2BKPG-JNG14Mini PC

5-05-00143 FCC Warning This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any inte rference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interferenceto radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. ISED Statement English: This device complies with Innovation, Science and Economic Development Canada’s license‐exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This d evice must accept any interference, including interference that may cause undesired operation of the device. The digital apparatus complies with Canadian CAN ICES‐3 (B)/NMB‐3(B). ‐ French: Le présentappareilestconforme aux CNR d' Innovation, sciences et développement économique Canada applicables aux appareils radio exempts de licence. L'exploitationestautorisée aux deux conditions suivantes: (1) l'appareil ne doit pas p roduire de brouillage, et (2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le brouillageest susceptible d'encompromettre le fonctionnement. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Radiation Exposure Statement This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Déclaration d'exposition aux radiations Cet équipement est conforme Canada limites d'exposition aux radiations dans un environnement non contrôlé. Cet équipement doit être installé et utilisé à distance minimum de 20cm entre le radiateur et votre corps. Caution: (i)The device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems; (ii)For devices with detachable antenna(s), the maximum antenna gain permitted for devices in the band 5725-5850 MHz shall be such that the equipment still complies with the EIRP limits specified for point-to-point and non-point-to-point operation as appropriate; and Avertissement: (i)les dispositifs fonctionnant dans la bande de 5150 à 5250MHz sont réservés uniquement pour une utilisation à l'intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux; (ii)pour les dispositifs munis d'antennes amovibles, le gain maximal d'antenne permis (pour les dispositifs utilisant la bande de 5725 à 5850 MHz) doit être conforme à la limite de la p.i.r.e. spécifiée pour l'exploitation point à point et l'exploitation non point à point, selon le cas;

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong RF Exposure evaluation Report Reference No. ................. : FCC ID. ......................................... : GTS20251225009-2-13 2BKPG-JNG14 Compiled by ( position+printed name+signature): File administrators Peter Xiao Supervised by ( position+printed name+signature): Test Engineer Evan Ouyang Approved by ( position+printed name+signature) . : Manager Jason Hu Date of issue .................................... : Mar.11, 2026 Representative Laboratory Name ....................................................... : Shenzhen Global Test Service Co.,Ltd. Address ......................................... : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ......................... : Gogogo technology Co., LIMITED Address ......................................... : FLAT/RM A, 9/F SILVERCORP INTERNATIONAL TOWER,707-713 NATHAN ROAD, MONGKOK, KOWLOON, HONG KONG, China Test specification ........................ : Standard ........................................ : 47CFR §1.1310 Basis and purpose 47CFR §2.1091 Radiofrequency radiation exposure evaluation: mobile devices TRF Originator .............................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................. : Mini PC Trade Mark .................................... : QAZIPO Manufacturer ................................. : Gogogo technology Co., LIMITED Model/Type reference ...................... : JNG14 Listed Models .............................. : JND13, JNE10, JNE12, JNG10, JNG11, JNG13, JPK09, JPK10, JPK07, MINI PC 3500U, MINI PC N150, NINI PC N150 PRO, MINI PC 6500Y, JNC15 , JPK08, JPE12 Hardware Version ........................ : N/A Software Version ........................... : N/A Rating ............................................ : DC 19.0V/3.42A by Adapter Result ............................................ : PASS Report No.:GTS20251225009-2-13 Page 2 of 19 T E S T R E P O R T Test Report No. : GTS20251225009-2-13 Mar.11, 2026 ______________________________________________________________________________________________ Date of issue Equipment under Test : Mini PC Model /Type : JNG14 Listed model : JND13, JNE10, JNE12, JNG10, JNG11, JNG13, JPK09, JPK10, JPK07, MINI PC 3500U, MINI PC N150, NINI PC N150 PRO, MINI PC 6500Y, JNC15 , JPK08, JPE12 Applicant : Gogogo technology Co., LIMITED Address : FLAT/RM A, 9/F SILVERCORP INTERNATIONAL TOWER,707-713 NATHAN ROAD, MONGKOK, KOWLOON, HONG KONG, China Manufacturer : Gogogo technology Co., LIMITED Address : FLAT/RM A, 9/F SILVERCORP INTERNATIONAL TOWER,707-713 NATHAN ROAD, MONGKOK, KOWLOON, HONG KONG, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.:GTS20251225009-2-13 Page 3 of 19 Contents 1. SUMMARY ................................................................................................................................................................. 4 1.1 EUT CONFIGURATION ........................................................................................................................................................ 4 1.2 PRODUCT DESCRIPTION ..................................................................................................................................................... 4 2. TEST ENVIRONMENT ................................................................................................................................................. 6 2.1 ADDRESS OF THE TEST LABORATORY ..................................................................................................................................... 6 2.2 TEST FACILITY .................................................................................................................................................................. 6 2.3 ENVIRONMENTAL CONDITIONS ............................................................................................................................................ 6 2.4 STATEMENT OF THE MEASUREMENT UNCERTAINTY .................................................................................................................. 6 3. METHOD OF MEASUREMENT .................................................................................................................................... 7 3.1 APPLICABLE STANDARD ...................................................................................................................................................... 7 3.2 REQUIREMENT ................................................................................................................................................................. 7 3.3 LIMIT ............................................................................................................................................................................. 7 3.4 MPE CALCULATION METHOD ............................................................................................................................................. 8 3.5 ANTENNA INFORMATION .…

Text truncated - open the document above for the full version.

FCC ID: 2BKPG-JNG14 _______________________________________________________________________________________________ Page 1 of 2 1. TEST SETUP PHOTOGRAPHS 1.1. Photo of Radiated Emissions Measurement Fig. 1 Fig. 2 FCC ID: 2BKPG-JNG14 _______________________________________________________________________________________________ Page 2 of 2 Photo of Conducted Emission Measurement Fig. 3 Fig. 4

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. .....................: FCC ID. ............................................ : GTS20251225009-2-11 2BKPG-JNG14 Compiled by ( position+printed name+signature) .. : File administrators Peter Xiao Supervised by ( position+printed name+signature) .. : Test Engineer Evan Ouyang Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : Mar.11, 2026 Representative Laboratory Name .: Shenzhen Global Test Service Co.,Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong,China Applicant’s name ............................ : Gogogo technology Co., LIMITED Address ............................................ : FLAT/RM A, 9/F SILVERCORP INTERNATIONAL TOWER,707-713 NATHAN ROAD, MONGKOK, KOWLOON, HONG KONG, China Test specification ...........................: Standard ........................................... : FCC Part 15.247: Operation within the bands 902-928 MHz, 2400- 2483.5 MHz and 5725-5850 MHz TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Mini PC Trade Mark ....................................... : QAZIPO Manufacturer .................................... : Gogogo technology Co., LIMITED Model/Type reference....................... : JNG14 Listed Models .................................. : JND13, JNE10, JNE12, JNG10, JNG11, JNG13, JPK09, JPK10, JPK07, MINI PC 3500U, MINI PC N150, NINI PC N150 PRO, MINI PC 6500Y, JNC15 , JPK08, JPE12 Operation Frequency ........................ : From 2412MHz to 2462MHz Hardware Version ............................ : N/A Software Version .............................. : N/A Rating ............................................... : DC 19.0V/3.42A by Adapter Result................................................ : PASS Report No.: GTS20251225009-2-11 Page 2 of 27 T E S T R E P O R T Test Report No. : GTS20251225009-2-11 Mar.11, 2026 ____________________________________________________________________________________ __________ Date of issue Equipment under Test : Mini PC Model /Type : JNG14 Listed model : JND13, JNE10, JNE12, JNG10, JNG11, JNG13, JPK09, JPK10, JPK07, MINI PC 3500U, MINI PC N150, NINI PC N150 PRO, MINI PC 6500Y, JNC15 , JPK08, JPE12 Applicant : Gogogo technology Co., LIMITED Address : FLAT/RM A, 9/F SILVERCORP INTERNATIONAL TOWER,707-713 NATHAN ROAD, MONGKOK, KOWLOON, HONG KONG, China Manufacturer : Gogogo technology Co., LIMITED Address : FLAT/RM A, 9/F SILVERCORP INTERNATIONAL TOWER,707-713 NATHAN ROAD, MONGKOK, KOWLOON, HONG KONG, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20251225009-2-11 Page 3 of 27 Contents 1. TEST STANDARDS ......................................................................................................................................... 4 2. SUMMARY ....................................................................................................................................................... 5 2.1. General Remarks ................................................................................................................................... 5 2.2. Product Description ................................................................................................................................ 5 2.3. Equipment Under Test ........................................................................................................................... 7 2.4. Short description of the Equipment under Test (EUT) ........................................................................... 7 2.5. EUT operation mode .............................................................................................................................. 7 2.6. Block Diagram of Test Setup ................................................................................................................. 7 2.7. Related Submittal(s) / Grant (s) ............................................................................................................. 7 2.8. EUT Exercise Software .......................................................................................................................... 8 2.9. Special Accessories ............................................................................................................................... 8 2.10. External I/O Cable ................................................................................................................................ 8 2.11. Modifications ........................................................................................................................................ 8 3. TEST ENVIRONMENT ..................................................................................................................................... 9 3.1. Address of the test laborat…

Text truncated - open the document above for the full version.

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID............................................. : GTS20251225009-2-10 2BKPG-JNG14 Compiled by ( position+printed name+signature) . : File administrators Peter Xiao Supervised by ( position+printed name+signature) . : Test Engineer Evan Ouyang Approved by ( position+printed name+signature) . : Manager Jason Hu Date of issue .................................... : Mar.11, 2026 Representative Laboratory Name . : Shenzhen Global Test Service Co.,Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong,China Applicant’s name ............................ : Gogogo technology Co., LIMITED Address ............................................ : FLAT/RM A, 9/F SILVERCORP INTERNATIONAL TOWER,707-713 NATHAN ROAD, MONGKOK, KOWLOON, HONG KONG, China Test specification ........................... : Standard ........................................... : FCC Part 15.247 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ...................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Mini PC Trade Mark ....................................... : QAZIPO Manufacturer .................................... : Gogogo technology Co., LIMITED Model/Type reference ...................... : JNG14 Listed Models .................................. : JND13, JNE10, JNE12, JNG10, JNG11, JNG13, JPK09, JPK10, JPK07, MINI PC 3500U, MINI PC N150, NINI PC N150 PRO, MINI PC 6500Y, JNC15 , JPK08, JPE12 Modulation Type ............................... : GFSK Operation Frequency ........................ : From 2402MHz to 2480MHz Hardware Version ............................ : N/A Software Version .............................. : N/A Rating ............................................... : DC 19.0V/3.42A by Adapter Result ............................................... : PASS Report No.: GTS20251225009-2-10 Page 2 of 26 T E S T R E P O R T Test Report No. : GTS20251225009-2-10 Mar.11, 2026 ______________________________________________________________________________________________ Date of issue Equipment under Test : Mini PC Model /Type : JNG14 Listed model : JND13, JNE10, JNE12, JNG10, JNG11, JNG13, JPK09, JPK10, JPK07, MINI PC 3500U, MINI PC N150, NINI PC N150 PRO, MINI PC 6500Y, JNC15 , JPK08, JPE12 Applicant : Gogogo technology Co., LIMITED Address : FLAT/RM A, 9/F SILVERCORP INTERNATIONAL TOWER,707-713 NATHAN ROAD, MONGKOK, KOWLOON, HONG KONG, China Manufacturer : Gogogo technology Co., LIMITED Address : FLAT/RM A, 9/F SILVERCORP INTERNATIONAL TOWER,707-713 NATHAN ROAD, MONGKOK, KOWLOON, HONG KONG, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20251225009-2-10 Page 3 of 26 Contents 1. TEST STANDARDS ......................................................................................................................................... 4 2. SUMMARY ....................................................................................................................................................... 5 2.1. General Remarks ................................................................................................................................... 5 2.2. Product Description ................................................................................................................................ 5 2.3. Equipment Under Test ........................................................................................................................... 7 2.4. Short description of the Equipment under Test (EUT) ........................................................................... 7 2.5. EUT operation mode .............................................................................................................................. 7 2.6. Block Diagram of Test Setup ................................................................................................................. 8 2.7. EUT Exercise Software .......................................................................................................................... 8 2.8. Special Accessories ............................................................................................................................... 8 2.9. External I/O Cable .................................................................................................................................. 8 2.10. Related Submittal(s) / Grant (s) ........................................................................................................... 8 2.11. Modifications ........................................................................................................................................ 8 3. TEST ENVIRONMENT ..................................................................................................................................... 9 3.1. Address of the test laboratory ....................…

Text truncated - open the document above for the full version.

FCCID:2BKPG-JNG14 1 Case No. : GTS20251225009-2-11 Ambient Condition: 23°C,51%RH, Test Date:2026.1.19-2026.3.10Test Engineer:Evan ouyang Appendix C.1: DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant2 2412 10.320 2406.840 2417.160 0.5 PASS 2437 10.320 2431.840 2442.160 0.5 PASS 2462 10.320 2456.840 2467.160 0.5 PASS 11G Ant2 2412 16.400 2403.880 2420.280 0.5 PASS 2437 16.520 2428.800 2445.320 0.5 PASS 2462 16.440 2453.760 2470.200 0.5 PASS 11N20SISO Ant2 2412 17.640 2403.240 2420.880 0.5 PASS 2437 17.720 2428.080 2445.800 0.5 PASS 2462 17.600 2453.200 2470.800 0.5 PASS 11N40SISO Ant2 2422 36.240 2403.920 2440.160 0.5 PASS 2437 36.320 2418.840 2455.160 0.5 PASS 2452 36.400 2433.840 2470.240 0.5 PASS FCCID:2BKPG-JNG14 2 Test Graphs 11B_Ant2_2412 11B_Ant2_2437 11B_Ant2_2462 FCCID:2BKPG-JNG14 3 11G_Ant2_2412 11G_Ant2_2437 FCCID:2BKPG-JNG14 4 11G_Ant2_2462 11N20SISO_Ant2_2412 11N20SISO_Ant2_2437 FCCID:2BKPG-JNG14 5 11N20SISO_Ant2_2462 11N40SISO_Ant2_2422 FCCID:2BKPG-JNG14 6 11N40SISO_Ant2_2437 11N40SISO_Ant2_2452 FCCID:2BKPG-JNG14 7 Appendix C.2: Occupied Channel Bandwidth Test Result TestMode Antenna Channel Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant2 2412 15.181 2404.4260 2419.6070 --- --- 2437 15.176 2429.3966 2444.5726 --- --- 2462 15.196 2454.3449 2469.5409 --- --- 11G Ant2 2412 17.143 2403.3728 2420.5158 --- --- 2437 17.169 2428.3796 2445.5486 --- --- 2462 17.203 2453.2715 2470.4745 --- --- 11N20SISO Ant2 2412 18.197 2402.9231 2421.1201 --- --- 2437 18.277 2427.8141 2446.0911 --- --- 2462 18.191 2452.8499 2471.0409 --- --- 11N40SISO Ant2 2422 36.951 2403.5497 2440.5007 --- --- 2437 36.867 2418.5266 2455.3936 --- --- 2452 36.951 2433.4388 2470.3898 --- --- FCCID:2BKPG-JNG14 8 Test Graphs 11B_Ant2_2412 11B_Ant2_2437 11B_Ant2_2462 FCCID:2BKPG-JNG14 9 11G_Ant2_2412 11G_Ant2_2437 FCCID:2BKPG-JNG14 10 11G_Ant2_2462 11N20SISO_Ant2_2412 11N20SISO_Ant2_2437 FCCID:2BKPG-JNG14 11 11N20SISO_Ant2_2462 11N40SISO_Ant2_2422 FCCID:2BKPG-JNG14 12 11N40SISO_Ant2_2437 11N40SISO_Ant2_2452 FCCID:2BKPG-JNG14 13 Appendix C.3: Maximum conducted output power Test Result -CHP TestMode Antenna Frequency [MHz] Peak power [dBm] Limit [dBm] Verdict 11B Ant2 2412 15.66 ≤30.00 PASS 2437 16.57 ≤30.00 PASS 2462 16.21 ≤30.00 PASS 11G Ant2 2412 16.30 ≤30.00 PASS 2437 19.23 ≤30.00 PASS 2462 18.36 ≤30.00 PASS 11N20SISO Ant2 2412 16.78 ≤30.00 PASS 2437 19.61 ≤30.00 PASS 2462 18.08 ≤30.00 PASS 11N40SISO Ant2 2422 16.89 ≤30.00 PASS 2437 19.38 ≤30.00 PASS 2452 18.11 ≤30.00 PASS FCCID:2BKPG-JNG14 14 Appendix C.4: Maximum power spectral density Test Result TestMode Antenna Frequency[MHz] Result[dBm/3-100kHz] Limit[dBm/3kHz] Verdict 11B Ant2 2412 -17.72 ≤8.00 PASS 2437 -16.74 ≤8.00 PASS 2462 -17.05 ≤8.00 PASS 11G Ant2 2412 -19.30 ≤8.00 PASS 2437 -16.30 ≤8.00 PASS 2462 -17.37 ≤8.00 PASS 11N20SISO Ant2 2412 -17.58 ≤8.00 PASS 2437 -15.08 ≤8.00 PASS 2462 -17.38 ≤8.00 PASS 11N40SISO Ant2 2422 -19.11 ≤8.00 PASS 2437 -16.83 ≤8.00 PASS 2452 -18.98 ≤8.00 PASS FCCID:2BKPG-JNG14 15 Test Graphs 11B_Ant2_2412 11B_Ant2_2437 11B_Ant2_2462 FCCID:2BKPG-JNG14 16 11G_Ant2_2412 11G_Ant2_2437 FCCID:2BKPG-JNG14 17 11G_Ant2_2462 11N20SISO_Ant2_2412 11N20SISO_Ant2_2437 FCCID:2BKPG-JNG14 18 11N20SISO_Ant2_2462 11N40SISO_Ant2_2422 FCCID:2BKPG-JNG14 19 11N40SISO_Ant2_2437 11N40SISO_Ant2_2452 FCCID:2BKPG-JNG14 20 Appendix C.5:Band edge measurements Test Result TestMode Antenna ChName Frequency [MHz] RefLevel[dBm] Result[dBm] Limit[dBm] Verdict 11B Ant2 Low 2412 2.04 -37.63 ≤-17.96 PASS High 2462 3.00 -49.48 ≤-17 PASS 11G Ant2 Low 2412 -4.95 -37.23 ≤-24.95 PASS High 2462 -2.58 -47.29 ≤-22.58 PASS 11N20SISO Ant2 Low 2412 -4.62 -36.32 ≤-24.62 PASS High 2462 -2.95 -47.15 ≤-22.95 PASS 11N40SISO Ant2 Low 2422 -7.37 -38.98 ≤-27.37 PASS High 2452 -6.50 -40.04 ≤-26.5 PASS FCCID:2BKPG-JNG14 21 Test Graphs 11B_Ant2_Low_2412 11B_Ant2_High_2462 11G_Ant2_Low_2412 FCCID:2BKPG-JNG14 22 11G_Ant2_High_2462 11N20SISO_Ant2_Low_2412 FCCID:2BKPG-JNG14 23 11N20SISO_Ant2_High_2462 11N40SISO_Ant2_Low_2422 11N40SISO_Ant2_High_2452 FCCID:2BKPG-JNG14 24 FCCID:2BKPG-JNG14 25 Appendix C.6:Conducted Spurious Emission Test Result TestMode Antenna Frequency[MHz] FreqRange [Mhz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict 11B Ant2 2412 Reference 0.94 0.94 --- PASS 30~1000 0.94 -60.3 ≤-19.06 PASS 1000~26500 0.94 -48.84 ≤-19.06 PASS 2437 Reference 2.76 2.76 --- PASS 30~1000 2.76 -60.16 ≤-17.24 PASS 1000~26500 2.76 -48.19 ≤-17.24 PASS 2462 Reference 2.91 2.91 --- PASS 30~1000 2.91 -59.54 ≤-17.09 PASS 1000~26500 2.91 -48.22 ≤-17.09 PASS 11G Ant2 2412 Reference -5.33 -5.33 --- PASS 30~1000 -5.33 -60.06 ≤-25.33 PASS 1000~26500 -5.33 -48.44 ≤-25.33 PASS 2437 Reference -2.58 -2.58 --- PASS 30~1000 -2.58 -60.27 ≤-22.58 PASS 1000~26500 -2.58 -48.22 ≤-22.58 PASS 2462 Reference -3.53 -3.53 --- PASS 30~1000 -3.53 -60.02 ≤-23.53 PASS 1000~26500 -3.53 -46.83 ≤-23.53 PASS 11N20SISO Ant2 2412 Reference -5.48 -5.48 --- PASS 30~1000 -5.48 -60.45 ≤-25.48 PASS 1000~26500 -5.48 -47.79 ≤-25.48 PASS 2437 Reference -2.50 -2.50 --- PASS 30~1000 -2.50 -59.85 ≤-22.5 PASS 1000~26500 -2.50 -47.51 ≤-22.5 PASS 2462 Reference -3.87 -3.87 --- PASS 30~1000 -3.87 -59.65 ≤-23.87 PASS 1000~26500 -3.87 -48.56 ≤-23.87 PASS 11N40SISO Ant2 2422 Reference -8.02 -8.02 --- PASS 30~1000 -8.02 -60.05 ≤-28.02 PASS 1000~26500 -8.02 -47.87 ≤-28.02 PASS 2437 Reference -5.80 -5.80 --- PASS 30~1000 -5.80 -59.28 ≤-25.8 PASS 1000~26500 -5.80 -48.03 ≤-25.8 PASS 2452 Reference -6.66 -6.66 --- PASS 30~1000 -6.66 -60.35 ≤-26.66 PASS 1000~26500 -6.66 -47.93 ≤-26.66 PASS FCCID:2BKPG-JNG14 26 Test Graphs 11B_Ant2_2412_0~Reference 11B_Ant2_2412_30~1000 11B_Ant2_2412_1000~26500 FCCID:2BKPG-JNG14 27 11B_Ant2_2437_0~Reference 11B_Ant2_2437_30~1000 FCCID:2BKPG-JNG14 28 11B_Ant2_2437_1000~26500 11B_Ant2_2462_0~Reference 11B_Ant2_2462_30~1000 FCCID:2BKPG-JNG14 29 11B_Ant2_2462_1000~26500 11G_Ant2_2412_0~Reference FCCID:2BKPG-JNG14 30 11G_Ant2_2412_30~1000 11G_Ant2_241…

Text truncated - open the document above for the full version.

FCCID:2BKPG-JNG14 1 Case No. : GTS20251225009-2-11 Ambient Condition: 23°C,52%RH, Test Date:2026.1.19-2026.3.10Test Engineer:Evan ouyang Appendix C.1: DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 10.320 2406.840 2417.160 0.5 PASS 2437 10.320 2431.840 2442.160 0.5 PASS 2462 10.320 2456.840 2467.160 0.5 PASS 11G Ant1 2412 16.480 2403.800 2420.280 0.5 PASS 2437 16.480 2428.760 2445.240 0.5 PASS 2462 16.480 2453.760 2470.240 0.5 PASS 11N20SISO Ant1 2412 17.680 2403.120 2420.800 0.5 PASS 2437 17.600 2428.160 2445.760 0.5 PASS 2462 17.640 2453.160 2470.800 0.5 PASS 11N40SISO Ant1 2422 36.560 2403.680 2440.240 0.5 PASS 2437 36.480 2418.680 2455.160 0.5 PASS 2452 36.720 2433.520 2470.240 0.5 PASS FCCID:2BKPG-JNG14 2 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 FCCID:2BKPG-JNG14 3 11G_Ant1_2412 11G_Ant1_2437 FCCID:2BKPG-JNG14 4 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 FCCID:2BKPG-JNG14 5 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 FCCID:2BKPG-JNG14 6 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 FCCID:2BKPG-JNG14 7 Appendix C.2: Occupied Channel Bandwidth Test Result TestMode Antenna Channel Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 15.204 2404.3764 2419.5804 --- --- 2437 15.256 2429.3282 2444.5842 --- --- 2462 15.234 2454.3529 2469.5869 --- --- 11G Ant1 2412 17.116 2403.4077 2420.5237 --- --- 2…

Text truncated - open the document above for the full version.
