2BHZ9JX-37Wireless Meat Thermometer

FCC Caution This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

Dong guan jin xun Electronic Technology Co., Ltd Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2024-07-31 FCC ID: 2BHZ9JX-37 Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing Dong guan jin xun Electronic Technology Co., Ltd certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing Dong guan jin xun Electronic Technology Co., Ltd certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Applicant: Dong guan jin xun Electronic Technology Co., Ltd Address: Room 14030, Building 2, No. 69 Fengqing Road, Fenggang Town, Dongguan City, Guangdong Province Contact Person: Liu Yusheng Tel.: 13148736025 Email: [email protected] Sincerely, Signature:

Attestation Statements Date: 2024-08-20 TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for (FCC ID:2BHZ9JX-37) Dong guan jin xun Electronic Technology Co., Ltd, the undersigned, hereby authorize HOPEK CORPORATION INC to act as our designated U.S. agent for service of process, Dong guan jin xun Electronic Technology Co., Ltd accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. HOPEK CORPORATION INC accepts the responsibility to act as designated U.S. agent for service of process. Applicant Information： Company name: Dong guan jin xun Electronic Technology Co., Ltd Contact Name: Liu Yusheng Address: Room 14030, Building 2, No. 69 Fengqing Road, Fenggang Town, Dongguan City, Guangdong Province Telephone No: 13148736025 Email: [email protected] FRN: 0035752732 Signature: Liu Yusheng U.S. Agent Information: Company Name:HOPEK CORPORATION INC Address:4358 S BANNOCK ST ENGLEWOOD, CO 80110 United States FRN: 0034562900 Contact Name:Peter Davis Telephone No: 561-235-6113 Email: [email protected] Signature: Peter Davis

ຐ཰ࣽިמҽԖज़Ϧљ Unictron Technologies Corporation Website:www.unictron.com THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF UNICTRON TECHNOLOGIES CORPORATION AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES W ITHOUT PERMISSION Prepared by : Jane Designed by :James Checked by : Mike Approved by烉Herbert TITLE烉3.2 x 1.6 x 0.5(mm) WiFi/Bluetooth Ceramic Chip Antenna (AA055U) Engineering Specification DOCUMENT H2U34W1H1Z0700 REV. NO. C PAGE 1 OF 11 3.2 x 1.6 x 0.5 (mm) WiFi/Bluetooth Ceramic Chip Antenna (AA055U) Engineering Specification 1. Product Number 2. Features *Stable and reliable in performances *Low profile, compact size *RoHS 2.0 compliance *SMT processes compatible 3. Applications *ISM 2.4 GHz applications *ZigBee/BLE applications *Bluetooth earphone systems *Hand-held devices when WiFi / Bluetooth functions are needed, e.g., Smart phones *IEEE802.11 b/g/n *Wireless PCMCIA cards or USB dongles 4. Description Unictron’s AA055U ceramic chip antenna is designed for ISM 2.4GHz applications, covering frequencies 2400~2500MHz. Fabricated with proprietary design and processes, AA055U shows excellent performance and is fully compatible with SMT processes which can decrease the assembly cost and improve device’s quality and consistency. H 2 1 4 W H Z 7 0 U 3 0 1 0 ຐ཰ࣽިמҽԖज़Ϧљ Unictron Technologies Corporation Website:www.unictron.com THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF UNICTRON TECHNOLOGIES CORPORATION AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES W ITHOUT PERMISSION Prepared by : Jane Designed by :James Checked by : Mike Approved by烉Herbert TITLE烉3.2 x 1.6 x 0.5(mm) WiFi/Bluetooth Ceramic Chip Antenna (AA055U) Engineering Specification DOCUMENT H2U34W1H1Z0700 REV. NO. C PAGE 2 OF 11 5. Layout Guide & Electrical Specifications 5-1. Layout Guide (unit:mm) Solder Land Pattern: The solder land pattern (gold marking areas) is shown below. Recommendation on matching circuit will be provided according to customer’s installation conditions. ຐ཰ࣽިמҽԖज़Ϧљ Unictron Technologies Corporation Website:www.unictron.com THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF UNICTRON TECHNOLOGIES CORPORATION AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES W ITHOUT PERMISSION Prepared by : Jane Designed by :James Checked by : Mike Approved by烉Herbert TITLE烉3.2 x 1.6 x 0.5(mm) WiFi/Bluetooth Ceramic Chip Antenna (AA055U) Engineering Specification DOCUMENT H2U34W1H1Z0700 REV. NO. C PAGE 3 OF 11 5-2. Electrical Specifications (Evaluation Board Dimensions: 80 x 40 mm 2 ) 5-2-1. Electrical Table Characteristics Specifications Unit Outline Dimensions 3.2 x 1.6 x 0.5 mm Ground Plane Dimensions 80 x 40 mm Working Frequency 2400~2500 MHz VSWR (@ center frequency)* 2 Max. Characteristic Impedance 50 : Polarization Linear Polarization Peak Gain (@2442 MHz) 1.8 (typical**) dBi Efficiency 76.3 (typical**) % *Center frequency means the frequency with the lowest value in return loss of the chip antenna on the evaluation board. **A typical value is for reference only, not guaranteed. 5-2-2. Frequency vs. V.S.W.R. and Total Radiation Gain ຐ཰ࣽިמҽԖज़Ϧљ Unictron Technologies Corporation Website:www.unictron.com THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF UNICTRON TECHNOLOGIES CORPORATION AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES W ITHOUT PERMISSION Prepared by : Jane Designed by :James Checked by : Mike Approved by烉Herbert TITLE烉3.2 x 1.6 x 0.5(mm) WiFi/Bluetooth Ceramic Chip Antenna (AA055U) Engineering Specification DOCUMENT H2U34W1H1Z0700 REV. NO. C PAGE 4 OF 11 6. Outline Dimensions of Antenna & Evaluation Board (unit: mm) 6-1. Antenna Dimensions PIN Definition PIN 1 2 Soldering PAD Signal Tuning / Ground ຐ཰ࣽިמҽԖज़Ϧљ Unictron Technologies Corporation Website:www.unictron.com THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF UNICTRON TECHNOLOGIES CORPORATION AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES W ITHOUT PERMISSION Prepared by : Jane Designed by :James Checked by : Mike Approved by烉Herbert TITLE烉3.2 x 1.6 x 0.5(mm) WiFi/Bluetooth Ceramic Chip Antenna (AA055U) Engineering Specification DOCUMENT H2U34W1H1Z0700 REV. NO. C PAGE 5 OF 11 6-2. Evaluation Board with Antenna ຐ཰ࣽިמҽԖज़Ϧљ Unictron Technologies Corporation Website:www.unictron.com THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF UNICTRON TECHNOLOGIES CORPORATION AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES W ITHOUT PERMISSION Prepared by : Jane Designed by :James Checked by : Mike Approved by烉Herbert TITLE烉3.2 x 1.6 x 0.5(mm) WiFi/Bluetooth Ceramic Chip Antenna (AA055U) Engineering Specification DOCUMENT H2U34W1H1Z0700 REV. NO. C PAGE 6 OF 11 7. 3D Radiation Gain Pattern (with 80 x 40 mm 2 Evaluation Board) 3D Radiation Gain Pattern @ 2442 MHz (unit: dBi) Z X Z Y ຐ཰ࣽިמҽԖज़Ϧљ Unictron Technologies Corporation Website:www.unictron.com THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF UNICTRON TECHNOLOGIES CORPORATION AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES W ITHOUT PERMISSION Prepared by : Jane Designed by :James Checked by : Mike Approved by烉Herbert TITLE烉3.2 x 1.6 x 0.5(mm) WiFi/Bluetooth Ceramic Chip Antenna (AA055U) Engineering Specification DOCUMENT H2U34W1H1Z0700 REV. NO. C PAGE 7 OF 11 8. Frequency tuning and Matching circuit 8-1. Chip antenna tuning scenarioǺ 8-2. Matching circuit烉 With the following recommended values of matching and tuning components, the center frequencies will be about 2442 MHz at our standard 80x40 mm 2 evaluation board. However, these are typical reference values which may need to be changed when circuit boards or part vendors are different. System Matching Circuit Component Location Description Vendor Tolerance 1 1.2pF, (0…

Text truncated - open the document above for the full version.

Dong guan jin xun Electronic Technology Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: August 20, 2024 Subject; Request for Confidentiality FCC ID: 2BHZ9JX-37 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Liu Yusheng Title: Manager

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 Dong guan jin xun Electronic Technology Co., Ltd Date：2024-07-31 Product Model Number: JX-37 FCC ID：2BHZ9JX-37 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. Signature: By: Liu Yusheng Contact Listed on FCC Wesbite Title: Manager Email: [email protected] On behalf of: Dong guan jin xun Electronic Technology Co., Ltd

Page 1 of 4 Report No.: LGT24G037 Appendix - External Photographs of EUT Constructional Details Model: JX-37 Photo 1 Photo 2 Page 2 of 4 Report No.: LGT24G037 Photo 3 Photo 4 Page 3 of 4 Report No.: LGT24G037 Photo 5 Photo 6 Page 4 of 4 Report No.: LGT24G037 Photo 7 Photo 8

Label Wireless Meat Thermometer Model: JX-37 FCC ID: 2BHZ9JX-37

Page 1 of 4 Report No.: LGT24G037 Appendix - Internal Photographs of EUT Constructional Details Model: JX-37 Photo 1 Photo 2 Page 2 of 4 Report No.: LGT24G037 Photo 3 Photo 4 ANTENNA Page 3 of 4 Report No.: LGT24G037 Photo 5 Photo 6 Page 4 of 4 Report No.: LGT24G037 Photo 7 Photo 8

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China RF TEST REPORT Product Name: Wireless Meat Thermometer Model Name: JX-37 FCC ID: 2BHZ9JX-37 Issued For : Dong guan jin xun Electronic Technology Co., Ltd Room 14030, Building 2, No. 69 Fengqing Road, Fenggang Town, Dongguan City, Guangdong Province Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT24G037HA02 Sample Received Date: Jul. 04, 2024 Date of Test: Jul. 04, 2024 – Jul. 19, 2024 Date of Issue: Jul. 19, 2024 Report No.: LGT24G037HA02 Page 2 of 8 TEST REPORT CERTIFICATION Applicant: Dong guan jin xun Electronic Technology Co., Ltd Address: Room 14030, Building 2, No. 69 Fengqing Road, Fenggang Town, Dongguan City, Guangdong Province Manufacture: Dong guan jin xun Electronic Technology Co., Ltd Address: Room 14030, Building 2, No. 69 Fengqing Road, Fenggang Town, Dongguan City, Guangdong Province Product Name: Wireless Meat Thermometer Trademark: N/A Model Name: JX-37 Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47 CFR §2.1093 KDB 447498 D01 General RF Exposure Guidance v06 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT24G037HA02 Page 3 of 8 TABLE OF CONTENTS 1 . GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST LABORATORY 5 2 . FCC 47CFR §2.1093 REQUIREMENT 6 APPENDIX I - PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS 8 Report No.: LGT24G037HA02 Page 4 of 8 Revision History Rev. Issue Date Revisions 00 Jul. 19, 2024 Initial Issue Report No.: LGT24G037HA02 Page 5 of 8 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name: Wireless Meat Thermometer Trademark: N/A Model Name: JX-37 Series Model: N/A Model Difference: N/A Frequency Bands: Bluetooth 2402-2480MHz Battery: Model: 902030 Capacity: 500mAh Rated Voltage: 3.7V Hardware Version: REV03 Software Version: V1.0.0 1.2 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate A2LA Certificate No.: 6727.01 FCC Registration No.: 746540 CAB ID: CN0136 Report No.: LGT24G037HA02 Page 6 of 8 2. FCC 47CFR §2.1093 REQUIREMENT 2.1RF Exposure Evaluation Method SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. Note: 10-g Extremity SAR Test Exclusion Power Thresholds are 2.5 times higher than the 1-g SAR Test Exclusion Thresholds indicated above. These thresholds do not apply, by extrapolation or other means, to occupational exposure limits. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Report No.: LGT24G037HA02 Page 7 of 8 BLE Mode 2402-2480MHz Detector PEAK BLE 1M-GFSK -2±1dBm BLE 2M-GFSK -2±1dBm BLE 1Mbps2.402-1.51-10.7940.2463 BLE 2Mbps2.402-1.51-10.7940.2463 Mode Limit Maximum Peak Conducted Output Power (dBm) frequency (GHz) Tune up Power (dBm) Tune up Power (mW) Result Remark: Threshold at which no SAR required is Max.0.246≤ 3.0 for 1-g SAR, Separation distance is 5mm. Report No.: LGT24G037HA02 Page 8 of 8 APPENDIX I - PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Note: Please see the attached JX-37_EUT Photos. ※※※※※END OF THE REPORT※※※※※

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China RF TEST REPORT Product Name: Wireless Meat Thermometer Model Name: JX-37 FCC ID: 2BHZ9JX-37 Issued For : Dong guan jin xun Electronic Technology Co., Ltd Room 14030, Building 2, No. 69 Fengqing Road, Fenggang Town, Dongguan City, Guangdong Province Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT24G037RF02 Sample Received Date: Jul. 04, 2024 Date of Test: Jul. 04, 2024 – Jul. 19, 2024 Date of Issue: Jul. 19, 2024 Report No.: LGT24G037RF02 Page 2 of 55 TEST REPORT CERTIFICATION Applicant: Dong guan jin xun Electronic Technology Co., Ltd Address: Room 14030, Building 2, No. 69 Fengqing Road, Fenggang Town, Dongguan City, Guangdong Province Manufacturer: Dong guan jin xun Electronic Technology Co., Ltd Address: Room 14030, Building 2, No. 69 Fengqing Road, Fenggang Town, Dongguan City, Guangdong Province Product Name: Wireless Meat Thermometer Trademark: N/A Model Name: JX-37 Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 15.247, Subpart C ANSI C63.10-2013 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT24G037RF02 Page 3 of 55 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 TEST SOFTWARE AND POWER LEVEL 9 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 10 2.5 EQUIPMENTS LIST 11 3. EMC EMISSION TEST 12 3.1 CONDUCTED EMISSION MEASUREMENT 12 3.2 TEST PROCEDURE 13 3.3 TEST SETUP 13 3.4 EUT OPERATING CONDITIONS 13 3.5 TEST RESULTS 14 4. RADIATED EMISSION MEASUREMENT 16 4.1 RADIATED EMISSION LIMITS 16 4.2 TEST PROCEDURE 18 4.3 TEST SETUP 18 4.4 EUT OPERATING CONDITIONS 19 4.5 FIELD STRENGTH CALCULATION 19 4.6 TEST RESULTS (BAND EDGE REQUIREMENTS) 25 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 27 5.1 LIMIT 27 5.2 TEST PROCEDURE 27 5.3 TEST SETUP 27 5.4 EUT OPERATION CONDITIONS 27 5.5 TEST RESULTS 27 6. POWER SPECTRAL DENSITY TEST 28 6.1 LIMIT 28 6.2 TEST PROCEDURE 28 6.3 TEST SETUP 28 6.4 EUT OPERATION CONDITIONS 28 Report No.: LGT24G037RF02 Page 4 of 55 Table of Contents Page 6.5 TEST RESULTS 28 7. BANDWIDTH TEST 29 7.1 LIMIT 29 7.2 TEST PROCEDURE 29 7.3 TEST SETUP 29 7.4 EUT OPERATION CONDITIONS 29 7.5 TEST RESULTS 29 8. PEAK OUTPUT POWER TEST 30 8.1 LIMIT 30 8.2 TEST PROCEDURE 30 8.3 TEST SETUP 30 8.4 EUT OPERATION CONDITIONS 30 8.5 TEST RESULTS 30 9. ANTENNA REQUIREMENT 31 9.1 STANDARD REQUIREMENT 31 9.2 EUT ANTENNA 31 APPENDIX I - TEST RESULTS 32 DUTY CYCLE 32 MAXIMUM PEAK CONDUCTED OUTPUT POWER 35 -6DB BANDWIDTH 36 OCCUPIED CHANNEL BANDWIDTH 39 MAXIMUM POWER SPECTRAL DENSITY LEVEL 42 BAND EDGE 45 CONDUCTED RF SPURIOUS EMISSION 49 APPENDIX II - MEASUREMENT PHOTOS 54 APPENDIX III - PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS 55 Report No.: LGT24G037RF02 Page 5 of 55 Revision History Rev. Issue Date Revisions 00 Jul. 19, 2024 Initial Issue Report No.: LGT24G037RF02 Page 6 of 55 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 Part 15.247 Meas Guidance v05r02. FCC Part 15.247, Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted Band Edge Emission PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. Report No.: LGT24G037RF02 Page 7 of 55 1.1 TEST FACTORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate A2LA Certificate No.: 6727.01 FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.68dB 2 Unwanted Emissions, conducted ±2.988dB 3 All emissions, radiated 9K-30MHz ±2.84dB 4 All emissions, radiated 30M-1GHz ±4.39dB 5 All emissions, radiated 1G-6GHz ±5.10dB 6 All emissions, radiated>6G ±5.48dB 7 Conducted Emission (9KHz-150KHz) ±2.79dB 8 Conducted Emission (150KHz-30MHz) ±2.80dB Note: The measurement uncertainty is not included in the test result. Report No.: LGT24G037RF02 Page 8 of 55 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name: Wireless Meat Thermometer Trademark: N/A Model Name: JX-37 Series Model: N/A Model Difference: N/A Product Description: Operation Frequency: 2402~2480 MHz Modulation Type: GFSK Radio Technology: BLE Bluetooth Configuration: BLE (1M PHY, 2M PHY) Number Of Channel: 40 Antenna Designation: Chip Antenna Antenna Gain (dBi) 1.8dBi Channel List: Please refer to the Note 3. Battery: Model: 902030 Capacity: 500mAh Rated Voltage: 3.7V Hardware Version: REV03 Software Version: V1.0.0 Connecting I/O Port(s): Please refer to the Note 1. Note: 1. For a mor…

Text truncated - open the document above for the full version.

Page 1 of 2 Report No.: LGT24G037 Appendix - Test Setup photos Set-up for Radiated Spurious Emission, Below 1GHz Set-up for Radiated Spurious Emission, Above 1GHz Page 2 of 2 Report No.: LGT24G037 Set-up for Conducted Emission
