2BKOL-WCH4R01Car Wireless charger for 4Runner

HG-TECH Since-2013 Shenzhen huagon technology CO ., Ltd SZ Office: 102, Building D,Weihuada Industrial Park, No. 5, Lirong Road, Dalang street, Longhua District, Shenzhen, China www.huagoncharging.com Car Wireless charger for 4Runner 本文档涉及华功科技公司的保密内容。禁止以任何形式向第三方传播这份文档或者文档里面的任何信息。华功科技公司对此 文档保留所有权利。 This document is convenient about HG-TECH. It is inhibit to transfer this document and the any information to the three part. This document is copyright © 2024 by the HG-TECH . Shenzhen huagon technology CO ., Ltd SZ Office: 102, Building D,Weihuada Industrial Park, No. 5, Lirong Road, Dalang street, Longhua District, Shenzhen, China www.huagoncharging.com HG-TECH Since-2013 r 1. Product definition description The 2 coil wireless charging module that complies with the Wireless Power Consortium (WPC) Qi1.3.3 10W standard. This module can automatically detect Qi-standard receivers, initiate data communication with them, and intelligently manage wireless power transmission. It supports 7.5W fast wireless charging for Apple iPhone 12 to 15 series, as well as 10W fast wireless charging for Samsung Huawei google etc android phones . To enhance application flexibility, it is equipped with a dynamically detectable input power supply, compatible input DC 9-18V Power input . By continuously monitoring the efficiency conversion between received power and transmitted power, the module can detect the presence of metallic foreign objects, thereby preventing abrupt temperature rises during charging. 2. Product features 1. WPC Qi1.3.3 BPP standard ; 2. Maximum support for charging 15W receiver; 3. Compatible with charging equipment with Qi BPP, EPP standards; 4. Support Samsung，LG，Google Huawei mobile phone 10-15W fast charging; 5. Support Apple mobile phone Max 7.5W fast charge; 6. Overvoltage and overcurrent protection; 7. Foreign body detection (FOD); 8. Up to 73% charging efficiency ; 9. Reserved expansion interface, can be connected with LED-RGB fan, etc ; 10. Certificated : Support Passed CE-RED / FCC-ID / Rohs 2.0 / QI1.3.3 3. Electrical Specification 1. Input voltage : 12V4A 2. Rated input current: 4A MAX 3. Required input ripple voltage:<150mVp-p @ 2.3A 15V 4. Output power of Rx: 15W (Max 15W ) 5. Switching frequency: EPP 115Khz-205Khz 6. Wireless charging efficiency 72% (Max) 7. Ambient operating Temperature: -30°C to 80°C 8. Over current protection: 4.1A 9. Over voltage protection: 18.5V 10. Thermal protection:yes : 75°C （80°C power reduction, 85°C error reporting , 65°C recovery） 11. Operating temperature：0°C to 45°C 12. Storage temperature：-20°C to 80°C 13. Operating humidity：10% to 70% RH 14. Effective charging area: typ. +/-5mm from coil centre (Dz=3 mm) 15. Effective charging distance: 1~ 6mm from Tx-coil to Rx-coil 16. Charging power with charging distance : ≤3mm （15W） ＞3mm （10-15W） Shenzhen huagon technology CO ., Ltd SZ Office: 102, Building D,Weihuada Industrial Park, No. 5, Lirong Road, Dalang street, Longhua District, Shenzhen, China www.huagoncharging.com HG-TECH Since-2013 r Wireless charger design compatible the phone brand and charging power Brand mode Charging power Iphone iPhone8 7.5W iPhone8plus 7.5W iPhoneX 7.5W iPhoneXS 7.5W iPhoneXS Max 7.5W iPhone XR 7.5W iPhone 11 7.5W iPhone 11 Pro 7.5W iPhone 11 ProMAX 7.5W iPhoneSE 2 7.5W iPhoneSE 3 7.5W iPhone 12 7.5W iPhone 12mini 7.5W iPhone 12Pro 7.5W iPhone 12ProMax 7.5W iPhone 13 7.5W iPhone 13mini 7.5W iPhone 13Pro 7.5W iPhone 13ProMax 7.5W iPhone 14 7.5W iPhone 14Plus 7.5W iPhone 14Pro 7.5W iPhone 14ProMax 7.5W iPhone 15 7.5W iPhone 15Plus 7.5W iPhone 15Pro 7.5W iPhone 15ProMax 7.5W iPhone 16 7.5W iPhone 16Plus 7.5W iPhone 16Pro 7.5W iPhone 16ProMax 7.5W iPhone 17 7.5W iPhone 17Pro 7.5W iPhone 17Pro Max 7.5W Google PIXEL 5 10W PIXEL 6 10W PIXEL 6pro 10W PIXEL 7a 7.5W PIXEL 7 10W PIXEL 7pro 10W PIXEL 8a 10W PIXEL 8 10W Shenzhen huagon technology CO ., Ltd SZ Office: 102, Building D,Weihuada Industrial Park, No. 5, Lirong Road, Dalang street, Longhua District, Shenzhen, China www.huagoncharging.com HG-TECH Since-2013 r PIXEL 8pro 10W PIXEL 9a 10W PIXEL 9 10W PIXEL 9pro 10W PIXEL 9proXL 10W PIXEL 9 Pro Fold 7.5W Samsung Galaxy Note9 10W Galaxy Note10 10W Note10+ 10W Note10+ 5G 10W Note20 5G 10W Note20 Ultra 5G 10W Galaxy S8 10W Galaxy S8+ 10W Galaxy S9 10W Galaxy S9+ 10W Galaxy S10 10W Galaxy S10e 10W Galaxy S10+ 10W Galaxy S20 10W Galaxy S20+ 10W Galaxy S20 Ultra 10W Galaxy S21 10W Galaxy S21+ 10W Galaxy S21 Ultra 10W Galaxy S22 10W Galaxy S22+ 10W Galaxy S22 Ultra 10W Galaxy S23 10W Galaxy S23+ 10W Galaxy S23 Ultra 10W Galaxy S24 10W Galaxy S24+ 10W Galaxy S24 Ultra 10W Galaxy S25 10W Galaxy S25+ 10W Galaxy S25 Ultra 10W Galaxy Z Flip 4 10W Galaxy Z Flip 5 10W Galaxy Z Flip 6 10W Galaxy Z Fold 1 10W Galaxy Z Fold 2 10W Galaxy Z Fold 3 10W Galaxy Z Fold 4 10W Galaxy Z Fold 5 10W Galaxy Z Fold 6 10W Galaxy W21 10W Shenzhen huagon technology CO ., Ltd SZ Office: 102, Building D,Weihuada Industrial Park, No. 5, Lirong Road, Dalang street, Longhua District, Shenzhen, China www.huagoncharging.com HG-TECH Since-2013 r Galaxy W22 10W Galaxy W23 10W Galaxy W23 Flip 10W Galaxy W24 10W Galaxy W24 Flip 10W Galaxy W25 10W Galaxy W25 Flip 10W FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instru…

Text truncated - open the document above for the full version.

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: Picus Advisors US LLC FRN: 0034336891 Contact Name: lvan Wang Address: 5855 SOVEREIGN DRSTE B-1, HOUSTON, TX 77036, USA Telephone No: (713) 391-4488 Email: [email protected] Applicant: Company name: Shenzhen Huagon Technology Co.,Ltd FRN: 0035882588 Product Description: Car Wireless charger for 4Runner Grantee code: 2BKOL FCC ID: 2BKOL-WCH4R01 Contact Name: Mike zhu Address: 6 floor, Building A, Weihuada Industrial Park, No.5 Lirong Road, Xinshi community, Dalang street, Longhua District, shenzhen, China Telephone No: 15219486699 Email: [email protected] [Shenzhen Huagon Technology Co.,Ltd] certifies that, as of the date of this filing of the application with the TCB, [Picus Advisors US LLC] is our designated US agent for service of process for the above referenced FCC ID. [Shenzhen Huagon Technology Co.,Ltd] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [Picus Advisors US LLC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 05.14.2026 Applicant’s Name: Mike zhu US Agent’s Name: lvan Wang Title: Manager Title: CEO Signature Signature

Attestation Statement. Old Code: C5266091 24 New Code: 00015544 Ed.3 Change reason: FRN is added to the Applicant information section. 1/1 TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Shenzhen Huagon Technology Co.,Ltd Grantee code: 2BKOL FCC ID: 2BKOL-WCH4R01 FRN: 0035882588 Contact Name: Mike zhu Address: 6 floor, Building A, Weihuada Industrial Park, No.5 Lirong Road, Xinshi community, Dalang street, Longhua District, shenzhen, China Telephone No: 15219486699 Fax No: Email: [email protected] i. [Shenzhen Huagon Technology Co.,Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Shenzhen Huagon Technology Co.,Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. Shenzhen Huagon Technology Co.,Ltd certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Date: 05.14.2026 Applicant’s Name: Mike zhu Title: Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Shenzhen Huagon Technology Co.,Ltd Code 00018768 Ed. 1 Item 1. The device is able to install software/program installation? ☐ Yes, go to Item 2. ☒ No. In this case, the rest of the items do not apply. The device cannot support installation of Kaspersky cybersecurity or anti-virus software. Item 2. Technical Requirements for Kaspersky Cybersecurity Software: # General Requirements (For all Devices) Yes / No or N/A Comments 1 Internet connection for activation and updates (For all Operating Systems) N/A Device Car Wireless charger for 4Runner Company name Shenzhen Huagon Technology Co.,Ltd Grantee code 2BKOL FCC ID 2BKOL-WCH4R01 FRN 0035882588 Contact name Mike zhu Address 6 floor, Building A, Weihuada Industrial Park, No.5 Lirong Road, Xinshi community, Dalang street, Longhua District, shenzhen, China Telephone number 15219486699 E-mail [email protected] Chipset/module information XL1501 Operating System (if applicable) N/A Storage Capacity (hard drive or other permanent memory storage, if applicable) N/A 2 # General Requirements (For Windows Devices) Yes / No or N/A Comments 1 Storage: 1500 MB free space on the hard drive N/A 2 Operating System: Microsoft Windows 8, 8.1, 10 & 11 Home / Pro / Enterprise Microsoft Windows 7 Starter / Home Basic & Premium / Professional / Ultimate SP1 or higher N/A 3 Processor: 1 GHz or higher (x86 or x64) N/A 4 Memory (RAM)1 GB (32-bit) or 2 GB (64-bit) N/A 5 Screen Resolution: Minimum resolution of 1024 x 768 N/A # General Requirements (For macOS devices) Yes / No or N/A Comments 1 Operating System macOS® 13 – 14 N/A 2 Memory (RAM)4 GB N/A 3 Storage: 3455 MB free space on the hard drive N/A # General Requirements (For Android Devices) Yes / No or N/A Comments 1 Storage: 150 MB free space N/A 2 Operating System: Android™ 10 – 14 N/A 3 Screen Resolution: Minimum resolution of 320 x 480 N/A # General Requirements (for iOS devices) Yes / No or N/A Comments 1 Storage: 150 MB free space N/A 2 Operating System: iOS® 17 N/A 3 After reviewed the technical requirements, is the device capable of supporting the installation of Kaspersky software? ☐ Yes, go to Item 3. ☒ No. In this case, the rest of the items do not apply. The device cannot support installation of Kaspersky software Item 3. Connectivity Capabilities: # Physical Interface Purpose Justification 1 1 # Wireless Interface Purpose Justification 1 1 After the review of this items, the device: ☒ Cannot support installation of any cybersecurity or anti-virus software on the covered list. ☐ Potentially can operate with any cybersecurity or anti-virus software on the covered list – additional third- party proof is provided to demonstrate compliance with requirements as of 2.911(d)5(i),(ii) – “Proof of Compliance with Covered List Software Requirements” of this document applies Signature: Name: Mike zhu Date: 04.28.2025 1 The justification field is used to justify why the software cannot be received through that interface. Check the annex for more indications.

TCB CALL página 1 File FCC ID: 2BKOL-WCH4R01 Please upload an exhibit that explains how does the TCB verify the new agent information: 1- Is the address of the agent a valid physical US mailing address (not a US post office box, not a virtual mailbox, not P.O. Boxes, not a vacant lot, not a public building, etc.) ○ We have checked if the address exists in a real and potential building (Google maps) + official US register, after this verification and the evidence below we can guarantee the following: not a US post office box not a virtual mailbox not P.O. Boxes not a vacant lot not a public building(note) ► We checked the FCC FRN Search based on the information provided by the grantee. Google: TCB CALL página 2 EIN Statement TCB CALL página 3 ► CONCLUSION by TCB: The ASOP defined and provided by grantee is VALID and confirmed. Therefore the exhibit "C5266091_X23_Ed1_US_Agent_Letter" included in the file is ok. 2- Is the agent physically located at that valid US address such that the agent can be legally served at that address? Yes , check above 3- Has the listed agent clearly agreed in writing to serve as the agent for the grantee at that address? Yes, it is included in the exhibit "C5266091_X23_Ed1_US_Agent_Letter"

C5266091_X10_Ed.2 1/1 Shenzhen Huagon Technology Co.,Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 5/14/2026 Subject: Request for Confidentiality FCC ID: 2BKOL-WCH4R01 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name: Mike zhu Title: Manager

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Shenzhen Huagon Technology Co.,Ltd Address: 6 floor, Building A, Weihuada Industrial Park, No.5 Lirong Road, Xinshi community, Dalang street, Longhua District, shenzhen, China Product Name: Car Wireless charger for 4Runner Model Number: WCH4R01 FCC Identifier: 2BKOL-WCH4R01 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Mike zhu Date: 5/14/2026 Title: Manager Signature of applicant:

Page1of3ReportNo.:MTi260408002-0102 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] PhotographsoftheEUT(ExternalPhotos) Model:WCH4R01 Page2of3ReportNo.:MTi260408002-0102 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Page3of3ReportNo.:MTi260408002-0102 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected]

Model：WCH4R01 FCC ID: 2BKOL-WCH4R01 Input: DC 12V/4A

Page1of3ReportNo.:MTi260408002-0102 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] PhotographsoftheEUT(InternalPhotos) Model:WCH4R01 Page2of3ReportNo.:MTi260408002-0102 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Page3of3ReportNo.:MTi260408002-0102 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected]

Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE014 Ver./Rev.：A1 Page 1 of 18 TestReport ReportNo.:MTi260408002-0102E2 Dateofissue:2026-04-23 Applicant:ShenzhenHuagonTechnologyCo.,Ltd Product:CarWirelesschargerfor4Runner Model(s):WCH4R01 FCCID:2BKOL-WCH4R01 ShenzhenMicrotestCo.,Ltd. TESTREPORT ReportNo.:MTi260408002-0102E2 Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE014 Ver./Rev.：A1 Page2of18 Tableofcontents 1GeneralDescription...................................................................................................................4 1.1DescriptionoftheEUT.................................................................................................................................4 1.2Descriptionoftestmodes............................................................................................................................4 1.3Descriptionofsupportunits.........................................................................................................................7 2Measurementuncertainty.........................................................................................................7 3Testfacilitiesandaccreditations.............................................................................................7 3.1Testlaboratory..............................................................................................................................................7 4Listoftestequipment...............................................................................................................8 5Testresult...................................................................................................................................9 5.2Testsetup....................................................................................................................................................10 5.3TestProcedures..........................................................................................................................................10 5.4Informationoftestequipment.....................................................................................................................11 5.5Testresults..................................................................................................................................................12 PhotographsoftheTestSetup.......................................................................................................16 PhotographsoftheEUT..................................................................................................................17 TESTREPORT ReportNo.:MTi260408002-0102E2 Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE014 Ver./Rev.：A1 Page 3 of 18 TestResultCertification ApplicantShenzhenHuagonTechnologyCo.,Ltd ApplicantAddress 6floor,BuildingA,WeihuadaIndustrialPark,No.5LirongRoad,Xinshi community,Dalangstreet,LonghuaDistrict,shenzhen,China ManufacturerShenzhenHuagonTechnologyCo.,Ltd Manufacturer Address 6floor,BuildingA,WeihuadaIndustrialPark,No.5LirongRoad,Xinshi community,Dalangstreet,LonghuaDistrict,shenzhen,China FactoryShenzhenHuagonTechnologyCo.,Ltd FactoryAddress 6floor,BuildingA,WeihuadaIndustrialPark,No.5LirongRoad,Xinshi community,Dalangstreet,LonghuaDistrict,shenzhen,China Productdescription ProductnameCarWirelesschargerfor4Runner TrademarkMtMisión ModelnameWCH4R01 SeriesModel(s)N/A Standards FCCCFR47PART1,§1.1310 FCCCFR47Part2.1091 TestmethodKDB680106D01WirelessPowerTransferv04 TestingInformation Dateoftest2026-04-17to2026-04-20 TestResultPass Preparedby:JamesQin Reviewedby:DavidLee Approvedby:LewisLian TESTREPORT ReportNo.:MTi260408002-0102E2 Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE014 Ver./Rev.：A1 Page 4 of 18 1GeneralDescription 1.1DescriptionoftheEUT Productname:CarWirelesschargerfor4Runner Modelname:WCH4R01 SeriesModel(s):N/A Modeldifference:N/A Electricalrating: Input:DC12V/4A WirelessOutput:5W/7.5W/10W/15W Accessories:N/A Hardwareversion:V1 Softwareversion:V1 Testsample(s)number:MTi260408002-01-R001 RFspecification: Operationfrequency:115-205kHz Modulationtype:ASK Antennatype:Coil 1.2Descriptionoftestmodes AllthetestmodeswerecarriedoutwiththeEUTinnormaloperation,thefinaltestmodeofthe EUTwastheworsttestmodeforemissiontest,whichwasshowninthisreportanddefinedas: No.Emissiontestmodes Mode1WirelessOutputCoil1(5W)+Coil3(5W) Mode2WirelessOutputCoil1(5W)+Coil3(7.5W) Mode3WirelessOutputCoil1(5W)+Coil3(10W) Mode4WirelessOutputCoil1(5W)+Coil3(15W) Mode5WirelessOutputCoil1(7.5W)+Coil3(5W) Mode6WirelessOutputCoil1(7.5W)+Coil3(7.5W) Mode7WirelessOutputCoil1(7.5W)+Coil3(10W) Mode8WirelessOutputCoil1(7.5W)+Coil3(15W) Mode9WirelessOutputCoil1(10W)+Coil3(5W) Mode10WirelessOutputCoil1(10W)+Coil3(7.5W) Mode11WirelessOutputCoil1(10W)+Coil3(10W) Mode12WirelessOutputCoil1(10W)+Coil3(15W) Mode13WirelessOutputCoil1(15W)+Coil3(5W) Mode14WirelessOutputCoil1(15W)+Coil3(7.5W) Mode15WirelessOutputCoil1(15W)+Coil3(10W) Mode16WirelessOutputCoil1(15W)+Coil3(15W) Mode17WirelessOutputCoil1(5W)+Coil4(5W) TESTREPORT ReportNo.:MTi260408002-0102E2 Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPar…

Text truncated - open the document above for the full version.

Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE038 Ver./Rev.：A1 Page 1 of 34 TestReport ReportNo.:MTi260408002-0102E1 Dateofissue:2026-04-23 Applicant:ShenzhenHuagonTechnologyCo.,Ltd Product:CarWirelesschargerfor4Runner Model(s):WCH4R01 FCCID:2BKOL-WCH4R01 ShenzhenMicrotestCo.,Ltd. TESTREPORT ReportNo.:MTi260408002-0102E1 Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE038 Ver./Rev.：A1 Page 2 of 34 Tableofcontents 1GeneralDescription.......................................................................................................................4 1.1DescriptionoftheEUT.........................................................................................................4 1.2Descriptionoftestmodes.....................................................................................................4 1.3EnvironmentalConditions.....................................................................................................7 1.4Descriptionofsupportunits..................................................................................................7 1.5Measurementuncertainty.....................................................................................................7 2SummaryofTestResult................................................................................................................8 3TestFacilitiesandaccreditations................................................................................................9 3.1Testlaboratory......................................................................................................................9 4Listoftestequipment..................................................................................................................10 5EvaluationResults(Evaluation).................................................................................................11 5.1Antennarequirement..........................................................................................................11 6RadioSpectrumMatterTestResults(RF)................................................................................12 6.120dBOccupiedBandwidth.................................................................................................12 6.2Emissionsinfrequencybands(below30MHz)..................................................................18 6.3Emissionsinfrequencybands(30MHz-1GHz)................................................................28 Photographsofthetestsetup...........................................................................................................32 PhotographsoftheEUT.....................................................................................................................33 TESTREPORT ReportNo.:MTi260408002-0102E1 Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE038 Ver./Rev.：A1 Page 3 of 34 TestResultCertification ApplicantShenzhenHuagonTechnologyCo.,Ltd ApplicantAddress 6floor,BuildingA,WeihuadaIndustrialPark,No.5LirongRoad,Xinshi community,Dalangstreet,LonghuaDistrict,shenzhen,China ManufacturerShenzhenHuagonTechnologyCo.,Ltd Manufacturer Address 6floor,BuildingA,WeihuadaIndustrialPark,No.5LirongRoad,Xinshi community,Dalangstreet,LonghuaDistrict,shenzhen,China FactoryShenzhenHuagonTechnologyCo.,Ltd FactoryAddress 6floor,BuildingA,WeihuadaIndustrialPark,No.5LirongRoad,Xinshi community,Dalangstreet,LonghuaDistrict,shenzhen,China Productdescription ProductnameCarWirelesschargerfor4Runner TrademarkMtMisión ModelnameWCH4R01 SeriesModel(s)N/A Standards47CFRPart15C TestMethodANSIC63.10-2020+Cor1-2023 TestingInformation Dateoftest2026-04-17to2026-04-23 TestresultPass Preparedby:JamesQin Reviewedby:DavidLee Approvedby:LewisLian TESTREPORT ReportNo.:MTi260408002-0102E1 Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE038 Ver./Rev.：A1 Page 4 of 34 1GeneralDescription 1.1DescriptionoftheEUT Productname:CarWirelesschargerfor4Runner Modelname:WCH4R01 SeriesModel(s):N/A Modeldifference:N/A Electricalrating: Input:DC12V/4A WirelessOutput:5W/7.5W/10W/15W Accessorie…

Text truncated - open the document above for the full version.
