2BKAQ-NH8801car stereo system

Warm prompt For your safety, please do not watch videos or operate machines while driving; When driving, please adjust the volume to the level that you can hear the outside sound clearly. Before starting the operation, please read this manual and other manuals of the operating system in detail, understand this manual and relevant safety tips and warning slogans on the machine, and put them in the accessible place for reference at any time after reading. 1. Pay attention to traffic safety first. 2. If you encounter difficulties in operating the system, please park your car in a safe place before operating. 3. Do not allow children to operate the machine, so as to avoid personal injury and machine damage. 4. Please follow the traffic rules when using the satellite navigation function. 5. Please do not use electronic equipment or open fire prohibited places, such as gas stations, wineries, electromagnetic strong interference areas, otherwise it may cause danger. 6. Do not maintain, maintain or install the machine by yourself. Do not install or repair the machine with power on. It is very dangerous to install or repair the machine by persons who are not trained or inexperienced in the installation of electronic equipment or vehicle accessories 7. Do not install the machine or stored in direct sunlight place, don't put it in other hazardous substances in the environment, especially the LCD screen, if the installation of the LCD screen is in the air conditioning ventilation near, please keep cool and hot air blows directly to the machine, otherwise it may damage the machine, and even harm the car and personal. 8. Do not scratch the display screen with sharp objects, and do not press the display screen vigorously with hard objects, otherwise it will cause damage to the display screen or touch screen. 9. In order to ensure the normal operation of the machine and prevent the occurrence of fire or electric shock, please do not expose the machine to the damp air, let alone sprinkle the liquid on the machine. Tips and Warnings To highlight some important information in the user manual, You should pay special attention when you see this tag , which represents some important warnings and prompts. Note: Due to continuous improvement of product functions, this manual is for reference only. Matters needing attention Safety note Please read all instructions carefully before installation, and it is recommended that the machine be installed by a car audio professional. This machine is suitable for car 12V power system (must have a grounding wire), please do not install this equipment on the 24V car, otherwise it will damage the machine. Do not replace the power fuse without professional guidance. Improper use of the fuse will cause damage to the machine or cause fire. In order to avoid violating traffic rules, drivers are not allowed to watch the program and operate the unit while driving, so as to avoid unnecessary traffic accidents。 For the sake of safety and ensure the normal use of the product, please hand over to the professional installation of the product, do not disassemble and repair the machine, so as not to cause damage to the machine or accident, details, please consult with the local professional car audio sales shop. Please avoid placing the product in wet environment or water to avoid electric shock caused by short circuit or other unwanted damage or fire. Note: To prevent short circuit, please turn off the car and disconnect the connection between ACC and B+ before installation. The machine is reset 1.The machine must be reset before using the system for the first time or after replacing the car battery. 2.The unit must be reset when it does not function properly. 3.Click "Restore Factory Settings" in the setting interface to restore the machine to the original factory state. 4.Press the Reset button on the panel with a pointed object, or click System Reset in System Settings, and the machine will be shut down and returned to the original factory state. Note: Restoring factory Settings will lose the previous time and setting values. Functional operation 一．The main menu Each time the machine starts up, the original interface will be displayed. Long press the MENU key of the original car to switch to the added navigation interface. First display the main menu, touch to return to the main interface, touch to return to the menu of the next level, touch to close the screen, as shown below To slide touch, you can swipe your finger left or right to clear programs running in the background Drag from the top down, the page will appear a system notification bar, at the same time in the operation of the function is more convenient 二、the application interface The vehicle-mounted system supports, voice control, traffic recorder (optional), reversing image (optional), mobile phone interconnection, Bluetooth, online music, online navigation and other functions. Click "Application" on the main menu to enter the application interface. Click the ICONS of each module, you can enter the relevant functions. In any state, scroll down the page and press the main menu key or the return key to return to the main interface, as shown below: 三、System Settings Click "Settings" on the main menu interface to enter the system Settings interface, which includes WiFi, language, audio, system and system information functions. Click "Navigation Settings" on the screen to enter the secondary menu interface of navigation Settings, and so on, as shown in the following figure: 五、bluetooth Click "Bluetooth" in the main interface of the system to enter the Bluetooth application interface. When the Bluetooth is paired with the phone, all the ICONS in the interface will be lit up In the Bluetooth interface, click "Bluetooth Music" to enter the Bluetooth music playing interface. 六、The movie Click "Movie" on the main interface and enter the video playback interface. You can play the audio and video files in the system or the multimedia …

Text truncated - open the document above for the full version.

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: UGK-LVMUNITEDINC FRN: 0033476375 Contact Name: Jimmychen Address: 6547NAcademyBlvd#2266,ColoradoSprings,CO80918 Telephone No: 001-323-51 04660 Email: [email protected] Applicant: Company name: Navihua (shenzhen) Technology Co., Ltd. Grantee code: 2BKAQ FCC ID: 2BKAQ-NH8801 FRN: 0035810316 Contact Name: Jack bu Address: 6 Floor, Building 15, BaoKe industrial, Dalang LangKou District, LongHua District, Shenzhen, GuangDong Province. 518110 Telephone: 18906679427 Fax: 18906679427 E-mail: [email protected] [Navihua (shenzhen) Technology Co., Ltd.] certifies that, as of the date of this filing of the application with the TCB, [UGK-LVMUNITEDINC] is our designated US agent for service of process for the above referenced FCC ID. [Navihua (shenzhen) Technology Co., Ltd.] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [UGK-LVMUNITEDINC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2024/08/19 Applicant’s Name: Jack bu US Agent’s Name: Jimmychen Title: Manager Title: Manager Signature Signature

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Navihua (shenzhen) Technology Co., Ltd. Grantee code: 2BKAQ FCC ID: 2BKAQ-NH8801 FRN: 0035810316 Contact Name: Jack bu Address: 6 Floor, Building 15, BaoKe industrial, Dalang LangKou District, LongHua District, Shenzhen, GuangDong Province. 518110 Telephone: 18906679427 Fax: 18906679427 E-mail: [email protected] i. [Navihua (shenzhen) Technology Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Navihua (shenzhen) Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [Navihua (shenzhen) Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered List as an entity producing “covered”equipment . Date: 2024/08/19 Applicant’s Name: Jack bu Title: Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Navihua (shenzhen) Technology Co., Ltd. Product Similarity Declaration Company: Navihua (shenzhen) Technology Co., Ltd. Address: 6 Floor, Building 15, BaoKe industrial, Dalang LangKou District, LongHua District, Shenzhen, GuangDong Province. 518110 Product Name: car stereo system Model Number: NH8801, NH8802, NH8803, NHx, ("x"=0-9999, representing different combinations ofnumbers, representing different models, the difference is only the model name.) FCC Identifier: 2BKAQ-NH8801 We (Navihua (shenzhen) Technology Co., Ltd.) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), the only difference is the model name. Client’s signature Name: Jack bu Date: 2024-08-19 Title: Manager Signature of applicant:

Navihua (shenzhen) Technology Co., Ltd. Product function Declaration Company: Navihua (shenzhen) Technology Co., Ltd. Address: 6 Floor, Building 15, BaoKe industrial, Dalang LangKou District, LongHua District, Shenzhen, GuangDong Province. 518110 Product Name: car stereo system Model Number: NH8801, NH8802, NH8803, NHx, ("x"=0-9999, representing different combinations ofnumbers, representing different models, the difference is only the model name.) FCC Identifier: 2BKAQ-NH8801 We (Navihua (shenzhen) Technology Co., Ltd.) here by state that The product RF module has (LTE, 5GWiFi) function at the beginning of design. However, due to the iteration of the product, this function is no longer required at present, so through the (Software system control and shielding) method, the function is forced off, and the product RF module (SC665S-EM) no longer has the (LTE, 5GWiFi) function. Signature: Name: Jack bu Date: 2024-07-19 Title: Manager Signature of applicant:

Navihua (shenzhen) Technology Co., Ltd. 1/1 Letter of Authorization Company: Navihua (shenzhen) Technology Co., Ltd. Address: 6 Floor, Building 15, BaoKe industrial, Dalang LangKou District, LongHua District, Shenzhen, GuangDong Province. 518110 Product Name: car stereo system Model Number: NH8801, NH8802, NH8803, NHx, ("x"=0-9999, representing different combinations ofnumbers, representing different models, the difference is only the model name.) FCC Identifier: 2BKAQ-NH8801 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Jack bu Date: 2024-08-19 Title: Manager Signature of applicant:

Navihua (shenzhen) Technology Co., Ltd. 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2024-08-19 Subject: Request for Confidentiality FCC ID: 2BKAQ-NH8801 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Name: Jack bu Date: 2024-08-19 Title: Manager Signature of applicant:

Shenzhen DL Testing Technology Co., Ltd. EUT PHOTO(External Photos) GPS RXANT Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. ※※※※※ END OF REPORT ※※※※※

Size: 16*12mm M/N: NH8801 FCC ID: 2BKAQ-NH8801 Label location

Shenzhen DL Testing Technology Co., Ltd. EUT PHOTO(Internal Photos) Shenzhen DL Testing Technology Co., Ltd. ANT Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. ※※※※※ END OF REPORT ※※※※※

FCC ID: 2BKAQ-NH8801 RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in KDB 447498 D01 V06 and 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. EIRP=EMeas+20log(dMeas)-104.7 EIRP is the equivalent isotropically radiated power, in dBm EMeas is the field strength of the emission at the measurement distance, in dBμV/m dMeas is the measurement distance, in m Test Result of RF Exposure Evaluation wifi 2.4G mode Channel Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11b 7.024 5.0396 0.00100 1.0 PASS 802.11g 6.218 4.1860 0.00083 1.0 PASS 802.11n HT20 6.767 4.7501 0.00094 1.0 PASS 802.11n HT40 6.875 4.8697 0.00097 1.0 PASS Remark: antenna gain=0dBi For BT Field strength (dBuV/m) EIRP (dBm) Max tune-up (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 84.66 -10.5 0.0891 0.00002 1.0 PASS Remark: antenna gain=0dBi For Simultaneous transmitting, 1): The sum of the ratios of the spatially averaged results to the applicable frequency dependent MPE limits =0.00100/1 + 0.00002/1 = 0.00102< 1 Since the sum of the MPE ratios for all simultaneously transmitting antennas incorporated in the device is ≤ 1.0, the EUT is considered to satisfy MPE compliance for simultaneous transmission operations.

Product specification Quick Reference Date FPC 天线 Model GDT-SL--70 Frequency 2400~2500， Ant. Port Input Pwr. (dBm) 0 Tot. Rad. Pwr. (dBm) -2.3 (Input pwr – loss pwr) Peak EIRP(dBm) 1.3 Directivity (dBi) 1 (all direction antenna) Efficiency (dB) -2.3 (58.5%) Gain (dBi) 0 (Peak Gain XZ-plane) Maximum Power (dBm) 0 (XY-plane) Minimum Power (dBm) -4(XY-plane) Avg. Power (dBm) -0.5(XY-plane) Average Gain (dB) -0.5 (Avg Gain XY-plane) Manufacturer: Becool Technology (Shenzhen) Co., Ltd. Address 3F, Building E, Fenda High-tech Park, Sanwei Community, Hangcheng Baoan Dist., Shenzhen, Guangdong Province, China All the technical data and information contained herein are subject to change without prior notice Antenna layout on the Module board(mm) Antenna Gain Gain Table Unit in dBi @2400~2500MHz XY-plane XZ-plane YZ-plane Efficiency Peak Avg. Peak Avg. Peak Avg. Module board 0.0 -0.5 -0.3 -0.9 -1.3 -2.7 58.5% XY-plane Far-field Power Distribution(H+V) on X-Y Plane Plot Peak Gain(H+V)= 0 dBi; Plot AvgGain(H+V)=-0.50dBi @2400 MHz Far-field Power Distribution(H+V) on X-Y Plane Plot Peak Gain(H+V)= -0.70 dBi; Plot AvgGain(H+V)=-2.73dBi @2450 MHz XY-plane Far-field Power Distribution(H+V) on X-Y Plane Plot Peak Gain(H+V)= -1.15 dBi; Plot AvgGain(H+V)=-1.14dBi @2500 MHz XZ-plane Far-field Power Distribution(H+ V) on X-Z Plane Plot Peak Gain(H+V)=-0.30 dBi; Plot AvgGain(H+V)=-0.90dBi @2400 MHz) XZ-plane Far-field Power Distribution(H+ V) on X-Z Plane Plot Peak Gain(H+V)=-1.89 dBi; Plot AvgGain(H+V)=-2.54dBi @2450 MHz) XZ-plane Far-field Power Distribution(H+ V) on X-Z Plane Plot Peak Gain(H+V)=-1.67 dBi; Plot AvgGain(H+V)=-2.68dBi @2500 MHz) YZ-plane Far-field Power Distribution(H+ V) on X-Z Plane Plot Peak Gain(H+V)=-1.3 dBi; Plot AvgGain(H+V)=-2.70dBi @2400 MHz) YZ-plane Far-field Power Distribution(H+ V) on X-Z Plane Plot Peak Gain(H+V)=-1.76 dBi; Plot AvgGain(H+V)=-2.87dBi @2450 MHz) YZ-plane Far-field Power Distribution(H+ V) on X-Z Plane Plot Peak Gain(H+V)=-2.17 dBi; Plot AvgGain(H+V)=-3.32dBi @2500 MHz)

Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-240709029ER Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 43 FCC Part 15C Test Report FCC ID: 2BKAQ-NH8801 Applicant: Navihua (shenzhen) Technology Co., Ltd. Address: 6 Floor, Building 15, BaoKe industrial, Dalang LangKou District, LongHua District, Shenzhen, GuangDong Province. 518110 Manufacturer: Navihua (shenzhen) Technology Co., Ltd. Address: 6 Floor, Building 15, BaoKe industrial, Dalang LangKou District, LongHua District, Shenzhen, GuangDong Province. 518110 EUT: car stereo system Trade Mark: N/A Model Number: NH8801 NH8802, NH8803, NHx, ("x"=0-9999, representing different combinations ofnumbers, representing different models, the difference is only the model name.) Date of Receipt: Jul. 09, 2024 Test Date: Jul. 09, 2024 - Jul. 27, 2024 Date of Report: Jul. 27, 2024 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Applicable Standards: FCC PART 15 C 15.247 ANSI C63.10:2013 Test Result: Pass Report Number: DL-240709029ER Prepared (Test Engineer): Alisa Song Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-240709029ER Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 43 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 6 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 6 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 7 2.5 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 7 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 8 3 . EMC EMISSION TEST 9 3.1 CONDUCTED EMISSION MEASUREMENT 9 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 9 3.1.2 TEST PROCEDURE 9 3.1.3 DEVIATION FROM TEST STANDARD 9 3.1.4 TEST SETUP 10 3.1.5 EUT OPERATING CONDITIONS 10 3.1.6 TEST RESULTS 10 3.2 RADIATED EMISSION MEASUREMENT 11 3.2.1 RADIATED EMISSION LIMITS 11 3.2.2 TEST PROCEDURE 12 3.2.3 DEVIATION FROM TEST STANDARD 12 3.2.4 TEST SETUP 12 3.2.5 EUT OPERATING CONDITIONS 13 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 14 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 15 3.2.8 TEST RESULTS (1GHZ~25GHZ) 17 3.3 RADIATED BAND EMISSION MEASUREMENT 21 3.3.1 TEST REQUIREMENT: 21 3.3.2 TEST PROCEDURE 21 3.3.3 DEVIATION FROM TEST STANDARD 21 3.3.4 TEST SETUP 22 3.3.5 EUT OPERATING CONDITIONS 22 3.4 CONDUCTED BAND EDGE EMISSION&CONDUCTED SPURIOUS EMISSIONS MEASUREMENT 27 3.4.1 APPLICABLE STANDARD 27 3.4.2 TEST PROCEDURE 27 3.4.3 DEVIATION FROM STANDARD 27 3.4.4 TEST SETUP 27 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-240709029ER Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 43 Table of Contents Page 3.4.5 EUT OPERATION CONDITIONS 27 3.4.6 TEST RESULTS 27 4 . AVERAGE OUTPUT POWER 31 4.1 APPLIED PROCEDURES / LIMIT 31 4.1.1 TEST PROCEDURE 31 4.1.2 DEVIATION FROM STANDARD 31 4.1.3 TEST SETUP 31 4.1.4 EUT OPERATION CONDITIONS 31 4.1.5 TEST RESULTS 32 5 . POWER SPECTRAL DENSITY TEST 35 5.1 APPLIED PROCEDURES / LIMIT 35 5.1.1 TEST PROCEDURE 35 5.1.2 DEVIATION FROM STANDARD 35 5.1.3 TEST SETUP 35 5.1.4 EUT OPERATION CONDITIONS 35 5.1.5 TEST RESULTS 36 6 . 6DB BANDWIDTH TEST 39 6.1 APPLIED PROCEDURES / LIMIT 39 6.1.1 TEST PROCEDURE 39 6.1.2 DEVIATION FROM STANDARD 39 6.1.3 TEST SETUP 39 6.1.4 EUT OPERATION CONDITIONS 39 6.1.5 TEST RESULTS 40 7 . ANTENNA REQUIREMENT 43 7.1 STANDARD REQUIREMENT 43 7.2 EUT ANTENNA 43 8 . TEST SEUUP PHOTO 43 9 . EUT PHOTO 43 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-240709029ER Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 43 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A 15.205, 15.209, 15.247(d) Radiated Spurious Emission PASS 15.205, 15.247(d) Band Edge Emission& Conducted Spurious Emissions PASS 15.247(b) Average Output Power PASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(e) Power Spectral Density PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Test lab: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China FCC Test Firm Registration Number: 854456 Designation Number: CN1307 IC Registered No.: 27485 CAB ID.: CN0118 1.1 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±2.56dB 2 RF power,conducted ±0.42dB 3 Spurious emissions,conducted ±2.76dB 4 All emissions,radiated(<1G) ±3.65dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% 8 6dB Bandwidth ±0.2MHz Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-240709029ER Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 43 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product Name: car stereo system Trademark N/A Model No.: NH8801 NH8801 NH8802, NH8803, NHx, ("x"=0-9999, representing different combinations ofnumbers, representing different models, the difference is only the model name.) Model Difference The product's different for model number. Operation Frequency: 2412~2462 MHz for 802.11b/g/nHT20 2422~2452 MHz for 802.11nHT40 Channel numbers: 11 Channels for 802.1…

Text truncated - open the document above for the full version.

Shenzhen DL Testing Technology Co., Ltd. EUT TEST PHOTO Radiated Measurement Photos ※※※※※ END OF REPORT ※※※※※
