2BHH3AD31Vision Enhancement Imager

Thank you for purchasing this product. Please read this Guide first and keep it properly for future reference. We hope this product will meet your expectations. Quickstart Guide Vision Enhancement Imager Bobcat B Important This Guide is a general guide for a series of products, which means that the product you receive may differ from the description in the Guide. The actual product you receive shall prevail. This Guide is prepared to introduce our products to the users. We will try our best to ensure the accuracy of the Guide, but the completeness of the Guide still cannot be guaranteed, because our products have been continuously upgraded. We reserve the right to modify at any time without prior notice. IIIustrations P1 1 2 3 7 10 9 11 8 6 5 4 P2 P3 12 iOS Android EN English 1. Appearance (P1~P2) No.DescriptionFunction 1Power Switch Short press: shutter compensation/wake-up/exit menu Long press: power on/off 2MENU Short press: bring up the shortcut menu/confirm to save the settings Long press: bring up the main menu/exit the current menu without saving 3UP Short press: photography/menu option switching Long press: video recording/menu option switching 4DOWN Short press: quick pseudo color switching/ menu option switching Long press: exit shortcut pseudo color menu/ menu option switching 5Lens capLens protection 6Battery compartmentSpace to accommodate battery 7Left focusing knob Turn toward the eyepiece lens for close focus regulation Turn toward the objective lens for far focus regulation 8Right focusing knob Turn toward the eyepiece lens for far focus regulation Turn toward the objective lens for close focus regulation No.DescriptionFunction 9MICSound recording port 10Type-C portConnection with PC and external screen via type-C cable 11 Regulating ringRotating the fixable optical sight 12Adapter ringConnection with the devices and the optical sight 2. Battery Installation (P2) 1. Push the battery compartment cover buckle to open the battery compartment cover; 2. Insert 2 batteries according to the "+” and "-" indications; 3. Close the battery compartment cover; 3. Data transmission (P2) 1. Turn on the device to a power-on state; 2. Connect the device to the PC via USB-Type C cable; 3. Access the data stored in the device from the PC side; 4. Mobile APP connection (P3) 1. Turn on the device to a power-on state; 2. Open the WiFi Hotspot in the device; 3. Search the device's WiFi hotspot name with the mobile phone and connect the WiFi hotspot; 4. Open the TargetIR APP on the mobile phone to see the real-time screen of the device, allowing device control and access; 5. Detailed operation Scan the QR code for more instructions. 1. Apariencia (P1~P2) N.ºComponenteFunción 1Botón de encendido Pulsar: calibración de obturador / activar / salir del menú Mantener pulsado: conectar / desconectar la fuente de alimentación 2Botón de menú Pulsar: abrir el menú de acceso directo / confirmar y guardar la configuración Mantener pulsado: abrir el menú principal / salir del menú actual sin guardar 3Arriba Pulsar: tomar fotos / cambiar opciones del menú Mantener pulsado: grabar vídeos/ cambiar opciones del menú 4Abajo Pulsar: cambio rápido del pseudocolor / cambiar opciones del menú Mantener pulsado: salir del menú de pseudocolor de acceso directo / cambiar opciones del menú 5Tapa de lenteProtección de la lente 6Compartimiento de la bateríaLa batería se instala aquí 7Perilla de enfoque izquierda Gírela hacia el ocular para acercar el zoom Gírela hacia el objetivo para alejar el zoom 8Perilla de enfoque derecha Gírela hacia el ocular para alejar el zoom Gírela hacia el objetivo para acercar el zoom ES Español N.ºComponenteFunción 9MICConector de micrófono 10Interfaz Type - CConectar la PC a la pantalla externa utilizando un cable type-C 11Anillo de ajusteGírelo para fijar el visor óptico 12Anillo adaptadorConectar el dispositivo al visor óptico 2. Instalación de la batería (P2) 1. Empuje la hebilla de la tapa del compartimiento de la batería y abra la tapa; 2. Instale las dos (2) baterías teniendo en cuenta las marcas de los terminales positivo y negativo; 3. Cierre la tapa del compartimiento de la batería; 3. Transmisión de datos (P2) 1. Encienda el dispositivo; 2. Conecte el dispositivo a la PC utilizando un cable USB-TypeC; 3. Acceda a los datos almacenados en el dispositivo en el lado de la PC; 4. Conexión de la aplicación del teléfono móvil (P3) 1. Encienda el dispositivo; 2. Active el punto de acceso WiFi en el dispositivo; 3. Busque el nombre del punto de acceso WiFi del dispositivo usando el teléfono móvil y conéctelo; 4. Inicie la aplicación TargetIR en su teléfono para obtener imágenes del dispositivo en tiempo real, controlarlo y acceder al mismo; 5. Operación detallada Escanee el código QR para conocer más métodos de uso. Special statement: the version of the guide will be updated after the technical improvement of the product. Providence Enterprise (Vietnam) Company Limited

Rev 31/3/2024 Advanced Vision Inc Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 27-08-2024 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2BHH3AD31 [Advanced Vision Inc] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) (Applicant printed name) Sliver Kim Rev 31/3/2024 Advanced Vision Inc Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 27-08-2024 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2BHH3AD31 [Advanced Vision Inc] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Sliver Kim

Rev 1/26/2023 Advanced Vision Inc. 4340 Spring Valley Road, Farmers Branch, TX 75244 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2024-8-29 Ref: Attestation Statements Part 2.911(d)(7) Filing Grantee Code: 2BHH3 Advanced Vision Inc.(“the applicant”) certifies that, as of the date of the filing of the application, we designate ourselves as the U.S. agent for service of process. Designated U.S. Agent Information: FRN: 0035666411 Name: Advanced Vision Inc. Address: 4340 Spring Valley Road, Farmers Branch, TX 75244 Contact Person:Sliver Kim Tel.: 214 272 8864 ext. 2 Email: [email protected] Sincerely, Advanced Vision Inc. Sliver Kim [Applicant signature]

Rev 11/20/07 Advanced Vision Inc Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2BHH3AD31 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics, Operational Description, NII Software Security Info Block Diagram Operation Description schematic diagram NII Software Security Info The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Sliver Kim Advanced Vision Inc

Advanced Vision Inc Date: 2024-08-27 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BHH3AD31 To Whom It May Concern: This letter is to ascertain that Advanced Vision Inc EUT：Vision Enhancement Imager MODEL No.: BOBCAT B3+ Has been the units used for conducting FCC compliance testing, the SDoC part will be tested by EMTEK (SHENZHEN) CO., LTD. If you have any question or concerns, pls. contact us. Sincerely, Client’s signature ： Client’s name / title ： Sliver Kim Contact information / address: Advanced Vision Inc /4340 Spring Valley Road, Farmers Branch, TX 75244

Advanced Vision Inc Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Date: 2024-08-27 SUBJECT: FCC Application for FCC ID: 2BHH3AD31 To Whom It May Concern: We, the undersigned, hereby authorize Lisa Wang at EMTEK (SHENZHEN) CO., LTD. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by EMTEK (SHENZHEN) CO., LTD. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Sliver Kim Advanced Vision Inc

EUT EXTERNAL PHOTOGRAPHS ----------------The end----------------

EUT INTERNAL PHOTOGRAPHS RF module ANTENNA ----------------The end----------------

Report No. ENS2407030155W00704R Page 1 of 43 Ver.1.0 TEST REPORT Product Name ： Vision Enhancement Imager Model Number ： Bobcat B3+ FCC ID ： 2BHH3AD31 Prepared for : Advanced Vision Inc. Address : 4340 Spring Valley Road, Farmers Branch, TX 75244 Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ENS2407030155W00704R Date(s) of Tests : July 22, 2024 to July 23, 2024 Date of Issue : July 24, 2024 $二维码$ Report No. ENS2407030155W00704R Page 2 of 43 Ver.1.0 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION ............................................................................................................................ 4 2. Description of Equipment Under Test .................................................................................................................. 6 3. SAR Measurement System .................................................................................................................................... 7 3.1 Definition of SpecificAbsorptionRate (SAR) ..................................................................................................... 7 3.2 SPEAG DASY System ..................................................................................................................................... 7 3.2.1 Robot .................................................................................................................................................. 8 3.2.2 Probes ................................................................................................................................................ 9 3.2.3 Data Acquisition Electronics (DAE) .................................................................................................... 9 3.2.4 Phantoms ......................................................................................................................................... 10 3.2.5 Device Holder ................................................................................................................................... 11 3.2.6 System Validation Dipoles ................................................................................................................ 11 3.2.7 Tissue Simulating Liquids ................................................................................................................. 12 3.3 SAR System Verification ................................................................................................................................ 14 3.4 SAR Measurement Procedure ....................................................................................................................... 15 3.4.1 Area & Zoom Scan Procedure.......................................................................................................... 15 3.4.2 VolumeScan Procedure .................................................................................................................... 15 3.4.3 Power Drift Monitoring ...................................................................................................................... 16 3.4.4 Spatial Peak SAR Evaluation ........................................................................................................... 16 3.4.5 SAR Averaged Methods ................................................................................................................... 16 4. SARMeasurement Evaluation .............................................................................................................................. 17 4.1 Applicable Standards ..................................................................................................................................... 17 4.2 EUT Configuration and Setting ...................................................................................................................... 17 4.3 EUT Testing Position ...................................................................................................................................... 19 4.3.1 Front-of-face device ......................................................................................................................... 19 4.3.2 SAR Test Exclusion Evaluations ...................................................................................................... 21 4.4 Tissue Verification .......................................................................................................................................... 23 4.5 System Validation ........................................................................................................................................... 23 4.6 System Verification ......................................................................................................................................... 24 4.7 Maximum Output Power ................................................................................................................................. 25 4.7.1 Maximum Conducted Power ............................................................................................................ 25 4.7.2 Measured Conducted Power Result ................................................................................................ 26 4.8 SAR Testing Results ....................................................................................................................................... 29 4.8.1 SAR Test Reduction Considerations ................................................................................................ 29 4.8.2 SAR Results for Body Exposure Condition ...................................................................................... 30 4.8.3 2.4GHz 802.11g/n OFDM SAR Test Exclusion Consideration: ........................................................ 30 4.8.4 SAR Measurement Variability ........................…

Text truncated - open the document above for the full version.

. Test Laboratory: Shenzhen EMTEK Co.,Ltd.Date: 2024/7/22 System Check_H2450 DUT: Dipole 2450 MHz; Type:D2450V2; SN:927 Communication System: CW; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium: H2450 Medium parameters used: f = 2450 MHz;σ=1.77S/m;ε r =40.13;ρ=1000kg/m 3 AmbientTemperature：22.1°C; LiquidTemperature：21.9°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2024/6/25; - Electronics: DAE4 Sn1418; Calibrated: 2024/5/17 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Pin=250mW/Area Scan (41x51x1):Interpolated grid: dx=2.000 mm, dy=2.000 mm Maximum value of SAR (interpolated) = 25.1 W/kg Pin=250mW/Zoom Scan (5x5x7)/Cube 0:Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 114.9 V/m; Power Drift = 0.11 dB Peak SAR (extrapolated) = 31.5 W/kg SAR(1 g) = 13.09 W/kg; SAR(10 g) = 6.11 W/kg Maximum value of SAR (measured) = 23.1 W/kg . Test Laboratory: Shenzhen EMTEK Co.,Ltd.Date: 2024/7/23 System Check_H5250 DUT: Dipole 5GHzV2;Type:D5GHzV2; SN:1169 Communication System: CW; Frequency: 5250 MHz;Duty Cycle: 1:1 Medium: H5G Medium parameters used: f = 5250 MHz;σ=4.74S/m;ε r = 36.82;ρ= 1000 kg/m 3 AmbientTemperature：22.2°C; LiquidTemperature：22.0°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2024/6/25; - Electronics: DAE4 Sn1418; Calibrated: 2024/5/17 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Pin=100mW/Area Scan (91x91x1):Interpolated grid: dx=1.000 mm, dy=1.000 mm Maximum value of SAR (interpolated) = 22.3 W/kg Pin=100mW/Zoom Scan (4x4x2mm) (7x7x12)/Cube 0:Measurement grid: dx=4mm, dy=4mm, dz=2mm Reference Value = 58.441 V/m; Power Drift = 0.12 dB Peak SAR (extrapolated) = 36.7 W/kg SAR(1 g) =7.91 W/kg; SAR(10 g) = 2.15 W/kg Maximum value of SAR (measured) = 23.4 W/kg

Date: 2024/7/22 Test Laboratory: Shenzhen EMTEK Co.,Ltd. 2.4GWIFI DUT: TB420 Communication System: 802.11b ; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium: H2450 Medium parameters used: f = 2437 MHz;σ=1.75S/m;ε r =40.10;ρ= 1000 kg/m 3 AmbientTemperature：22.1°C; LiquidTemperature：21.9°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2024/6/25; - Electronics: DAE4 Sn1418; Calibrated: 2024/5/17 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Front/Area Scan (8x11x1):Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.0814 W/kg Front/Zoom Scan (5x5x7)/Cube 0:Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 5.687 V/m; Power Drift = -0.12 dB Peak SAR (extrapolated) = 0.120 W/kg SAR(1 g) = 0.065 W/kg; SAR(10 g) = 0.052 W/kg Maximum value of SAR (measured) = 0.0901 W/kg Date: 2024/7/23 Test Laboratory: Shenzhen EMTEK Co.,Ltd. 5.2GWIFI DUT: TB420 Communication System: 802.11a ; Frequency: 5200 MHz;Duty Cycle: 1:1 Medium: H5G Medium parameters used: f = 5200 MHz;σ=4.72S/m;ε r = 36.80;ρ= 1000 kg/m 3 AmbientTemperature：22.2°C; LiquidTemperature：22.0°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2024/6/25; - Electronics: DAE4 Sn1418; Calibrated: 2024/5/17 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Front/Area Scan (8x11x1):Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.211 W/kg Front/Zoom Scan (9x9x16)/Cube 0:Measurement grid: dx=4mm, dy=4mm, dz=2mm Reference Value = 3.574 V/m; Power Drift = 0.11 dB Peak SAR (extrapolated) = 0.962 W/kg SAR(1 g) = 0.088 W/kg; SAR(10 g) = 0.023 W/kg Maximum value of SAR (measured) = 0.397 W/kg

Dongguan YiJia Electronics Communication Technology Co.,Ltd. SPECIFICATION FOR APPROVAL Date 2023/11/10 File No 23111001 Revision 1.0 CUSTOMER: CUSTOMER NO: ZG31A WIFI Antenna L 105mm MHF PART NAM E: WIFI Antenna L=105mm MHF SUPPLIER NO: YJT01.220.023.301A Date: Q“TY: CUSTOMER A PPROVED BY APPROVALCHIEFSUPERVISOR SUPPLIER SIGNATURE APPROVALCHECKDESIGN add：Yuanfu Industrial Zone, 59 Muyu Road, Shatou Community, Changan Town, Dongguan City Tel:0769-82586086 Fax:0769-82586086 APPROVALCHECKDESIGN ChenGuoqiangXieLiChenXingyi YJ-RD-F04-A Advanced Vision Inc. Admission book item table NO . （Contents） （Number of Page） （Page Code） 11 1 （Sppec Cover）） 2 （S pec Item ） 12 3 （Drawing） 13 4 （A ntenna Specification） 14 5 （S Parameter ） 15 6 （P assive Tes t ） 36 ~ 8 7 （Radiation Pattern ） 29 ~ 10 8 （Antenna Profile） 211 ~ 12 9 NANANA 10 NA NANA 11N/AN/AN/A add：Yuanfu Industrial Zone, 59 Muyu Road, Shatou Community, Changan Town, Dongguan City Tel:0769-82586086 Fax:0769-82586086 12--- 13--- Antenna Specification Electrical Properties Frequency 2.4-2.5GHz 5.15-5.85GHz Impedance50 Ohm Nominal V.S.W.R 2.0 [email protected] 5.0 [email protected] GainGain 1.0 [email protected] 1.2 [email protected] RadiationOmni-directional PolarizationLinear Physical Properties Connector Generation 1IPEX Cable TypeO.D.1.13mm Cable Length105mm Cable ColorBlack add：Yuanfu Industrial Zone, 59 Muyu Road, Shatou Community, Changan Town, Dongguan City Tel:0769-82586086 Fax:0769-82586086 Operating Temp.-40 ~ +85 ̊C Storage Temp / Humidity 25±5 ̊C / <70% Antenna Performance Test Agilent Antenna Performance Te s t Agilent E5071B SS Parameter Test // WiFi Antenna add：Yuanfu Industrial Zone, 59 Muyu Road, Shatou Community, Changan Town, Dongguan City Tel:0769-82586086 Fax:0769-82586086 AntennaPassive TestAntenna Passive Te s t Z Y X X Z Y add：Yuanfu Industrial Zone, 59 Muyu Road, Shatou Community, Changan Town, Dongguan CityTel:0769-82586086 Fax:0769-82586086 Passive Test For WiFi Antenna(2.4G) FreqEffiEffiGain (MHz)(%)(dB)(dBi) 2400 40.7 -3.9 0.2 2410 40.2 -4.0 0.4 2420 44.2 -3.5 0.5 2430 41.8 -3.8 0.6 2440 41.6 -3.8 0.7 2450 40.1 -4.0 0.9 2460 37.2 -4.3 1.0 2470 42.9 -3.7 0.8 2480 43.1 -3.7 0.6 add：Yuanfu Industrial Zone, 59 Muyu Road, Shatou Community, Changan Town, Dongguan City Tel:0769-82586086 Fax:0769-82586086 2490 41.5 -3.8 0.4 2500 41.8 -3.8 0.2 Passive Test For WiFi Antenna(5.8G) FreqEffiEffiGain (MHz)(%)(dB)(dBi) 5150 35.3 -4.5 0.7 5200 38.6 -4.1 0.4 5250 30 8-51 5250 30.8 -5.1 0.7 5300 31.8 -5.0 0.8 5350 33.4 -4.8 0.9 5400 34.2 -4.7 1.2 5450 33.0 -4.8 1.0 5500 31.1 -5.1 1.0 5550 37.9 -4.2 1.2 5600 41.4 -3.8 0.6 5650 33.0 -4.8 0.9 5700 37.6 -4.2 0.5 5750 40 140 add：Yuanfu Industrial Zone, 59 Muyu Road, Shatou Community, Changan Town, Dongguan City Tel:0769-82586086 Fax:0769-82586086 5750 40.1-4.0 0.4 5800 33.2 -4.8 0.2 5850 34.1 -4.7 0.2 Radiation Pattern For WiFi Antenna(2450MHz) add：Yuanfu Industrial Zone, 59 Muyu Road, Shatou Community, Changan Town, Dongguan City Tel:0769-82586086 Fax:0769-82586086 Radiation Pattern For WiFi Antenna(5150MHz) add：Yuanfu Industrial Zone, 59 Muyu Road, Shatou Community, Changan Town, Dongguan City Tel:0769-82586086 Fax:0769-82586086 Device WiFi Antenna add：Yuanfu Industrial Zone, 59 Muyu Road, Shatou Community, Changan Town, Dongguan City Tel:0769-82586086 Fax:0769-82586086 WiFiAntenna add：Yuanfu Industrial Zone, 59 Muyu Road, Shatou Community, Changan Town, Dongguan City Tel:0769-82586086 Fax:0769-82586086

Report No. ENS2407030155W00701R Page 1 of 43 Ver.1.0 TEST REPORT Product Name ： Vision Enhancement Imager Model Number ： BOBCAT B3+ FCC ID ： 2BHH3AD31 Prepared for : Advanced Vision Inc. Address : 4340 Spring Valley Road, Farmers Branch, TX 75244 Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Building 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ENS2407030155W00701R Date(s) of Tests : July 5, 2024 to July 31, 2024 Date of issue : August 3, 2024 $二维码$ Report No. ENS2407030155W00701R Page 2 of 43 Ver.1.0 TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION .................................................................................................................................... 3 2 EUT TECHNICAL DESCRIPTION .................................................................................................................................. 5 3 SUMMARY OF TEST RESULT ......................................................................................................................................... 6 4 TEST METHODOLOGY .................................................................................................................................................... 7 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................................................................. 7 4.2 MEASUREMENT EQUIPMENT USED ........................................................................................................................ 7 4.3 DESCRIPTION OF TEST MODES ................................................................................................................................ 8 5 FACILITIES AND ACCREDITATIONS ........................................................................................................................... 9 5.1 FACILITIES .................................................................................................................................................................... 9 5.2 LABORATORY ACCREDITATIONS AND LISTINGS ................................................................................................. 9 6 TEST SYSTEM UNCERTAINTY .................................................................................................................................... 10 7 SETUP OF EQUIPMENT UNDER TEST ........................................................................................................................11 7.1 RADIO FREQUENCY TEST SETUP 1 ........................................................................................................................ 11 7.2 RADIO FREQUENCY TEST SETUP 2 ........................................................................................................................ 11 7.3 CONDUCTED EMISSION TEST SETUP .................................................................................................................... 12 7.4 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ................................................................................... 13 7.5 SUPPORT EQUIPMENT .............................................................................................................................................. 13 8 TEST REQUIREMENTS .................................................................................................................................................. 14 8.1 DTS 6DB BANDWIDTH .............................................................................................................................................. 14 8.2 MAXIMUM PEAK CONDUCTED OUTPUT POWER ............................................................................................... 16 8.3 MAXIMUM POWER SPECTRAL DENSITY ............................................................................................................. 18 8.4 UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS ............................................................ 20 8.5 RADIATED SPURIOUS EMISSION ........................................................................................................................... 27 8.6 CONDUCTED EMISSIONS TEST .............................................................................................................................. 39 8.7 ANTENNA APPLICATION .......................................................................................................................................... 42 Report No. ENS2407030155W00701R Page 3 of 43 Ver.1.0 1 TEST RESULT CERTIFICATION Applicant : Advanced Vision Inc. Address： 4340 Spring Valley Road, Farmers Branch, TX 75244 Manufacturer : Providence Enterprise（Vietnam) Company Limited Address： B26 parcel of lot CN3, An Duong Industrial zone, Hong Phong Commune, An Duong District, Hai Phong City, Vietnam EUT : Vision Enhancement Imager Model Name : BOBCAT B3+ Trademark : FOCI Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2 , Subpart J FCC 47 CFR Part 15, Subpart C PASS The above equipment was tested by EMTEK(SHENZHEN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.247 The test results of this report relate only to the tested sample identified in this report Date of Test : July 5, 2024 to July 31, 2024 Prepared by : Una Yu/Editor Reviewer : Joe Xia/Supervisor Approved & Authorized Signer : Lisa Wang/Manager Report No. ENS2407030155W00701R Page 4 of 43 Ver.1.0 Modified Information Version Report No. Revision Date Summary Ver.1.0 ENS2407030155W00701R / Original Report Report No. ENS2407030155W00701R Page 5 of 43 Ver.1.0 2 EUT TECHNICAL DESCRIPTION Product Vision Enhancement Imager Mod…

Text truncated - open the document above for the full version.

Report No. ENS2407030155W00702R Page 1 of 53 Ver.1.0 TEST REPORT Product Name ： Vision Enhancement Imager Model Number ： BOBCAT B3+ FCC ID ： 2BHH3AD31 Prepared for : Advanced Vision Inc. Address : 4340 Spring Valley Road, Farmers Branch, TX 75244 Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Building 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ENS2407030155W00702R Date(s) of Tests : July 5, 2024 to July 31, 2024 Date of issue : August 3, 2024 $二维码$ Report No. ENS2407030155W00702R Page 2 of 53 Ver.1.0 TEST RESULT CERTIFICATION Applicant : Advanced Vision Inc. Address : 4340 Spring Valley Road, Farmers Branch, TX 75244 Manufacturer : Providence Enterprise（Vietnam) Company Limited Address : B26 parcel of lot CN3, An Duong Industrial zone, Hong Phong Commune, An Duong District, Hai Phong City, Vietnam EUT : Vision Enhancement Imager Model Name : BOBCAT B3+ Trademark : FOCI Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2 , Subpart J FCC 47 CFR Part 15 , Subpart C PASS The above equipment was tested by EMTEK (SHENZHEN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.247 The test results of this report relate only to the tested sample identified in this report. Date of Test …

Text truncated - open the document above for the full version.
