2BKZEHLIGM1GWireless induction alarm Radar Motion Alarm System

installation instructions Camping safety box 1 installation group 2 way to install 3 method of application Single key switch In the shutdown state, hold down the power button of the host/probe. If the status indicator blinks blue, the device is powered on successfully. Press and hold the power button of the host/probe when the device is powered on. If the status indicator blinks red, the device is powered off successfully. Pair and delete Press the numeric keypad (1-6) to select the channel. If the keyboard indicator blinks yellow, it indicates selected. Click the host pairing button. When the status indicator blinks yellow, release the button. Press the probe number button (1-6) that you want to delete. If the keyboard indicator blinks yellow, the probe number is selected. If the host status indicator blinks yellow, the host status indicator blinks red, the probe number is successfully deleted. zone setting After the probe is installed, press the corresponding probe number button, click the setting button after the keyboard light blinks yellow, and the host light blinks yellow to enter the setting mode. 3. 2. 1. paper-cover： Installation height 0.5-1.5 meters, 1.2 meters recommended; Pedestrian detection distance (front and rear) 10 meters; Vehicle detection distance (front and rear) 15 meters; The detection distance of the left and right sides (one side) is about 3 meters. angle mount： The installation Angle is recommended to be 30°, 2 meters; Pedestrian detection distance (front and rear) 12 meters Vehicle detection distance (front and rear) 15 meters left and right side detection distance (side) about 3 meters 4 5 Notification Forced reset Warning After the radar detects the target, the host alarm light blinks blue and emits an alarm bell, and the corresponding probe keyboard light blinks red. 1. Low battery lindication When the probe battery is low, the corresponding keyboard indicator is steady yellow. 2. Lost hint The probe is abnormally shut down, and the corresponding keyboard indicator is steady red when the signal is lost. 3. Battery status Press the probe/host power button to activate the power indicator. 4. If the device fails to turn on and off normally and respond to operation for unknown reasons, use a card pin or similar pointed object to trigger the bottom reset key to forcibly shut down the device. 6 Product Parameter Itemdescription product model host：HLIZT probe：HLIZx Power cable specification TypeC charge modeSwitch step-down charging Rated charging voltage(V) 5 rated power（W） 5.5 operating frequency 433.92MHz Host board controls the distance range 100m Probe plate detection range20 meters straight ahead, 3 meters on each side Maximum operating current of the host （battery voltage4.1V） Probe maximum operating current （battery voltage4.1V） type of batteryTinfoil coated lithium battery battery capacity 3000mhA time of endurance More than 24 hours temperature range Charging:0-45°C Discharging:- 20-45°C humidity range Operating humidity range: less than75% RH Storage humidity: less than75% RH 7 safety information Before using and operating the equipment, to ensure the best performance of the equipment and to avoid dangerous or illegal situations, please review and follow all safety information Please use this product in the temperature range of 0°C-35°C, store this product in the -20°C-+45°C pattern. The power plug is used as a disconnecting device. For pluggable devices, the power socket should be installed near the product and should be easy to operate. [Warning] There is a risk of fire or explosion if the battery is replaced with an incorrect model. Do not expose batteries to high temperatures or near hot products, such as space heaters, microwaves, ovens, or water heaters. Overheating of the battery may cause an explosion. Do not throw the battery into the fire, otherwise it will cause the battery to catch fire and explode Do not drop, squeeze or puncture the battery, so that the battery is not subjected to large external pressure Resulting in internal short circuit and overheating of the battery. Do not disassemble or modify the battery, insert foreign objects, immerse in water or other liquids to avoid ignition Cause battery leakage, overheating, fire or explosion. Please dispose of the battery according to local regulations, do not dispose of the battery as domestic waste. If cell Improper storage may cause the battery to explode. This device uses a non-removable built-in battery. Do not replace the battery yourself to avoid failure The standby fails to work properly or the battery is damaged. Do not use power fittings in wet areas, such as near sinks, bathtubs or showers Do not plug and remove the power adapter with wet hands Use of unauthorized or incompatible power adapters or batteries may cause fire, explosion Or other dangers. 8 FCC Statement The human body moves forward at a constant speed within the probe detection range according to the action track. After returning to the starting point, press the setting button. The green light of the indicator indicates that the setting is successful. Remote standby When the probe is on, short press the probe number button (1-6) that you want to turn off. The yellow light of the keyboard indicator indicates that it is selected. Long press the probe switch button under the main engine until the yellow light of the main engine status indicator blinks to release. In the standby state, repeat the above process, and the green light of the host status indicator indicates that the probe is on. 4.4. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to ra…

Text truncated - open the document above for the full version.

ShenzhenNoahAnzhouprotectiontechnologyCo.,LTD Address ： 705,Floor7,HongyuBuilding,IntersectionofChangyongRoadandLongguanAvenue,Longhua District,Shenzhen,Guangdong,China Rev1/26/2023 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:2026-01-15 Ref:AttestationStatementsPart2.911(d)(5)(i)Filing FCCID:2BKZEHLIGM1G ShenzhenNoahAnzhouprotectiontechnologyCo.,LTDcertifiesthattheequipmentforwhich authorizationissoughtisnot“covered”equipmentprohibitedfromreceivinganequipment authorizationpursuanttosection2.903oftheFCCrules. ShenzhenNoahAnzhouprotectiontechnologyCo.,LTD certifiesthattheequipmentforwhich authorizationissoughtdoesnotincludecybersecurityoranti-virussoftwareproducedorprovidedby KasperskyLab,Inc.oranyofitssuccessorsandassignees,includingequipmentwithintegratedKaspersky Lab,Inc.(oranyofitssuccessorsandassignees)cybersecurityoranti-virussoftwarepursuanttoDA-24- 886andKDB986446D01CoveredEquipmentGuidancesectionB(2a). Deviceisinherentlycompliantbasedonhardwarelimitationsorsoftwarecontrols. or ASoftwareBillofMaterials(SBOM)isprovidedtotheTCBforreview,and Theend-userorthirdpartiescannotinstalladditionalsoftwareonthisdevice. Sincerely, (Applicantsignature) (WenhaoYu) ShenzhenNoahAnzhouprotectiontechnologyCo.,LTD Address ： 705,Floor7,HongyuBuilding,IntersectionofChangyongRoadandLongguanAvenue,Longhua District,Shenzhen,Guangdong,China Rev1/26/2023 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:01-15-2026 Ref:AttestationStatementsPart2.911(d)(5)(ii)Filing FCCID:2BKZEHLIGM1G ShenzhenNoahAnzhouprotectiontechnologyCo.,LTDcertifiesthat,asofthedateofthefilingof theapplication,theapplicantisnotidentifiedontheCoveredList(asaspecificallynamedentityorany ofitssubsidiariesoraffiliates)asanentityproducing“covered”equipment. Sincerely, (Applicantsignature) (WenhaoYu)

ShenzhenNoahAnzhouprotectiontechnologyCo.,LTD Address ： 705,Floor7,HongyuBuilding,IntersectionofChangyongRoadandLongguanAvenue, LonghuaDistrict,Shenzhen,Guangdong,China Date:2026-01-15 FederalCommunicationsCommission AuthorizationandEvaluationDivision 1435OaklandMillsRoad Columbia,MD21046 Ref:AttestationStatementsPart2.911(d)(7)Filing SUBJECT:FCCApplicationforFCCID:2BKZEHLIGM1G,FRN:0035933829 ShenzhenNoahAnzhouprotectiontechnologyCo.,LTDcertifiesthat,asofthedateofthe filingoftheapplication,LuxeLaneE-trading,LLCisourdesignatedU.S.agentforserviceof processfortheabovereferencedFCCID.ShenzhenNoahAnzhouprotectiontechnologyCo., LTDacceptstomaintainanagentfornolessthanoneyearafterthegranteehasterminated allmarketingandimportationortheconclusionofanyCommission-relatedproceeding involvingtheequipment. LuxeLaneE-trading,LLCaccepts,asofthedateofthefilingoftheapplication,theobligation ofthedesignatedU.S.agentforserviceofprocessfortheabovereferencedFCCID. DesignatedU.S.AgentInformation: Name:LuxeLaneE-trading,LLC Address:6519TAMARINDSKYLNFULSHEAR,TX77441UnitedStates FRN:0036352755 ContactPerson:YUANSU Tel.:(713)568-5923 Email:[email protected] Sincerely, SignedonbehalfofSignedonbehalfof ShenzhenNoahAnzhouprotection technologyCo.,LTD LuxeLaneE-trading,LLC Name:WenhaoYu Name:YUANSU Title:ManagerTitle:Manager Signature:Signature: Date:2026-01-15Date:2026-01-15

Guangzhou Cambrian electronic Technology Co., LTD CA-S01_V01 1 Antenna specification PN: CA-S01 NB-IOT B5 B8 /Lora/ Sub-1g/ UHF Antenna Guangzhou Cambrian electronic Technology Co., LTD Address: Building 1#, Hongda Business Creative Park, No. 96 Yuanxiang Road, Yunpu Street, Huangpu District, Guangzhou CA-S01_V01 2 Specialty 1. Si]e15.0 X 3.0 X 1.0 mm 3 。 2. Low energy loss, high antenna efficiency. 3. High stability in the case of temperature and humidity changes. Apply 1. NB-IoT B5 B8 $QAntenna applications in frequency bands 2. Lora 915M 868M 490M 433MHz Antenna applications in frequency bands。 3. Sub-1 g 915M 868M 490M 433MHz Antenna applications in frequency bands 4. UHF band (400M-800Mhz) Antenna applications in frequency bands construction 1、Antenna feed end 2、Feed identification mark 3、Antenna welding fixed end Size three viewssymbol size(mm) L 15.0±0.2 w 3.0±0.1 T 1.0±0.05 a 0.9±0.1 Guangzhou Cambrian electronic Technology Co., LTD Guangzhou Cambrian electronic Technology Co., LTD CA-S01_V01 3 electrical specification CA-S01 Specification Working Frequency 420Mh z-440Mhz Initial frequency band(GHz) 433MH z Band Width >80MHz Impedance 50Ω Gain(dBi) 2.5 VSWR <2 Operation Temperature -40°C~+85°C Antenna Type Internal Antenna The antenna operating frequency needs to be realized through impedance matching device debugging Antenna pad and wiring design PCB SCH PCB Design dimension drawing CA-S01_V01 4 CA-S01_V01 5 Test board antenna test(thickness 1.0mm) speciality VSWR speciality CA-S01_V01 6 Efficiency and radiation maps The efficiency, radiation pattern, gain and other properties are designed based on the test board. The specification and characteristic test data of the CA-S01 antenna are obtained based on the test PCB board size and the test direction shown in the figure below. The following data was obtained in ETS 3D microwave darkroom testing. + Gain and efficiency Band 433MHz Peak Gain 2.5dBi Average Gain acro ss the band 1.6dBi Gai n Range across the band 0.2dBi~2.2dBi Peak Efficiency 39.5% Average Efficiency acro ss the band 28.7% Efficiency Range across the band 12.3%~39.5% Z Y X CA-S01_V01 7 Theta @420 MHz Phi @430 MHz Total @440 MHz Solder Temperature Typical welding specifications for reliable and non-destructive welding are shown below: CA-S01_V01 8 packaging CA-S01_V01 9 Plastic carrier tape specifications (Unit:mm) Index Ao Bo Ko T W Dimension (mm) 3.3±0.1 15.5±0.1 1.3±0.1 0.3±0.05 24.0±0.3 Index E F P P0 P2 Dimension (mm) 1.75±0.1 11.0±0.1 8.0±0.1 4.0±0.1 2.0±0.1 Reel size Index A B C Dimension(mm) 330 100 13.5 Standard quantity: 2000 PCS/ disk Storage Environment The following conditions should be met when the product is stored: temperature : -10°C~+40°C humidity : 30% - 70% relative humidity Do not place the product in contact with corrosive gases, such as sulfur. Chlorine gas or acid may lead to oxidation of product electrodes resulting in poor weldability. The product should be placed in the toolbox and protected from moisture and dust. Products should be stored in the warehouse and away from heat, vibration and direct sunlight. Products should be stored in closed conditions.

ShenzhenNoahAnzhouprotectiontechnologyCo.,LTD OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:January15,2026 Subject;RequestforConfidentiality FCCID:2BKZEHLIGM1G ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthese documentsmightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantage inthemarket. SchematicDiagram BlockDiagram PartsList OperationalDescription Tune-upProcedure Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulations inTitle47CFR§2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthat businesssensitiveinformationremainsconfidentialuntiltheactualmarketingofnewly authorizeddevices,werequestShortTermConfidentialityofthefollowingattachment(s); ExternalPhotos TestSetupPhotos InternalPhotos UserManual For45days,pursuanttoPublicNoticeDA04-1705. OR For180dayspursuanttoKDB726920D01. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:WenhaoYu Title: Manager

ShenzhenNoahAnzhouprotectiontechnologyCo.,LTD Date: 2026/01/15 ProductModelNumber: HLIGM1G,LIGM2G,HLIGM3G,HLIGM4G,HLIGM5G,HLIGM6G,HLIZTG, HLITMG,RA11LV,RA01LV,RA11SM,RA11CL,RA11LD,RA01SM,RA01CL,RA01LD FCCID: 2BKZEHLIGM1G Towhomitmayconcern, Re:ProductCertificationRepresentativeAuthorizationLetter WeauthorizeQAILaboratoriesLtd.3980NorthFraserWay,BurnabyB.C.CanadaV5J5K5to actonourbehalfonallmattersconcerningtheabovenamedequipment. Thisshallincludethefollowing: Testing Approvalapplicationsandprocedures WedeclarethatQAILaboratoriesLtd.isallowedtoforwardallinformationrelatedtothe approvalprojecttotheappliedcertificationbodyandtothenotificationentitiesandtodiscuss anyissuesconcerningtheapprovalapplication.AnyandallactscarriedoutbyQAILaboratories Ltd.onourbehalfshallhavethesameeffectasactsofourown. By: Title:Manager Email:[email protected] Telephone:17600278051 Onbehalfof:WenhaoYu

ShenzhenNoahAnzhouprotectiontechnologyCo.,LTD ModelDifferent Modelname：MotionAlarmSystem FCCID:2BKZEHLIGM1G Modelnumber:HLIGM1G,LIGM2G,HLIGM3G,HLIGM4G,HLIGM5G,HLIGM6G,HLIZTG, HLITMG,RA11LV,RA01LV,RA11SM,RA11CL,RA11LD,RA01SM,RA01CL,RA01LD Allmodel’sthefunction,softwareandelectriccircuitarethesame,exceptthecolourandthe modelnumber. Name:WenhaoYu Date:2026-01-14 Title:Manager Signatureofapplicant:

FCCID:2BKZEHLIGM1G FCCID:2BKZEHLIGM1G FCCID:2BKZEHLIGM1G FCCID:2BKZEHLIGM1G

Size:50*35mm

FCCID:2BKZEHLIGM1G FCCID:2BKZEHLIGM1G Antenna

FCCID:2BKZEHLIZT1G RFExposureEvaluation AccordingtoKDB447498D01GeneralRFExposureGuidancev06andpart2.1093， UnlessspecificallyrequiredbythepublishedRFexposureKDBprocedures,standalone 1-gheadorbodyand10-gextremitySARevaluationforgeneralpopulationexposure conditions,bymeasurementornumericalsimulation,isnotrequiredwhenthe correspondingSARTestExclusionThresholdcondition(s),listedbelow,is(are)satisfied. For100MHzto6GHzandtestseparationdistances≤50mm,the1-gand10-gSARtest exclusionthresholdsaredeterminedbythefollowing: [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparationdistance, mm)]·[√f (GHz) ]≤3.0for1-gSAR,and≤7.5for10-gextremitySAR,where f (GHz) istheRFchanneltransmitfrequencyinGHz PoweranddistanceareroundedtothenearestmWandmmbeforecalculation Theresultisroundedtoonedecimalplaceforcomparison EIRP=E Meas +20log(d Meas )-104.7 EIRPistheequivalentisotropicallyradiatedpower,indBm E Meas isthefieldstrengthoftheemissionatthemeasurementdistance,indB μ V/m d Meas isthemeasurementdistance,inm Here, For433.92MHz SoaSARtestisnotrequired Freque ncy (MHz) Field strength (dBuV/ m) Max Power (dBm) Target power W/ tolerance (dBm) Maxtune uppower tolerance (dBm) Max Power (mW) Min. Distance (mm) Calc. thresholds limit 433.9270.44-24.76 -24±1 -230.0055.000.00066 3.0

ShenzhenDLTestingTechnologyCo.,Ltd.ReportNo.:DLE-260108010R TestReportTel:400-688-3552Web:www.dl-cert.comEmail:[email protected] 1 of 29 FCCPart15CTestReport FCCID:2BKZEHLIGM1G Applicant:ShenzhenNoahAnzhouProtectionTechnologyCo.,Ltd Address: 705,Floor7,HongyuBuilding,IntersectionofChangyongRoadandLongguanAvenue, LonghuaDistrict,Shenzhen,Guangdong,China Manufacturer:ShenzhenNoahAnzhouProtectionTechnologyCo.,Ltd Address: 705,Floor7,HongyuBuilding,IntersectionofChangyongRoadandLongguanAvenue, LonghuaDistrict,Shenzhen,Guangdong,China ProductName:WirelessinductionalarmRadarMotionAlarmSystem TradeMark: LETWESAF ModelNumber: HLIGM1G,LIGM2G,HLIGM3G,HLIGM4G,HLIGM5G,HLIGM6G,HLIZTG,HLITMG, RA11LV,RA01LV,RA11SM,RA11CL,RA11LD,RA01SM,RA01CL,RA01LD DateofReceipt:Dec.25,2025 TestDate:Dec.25,2025-Jan.09,2026 DateofReport:Jan.09,2026 PreparedBy:ShenzhenDLTestingTechnologyCo.,Ltd. Address: 101-201,ComprehensiveBuilding,TongzhouElectronicsLonggangFactoryArea,No.1 BaolongFifthRoad,BaolongCommunity,BaolongStreet,LonggangDistrict,Shenzhen, China Applicable Standards: FCCPART15C15.231 ANSIC63.10:2020 TestResult:Pass ReportNumber:DLE-260108010R Prepared(TestEngineer):PxingHuang Reviewer(Supervisor):JackBu Approved(Manager):JadeYang Thistestreportisbasedonasingleevaluationofonesampleofabovementionedproducts.Itisnotpermittedto beduplicatedinextractswithoutwrittenapprovalofShenzhenDLTestingTechnologyCo.,Ltd. ShenzhenDLTestingTechnologyCo.,Ltd.ReportNo.:DLE-260108010R TestReportTel:400-688-3552Web:www.dl-cert.comEmail:[email protected] 2 of 29 TableofContentsPage 1.SUMMARYOFTESTRESULTS...............................................................................4 1.1MEASUREMENTUNCERTAINTY....................................................................................4 2.GENERALINFORMATION........................................................................................5 2.1GENERALDESCRIPTIONOFEUT................................................................................5 2.2DESCRIPTIONOFTESTMODES....................................................................................5 2.3BLOCKDIGRAMSHOWINGTHECONFIGURATIONOFSYSTEMTESTED............6 2.4DESCRIPTIONOFSUPPORTUNITS(CONDUCTEDMODE)......................................6 2.5TABLEOFPARAMETERSOFTESTSOFTWARESETTING......................................6 2.6EQUIPMENTSLISTFORALLTESTITEMS.................................................................7 3.EMCEMISSIONTEST...............................................................................................8 3.1CONDUCTEDEMISSIONMEASUREMENT....................................................................8 3.1.1POWERLINECONDUCTEDEMISSIONLimits.....................................................8 3.1.2TESTPROCEDURE.................................................................................................8 3.1.3DEVIATIONFROMTESTSTANDARD....................................................................8 3.1.4TESTSETUP.............................................................................................................9 3.1.5EUTOPERATINGCONDITIONS.............................................................................9 3.1.6TESTRESULTS........................................................................................................9 3.2RADIATEDEMISSIONMEASUREMENT.....................................................................12 3.2.1RADIATEDEMISSIONLIMITS.............................................................................12 3.2.2TESTPROCEDURE...............................................................................................13 3.2.3DEVIATIONFROMTESTSTANDARD..................................................................13 3.2.4TESTSETUP.........................................................................................................14 3.2.5EUTOPERATINGCONDITIONS...........................................................................15 3.2.6TESTRESULTS(BETWEEN9KHZ–30MHZ)....................................................16 3.2.7TESTRESULTS(BETWEEN30MHZ–1GHZ).....................................................17 3.2.8TESTRESULTS(1GHZTO10 TH HARMONICS)..................................................20 4.BANDWIDTHTEST.................................................................................................21 4.1APPLIEDPROCEDURES/LIMIT.................................................................................21 4.2TESTPROCEDURE..................................................................................................21 4.3DEVIATIONFROMSTANDARD...............................................................................21 TESTSETUP..................................................................................................................21 4.4EUTOPERATIONCONDITIONS..............................................................................21 4.5TESTRESULTS.......................................................................................................22 5.CALCULATIONOFAVERAGEFACTOR................................................................23 5.1APPLIEDPROCEDURES/LIMIT.................................................................................23 5.2TESTPROCEDURE..................................................................................................23 5.3TESTSETUP..............................................................................................................23 ShenzhenDLTestingTechnologyCo.,Ltd.ReportNo.:DLE-260108010R TestReportTel:400-688-3552Web:www.dl-cert.comEmail:[email protected] 3 of 29 TableofContentsPage 5.4EUTOPERATIONCONDITIONS..............................................................................23 5.5TESTRESULTS.........................................................................................................24 6.TRANSMISSIONCEASETIME...............................................................................27 6.1APPLIEDPR…
