2BHNR-LENOVOS01Gamepad

130mm 90mm 130mm*90mm Product Description This product is a multi-platform wireless Bluetooth controller. It supports both wired and wireless connections to the host and features back button macro programming functionality. Function Description （1）Connection method between the controller and the Switch host: ①Wired connection: Use a USB data cable to connect to the host. ②Wireless connection: Connect to the host through Bluetooth communication. （2）Wired Bluetooth automatic switching connection function：After the controller is connected to the host via USB data cable, press any key on the controller to wake up, unplug the data cable, and the controller will automatically connect to the host via Bluetooth. （3）Startup and shutdown operations：Press the "Home" button for less than 4 seconds, the LED12 light will slowly flash on, and the handle will enter the Bluetooth pairing state with the host from sleep mode. Press and hold the "Home" button for more than 5 seconds to shut down. （4）When the SWITCH host is in sleep mode, short pressing the "Home" button on the handle for less than 4 seconds can wake up and reconnect to the host. （5）The controller supports upgrading through the APP or by connecting to a PC, and requires downloading our upgrade software. （6）Turbo function：Press and hold any single button (except for the joystick), then press the "Turbo" button, and the corresponding button will activate Turbo mode. （7）The controller consists of top, bottom, left, and right A、 B 、X 、Y 、L 、R 、Z L 、Z R 、L S 、R S 、L 3 、R 3 、‐ 、+ 、T U R B O 、H o m e 、 Screenshots, connection keys, M1 and M2 macro programming buttons on the back of the controller, consisting of a total of 24 function buttons and two 3D simulation sticks. （8）Handle vibration adjustment function：Press and hold the T key, then press the up and down cross keys to increase -1- -11--12--13- -2--5--3--4- -8- -6--7- -9--10- Product features (1) Includes all buttons on the controller and their corresponding functions, with added motor vibration intensity adjustment functionality; (2) Gyroscope mapping joystick function; (3) Features 24 function keys; (4) Built-in eccentric motor and high-precision Hall joystick; (5) Six-axis gyroscope; (6) M1 and M2 macro programming functionality on the back of the controller; (7) Compatible with multiple platforms (Switch/PC/Android TV/iOS/HarmonyOS/car systems), supporting wired, Bluetooth connections to the host; (8) The controller's left and right joysticks feature ring lighting Fully charged：After the handle is fully charged, all lights turn off. effects, with 4 lighting modes and 9 color lighting effects. Charging：Connect the USB data cable to the handle and insert it into the 5V/0.5A power adapter. When the power is turned off, the charging LED indicator light will flash slowly. Charging will be prioritized when connected, and the charging light will be displayed as active Low battery alarm：When the battery voltage of the controller is below 3.6V, it flashes rapidly 5 times per second and cycles every 30 seconds, indicating that the controller battery is low and needs to be charged. /decrease the vibration intensity of the handle. The intensity can be adjusted in four levels: 0, 25%, 50%, 75%, and 100%. (Adjustment successful, current vibration intensity prompt vibration for 0.5 seconds, handle needs to be adjusted in connected state, default intensity is 50%) （9）The back of the handle M1 and M2 have macro programming functions. Restore factory settings function When there is an abnormality in the handle, press and hold the "reset" button for more than 5 seconds to restore the factory settings. Receiving distance The effective receiving distance of the handle is within 10 meters. Connecting to the host via Bluetooth A 、 Host Bluetooth enable settings： Click on "System Settings" ->"Airplane Mode" ->Turn on "Airplane Mode" ->"Connection to the controller (Bluetooth)" ->Use on the host homepage interface. M1 and M2 key macro programming function settings： 1.Programming supports mapping and macro definition functions 2.Factory Key Values：The M1 button is the A button, and the M2 button is the B button 3.Backkey macro programming：Press any key M1 or M2 plus the "T" key, and the handle vibrates once to enter programming mode. Then press the function key to be mapped (A/B/X/Y/L/R/ ZL/ZR/L3/R3/Cross key (any key position up/down/left/right), and press the M1/M2 key again (the same key position during programming) to confirm programming. At this time, the handle motor vibrates once, indicating successful programming Macro programming function clear： Press any programming key M1 or M2, then hold down the "T" key, and the motor vibration will enter the programming state. Press the programming key again to clear the program- ming of the macro key. Clearing completed motor vibration feedback. Calibrate the gyroscope sensor and 3D joystick 1. Calibrate gyroscope sensor A、 After successfully connecting the controller to the host, return to the main menu on the screen. B、 Click on "System Settings" - "Handle and Sensor" - "Calibrate Gyroscope Sensor" - "Calibration handle" - "Long press" - "or"+". C、 Place the handle with the joystick facing upwards and wait for a moment on a flat and stable surface. D、 Calibration completed. the following 9 light colors: dual aperture red light - dual aperture red orange light - dual aperture yellow light - dual aperture green light - dual aperture blue light - dual aperture blue light - dual aperture blue light - dual aperture purple light - dual aperture white light - dual aperture breathing cycle color change. 3：Four level adjustment method for light brightness： The brightness of the light is divided into four levels: 25% - 50% -75% -100%. Hold down "R3" and hold it down while moving it up the left joystick to increase the brightness. Hold down "R3" and move it down the left joystick to decrease the brightness. The brightness can be remembered when turned off, with a default br…
