2BKCX-DEE31ACTIVO BR01

MITER Inc.
ACTIVO BR01 - FCC ID 2BKCX-DEE31 - MITER Inc.
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Jul 06, 2026
Application Purpose
Original Equipment
Equipment Note
ACTIVO BR01
Frequency Range
2402.00000000 - 2480.00000000
Company
MITER Inc.
Country
South Korea

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗
↗
↗

Cover Letter(s)

↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗
↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Cover Letter(s)

MITER Inc. No.1106, M-dong, 249, Sunhwagung-ro, Namyangju-si, Gyeonggi-do, Republic of Korea Letter of Authorization Company: MITER Inc. Address: No.1106, M-dong, 249, Sunhwagung-ro, Namyangju-si, Gyeonggi-do, Republic of Korea Product Name: ACTIVO BR01 Model Number(s): DEE31 Product Description: ACTIVO BR01 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Apr. 16, 2026 Name: YONGCHUL LEE Title: Manager Company: MITER Inc.

External Photos

ReportNo.:AGC00803260308AP02 Page 1 of 4 EXTERNALPHOTOS TopviewofEUT BottomviewofEUT ReportNo.:AGC00803260308AP02 Page 2 of 4 FrontviewofEUT BackviewofEUT ReportNo.:AGC00803260308AP02 Page 3 of 4 LeftviewofEUT RightviewofEUT ReportNo.:AGC00803260308AP02 Page 4 of 4 PortviewofEUT ****************************************EndofReport*************************************

ID Label/Location Info

FCC ID Label Location FCC ID: 2BKCX-DEE31 10mm*10mm

Internal Photos

ReportNo.:AGC00803260308AP02 Page 1 of 4 INTERNALPHOTOS OpenviewofEUT BatteryviewofEUT ReportNo.:AGC00803260308AP02 Page 2 of 4 Internalview-1ofEUT Internalview-2ofEUT BTAntenna ReportNo.:AGC00803260308AP02 Page 3 of 4 Internalview-3ofEUT Internalview-4ofEUT ReportNo.:AGC00803260308AP02 Page 4 of 4 Internalview-5ofEUT ****************************************EndofReport*************************************

RF Exposure Info

Page1of10 RFExposureReport ReportNo.:AGC00803260308FH01 FCCID:2BKCX-DEE31 APPLICATIONPURPOSE:OriginalEquipment PRODUCTDESIGNATION:ACTIVOBR01 BRANDNAME:ACTIVO MODELNAME:DEE31 APPLICANT:MITERInc. DATEOFISSUE:Apr.16,2026 STANDARD(S): FCCPart2SubpartJ§2.1093 FCCKDB447498D01V06 REPORTVERSION:V1.0 AttestationofGlobalCompliance(Shenzhen)Co.,Ltd ReportNo.:AGC00803260308FH01 Page 2 of 10 ReportReviseRecord ReportVersionReviseTimeIssuedDateValidVersionNotes V1.0/Apr.16,2026ValidInitialRelease ReportNo.:AGC00803260308FH01 Page 3 of 10 TableofContents 1.GeneralInformation..........................................................................................................................................4 2.ProductInformation..........................................................................................................................................5 2.1ProductTechnicalDescription....................................................................................................................5 3.TestEnvironment..............................................................................................................................................6 3.1AddressOfTheTestLaboratory.................................................................................................................6 3.2TestFacility..................................................................................................................................................6 3.3EnvironmentalConditions...........................................................................................................................7 4.PortableDeviceEvaluationMethodandLimit..............................................................................................8 5.MeasurementResults.......................................................................................................................................9 6.MeasurementEvaluation.................................................................................................................................9 ReportNo.:AGC00803260308FH01 Page 4 of 10 1.GeneralInformation Applicant MITERInc. Address No.1106,M-dong,249,Sunhwagung-ro,Namyangju-si,Gyeonggi-do,Republicof Korea Manufacturer MITERInc. Address No.1106,M-dong,249,Sunhwagung-ro,Namyangju-si,Gyeonggi-do,Republicof Korea Factory ShenzhenHangshiElectronicTechnologyCo.,Ltd. Address 2/F,G-A1BLDG,DemocracyWestlndustryPark,ShajingStreet,Bao'anDistrict, ShenzhenCity,GuangdongProvince,P.R.China ProductDesignation ACTIVOBR01 BrandName ACTIVO TestModel DEE31 SeriesModel(s) N/A DifferenceDescription N/A Dateofreceiptoftestitem Mar.30,2026 DateofTest Mar.30,2026-Apr.16,2026 DeviationfromStandard Noanydeviationfromthetestmethod ConditionofTestSample Normal TestResult Pass TestReportFormNo AGCER-FCC-RFExposure-V1 Note:Thetestresultsofthisreportrelateonlytothetestedsampleidentifiedinthisreport. PreparedBy JackGui (ProjectEngineer) Apr.16,2026 ReviewedBy BiboZhang (Reviewer) Apr.16,2026 ApprovedBy AngelaLi (AuthorizedOfficer) Apr.16,2026 ReportNo.:AGC00803260308FH01 Page 5 of 10 2.ProductInformation 2.1ProductTechnicalDescription FrequencyBand(Operating)Bluetooth:2.402GHz~2.480GHz HardwareVersionV1.0 SoftwareVersionV1.0 ModulationTypeBluetooth:BLEGFSK1MbpsGFSK2Mbps MaximumTransmitterPower BLE_1Mbps:-1.666dBm BLE_2Mbps:-2.330dBm DeviceCategory Portable(<20cmseparation) Mobile(>20cmseparation) Others: AntennaDiversity Singleantenna Multipleantennas Txdiversity Rxdiversity Tx/Rxdiversity AntennaDesignationPCBAntenna AntennaGain1.87dBi MinimumAssessmentDistance5mm EvaluationApplied MPEEvaluation SAREvaluation ReportNo.:AGC00803260308FH01 Page 6 of 10 3.TestEnvironment 3.1AddressOfTheTestLaboratory Laboratory:AttestationofGlobalCompliance(Shenzhen)Co.,Ltd. Address:101&201,Building19(B5),JunfengIndustrialPark,ChongqingRoad,P.R.C. 3.2TestFacility Thetestfacilityisrecognized,certified,oraccreditedbythefollowingorganizations: CNAS-LabCode:L5488 AttestationofGlobalCompliance(Shenzhen)Co.,Ltd.hasbeenassessedandprovedtofollowCNAS-CL01 AccreditationCriteriaforTestingandCalibrationLaboratories(identicaltoISO/IEC17025:2017General RequirementsfortheCompetenceofTestingandCalibrationLaboratories.) A2LA-LabCert.No.:5054.02 AttestationofGlobalCompliance(Shenzhen)Co.,Ltd.EMCLaboratoryhasbeenaccreditedbyA2LAfor technicalcompetenceinthefieldofelectricaltesting,andprovedtofollowISO/IEC17025:2017General RequirementsfortheCompetenceofTestingandCalibrationLaboratoriesandanyadditionalprogram requirementsintheidentifiedfieldoftesting. FCC-RegistrationNo.:975832 AttestationofGlobalCompliance(Shenzhen)Co.,Ltd.EMCLaboratoryhasbeenregisteredandfully describedinareportfiledwiththeFCC(FederalCommunicationsCommission).Theacceptanceletterfromthe FCCismaintainedinourfileswithRegistration975832. IC-RegistrationNo.:24842(CABidentifier:CN0063) AttestationofGlobalCompliance(Shenzhen)Co.,Ltd.EMCLaboratoryhasbeenregisteredandfully describedinareportfiledwiththeCertificationandEngineeringBureauofIndustryCanada.Theacceptance letterfromtheICismaintainedinourfileswithRegistration24842. ReportNo.:AGC00803260308FH01 Page 7 of 10 3.3EnvironmentalConditions NORMALCONDITIONS Temperaturerange(°C) 15-35 Relativehumidityrange 20%-75% Pressurerange(kPa) 86-106 PowersupplyDC3.7VbybatteryorDC5Vbyadapter Note:TheExtremeTemperatureandExtremeVoltagesdeclaredbythemanufacturer. ReportNo.:AGC00803260308FH01 Page 8 of 10 4.PortableDeviceEvaluationMethodandLimit FollowingFCCKDB447498D01“GeneralSARtestexclusionguidance”ThecorrespondingSARExclusion Thresholdcondition,listedbelow:  The1-gand10-gSARtestexclusionthresholdsfor100MHzto6GHzattestseparationdistances≤50 mmaredeterminedby: [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparationdistance,mm)][√ f(GHz)]≤3.0for1-gSAR,and≤7.5for10-gextremitySAR,where  f(GHz)istheRFchanneltransmitfrequencyinGHz. PoweranddistanceareroundedtothenearestmWandmmbeforecalculation. TheresultisroundedtoonedecimalplaceforcomparisonThe…

Text truncated - open the document above for the full version.

Test Report

UCICENTERFORRFDESIGNANDCHARACTERIZATION Report UCICENTERFORRFDESIGNANDCHARACTERIZATION UCICENTERFORRFDESIGNANDCHARACTERIZATION estedProducts. •Antenna1:integratedantenna. •Frequency=2.402GHz. •Frequency=2.441GHz. •Frequency=2.480GHz. UCICENTERFORRFDESIGNANDCHARACTERIZATION CoordinateSystemReference:Antenna1. TopviewSideview Frontview Z Frontview Y X Rearview SMA connector Y ZX UCICENTERFORRFDESIGNANDCHARACTERIZATION 135 225315 0 135 -5 -10 -15 -20 -25 -30 -35-30-25-20-15-10-5 45 0 225315 Radiationpattern:Antenna1.XZPlaneatf=2.402GHz 90 90 18001800 270 Co-crosspolarizationfield(dBi) Solidline:verticalpolarization Dashline:horizontalpolarization 270 Totalfield(dBi) 0 45 -5 -10 -15 -10-5 0 UCICENTERFORRFDESIGNANDCHARACTERIZATION 225 315 135 0 45 -5 -10 -15-10 -5 0 225315 Radiationpattern:Antenna1.YZPlaneatf=2.402GHz 90 180 270 Co-crosspolarizationfield(dBi) Solidline:verticalpolarization Dashline:horizontalpolarization 01800 270 Totalfield(dBi) 90 0 135 -5 45 -10 -15 -20 -25 -30 -35-30-25-20-15-10-50 UCICENTERFORRFDESIGNANDCHARACTERIZATION 135 0 45 -5 -10 -15-10-50 225315 135 225315 Radiationpattern:Antenna1.XYPlaneatf=2.402GHz 90 90 1800 270 Co-crosspolarizationfield(dBi) Solidline:verticalpolarization Dashline:horizontalpolarization 1800 270 Totalfield(dBi) 0 -5 45 -10 -15 -20 -25 -30 -35-30-25-20-15-10-50 UCICENTERFORRFDESIGNANDCHARACTERIZATION 0 135 -5 -10 -15 -20 -25 -30 -35-30-25-20-15-10-5 45 0 225315 135 0 45 -5 -10 -15-10 -5 0 225315 Radiationpattern:Antenna1.XZPlaneatf=2.441GHz 90 90 1800 1800 270 Co-crosspolarizationfield(dBi) Solidline:verticalpolarization Dashline:horizontalpolarization 270 Totalfield(dBi) UCICENTERFORRFDESIGNANDCHARACTERIZATION 135 225315 135 0 45 -5 -10 -15-10-50 225315 Radiationpattern:Antenna1.YZPlaneatf=2.441GHz 90 90 0 -5 45 -10 -15 -20 -25 -30 -35-30-25-20-15-10-50 18001800 270 Co-crosspolarizationfield(dBi) Solidline:verticalpolarization Dashline:horizontalpolarization 270 Totalfield(dBi) UCICENTERFORRFDESIGNANDCHARACTERIZATION 0 135 -5 -10 -15 -20 -25 -30 -35-30-25-20-15-10-5 45 0 225315 135 0 45 -5 -10 -15-10 -5 0 225315 Radiationpattern:Antenna1.XYPlaneatf=2.441GHz 90 90 1800 1800 270 Co-crosspolarizationfield(dBi) Solidline:verticalpolarization Dashline:horizontalpolarization 270 Totalfield(dBi) UCICENTERFORRFDESIGNANDCHARACTERIZATION 135 225315 0 135 -5 -10 -15 -20 -25 -30 -35-30-25-20-15-10-5 45 0 225315 Radiationpattern:Antenna1.XZPlaneatf=2.480GHz 90 90 1800 1800 270 Co-crosspolarizationfield(dBi) Solidline:verticalpolarization Dashline:horizontalpolarization 270 Totalfield(dBi) 0 45 -5 -10 -15-10-50 UCICENTERFORRFDESIGNANDCHARACTERIZATION 0 135 -5 -10 -15 -20 -25 -30 -35-30-25-20-15-10-5 45 0 225315 135 0 45 -5 -10 -15-10 -5 0 225315 Radiationpattern:Antenna1.YZPlaneatf=2.480GHz 90 90 1800 1800 270 Co-crosspolarizationfield(dBi) Solidline:verticalpolarization Dashline:horizontalpolarization 270 Totalfield(dBi) UCICENTERFORRFDESIGNANDCHARACTERIZATION 0 135 -5 -10 -15 -20 -25 -30 -35-30-25-20-15-10-5 45 0 225315 135 0 45 -5 -10 -15-10-50 225315 Radiationpattern:Antenna1.XYPlaneatf=2.480GHz 90 90 1800 1800 270 Co-crosspolarizationfield(dBi) Solidline:verticalpolarization Dashline:horizontalpolarization 270 Totalfield(dBi) UCICENTERFORRFDESIGNANDCHARACTERIZATION ReturnLoss:Antenna1 -2 -4 -6 -8 -10 -12 -14 -16 22.22.42.62.83 Frequency(GHz) BW(-10dB)  13.48% R e t u r n L o s s ( d B ) UCICENTERFORRFDESIGNANDCHARACTERIZATION Measurementssummary Frequency(GHz)PlaneReturnLoss(dB)PolarizationGainmax.(dBi)θforGainmax.φforGainmax. Antenna1 2.402XZ-10.90Vertical-7.8290 2.402XZ-10.90Horizontal0.786182 2.402YZ-10.90Vertical1.21226 2.402YZ-10.90Horizontal-7.7510 2.402XY-10.90Vertical-15.420 2.402XY-10.90Horizontal0.93180 2.441XZ-12.20Vertical-7.36318 2.441XZ-12.20Horizontal1.32180 2.441YZ-12.20Vertical0.981204 2.441YZ-12.20Horizontal-8.2324 2.441XY-12.20Vertical-14.1-14 2.441XY-12.20Horizontal1.74180 2.48XZ-13.80Vertical-7.95312 2.48XZ-13.80Horizontal1.81186 2.48YZ-13.80Vertical0.204214 2.48YZ-13.80Horizontal-8.388 2.48XY-13.80Vertical-15.812 2.48XY-13.80Horizontal1.87180

Test Report

Page 1 of 65 FCCTestReport ReportNo.:AGC00803260308FR01 FCCID: 2BKCX-DEE31 APPLICATIONPURPOSE: OriginalEquipment PRODUCTDESIGNATION:ACTIVOBR01 BRANDNAME:ACTIVO MODELNAME:DEE31 APPLICANT:MITERInc. DATEOFISSUE:Apr.16,2026 STANDARD(S):FCCPart15SubpartC§15.247 REPORTVERSION:V1.0 AttestationOfGlobalCompliance(Shenzhen)Co.,Ltd ReportNo.:AGC00803260308FR01 Page2of65 ReportReviseRecord ReportVersionReviseTimeIssuedDateValidVersionNotes V1.0/Apr.16,2026ValidInitialRelease ReportNo.:AGC00803260308FR01 Page3of65 TableofContents 1.GeneralInformation..........................................................................................................................................5 2.ProductInformation..........................................................................................................................................6 2.1ProductTechnicalDescription....................................................................................................................6 2.2TestFrequencyList.....................................................................................................................................6 2.3RelatedSubmittal(S)/Grant(S).................................................................................................................7 2.4TestMethodology........................................................................................................................................7 2.5SpecialAccessories....................................................................................................................................7 2.6EquipmentModifications.............................................................................................................................7 2.7AntennaRequirement.................................................................................................................................7 3.TestEnvironment..............................................................................................................................................8 3.1AddressoftheTestLaboratory...................................................................................................................8 3.2TestFacility..................................................................................................................................................8 3.3EnvironmentalConditions...........................................................................................................................9 3.4MeasurementUncertainty...........................................................................................................................9 3.5ListofEquipmentUse...............................................................................................................................10 4.SystemTestConfiguration.............................................................................................................................12 4.1EUTConfiguration....................................................................................................................................12 4.2EUTExercise............................................................................................................................................12 4.3ConfigurationofTestedSystem................................................................................................................12 4.4EquipmentUsedInTestedSystem..........................................................................................................13 4.5SummaryofTestResults..........................................................................................................................14 5.DescriptionofTestModes.............................................................................................................................15 6.DutyCycleMeasurement...............................................................................................................................16 7.RFOutputPowerMeasurement....................................................................................................................17 7.1ProvisionsApplicable................................................................................................................................17 7.2MeasurementProcedure..........................................................................................................................17 7.3MeasurementSetup(BlockDiagramofConfiguration)...........................................................................17 7.4MeasurementResult.................................................................................................................................18 8.6dBBandwidthMeasurement.......................................................................................................................22 8.1ProvisionsApplicable................................................................................................................................22 8.2MeasurementProcedure..........................................................................................................................22 8.3MeasurementSetup(BlockDiagramofConfiguration)...........................................................................22 8.4MeasurementResults...............................................................................................................................23 9.PowerSpectralDensityMeasurement.........................................................................................................30 9.1ProvisionsApplicable................................................................................................................................30 9.2MeasurementProcedure..........................................................................................................................30 9.3MeasurementSetup(BlockDiagramofConfiguration).............................…

Text truncated - open the document above for the full version.

Test Report

ReportNo.:AGC00803260308FR01 Page40of65 Test_Graph_LE1M_ANT1_2480_1Mbps_HigherBandEmissions Test_Graph_LE2M_ANT1_2402_2Mbps_ReferenceLevel ReportNo.:AGC00803260308FR01 Page41of65 Test_Graph_LE2M_ANT1_2402_2Mbps_LowerBandEmissions Test_Graph_LE2M_ANT1_2402_2Mbps_HigherBandEmissions ReportNo.:AGC00803260308FR01 Page42of65 Test_Graph_LE2M_ANT1_2440_2Mbps_ReferenceLevel Test_Graph_LE2M_ANT1_2440_2Mbps_LowerBandEmissions ReportNo.:AGC00803260308FR01 Page43of65 Test_Graph_LE2M_ANT1_2440_2Mbps_HigherBandEmissions Test_Graph_LE2M_ANT1_2480_2Mbps_ReferenceLevel ReportNo.:AGC00803260308FR01 Page44of65 Test_Graph_LE2M_ANT1_2480_2Mbps_LowerBandEmissions Test_Graph_LE2M_ANT1_2480_2Mbps_HigherBandEmissions ReportNo.:AGC00803260308FR01 Page45of65 TestGraphsofBandEdgeEmissionsinNon-RestrictedFrequencyBands Test_Graph_LE1M_ANT1_2402_1Mbps_LowerBandEdgeEmissions Test_Graph_LE1M_ANT1_2480_1Mbps_HigherBandEdgeEmissions ReportNo.:AGC00803260308FR01 Page46of65 Test_Graph_LE2M_ANT1_2402_2Mbps_LowerBandEdgeEmissions Test_Graph_LE2M_ANT1_2480_2Mbps_HigherBandEdgeEmissions ReportNo.:AGC00803260308FR01 Page47of65 11.RadiatedSpuriousEmission 11.1MeasurementLimit  FCCPart15.209Limitinthebelowtabletobefollowed Frequencies (MHz) FieldStrength (microvolts/meter) MeasurementDistance (meters) 0.009~0.4902400/F(kHz)300 0.490~1.70524000/F(kHz)30 1.705~30.03030 30~881003 88~2161503 216~9602003 Above9605003 Note:Allmodesweretestedforrestrictedbandradiatedemission,thetestrecordsreportedbelowaretheworst resultcomparedtoothermodes. 11.2MeasurementProcedure 1.TheEUTwasplacedonthetopoftheturntable0.8or1.5meteraboveground.Thephasecenterofthe receivingantennamountedonthetopofaheight-variableantennatowerwasplaced3metersfaraway fromtheturntable. 2.PowerontheEUTandallthesupportingunits.Theturntablewasrotatedby360degreestodeterminethe positionofthehighestradiation. 3.Theheightofthebroadbandreceivingantennawasvariedbetweenonemeterandfourmetersabove groundtofindthemaximumemissionsfieldstrengthofbothhorizontalandverticalpolarization. 4.Foreachsuspectedemission,theantennatowerwasscan(from1Mto4M)andthentheturntablewas rotated(from0degreeto360degrees)tofindthemaximumreading. 5.Setthetest-receiversystemtoPeakorCISPRquasi-peakDetectFunctionwithspecifiedbandwidthunder MaximumHoldMode. 6.Foremissionsabove1GHz,use1MHzRBWand3MHzVBWforpeakreading.Placethemeasurement antennaawayfromeachareaoftheEUTdeterminedtobeasourceofemissionsatthespecified measurementdistance,whilekeepingthemeasurementantennaaimedatthesourceofemissionsateach frequencyofsignificantemissions,withpolarizationorientedformaximumresponse.Themeasurement antennamayhavetobehigherorlowerthantheEUT,dependingontheradiationpatternoftheemission andstayingaimedattheemissionsourceforreceivingthemaximumsignal.Thefinalmeasurement antennaelevationshallbethatwhichmaximizestheemissions.Themeasurementantennaelevationfor maximumemissionsshallberestrictedtoarangeofheightsoffrom1mto4mabovethegroundor referencegroundplane. 7.Whentheradiatedemissionslimitsareexpressedintermsoftheaveragevalueoftheemissions,and pulsedoperationisemployed,themeasurementfieldstrengthshallbedeterminedbyaveragingoverone completepulsetrain,includingblankingintervals,aslongasthepulsetraindoesnotexceed0.1seconds. ReportNo.:AGC00803260308FR01 Page48of65 8.Asanalternative(providedthetransmitteroperatesforlongerthan0.1seconds)orincaseswherethe pulsetrainexceeds0.1seconds,themeasuredfieldstrengthshallbedeterminedfromtheaverage absolutevoltageduringa0.1secondintervalduringwhichthefieldstrengthisatitsmaximumvalues. 9.IftheemissionsleveloftheEUTinpeakmodewas3dBlowerthantheaveragelimitspecified,then testingwillbestoppedandpeakvaluesofEUTwillbereported,otherwise,theemissionswhichdonot have3dBmarginwillberepeatedonebyoneusingthequasi-peakmethodforbelow1GHz. 10.Fortestingabove1GHz,theemissionsleveloftheEUTinpeakmodewaslowerthanaveragelimit(that meanstheemissionslevelinpeakmodealsocomplieswiththelimitinaveragemode),thentestingwillbe stoppedandpeakvaluesofEUTwillbereported,otherwise,theemissionswillbemeasuredinaverage modeagainandreported. 11.Incasetheemissionislowerthan30MHz,loopantennahastobeusedformeasurementandtherecorded datashouldbeQPmeasuredbyreceiver.High-Lowscanisnotrequiredinthiscase. Thefollowingtableisthesettingofspectrumanalyzerandreceiver. SpectrumParameterSetting Start~StopFrequency9kHz~150kHz/RB200HzforQP Start~StopFrequency150kHz~30MHz/RB9kHzforQP Start~StopFrequency30MHz~1000MHz/RB120kHzforQP Start~StopFrequency 1GHz~26.5GHz 1MHz/3MHzforPeak,1MHz/3MHzforAverage ReceiverParameterSetting Start~StopFrequency9kHz~150kHz/RB200HzforQP Start~StopFrequency150kHz~30MHz/RB9kHzforQP Start~StopFrequency30MHz~1000MHz/RB120kHzforQP ReportNo.:AGC00803260308FR01 Page49of65 Quasi-PeakMeasurementsbelow1GHz 1.Analyzercenterfrequencywassettothefrequencyoftheradiatedspuriousemissionofinterest 2.Spanwassetgreaterthan1MHz 3.RBW=asshowninthetableabove 4.Detector=CISPRquasi-peak 5.Sweeptime=autocouple 6.Tracewasallowedtostabilize PeakMeasurementsabove1GHz 1.Analyzercenterfrequencywassettothefrequencyoftheradiatedspuriousemissionofinterest 2.RBW=1MHz 3.VBW=3MHz 4.Detector=peak 5.Sweeptime=autocouple 6.Tracemode=maxhold 7.Tracewasallowedtostabilize AverageMeasurementsabove1GHz 1.Analyzercenterfrequencywassettothefrequencyoftheradiatedspuriousemissionofinterest 2.RBW=1MHz 3.VBW≥[3×RBW] 4.Detector=Poweraveraging(rms) 5.Averagingtype=power(i.e.,rms) 6.Sweeptime=auto 7.Performatraceaverageofatleast100traces. 8.Theapplicablecorrectionfactoris[10*log(1/D)],whereDisthedutycycle.Thefactorhadbeeneditedin the“InputCorrection”oftheSpectrumAnalyzer. ReportNo.:AGC00803260308FR01 Page50of65 11.3MeasurementSetup(BlockDiagramofConfiguration) RadiatedEmissionTestSetup9kHz-30MHz RadiatedEmissionTestSetup30MHz-1000MHz RadiatedEmissionTestSetupAbove1000MHz ReportNo.:AGC00803260308FR01 Page51of65 11.4MeasurementResult RadiatedEmissionBelow30MHz Theamplitudeofspuriousemissionsfrom9kHzto30MHzwhichareattenuatedmorethan20dBbelowthe permissiblevalueneednotbereported. Radiate…

Text truncated - open the document above for the full version.

Test Setup Photos

ReportNo.:AGC00803260308AP01 Page 1 of 2 TESTSETUPPHOTOS RADIATEDEMISSIONTESTSETUPBELOW1GHz RADIATEDEMISSIONTESTSETUPABOVE1GHz ReportNo.:AGC00803260308AP01 Page 2 of 2 ACPOWERLINECONDUCTEDTESTSETUP RFCONDUCTEDTESTSETUP-BLE ****************************************EndofReport*************************************

Contact Information

Applicant

YONGCHUL LEE
[email protected]Fax: N/A

Technical Contact

Wedo GroupJeffrey Chen
[email protected]

710 Arabian Ln · Walnut, California, 91789 · United States

Test Firm

Attestation of Global Compliance (Shenzhen) Co., LDoris Li
[email protected]

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.40 GHz - 2.48 GHz700.00 µW
Confidentiality
Long Term
Grant Notes
Output power listed is conducted power.
