2BKFN-P3PROIntelligent Factory Delivery Robot

IntelligentFactoryDeliveryRobot P3 Pro User Manual 2 / 22 Copyright(c) 2016-2023ShanghaiSlamtecCo.,Ltd. content 1. Background .....................................................................................................3 2. Mapping..........................................................................................................3 2.1 Environmentalpreparation.......................................................................3 2.2 Softwarerequirements.............................................................................4 2.3 Creatingmaps............................................................................................5 3. Edit mapprocess............................................................................................8 3.1 ConnectingRobots....................................................................................8 3.2 Mappreprocessing ....................................................................................9 4. P3 Pro OperatingInstructions ......................................................................15 3 / 22 Copyright(c) 2016-2023ShanghaiSlamtecCo.,Ltd. 1. Background This documentis a quickmanualfor the IntelligentFactoryDeliveryRobotwhenit entersthe site. Operatorscan referto this manualin conjunctionwiththe site environmentto improvethe efficiencyof deployment. Note:Beforethe si te deployment,the customershouldcarryout the site environment surveyworkto understandthe site environment,if necessary,needto carryout the preliminaryenvironmentaltransformation. 2. Mapping 2.1 Environmentalpreparation 1. Try to sweepat a pointin timewhenthe areato be sweptis empty,or less crowded. 2. Try to removefrequentlymovingobjectsfromthe areato be swept. 3. For reflective,translucentand light-absorbingobjectsin the scene,try to stickother materialsthat do not affectthe normalscanningof the lidarat the lidarscanningplane of the robotif the conditionsis allowed. 2.1.1NavigatingPOI points Note: 1) If thereis an obstaclenearthe POI, it mustbe greaterthan40cm. 2) WhenbuildingPOI points,try to movethe robotdirectlyto the specifiedlocation and createPOI pointsat the currentlocation,so that the POI pointsstationcreated are highlyaccurate. 2.1.2Locationof chargingstation The locationof the chargingstationhas a significantimpacton the successof the machine'sautomaticreturnto the chargingstation, so a suitablelocationneedsto be selectedaccordingto the followingrequirements. Chargingstationlocationselectionconsiderations: 1) Obstacleson the left and rightsidesneedto be largerthan35cm. 4 / 22 Copyright(c) 2016-2023ShanghaiSlamtecCo.,Ltd. 2) The chargingstationneedsto be againsta wall,not placedin an areasuchas a mirroredwall or a hollowedout back. 3) The chargingstationlocationshouldnot be placedon a soft floorsuchas carpet, otherwiseit will createa heightdifferenceand will not be ableto be charged 4) The locationof the chargingstationin the sceneneedsto be markedto prevent incorrectrecoveryaftermoving. Obstaclesinclude:magneticstripsfor obstacleavoidance,virtualforbiddenarea,and physicalobstacles. For the locationof fall prevention,it is recommendedto drawthe forbiddenzoneand virtualwall directlyto preventthe robotfromaccidents. 2.2 Softwarerequirements App Buildmap Figure2-1Buildmapmapbuildingtool Robostudiowithfull functionality  Robostudiotool downloadlink: https://www.slamtec.ai/home/support/ You can also contactSLAMTEC's operationand maintenancestaffto get the offline installationpackage. 5 / 22 Copyright(c) 2016-2023ShanghaiSlamtecCo.,Ltd. Figure2-2 RoboStudiomapeditingtool 2.3 Creatingmaps 2.3.1Openingthe BuildmapApp Figure2-3 Buildmaptool 1）EXITAPP Exit the BuildmapApp. 2）Createmapfile Createa map,if you openthe app withthe intentionof doingmapbuildingwork,make sureto checkthis option. 3）CONNECTAGV If the robotinformationis not displayedfor a longtimeafteropeningthe buildmap,you can click"CONNECTAGV"to reconnect. 6 / 22 Copyright(c) 2016-2023ShanghaiSlamtecCo.,Ltd. 4）LOADMAP Loadmap,afterclicking"LOADMAP",the existingmapwillbe loadedandthe correspondingpointgroupdataof "Choosestation"will be displayed. 5）Choosestation Multi-groupstationoption.If thereare severalgroupsof pointsunderthe samemap, you can chooseto operatea certaingroupof pointshere,the defaultis myMapData.txt. 6）CREATEMAPFILE Whencreatinga newmapand clicking"CREATEMAPFILE",pleasemakesurethe robot is on the chargingstation. 7）STARTMAPSCAN Turnon the maprefresh,the robotwill startscanningto createa map,at this timethe robotwill synchronizethe creationof chargingpiles,so pleaseensurethat the robotis on the chargingpiles,and will be displayedin Figure2-4, at this timeyou can pressthe brakebuttonand movethe robotto startscanningthe environmentto builda map,in the processof movement,the radarinstalledon the robotbodywill be scannedfor the environment,at the sametime,the robotwill processthe radardataand generatea map.Figure2-4. Figure2-4 Openmaprefresh 7 / 22 Copyright(c) 2016-2023ShanghaiSlamtecCo.,Ltd. The followingprinciplesshouldbe followedwhencontrollingthe robottravelingto builda map: •Lowerspeedsare recommended,less than0.5m/s,dependingon the current platformcapabilities. •Takemoreloopsthat produceclosedloops. •Afterthe loopreturnsto the origin,keepthe robotmovingand take moreoverlapping paths.Do not stopmovingimmediately. •Afterthe loopreturnsto the origin,if the mapdoesnot close,continuewalkinguntil it does. In the processof scanningthe map,pleasetry not to let the robotwalkin a serpentine line,do not go backwards,the first timeyou can quicklywalkaroundto let the map closed! 8）MAKESTATION Set POIpoints.Markingspecificpoints,includingpositionandrotationangle,can facilitatesubsequentreuse.It is recommendedto movethe robotto eachpointafter scanningthe environmentfirst,and thenclick"MAKESTATION"to set POI points. a.unrealstation:virtualpoint.If you don'tworkaccordingto the routeof the robot's automaticnavigation,you needto let the robotfollowa fixedrouteto performthe ta…

Text truncated - open the document above for the full version.

Signature: Typed or Printed Name: Meng Li Title: Deputy Director Company name: Shanghai SLAMTEC Co., Ltd. ADD: Room 601, Building 3, Kailong Technology Building, No. 6, Lane 3158, Longdong Avenue, Shanghai, China TEL: +86 15201935569 FAX: +86-21-68620565 E-mail: [email protected] Attestation Letter Date: 2025/03/12 To Whom It May Concern, The chip AIC8800D installed in our product Intelligent Factory Delivery Robot (model name: P3 PRO; FCC ID: 2BKFN-P3PRO), for this product, it only activates 2.4G Wi-Fi: 2 412~2462 MHz(802.11b/g/n20/ax20), 2422~2452 MHz(802.11n40/ax40);BT: 2402-2480 MHz(GFSK, π/4- DQPSK, 8DPSK); 5G Wi-Fi B1: 5150-5250 MHz, B2: 5250-5350 MHz, B3: 5470-5725 MHz, B4: 5725-5850 MHz (802.11a/ac/n/ax20,802.11ac/n/ax40), the other bands are disabled by using the software. The SX1276 chip for the product, it only activates SRD:917.1-923.3 MHz,the other bands are disabled by using the software. The RF module AR5BMD22 for the product, it only activates BT: 2402-2480 MHz(GFSK, π/4- DQPSK, 8DPSK), 2.4G Wi-Fi: 2412~2462 MHz(802.11b/g/n20/n40),5G Wi-Fi B1: 5150-5250 MHz, B2: 5250-5350 MHz, B3: 5470-5725 MHz(802.11a/n20/n40), the other bands are disabled by using the software. Please contact me if there is need for any additional clarification or information. Best Regards, Sincerely Yours, FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046

Company name: Shanghai SLAMTEC Co., Ltd. ADD: Room 601, Building 3, Kailong Technology Building, No. 6, Lane 3158, Longdong Avenue, Shanghai, China TEL: +86 15201935569 FAX: +86-21-68620565 E-mail: [email protected] Attestation Letter Date: 2025/03/12 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911 (d) (5) (i) (ii) Filing FCC ID: 2BKFN-P3PRO Shanghai SLAMTEC Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Shanghai SLAMTEC Co., Ltd. (“the applicant”) certifies that as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Shanghai SLAMTEC Co., Ltd. (“the applicant”) certifies that the equipment does not use Kaspersky's software information. Sincerely, Signature: Contact Person: Meng Li Title: Deputy Director

U.S. AGENT LETTER OF ATTESTATION Date: 2025-03-12 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(7) Filing FCC ID: 2BKFN-P3PRO Shanghai SLAMTEC Co., Ltd. (“the Applicant”) certifies that, as of the date of the filing of the application, Iconsigh is our designated U.S. agent for service of process for the above referenced FCC ID. Shanghai SLAMTEC Co., Lt d. (“the Applicant”) accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Iconsigh accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Company Name: Iconsigh Address: 2310 Homestead Road, Suite C1, Los Altos, CA 94024, USA FRN: 0033398652 Tel.: +1 (408) 320-9867 Email: [email protected] Signed by (printed name): Benjamin Kaur Signature: Applicant: Shanghai SLAMTEC Co., Ltd. Address: Room 601, Building 3, Kailong Technology Building, No. 6, Lane 3158, Longdong Avenue, Shanghai, China FRN: 0035762723 Tel: +86 15201935569 Email: [email protected] Signed by (printed name): Meng Li Signature:

Company name: Shanghai SLAMTEC Co., Ltd. ADD: Room 601, Building 3, Kailong Technology Building, No. 6, Lane 3158, Longdong Avenue, Shanghai, China TEL: +86 15201935569 FAX: +86-21-68620565 E-mail: [email protected] FCC Authorization Date: 2025/03/12 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We, Shanghai SLAMTEC Co., Ltd., hereby authorizes Bay Area Compliance Laboratories Corp. (Kunshan) to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratories Corp. (Kunshan) on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely, Signature: Printed Name: Meng Li Title: Deputy Director QA-FR-170-B

QA-FR-171-A Company name: Shanghai SLAMTEC Co., Ltd. ADD: Room 601, Building 3, Kailong Technology Building, No. 6, Lane 3158, Longdong Avenue, Shanghai, China TEL: +86 15201935569 FAX: +86-21-68620565 E-mail: [email protected] FCC Confidential Authorization Date: 202 5/03/12 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: 2BKFN-P3PRO In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Shanghai SLAMTEC Co., Ltd. hereby requests long-term confidential treatment of information accompanying this application as outlined below: •Block Diagram •Schematics •Operation Description •U-NII Device Security Declaration The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Signature: Printed Name: Meng Li Title: Deputy Director

Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSC250312002 1 / 3 EXHIBIT A - EUT EXTERNAL PHOTOGRAPHS Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSC250312002 2 / 3 Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSC250312002 3 / 3

Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSC250312002 1 / 14 EXHIBIT B - EUT INTERNAL PHOTOGRAPHS Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSC250312002 2 / 14 The module FCC ID: PPD-AR5BMD22 (Grant on: 05/02/2013). WiFi/BTAntenna Module 1 Module 2 Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSC250312002 3 / 14 Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSC250312002 4 / 14 Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSC250312002 5 / 14 WiFi/BT Antenna Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSC250312002 6 / 14 Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSC250312002 7 / 14 Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSC250312002 8 / 14 LoRa Antenna Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSC250312002 9 / 14

Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSC250312002 10 / 14 Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSC250312002 11 / 14 Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSC250312002 12 / 14 Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSC250312002 13 / 14 Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSC250312002 14 / 14

Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: RKSC250312002-00B Page 15 of 79 FCC §1.1310 & §2.1091 - MAXIMUM PERMISSIBLE EXPOSURE (MPE) Applicable Standard According to subpart §2.1091 and subpart §1.1310, systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Maximum Permissible Exposure (MPE) (§1.1310, §2.1091) (B) Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f²) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 f = frequency in MHz; * = Plane-wave equivalent power density; According to §1.1310 and §2.1091 RF exposure is calculated. Calculated Formulary Predication of MPE limit at a given distance S = PG/4πR² = power density (in appropriate units, e.g. mW/cm 2 ); P = power input to the antenna (in appropriate units, e.g., mW); G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain; R = distance to the center of radiation of the antenna (appropriate units, e.g., cm); For simultaneously transmit system, the calculated power density should comply with: Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: RKSC250312002-00B Page 16 of 79 Calculated Data: Module 1: Mode Frequency Range (MHz) Antenna Gain ★Tune-up Output Power Evaluation Distance (cm) Power Density (mW/cm 2 ) MPE Limit (mW/cm 2 ) MPE ratio (dBi) (numeric) (dBm) (mW) 2.4G Wi- Fi 2412~2462 3.01 2.0 20 100 20 0.0398 1.0 0.0398 BT 2402~2480 3.01 2.0 9.0 7.94 20 0.0010 1.0 0.0010 SRD 917.1~923.3 2.4 1.74 0.2 1.05 20 0.0004 0.6114 0.0007 5G Wi-Fi 5150-5250 -2.23 0.6 14.0 25.12 20 0.0030 1.0 0.0030 5250-5350 -1.37 0.73 13.5 22.39 20 0.0033 1.0 0.0033 5470-5725 -0.31 0.93 9.50 8.91 20 0.0016 1.0 0.0016 5725-5850 0.69 1.17 12.00 15.85 20 0.0037 1.0 0.0037 Module 2 (contains FCC ID: PPD-AR5BMD22): Mode Frequency Range (MHz) Antenna Gain ★Tune-up Output Power Evaluation Distance (cm) Power Density (mW/cm 2 ) MPE Limit (mW/cm 2 ) MPE ratio (dBi) (numeric) (dBm) (mW) 2.4G Wi- Fi 2412~2462 2.1 1.62 26.0 398.11 20 0.1283 1.0 0.1283 BT 2402~2480 2.1 1.62 7.0 5.01 20 0.0016 1.0 0.0016 5G Wi-Fi 5150-5250 2.9 1.95 16.5 44.67 20 0.0173 1.0 0.0173 5250-5350 2.9 1.95 18.0 63.10 20 0.0245 1.0 0.0245 5470-5725 3.3 2.14 17.5 56.23 20 0.0239 1.0 0.0239 Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: RKSC250312002-00B Page 17 of 79 Note: 1. For the above tune up power were declared by the manufacturer. 2. The contain module FCC ID: PPD-AR5BMD22 (Grant on: 05/02/2013). 3. For module 1, SRD and 2.4G Wi-Fi/5G WIFI/BT/BLE can transmit simultaneously, module 1 and module 2 can transmit simultaneously =0.0007+0.0398+0.1283 =0.1688 < 1.0 Result: The device meet FCC MPE at 20 cm distance.

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (Kunshan). This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP, or any agency of the U.S.Govemment. FCC PART 15.247 TEST REPORT For Shanghai SLAMTEC Co., Ltd. Room 601, Building 3, Kailong Technology Building, No. 6, Lane 3158, Longdong Avenue, Shanghai, China FCC ID: 2BKFN-P3PRO Report Type: Original Report Product Name: Intelligent Factory Delivery Robot Report Number: RKSC250312002-00C Report Date: 2025-09-10 Reviewed By: Bard Liu Approved By: Kyle Xu Test Laboratory: Bay Area Compliance Laboratories Corp. (Kunshan) No.248 Chenghu Road, Kunshan, Jiangsu Province, China Tel: +86-512-86175000 Fax: +86-512-88934268 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: RKSC250312002-00C FCC Part 15.247 Page 2 of 68 TABLE OF CONTENTS REPORT REVISION HISTORY................................................................................................................................. 4 GENERAL INFORMATION ....................................................................................................................................... 5 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 5 OBJECTIVE ................................................................................................................................................................... 5 TEST METHODOLOGY .................................................................................................................................................. 5 MEASUREMENT UNCERTAINTY .................................................................................................................................... 6 TEST FACILITY ............................................................................................................................................................. 6 SYSTEM TEST CONFIGURATION .......................................................................................................................... 7 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 7 EUT EXERCISE SOFTWARE .......................................................................................................................................... 7 SPECIAL ACCESSORIES ................................................................................................................................................. 7 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 7 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 8 EXTERNAL I/O CABLE.................................................................................................................................................. 8 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 8 SUMMARY OF TEST RESULTS ............................................................................................................................. 10 TEST EQUIPMENT LIST ......................................................................................................................................... 11 FCC §1.1310 & §2.1091 - MAXIMUM PERMISSIBLE EXPOSURE (MPE) ....................................................... 13 FCC §15.203 – ANTENNA REQUIREMENT .......................................................................................................... 16 APPLICABLE STANDARD ............................................................................................................................................ 16 ANTENNA CONNECTOR CONSTRUCTION .................................................................................................................... 16 FCC §15.207 (a) – AC LINE CONDUCTED EMISSIONS ..................................................................................... 17 APPLICABLE STANDARD ............................................................................................................................................ 17 TEST SYSTEM SETUP .................................................................................................................................................. 17 EMI TEST RECEIVER SETUP ....................................................................................................................................... 17 TEST PROCEDURE ...................................................................................................................................................... 18 TEST RESULTS SUMMARY .......................................................................................................................................... 18 TEST DATA: SEE APPENDIX ....................................................................................................................................... 18 FCC §15.205, §15.209 & §15.247(d) – RADIATED EMISSIONS ........................................................................... 19 APPLICABLE STANDARD ............................................................................................................................................ 19 TEST SYSTEM SETUP .................................................................................................................................................. 19 EMI TEST RECEIVER SETUP ............................................…

Text truncated - open the document above for the full version.

LZANT-10457-C 2023.07.11 1.0 Product Customer P/N Specifications Model Lianzhao P/N Date Prepared Revision Metal sheet antenna 2.4/5.8G, 35.8x8.6x7.5mm metal sheet RG137 cord, 100mm in length, ipex end R&D R&DDQE Customer QCPUR Prepare APPROVAL SHEET Customer Name Lianzhao Electronics Manufacturer：Dongguan lianzhao electronics CO.LTD Address：2nd Floor, Building 1, No.162, Xinhe Industry Park, Zhen'an East Road, Xiaobian Community, Chang'an Town,Dongguan City. Tel:0769- 21018679 Website:www.leenz.cn Page 1 / 10 Page2 / 10 Index 1. Co ver ·····························1 2. Index···························2 3. Product Specification······················3 4. Reliability Test ····················4 5. Product Drawing·····················5 6. Test Equipment & Conditions···············6 7. Test Report·····················7-10 Page3 / 10 2400-2500MHz / 5150-5850MHz < 2.0 2-4dBi ≈67% 50 Ohm Linear 360° 20-40° - 40 ̊C ~ +80 ̊C - 45 ̊C ~ +85 ̊C ≤95% D. Photo Operation Temperature Storage Temperature Humidity C. Environmental Cable Type Connector Type Dimension Weight 100mm in length,RG137 cord 1st generation ip ex 35.8x8.6x7.5mm 0.002Kg B. Material & Mechanical A. Electrical Characteristics Frequency VSWR Peak Gain Efficiency Impedance Polarization Horizontal Beamwidth垂 Vertical Beamwidth Product Specification Page4 / 10 2.0(nominal) 2.9(nominal) 3.2(nominal) 3.7(nominal) 4.3(nominal) 4.8(nominal) 5.3(nominal) 1GHz 2GHz 2.4GHz 3.0GHz 4.0GHz 5.0GHz 6.0GHz 3.3dB/m (at20°C) Item Specification Electrical and mechanical performance shall be normal. Electrical and mechanical performance shall be normal. Electrical and mechanical performance shall be normal. Electrical and mechanical performance shall be normal. Dimensions shall meet specifications and satisfy mechanical and electrical performance requirements. Dimensions shall meet specifications and satisfy mechanical and electrical performance requirements. Electrical and mechanical performance shall be normal. Test Conditions When not otherwise specified, test temperature, humidity, and atmospheric pressure are as follows: 1. Temperature: -45°C ~ +85°C 2. Relative Humidity: 45% - 85% 3. A tmospheric Pressure: 86 kPa - 106 kPa Perform 5 cycles between 85°C and -45°C, then place under normal conditions for 1-2 hours and inspect appearance quality. Relative Humidity: 95% ± 3%, Test Temperature: 40°C. Duration: 2 hours. After testing, measure electrical performance within 5 minutes after removal. Place the sample under normal conditions for 1-2 hours and inspect appearance quality. Frequency Range: 10-55 Hz, Displacement Amplitude: 0.35 mm, Acceleration Amplitude: 50.0 m/s², Sweep Cycles: 30 times. Drop from 1 meter height. Use a push-pull force gauge to test the withstanding force: ≥ 5 N. 1. Insulation Spark Voltage: 1.5 KV 2. Sheath Spark Voltage: 1.5 KV 3. Insulation to Sheath Withstand Voltage: 0.5 KV Storage Environment High & Low Temperature Test Damp Heat, Steady State Test Vibration Test Drop Test Withdrawal Force Test Voltage Withstand Test Attenuation Value Reliability Test Page5 / 10 Product Drawing: Expanded Plan 3D Model Thickness Material Brass Page6 / 10 Test Equipment & Conditions 1、Network Analyzers : Keysight E5071C 2、3D Chamber Test System Page7 / 10 VSWR Page8 / 10 Frequency(MHz)Gain(dBi)Efficiency(%) 24001.458.0 24101.966.3 24202.170.7 24302.172.8 24402.067.5 24501.964.3 24602.064.8 24701.866.3 24801.767.4 24902.072.9 25001.765.1 51502.953.9 52002.953.9 52502.957.0 53002.352.1 53502.454.5 54003.156.5 54503.054.3 55003.357.4 55503.258.0 56003.058.4 56503.058.8 57003.058.0 57503.057.8 58003.159.2 58503.156.3 Total Efficiency& Gain : Page9 / 10 2.4G3D 2400MHz 2450MHz 2500MHz 2D-Horizontal 2D-Vertical Radiation Pattern Page10 / 10 5.8G3D 5150MHz 5500MHz 5850MHz 2D-Horizontal 2D-Vertiacal

www.nicerf.comSW915-WT100 NiceRFWirelessTechnologyCo.,Ltd.Rev2.2 [email protected] -2- Catalogue 1.Description..............................................................................................................................................................-3- 2.TechnicalParameter...............................................................................................................................................-3- 3.Size.........................................................................................................................................................................-3- 4.TestDatas................................................................................................................................................................-3-  VSWRChart........................................................................................................................................................-4-  SmithChart..........................................................................................................................................................-4-  2D&3DPatternPlotsofPassive(@905MHz)....................................................................................................-5-  2D&3DPatternPlotsofPassive(@915MHz)....................................................................................................-7-  2D&3DPatternPlotsofPassive(@925MHz)....................................................................................................-9- Note:RevisionHistory RevisionDateComment V1.02013-06Firstrelease V2.02016-06Typesetting,measurementsrevsied V2.12017-06Logoupdated V2.22018-8Increasetestdatas www.nicerf.comSW915-WT100 NiceRFWirelessTechnologyCo.,Ltd.Rev2.2 [email protected] -3- 1.Description SW915-WT100,anelbowrodantenna,designedspeciallyfor915MHzwirelesscommunicationand MeterReadingCommunicationSystem,ithasgoodVSWR,ingeniousstructure,easyinstallation, stableperformance,withgoodanti-vibrationandanti-agingability. 2.TechnicalParameter FrequencyRange:915±10MHz VSWR:≤2.0 Gain:2.3dBi Inputimpedance:50Ω Maxpower:10W Polarization:verticalpolarization Height:106±1mm Interfaceform:SMA-JW Leadwire:none AntennaColor:black Weight:15g 3.Size 4.TestDatas Frequency （ MHz ） Gain(dBi)Efficiency(%) 905MHz2.112% 915MHz2.313% 925MHz2.414% www.nicerf.comSW915-WT100 NiceRFWirelessTechnologyCo.,Ltd.Rev2.2 [email protected] -4-  VSWRChart  SmithChart www.nicerf.comSW915-WT100 NiceRFWirelessTechnologyCo.,Ltd.Rev2.2 [email protected] -5-  2D&3DPatternPlotsofPassive(@905MHz) www.nicerf.comSW915-WT100 NiceRFWirelessTechnologyCo.,Ltd.Rev2.2 [email protected] -6- www.nicerf.comSW915-WT100 NiceRFWirelessTechnologyCo.,Ltd.Rev2.2 [email protected] -7-  2D&3DPatternPlotsofPassive(@915MHz) www.nicerf.comSW915-WT100 NiceRFWirelessTechnologyCo.,Ltd.Rev2.2 [email protected] -8- www.nicerf.comSW915-WT100 NiceRFWirelessTechnologyCo.,Ltd.Rev2.2 [email protected] -9- 2D&3DPatternPlotsofPassive(@925MHz) www.nicerf.comSW915-WT100 NiceRFWirelessTechnologyCo.,Ltd.Rev2.2 [email protected] -10- Company Name: NiceRF Wireless Technology Co., Ltd. Company Address: Room 309, 315, 3rd Floor, Building A, Hongdu Business Building, Area 43, Xin'an Sub-district, Bao'an District, Shenzhen City, Guangdong Province

ANTENNA TEST REPORT Manufacturer: Shanghai SLAMTEC Co., Ltd. Address: Room 601, Building 3, Kailong Technology Buil…

Text truncated - open the document above for the full version.
