2BLB8-BS-300Manual Controller

平板遥控器（零重力）-15键 -BS300A(Kanes)说明书 Instruction Manual for Flat Panel Remote Control (Zero Gravity) - 15 Keys - BS300A (Kanes) Remote Control Button Function Description 遥控器按键功能说明 1. 按键配码说明（Button Pairing Instructions）： 中文：把控制盒上电，控制盒内会有灯光闪烁，在 10 秒内同时按手柄上的同升和同降键 3-5s 左右，背光灯闪烁，在和控制盒配对后成功蜂鸣器响 2 声。背光停止闪烁，配对成功。 English：Power on the control box, and the indicator light inside will flash. Within 10 seconds, press and hold the Up All and Down All buttons on the remote simultaneously for about 3-5 seconds. The backlight will flash, and a 2-beep confirmation sound will play once pairing with the control box is successful. The backlight will stop flashing to indicate pairing completion. 2. 按键控制说明（Button Operation Instructions）： （1）中文：长按头部上升按键头部电机伸出，松开按键停止；长按头部下降按键头部电机 收回，松开按键停止； English：Press and hold the Head Up button to extend the head motor; release to stop. Press and hold the Head Down button to retract the head motor; release to stop. （2） 中文：长按背部上升按键背部电机伸出，松开按键停止；长按背部下降按键背部电机 收回，松开按键停止； English：Press and hold the Back Up button to extend the back motor; release to stop. Press and hold the Back Down button to retract the back motor; release to stop. （3） 中文：长按脚部上升按键脚部电机伸出，松开按键停止；长按脚部下降按键脚部电机 收回，松开按键停止； English：Press and hold the Foot Up button to extend the foot motor; release to stop. Press and hold the Foot Down button to retract the foot motor; release to stop. （4） 中文：长按同升按键电机全部伸出，松开按键停止；长按同降按键电机全部收回，松 开按键停止； English：Press and hold the Up All button to extend all motors; release to stop. Press and hold the Down All button to retract all motors; release to stop. （5）中文：点按一键放平，全部电机全部收回； English：Short press the Flat Position button to retract all motors to the fully flat position. （6）中文：长按记忆键 1 或 2 键 3 秒，记忆电机当前位置，当电机运行到其它位置时， 点按记忆键，电机自动运行到之前记忆位置； English：Press and hold the Memory 1 (M1) or Memory 2 (M2) button for 3 seconds to save the current motor positions. When the motors are in other positions, short press the memory button to automatically return to the saved position. （7）中文：点按脚灯功能键打开脚灯，再次点按关闭脚灯； English：Short press the Foot Light button to turn on the foot light; press again to turn it off. （8）中文：点按一键止鼾预设位置，电机运行至模式角度； English：Press the Anti-Snore Preset button to move the motors to the pre-set anti-snore position. （9）中文：点按一键电视预设位置，电机运行至模式角度； English：Press the TV Preset button to move the motors to the pre-set TV viewing position. （10）中文：点按一键 ZERO G 预设位置，电机运行至模式角度； English：Press the ZERO G Preset button to move the motors to the pre-set Zero-Gravity position. 3.功能示意图(Function Diagram ）： FCC Statement 1.This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2.Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

External

AB D A B C D 1 2 3 4 5 6 1 2 3 4 5 版本 描述 日期 姓名 A 初次发放 赖福宏 B C 2026.04.24 设计 审核 批准 日期 日期 日期 材料 A4 表面处理 单位 毫米（mm） 未注公差 比例 1:2 页数 1/1 锐迈科技股份有限公司 Cpk 重要尺寸标记 物料描述 >1.67>1.33 X.X >1.00 物料号 不作cpk要求 平板遥控器（零重力）-15键-BS300A(kanes) 23300949X000 RK23300949X000 此文件是公司保密文件， 未经授权和允许，禁止直接或间接的复制和转载。 文件解释权归本公司所有 技术要求： 1、各零部件组装到位，无变形，表面无划伤，油污等 不良，装配后间隙符合RMT成品检验要求：2.按键按压顺滑，无卡顿等不良：3.图面中以①②③...加以注释的为重点管控尺寸、注释或文字； 4.所有材料及加工工艺需符合ROHS及REACH要求： 171,91 +0,5 -0,2 49,92±0,2 14,32 13,79±0,2 S/N:1D0000000000000 INPUT:AAA X 2(1.5V) Remote Control 24.60 19.60 R 0 , 9 0 2,0 2,0 R FCC:ID:2BLB8-BS-300

Internal Antenna

RF EXPOSURE EVALUATION EUT Specification EUT Manual Controller Model Number BS-300A FCC ID 2BLB8-BS-300 Antenna gain (Max) 1.09 dBi Operation Frequency 2403MHz, 2442MHz, 2480MHz Rating 4.5V (3 x 1.5V AA batteries) Classification Per Stipulated Test Standard §15.247(i), §2.1093 Modulation GFSK Max. output power -1.01dBm(0.7925mW) Test Requirement: According to §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Routine SAR evaluation refers to that specifically required by §2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to quality for TCB approval. One antenna is available for the EUT. The minimum separation distance is 5mm. 802.15.4: Transmit Frequency (MHz) Mode Measured Power (dBm) Tune up Power (dBm) Max tune up power(dBm) Calculation Result 1-g SAR 2403 GFSK -1.01 -1±1 0 0.310032 3 According to KDB 447498, no stand-alone required for BT antenna, and no simultaneous SAR measurement is required. Signature: Shawn Wen Date: 2026-4-2

ANTENNA DOCUMENT 1:SPECIFICATIONS 1.1Electrical Specifications ITEM SPEC UNIT Frequency 2400-2500 MHz Gain1.09(Max) dBi S.W.R<=2.0 Antenna typetype PIFA Impedance50 Ω 1.2 Mechanical Specification ITEM SPEC UNIT Size 23.8 mm Radiator material material Brass(Gold coating) Operation Temperature Temperature -20—+65 1.3 Appearance and Dimensions ANTENNA DOCUMENT 2:MEASUREMENT PHI=0 PHI=90 THETA=90 Gain[dBi] Beam Peak Beam Null Freq.[MHz] Value Phi ThetaValue Phi Theta Efficiency 2403 1.09 45.53% 2440 -0.18 38.38% 2480 0.30 37.07%

TRF No.: 04-E001-0B TRF Originator: GTG TRF Date: 2023-12-13 Web: www.gtggroup.com E-mail: [email protected] Tel.: 86-400 755 8988 CFR 47 FCC PART 15 SUBPART C TEST REPORT For Manual Controller MODEL NUMBER: BS-300A, BS-300I, BS-300M REPORT NUMBER: E04A2611039F00601 ISSUE DATE: March 27, 2026 FCC ID: 2BLB8-BS-300 Prepared for Remacro Technology Co.,Ltd No.5555, Tongjin Road, Wujiang Economic Development Zone, Suzhou, Jiangsu, China Prepared by Guangdong Global Testing Technology Co., Ltd. Room 101-105, 203-210, Building 1, No.2, Keji 8 Road, Songshan Lake Park, Dongguan city, Guangdong, People’s Republic of China, 523808 This report is based on a single evaluation of the submitted sample(s) of the above mentioned product, it does not imply an assessment of the production of the products. This report shall not be reproduced, except in full, without the written approval of Guangdong Global Testing Technology Co., Ltd. REPORT NO.: E04A2611039F00601 Page 2 of 61 TRF No.: 04-E001-0B Global Testing , Great Quality. Revision History Rev. Issue Date Revisions Revised By V0 March 27, 2026 Initial Issue REPORT NO.: E04A2611039F00601 Page 3 of 61 TRF No.: 04-E001-0B Global Testing , Great Quality. Summary of Test Results Test Item Clause Limit/Requirement Result Antenna Requirement N/A FCC Part 15.203/15.247 (c) Pass AC Power Line Conducted Emission ANSI C63.10-2020, Clause 6.2 FCC Part 15.207 N/A Conducted Output Power ANSI C63.10-2020, Clause 11.9.1.2 FCC Part 15.247 (b)(3) Pass 6dB Bandwidth and 99% Occupied Bandwidth ANSI C63.10-2020, Clause 11.8.1 FCC Part 15.247 (a)(2) Pass Power Spectral Density ANSI C63.10-2020, Clause 11.10.2 FCC Part 15.247 (e) Pass Conducted Band edge and spurious emission ANSI C63.10-2020, Clause 11.11 FCC Part 15.247(d) Pass Radiated Band edge and Spurious Emission ANSI C63.10-2020, Clause 11.12 FCC Part 15.205/15.209 Pass Duty Cycle ANSI C63.10-2020, Clause 11.6 None; for reporting purposes only. Pass *This test report is only published to and used by the applicant, and it is not for evidence purpose in China. *The measurement result for the sample received is <Pass> according to <CFR 47 FCC PART 15 SUBPART C(DTS)> when <Accuracy Method> decision rule is applied. REPORT NO.: E04A2611039F00601 Page 4 of 61 TRF No.: 04-E001-0B Global Testing , Great Quality. CONTENTS 1. ATTESTATION OF TEST RESULTS..................................................................................... 5 2. TEST METHODOLOGY......................................................................................................... 6 3. FACILITIES AND ACCREDITATION..................................................................................... 6 4. CALIBRATION AND UNCERTAINTY ................................................................................... 7 4.1. MEASURING INSTRUMENT CALIBRATION ........................................................... 7 4.2. MEASUREMENT UNCERTAINTY ............................................................................ 7 5. EQUIPMENT UNDER TEST .................................................................................................. 8 5.1. DESCRIPTION OF EUT ........................................................................................... 8 5.1. CHANNEL LIST ........................................................................................................ 8 5.2. MAXIMUM CONDUCTED OUTPUT POWER ........................................................... 9 5.3. TEST CHANNEL CONFIGURATION ........................................................................ 9 5.4. THE WORSE CASE POWER SETTING PARAMETER ............................................ 9 5.5. DESCRIPTION OF AVAILABLE ANTENNAS ........................................................... 9 5.6. SUPPORT UNITS FOR SYSTEM TEST ................................................................. 10 5.7. SETUP DIAGRAM .................................................................................................. 10 6. MEASURING EQUIPMENT AND SOFTWARE USED......................................................... 11 7. ANTENNA PORT TEST RESULTS ..................................................................................... 12 7.1. Conducted Output Power ........................................................................................ 12 7.2. 6dB Bandwidth ........................................................................................................ 14 7.1. Power Spectral Density ........................................................................................... 16 7.2. Conducted Band edge and spurious emission ........................................................ 17 7.3. Duty Cycle .............................................................................................................. 19 8. RADIATED TEST RESULTS ............................................................................................... 20 9. ANTENNA REQUIREMENT ................................................................................................ 37 10. AC POWER LINE CONDUCTED EMISSION ......................................................... 38 11. TEST DATA - Appendix A ..................................................................................... 40 REPORT NO.: E04A2611039F00601 Page 5 of 61 TRF No.: 04-E001-0B Global Testing , Great Quality. 1. ATTESTATION OF TEST RESULTS Applicant Information Company Name: Remacro Technology Co.,Ltd Address: No.5555, Tongjin Road, Wujiang Economic Development Zone, Suzhou, Jiangsu, China Manufacturer Information Company Name: Remacro Technology Co.,Ltd Address: No.5555, Tongjin Road, Wujiang Economic Development Zone, Suzhou, Jiangsu, China EUT Information Product Description: Manual Controller Model: BS-300A Series Model: BS-300I, BS-300M Brand: / Sample Received Date: February 5, 2026 Sample Status: A26011039 001 Sample ID: February 5, 2026 to March 27, 2026 Date of Tested: Manual Controller APPLICABLE STAN…

Text truncated - open the document above for the full version.

Radiated Band edge and Spurious Emission
