2BHXQ2101TCAthlon Thermal Clip-On

CRONUS ATS PRO CLIP-ON 35C-400 | 35C-640 QUICK START GUIDE athlonoptics.com - CONTENTS - CRONUS ATS PRO CLIP-ON Quickstart Guide ...................................................................1-25 Wärmebild-Zielfernrohre der CRONUS ATS PRO CLIP- ON-Serie Schnellstartanleitung ...................................27-55 Lunettes thermiques série CRONUS ATS PRO CLIP-ON Guide de démarrage rapide ............................................57-85 Ottici termici serie CRONUS ATS PRO CLIP-ON Guida Rapi da.....................................................................87-114 Visores térmicos de la serie CRONUS ATS PRO CLIP-ON Guía de inicio rápido. ....................................................115-143 Celowniki termowizyjne serii CRONUS ATS PRO CLIP- ON Skrócona instrukcja obsługi. ..............................145-173 EN IT ES DE FR PL 1 EN DE FR IT ES PL - IMPORTANT - Welcome to the Athlon family and thank you for your purchase. Please read this guide before use and keep it for future reference. This is a general guide for Cronus ATS PRO family of thermal Clip-Ons, which means that the specific model you receive may differ from the picture in this guide. 2 EN DE FR IT ES PL - FCC WARNING - This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made. This unit complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This unit may not cause harmful interference, and (2) this unit must accept any interference received, including interference that may cause undesired operation. The unit has been evaluated to meet general RF exposure requirement. The unit can be used in portable exposure condition without restriction. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital unit, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful 3 EN DE FR IT ES PL interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. • The rating information is located at the bottom of the unit. - PRECAUTIONS - DANGER 1) Please charge the battery with the battery charger provided. Be sure to place the battery (+/-) in the right position. Improper battery charging will cause heating, damage and even physical injury. 2) Do not try to open or disassemble the battery at any time. 4 EN DE FR IT ES PL WARNING 1) This unit contains advanced electronics. To prolong the life of this unit, avoid any undue physical damage or violent actions; 2) Do not use or store the equipment in an environment that exceeds the allowable operating or storage temperature; 3) Do not directly aim the equipment at high-intensity thermal radiation sources, such as the sun, lasers, spot welding machines, etc.; 4) Avoid allowing debris to enter any ports in this optic. 5) Do not knock, throw or vibrate instruments and accessories to avoid damage; 6) Any modifcation, alterations or attempts to dissassemble this unit will void the user's warranty. All repairs must be made through Athlon Optics. 7) Avoid contaminating this unit with oils or solvents. 8) Please observe the following measures when wiping this unit: • Non-optical surface: Use clean and soft cloth to wipe the non-optical surface of the thermal unit; 5 EN DE FR IT ES PL • Optical surface: When using the thermal unit, avoid contaminating the optical lens surfaces of this unit. Avoid touching the objective lens with your hands. Oils and solvents, can degrade the lens coatings. When the surface of the optical lens is polluted, use special lens paper to wipe it carefully; 9) Do not place the battery in a high temperature or near a high-temperature object; 10) Do not short circuit the positive and negative poles of the battery; 11) Do not expose the battery to moisture or water; 12) Only use the original chargers and adapters provided with this unit. - PRODUCT INTRODUCTION - Athlon Optics thermal Clip-on can be mounted through included QD mount in front of a LVPO optical sight or clipped on the objective side of a traditional hunting scope through an optional adapter. 6 EN DE FR IT ES PL - STORAGE AND TRANSPORTATION - The following is the correct storage and transportation of the product. To prevent damage to yourself or the unit, please read the manual carefully before using it. STORAGE: 1) The unit and accessories including batteries shall be stored in a well-ventilated, clean, condensate- free and corrosive gas-free room with temperature of -22°F ~ 140°F (-30°C ~ 60°C) and relative humidity not exceeding 95%. 2) To prevent battery damage, the unit and batteries should be charged every 3 months. TRANSPORT: During transport, it shall be protected against rain, water flooding, without severe vibration and impact. 7 EN DE FR IT ES PL - LIST OF PARTS - 5V2A adapter x1 Adapter plug: EU x1, UK x1, US x1,AU x1 Battery x2 Battery charging stand x1 USB-C Cable x1 Quick Start Guide x1 Warranty card x1 Carrying Case x1 8 E…

Text truncated - open the document above for the full version.

Rev 31/3/2024 Sportsgear Outdoor Products LLC Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 19-08-2024 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2BHXQ2101TC [Sportsgear Outdoor Products LLC] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) (Applicant printed name) Kevin Qu Rev 31/3/2024 Sportsgear Outdoor Products LLC Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 19-08-2024 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2BHXQ2101TC [Sportsgear Outdoor Products LLC] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Kevin Qu

Sportsgear Outdoor Products LLC Date: 2024-08-19 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BHXQ2101TC To Whom It May Concern: This letter is to ascertain that Sportsgear Outdoor Products LLC EUT：Athlon Thermal Clip-On MODEL No.: Cronus ATS PRO 35C-400、 Cronus ATS PRO 35C-640、 Cronus ATS PRO 35CL-400、Cronus ATS PRO 35CL-640 Has been the units used for conducting FCC compliance testing, the SDoC part will be tested by EMTEK (SHENZHEN) CO., LTD. If you have any question or concerns, pls. contact us. Sincerely, Client’s signature ： Client’s name / title ： Kevin Qu Contact information / address: Sportsgear Outdoor Products LLC /10817 Renner Blvd Lenexa KS 66219

Rev 1/26/2023 Sportsgear Outdoor Products LLC 10817 Renner Blvd Lenexa KS 66219 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2024-8-19 Ref: Attestation Statements Part 2.911(d)(7) Filing Grantee Code: 2BHXQ Sportsgear Outdoor Products LLC(“the applicant”) certifies that, as of the date of the filing of the application, we designate ourselves as the U.S. agent for service of process. Designated U.S. Agent Information: FRN: 0035739564 Name: Sportsgear Outdoor Products LLC Address: 10817 Renner Blvd Lenexa KS 66219 Contact Person: Kevin Qu Tel.: (610) 597-7698 Email: [email protected] Sincerely, Sportsgear Outdoor Products LLC Kevin Qu [Applicant signature]

Rev 11/20/07 Sportsgear Outdoor Products LLC Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2BHXQ2101TC Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics, Operational Description, Block Diagram Operation Description schematic diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Kevin Qu Sportsgear Outdoor Products LLC

Declaration on model difference We the undersigned hereby confirm that any of our production units bearing the following model numbers are identical in circuitry and electrical, mechanical and physical construction; the only differences are the model name and the color of appearance for trading purpose. FCC ID: 2BHXQ2101TC Production name Trade name Model no. Athlon Thermal Clip-On Athlon Cronus ATS PRO 35C-400、 Cronus ATS PRO 35C- 640、 Cronus ATS PRO 35CL-400、Cronus ATS PRO 35CL-640 Confirmed by Sportsgear Outdoor Products LLC Kevin Qu Sportsgear Outdoor Products LLC Date: 2024-08-19

Sportsgear Outdoor Products LLC Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Date: 2024-08-19 SUBJECT: FCC Application for FCC ID: 2BHXQ2101TC To Whom It May Concern: We, the undersigned, hereby authorize Lisa Wang at EMTEK (SHENZHEN) CO., LTD. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by EMTEK (SHENZHEN) CO., LTD. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Kevin Qu Sportsgear Outdoor Products LLC

EUT EXTERNAL PHOTOGRAPHS ----------------The end----------------

EUT INTERNAL PHOTOGRAPHS RF M ODULE

Antenna ----------------The end----------------

. Test Laboratory: Shenzhen EMTEK Co.,Ltd.Date: 2024/7/8 System Check_H2450 DUT: Dipole 2450 MHz; Type:D2450V2; SN:927 Communication System: CW; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium: H2450 Medium parameters used: f = 2450 MHz;σ=1.78S/m;ε r =40.11;ρ=1000kg/m 3 AmbientTemperature：22.0°C; LiquidTemperature：21.8°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2024/6/25; - Electronics: DAE4 Sn1418; Calibrated: 2024/5/17 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Pin=250mW/Area Scan (41x51x1):Interpolated grid: dx=2.000 mm, dy=2.000 mm Maximum value of SAR (interpolated) = 25.2 W/kg Pin=250mW/Zoom Scan (5x5x7)/Cube 0:Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 115.7 V/m; Power Drift = 0.18 dB Peak SAR (extrapolated) = 31.7 W/kg SAR(1 g) = 13.07 W/kg; SAR(10 g) = 6.12 W/kg Maximum value of SAR (measured) = 23.2 W/kg . Test Laboratory: Shenzhen EMTEK Co.,Ltd.Date: 2024/7/9 System Check_H5250 DUT: Dipole 5GHzV2;Type:D5GHzV2; SN:1169 Communication System: CW; Frequency: 5250 MHz;Duty Cycle: 1:1 Medium: H5G Medium parameters used: f = 5250 MHz;σ=4.75S/m;ε r = 36.87;ρ= 1000 kg/m 3 AmbientTemperature：22.3°C; LiquidTemperature：22.1°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2024/6/25; - Electronics: DAE4 Sn1418; Calibrated: 2024/5/17 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Pin=100mW/Area Scan (91x91x1):Interpolated grid: dx=1.000 mm, dy=1.000 mm Maximum value of SAR (interpolated) = 22.1 W/kg Pin=100mW/Zoom Scan (4x4x2mm) (7x7x12)/Cube 0:Measurement grid: dx=4mm, dy=4mm, dz=2mm Reference Value = 57.180 V/m; Power Drift = 0.14 dB Peak SAR (extrapolated) = 37.4 W/kg SAR(1 g) =7.93 W/kg; SAR(10 g) = 2.14 W/kg Maximum value of SAR (measured) = 23.3 W/kg

TestLaboratory:ShenzhenEMTEKCo.,Ltd.Date:2024/7/8 2.4GWIFI DUT: ZG41 Communication System: 802.11b ; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium: HSL2450 Medium parameters used : f = 2437 MHz;σ=1.80S/m;ε r = 39.62;ρ= 1000 kg/m 3 AmbientTemperature：22.0°C; LiquidTemperature：21.8°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2024/6/25; - Electronics: DAE4 Sn1418; Calibrated: 2024/5/17 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Front/Area Scan (8x11x1):Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (measured) = 0.389 W/kg Front/Zoom Scan (7x7x7)/Cube 0:Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 6.327 V/m; Power Drift = 0.07 dB Peak SAR (extrapolated) = 1.54 W/kg SAR(1 g) = 0.558 W/kg; SAR(10 g) = 0.194 W/kg Maximum value of SAR (measured) = 0.922 W/kg TestLaboratory:ShenzhenEMTEKCo.,Ltd.Date:2024/7/9 5.2GWIFI DUT: ZG41 Communication System: 802.11a ; Frequency: 5240 MHz;Duty Cycle: 1:1 Medium: HSL 5GHz Medium parameters used: f = 5240 MHz;σ=4.66S/m;ε r = 36.91;ρ= 1000 kg/m 3 AmbientTemperature：22.3°C; LiquidTemperature：22.1°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2024/6/25; - Electronics: DAE4 Sn1418; Calibrated: 2024/5/17 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Front-High/Area Scan (8x11x1):Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (measured) = 0.593 W/kg Front-High/Zoom Scan (7x7x7)/Cube 0:Measurement grid: dx=4mm, dy=4mm, dz=2mm Reference Value = 3.340 V/m; Power Drift = 0.06 dB Peak SAR (extrapolated) = 10.2 W/kg SAR(1 g) = 1.06 W/kg; SAR(10 g) = 0.280 W/kg Maximum value of SAR (measured) = 2.61 W/kg

Photographs of EUT Setup Fig-4.1 Front Face of EUT with 0 cm Gap (Body Mode) Photographs of EUT
