2BK3M-BIR3XA3Electric Golf Push Cart Remote Control

NAVEE Electric Golf Push Cart SPU: Birdie 3/Birdie 3X ENImportant Information FR-CAInformations importantes ES-LAInformación de seguridad 12 ENEN Safety Information ·NAVEE Elecitric golf push carts (hereinafter referred to as push cart) are designed for the transportation of golf bags and clubs contained within. Using the push cart for any other purpose may cause damage to the push cart and cause harm to the user. ·This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental Read this manual carefully before use, and retain it for future reference. For detailed e-manual, please go to naveetech.com Original instructions capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. ·This appliance is not intended for use by persons (including children) with reduced physical, sensoryor mental capabilities, or lack of experience and knowledge, unless they have been given supervision orinstruction concerning use of the appliance by a person responsible for their safety. ·Children should be supervised to ensure that they do not play with the appliance. ·Children shall not play with this product. Ensure children and pets are kept at a safe distance from the push cart while it is operating. ·Do not attempt to transport any other equipment. ·The push cart is not designed for the transportation of people. ·The maximum rated load suitable for this push cart is 30 kg (66.1 lbs). ·Keep your hands and feet away from the wheels when the push cart is moving. ·Do not use the push cart to assist you when walking up hills. ·Do not place the push cart near a heat source or fire source. ·Submerging the push cart in water (e.g. a lake) is likely to cause damage to the push cart. ·Do not operate the push cart whilst under the influence of drugs or alcohol. ·Only use accessories and replacement parts that are approved by the manufacturer. Safety Instructions IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. SAVE THESE INSTRUCTIONS Prolonged Exposure to UV Rays, Rain and the Elements May Damage the Enclosure Materials. Store Indoors When Not in Use. WARNING– To reduce the risk of injury, user must read instruction manual. 34 ENEN ·Watch out for hand crush and pinch points hazards in the following positions during installation and use: between the wheel and frame when installing the wheel; openings on the wheels; and between the folding joint and the stem when folding or unfolding. ·If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. ·Power-off the vehicle during charging, or into a certain nonoperational mode. · WARNING! Keep plastic covering away from children to avoid suffocation. · WARNING! Never use the product close to a water source. · WARNING! Stop using the product when damaged. ·Make sure the push cart is turned off when being transported and kept in its original packaging if possible. ·Please use this product in accordance with the instructions in the user manual. Users are responsible for any loss or damage arising from improper use of this product. · WARNING! Do not use any third-party battery or battery charger. The push cart can only be used with the model FY0422521500 battery charger. · WARNING: For the purposes of recharging the battery, only use the charger provided with this push cart. ·Only use the T2345-B64A battery pack provided with the appliance. ·Always recharge as soon as possible after finishing your round, regardless of the number of holes played. ·Batteries must be stored and charged on a dry, non–carpeted surface at a temperature ranging between 0°C and 40°C. ·Never leave batteries charging for longer than necessary - disconnect when the green LED light indicates the battery is fully charged. ·The battery and charger must only be opened and maintained by authorised personnel. Unauthorised opening increases the risk of safety issues and will invalidate your warranty. ·Take care not to drop the battery as this may cause damage to the internal cells which could affect battery performance and safety. ·Regularly check the battery for visible signs of damage. Do not charge or use the battery if any damage is suspected–contact our Technical Support team immediately for advice. ·If the push cart will not be used for an extended period, fully charge it, then turn it off and store in a cool, dry place. Recharge the push cart at least once every 3 months to avoid over-discharging the battery. ·Do not expose the unit or battery to excessive temperatures. ·Do not damage the battery when removing it to avoid short circuits or liquid leakage. If the battery leaks, keep the fluid from touching your skin or clothes, and wipe it away immediately with a dry cloth. Then send the battery to an appropriate recycling facility or the designated after-sales service team to properly dispose of it. ·Accessories and any additional items which are not approved by the manufacturer shall not be used. ·The appliance is not intended for use at elevations greater than 2000 m above sea level. · WARNING: Cancer and Reproductive Harm – www.P65Warnings. ca.gov. 56 ENEN 1. When removing the batteries from the product, it is better to use up the batteries and make sure your product is disconnected from power. 2.Slide the red toggle switch to disconnect the battery, press and hold the release clip, then lifting the battery using the handle grooves. Do not damage the battery case to avoid any…

Text truncated - open the document above for the full version.

Company name: SPACEWALKER PTE. LTD. ADD: 60 PAYA LEBAR ROAD SINGAPORE Singapore TEL: +86 18861121657 FAX: N/A E-mail: [email protected] Attestation Letter Date: 2026/3/17 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911 (d) (5) (i) (ii) Filing FCC ID: 2BK3M-BIR3XA3 SPACEWALKER PTE. LTD. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. SPACEWALKER PTE. LTD. (“the applicant”) certifies that as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. SPACEWALKER PTE. LTD. (“the applicant”) certifies that the equipment does not use Kaspersky's software information. Sincerely, Signature: Printed Name: xingyu hu Title: Certification Engineer

U.S. AGENT LETTER OF ATTESTATION Date: 2026-05-21 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 § 2.911(d)(7) Filing FCC ID: 2BK3M-BIR3XA3 SPACEWALKER PTE. LTD. certifies that, as of the date of the filing of the application, Iconsigh is our designated U.S. agent for service of process for the above referenced FCC ID. SPACEWALKER PTE. LTD. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Iconsigh accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Company Name: Iconsigh Address: 2310 Homestead Road, Suite C1, Los Altos, CA 94024, USA FRN: 0033398652 Tel.: +1 (408) 320-9867 Email: [email protected] Signed by (printed name): Benjamin Kaur Signature: Applicant: SPACEWALKER PTE. LTD. Address: 60 PAYA LEBAR ROAD SINGAPORE Singapore FRN: 0035939636 Tel: +86 18861121657 Email: [email protected] Signed by (printed name): xingyu hu Signature:

QA-FR-170-B Company name: SPACEWALKER PTE. LTD. ADD: 60 PAYA LEBAR ROAD SINGAPORE Singapore TEL: +86 18861121657 FAX: N/A E-mail: [email protected] FCC Authorization Date: 2026/3/17 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We, SPACEWALKER PTE. LTD., hereby authorizes Bay Area Compliance Laboratories Corp. (Kunshan) to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratories Corp. (Kunshan) on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely, Signature: Printed Name: xingyu hu Title: Certification Engineer

QA-FR-171-A Company name: SPACEWALKER PTE. LTD. ADD: 60 PAYA LEBAR ROAD SINGAPORE Singapore TEL: +86 18861121657 FAX: N/A E-mail: [email protected] FCC Confidential Authorization Date: 2026/3/17 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: 2BK3M-BIR3XA3 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, SPACEWALKER PTE. LTD. hereby requests long-term confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operation Description The abovematerials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Signature: Printed Name: xingyu hu Title: Certification Engineer

Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSA260317002 1 / 3 EXHIBIT A - EUT EXTERNAL PHOTOGRAPHS Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSA260317002 2 / 3 Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSA260317002 3 / 3





Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSA260317002 1 / 4 EXHIBIT B - EUT INTERNAL PHOTOGRAPHS UWB Antenna: Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSA260317002 2 / 4 BLE Antenna Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSA260317002 3 / 4 Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSA260317002 4 / 4

Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: RKSA260317002-00A Page 13 of 66 FCC §1.1310 &§2.1093 - RF EXPOSURE Applicable Standard According to§2.1093 and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. According to KDB 447498 D01 General RF Exposure Guidance 1. f (GHz) is the RF channel transmit frequency in GHz. 2. Power and distance are rounded to the nearest mW and mm before calculation. 3. The result is rounded to one decimal place for comparison. 4. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test Exclusion. RF Exposure for devices that operate above 6 GHz (1.1310): 2.1093 (d): Portable devices that transmit at frequencies above 6 GHz are to be evaluated in terms of the MPE limits specified 47 CFR 1.1310. Measurements and calculations to demonstrate compliance with MPE Field strength or power density limits for device operating above 6 GHz should be made at a minimum distance of 0.5 cm from the radiating source. Limits for General Population/Uncontrolled Exposure Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f²) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 f = frequency in MHz; * = Plane-wave equivalent power density Calculated Formulary: Predication of MPE limit at a given distance S = PG/4πR² = power density (in appropriate units, e.g. mW/cm 2 ); P = power input to the antenna (in appropriate units, e.g., mW); G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain; R = distance to the center of radiation of the antenna (appropriate units, e.g., cm); Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: RKSA260317002-00A Page 14 of 66 Calculated Data: Mode Frequency Range (MHz) Max Tune-up Conducted Power★ Calculated Distance (mm) Calculated Value Threshold (1-g SAR) SAR Test Exclusion (dBm) (mW) BLE 2402-2480 2.5 1.78 5 0.6 3.0 Yes Mode Frequency Range (MHz) Antenna Gain Max Tune-up Conducted Power★ Evaluation Distance (mm) Power Density (mW/cm 2 ) MPE Limit (mW/cm 2 ) (dBi) (numeric) (dBm) (mW) UWB 6489.6 2.18 1.65 -6.18 0.24 5 0.1267 1.0 Note： 1. Max Tune-up Conducted Power★ (-6.18dBm)= Max Tune-up EIRP★(-4.0 dBm)- Antenna Gain (2.18dBi) 2. BLE and UWB can Simultaneous Transmit For simultaneously transmit, the worst condition is below: =0.6/3.0+ 0.1267/1=0.2+0.1267= 0.3267 < 1.0 Result: No SAR test is required.

MSU1668AntennaSpecificationDocument Projectname： MSU1668AntFrequency range： 6.24GHz-6.74Ghz InternalPart Number: /Version number ： A.1 Date ： 2026/01/17 FutenTechnology(Shanghai)Co.,Ltd. Audit RFFrankwu Design RFFrankwu MEZhang Liuyang QEGaoYu MEZhangLiuyang SalesWangQiao Date： 2026-01-17 Affirm RF ME Remarks TableofContents 1.ProjectImage 2.TestFixture 3.MatchingCircuit 4.S11Test 4.0SllTestingMethod 4.lS11Parameters 4.2ParameterImage 4.2.1Returnloss 4.2.2V.S.W.R 5.DarkroomTestData 5.0testingfacility 5.lActiveData 5.2PassiveData 6.GroundingTreatmentforthePrototype 7.AntennaDiagram UWBAnt 1.ProjectImage AntPicture 2. AntennaSpecifications UWBantenna Specification WorkingFrequencyRangeWorkingFrequency CH5:6.24Ghz-6.74Ghz Bandwidth >500MHz Impedance 50 Ω Gain (dBi) 2.18 StandingWave Ratio (VSWR) <1.6 WorkingTemperature -40°C~+85 °C Power Capacity 5W 3. MatchingCircuit NO Matching 4. S11Test 4.0 S11 TestingMethod 4.1 S11 Parameters Frequency（MHZ） 624065406740 VSWR1.521.591.08 RL-13.7-12.73-27.74 4.2ParameterImage 4.2.1Returnloss 4.2.2V.S.W.R 5.DarkroomTestData 5.0Testingequipment TestingSystem:ShieldedChamber TestEnvironment:Temperature22°C±3°C,Humidity50%±l5% Testingequipment:Fortestingpassivedata,usethe AgilentE5071Cnetworkanalyzer. 5.lActiveData NG 5.2PassiveData PassiveTestForUWB(CH5) Freq (MHz) Effi (%) Effi (dB) Gain (dBi) 624061.37-2.122.08 629057.49-2.42.18 634047.07-3.271.26 639056.61-2.472.01 644060.22-2.21.64 649058.56-2.321.37 654058.05-2.361.87 659055.64-2.551.94 664047.86-3.21.34 669048.62-3.131.95 674046.25-3.351.45 6.GroundingTreatmentforthePrototype Noprocessing 7.AntennaDiagram 8.RadiationPattern(3D/2D) 6340MHZ 6640MHZ

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (Kunshan). This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP, or any agency of the U.S. Government. This report contains data that are not covered by the NVLAP accreditation. Page 1 of 46 FCC PART 15F TEST REPORT For SPACEWALKER PTE. LTD. 60 PAYA LEBAR ROAD SINGAPORE Singapore FCC ID: 2BK3M-BIR3XA3 Report Type: Original Report Product Name: Electric Golf Push Cart Remote Control Report Number: RKSA260317002-00B Report Date: 2026-06-23 Reviewed By: Winnie Yang Approved By: Kyle Xu Prepared By: Bay Area Compliance Laboratories Corp. (Kunshan) No.248 Chenghu Road, Kunshan, Jiangsu Province, China Tel: +86-512-86175000 Fax: +86-512-88934268 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: RKSA260317002-00B Page 2 of 46 TABLE OF CONTENTS REPORT REVISION HISTORY................................................................................................................................. 4 GENERAL INFORMATION ....................................................................................................................................... 5 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 5 OBJECTIVE ................................................................................................................................................................... 5 TEST METHODOLOGY .................................................................................................................................................. 5 MEASUREMENT UNCERTAINTY .................................................................................................................................... 6 SYSTEM TEST CONFIGURATION .......................................................................................................................... 7 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 7 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 7 EUT EXERCISE SOFTWARE .......................................................................................................................................... 7 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 7 EXTERNAL I/O CABLE.................................................................................................................................................. 7 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 8 TEST EQUIPMENT LIST ......................................................................................................................................... 10 SUMMARY OF TEST RESULTS ............................................................................................................................. 11 FCC §1.1310 &§2.1093 - RF EXPOSURE .................................................................................................................. 12 CALCULATED FORMULARY: ....................................................................................................................................... 12 FCC §15.203 – ANTENNA REQUIREMENT .......................................................................................................... 14 APPLICABLE STANDARD ............................................................................................................................................ 14 ANTENNA CONNECTOR CONSTRUCTION .................................................................................................................... 14 FCC §15.207 (a) – AC LINE CONDUCTED EMISSIONS ..................................................................................... 15 APPLICABLE STANDARD ............................................................................................................................................ 15 TEST SYSTEM SETUP .................................................................................................................................................. 15 EMI TEST RECEIVER SETUP ....................................................................................................................................... 15 TEST PROCEDURE ...................................................................................................................................................... 16 TEST RESULTS SUMMARY .......................................................................................................................................... 16 TEST DATA: SEE APPENDIX ....................................................................................................................................... 16 FCC §15.209, §15.519(c)(d)- SPURIOUS EMISSIONS ........................................................................................... 17 APPLICABLE STANDARD ............................................................................................................................................ 17 EUT SETUP ................................................................................................................................................................ 17 EMI TEST RECEIVER & SPECTRUM ANALYZER SETUP .............................................................................................. 19 TEST PROCEDURE ...................................…

Text truncated - open the document above for the full version.

Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSA260317002 1 / 3 EXHIBIT D - TEST SETUP PHOTOGRAPHS Conducted Emissions (Front View) Conducted Emissions (Left View) Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSA260317002 2 / 3 Radiated Emissions (Below 30 MHz) Radiated Emissions (30MHz-1GHz) Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSA260317002 3 / 3 Radiated Spurious Emissions (1-18 GHz) Radiated Spurious Emissions (18-40 GHz)
