.52 1.69 2420MHz 54.20 1.96 2430MHz 51.29 2.02 2440MHz 47.64 2.00 2450MHz 47.86 2.25 2460MHz 46.56 1.89 2470MHz 47.53 1.92 2480MHz 48.98 1.78 2490MHz 50.23 1.83 2500MHz 45.81 1.51 Shenzhen Fengrui Communication Technology Co., Ltd. 7 Shenzhen Fengrui Communication Technology Co., Ltd. 8 Shenzhen Fengrui Communication Technology Co., Ltd. 9 Material RoHS conformity declaration form We hereby certify that the raw materials used and the additives in the production engineering of the products to your company are conformed to the RoHS environmental requiremetns. (RoHS directive 2011/65 / EU) About the report of composition of raw materials, packaging materials and additives used in the production process for components and auxiliary materials is as bellow: Component /Part Name Material Composition ICP report # Test Org. Test Date Content of harmful substances (ppm) PASS? Cd Pb Hg Cr 6+ PBB PBDE PASS Cupronicke l Cupronickel CANEC1922053501 SGS 19/11/13 ND 28 ND ND ND ND PASS Walsin Technology Corporation Page 1 of 8 ASC_RFANT5220110A0T_V08 Sep. 2006 MULTILAYER CERAMIC ANTENNA RFANT Series – RoHS Compliance 2.4 GHz ISM Band Working Frequency P/N: RFANT5220110A0T *Contents in this sheet are subject to change without prior notice . *Address: No. 566-1, Kao-Shi Road, Yangmei District, Taoyuan City, 32668, Taiwan Walsin Technology Corporation Page 2 of 8 ASC_RFANT5220110A0T_V08 Sep. 2006 L= 2.0 ±0.2 mm T= 1.15 ±0.10 mm W = 5.2 ± 0.2 mm B = 0.40 ± 0.25 mm A = 0.40 ± 0.25 mm WTC L= 2.0 ±0.2 mm T= 1.15 ±0.10 mm W = 5.2 ± 0.2 mm B = 0.40 ± 0.25 mm A = 0.40 ± 0.25 mm WTC FEATURES … Surface Mounted Devices with a small dimension of 5.2 x 2.0 x 1.1 mm 3 meet future miniaturization trend. … Embedded and LTCC (Low Temperature Co-fired Ceramic) technology is able to future integrate with system design as well as beautifying the housing of final product. … High Stability in Temperature / Humidity Change APPLICATIONS … Bluetooth … Wireless LAN … HormRF … ISM band 2.4GHz wireless applications DESCRIPTION Walsin Technology Corporation develops a new ceramic embedded antenna specified for 2.4 GHz ISM Band application, as shown in below “CONSTRUCTION”. Both of Wireless LAN IEEE 802.11b and Bluetooth TM typically located on this unlicensed frequency band which range covers from 2.4GHz to 2.4835GHz. To fulfil the friendly usage for antenna, this antenna has been designed to a typical 150MHz bandwidth through Walsin’s advanced LTCC (Low Temperature Co-fired Ceramic) technology and superior product design via 3D EM Simulation Skill. This antenna has a rectangular ceramic body with a tiny dimension of 5.2x 2.0 x 1.1 mm 3 meet the future SMT automation and miniaturization requirements on modern portable devices. CONSTRUCTION Fig 1. Outline of 2.4GHz Antenna – RFANT5220110A0T Fig 2. Dimension W T C W T C Soldering terminal Identification mark Feeding W T C W T C Soldering terminal Identification mark Feeding Walsin Technology Corporation Page 3 of 8 ASC_RFANT5220110A0T_V08 Sep. 2006 SOLDER LAND PATTERN DESIGN Figure ELECTRICAL CHARACTERISTICS Item Specification Working Frequency Range 2.4 GHz ～ 2.5GHz Gain 2 dBi (Typical) VSWR…

Text truncated - open the document above for the full version.

HY-FCC part 15C-BT Ver.1.1 Page 1 of 88 Report No.: RF260709006-01-002 RF TEST REPORT FCC ID: 2BHEM-X8S Test Report No...........:RF260709006-01-002 Product(s) Name.........:Helmet Headset Model(s)....................:X8S, X6S, X6S Lite, M910, R19, R20, R6S, X5, X6, X8, X8 Lite, X8S Lite Trade Mark................:N/A Applicant...................:ShenZhen City Xingyaoda Technology Co., Limited Address.....................:Room 303, 3rd Floor, Xuchong Industrial Park, No. 8, Road 7, Yangyong Industrial Zone, Songgang Street, Bao'an District, Shenzhen, China. Receipt Date..............:2026.07.10 Test Date...................:2026.07.11 ~ 2026.08.04 Issued Date................:2026.08.05 Standards..................:47 CFR FCC Part 15, Subpart C(Section 15.247) ANSI C63.10: 2020 Testing Laboratory......:Shenzhen Haiyun Standard Technical Co., Ltd. Prepared By:Checked By:Approved By: Jason HuangBlack DingTim Zhang HY-FCC part 15C-BT Ver.1.1 Page 2 of 88 Report No.: RF260709006-01-002 Table of Contents 1 . SUMMARY OF TEST RESULTS6 1.1 TEST FACILITY7 1.2 MEASUREMENT UNCERTAINTY7 1.3 TEST ENVIRONMENT CONDITIONS7 2 . GENERAL INFORMATION8 2.1 GENERAL DESCRIPTION OF EUT8 2.2 DESCRIPTION OF TEST MODES10 2.3 PARAMETERS OF TEST SOFTWARE11 2.4 SUPPORT UNITS11 3 . AC POWER LINE CONDUCTED EMISSIONS12 3.1 LIMIT12 3.2 TEST PROCEDURE12 3.3 DEVIATION FROM TEST STANDARD12 3.4 TEST SETUP13 3.5 EUT OPERATING CONDITIONS13 3.6 TEST RESULTS13 4 . RADIATED EMISSIONS16 4.1 LIMIT16 4.2 TEST PROCEDURE17 4.3 DEVIATION FROM TEST STANDARD18 4.4 TEST SETUP18 4.5 EUT OPERATING CONDITIONS19 4.6 TEST RESULTS - 9 KHZ TO 30 MHZ19 4.7 TEST RESULTS - 30 MHZ TO 1000 MHZ19 4.8 TEST RESULTS - ABOVE 1000 MHZ19 5 . NUMBER OF HOPPING FREQUENCY20 5.1 LIMIT20 5.2 TEST PROCEDURE20 5.3 DEVIATION FROM STANDARD20 5.4 TEST SETUP20 5.5 EUT OPERATION CONDITIONS20 5.6 TEST RESULTS20 6 . AVERAGE TIME OF OCCUPANCY21 6.1 LIMIT21 6.2 TEST PROCEDURE21 HY-FCC part 15C-BT Ver.1.1 Page 3 of 88 Report No.: RF260709006-01-002 6.3 DEVIATION FROM STANDARD21 6.4 TEST SETUP21 6.5 EUT OPERATION CONDITIONS21 6.6 TEST RESULTS21 7 . HOPPING CHANNEL SEPARATION22 7.1 LIMIT22 7.2 TEST PROCEDURE22 7.3 DEVIATION FROM STANDARD22 7.4 TEST SETUP22 7.5 EUT OPERATION CONDITIONS22 7.6 TEST RESULTS22 8 . BANDWIDTH23 8.1 LIMIT23 8.2 TEST PROCEDURE23 8.3 DEVIATION FROM STANDARD23 8.4 TEST SETUP23 8.5 EUT OPERATION CONDITIONS23 8.6 TEST RESULTS23 9 . MAXIMUM OUTPUT POWER24 9.1 LIMIT24 9.2 TEST PROCEDURE24 9.3 DEVIATION FROM STANDARD24 9.4 TEST SETUP24 9.5 EUT OPERATION CONDITIONS24 9.6 TEST RESULTS24 10 . CONDUCTED SPURIOUS EMISSION25 10.1 LIMIT25 10.2 TEST PROCEDURE25 10.3 DEVIATION FROM STANDARD25 10.4 TEST SETUP25 10.5 EUT OPERATION CONDITIONS25 10.6 TEST RESULTS25 11 . MEASUREMENT INSTRUMENTS LIST26 12 . ANTENNA REQUIREMENT27 APPENDIX A - RADIATED EMISSION - 9 KHZ TO 30 MHZ28 APPENDIX B - RADIATED EMISSION - 30 MHZ TO 1000 MHZ29 APPENDIX C - RADIATED EMISSION - ABOVE 1000 MHZ32 HY-FCC part 15C-BT Ver.1.1 Page 4 of 88 Report No.: RF260709006-01-002 APPENDIX D - NUMBER OF HOPPING FREQUENCY43 APPENDIX E - AVERAGE TIME OF OCCUPANCY46 APPENDIX F - HOPPING CHANNEL SEPARATION54 APPENDIX G - BANDWIDTH57 APPENDIX H - MAXIMUM OUTPUT POWER66 APPENDIX I - CONDUCTED SPURIOUS EMISSION71 APPENDIX J - DECLARATION FOR BLUETOOTH DEVICE85 HY-FCC part 15C-BT Ver.1.1 Page 5 of 88 Report No.: RF260709006-01-002 HISTORY OF THIS TEST REPORT Original Report Issue Date: 2026.08.05 ● No additional attachment ○ Additional attachments were issued following record Attachment No.Issue DateDescription HY-FCC part 15C-BT Ver.1.1 Page 6 of 88 Report No.: RF260709006-01-002 1.. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC CFR Title 47, Part 15, Subpart C Standard(s) Section Test ItemTest ResultJudgmentRemark 15.207 AC Power Line Conducted Emissions SECTION 3.6 PASS------ 15.247(d) 15.205(a) 15.209(a) Radiated Emission APPENDIX A APPENDIX B APPENDIX C PASS------ 15.247 (a)(1)(iii) Number of Hopping Frequency APPENDIX D PASS------ 15.247 (a)(1)(iii) Average Time of Occupancy APPENDIX E PASS------ 15.247(a)(1)Hopping Channel Separation APPENDIX F PASS------ 15.247(a)(1)Bandwidth APPENDIX G PASS------ 15.247(a)(1)Maximum Output Power APPENDIX H PASS------ 15.247(d)Conducted Spurious Emission APPENDIX I PASS------ 15.203Antenna Requirement ------ PASSNote(2) Note: (1) “N/A” denotes test is not applicable in this test report (2) The device what use a permanently attached antenna were considered sufficient to comply with the provisions of 15.203. HY-FCC part 15C-BT Ver.1.1 Page 7 of 88 Report No.: RF260709006-01-002 1.1. TEST FACILITY Company:Shenzhen Haiyun Standard Technical Co., Ltd. Address: No. 110-113, 115, 116, Block B, Jinyuan Business Building, Bao'an District, Shenzhen, China CNAS Registration Number: CNAS L18252 CAB identifier:CN0145 A2LA Certificate Number:6823.01 1.2. MEASUREMENT UNCERTAINTY ISO/IEC 17025 requires that an estimate of the measurement uncertainties associated with the emissions test results be included in the report. The measurement uncertainties given below are based on a 95% confidence level (based on a coverage factor (k=2)) Uncertainty ParameterUncertainty Occupied Channel Bandwidth±102kHz RF power conducted±0.243dB Power Spectral Density ±0.743dB Conducted Spurious Emission±1.328dB Time ±0.19％ Conducted emission(9kHz~30MHz) AC main±2.68dB Radiated emission(9kHz~30MHz)±3.50dB Radiated emission (30MHz~1GHz)±4.20dB Radiated emission (1GHz~18GHz)±5.10dB Radiated emission (18GHz~40GHz)±5.26dB Note: Unless specifically mentioned, the uncertainty of measurement has not been take into account to declare the compliance or non-compliance to the specification. 1.3. TEST ENVIRONMENT CONDITIONS Test Item Temperatur e HumidityTest VoltageTested By Radiated Emissions-9 kHz to 30 MHz22.6°C48%AC 120V/60Hz Keith Huang Radiated Emissions-30 MHz to 1000 MHz22.6°C48%AC 120V/60Hz Keith Huang Radiated Emissions-Above 1000 MHz22.6°C48%AC 120V/60Hz Keith Huang Bandwid…

Text truncated - open the document above for the full version.

Test Photos Photograph 1: Set-up photo for Radiated Spurious Emission, 30MHz - 1GHz Photograph 2: Set-up photo for Radiated Spurious Emission, 1GHz - 18GHz FCC ID: 2BHEM-X8S Photograph 3: Set-up photo for Conducted test(RF) Photograph 3: Set-up photo for Conducted emission test
