2BLAU-ATWR-V4wireless wrist receiver device

USER MANUAL – ARMILLA WRIST RECEIVER – MODEL ARWR-V4 1 | P a g e Table of Contents 1. Introduction to the Armilla System ......................................................................................... 2 2. How to Power ON the Command Center ................................................................................ 2 3. How to Power ON a Wristband Device ................................................................................... 2 4. How to use the System for the First Time ............................................................................... 2 4.1 Setting-up your account and registering the tablet(s)....................................................... 2 4.2 Creating your Play Library ............................................................................................... 3 4.3 Configuring your tablet .................................................................................................... 3 4.4 Pairing Wristband Devices ............................................................................................... 3 4.5 Assigning a player name to each device (optional) .......................................................... 3 5. Starting a Game ....................................................................................................................... 4 6. Using Two Tablets .................................................................................................................... 4 7. Using the System in the Rain ................................................................................................... 4 8. Using the Wristband Devices in Cold Conditions .................................................................... 4 9. User Manual Information for Certified Device ........................................................................ 5 USER MANUAL – ARMILLA WRIST RECEIVER – MODEL ARWR-V4 2 | P a g e 1. Introduction to the Armilla System Thank you for purchasing the Armilla Tech system designed to improve communication between the coach and players during games and in training. The following system combinations are available: A. NAME: 1 Tablet System One tablet for the coach directing both the offence and defense plays during games/training, and up to 22 wristband devices for players. B. NAME: 2 Tablet System Two tablets for two coaches, one coach directing the offence, one coach directing the defense during the game/training, and up to 22 wristband devices for players. 2. How to Power ON the Command Center Press and hold the power button for 2-3 seconds – the command centre should power up. 3. How to Power ON a Wristband Device Press and hold the power button for 2-3 seconds – the wristband device will power up and vibrate. The screen will display the: 1. Device ID 2. Player Name (once assigned) 3. FW version 4. Start message: “NO TABLET PAIRED” or “TABLET: FFFFnnnn WAITING TO PLAY” 4. How to use the System for the First Time Before using your new system for first time there are a few steps that need to be completed: user account setup, tablet(s) registration, play library creation as well as pairing the wristband devices with the tablet through the Armilla mobile app. 4.1 Setting-up your account and registering the tablet(s) 1. Call Armilla Tech to create a new user account and provide the tablet’s IMEI number. 2. Once a new account has been created, Armilla will provide the credentials to log into the Armilla Web Portal https://armillatech.com/portal and the Armilla mobile app already installed on the tablet. 3. Login on the web portal with the given username and password 4. Select and pay for an Annual Subscription. 5. Register the tablet by having the tablet IMEI number ready (found on label in the back of the tablet or on the Login page in the Armilla mobile app) USER MANUAL – ARMILLA WRIST RECEIVER – MODEL ARWR-V4 3 | P a g e 6. Specify the type of usage for the tablet: “Offence only”, “Defense only” or “Offence & Defense”. The web portal should confirm the registration. 4.2 Creating your Play Library On the Web Portal, use the “Play Sheet / Play Library” to download templates, customize and upload your custom Play library or Constructive Play sheet in a .csv file format. 4.3 Configuring your tablet 1. Power ON the tablet 2. Configure Wi-Fi to provide internet connection to the tablet. 3. The log into the Armilla mobile app 4. On the Play Library tab, click the “+” icon to add Play Libraries by selecting “Import from the portal”, “Import from a file” or “Add a new play”. 4.4 Pairing Wristband Devices The wristband devices need to be paired with the tablet before starting a game. Before giving the wristband devices to the players, first power on all devices and use the Armilla mobile app to pair them. 1. Open Armilla mobile app and login with the provided credentials. 2. On the Devices tab, click the “+” icon and select “Pair new devices”. 3. Place up to four (4) wristband devices in pairing mode by double pressing the power button. You have 30 seconds to pair the device. 4. On the tablet click “Stat Scan” and the tablet will list all wristband devices in pairing mode. 5. Select one wristband device in the list and click “Connect”. The color of the icon will turn from grey to green if paring is successful. 6. Repeat 5 for all wristband devices in the list. 7. Repeat steps 3-6 until all your wristband devices are paired with the tablet. 4.5 Assigning a player name to each device (optional) You can assign a player name to each wristband device in the “Devices” tab. Select a device and hold to open a pop-up menu. Select “Edit Device Information”, here you may input the name of the player that will be using this device. The name will be sent to the wristband device and displayed. Distribute the wristband devices to the players as per the name on the screens. Now you are ready to start a game. USER MANUAL – ARMILLA WRIST RECEIVER – MODEL ARWR-V4 4 | P a g e 5. Starting a Game 1. On the Games ta…

Text truncated - open the document above for the full version.

3505 Francis Circle Alpharetta, GA 30004 PH: 770-740-0717 Fax: 770-740-1508 www.ustech-lab.com SDoC Attestation Letter Date: September 10, 2024 Subject: SDoC Attestation Letter: FCC ID: 2BLAU-ATWR-V4 The following equipment meets FCC Part 15 Subpart B SDoC Requirements for digital device: Responsible Party: Armilla Tech Ltd 2159 Salmon River Rd, Salmon Arm, BC, V1E 3H7 Responsible Party Contact Person: Lance Heron, CEO Equipment: Wrist receiver Model: ATWR-V4 Sincerely, By: __________________________ ___George Yang__- Agent (Signature/Title) (Print name)
