Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
1 Product User Manual Vehicle Terminal T-BOX Product Model:T29-CEV HANGZHOU HUIJIECHELIAN TECHNOLOGY CO., LTD 1 Product Composition and Interface Definition 1、 Product Overview Vehicle Terminal T-Box provided a remote intelligent vehicle control terminal, the main functions are remote start / flameout vehicle, remote switch window, remote switch tail box, remote switch air conditioning, reading the whole car fault code, remote diagnosis, etc. The T-BOX supports three communication modes: 4G, BLE, and can still support users to control the car in special scenarios such as no network signal and mobile phone shutdown. The T-BOX can monitor the door lock, door, window, sunroof, air conditioning, battery voltage, BMS battery status, which users can view in real time through the APP. When the vehicle has anti-theft alarm, tire failure and other problems, T-BOX can immediately push the fault information to the owner's mobile phone. The T-BOX can follow the vehicle to sleep, reducing its power consumption to a minimum when the vehicle is dormant. When the vehicle wakes up or the user controls the vehicle through the network, BLE , T-BOX will automatically wake up and enter the working state. 1 2、 Product physical schematic diagram 1 1 Product name:Vehicle Terminal T-BOX Product model:T29-CEV Product size:L160mm*W120mm*H40mm 3、Product External Interface Definition Figure 1:Main connector Figure 1 view direction of main connector Pin Signal Type Description 1 Digital Input IGN ON 19 Digital Signal CAN H 20 Power Power 39 Digital Signal CAN L 40 GND Power Ground others reserved 1 4. Description of production parameters and functions 1. List of production parameters 2. List of production functions Function Type Function Items Description Remote Control Lock/Unlock Open/Close Window Open/Close Trunk Open/Close Sunroof Open/Close Air Conditioner Set Temperature Status Monitor Monitoring vehicle Status Including status of door lock, doors, windows, trunk, sunroof, air conditioner and battery pack. Diagnostic Read DTC Read DTC of the vehicle Remote Diagnose Support dealer shop to diagnose the vehicle with the support of this production and another remote diagnose device. Others Updating Firmware Support BLE/Net to update device firmware 5. Product installation operation process 1. Equipment installation NO. Items Specification remark 1 Operating voltage 9-16VDC 10-100mA 2 Operating current 25mA@12V(Quiescent 10mA ) 3 Size L117mm*W98mm*H37mm 4 Communication Type 4G、Bluetooth 5 Operating temperature -40 ~ +85°C 6 Storage temperature -40 ~ +85°C 1 (1) Check the equipment Check whether the equipment appearance is good, whether the relevant accessories are complete. (2)Select the terminal installation location requirements (3)The terminal host shall be installed in the designated position of the vehicle, connected to the reserved main line of the vehicle, and fixed with screws. 2. Device binding and activation After the equipment is installed, the dealer operator shall use the B-end APP to bind the equipment with the vehicle, and check that all the vehicle control functions are normal. After passing the test, the equipment will be automatically activated. 6. Analysis of Common Problems 1、Common problem analysis fault phenomenon analysis of causes processing method The equipment is offline SIM card overdue shutdown Contact the network operator to pay for the fee Vehicles are in the underground parking lot, and the tunnel signal is weak Leave the area with a poor signal 1 2、 Precautions 1. Please pay attention to waterproof for electronic products. 2. Electricity is DC 9-15VDC 100mA DC, installation should first determine whether the user's power system is within this range, exceeding the maximum voltage of the terminal will damage the terminal. 3. When the ambient temperature exceeds the normal operating temperature range of the terminal, it is recommended to reduce the power off. 4. When the vehicle is in an underground parking lot, tunnel or garage, it will affect the signal of the location. And the communication network signal blind area may cause the equipment to go offline; when the vehicle leaves the above area, the equipment will automatically return to normal operation. 5. In case of any abnormal situation, please do not repair it by yourself. The manufacturer shall not be liable for damage caused by connection of non-original accessories or removed connections between parts. 7. After sales service 1. This product shall enjoy a one-year warranty service from the date of installation. During the warranty period, for equipment damage caused by non-human factors or product quality, please contact the agent or call the after-sales service department 2. The damage caused by the customer's private disassembly or force majeure (such as flood, vehicle accident) shall not be repaired. 3. After the expiration of the warranty period, the product damage and failure caused by the use, but the cost of maintenance materials should be charged.4. Provide customers with free consulting and technical services such as the purchase, use and installation of products. FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful interference in a residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and used in accordance with the instructions, maycause harmful interference to radio communications. However, there is no guarantee thatinterference will not occur in a particular installation. If this equipment does cause harmfulinterference to radio or television reception, which can be determined by turning the equipmentoff and on, the user is encouraged to try to correct the interference by one or more of thefollowing measures: • Reorient or relocate the receiving antenna. • Increase the separation betwee…
Text truncated - open the document above for the full version.
HANGZHOU HUIJIECHELIAN TECHNOLOGY CO., LTD Room 109, Floor 1, Suite B, Building 25, No.9, Jiusheng Road, Shangcheng District,Hangzhou,Zhejiang Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-7-11 To whom it may concern: We, HANGZHOU HUIJIECHELIAN TECHNOLOGY CO., LTD, hereby certify that the equipment for which authorization is sought (FCC ID: 2BHFT-T29-CEV) is not “covered” equipment prohibited from receiving an equipment authorization pursuant to § 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, we are not identified on the Covered List (https://www.fcc.gov/supplychain/coveredlist) as an entity producing “covered” equipment. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(b) and (d)(5) and (6). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Sincerely, Signature Jinghua Zeng Manager HANGZHOU HUIJIECHELIAN TECHNOLOGY CO., LTD 62_[model] CoveredEqu_2.911(d)(5)(i) and (ii) - U, V03
HANGZHOU HUIJIECHELIAN TECHNOLOGY CO., LTD Room 109, Floor 1, Suite B, Building 25, No.9, Jiusheng Road, Shangcheng District, Hangzhou, Zhejiang, China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024/07/05 U.S. Agent Designation HANGZHOU HUIJIECHELIAN TECHNOLOGY CO., LTD acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2BHFT-T29-CEV): Name and company of U.S. agent: GSS SERVICE INC Physical U.S. address of agent: 6547 N Academy Blvd #2266 Colorado Springs COLORADO 80918 United States FRN of U.S. agent: 0033402082 Email address of U.S. agent: [email protected] GSS SERVICE INC acknowledges their obligation to accept service of process on behalf of HANGZHOU HUIJIECHELIAN TECHNOLOGY CO., LTD HANGZHOU HUIJIECHELIAN TECHNOLOGY CO., LTD with the FRN [0035647965] accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature Jinghua Zeng General Manager HANGZHOU HUIJIECHELIAN TECHNOLOGY CO., LTD Signature Michoux Logan PM GSS SERVICE INC 48_[mo del] US_Agent_2.911(d)(7) - U, V0 5
HANGZHOU HUIJIECHELIAN TECHNOLOGY CO., LTD Add: Room 109, Floor 1, Suite B, Building 25, No.9, Jiusheng Road, Shangcheng District,Hangzhou,Zhejiang Date: 2024-7-11 FCC ID: 2BHFT-T29-CEV Dear Sir/Madam, We, HANGZHOU HUIJIECHELIAN TECHNOLOGY CO., LTD Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: Vehicle Terminal T-BOX Model no.: T29-CEV, T69-CEV, T79-CEV, T89-CEV, T99-CEV Sincerely, Name/Title: Jinghua Zeng/Manager Company: HANGZHOU HUIJIECHELIAN TECHNOLOGY CO., LTD Address: Room 109, Floor 1, Suite B, Building 25, No.9, Jiusheng Road, Shangcheng District,Hangzhou,Zhejiang Phone: 13360531435 Fax: N/A E-Mail: [email protected]
CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2024-7-11> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2BHFT-T29-CEV T29-CEV For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title: Jinghua Zeng/Manager Company: HANGZHOU HUIJIECHELIAN TECHNOLOGY CO., LTD Address: Room 109, Floor 1, Suite B, Building 25, No.9, Jiusheng Road, Shangcheng District,Hangzhou,Zhejiang Phone: 13360531435 Fax: N/A E-Mail: [email protected]
HANGZHOU HUIJIECHELIAN TECHNOLOGY CO., LTD Room 109, Floor 1, Suite B, Building 25, No.9, Jiusheng Road, Shangcheng District,Hangzhou,Zhejiang Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-7-11 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2BHFT-T29-CEV including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. By signing this application form, we agree to Eurofins’ current valid General Terms and Conditions (AGB),Testing and Certification Regulations (PZO) which can be viewed on following website www.eurofins.de/ee or retrieved on request. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title: Jinghua Zeng/Manager Company: HANGZHOU HUIJIECHELIAN TECHNOLOGY CO., LTD Address: Room 109, Floor 1, Suite B, Building 25, No.9, Jiusheng Road, Shangcheng District,Hangzhou,Zhejiang Phone: 13360531435 Fax: N/A E-Mail: [email protected]
FCC ID: 2BHFT-T29-CEV External Photos of the EUT FCC ID: 2BHFT-T29-CEV FCC ID: 2BHFT-T29-CEV
Label and Location Size: L: 4cm*W: 3cm Label and Location FCC ID: 2BHFT-T29-CEV
FCC ID: 2BHFT-T29-CEV Internal Photos of the EUT LTE ANT FCC ID: 2BHFT-T29-CEV FCC ID: 2BHFT-T29-CEV BT ANT FCC ID: 2BHFT-T29-CEV
RF Exposure evaluation FCC ID: 2BHFT-T29-CEV Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Mobile Device 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2. Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Antenna Information T29-CEV can only use antennas certificated as follows provided by manufacturer; Antenna No. Model No. of antenna: Type of antenna: Gain of the antenna (Max.) Frequency range: BLE / PCB antenna 1.25dBi for 2400-2500MHz; LTE / PCB antenna LTE Band 5 (824-849MHz): 2.49dBi LTE Band 2 (1850-1910MHz): 2.66dBi LTE Band 4 (1710-1755MHz): 3.26dBi LTE Band 7(2500 MHz -2570MHz): 3.36dBi LTE Band 66(1710 MHz -1780MHz): 2.66dBi 5. Manufacturing Tolerance Mode Max. Peak Conducted Output Power (dBm) Max. tune-up BLE -3.65 -3.0±1 Mode Max. Average Conducted Output Power (dBm) Max. tune-up Band 2 24.27 24±1 Band 4 22.44 22±1 Band 5 23.7 23±1 Band 7 17.97 18±1 Band 66 22.52 22±1 6. Standalone MPE Result As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of the used antenna is refer to section, the RF power density can be obtained. Modulation Type Output power Antenna Gain (dBi) Antenna Gain (linear) MPE (mW/cm 2 ) MPE Limits (mW/cm 2 ) dBm mW BLE -2.0 0.6310 1.25 1.3335 0.0002 1.0000 Band 2 25.0 316.2278 2.66 1.8450 0.1161 1.0000 Band 4 23.0 199.5262 3.26 2.1184 0.0841 1.0000 Band 5 24.0 251.1886 2.49 1.7742 0.0887 0.55 Band 7 19.0 79.4328 3.36 2.1677 0.0343 1.0000 Band 66 23.0 199.5262 2.66 1.8450 0.0733 1.0000 Remark: 1. Output power (Peak) including turn-up tolerance; 2. MPE evaluate distance is 20cm from user manual provide by manufacturer. 7. simultaneous MPE Result BLE MPE (Ratio) LTE MPE (Ratio) simultaneous MPE (Ratio) MPE Limits (Ratio) 0.0002 0.1161 0.1163 1.0000 8. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device. ----------------THE END OF REPORT---------------
1. Antenna Description: Antenna type PCB antenna Model T29-CEV-BT Frequency range 2400-2500MHz Manufacturer HANGZHOU HUIJIECHELIAN TECHNOLOGY CO., LTD ANT Peak Gain 1.25 dBi 2. Antenna Photo: Length :12.22mm Width:5.86mm 3. Test Equipment & Conditions 3.1 Test instrument VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. 3.2 Test environment and methods 4.Antenna Radiation Pattern 2400MHz 2450MHz 2500MHz
Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ........................................... : CTA24061900201 2BHFT-T29-CEV Compiled by ( position+printed name+signature) .. : File administrators Jinghua Xiao Supervised by ( position+printed name+signature) .. : Project Engineer Lushan Kong Approved by ( position+printed name+signature) .. : RF Manager Eric Wang Date of issue ..................................... : Jul. 13, 2024 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Applicant’s name ............................ : HANGZHOU HUIJIECHELIAN TECHNOLOGY CO., LTD Address ............................................ : Room 109, Floor 1, Suite B, Building 25, No.9, Jiusheng Road, Shangcheng District, Hangzhou, Zhejiang, China Test specification ...........................: Standard ........................................... : FCC Part 15.247 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Vehicle Terminal T-BOX Trade Mark ....................................... : OBDWEB Manufacturer .................................... : HANGZHOU HUIJIECHELIAN TECHNOLOGY CO., LTD Model/Type reference....................... : T29-CEV Listed Models .................................. : T69-CEV, T79-CEV, T89-CEV, T99-CEV Modulation ....................................... : GFSK Frequency .......................................... From 2402MHz to 2480MHz Ratings ............................................. : DC 9-15V From external circuit Result................................................ : PASS Report No.: CTA24061900201 Page 2 of 37 T E S T R E P O R T Equipment under Test : Vehicle Terminal T-BOX Model /Type : T29-CEV Listed Models : T69-CEV, T79-CEV, T89-CEV, T99-CEV Applicant : HANGZHOU HUIJIECHELIAN TECHNOLOGY CO., LTD Address : Room 109, Floor 1, Suite B, Building 25, No.9, Jiusheng Road, Shangcheng District, Hangzhou, Zhejiang, China Manufacturer : HANGZHOU HUIJIECHELIAN TECHNOLOGY CO., LTD Address : Room 109, Floor 1, Suite B, Building 25, No.9, Jiusheng Road, Shangcheng District, Hangzhou, Zhejiang, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA24061900201 Page 3 of 37 Contents 1 T E S T S T A N D A R D S .................................................................. 4 2 S U M M A R Y ............................................................................. 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 6 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T ............................................................... 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 9 3.6 Equipments Used during the Test 10 4 T E S T C O N D I T I O N S A N D R E S U L T S ............................................ 11 4.1 AC Power Conducted Emission 11 4.2 Radiated Emissions and Band Edge 12 4.3 Maximum Peak Output Power 18 4.4 Power Spectral Density 19 4.5 6dB Bandwidth 22 4.6 Out-of-band Emissions 25 4.7 Antenna Requirement 30 5 T E S T S E T U P P H O T O S O F T H E E U T .......................................... 31 6 P H O T O S O F T H E E U T ............................................................. 32 Report No.: CTA24061900201 Page 4 of 37 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 V03r05: Guidance for Performing Compliance Measurements on Digital Transmission Systems (DTS) Operating Under §15.247 Report No.: CTA24061900201 Page 5 of 37 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Jun. 20, 2024 Testing commenced on : Jun. 20, 2024 Testing concluded on : Jul. 13, 2024 2.2 Product Description Product Description: Vehicle Terminal T-BOX Model/Type reference: T29-CEV Power supply: DC 9-15V From external circuit Hardware version: V1.0 Software version: V1.1.2 Testing sample ID: CTA240619002-1# (Engineer sample) CTA240619002-2# (Normal sample) Bluetooth BLE Supported type: Bluetooth low Energy Modulation: GFSK Operation frequency: 2402MHz to 2480MHz Channel number: 40 Channel separation: 2 MHz Antenna type: PCB antenna Antenna gain: 1.25 dBi 2.3 Equipment Under Test Power supply system utilised Power supply voltage : ○ 230V / 50 Hz ○ 120V / 60Hz ● 12 V DC ○ 24 V DC ○ Other (specified in blank below) / 2.4 Short description of the Equipment under Test (EUT) This is a Vehicle Terminal T-BOX. For more details, refer to the user’s manual of the EUT. Report No.: CTA24061900201 Page 6 of 37 2.5 EUT operation mode The Applicant …
Text truncated - open the document above for the full version.
Report No.: CTA24061900201 Page 29 of 37 Band-edge Measurements for RF Conducted Emissions: BLE GFSK 1Mpbs Left bandedge Right bandedge BLE GFSK 2Mpbs Left bandedge Right bandedge Report No.: CTA24061900201 Page 30 of 37 4.7 Antenna Requirement Standard Applicable For intentional device, according to RSS-Gen 6.8: An intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. The use of a permanently attached antenna or of an antenna that uses a unique coupling to the intentional radiator, the manufacturer may design the unit so that a broken antenna can be replaced by the user, but the use of a standard antenna jack or electrical connector is prohibited For intentional device, according to FCC 47 CFR Section 15.203: An intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. The use of a permanently attached antenna or of an antenna that uses a unique coupling to the intentional radiator, the manufacturer may design the unit so that a broken antenna can be replaced by the user, but the use of a standard antenna jack or electrical connector is prohibited FCC CFR Title 47 Part 15 Subpart C Section 15.247(c) (1) (I): (i) Systems operating in the 2400-2483.5 MHz band that is used exclusively for fixed. Point-to-point operations may employ transmitting antennas with directional gain greater than 6dBi provided the maximum conducted output power of the intentional radiator is reduced by 1 dB for every 3 dB that the directional gain of the antenna exceeds 6dBi. Test Result: The maximum gain of antenna was 1.25 dBi. Remark:The antenna gain is provided by the customer , if the data provided by the customer is not accurate, Shenzhen CTA Testing Technology Co., Ltd. does not assume any responsibility. Report No.: CTA24061900201 Page 31 of 37 5 T e s t S e t u p P h o t o s o f t h e E U T Report No.: CTA24061900201 Page 32 of 37 6 P h o t o s o f t h e E U T Report No.: CTA24061900201 Page 33 of 37 Report No.: CTA24061900201 Page 34 of 37 Report No.: CTA24061900201 Page 35 of 37 LTE ANT Report No.: CTA24061900201 Page 36 of 37 Report No.: CTA24061900201 Page 37 of 37 **********************End of Report********************** BT ANT
FCC ID: 2BHFT-T29-CEV Test Setup Photos of the EUT
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 400.00 µW |
