2BKPR-TZB-100TOO Zigbee Hub

ZigBee Smart Hub ZB-GW03 温湿度范围 材 料PC 支持平台Android & IOS -10~60°C 产品规格76x76x23mm 配对按钮 输入接口 网线接口 快速配网 长按按键，直到绿灯常亮，红灯快闪 手机连入一个2.4G的WIFI，然后打开易微联APP，点击添加按钮+， 点击【快速添加】，选择【添加一个设备】 输入当前SSID的密码，点击【下一步】，等待1-2分钟即可添加成功 正常模式 未连接网络 升级 以太网配网 AP 模式 快速配网 添加子设备 红灯常亮 红灯慢闪 红灯常亮 红灯快闪 红灯慢闪 红灯快闪 红灯常亮 绿灯常亮 绿灯熄灭 绿灯慢闪 绿灯熄灭 绿灯常亮 绿灯常亮 绿灯快闪 长按配对按钮，直到绿灯常亮，红灯快闪，松开，再次长按配对按钮5S， 直到红灯慢闪，绿灯常亮，此时设备进入兼容模式。 在APP界面点击“+”,选择APP底部的【兼容模式】，点击【下一步】 等待配对完成。 Android设备：只需输入Wi-Fi密码，点击【下一步】等待配对完成。 iOS设备：先把移动设备连接上Wi-Fi账号为：ITEAD-******， 密码为：12345678，然后回到APP，点击【下一步】等待配对完成。 按住按键，等待红灯和绿灯同时闪烁，继续按住按键直到红灯和绿灯常亮， 松开按键等待红灯闪烁后设备恢复出厂成功 3 Open eWeLink APP, Tap ”+” and select “All devices”. Tap “Hubs” and select ZigBee Hub(Ethernet), operate following the prompt on the APP. Then tap the following device named “eWeLink_****** “. Power on Hub, Plug the Ethernet cable, Wait red LED flashes quickly 3.Hub add to appdefault : Ethernet 4.Hub add to appdefault : Ethernet Set Sub-devices to pairing mode ,Tap“ZigBee Hub”, tap “+” to pair Sub-devices into your Hub. Normal Mode No network connection Upgrade Ethernet Pair Mode AP Pair Mode Quick Pair Mode Add Sub-device Red LED keeps on Red LED flashes slowly Red LED keeps on Red LED flashes quickly Red LED flashes slowly Red LED flashes quickly Red LED keeps on Green LED keeps on Green LED keeps off Green LED flashes slowly Green LED keeps off Green LED keeps on Green LED keeps on Green LED flashes quickly This is a ZigBee Hub that allows you to control a variety of ZigBee devices by transforming Wi-Fi into ZigBee. You can remotely turn on/off or schedule connected ZigBee devices, or share it with your family to control them together. Quick pairing mode Long press pairing button until green LED keep on and red LED flashes quickly. Tap ”+” and select “Quick Pairing”. Then operate following the prompt on the APP. Compatible Pairing ModeAP Long press pairing button until green LED keep on and red LED flashes quicklyThen release the buttonLong press pairing button again until green LED keep on and red LED flashes slowly, then the Hub enters AP mode.Tap ”+” and select “Compatible mode” on the bottom. For Android systemEnter Wi-Fi password and tap “Next”. Be patient until pairing completes. For iOS systemSelect Wi-Fi SSID with ITEAD-****** and enter the password12345678, then go back to APP and tap “Next” . Be patient until pairing completes. 3 Long press pairing button about 15s red and green LED flash at the same time， when the red and green LED all keep on, release the button, waiting until the red LED flashes and green LED off, the Hub enter Factory mode. 67 11 105g铜板 四色印刷 手风琴6折页 展开:330*70 折后:55*70mm 将ZigBee 网关 插上电源，使用网线连接网关和路由器，等待红灯由慢闪变为快闪 3．添加网关（以太网方式）（默认以及推荐添加方式） 打开易微联APP，点击添加按钮+，点击【所有设备】，选择【网关类】， 点击【Zigbee网关（带网口）】点击【确认上述操作】, 在扫描界面会出现需要 配对的网关设备，点击下面的eWeLink_******的设备，等待片刻即可添加成功。 在主界面点击“网关设备”，点击【添加】，此时网关变成红灯常亮， 绿灯快闪状态，重置子设备进入配网状态，等待数秒APP会提示找到设备 本设备是一款ZigBee多功能网关，网关通过Wi-Fi转ZigBee的方式进行连接 控制多种ZigBee设备，实现远程控制该设备的开和关，设置定时和分享给您 的家人一起控制等等。 ZigBeeIEEE 802.15.4 WifiIEEE 802.11 b/g/n 2.4GHz 以太网10/100M 输 入DC 5V/1A 信号指示灯(红色) 信号指示灯(绿色) Working temperature MaterialPC Operating systemsAndroid & IOS -10~60°C Dimension76x76x23mm ZigBeeIEEE 802.15.4 WifiIEEE 802.11 b/g/n 2.4GHz Ethernet10/100M InputDC 5V/1A Pairing button Input Ethernet Port Signal indicator (red)Signal indicator (green) FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful interference in a residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and used in accordance with the instructions, maycause harmful interference to radio communications. However, there is no guarantee thatinterference will not occur in a particular installation. If this equipment does cause harmfulinterference to radio or television reception, which can be determined by turning the equipmentoff and on, the user is encouraged to try to correct the interference by one or more of thefollowing measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.

Thingscare Inc Room 512,43 Yangsan-ro, Yeongdeungpo-gu,Seoul South Korea Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-9-4 To whom it may concern: We, Thingscare Inc, hereby certify that the equipment for which authorization is sought (FCC ID: 2BKPR-TZB-100) is not “covered” equipment prohibited from receiving an equipment authorization pursuant to § 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, we are not identified on the Covered List (https://www.fcc.gov/supplychain/coveredlist) as an entity producing “covered” equipment. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(b) and (d)(5) and (6). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Sincerely, Signature ShunLong Zhang Manager Thingscare Inc 62_[model] CoveredEqu_2.911(d)(5 )(i) and (ii) - U, V03

Thingscare Inc. Room 512, 43 Yangsan-ro, Yeongdeungpo-gu, Seoul, Republic of Korea Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024/08/30 U.S. Agent Designation Thingscare Inc. acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2BKPR-TZB-100): Name and company of U.S. agent: GSS SERVICE INC Physical U.S. address of agent: 6547 N Academy Blvd #2266 Colorado Springs COLORADO 80918 United States FRN of U.S. agent: 0033402082 Email address of U.S. agent: [email protected] GSS SERVICE INC acknowledges their obligation to accept service of process on behalf of Thingscare Inc. Thingscare Inc. with the FRN [0035886548] accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature ShunLong Zhang Manager Thingscare Inc. Signature Michoux Logan PM GSS SERVICE INC 48_[mo del] US_Agent_2.911(d )(7) - U, V0 5

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2024-9-4> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2BKPR-TZB-100 TZB-100 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： ShunLong Zhang/Manager Company: Thingscare Inc Address: Room 512,43 Yangsan-ro, Yeongdeungpo-gu,Seoul South Korea Phone: +8613725846760 Fax: N/A E-Mail: [email protected]

Thingscare Inc Room 512,43 Yangsan-ro, Yeongdeungpo-gu,Seoul South Korea Date: 2024-9-4 FCC ID: 2BKPR-TZB-100 Model Number: TZB-100 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, Thingscare Inc, declare that this EUT (FCC ID: 2BKPR-TZB-100) doesn’t have Ad Hoc mode function on “non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, Name/Title： ShunLong Zhang/Manager Company: Thingscare Inc Address: Room 512,43 Yangsan-ro, Yeongdeungpo-gu,Seoul South Korea Phone: +8613725846760 Fax: N/A E-Mail: [email protected]

Thingscare Inc Room 512,43 Yangsan-ro, Yeongdeungpo-gu,Seoul South Korea Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-9-4 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2BKPR-TZB-100 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. By signing this application form, we agree to Eurofins’ current valid General Terms and Conditions (AGB),Testing and Certification Regulations (PZO) which can be viewed on following website www.eurofins.de/ee or retrieved on request. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： ShunLong Zhang/Manager Company: Thingscare Inc Address: Room 512,43 Yangsan-ro, Yeongdeungpo-gu,Seoul South Korea Phone: +8613725846760 Fax: N/A E-Mail: [email protected]

FCC ID: 2BKPR-TZB-100 External Photos of the EUT FCC ID: 2BKPR-TZB-100 FCC ID: 2BKPR-TZB-100

Label and Location Size: L: 3.0cm*W: 2.0cm Label and Location FCC ID : 2BKPR-TZB-100

FCC ID: 2BKPR-TZB-100 Internal Photos of the EUT FCC ID: 2BKPR-TZB-100 ZIGBEE ANT FCC ID: 2BKPR-TZB-100 WIFI ANT

RF Exposure evaluation FCC ID: 2BKPR-TZB-100 Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Mobile Device 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2. Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Antenna Information TZB-100 can only use antennas certificated as follows provided by manufacturer; Antenna No. Model No. of antenna: Type of antenna: Gain of the antenna (Max.) Frequency range: Zigbee / PCB antenna 0.52dBi for 2400-2500MHz; 2.4GWIFI / PCB antenna 0.68dBi for 2400-2500MHz 5. Manufacturing Tolerance Zigbee GFSK(Peak) Channel Channel 11 Channel 18 Channel 26 Target (dBm) -2.0 -2.0 -2.0 Tolerance ±(dB) 1.0 1.0 1.0 WIFI(Peak) Frequency (MHz) 11b 2412 2437 2462 Target (dBm) 14.0 12.0 11.0 Tolerance ± (dB) 1.0 1.0 1.0 Frequency (MHz) 11g 2412 2437 2462 Target (dBm) 13.0 12.0 11.0 Tolerance ± (dB) 1.0 1.0 1.0 Frequency (MHz) 11n(HT20) 2412 2437 2462 Target (dBm) 13.0 12.0 11.0 Tolerance ± (dB) 1.0 1.0 1.0 6. Standalone MPE Result As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of the used antenna is refer to section, the RF power density can be obtained. Modulation Type Output power Antenna Gain (dBi) Antenna Gain (linear) MPE (mW/cm 2 ) MPE Limits (mW/cm 2 ) dBm mW Zigbee -1.0 0.7943 0.52 1.1272 0.0002 1.0000 2.4GWIFI 15.0 31.6228 0.68 1.1695 0.0074 1.0000 Remark: 1. Output power (Peak) including turn-up tolerance; 2. MPE evaluate distance is 20cm from user manual provide by manufacturer. 7. simultaneous MPE Result 2.4GWIFI MPE (Ratio) Zigbee MPE (Ratio) simultaneous MPE (Ratio) MPE Limits (Ratio) 0.0074 0.0002 0.0076 1.0000 8. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device. ----------------THE END OF REPORT---------------

1. Antenna Description: Antenna type PCB antenna Model TZB-100 Frequency range 2400-2500MHz Manufacturer Shenzhen easyiot Technology Co., Ltd ANT Peak Gain 0.68 dBi 2. Antenna Photo: Length: 10mm Width: 5mm 3. Test Equipment & Conditions 3.1 Test instrument VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. 3.2 Test environment and methods 4．Antenna Radiation Pattern 2400MHz 2450MHz 2500MHz

1. Antenna Description: Antenna type PCB antenna Model TZB-100 Frequency range 2400-2500MHz Manufacturer Shenzhen easyiot Technology Co., Ltd ANT Peak Gain 0.52 dBi 2. Antenna Photo: Length: 10mm Width: 4mm 3. Test Equipment & Conditions 3.1 Test instrument VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. 3.2 Test environment and methods 4．Antenna Radiation Pattern 2400MHz 2450MHz 2500MHz

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ........................................... : CTA24072501101 2BKPR-TZB-100 Compiled by ( position+printed name+signature) .. : File administrators Jinghua Xiao Supervised by ( position+printed name+signature) .. : Project Engineer Xudong Zhang Approved by ( position+printed name+signature) .. : RF Manager Eric Wang Date of issue ..................................... : Aug. 01, 2024 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Applicant’s name ............................ : Thingscare Inc. Address ............................................ : Room 512, 43 Yangsan-ro, Yeongdeungpo-gu, Seoul, Republic of Korea Test specification ...........................: Standard ........................................... : FCC Part 15.247 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Equipment description ................... : TOO Zigbee Hub Trade Mark ....................................... : TOO Manufacturer .................................... : Shenzhen easyiot Technology Co., Ltd Model/Type reference....................... : TZB-100 Listed Models .................................. : N/A Modulation ....................................... : OQPSK Frequency .......................................... 2405-2480MHz Ratings ............................................. : DC 5.0V From external circuit Result................................................ : PASS Report No.: CTA24072501101 Page 2 of 36 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : TOO Zigbee Hub Model /Type : TZB-100 Listed Models : N/A Applicant : Thingscare Inc. Address : Room 512, 43 Yangsan-ro, Yeongdeungpo-gu, Seoul, Republic of Korea Manufacturer : Shenzhen easyiot Technology Co., Ltd Address : 409, Block A, Building 1, Ruishangju, Guxing Community, Xixiang Subdistrict, Shenzhen Bao'an District, Guangdong Province, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA24072501101 Page 3 of 36 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 T E S T S T A N D A R D S .................................................................. 4 2 S U M M A R Y ............................................................................. 5 2.1 General Remarks 5 2.2 Product Description* 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 6 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T ............................................................... 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ............................................ 11 4.1 AC Power Conducted Emission 11 4.2 Radiated Emissions and Band Edge 14 4.3 Maximum Peak Output Power 21 4.4 Power Spectral Density 22 4.5 6dB Bandwidth 24 4.6 Out-of-band Emissions 26 4.7 Antenna Requirement 30 T E S T S E T U P P H O T O S O F T H E E U T ................................................... 31 5 P H O T O S O F T H E E U T ............................................................. 32 Report No.: CTA24072501101 Page 4 of 36 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 V05r02: Guidance for Performing Compliance Measurements on Digital Transmission Systems (DTS) Operating Under §15.247 Report No.: CTA24072501101 Page 5 of 36 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Jul. 25, 2024 Testing commenc…
