2BLN2-XL2-2A0Smart projector

智能投影仪 用户说明书 .01. 注意事项 1.务必使用设备标配电源适配器，如使用电源不当会对设备造成严重损坏； 2.长时间不使用设备，请保证关闭电源开关； 3.风扇口请避免有异物进入或遮挡出风口，以免影响风扇工作; 4.设备工作状态，请勿直接断电关机; 5.外接功耗较大的外置设备时,请确认功耗能否支持； 6.设备内置电源,请勿放置于高温或潮湿处,以免发生危险; 7.适用于海拔2000米及以下、非热带气候条件下安全使用; 为预防触电，请勿打开机壳。机内无顾客能够进行修理的部件。 维修事宜请委托有资格的专业维修人员来进行。 本标识警告用户机组内有未进行绝缘处理的电压，有可能引起表面磁 场造成触电。因此，接触机组内部的任何部件均非常危险。 为预防失火或触电，切勿将本机暴露于雨水或潮气之中。 此为A级产品,在生活环境中,该产品可能会造成无线电干扰。 在这种情况下,可能需要用户对其干扰采取切实可行的措施。 注意 警告 警告 警告 .02. 主机遥控器电源线 说明书 用户说明书 智能投影仪 包装内容 .03. 安装图示 不要安装在受空调的冷暖风直接吹 拂的场所，否则可能会由于水气凝 结或温度升高而导致机体故障 .04. 注意散热 为了达到更好的观影效果，我们建议您选择以下安装式 安装好投影机。 .05. 开始使用 成像模糊 .06. 调节焦距 当画面成像模糊时，建议通过遥控器的一键对焦功能，以提升 画面清晰度，如果无法获得满意的清晰度，也可以通过F+/F- 微调再次调整。或者请将产品向前或向后酌量移动。 一键对焦 电源输入口 喇叭 音频输出口 USB 高清接口 摄像头 遥控接收窗 .07. 开/关机 部件说明 .08. 外接设备 .09. 首次使用请按此方法配对: 自动配对： 1.按遥控器语音键 进入配对页面； 2.同时按住遥控器左键与右键 ； 3.直到遥控器指示灯闪烁后松开； 4.等待自动配对成功后退出配对页。 手动配对： 1.按遥控器语音键 进入配对页面； 2.再按ok键进入设置页的蓝牙设置； 3.同时按住遥控器左键与右键 ； 4.至遥控器指示灯闪烁后松开; 5.找到“语音助手”点击连接。 1、工作指示灯 2、电源键 3、一键对焦 4、输入信号源 5、方向选择键-向上 6、方向选择键-向左 7、方向选择键-向右 8、方向选择键-向下 9、确定/播放/暂停 10、菜单键 11、返回键 12、主页键 13、手动对焦 14、音量加 15、音量减 16、语音键 遥控器按键功能 投影 开/关机 开关机处指示灯状态： 待机：红灯 开机：蓝灯 .10. 22 50 100 0.47 1.04 2 英寸 英寸 英寸 长 长 0.270.49米 0.611.11米 1.242.21米 高长米 高长 米 高长米 米 米 米 .11. 1.04 0.47 2 3.01 50” 22” 100” 150” x x x 150 3 英寸 1.873.34米 高长米 米 x 附录：投影距离画面尺寸对照表 附录：投影机产品保修卡 Smart Projector Before using the projector,please read this guidance carefully and keep it safely Microsoft and Windows is the registered trademark of Microsoft Corporation(US and other country). Apple is the trademark of Apple Computer Inc.(U.S.A) Cautious: The trademarks and product trademarks of the above company will all get stern treatment even under the situation without annotation. Caution .01. 1. It is necessary to use the standard power adapter of the device. Improper use of the power adapter can cause serious damage to the device; To prevent electric shock, do not open the casing. There are no components inside the aircraft that customers can repair. Please entrust qualified professional maintenance personnel to carry out maintenance matters. This label warns users that there is voltage inside the unit that has not been insulated, which may cause surface magnetic fields to cause electric shock. Therefore, it is very dangerous to come into contact with any components inside the unit. To prevent fire or electric shock, do not expose this machine to rainwater or moisture. This is an A-grade product that may cause radio interference in living environments. In this case, it may be necessary for users to take practical and feasible measures to interfere with it. 2. If the device is not used for a long time, please ensure to turn off the power switch; 3. Please avoid foreign objects entering or obstructing the fan outlet to avoid affecting the fan's operation; 4. The equipment is in working condition, please do not directly power off or shut down; 5. When connecting external devices with high power consumption, please confirm if the power consumption can be supported; 6. The device is equipped with a built-in power supply. Please do not place it in a high temperature or damp place to avoid danger; 7. Suitable for safe use in non tropical climate conditions with an altitude of 2000 meters and below; Caution Warning Warning Warning Caution .02. ProjectorRemotePower cord Instruction After opening the package, please check if the content inside is in good condition. If there's any missing parts, please contact the manufactur for replacement. Smart Projector Before using the projector,please read this guidance carefully and keep it safely Microsoft and Windows is the registered trademark of Microsoft Corporation(US and other country). Apple is the trademark of Apple Computer Inc.(U.S.A) Cautious: The trademarks and product trademarks of the above company will all get stern treatment even under the situation without annotation. Caution Packing .03. The guidance below makes sure the long service life of the device. To prevent fire and electronic shock, please read the instruction carefully and be cautious about the warning below. Installing Do not install into places with poor ventilation Do not install into places are hot and humid Do not plugged the vent(Intake and exhaust) Do not install in smoky and dusty environment Do not install somewhere directly blown by the warm/cold wind of the A/C, or it may cause the breakdown because of the water vapor condensation .04. To maintain the projector's performance and reliability, please leave at least 30cm space between the projector and the objects around. The projector is with high brightness, please do not directly look into it or do not let the projector's light shine through the eyes, to avoid eyesight damage. Note for Heat Dissipation Note for eyes Horizontal Placement Easy installtion, Easy adjustment .05. For best projection effectwe suggest you to choose the following method to install the projector. Start Using Fuzzy ImageClear Image Focus Adjustment .06. One Click Autofocus When the image is blurry, it is recommended to use the One Click Autofocus function of the remote control to improve the clarity of the image. If satisfactory clarity cannot be achieved, it can also be adjusted again through F+/F fine tuning. Alternatively, please move the product forward or backward in moderation. Loudspeaker USB HDMI Power Input Turn on/off Audio .07. Camera Remote reveiver window Parts Info .08. External Device Remote Control .09. 1. Work indicator light 2. Power button 3. One click autofocus 4. Input signal source 5. Direction selection key - up 6. Direction selection key - left 7. Direction selection key - right 8. Direction selection key - down 9. Confirm/Play/Pause 10. Menu key 11. Return key 12. Home key 13. Manual focusing 14. Volume increase 15. Volume decrease 16. Mute Auto pairing: 1. Press the voice button to enter bluetooth audio pairing page; 2. Long press the left/right button to enter auto pairing mode. Manual pairing: 1. Press the home button , choose setting in the pop-up interface. 2. E…
