2BKZ2-WI01Wireless Charger

-- Reorient or relocate the receiving antenna.

Shenzhen Sanyou Technology Co., LTD Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 09-25-2024 FCC ID: 2BKZ2-WI01 Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing (Shenzhen Sanyou Technology Co., LTD) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing (Shenzhen Sanyou Technology Co., LTD) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Applicant: Shenzhen Sanyou Technology Co., LTD Address: 303, 3rd Fl., Bldg. 2, Dayang Industrial Park, No.4 Industrial Avenue, Fuhai St., Bao'an Dist., Shenzhen, China Contact Person: Liu Ji jin Tel.: 0755-23056169 Email: [email protected] Sincerely, Signature:

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 Shenzhen Sanyou Technology Co., LTD Date：09/25/2024 Product Model Number: WI01, WIXX(X stands for 0-9) FCC ID：2BKZ2-WI01 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that ORGANIZATION. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by ORGANIZATION. on our behalf shall have the same effect as acts of our own. By: Liu Ji jin Contact Listed on FCC Wesbite Title: CEO Email: [email protected] On behalf of: Shenzhen Sanyou Technology Co., LTD

Shenzhen Sanyou Technology Co., LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: September 25, 2024 Subject; Request for Confidentiality FCC ID: 2BKZ2-WI01 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Liu Ji jin Title: CEO

Page 1 of 4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address: 东莞市石碣镇西沙路 2 号 Tel ： 86-076986018114Fax ： 86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 东莞市金赞智能科技有限公司 产品规格书 PRODUCTSPECIFICATION 拟制 PREPAREDBY 跟单员 MERCHANDISER 工程审核 ENGINEER CHECKEDBY 批准 APPROVEDBY 严慧琳 客户： CUSTOMER:____________________________________________________________________ 客户料号： CUSTP/N:____________________________________________________________________ 金赞料号：J30-000226-001 KCP/N:____________________________________________________________________ 产品型号：20.5*39.5*0.08*80P*10TS*20MM DESE: 日期：2024.6.24 DATE:____________________________________________________________________ 版本：A.0 VERSION:____________________________________________________________________ （客户承认受领印）ACCEPTANCESTAMP Pageof 4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address:东莞市石碣镇西沙路2号Tel：86-076986018114Fax：86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 20.5*39.5*0.08*80P*11TS*20M M 拟制 PREPAREDBY 工程审核 ENGINEERCHECKEDBY 2 版本 Rev. 变更前 BeforeChange 变更后内容 DESCRIPTION(ContentOrReasonForChanged) 日期 Date 修订者 Revisor A.0--新发行（InitialRelease）2024/6/24严慧琳 Pageof 4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address:东莞市石碣镇西沙路2号Tel：86-076986018114Fax：86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 20.5*39.5*0.08*80P*10TS*20M M 拟制 PREPAREDBY 工程审核 ENGINEERCHECKEDBY 3 1.产品外形尺寸（OVERALLDIMENSIONSOFPRODUCTS): 单位(Unit):毫米(mm) 圈数 Turn s 线径 WireDia. 绕线方式疏/密 Wdg.Type Spred/Close 绕线方向 Wdg.Direction 相交是/否 Intersect Yes/Not 线圈正/反贴 Coil Positive/AntiPaste 10TS 0.08*80P热风绞线 （Strandedwire） 密绕（Close） 逆时针 （Anticlockwise） 是（Yes）反贴（Anti/-Paste） 所有材料要求合格ROHS标准 ABCDEFGH 15±0.520.5±0.539.5±0.543.5±0.53±120±10.95±0.052.15±0.2 Black heat shrink tubing 3M double-sided tape PS: 1. (F) The length of the outer magnetic lead; 2. (H) Includes incoming wire, not release paper; 3. First, thread the thin black heat shrink sleeve, and then press the wire with a stop machine. Then, thread the wire through the sleeve to the bend and to the end. All materials are required to be ROHS compliant Operation frequency: 113kHz-205kHz Antenna Type: Loop coil Antenna Antenna gain: 0dBi Pageof 4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address:东莞市石碣镇西沙路2号Tel：86-076986018114Fax：86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 20.5*39.5*0.08*80P*10TS*20M M 拟制 PREPAREDBY 工程审核 ENGINEERCHECKEDBY 4 2.电气特性（ELECTRICALCHARACTERISTICS): 温度TEMPERATURE:25±10°C,湿度RELATIVEHUMIDITY:65±10% 序号 NO. 项目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TESTFREQUENCY 测试仪器 TESTEQUIPMENTS 1INDS-F ：7.7uH±10% 100kHz/1VLCZMETER1062 2DCRS-F ：65mΩMAX /LCZMETER1062 3Q值S-F ：60MIN 100kHz/1VLCZMETER1062 3. 材料清单（BILLOFMATERIAIS): 序号 NO. 材料名称 Materialname 品名描述 Description 物料代码 MaterialCode 厂商代码 Vendorcode 1 / / 2 GCP-T-00298HYT 3 GCP-T-00305 LX 4 SMJ-3M-00079 HWD 5 SMJ-T-0082HWD 6 3mm JRM 7 E7202WHZY 8 XC 9 9MM*Ф1.5 // Coil and disc Resistance Q value Wire rod 0.08*80P hot air stranded cable Large diskette minicycle Hard magnetic circle 15*0.7H without holes or slots G43.5±0.5*5.3*0.8H with double groove with hole, the middle small groove 3MM 3M double-sided tape 42*5.3*0.12H 3M9448A with hole and hand tear Small double-sided tape Round ordinary double-sided tape 13*0.08H with hand tear Gold finger tape High temperature adhesive paper 3MM glue JS-E7202 (thickened) white glue Tin bar Environmentally friendly lead-free solder bar Lead-free high Black heat shrink tubing thin temperature tin strip

Page 1 of 4 Report No.: FCS202409213 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: WI01 Photo 1 Photo 2 Page 2 of 4 Report No.: FCS202409213 Photo 3 Photo 4 Page 3 of 4 Report No.: FCS202409213 Photo 5 Photo 6 Page 4 of 4 Report No.: FCS202409213 Photo 7 Photo 8

Label Size: L40mm * W30mm 1. The label is silk-screen on the sample 15W Wireless Charger Model Name: WI01 FCC ID: 2BKZ2-WI01

Page 1 of 3 Report No.: FCS202409213 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: WI01 Photo 1 Photo 2 Loop Antenna Page 2 of 3 Report No.: FCS202409213 Photo 3 Photo 4 Page 3 of 3 Report No.: FCS202409213 Photo 5

FCC Test Report Report No: FCS202409213W02 Issued for Applicant: Shenzhen Sanyou Technology Co., LTD Address: 303, 3rd Fl., Bldg. 2, Dayang Industrial Park, No.4 Industrial Avenue, Fuhai St., Bao'an Dist., Shenzhen, China Product Name: Wireless Charger Brand Name: N/A Model Name: WI01 Series Model: WIXX(X stands for 0-9) FCC ID: 2BKZ2-WI01 Issued By: Flux Compliance Service Laboratory Add: Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com Page 2 of 31 Report No.: FCS202409213W02 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com TEST RESULT CERTIFICATION Applicant’s Name ................... : Shenzhen Sanyou Technology Co., LTD Address .................................. : 303, 3rd Fl., Bldg. 2, Dayang Industrial Park, No.4 Industrial Avenue, Fuhai St., Bao'an Dist., Shenzhen, China Manufacture's Name .............. : Shenzhen Sanyou Technology Co., LTD Address .................................. : 303, 3rd Fl., Bldg. 2, Dayang Industrial Park, No.4 Industrial Avenue, Fuhai St., Bao'an Dist., Shenzhen, China Product Description Product Name ........................ : Wireless Charger Brand Name ......................... : N/A Model Name .......................... : WI01 Series Model .......................... : WIXX(X stands for 0-9) Test Standards ....................... : FCC CFR 47 PART 1, § 1.1310 KDB 680106 D01 Wireless Power Transfer v04 This device described above has been tested FCS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of FCS, this document may be altered or revised by FCS, personal only, and shall be noted in the revision of the document.. Date of Test .............................. : Date (s) of performance of tests : 07 Sep., 2024 ~ 13 Sep., 2024 Date of Issue ............................. : 13 Sep., 2024 Test Result ................................. : Pass Tested by : (Scott Shen) Reviewed by : (Duke Qian) Approved by : (Jack Wang) Page 3 of 31 Report No.: FCS202409213W02 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com Table of Contents Page 1. TEST FACTORY 5 2. GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF THE EUT 6 3 TEST METHODOLOGY 7 3.1 MEASURING STANDARD 7 3.2 REQUIREMENTS 7 3.1 LIMITS 7 3.2 TEST SETUP 8 3.3 TEST PROCEDURE 8 4 EQUIPMENT APPROVAL CONSIDERATIONS 9 4.1 DESCRIPTION OF THE TEST MODE 10 4.2 PERIPHERAL LIST 10 4.3 TEST INSTRUMENTS LIST 10 4.4 DUTY CYCLE 11 4.5 TEST RESULT 12 4.6 TEST SETUP PHOTO 13 Page 4 of 31 Report No.: FCS202409213W02 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com Revision History Rev. Issue Date Effect Page Contents 00 13 Sep., 2024 ALL Initial Issue Page 5 of 31 Report No.: FCS202409213W02 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com 1. TEST FACTORY Company Name: Flux Compliance Service Laboratory Address: Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Telephone: +86-769-27280901 Fax: +86-769-27280901 FCC Test Firm Registration Number: 514908 Designation number: CN0127 A2LA accreditation number：5545.01 CNAS: L15566 Page 6 of 31 Report No.: FCS202409213W02 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name Wireless Charger Trade Name N/A Model Name WI01 Series Model WIXX(X stands for 0-9) Model Difference Only different of model name. Operation frequency 113kHz-205kHz Modulation Technology ASK Antenna Type Loop coil antenna Antenna gain 0dBi Power Supply Input: DC12V-2A, 9V-2A, 5V-2A Output: 15W/10W/7.5W/5W Hardware version number V1.0 Software version number V1.0 Connecting I/O Port(s) Please refer to the User's Manual Page 7 of 31 Report No.: FCS202409213W02 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com 3 TEST METHODOLOGY 3.1 Measuring Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. According KDB680106 D01: KDB 680106 D01 Wireless Power Transfer v04. 3.2 Requirements According to the item 3 of KDB 680106 D01v04: Inductive wireless power transfer applications that meet all of the following requirements are excluded from submitting an RF exposure evaluation. (1) Mobile Device and Portable Device Configurations (2) Equipment Authorization Procedures for Devices Operating at Frequencies Below 4 MHz (3) The aggregate H-field strengths anywhere at or beyond 15 cm surrounding the device, and 20 cm away from the top surface. 3.1 Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.130…
