Smart Camera ICAM-C8 From life Guarding life Loving life 4GsolarbatterycameraEnglishmanual 1.DownloadAPP(supportAndroidandIOS) ScantheQRcodetodownloadiCam365APP, orSearchanddownloadiCam365APP inAppleStoreorAndroidMarket. 2.OpentheAPPsoftwareandusetheAPPforthefirsttime,Usersneedtoregister viamobilephonenumberoremailaccount,Clicktoregisteranewaccountand followthewizardtocompletetheusercreation.Newaccountregistrationandlogin; ifyouhaveanaccount,pleaseentertheaccount.Loginaccountnumberand password. 3.Adddevice Addadevice:Afteraddingadevicewithyourmobilephone,youcanuse4G networkorWiFinetworktologintotheAPPanywheretowatch: Pressandholdthe"ON/OFF"cameraorconnectthesolarchargingpanelwherethereis sufficientlightsourcetoturnonthecamerapower,andpressandholdthe"reset"keyfor about5secondstoreset,thenopentheAPPtoaddacamera.Firstselect"Surveillance Camera",andthenselect"4GCamera".Operateasshowninthefollowingfiguretoadd equipmentto"4Gcamera".The4Gnetworkisbeingconnected,andthevoiceof"waitingto connecttothenetwork"sounds.Pleasewaitatthistime;Waituntilthecamerasendsoutthe soundof"Connectsuccessfully,pleaseconnectthe4Gcamera",click"Ihaveheardtheprompt tone",thenclickNext,openthemobilephonecameraandaimatthecamera"QRcode"to scanthecodetoadd;Afteradding,thecamerawillsound"connectedsuccessfully".Ifyoudo notheartheprompttone,pressandholdtheresetkeyforalongtime.Theresetissuccessful. Thecamerarotatesbyselfchecking.Waitfortheprompttoneofthecamera,andthenre operatetheconnectionprocedure. 4.4Gsolarbatterycamerasettings Afterthe4Gsmartcameraisconnected,youneedtosetthedevicename,oryou canenterthedevicedetailsandclickthedevicenametomodifythename;click onthe"..."inthefiguretopopupadialogbox,clickonsettings,youcan customizethesettings;clickon"+",Youcansetthedisplayinterface:listmode andfour-splitscreen. 5.Features （1）Voiceintercom:Clicktheintercomicononthereal-timeviewinginterface, andtheintercomscreenwillappeartorealizetheintercomwiththepersonnext tothecamera.Suchas:Picture(1) (2)PTZcontrol:WhenthecamerahasaPTZfunction,youcanclickordragthe steeringwheelonthereal-timeviewinginterfacetocontrolthecamerarotation. Suchas:Picture(2) (3)Alarmmessage:Clickthe""iconintheupperleftcorneroftheAPPtoview allalarmmessagesofalldevicesunderthecurrentaccount.Inthealarmmessage, youcanseethepictureofthealarmmessage.Ifyouhavepurchasedvalue-added services,youcanseethevideoofthealarmmessage.Suchas:Picture(3) (4)Memorycardplaybackvideo:blackonthesidetimeaxismeansthereisnovideo currently,andgraymeansthereisvideo.Dragtheareaontherighttoselectthe playbackstarttime.Suchas:Picture(4) 6. Common problem (1) Note that the 4G camera only supports 4G signals and cannot use WIFI signals; When connecting the camera, if there is no prompt tone, please check the power interface, or long press the reset key. If the reset is successful, the camera will give a prompt tone "Restore factory settings" to restore factory settings. (2) Why is the video intermittent? Cloud service trial package, alarm recording package and memory card event recording mode will record only when an exception is detected, so the recording may not be continuous. (3) Why do I insert a memory card, choose continuous recording or intermittent recording? If there is a cloud service, the video playback is cloud video playback by default. The event package may not be continuous. Please select the video viewing mode as memory card. (4) Why can't the mobile phone receive the alarm message? First confirm that the notification push permission of the APP in the mobile phone settings is turned on, then turn on "Sound Detected" and "Moving Object Detected" in the "Message Push Settings" of the APP, and the current time is not in the planned time period for stopping notification. Under normal circumstances, when an exception is detected, a message will appear in the phone notification bar. Whether there is a sound or vibration depends on the phone settings. In addition, when viewing the real-time image in the APP, you will not receive an alarm from the camera you are watching, because the default user focuses on the monitoring image at that time, and there is no need to alarm. (5) What if the display camera is disconnected? First confirm whether the power supply and network are normal, and then power off and restart the camera if there is no problem. If the connection is still lost after restart, please remove the camera from the APP and add it again. (6) How many accounts can I share with my family? How to cancel sharing? 10 accounts can be shared; Long press or left swipe to cancel the shared account, and then click Delete Account. (7) For your security, one account can only be logged in on one mobile phone at the same time. (8) One camera can only be bound to one account, and other accounts can only be viewed through the sharing mechanism. If another account needs to reconfigure the camera, please use the first account to remove the device. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determi…
