2BK7ZKSSP004KEESON-SPEAKER

KSSP004 客户使用说明书 Customer User Guide 适用于 KSSP004 条箱 / Applicable to KSSP004 文档用途 / Purpose 供客户了解产品功能、模式说明及日常使用方法。 / For customer reference on functions, mode descriptions, and daily operation. 需配套相关主控盒和遥控器使用。 / It needs to be used in conjunction with the relevant main control box and remote control. 中文说明 感谢您选择 KSSP004。使用本产品前，请先阅读本说明书并妥善保存，以便日后查阅。 1. 产品概述 KSSP004 为一款带振动按摩功能的音响系统，可通过遥控器进行模式切换与振动强度调节；在音乐按摩模 式下，可通过蓝牙连接手机播放音乐，并使振子随音乐节奏产生震动。 2. 主要功能 • 普通按摩模式：支持头部与脚部两路振动控制，每路均提供三个强度档位。 • 音乐按摩模式：连接蓝牙后可播放手机音频，振子会随音乐律动。 • 多种按摩模式：提供 28Hz、40Hz 以及模式 1、2、3 共五种模式。 • 有线音频：AUX 线接入播放设备后可播放声音。 • 语音提示：支持开机、蓝牙连接/断开、普通模式、音乐模式等语音提示。 • 蓝牙回连：已连接设备在规定条件下可自动回连。 3. 模式介绍 以下模式说明为本产品的核心使用内容，请在使用前熟悉各模式的进入方式与效果。 • 普通模式：产品上电后默认进入普通模式，并播报“Message Mode”。在普通模式下，遥控器可用于控 制按摩功能。 • 音乐模式：长按模式键约 3 秒，指示灯闪烁后常亮，产品播报“Sound Mode”，进入音乐模式。此时可 搜索并连接蓝牙，连接后可播放手机音乐，并通过手机音量和遥控器共同调节震动体验。 • 模式退出：再次长按模式键约 3 秒，指示灯闪烁后熄灭，产品退出音乐模式并返回普通模式，同时播 报“Message Mode”。 • 按摩模式：支持 28Hz、40Hz 以及模式 1、2、3。点按相应按键可切换模式；模式 1、2、3 采用循环切 换方式，第四次按下可关闭。头部按摩与脚部按摩均支持三档强度调节。 模式 进入方式 功能说明 普通按摩模式 产品上电后默认进入 可通过遥控器控制头部与脚部振 动；支持 28Hz、40Hz 及模式 1/2/3；可调节三档强度。 音乐按摩模式 长按模式键约 3 秒，听到“Sound Mode” 可搜索并连接蓝牙，播放手机音 乐；振子会随音乐节奏振动；遥 控器仍可调节振动强度。 返回普通按摩模式 再次长按模式键约 3 秒，听到 “Message Mode” 退出音乐按摩模式并返回普通按 摩模式。 4. 控制与指示说明 3.1 模式与功能对照表 以下表格保留原使用说明书中的模式介绍、图示和对应说明，便于客户快速识别头部按摩、脚部按摩以及遥控器上的 对应模式。 项目 分类 / 图示 描述 1.连接及提示音 上电 音响与控制盒连接上电后发出“Line mode”提示音，此时默认无法搜索到蓝 牙。 连接蓝牙 蓝牙连接成功后发出“Bluetooth connected”提示音；连接后其他手机 无法再次搜索到该蓝牙号。 断开蓝牙 蓝牙断开连接后发出“Bluetooth disconnected”提示音。 普通模式 进入普通模式时播放“Massage Mode / Message Mode”提示音。 音乐模式 进入音乐模式时播放“Sound Mode”提 示音。 有线模式 AUX 线插入播放设备后可播放声音。 音乐播放优先级 当蓝牙模式与有线模式同时播放音乐 时，只播放蓝牙模式中的音乐。 蓝牙回连 1）音响断电再上电后，约 5 秒会自动 重连。 2）离开蓝牙范围后断开连接；约 120 秒内重新靠近可自动重连，超过 120 秒不再自动重连。 配对窗口 / 隐藏蓝牙版本 上电后发出“Line mode”，默认无法搜 索到蓝牙。 需长按遥控器模式键进入音乐模式， 指示灯闪烁一次后常亮；在约 30 秒内 可搜索并连接蓝牙，搜索名为 “ProSmart *******”。 蓝牙断开后，需重新开启音乐模式才 可再次被搜索到。 2.蓝牙有效范围 在空旷空间内，蓝牙有效连接范围约 10 米。 3.普通模式 头部按摩 / Head 按下对应遥控器按键，LED 灯点亮， 共三个档位；第四次按下关闭头部按 摩。 脚部按摩 / Foot 按下对应遥控器按键，LED 灯点亮， 共三个档位；第四次按下关闭脚部按 摩。 28Hz 开启或关闭全部按摩器；可通过头部 按摩/脚部按摩按键改变强度。 40Hz 开启或关闭全部按摩器；可通过头部 按摩/脚部按摩按键改变强度。 4.模式切换 模式键 / Mode Key 上电后控制盒默认处于普通模式。 长按模式键至 LED 灯闪烁一次后常 亮，音响播报“Sound Mode”，进入音 乐模式；此时声波马达会随音乐震 动，遥控器可调节三档强度，默认定 时 10 小时。 再次长按模式键至 LED 灯闪烁一次后 熄灭，音响播报“Massage Mode / Message Mode”，返回普通模式。 5.按摩模式 模式一 鼓点波形。 模式二 三角波形。 模式三 葫芦波形。 模式说明 点按模式键可在模式 1 / 2 / 3 之间切 换；对应指示灯点亮。第四次按下关 闭，可通过头部按摩/脚部按摩改变强 度。 • 头部振动与脚部振动为独立控制，每路均有 Low / Med / High 三个档位。 • 强度指示灯显示规则：亮 1 灯为 Low，亮 2 灯为 Med，亮 3 灯为 High。 • 28Hz 与 40Hz 为独立模式按钮；模式 1、2、3 通过模式切换键进行切换。 • 产品开机默认模式为 28Hz。 • 当振子停止振动时，主控盒风扇会停止转动。 5. 快速使用步骤 1. 首次使用时，请先将遥控器与主控盒配对：按住遥控器上的“pair”键，同时打开主控开关电源。 2. 接通电源后，设备会发出提示音。根据当前状态，产品可进入相应模式。 3. 如需进行普通按摩，使用遥控器选择头部/脚部振动，并调节强度和模式。 4. 如需使用音乐按摩，长按模式键约 3 秒；进入音乐按摩模式后，用手机搜索并连接蓝牙设备。 5. 蓝牙连接成功后，设备会发出“Bluetooth connected”提示音；断开时会发出“Bluetooth disconnected”提 示音。 6. 如需退出音乐按摩，再次长按模式键约 3 秒，返回普通按摩模式。 6. 蓝牙与音频使用 • 蓝牙搜索窗口：产品上电后会播报“Line mode”，此时默认不可被蓝牙搜索。只有进入音乐模式后，才 会在约 30 秒内开放蓝牙搜索窗口。 • 蓝牙连接成功后，其他手机无法再次搜索到该设备。 • 当蓝牙模式与 AUX 有线模式同时存在音频输入时，优先播放蓝牙音乐。 • 产品断电重启后，约 5 秒内会自动尝试回连已记忆设备；离开蓝牙有效范围后，如在约 120 秒内重新 靠近，系统可自动回连。 • 蓝牙有效距离：在空旷环境下，蓝牙有效连接范围约为 10 米。 7. 提示音说明 7.1 音响外观尺寸图 以下尺寸图来自原使用说明书，便于客户在安装、开孔或结构预留时进行确认。 提示音 含义 Line mode 上电提示音 Bluetooth connected 蓝牙连接成功 Bluetooth disconnected 蓝牙连接断开 Message Mode 进入普通按摩模式 Sound Mode 进入音乐按摩模式 8. 日常注意事项 • 使用前请确认电源线与 AUX 线连接可靠。 • 请避免过度拉扯电源线和连接线；如发现接触不良或磨损，应及时更换。 • 请勿让包装箱过度堆叠，避免与尖锐物碰撞，搬运时避免用力挤压。 • 若产品在使用过程中出现异常，请停止使用并联系服务人员。 English User Guide Thank you for choosing KSSP004. Please read this guide before use and keep it for future reference. 1. Product Overview KSSP004 is an audio system with vibration massage functions. It can be operated by remote control for mode switching and vibration intensity adjustment. In Sound Mode, the system can connect to a mobile phone via Bluetooth, play music, and drive the vibrators in sync with the music rhythm. 2. Main Functions • Massage Mode: supports separate head and foot vibration control, each with three intensity levels. • Sound Mode: after Bluetooth connection, the system plays music from a mobile phone and the vibrators move with the audio rhythm. • Multiple massage options: 28Hz, 40Hz, and modes 1, 2, and 3. • Wired audio input: music can also be played through the AUX connection. • Voice prompts: power-on, Bluetooth connected/disconnected, Massage Mode, and Sound Mode prompts are supported. • Bluetooth reconnection: previously paired devices may reconnect automatically under specified conditions. 3. Mode Introduction The following mode descriptions are the key part of product operation and should be understood before use. • Massage Mode: The product enters Massage Mode by default after power-on and announces "Message Mode". In this mode, the remote control is used for vibration massage control. • Sound Mode: Press and hold the mode key for about 3 seconds. After the indicator flashes once and stays on, the product announces "Sound Mode" and enters Sound Mode. Bluetooth becomes discoverable, the phone can connect for music playback, and the vibration effect can be adjusted by both phone volume and the remote control. • Exit Sound Mode: Press and hold the mode key again for about 3 seconds. After the indicator flashes and turns off, the product exits Sound Mode, returns to Massage Mode, and announces "Message Mode". • Massage Options: The system supports 28Hz, 40Hz, and modes 1, 2, and 3. Press the corresponding key to switch modes. Modes 1, 2, and 3 are cycled by repeated pressing, and the fourth press turns the mode off. Both head and foot massage channels support three intensity levels. Mode How to Enter Description Massage Mode Default after power-on Remote control can adjust head and foot vibration. Supports 28Hz, 40Hz, and modes 1/2/3 with three intensity levels. Sound Mode Press and hold the mode key for about 3 seconds until "Sound Mode" is heard Bluetooth becomes available for search and connection. Music from the phone can be played, and the vibrators move with the music rhythm. Return to Massage Mode Press and hold the mode key again for about 3 seconds until "M…

Text truncated - open the document above for the full version.

Attestation Statements Date: 2026-03-05 TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for(FCC ID: 2BK7ZKSSP004) JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD, the undersigned, hereby authorize FCC US Agent, LLC to act as our designated agent for service of process, JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. FCC US Agent, LLC accepts the responsibility to act as designated agent for service of process. Applicant Information： Company name: JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD Contact Name: Baojiu Zhang Address: NO.1842 Huayu Road, Jiaxing, Zhejiang CHINA Telephone No: 15384295081 Email: [email protected] FRN: 0035969013 Signature: Baojiu Zhang Agent Information: Company Name: FCC US Agent, LLC Address:3722 Illinois Avenue, Saint Charles, IL, 60174, USA FRN: 0033402884 Contact Name: Tim Payne Telephone No: 708-571-3148 Email: Signature: Tim Payne [email protected]

Rev 1/26/2023 JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026-03-05 FCC ID: 2BK7ZKSSP004 Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24- 886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Applicant: JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD Address: NO.1842 Huayu Road, Jiaxing, Zhejiang CHINA Contact Person: Baojiu Zhang Tel.: 15384295081 Email: [email protected] Sincerely, Signature:

JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD Declaration Letter of Model Difference Date: 2026-03-05 FCC ID: 2BK7ZKSSP004 Tested Model Number: KSSP004 Adding Model Number(s): KSSP020, KSSP018 All Adding Model Number(s) is/are same electrically identical as Tested Model Number. Only the model and appearance are different. Yours Sincerely, Applicant: JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD Address: NO.1842 Huayu Road, Jiaxing, Zhejiang CHINA Contact Person: Baojiu Zhang Tel.: 15384295081 Email: [email protected] Sincerely, Signature:

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD Date：2026-03-05 Product Model Number: KSSP004, KSSP020, KSSP018 FCC ID：2BK7ZKSSP004 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. Signature: By: Baojiu Zhang Contact Listed on FCC Wesbite Title: Manager Email: [email protected] On behalf of: JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD

JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: March 20, 2026 Subject; Request for Confidentiality FCC ID: 2BK7ZKSSP004 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Baojiu Zhang Title: Manager

Page 1 of 3 Report No.: LGT26A142 Appendix - External Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 3 Report No.: LGT26A142 Appendix - External Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 3 Report No.: LGT26A142 Appendix - External Photographs of EUT Constructional Details Photo 5 Photo 6

Label Size: 30*56mm FCC ID: 2BK7ZKSSP004 IC: 35126-KSSP004 HVIN: KSSP004 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Page 1 of 3 Report No.: LGT26A142 Appendix - Internal Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 3 Report No.: LGT26A142 Appendix - Internal Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 3 Report No.: LGT26A142 Appendix - Internal Photographs of EUT Constructional Details Photo 5 ANT

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 8 EMF TEST REPORT Product Name: KEESON-SPEAKER Model Number: KSSP004, KSSP020, KSSP018 FCC ID: 2BK7ZKSSP004 Issued For : JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD NO.1842 Huayu Road, Jiaxing, Zhejiang CHINA Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT26A142HA01 Sample Received Date: Jan. 21, 2026 Date of Test: Jan. 21, 2026 ~ Jan. 30, 2026 Date of Issue: Jan. 30, 2026 Report No.: LGT26A142HA01 Page 2 of 8 TEST REPORT CERTIFICATION Applicant: JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD Address: NO.1842 Huayu Road, Jiaxing, Zhejiang CHINA Manufacturer: JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD Address: NO.1842 Huayu Road, Jiaxing, Zhejiang CHINA Product Name: KEESON-SPEAKER Trademark: N/A Model Number: KSSP004, KSSP020, KSSP018 Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47 CFR §2.1093 KDB 447498 D01 General RF Exposure Guidance v06 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT26A142HA01 Page 3 of 8 TABLE OF CONTENTS 1 . GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST LABORATORY 5 2 . FCC 47CFR §2.1093 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 8 Report No.: LGT26A142HA01 Page 4 of 8 Revision History Rev. Issue Date Revisions 00 Jan. 30, 2026 Initial Issue Report No.: LGT26A142HA01 Page 5 of 8 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name: KEESON-SPEAKER Test Model Number: KSSP004 Series Number: KSSP020, KSSP018 Model Difference: Only the model and appearance are different. Frequency Bands: Bluetooth 2402-2480MHz Rating: Input: DC 29V Hardware Version: QS002B-EP Software Version: N/A 1.2 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate: FCC Registration No.: 746540 CAB ID: CN0136 Report No.: LGT26A142HA01 Page 6 of 8 2. FCC 47CFR §2.1093 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in KDB 447498 D01 General RF Exposure Guidance v06 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. Report No.: LGT26A142HA01 Page 7 of 8 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] • [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz. Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Report No.: LGT26A142HA01 Page 8 of 8 2.3 TEST RESULT Turn up Result Mode Turn up Power BT-GFSK 0±1dBm BT-π/4-DQPSK 1.5±1dBm BT-8DPSK 2±1dBm The MPE result of worst mode: RF Function Frequency (MHz) Max Turn up Power (dBm) Max Turn up Power (mW) Estimated SAR Limit Ratio Result BT 2480 3.00 2.00 0.628 3 0.209 Pass Note: 1. The Maximum Power Density is less than the limit, complies with the exemption requirements. ※※※※※END OF THE REPORT※※※※※

Manufacturer: JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD Address: NO.1842 Huayu Road, Jiaxing, Zhejiang CHINA Antenna specifications Product name 2.4G Antenna Frequency (MHz) 2400-2500 MHz VSWR <2.0 Peak Gain (dBi) 0 Impendance (Ohm) 50 Materail PCB Antenna Radiation Pattern Omni-Directional Max. Input Power (W) 10W Dimensions (mm) Manufacturer: JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD Address: NO.1842 Huayu Road, Jiaxing, Zhejiang CHINA 1.Gain and Efficiency Frequency Gain (dBi) Efficiency( ) 2402MHz 0 31% 2441MHz -0.85 28% 2480MHz -1.01 26% 2.VSWR Frequency(MHz) VSWR 2400 1.25 2450 1.18 2500 1.16 Manufacturer: JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD Address: NO.1842 Huayu Road, Jiaxing, Zhejiang CHINA 3.Directional diagram

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 78 RF TEST REPORT Product Name: KEESON-SPEAKER Model Number: KSSP004, KSSP020, KSSP018 FCC ID: 2BK7ZKSSP004 Issued For : JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD NO.1842 Huayu Road, Jiaxing, Zhejiang CHINA Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT26A142RF01 Sample Received Date: Jan. 21, 2026 Date of Test: Jan. 21, 2026 ~ Jan. 30, 2026 Date of Issue: Jan. 30, 2026 Report No.: LGT26A142RF01 Page 2 of 78 TEST REPORT CERTIFICATION Applicant: JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD Address: NO.1842 Huayu Road, Jiaxing, Zhejiang CHINA Manufacturer: JIAXING VANSONIC ELECTRONICS TECHNOLOGY CO.,LTD Address: NO.1842 Huayu Road, Jiaxing, Zhejiang CHINA Product Name: KEESON-SPEAKER Trademark: N/A Model Number: KSSP004, KSSP020, KSSP018 Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 15.247, Subpart C ANSI C63.10-2020 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT26A142RF01 Page 3 of 78 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST LABORATORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 FREQUENCY HOPPING SYSTEM REQUIREMENTS 10 2.4 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 12 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 12 2.6 EQUIPMENTS LIST 13 3. EMC EMISSION TEST 15 3.1 CONDUCTED EMISSION MEASUREMENT 15 3.2 RADIATED EMISSION MEASUREMENT 19 4. CONDUCTED SPURIOUS & BAND EDGE EMISSION 26 4.1 LIMIT 34 4.2 TEST PROCEDURE 34 4.3 TEST SETUP 34 4.4 EUT OPERATION CONDITIONS 35 4.5 TEST RESULTS 35 5. NUMBER OF HOPPING CHANNEL 36 5.1 LIMIT 36 5.2 TEST PROCEDURE 36 5.3 TEST SETUP 36 5.4 EUT OPERATION CONDITIONS 36 5.5 TEST RESULTS 36 6. AVERAGE TIME OF OCCUPANCY 37 6.1 LIMIT 37 6.2 TEST PROCEDURE 37 6.3 TEST SETUP 37 6.4 EUT OPERATION CONDITIONS 37 6.5 TEST RESULTS 37 7. HOPPING CHANNEL SEPARATION MEASUREMEN 38 7.1 LIMIT 38 7.2 TEST PROCEDURE 38 Report No.: LGT26A142RF01 Page 4 of 78 7.3 TEST SETUP 38 7.4 EUT OPERATION CONDITIONS 38 7.5 TEST RESULTS 38 8. BANDWIDTH TEST 39 8.1 LIMIT 39 8.2 TEST PROCEDURE 39 8.3 TEST SETUP 39 8.4 EUT OPERATION CONDITIONS 39 8.5 TEST RESULTS 39 9. OUTPUT POWER TEST 40 9.1 LIMIT 40 9.2 TEST PROCEDURE 40 9.3 TEST SETUP 40 9.4 EUT OPERATION CONDITIONS 40 9.5 TEST RESULTS 40 10. ANTENNA REQUIREMENT 41 10.1 STANDARD REQUIREMENT 41 10.2 EUT ANTENNA 41 APPENDIX I - TEST RESULTS 42 1. DUTY CYCLE 42 2. BANDWIDTH 46 3. MAXIMUM CONDUCTED OUTPUT POWER 53 4. CARRIER FREQUENCY SEPARATION 57 5. NUMBER OF HOPPING FREQUENCIES 59 6. TIME OF OCCUPANCY (DWELL TIME) 61 7. UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS 64 APPENDIX II - MEASUREMENT PHOTOS 78 Report No.: LGT26A142RF01 Page 5 of 78 Revision History Rev. Issue Date Revisions 00 Jan. 30, 2026 Initial Issue Report No.: LGT26A142RF01 Page 6 of 78 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247, Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247(a)(1) Hopping Channel Separation PASS -- 15.247(a)(1)&(b)(1) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247(d) Conducted Spurious & Band Edge Emission PASS -- 15.247(a)(1)(iii) Number of Hopping Frequency PASS -- 15.247(a)(1)(iii) Dwell Time PASS -- 15.247(a)(1) Bandwidth PASS -- 15.205 Restricted bands of operation PASS -- Part 15.247(d)/part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. Report No.: LGT26A142RF01 Page 7 of 78 1.1 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate: FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 Occupied Channel Bandwidth ±0.46% 2 RF Output Power, Conducted ±0.71dB 3 Power Spectral Density, Conducted ±1.57dB 4 Unwanted Emission, Conducted ±0.63dB 5 Conducted emission ±2.80dB 6 All Emissions, Radiated (0.009-30MHz) ±2.16dB 7 All Emissions, Radiated (30MHz-1GHz) ±4.61dB 8 All Emissions, Radiated (1GHz-18GHz) ±5.49dB 9 Temperature ±0.5∞C 10 Humidity ±2% 11 Duty Cycle ±2.3% Note: The measurement uncertainty is not included in the test result. Report No.: LGT26A142RF01 Page 8 of 78 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name: KEESON-SPEAKER Test Model Number: KSSP004 Series Number: KSSP020, KSSP018 Model Difference: Only the model and appearance are different. Channel List: Please refer to the Note 3. Bluetooth: Frequency:2402 – 2480 MHz Modulation: GFSK(1Mbps), π/4-DQPSK(2Mbps), 8DPSK(3Mbps) Antenna Type: PCB Antenna Antenna Gain: 0dBi Rating: Input: DC 29V Hardware Version: QS002B-EP Software Version: N/A Connecting I/O Port(s): Please refer to the Note 1. Note: 1. For a more detailed features description, please refer to t…

Text truncated - open the document above for the full version.

Page 1 of 2 Report No.: LGT26A142 Appendix - Test Setup photos Set-up for Radiated Spurious Emission, Below 1GHz Set-up for Radiated Spurious Emission, Above 1GHz Page 2 of 2 Report No.: LGT26A142 Set-up for Conducted Emission Set-up for Radio Spectrum
