2BK7Z-YYY2.1 Amplifier Speaker

JIAXING VANSONIC Co., LTD QR-RD-07 Engineer Test Specification Model： 2.1 Amplifier Speaker Type: Car Speaker S/N： / Loudspeaker Client： / Speaker System Total High pitched Bass Box Dimension Drawing(Unit:mm) Weight ：2900g+/-10% Size ：BASS Box 260x185x118mm High pitched φ123mm 1、 Connection specification Input Voltage： DC 29V/2A Bluetooth： Sofa soundbar Bass Box： 4Ω30W High pitched： 2X 8Ω10W White Line Right Channel. Black Line Left Channel. 2、Listening Test R/B Test： Input：0 dBu；Freq. Range：20Hz~20KHz， Sweep speed：1-2S，Testing periodic time：2-3 Cycle 3、Power Test Setup Support Duration 96 Hours Level Bass Box 30W + High pitched 2x10W Signal music abuse Freq. Range 20Hz-20KHz JIAXING VANSONIC Co., LTD QR-RD-07 4、 Acoustic Performance Test equipment Klippel R&D Test condition subwoofer box on the ground and tweeters on Baffle IN ANECHOIC ROOM Smoothing 1/3 smoothing FREQ Response 20Hz-20KHz AT：1m Input：0 dBu 5、Quality Control Testing On-line Test equipment Sound Check Test requirement AQL 100% Test location On-line Testing Test description polarity、Frequency Response、Average SPL Test parameters On-line Base on Golden Sample Revision record Change Date content of change 2024-07-13 Initial release FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful interference in a residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and used in accordance with the instructions, maycause harmful interference to radio communications. However, there is no guarantee thatinterference will not occur in a particular installation. If this equipment does cause harmfulinterference to radio or television reception, which can be determined by turning the equipmentoff and on, the user is encouraged to try to correct the interference by one or more of thefollowing measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 0cm between the radiator and your body.

JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD NO.1842 Huayu Road, Jiaxing,Zhejiang China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-9-20 To whom it may concern: We, JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD, hereby certify that the equipment for which authorization is sought (FCC ID: 2BK7Z-YYY) is not “covered” equipment prohibited from receiving an equipment authorization pursuant to § 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, we are not identified on the Covered List (https://www.fcc.gov/supplychain/coveredlist) as an entity producing “covered” equipment. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(b) and (d)(5) and (6). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Sincerely, Signature Baojiu Zhang Manager JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD 62_[model] CoveredEqu_2.911(d)(5)(i) and (ii) - U, V03

JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD NO.1842 Huayu Road, Jiaxing, Zhejiang CHINA Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024/09/19 U.S. Agent Designation JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2BK7Z-YYY): Name and company of U.S. agent: GSS SERVICE INC Physical U.S. address of agent: 6547 N Academy Blvd #2266 Colorado Springs COLORADO 80918 United States FRN of U.S. agent: 0033402082 Email address of U.S. agent: [email protected] GSS SERVICE INC acknowledges their obligation to accept service of process on behalf of JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD with the FRN [0035969013] accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature Baojiu Zhang Manager JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD Signature Michoux Logan PM GSS SERVICE INC 48_[mo del] US_Agent_2.911(d)(7) - U, V0 5

JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD Add: NO.1842 Huayu Road, Jiaxing,Zhejiang China Date: 2024-9-20 FCC ID: 2BK7Z-YYY Dear Sir/Madam, We, JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: 2.1 Amplifier Speaker Model no.: 2.1 Amplifier Speaker, 2.1 Amplifier Speaker(silver) , 2.1 Amplifier Speaker(blue), 2.1 Amplifier Speaker(red), 2.1 Amplifier Speaker(brown), 2.1 Amplifier Speaker(yellow), 2.1 Amplifier Speaker(Silk), 2.1 Amplifier Speaker(thin), MS221 Amplifier Speaker, MB221 Amplifier Speaker, ZHS221 Amplifier Speaker, ZHB221 Amplifier Speaker, QS221 Amplifier Speaker, QB221 Amplifier Speaker, GS221 Amplifier Speaker, GB221 Amplifier Speaker Sincerely, Name/Title： Baojiu Zhang/Manager Company: JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD Address: NO.1842 Huayu Road, Jiaxing,Zhejiang China Phone: 15384295081 Fax: N/A E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2024-9-20> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2BK7Z-YYY 2.1 Amplifier Speaker For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Baojiu Zhang/Manager Company: JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD Address: NO.1842 Huayu Road, Jiaxing,Zhejiang China Phone: 15384295081 Fax: N/A E-Mail: [email protected]

JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD NO.1842 Huayu Road, Jiaxing,Zhejiang China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-9-20 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2BK7Z-YYY including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. By signing this application form, we agree to Eurofins’ current valid General Terms and Conditions (AGB),Testing and Certification Regulations (PZO) which can be viewed on following website www.eurofins.de/ee or retrieved on request. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Baojiu Zhang/Manager Company: JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD Address: NO.1842 Huayu Road, Jiaxing,Zhejiang China Phone: 15384295081 Fax: N/A E-Mail: [email protected]

FCC ID: 2BK7Z-YYY External Photos of the EUT FCC ID: 2BK7Z-YYY FCC ID: 2BK7Z-YYY

Label and Location Size: L: 3.0cm*W: 2.0cm Label and Location FCC ID : 2BK7Z-YYY

FCC ID: 2BK7Z-YYY Internal Photos of the EUT FCC ID: 2BK7Z-YYY ANT

RF Exposure evaluation FCC ID: 2BK7Z-YYY 1.1. Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure requirement KDB447498 v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 1.2. Requirement According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 1.3. Manufacturing tolerance GFSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) 3.0 3.0 3.0 Tolerance ±(dB) 1.0 1.0 1.0 π/4DQPSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) 1.0 1.0 2.0 Tolerance ±(dB) 1.0 1.0 1.0 Page 2 of 2 2. E v a l u a t i o n R e s u l t Evaluation Results Band/Mode f (GHz) Antenna Distance (mm) RF output power (including tune-up tolerance) SAR Test Exclusion Threshold SAR Test Exclusion dBm mW BT 2.450 5 4.0 2.5119 0.7863<3.0 Yes 3. C o n c l u s i o n The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06 .....................End of Report.........................

1. Antenna Description: Antenna type PCB antenna Model 2.1 Amplifier Speaker Frequency range 2400-2500MHz Manufacturer JIAXING VANSONIC Co., LTD ANT Peak Gain 0.88 dBi 2. Antenna Photo: Length :14.40mm Width:6.29mm 3. Test Equipment & Conditions 3.1 Test instrument VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. 3.2 Test environment and methods 4．Antenna Radiation Pattern 2400MHz 2450MHz 2500MHz
