2BHLL-V22Dash camera,Car Dvr

Tachograph user's Guide Dash camera,CarDvr V22 High-definitiontachograph Instructionsforuse Thankyouforpurchasingtheappearanceoffinehigh-resolutionmulti-function onboardrecorder.Thisproductuseshigh-performancechips,High-definitionvideo, dynamicpictureofthecontinuityofstrong,underlowlight,canrecordvideo,To achievehigh-definitionwide-angleshot. Thisusermanualdetailshowtouse,andprovideyouwithdetailedinformation, includingtheuse,Operationalandtechnicalspecifications,pleasereadthemanual carefullyandfullyunderstoodbeforeusing,pleasekeepthismanualBook,we hopethatthisproductwillmeetyourneedsandlong-termservicetoyou! Productmanual Introductiontomainfunctionsofmobileapp 1.Downloadapp Apploadingcanbeperformedintwoways: 1)Gototheappstoretodownload ForIOSsystem,youcansearch"Viidure"intheappstoretodownload: 2)ScantheQRcodeforIOSandAndroidsystems,whichcanbedownloaded byscanningtheQRcode"Viidure"APP.Thestepsareasfollows: 1）Openwechatorothersoftwarewith"scan"functiontoscan 2）Selectthecorrespondingsystemofthemobilephoneandclickto download 2．Registeredaccount 1)Enterthe"Viidure"appforaccountregistration 2)Fillinthecorrespondinginformationasrequired,obtainthe verificationcodeandfillinit.Clickregistrationtocompletethe operation 3.Connectingthecamera 1)Enterthemobilephonewifilist(asshowninthefigurebelow), click"CAR-******"toentertherecorderdevicename,enterthe password"12345678",andthemobilephoneissuccessfullyconnected totherecorder; 2)Logintothedownloadedapp,"Viidure"entersthemaininterface, clickthecameraiconabove"CAR-******"toentertherecorderscreen; 4.Parametersetting Settheparametersofthedashcam,suchasmodifyingtheWiFipassword, recordingornot,anddisplayingthewatermarktime,Videocycletime, collisionsensitivity,videoresolution,etc. 5.Parkingmonitoring Theparkingmonitoringmoderequiresathreecorestep-downwireconnection, andordinarycarchargerscannottriggerthisfunction! Parkingmonitoringfunctiontriggered-timesettingfortime-lapse recordingcycle:6hours,12hours,24hours,48hours,(seta6-hourtime, andthemachinewillautomaticallyshutdownaftercontinuouslyrecording for6hoursaftertriggeringtheparkingmonitoringfunction) Lowvoltageprotectionsettings:11.2V,11.5V,11.8V(When11.2Visset,the machinewillautomaticallyshutdownwhenthecarbatteryvoltageislower than11.2V) 6.videoreviewanddownload Productdescription Keyfunctiondescription 1.powerkey2Resetkey3TFcardslot Keyfunctiondescription: 1.powerkey On/offfunction Intheshutdownstate,longpressthe[powerkey]for2secondstoturn onthepowersupplyofthemachine,andthemachinewillstartworking automatically. Pressandholdthe[powerkey]for2secondswhenthemachineisturned on. The machinewillautomaticallysavethe videofileand usersettings andshutdown. 2. Resetkey Pressthe resetkey to resetthe machineand restartit whenthe machine crashesandcannotbe switchedon or offnormally. 3.Tf cardslot Usedto inserta memorycard,[note]pleaseuse a high-speedTF Card (class10or above)witha capacityof no lessthan8GB.The TF cardcan support128GBat most. ProductSpecifications productnameDash camera,Car Dvr FeaturesWiFidashcam Colourcustommade CameralensHigh-resolutionultrawide-angleCameralens LanguageEnglish, Japanese,French,Italian,German,Spanish,Thai Russian, Chinese(simplified、Traditional),Korean,etc. file formatMOV/MP4 Continuousloop recording Seamlesslooprecording,do not leak seconds MotiondetectionSupport Year MonthDay pointsSupport CarriermediaBuilt-inmemory(total:64MB) Cameramode800 W PhotoformatJPEG StoragecardTF (recommendedmorethan10 -speed,capacity 8G-128 G TF card) MicrophoneSupport Built-inaudioSupport InfrarednightvisionSupport PowerInterface5V 1.5 A Troubleshooting: Undernormaloperatingconditions,iftheproductshaveproblems, pleaserefertothesolution: 1,Couldnottakephotos,videoCheckTFcardwhetherthereisenough space,whetherlocked. 2,Whenrecording,itwillautomaticallystopBecauseofhuge high-definitionvideodata,useSDHCcompatiblehigh-speedTFcard, high-speedTFcardwillbeC10identity. 3,Replaypicturesandvideos,the"File"promptAnerroroccurredwhen TFcardmemorydata,resultinginincompletefiles,usetheCarDVR "Format"function,reformatthecard. 4.Theimageisfoggy Pleasecheckthelensfordirtandfingerprints.Beforeshooting,wipe thelenswithlenspaper. 5.Therecorderdoesnotwork.Youcanpresstheresetkeywithasharp objectandthenstartitagaintorestorenormal. 6.Openthenetworkaccesspermissionforthefirsttime,andopenthe localphotoalbum 7. Ifthemobilephonecannotbeconnectedtotheproduct,firstofall, checkwhetherthemobilephoneisconnectedtootherWiFihotspots.The appcanonlybeconnectedtotherecorderwhentheWiFiinthemobile phonesettingsisconnectedtotherecorder(forexample,athome,it isfoundthattherecordercannotbeconnected,soitisnecessaryto checkwhethertheWiFisignalinthemobilephonesettingsisconnected totheWiFiinthehome) 8.Thereal-timepictureofthemobilephoneisstuck,whichisgenerally relatedtotheWiFisignal.Forexample,whenthemobilephoneistoo farawayfromtherecorder,theWiFisignalisweak,andthereal-time pictureofthemobilephonewillgetstuck.Inaddition,ifthereare toomanyWiFisignalsaroundtherecorder,itwillalsointerferewith therecorderandcausethereal-timepicturetojam 9.Thepreviewspeedinthealbumisveryslow.Itmaybethatthere aretoomanyvideofilesintheTFcard,resultinginthetimeoutof obtainingfileinformation.ConsumersareadvisedtoformatTFcards regularly 10.recordappearancemanyclientsconnecttoit.Butonlyonemobile phonecanbeusedtolinkatthesametime.Ifitisfoundthatthemobile phonecannotbeconnectedtotherecorder,itshouldberuledoutwhether therecorderisconnectedtoothermobilephones 11.Usethecomputertoplayvideorecordings: TheproductusesH.264compressionformatThefiletypeismovorMP4 format.ManyMicrosoftWindowscomputers'built-inplaybacksoftware bodies(suchasWindowsMediaPlayer)donotsupportH.264encoding formatItmaynotbeabletoplay,ortheplayingofthemovieisnot smooth,theframeisfixedorbroken,orthevideoandaudioarenot synchronized.Itisrecommendedtodownloadotherprofessionalplaying software(suchaspotplayer,etc.). FCC warning： 1. This device should be installed and operated with minimum distance 20cm between the radiator&your …

Text truncated - open the document above for the full version.

Shenzhen Chuanghongyu Technology Co., Ltd Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 7/18/2024 U.S. Agent Designation Shenzhen Chuanghongyu Technology Co., Ltd. acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2BHLL-V22): Name and company of U.S. agent: SELLER HELPER INC Physical U.S. address of agent: 1312 17th Street#1298, Denver, CO 80202, Jnited States FRN of U.S. agent: 0033884602 Email address of U.S. agent: [email protected] SELLER HELPER INC acknowledges their obligation to accept service of process on behalf of Shenzhen Chuanghongyu Technology Co., Ltd Shenzhen Chuanghongyu Technology Co., Ltd.with the FRN：0035687045.. accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature [Name] yaobo [Title] Manager [Company] Shenzhen Chuanghongyu Technology Co., Ltd [Name of U.S. agent] Fairy Lee [Title of U.S. agent] Manager [Company of U.S. agent] SELLER HELPER INC 48_[mo del] US_Agent_2.911(d)(7) - U, V05

Dash camera,Car Dvr FCC ID: 2BHLL-V22 V22 External photographs

Label And Label Location FCC ID: 2BHLL-V22

Dash camera,Car Dvr FCC ID: 2BHLL-V22 V22 Internal photographs

Manufacturer ELEC Address No. 410, Building D2, Luogang Agile Plaza, Shui West Road, Science City, Huangpu District, Guangzhou Model OA-W01 Antenna type Pcb antenna Antenna Gain -2dBi for 2.4G 1.Test equipment and conditions: 1.1.Network Analyzer 1.2.Communication test equipment 1.3.Test system 1.4.Matching circuit 2.Test Data: 2.1. Standing wave ratio 2.2.Efficiency 2.4G Fred (MHz) Effi (%) Effi (%) Gain (dBi) Gain (dBd) UHIS (%) DHIS (%) Max (dB) Min (dB) Attenut (Hor) Attenut (Ver) 2400 44.38 -2.79 -1.26 3.12 40.28 13.32 2.29 -23.79 48.26 49.33 2410 44.63 -2.46 -1.66 3.52 42.42 13.54 2.46 -21.29 48.66 49.58 2420 44.94 -2.12 -1.96 3.68 40.96 14.77 2.68 -20.97 48.71 49.88 2430 44.27 -2.70 -1.40 3.26 43.24 15.23 2.29 -22.77 48.21 49.35 2440 44.75 -2.39 -1.00 2.86 40.71 15.79 2.53 -25.39 48.58 49.56 2450 44.82 -1.83 -1.50 3.36 41.19 16.18 3.15 -21.98 49.11 49.99 2460 44.28 -2.63 -1.10 3.96 42.39 18.25 2.31 -25.62 48.37 49.22 2470 44.49 -2.34 -1.44 3.30 41.78 18.80 2.50 -24.31 48.50 49.54 2480 45.08 -2.23 -1.00 2.86 40.89 19.05 3.14 -23.23 48.98 49.99 2490 44.21 -2.68 -1.25 3.11 43.21 19.23 2.35 -21.77 48.24 49.20 2500 44.46 -2.32 -1.61 3.47 40.44 19.62 2.48 -20.30 48.48 49.61 2.3.Directivity diagram 3.Antenna drawing:

Page: 1 of 57 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China TEST REPORT FCC Part 15C Report Reference No. ........................... : FCC ID. .................................................. : CTA240709105 2BHLL-V22 Compiled by ( position+printed name+signature) ........ : File administrators Zoey Cao Supervised by ( position+printed name+signature) ........ : Project Engineer Amy Wen Approved by ( position+printed name+signature) ........ : RF Manager Eric Wang Date of issue .......................................... : 2024-07-15 Testing Laboratory Name .................... : Shenzhen CTA Testing Technology Co., Ltd. Address .................................................. : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Applicant’s name .................................. : Shenzhen Chuanghongyu Technology Co., Ltd Address .................................................. : 301 Jinjin Building, No. 242 Jihua Road, Jihua Street, Longgang District, Shenzhen,Guangdong,China Test specification ................................. : Standard ................................................. : FCC Part 15C Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ........................... : Dash camera,Car Dvr Trade Mark ............................................. : / Manufacturer ......................................... : Shenzhen Chuanghongyu Technology Co., Ltd Model/Type reference ............................. : V22 Listed Models ........................................ : V21，V26A，V26B，K04，S5 Ratings ................................................... : DC5V, 2A from Car charging Result ..................................................... : PASS Report No.: CTA240709105 Page 2 of 57 TEST REPORT Equipment under Test : Dash camera,Car Dvr Model /Type : V22 Listed Models : V21，V26A，V26B，K04，S5 Applicant : Shenzhen Chuanghongyu Technology Co., Ltd Address : 301 Jinjin Building, No. 242 Jihua Road, Jihua Street, Longgang District, Shenzhen,Guangdong,China Manufacturer : Shenzhen Chuanghongyu Technology Co., Ltd Address : 301 Jinjin Building, No. 242 Jihua Road, Jihua Street, Longgang District, Shenzhen,Guangdong,China Test result Pass * Report No.: CTA240709105 Page 3 of 57 Contents 1. TEST S T A N D A R D S A N D R E P O R T V E R S I O N 4 1.1. Test Standards 4 1.2. Test Description 4 1.3. Address of the test laboratory 4 1.4. Test Facility 4 1.5. Statement of the measurement uncertainty 4 2. G E N E R A L I N F O R M A T I O N 6 2.1. General Remarks 6 2.2. Environmental conditions 6 2.3. General Description of EUT 6 2.4. Operation state 6 2.5. Equipments Used during the Test 7 2.6. Related Submittal(s) / Grant (s) 8 2.7. Modifications 8 2.8. Environmental conditions 8 3. TE S T C O N D I T I O N S A N D R E S U L T S 9 3.1. Antenna requirement 9 3.2. Conducted Emissions (AC Main) 10 3.3. Conducted Peak Output Power 13 3.4. Power Spectral Density 14 3.5. 6dB bandwidth 20 3.6. Restricted band 26 3.7. Band edge and Spurious Emissions (conducted) 31 3.8. Spurious Emissions (radiated) 48 4. TE S T S E T U P P H O T O S 53 5. EX T E R A N A L A N D I N T E R N A L P H O T O S 54 Report No.: CTA240709105 Page 4 of 57 1. TEST STANDARDS AND REPORT VERSION 1.1. Test Standards The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10:2013: American National Standard forTesting Unlicensed Wireless Devices KDB 558074 D01 DTS Meas Guidance v05: Guidance for Compliance Measurements on Digital Transmission System, Frequency Hopping Spread Spectrum System, and Hybrid System Devices Operating under Section 15.247 of The FCC Rules 1.2. Test Description Test Item FCC Rule Result Antenna requirement 15.203/15.247(c) PASS Line Conducted Emissions (AC Main) 15.207 PASS Conducted Peak Output Power 15.247(b)(3) PASS Power Spectral Density 15.247(e) PASS 6dB Bandwidth 15.247(a)(2) PASS Restricted band 15.247(d)/15.205 PASS Spurious Emissions 15.247(d)/15.209 PASS 1.3. Address of the test laboratory Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community,Fuhai Street, Bao‘an District, Shenzhen, China The 3m-Semi anechoic test site fulfils CISPR 16-1-4 according to ANSI C63.4:2014 and CISPR 16-1-4:2010 SVSWR requirement for radiated emission above 1GHz. 1.4. Test Facility The test facility is recognized, certified, or accredited by the following organizations: FCC-Registration No.: 517856 Designation Number: CN1318 Shenzhen CTA Testing Technology Co., Ltd. has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. A2LA-Lab Cert. No.: 6534.01 Shenzhen CTA Testing Technology Co., Ltd. has been listed by American Association for Laboratory Accreditation to perform electromagnetic emission measurement. ISED#: 27890 CAB identifier: CN0127 Shenzhen CTA Testing Technology Co., Ltd. has been listed by Innovation, Science and Economic Development Canada to perform electromagnetic emission measurement. 1.5. Statement of the measurement uncertainty The data and results referenced in this document are true and accurate. The reader is cautioned that there may be errors within the calibrati…

Text truncated - open the document above for the full version.

Dash camera,Car Dvr FCC ID: 2BHLL-V22 V22 Test setupt photos Radiated emission 30MHz~1GHz Conducted emission Radiated emission Above 1GHz
