2BKAL-IMUBOXgnss receiver

APOGEO SP. Z O.O.
gnss receiver - FCC ID 2BKAL-IMUBOX - APOGEO SP. Z O.O.
Click to zoom

Application Details

Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
Date of Grant
Aug 26, 2024
Application Purpose
Original Equipment
Date of Application
Aug 26, 2024
Equipment Note
gnss receiver
Frequency Range
2402.00000000 - 2480.00000000
Company
APOGEO SP. Z O.O.
Country
Poland

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗
↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗
↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

RTK Multifunctional Handbook Software Instruction Manuals September 2023 Introduction Introduction of the Manual This manual provides a detailed description of how to use the handbook software and guides the user on how to use the software to configure the receiver, survey mapping, road surveying, power surveying, and other tasks. Experience Requirements In order for you to use the GoodSurvey software, it is recommended that you have some knowledge of surveying and that you read this manual carefully. If you have any questions about using the software, please contact us. Exemption from Liability Please be sure to read the instruction manual carefully in order to use the product properly. GoodSurvey is not responsible for any damages caused by your failure to follow the instruction manual or your failure to properly understand the requirements of the instruction manual resulting in the mishandling of the product. However, we are committed to continuously improving the function and performance of the product, improving the quality of service, and reserve the right to change, optimize and improve the content of the instruction manual, and inform the updated content in the form of upgrading the release, please pay attention to the GoodSurvey official website (http://www.goodsurvey.cn/) the latest stakeout of the information, the instruction manual is subject to change Please note that this manual is subject to change without prior notice; Although we have double-checked the consistency of the contents of the printed materials and the hardware and software, however, we do not exclude the possibility that there is still a deviation, the pictures in the instruction manual are for reference only, if there is any inconsistency with the product in kind, please take the product in kind as the standard, and the final right of interpretation belongs to Guangxi GoodSurvey Navigation Terminal Co. Related Information You can find the instruction manual by: Through the GoodSurvey website, you can find the download at [Download Center] - [Instruction Manual]. Your Suggestions If you have any comments or suggestions about this manual or the software, please contact us, we will be very grateful for your contribution to the improvement of GoodSurvey product quality, and at the same time, our company will return your efforts accordingly. Technologies and Services Thank you for purchasing and using GoodSurvey products, if you still have any questions after studying the manual, you can contact us by phone or e-mail, and we will be sure to answer your questions at the earliest time and can carry out related useful discussions. Our contact information is listed below: Organization: Guangxi GoodSurvey Navigation Terminal Co. Address: C-210, Guilin National Hi-Tech Zone Innovation Building, Information Industry Park, Hi-Tech Zone, Qixing District, Guilin, China Tel: 0773-5871020 Fax: 0773-5871020 Zip code: 541004 Website: http://www.goodsurvey.cn/ E-mail: [email protected] (technical support) table of contents Chapter I. Introduction to Software .............................................................................................................................. 1 1.1 Software Introduction ..................................................................................................................................... 1 1.2 Software Features ........................................................................................................................................... 4 Chapter II. Projects ....................................................................................................................................................... 5 2.1 Project Management ....................................................................................................................................... 5 2.1.1 New Construction Projects .................................................................................................................. 6 2.1.2 Delete Projects ..................................................................................................................................... 7 2.1.3 Open Projects ....................................................................................................................................... 7 2.1.4 Projects Information ............................................................................................................................ 7 2.2 Coordinate System .......................................................................................................................................... 8 2.2.1 Ellipsoid ............................................................................................................................................... 8 2.2.2 Projector ............................................................................................................................................... 9 2.2.3 Base Conversion ................................................................................................................................ 10 2.2.4 Plane Conversion ............................................................................................................................... 11 2.2.5 Elevation Fitting ................................................................................................................................ 12 2.2.6 Point Correction ................................................................................................................................. 12 2.2.7 QR Code ............................................................................................................................................ 13 2.3 Parameter Calculation ................................................................................................................................... 14 2.3.1 Calculation of Coordinate Transformation Parameters .................................…

Text truncated - open the document above for the full version.

Attestation Statements

APOGEO Sp. z o. (August 23, 2024) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 ATTN.: Reviewing Engineer FCC ID: 2BKAL-IMUBOX APOGEO SP. Z O.O. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. APOGEO SP. Z O.O. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signature: Name WITOLD SILARSKI Position CEO Company Name APOGEO SP. Z O.O. Address LUKASIEWICZA 10, 31429 KRAKOW, MALOPOLSKA, POLAND Tel +48123977676 Fax [email protected] Email [email protected]

Attestation Statements

APOGEO SP. Z O.O. LUKASIEWICZA 10, 31429 KRAKOW, MALOPOLSKA, POLAND Date: August 20, 2024 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BKAL-IMUBOX FRN: 0035810258 US Agent – Attestation Statement / Part 2.911(d)(7) APOGEO SP. Z O.O. certifies, that as of August 16, 2024, we have designated FCC US Agent, LLC to accept service of process on our behalf for FCC ID: 2BKAL-IMUBOX. APOGEO SP. Z O.O., accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission- related administrative or judicial proceeding involving the equipment, whichever is later. FCC US Agent, LLC, accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of APOGEO SP. Z O.O. for FCC ID: 2BKAL-IMUBOX. Designated Agent Information: Company Name: FCC US Agent, LLC FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Phone: 708-571-3148 Email: [email protected] Sincerely, Company: APOGEO SP. Z O.O. Designated Agent: FCC US Agent, LLC Company Representative: WITOLD SILARSKI Designated Agent Representative: Tim Payne Signature: Signature:

Cover Letter(s)

APOGEO SP. Z O.O. (August 15, 2024) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (gnss receiver / IMUBox 300. # 2BKAL- IMUBOX #) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (Schematics, Block diagram, Operation description) required to be submitted with this application be permanently withheld from public review. These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Please contact me if there is any information you may need. Sincerely, Signature: Name WITOLD SILARSKI Position CEO Company Name APOGEO SP. Z O.O. Address LUKASIEWICZA 10, 31429 KRAKOW, MALOPOLSKA, POLAND Tel +48123977676 Fax [email protected] Email [email protected]

Cover Letter(s)

APOGEO SP. Z O.O. (August 15, 2024) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Shenzhen Alpha Product Testing Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature: Name WITOLD SILARSKI Position CEO Company Name APOGEO SP. Z O.O. Address LUKASIEWICZA 10, 31429 KRAKOW, MALOPOLSKA, POLAND Tel +48123977676 Fax [email protected] Email [email protected]

External Photos

FCC ID: 2BKAL-IMUBOX FCC ID: 2BKAL-IMUBOX FCC ID: 2BKAL-IMUBOX FCC ID: 2BKAL-IMUBOX

ID Label/Location Info

4.5cm 2.5cm Label Location FCC ID: 2BKA-IMUBOX APOGEO Sp. z o. Product name: gnss receiver Model No.: IMUBox 300. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

ID Label/Location Info

4.5cm 2.5cm Label Location FCC ID: 2BKAL-IMUBOX APOGEO SP. Z O.O. Product name: gnss receiver Model No.: IMUBox 300. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Internal Photos

FCC ID: 2BKAL-IMUBOX GPS ANT FCC ID: 2BKAL-IMUBOX FCC ID: 2BKAL-IMUBOX FCC ID: 2BKAL-IMUBOX BT ANT FCC ID: 2BKAL-IMUBOX

RF Exposure Info

FCC ID: 2BKAL-IMUBOX RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v06 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Worse case is as below: [2402MHz: 1.698dBm(1.478 mW) output power] (1.478mW /5mm) ·[√2.441 (GHz)]= 0.462 <3.0 for 1-g SAR Then SAR evaluation is not required

Test Report

ALPHA's reports is using a digital certificate that is trusted on Adobe's official server. If there is no digital certificate or the digital certificate shows damaged in your report. Please do not accept the report. E-mail: [email protected] Tel: 4008300895 Website: http://www.a-lab.cn/certificate FCC TEST REPORT FCC ID: 2BKAL-IMUBOX On Behalf of APOGEO SP. Z O.O. gnss receiver Model No.: IMUBox 300. Prepared for : APOGEO SP. Z O.O. Address : LUKASIEWICZA 10, 31429 KRAKOW, MALOPOLSKA, POLAND Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao’an District, 518103, Shenzhen, Guangdong, China Report Number : A2406137-C01-R07 Date of Receipt : June 19, 2024 Date of Test : June 19, 2024 - July 12, 2024 Date of Report : July 12, 2024 Version Number : V0 Test Result : Pass Page 2 of 75 Report No.: A2406137-C01-R07 TABLE OF CONTENTS Description Page 1. Summary of Standards And Results ............................................................................................ 6 1.1. Description of Standards and Results ..................................................................................... 6 2. General Information ........................................................................................................................ 7 2.1. Description of Device (EUT) .................................................................................................... 7 2.2. Accessories of Device (EUT) .................................................................................................. 8 2.3. Tested Supporting System Details .......................................................................................... 8 2.4. Block Diagram of connection between EUT and simulators ................................................... 8 2.5. Test Mode Description ............................................................................................................. 8 2.6. Test Conditions ...................................................................................................................... 10 2.7. Test Facility ............................................................................................................................ 10 2.8. Measurement Uncertainty ..................................................................................................... 10 2.9. Test Equipment List ............................................................................................................... 11 3. Maximum Peak Output power...................................................................................................... 13 3.1. Limit ....................................................................................................................................... 13 3.2. Test Procedure ...................................................................................................................... 13 3.3. Test Setup .............................................................................................................................. 13 3.4. Test Result ............................................................................................................................. 13 4. Bandwidth ...................................................................................................................................... 14 4.1. Limit ....................................................................................................................................... 14 4.2. Test Procedure ...................................................................................................................... 14 4.3. Test Result ............................................................................................................................. 14 5. Carrier Frequency Separation ..................................................................................................... 25 5.1. Limit ....................................................................................................................................... 25 5.2. Test Procedure ...................................................................................................................... 25 5.3. Test Result ............................................................................................................................. 25 6. Number Of Hopping Channel ....................................................................................................... 27 6.1. Limit ....................................................................................................................................... 27 6.2. Test Procedure ...................................................................................................................... 27 6.3. Test Result ............................................................................................................................. 27 7. Dwell Time ..................................................................................................................................... 29 7.1. Test limit ................................................................................................................................. 29 7.2. Test Procedure ...................................................................................................................... 29 7.3. Test Result ............................................................................................................................. 29 8. Radiated emissions ...................................................................................................................... 39 8.1. Limit ....................................................................................................................................... 39 8.2. Block Diagram of Test setup .........................................................................................…

Text truncated - open the document above for the full version.

Test Report

Page 1 Version: 1.0 Issue Date: 2022-08-16 东莞市辉益电子有限公司 DongGuan HuiYi Electronics Co., LTD 客户/Customer: 客户料号/Customer P/N: 规 格 书 Specification 编制/ Signed by: 广东省东莞市长安镇新岗路23号编制日期/ Date: No. 23, XinGang Road, Chang An, Dongguan City, Guangdong Province Page 2 Version: 1.0 Issue Date: 2022-08-16 东莞市辉益电子有限公司 DongGuan HuiYi Electronics Co., LTD Index: 1. Specification / Page 3 2. Characteristics and Reliability Test / Page 4 3. Antenna - S Parameter Test Data / Page 5 4. Antenna - Radiation Pattern Test Data / Page 6 5. Antenna Test method / Page 7 Page 3 Version: 1.0 Issue Date: 2022-08-16 东莞市辉益电子有限公司 DongGuan HuiYi Electronics Co., LTD 1.Specification Sample Photo A. Electrical Characteristics Frequency 2400 ~ 2500 MHz S.W.R. <= 2.0 Efficiency > 50% Polarization Linear Impedance 50 Ohm Antenna Type PIFA B. Material & Mechanical Characteristics Material of Radiator PCB Cable Type O.D. 1.13 mm (Black) 95mm Connector Type Mini1 Connector for O.D. 1.13 mm Coaxial Cable Pull Test >= 1.0 Kg C. Environmental Operation Temperature -40 ̊C ~ + 65 ̊C Storage Temperature -40 ̊C ~ + 80 ̊C Model Number:NB1807-113G-095BX Product NameBT Antenna Gain2.7dBi(Max) Page 4 Version: 1.0 Issue Date: 2022-08-16 东莞市辉益电子有限公司 DongGuan HuiYi Electronics Co., LTD 2.Characteristics and Reliability Test Test Items Test Condition and Procedure Requirements C1 S.W.R. Set DUT on Network Analyzer; make individual calibration to test Directive DUT specification C2 Antenna Gain Set DUT on Antenna Chamber; make individual calibration to test Directive DUT specification M1 Vibration MIL-STD-202G, 201A Amplitude: 0.03 inch (0.76mm); Freq: 10 to 55 Hz 3 directions; 2 hours for each direction 1. No Visual Damage 2. Frequency Tol.<= 5% M2 Random Drop Height: 1.5 Meter; 3 directions; 1 time for each direction 1. No parts separated 2. Frequency Tol.<= 5% M3 Solderability MIL-STD-202G, 210F, cond. A Solder iron: 350±10°C; Duration: 5 seconds 1. Mounted on PCB 2. No Visual Damage M4 Terminal- Pull Test MIL-STD-202G, 211A, cond. A Holding with individual specification; force applied to axis of terminal 1. Directive DUT specification 2. Frequency Tol.<= 5% M5 Dimension Inspection of dimension, color, material, package, surface process Directive DUT specification E1 Salt Spray MIL-STD-202G, 101E, cond. B Temp: 35°C; RH: >= 95%; NaCl solution: >= 5%; Time: 48 hours After 2 Hours Recovery 1. No Visual Damage 2. Frequency Tol.<= 5% E2 Humidity MIL-STD-202G, 103B, cond. B Temp: 40°C; RH: >= 95%; Time: 48 hours After 2 Hours Recovery 1. No Visual Damage 2. Frequency Tol.<= 5% E3 Thermal Shock 1 Cycle: - 40°C (30 minutes) to + 80°C (30 minutes) Cycles: 24 After 2 Hours Recovery 1. No Visual Damage 2. Frequency Tol.<= 5% E4 Life (High Temp.) MIL-STD-202G, 108A, cond. A Temp: 85°C; Time: 96 hours After 2 Hours Recovery 1. No Visual Damage 2. Frequency Tol.<= 5% Page 5 Version: 1.0 Issue Date: 2022-08-16 东莞市辉益电子有限公司 DongGuan HuiYi Electronics Co., LTD 3.Antenna - S Parameter Test Data Remark: Test data is based on casing matching test, it’s different from the single product test data. Page 6 Version: 1.0 Issue Date: 2022-08-16 东莞市辉益电子有限公司 DongGuan HuiYi Electronics Co., LTD 4.Antenna - Radiation Pattern Test Data See attached files Testing Equipment Specification: Antenna Anechoic Chamber Dimension: 8 x 4 x 4 m Quite Zone: 600mm @1 GHz Isolation: >100dB @ 1 MHz ~ 10 GHz Testing Equipment: Agilent 5071B Received Antenna: 0.7 ~ 6.0 GHz for Gain Calibration Double Ridged Horn Antenna Page 7 Version: 1.0 Issue Date: 2022-08-16 东莞市辉益电子有限公司 DongGuan HuiYi Electronics Co., LTD 5.Antenna Test method Technical parameters reference range: Page 8 Version: 1.0 Issue Date: 2022-08-16 东莞市辉益电子有限公司 DongGuan HuiYi Electronics Co., LTD Frequency 驻波比(V.S.W.R)范围 2.4GHz <2.0 2.45GHz <2.0 2.5GHz <2.5

Test Setup Photos

FCC ID: 2BKAL-IMUBOX 1.1. Photo of Radiated Emission test FCC ID: 2BKAL-IMUBOX 1.2. Photo of Conducted Emission test

Contact Information

Applicant

WITOLD SILARSKI(CEO)
[email protected]+48123977676Fax: +48123977676

Test Firm

Shenzhen Alpha Product Testing Co., LTD.Real Yak
[email protected]+86 755 29766001

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.40 GHz - 2.48 GHz1.48 mW
Confidentiality
Long Term
Grant Notes
Output power listed is conducted.
