2BLNX-MDC-HAP01Air Purifier

User Manual 1. Air Purifier Operational Manual ON/OFF: Turn on/off the Air purifier. Quiet Mode: Low speed with 20-30 dB sounds. High Speed Mode: High speed with 30-35 dB sounds. Timing 6 Hours: Air purifier will work 6 hours then turn off. Timing 24 Hours: Air purifier will work 24 hours then turn off. Air Purifier Feature: 1). 2-Stage Filtration System: True HEPA Filter, and High-Efficiency Activated Carbon Filter capture allergens. 2).Smoke, mold and odor, in addition to removing 98% of airborne contami- nants as small as 0.3 microns. 3).Ultra-Silent Operation: Filters the air with the lowest noise level as quiet as 20-30dB on Quiet Mode, helping you sleep deeply. And 30-35dB on High Speed Mode for High-Efficiency Filtration. 4.Timing System: You can set 6 or 24 Hours working time. And the machine will shut down automatically. Quality Assurance: 1-Year Warranty Notice: Connect the power supply and the camera start up automatically. Then set up your camera by your phone or tablet device. 2. Download APP User Registration (1)Open the TUYA Smart APP,click Register as the following pictures. (2)The System automatically determines the current country, or you could choose your country then put the mobile number or email address, then click agree Privacy policy. Then enter verification code as the following picture. (3)After you get the verification code, the put the password to finish registration. At last, put the account to log in as the following picture. (3)The APP will automatically recognize Bluetooth devices, and you can also directly select the device to be added to complete the addition. As shown in the figure below. (1)When you get this product, please make sure to connect with the standard power adaptor in the accessories, otherwise the device may not working properly. Before connecting,please make sure the mobile already connected the Wi-Fi(2.4GHz & 5GHz). (2)First,open the Bluetooth of your phone. Open the TUYA Smart APP and click + on the right to add device and choose “camera & lock” then smart camera (Ble) as the following picture. (4)Or select another way to add (WiFi Mode) to complete the addition. As shown in the following figure. Low Speed Mode 6 Hours Mode Camera Lens Purifier ON/OFF Strong Mode 24 Hours Mode Infrared Lights Power Input SD Card Slot Camera Reset -1--2--3--4--5- Search TUYA Smart in your mobile APP or Scan the QR Code to download it. 3. Add the Device 4. Function Introduction Please Note: Upgraded version, the upgraded content is as follows 1.It support both 2.4G and 5G Wi-Fi. 2.The device can directly connect to mobile apps via Bluetooth. (1)Connection Problem: Q: why the device can’t connect to the server? A: A: Check the network connection B: Check DNS configuration for the router C: Check if the router got any white list. 1)Device information Shows your IP, Device ID, signal Strength and Time Zone. 2)Tap-to-Run and Automation Not for this camera. 3)Private Mode Please turn off the Private mode so that you can modify the Basic function settings and IR Night Vision. 4)Basic Function Settings Status Indicator: On Flip Screen: turn off to upside down the screen. Time Watermark: On Talk mode: One-Way Communication & Two-way Talk. Anti-Flicker: Off, 50HZ, 60HZ. 5)IR Night Vision You can choose Auto, Off and On. 6)Detection Alarm Setting Choose the device setting and you can edit the device setting as below picture. Q: How to do with the device when it showed disconnected? A: Firstly to make sure the device is power on and the network connection is OK. If without any problem, try to reboot it. After reboot, if it is still the same problem, try to reset then do the network configuration again. If still not solved the problem, try to make the device near the router Q: Why the device can’t connect to WIF? A: A: now it only supports 802.11b/g/n at 2.4G WIFI, not support 5G WIFI. Please make sure the WIFI signal is within the range B: Because the Chinese coding mode may have the compatibility, we suggest you make the WIFI in English. C: Please keep the device near the router when you do the network configuration. Q: Why we couldn’t recognize the WIFI when we do the network configuration? Answer: Please turn on the location permission in the IOS or Android mobile. (2)Operation Problem. Q：Why I did set up event recording but have no record the video into the memory card? A: Please make sure Motion detection is turn on Q: How shall we add the mobile number to let the family members to view in the APP? A: Open the APP and choose share the device and then put the mobile number Q: Why the camera showed upside down? A: If the camera hang upside down, it will show like this, you could set the flip screen on in the APP. Q: How to do if warning message is sending too frequently? A: Please set the Alarm setting in the APP as your request Q: Why there is noise when preview? A: Please keep the mobile away from the camera. Q: Why there is no sound when checking the video? A：Firstly check whether the microphone is on for the camera. Then check the speaker is on in the APP and whether the mobile is in sound off Q: In the mobile, we couldn’t hear the voice from the camera. What shall we do? A: First, check whether the management permission for microphone or speaker in the APP with your mobile phone.IOS users can turn on the microphone permission of the APP in the privacy settings of the system. The Android phone finds the permission management settings in the phone, such as application management, mobile phone manager, security center, etc.,to opens the microphone and speaker permissions. Q: Is the Talkback function is the same as making mobile calls? A: A: it the APP shows hold the button then talk, it is one way communication as Wechat. B: If the APP shows Intercom, it is two way communication as calling. (3)Account Questions Q: When the client registers an account in the APP, it prompts that it has been registered. What shall we do? A: If so, it means you already have an acco…

Text truncated - open the document above for the full version.

1/1 USAgentforServiceofProcessLETTEROFATTESTATION TO: OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USAgentforServiceofProcess: CompanyName:GOLDENVICTORYINTERNATIONALTRADINGCOLTD FRN:0036377570 ContactName:LeonHowar Address:11016THSTREETSUITE1400DENVER,CO80202UnitedStates TelephoneNo:(337)255-0461 Email:[email protected] Applicant: Companyname:MDCELECTRONICSCo.,Limited ProductDescription: AirPurifier Granteecode:2BLNX FRN:0036120129 FCCID:2BLNX-MDC-HAP01 ContactName:chrischan Address:Room603,BusinessBuildingD,TongAnPark,GuShu,XiXiangBao'anDistrict,ShenZhen 518102China TelephoneNo.:13826585499 Email:[email protected] [MDCELECTRONICSCo.,Limited]certifiesthat,asofthedateofthisfilingof theapplicationwiththeTCB,[GOLDENVICTORYINTERNATIONALTRADING COLTD]isourdesignatedUSagentforserviceofprocessfortheabove referencedFCCID.[MDCELECTRONICSCo.,Limited]acceptstomaintainan agentfornolessthanoneyearafterthegranteehasterminatedallmarketing andimportationortheconclusionofanycommissionrelatedproceeding involvingequipment.[GOLDENVICTORYINTERNATIONALTRADINGCOLTD] accepts,asofthedateofthefilingoftheapplication,theobligationofthe designatedUSagentforserviceofprocessfortheabovereferenceFCCID. TheUSAgentforServiceofProcessisawareofandagreestocomplywiththerequirements outlinedintheFCCEquipmentAuthorizationProgram,ReportandOrderFCC22-84,andclause §2.911. TheApplicantisawareofandagreestocomplywiththerequirementsoutlinedintheFCC EquipmentAuthorizationProgram,ReportandOrderFCC22-84,andclause§2.911. Date:2025.11.24 Applicant’sName:chrischanUSAgent’sName:LeonHowar Title:managerTitle:Manager Signature Signature

AttestationStatement. OldCode:C526609124NewCode:00015544Ed.3 Changereason:FRNisaddedtotheApplicantinformationsection. 1/1 TO: OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 TheCommissionadoptedrulesthatprohibitequipmentauthorizationfor“covered” telecommunicationsequipmentandvideosurveillanceequipmentproducedbyentitiesidentified ontheCommission’sCoveredList 1 ,whichisperiodicallyupdated.SeetheCoveredListformore details.ThisAttestationStatementistoconfirmthatwefollowtheSection2.911(d)(5)(i)-(ii) Applicant Companyname:MDCELECTRONICSCo.,Limited Granteecode:2BLNX FRN:0036120129 FCCID:2BLNX-MDC-HAP01 ContactName:chrischan Address:Room603,BusinessBuildingD,TongAnPark,GuShu,XiXiangBao'anDistrict,ShenZhen 518102China TelephoneNo.:13826585499 Email:[email protected] i.MDCELECTRONICSCo.,Limited(“theapplicant”)certifiesthatthe equipmentforwhichauthorizationissoughtisnot“covered”equipment prohibitedfromreceivinganequipmentauthorizationpursuanttosection 2.903oftheFCCrules.Theapplicantmustsignthiscertification. ii.MDCELECTRONICSCo.,Limited(“theapplicant”)certifiesthat,asofthe dateofthefilingoftheapplication,theapplicant[isnot](asaspecifically namedentityoranyofitssubsidiariesoraffiliates)identifiedontheCovered Listasanentityproducing“covered”equipment.Theapplicantmustsign thiscertification. [MDCELECTRONICSCo.,Limited](“theapplicant”)certifiesthat,asofthedateof thefilingofthe application,theapplicant[isnot]identifiedontheCoveredList asanentityproducing“covered” equipment. Date:2025.11.24 Applicant’sName:chrischan Title:manager Signature 1 TheCommission’sCoveredListispublishedbythePublicSafetyandHomelandSecurityBureauandpostedonthe Commission’swebsite.ThisCoveredList,whichisperiodicallyupdated,identifiesparticularequipment,producedby particularentities,thatconstitutes“covered”equipment.https://www.fcc.gov/supplychain/coveredlist

MDCELECTRONICSCo.,Limited Code00018768Ed. 2 Item 1.The deviceis able to install software/programinstallation? ☐Yes, go to Item 2. ☒No. In this case, the rest of the items do not apply.The devicecannotsupport installationof Kasperskycybersecurityor anti-virussoftware. Item 2.TechnicalRequirementsfor KasperskyCybersecuritySoftware: #GeneralRequirements(For all Devices)Yes / No or N/A Comments 1Internetconnectionfor activationand updates(For all OperatingSystems) N/A DeviceAir Purifier CompanynameMDCELECTRONICSCo.,Limited Granteecode2BLNX FCC ID2BLNX-MDC-HAP01 FRN0036120129 Contactnamechrischan AddressRoom603,BusinessBuildingD,TongAnPark, GuShu,XiXiangBao'anDistrict,ShenZhen 518102China Telephonenumber13826585499 [email protected] Chipset/moduleinformationATBM6132 OperatingSystem(if applicable)N/A StorageCapacity(hard drive or other permanentmemorystorage, if applicable) N/A 2 #GeneralRequirements(ForWindowsDevices)Yes/Noor N/A Comments 1Storage:1500MBfreespaceontheharddriveN/A 2OperatingSystem: MicrosoftWindows8,8.1,10&11Home/Pro/ EnterpriseMicrosoft Windows7Starter/HomeBasic&Premium/ Professional/UltimateSP1orhigher N/A 3Processor:1GHzorhigher(x86orx64)N/A 4Memory(RAM)1GB(32-bit)or2GB(64-bit)N/A 5ScreenResolution:Minimumresolutionof1024x768N/A #GeneralRequirements(FormacOSdevices)Yes/Noor N/A Comments 1OperatingSystemmacOS®13–14N/A 2Memory(RAM)4GBN/A 3Storage:3455MBfreespaceontheharddriveN/A #GeneralRequirements(ForAndroidDevices)Yes/Noor N/A Comments 1Storage:150MBfreespaceN/A 2OperatingSystem:Android™10–14N/A 3ScreenResolution:Minimumresolutionof320x480N/A #GeneralRequirements(foriOSdevices)Yes/Noor N/A Comments 1Storage:150MBfreespaceN/A 2OperatingSystem:iOS®17N/A 3 #GeneralRequirements(ForLinuxsystem)Yes/Noor N/A Comments 1Harddrive:1GBoffreespaceN/A 2CPU:IntelPentium1GHzorhigherN/A 3RAM:1GBN/A 4Minimumsoftwarerequirements: AlmaLinuxOS8orlater; AlterOS7.5orlater; AstraLinuxCommonEdition2.12orlater; CentOS6.7orlater; DebianGNU/Linux10.0orlater; EulerOS2.0orlater; OracleLinux7.3orlater; RedHatEnterpriseLinux6.7orlater; RockyLinux8.5orlater; SUSELinuxEnterpriseServer12.5orlater; Ubuntu12.04orlater; UncomOSHome/Business/Education/Enterprise 2.2orlater; ALTLinuxWorkstaton/WorkstationK/Server/ Education8orlater; ROSALinuxWorkstation/Server12orlater; REDOS7.3andlater; N/A Afterreviewedthetechnicalrequirements,isthedevicecapableofsupportingthe installationofKasperskysoftware? ☐Yes,gotoItem3. 4 ☒No.Inthiscase,therestoftheitemsdonotapply.Thedevicecannotsupport installationofKasperskysoftware Item3.ConnectivityCapabilities: #PhysicalInterfacePurposeJustification 1 1 #WirelessInterfacePurposeJustification 1 1 Afterthereviewofthisitems,thedevice: ☒ Cannotsupportinstallationofanycybersecurityoranti-virussoftwareonthecovered list. ☐ Potentiallycanoperatewithanycybersecurityoranti-virussoftwareonthecoveredlist –additionalthird-partyproofisprovidedtodemonstratecompliancewithrequirementsas of2.911(d)5(i),(ii)–“ProofofCompliancewithCoveredListSoftwareRequirements”ofthis documentapplies Signature:Name:chrischan Date:2025.11.24 Oncethedocumentisfilledin,pleaseproceedtoprintaPDFofthisWord 1 Thejustificationfieldisusedtojustifywhythesoftwarecannotbereceivedthroughthatinterface.Checktheannexformore indications.

MDCELECTRONICSCo.,Limited ProductSimilarityDeclaration Productname:BluetoothHeadset Modelname:MDC-HAP01 MDC-WC01,MDC-WC02,MDC-KP05,MDC-KP04,MDC-KP06,MDC- KP09,MDC-SC01,VM001,AP-QF,AP-01,AP-02,AP-03,AP-04,AP- 05,AP-06,AP-07,AP-08 FCCID:2BLNX-MDC-HAP01 We(MDCELECTRONICSCo.,Limited)herebystatethatallthe modelsareelectricalidenticalincludingthesamesoftware parameterandhardwaredesign(i.e.,circuitdesign,PCBLayout, RFmodule/circuit,antennatype(s)andantennalocation, componentsonPCB,etc.,),samemechanicalstructureand design(includingproductenclosure,materials,etc.,),theonly differenceisthemodelname Signature: Name: chrischan Title:Manager Place,date:Room603,BusinessBuildingD,TongAnPark,GuShu,XiXiangBao'anDistrict, ShenZhen,518102China

TCB CALL página 1 File FCC ID: 2BLNX-MDC-HAP01 Please upload an exhibit that explains how does the TCB verify the new agent information: 1- Is the address of the agent a valid physical US mailing address (not a US post office box, not a virtual mailbox, not P.O. Boxes, not a vacant lot, not a public building, etc.) ○ We have checked if the address exists in a real and potential building (Google maps) + official US register, after this verification and the evidence below we can guarantee the following: not a US post office box not a virtual mailbox not P.O. Boxes not a vacant lot not a public building(note) ► We checked the FCC FRN Search based on the information provided by the grantee. On the official register from : https://www.sos.state.co.us/biz/BusinessEntityDetail.do?quitButtonDestination=BusinessEntityResults&nameTyp=ENT&masterFileId=20248279136&entityId2=20248279136&fileId=20248279136&srchTyp=ENTITY TCB CALL página 2 Google: EIN Number： TCB CALL página 3 ► CONCLUSION by TCB: The ASOP defined and provided by grantee is VALID and confirmed. Therefore the exhibit "C5266091_X23_Ed1_US_Agent_Letter" included in the file is ok. 2- Is the agent physically located at that valid US address such that the agent can be legally served at that address? Yes , check above 3- Has the listed agent clearly agreed in writing to serve as the agent for the grantee at that address? Yes, it is included in the exhibit "C5266091_X23_Ed1_US_Agent_Letter"

C5266091_X10_Ed.2 1/1 MDC ELECTRONICSCo.,Limited Officeof EngineeringTechnology FederalCommunicationsCommission 7435 OaklandMills Road Columbia,MD 21046 Date: 2025.11.24 Subject:Requestfor Confidentiality FCC ID:2BLNX-MDC-HAP01 To WhomIt May Concern, Pursuantto the provisionsof Sections0.457and 0.459of Commission'srules (47CFR0.457,0.459),we are requestingthe Commissionto withholdthe following attachment(s)as confidentialdocumentfrom publicdisclosure. ExhibitsLong-Term Confidentiality Short-Term Confidentiality NOTE2 ID Label/LocationNoNo AttestationStatementNoNo ExternalPhotosNo ☐ Block Diagram ☒☐ Schematics ☒☐ Test ReportNoNo Test SetupPhotosNo ☐ User’ s Manual ☐ NOTE 1 ☐ InternalPhotos ☐ NOTE 1 ☐ Parts List / Tune Up ☐☐ RF ExposureInfoNoNo OperationalDescription ☒☐ CoverLetter(s)NoNo SDR Software/ SecurityInfo ☐ No NOTE1: Long-TermConfidentialitymay be permittedunderspecialconditions(SeeII. LONG-TERMCONFIDENTIALITY,Section3 of KDB 726920,use last in force) NOTE2: Short-TermConfidentialitycan be requestedfor a maximumof 180 daysfromthe dateof the grant. Abovementioneddocumentcontainsdetailedsystemand equipmentdescriptionare consideredas proprietaryinformationin operationof the equipment.The public disclosureof abovedocumentsmightbe harmfulto our companyand wouldgive competitoran unfairadvantagein the market. In case of short-termConfidentiality,the applicantrequeststhe exhibitsselected aboveare withheldfrom publicview for a periodof ______days from the date of the Grantof EquipmentAuthorizationand prior to marketing. It is our understandingthat all measurementtest reports,FCC ID label formatand correspondentduringcertificationreviewprocesscannotbe grantedas confidential documentsand thoseinformationwill be availablefor publicreviewonce the grantof equipmentauthorizationis issued. C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name:chrischan Title:manager

C5266091_X8_Ed.1 1/1 LetterofAuthorization MDCELECTRONICSCo.,Limited Company:MDCELECTRONICSCo.,Limited Address:Room603,BusinessBuildingD,TongAnPark,GuShu,XiXiang Bao'anDistrict,ShenZhen518102China ProductName:AirPurifier ModelNumber:MDC-HAP01,MDC-WC01,MDC-WC02,MDC-KP05, MDC-KP04,MDC-KP06,MDC-KP09,MDC-SC01,VM001,AP-QF,AP-01, AP-02,AP-03,AP-04,AP-05,AP-06,AP-07,AP-08 FCCIdentifier:2BLNX-MDC-HAP01 WeauthorizeLGAITechnologicalCenterS.A.,RondadelaFontdelCarme,s/n, 08193Bellaterra,Spain,toactonourbehalfonallmattersconcerningthe abovenamedequipment. AnyindividualwithinLGAITechnologicalCenterS.A.isauthorizedtoactonour behalfandtakeactionontheapplication. WedeclarethatauthorizeLGAITechnologicalCenterS.A.,RondadelaFontdel Carme,s/n,08193Bellaterra,Spain,isallowedtoforwardallinformation relatedtotheapprovalprojecttotheFederalCommunicationCommissionand todiscussanyissuesconcerningtheapprovalapplication.Anyandallacts carriedoutbyLGAITechnologicalCenterS.A.onourbehalfshallhavethe sameeffectasactsofourown. Name:chrischanDate:2025.11.24 Title:manager Signatureofapplicant:

C5266091_X13_Ed.1 1/1 MDCELECTRONICSCo.,Limited FCCSoftwareConfigurationControlDeclaration Date:2025.11.24 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Attn:OETDept. Product/ModelNumber:AirPurifier/MDC-HAP01,MDC-WC01,MDC- WC02,MDC-KP05,MDC-KP04,MDC-KP06,MDC-KP09,MDC-SC01, VM001,AP-QF,AP-01,AP-02,AP-03,AP-04,AP-05,AP-06,AP-07,AP- 08 RegardingFCCCountryCodeSelectionguidelinesidentifiedinKDB594280. “Allapplicationsforequipmentauthorizationfortransmittersthatcanhave radioparameters,orothertechnicalparameters,reportedtotheCommission setbysoftwaremusthaveanattestationindicatingthatnothirdpartywillhave software,orconfigurationcontrol,toprogramthedeviceoutofcomplianceof thetechnicalrulesunderwhichithasbeencertified.” Wedeclarethatnothirdpartywillhavesoftware,orconfigurationcontrol,to programthedeviceoutofcomplianceofthetechnicalrulesunderwhichithas beencertified. Signatureofapplicant Name:chrischan Title:manager

EUTPHOTO(ExternalPhotos) TestMode:MDC-HAP01 ※※※※※ENDOFREPORT※※※※※

Labelandlabellocation 3.5cm AirPurifier FCCID:2BLNX-MDC-HAP01 1.5cm

EUTPHOTO(InternalPhotos) TestMode:MDC-HAP01 ANT ※※※※※ENDOFREPORT※※※※※

FCCID:2BLNX-MDC-HAP01 AccordingtoKDB447498D01GeneralRFExposureGuidancev06andpart2.1091 RFExposureEvaluation Limits Thecriterialistedinthefollowingtableshallbeusedtoevaluatetheenvironmentimpactofhumanexposure toradiofrequency(RF)radiationasspecifiedin1.1307(b) LimitsforMaximumPermissibleExposure(MPE) Frequencyrange (MHz) Electricfield strength (V/m) Magneticfieldstrength (A/m) Powerdensity (mW/cm 2 ) Averagingtime (minutes) (A)LimitsforOccupational/ControlledExposures 0.3–3.06141.63*(100)6 3.0–301842/f4.89/f*(900/f 2 )6 30–30061.40.1631.06 300–1500f/3006 1500–100,00056 (B)LimitsforGeneralPopulation/UncontrolledExposure 0.3–1.346141.63*(100)30 1.34–30824/f2.19/f*(180/f 2 )30 30–30027.50.0730.230 300–1500f/150030 1500–100,0001.030 f=frequencyinMHz Friistransmissionformula:Pd=(Pout*G)/(4*pi*r 2 ) Where Pd=powerdensityinmW/cm 2 ,Pout=outputpowertoantennainmW; G=gainofantennainlinearscale,Pi=3.1416; R=distancebetweenobservationpointandcenteroftheradiatorincm PdidthelimitofMPE,1mW/cm 2 .Ifweknowthemaximumgainoftheantennaandthetotalpowerinputto theantenna,throughthecalculation,wewillknowthedistancerwheretheMPElimitisreached. TestProcedure SoftwareprovidedbyclientenabledtheEUTtotransmitandreceivedataatlowest,middleandhighest channelindividually. TestResultofRFExposureEvaluation For2.4GWIFI Mode Output powerto antenna (dBm) TuneUP tolerance (dBm) MaxTune UPpower (dBm) MaxTune UPpower (mW) Power Densityat R=20cm (mW/cm2) Limit (mW/cm2) Result 802.11b3.513±142.510.0009261.0PASS 802.11g3.7933±142.510.0009261.0PASS 802.11n203.7283±142.510.0009261.0PASS 802.11n403.839 3±1 42.510.0009261.0PASS Antennagainfor:2.4GWIFI:2.68dBi For5.2GWIFI Mode Output powerto antenna (dBm) TuneUP tolerance (dBm) MaxTune UPpower (dBm) MaxTune UPpower (mW) Power Densityat R=20cm (mW/cm2) Limit (mW/cm2) Result 802.11a3.247 3±1 42.510.0006731.0PASS 802.11n203.1633±142.510.0006731.0PASS 802.11n403.2613±142.510.0006731.0PASS Antennagainfor:5.2GWIFI:1.29dBi SoaSARtestisnotrequired

ShenzhenDL TestingTechnologyCo., Ltd.ReportNo.: DLE-251031004R Test ReportTel: 400-688-3552Web:www.dl-cert.comEmai l:[email protected] of 55 FCC TEST REPORT FCC ID: 2BLNX-MDC-HAP01 Applicant:MDCELECTRONICSCo.,Limited Address: Room603,BusinessBuildingD,TongAnPark,GuShu,XiXiangBao'anDistrict,ShenZhen, 518102China Manufacturer:MDCELECTRONICSCo.,Limited Address: Room603,BusinessBuildingD,TongAnPark,GuShu,XiXiangBao'anDistrict,ShenZhen, 518102China EUT:Air Purifier TradeMark:N/A ModelNumber: MDC-HAP01 MDC-WC01,MDC-WC02,MDC-KP05,MDC-KP04,MDC-KP06,MDC-KP09,MDC-SC01, VM001,AP-QF,AP-01,AP-02,AP-03,AP-04,AP-05,AP-06,AP-07,AP-08 Dateof Receipt: Sep.25, 2025 Test Date: Sep.25, 2025to Dec.04, 2025 Dateof Report: Dec.04, 2025 PreparedBy:ShenzhenDL TestingTechnologyCo., Ltd. Address: 101-201,ComprehensiveBuilding,TongzhouElectronicsLonggangFactoryArea,No.1 BaolongFifth Road,BaolongCommunity,BaolongStreet,LonggangDistrict,Shenzhen, China Applicable Standards: FCCCFR Title 47 Part 15 SubpartE Section15.407 ANSIC63.10:2020 KDB789033D02 v0 2r0 1 Test Result:Pass ReportNumber:DLE-251031004R Prepared(TestEngineer): DimonTan Reviewer(Supervisor):JackBu Approved(Manager):JadeYang Thistestreportis basedona singleevaluationofonesampleofabovementionedproducts.It is notpermittedto beduplicatedin extractswithoutwrittenapprovalofShenzhenDLTestingTechnologyCo.,Ltd. ShenzhenDL TestingTechnologyCo., Ltd.ReportNo.: DLE-251031004R Test ReportTel: 400-688-3552Web:www.dl-cert.comEmai l:[email protected] of 55 Table of Contents Page 1. VERSION...................................................................................................................5 2. SUMMARYOF TEST RESULTS...............................................................................6 2.1 TEST FACILITY.................................................................................................................7 2.2 MEASUREMENTUNCERTAINTY....................................................................................7 3. GENERALINFORMATION........................................................................................8 3.1 GENERALDESCRIPTIONOF EUT .................................................................................8 3.3 BLOCKDIGRAMSHOWINGTHE CONFIGURATIONOF SYSTEMTESTED............10 3.4 DESCRIPTIONOF SUPPORTUNITS(CONDUCTEDMODE)......................................10 3.5 EQUIPMENTSLIST FOR ALL TEST ITEMS.................................................................11 4. EMC EMISSIONTEST .............................................................................................13 4.1 CONDUCTEDEMISSIONMEASUREMENT..................................................................13 4.1.1 POWERLINE CONDUCTEDEMISSIONLIMITS..................................................13 4.1.2 TEST PROCEDURE...............................................................................................13 4.1.3 DEVIATIONFROMTEST STANDARD..................................................................13 4.1.4 TEST SETUP...........................................................................................................14 4.1.5 EUT OPERATINGCONDITIONS...........................................................................14 4.1.6 TEST RESULT........................................................................................................15 4.2 RADIATEDEMISSIONAND BANDEDGEMEASUREMENT......................................17 4.2.1 APPLICABLESTANDARD.....................................................................................17 4.2.2 CONFORMANCELIMIT .........................................................................................17 4.2.3 MEASURINGINSTRUMENTS...............................................................................18 4.2.4 TEST CONFIGURATION........................................................................................18 4.2.5 TEST PROCEDURE...............................................................................................19 4.2.6 RADIATEDEMISSIONTEST RESULT..................................................................20 4.2. 7 RADIATEDBANDEDGETEST RESULT..............................................................27 5. POWERSPECTRALDENSITYTEST .....................................................................29 5.1 APPLIEDPROCEDURES/ LIMIT ..................................................................................29 5.2 TEST PROCEDURE........................................................................................................30 5.3 DEVIATIONFROMSTANDARD.....................................................................................30 5.4 TEST SETUP...................................................................................................................30 5.5 EUT OPERATIONCONDITIONS....................................................................................30 5.6 TEST RESULTS..............................................................................................................31 ShenzhenDL TestingTechnologyCo., Ltd.ReportNo.: DLE-251031004R Test ReportTel: 400-688-3552Web:www.dl-cert.comEmai l:[email protected] of 55 Table of Contents Page 6. 26DB EMISSIONBANDWIDTH& 6DB OCCUPIEDBANDWIDTH........................35 6.1 APPLIEDPROCEDURES/ LIMIT ..................................................................................35 6.2 TEST PROCEDURE........................................................................................................35 6.3 EUT OPERATIONCONDITIONS....................................................................................36 6.4 TEST RESULTS..............................................................................................................36 7. MAXIMUMCONDUCTEDOUTPUTPOWER..........................................................40 7.1 PPLIEDPROCEDURES/ LIMIT .....................................................................................40 7.2 …

Text truncated - open the document above for the full version.

1 深圳市飞敏科技有限公司 ShenZhen City FeiMin Technology CO.,LTD. 产品承认书 SPECIFICATION FOR APPROVED 客户 CUSTOMER: 深圳凯拓电子科技有限公司 产品名称 PRODUCTS: KT01内置天线 客户料号 PART NO: 产品型号 Spec.: FM-S2092-KT01-2.4G 日期 Data: 2025-10-17 备注：承认盖章后请回复一份承认书（或复印件）给我司，其余由贵公司存档 REMARK:Please send us one(or copy)of this approval with stamp after accepting,other copies filed by the customer. 地址：深圳市宝安区西乡街道固兴社区盛辉路 4 号科运达电商基地 8 楼 801室 ADD: Room 801, 8th Floor, Keyunda E-commerce Base, No. 4 Shenghui Road, Guxing Community, Xixiang Subdistrict, Baoan District, Shenzhen. 电话Tel: 0755-23035723 传真Fax: 0755-23036702 邮箱E-mail: [email protected] 网址HTTP:www.fmant.cn 客户 CUSTOMER 承认 ACCEPTED BY 审核 CHECKED BY 批准 APPROVED BY 供应商 SUPPLIER 拟制 PREPARED BY 审核 CHECKED BY 批准 APPROVED BY 2 目录 产品承认书 ..................................................................................................................... 1 1. 项目信息Project Information .................................................................................. 4 1.1. 外观尺寸Appearance and Dimensions .......................................................... 4 2. 电气性能 Electrical Characteristics ......................................................................... 5 2.1. 测试环境条件Test Environment Conditions ................................................. 5 2.2. 测示方法Measurement method ..................................................................... 5 2.2.1. 天线电压驻波比Antenna VSWR ............................................................... 5 2.2.2. 天线回波损耗Antenna Return loss ................................................... 6 2.3. 天线无源测试数据 Antenna passive test data ................................. 6 2.3.1. 测试系统Test system ............................................................................... 6 2.3.2天线效率及增益Antenna efficiency and gain .............................. 7 2.3.2. 天线辐射方向图Antenna Radiation Pattern ....................................... 8 3. 备注Notes................................................................................................................. 9 4. 产品包装规范Product packaging specification ...................................................... 9 ANTENNA SPECIFICATION 深圳市飞敏科技有限公司 Shenzhen Feimin Technology Co.,Ltd 3 Revision history 版本 日期 状态 A1 2022-9-9 首版 A2 2025-10-15 增加测试数据 A3 2025-10-17 更新测试数据 变更内容： 第一次变更： 变更前：（如有必要，请添加相应的图片，此处变更明细要描述清楚） 变更后：（如有必要，请添加相应的图片，此处变更明细要描述清楚） ANTENNA SPECIFICATION 深圳市飞敏科技有限公司 Shenzhen Feimin Technology Co.,Ltd 4 1. 项目信息Project Information 1.1. 外观尺寸Appearance and Dimensions ANTENNA SPECIFICATION 深圳市飞敏科技有限公司 Shenzhen Feimin Technology Co.,Ltd 5 2. 电气性能 Electrical Characteristics 2.1. 测试环境条件Test Environment Conditions 温度Temperature Ordinary Temperature (5 to 35°C) 湿度Humidity Ordinary Humidity (25 to 85% RH) 2.2. 测示方法Measurement method 2.2.1. 天线电压驻波比Antenna VSWR ANTENNA SPECIFICATION 深圳市飞敏科技有限公司 Shenzhen Feimin Technology Co.,Ltd 6 2.2…
