2BLTM-KLHUMEAHumidifier

Evaporative Air Humidifier MODEL: HUMEA WiFi User Manual ModelKlarta HUMEA Adaptor input100-240V~, 50/60Hz, 0.5A Adaptor output12V DC, 1.0A The humidifier input12V DC, 0.6A Operating range5-40°C and 20-80% humidity Humidistat, adjustable40-75% Humidification efficiency100-300 ml/hour±20%(30%RH, 21°C) Water tank capacity3 liters Airflow power4 modes (low, medium, high, turbo) Noise level(24-52)±3 dB Room sizeMax. 134 ft² Dimensions9.02in x 9.02in × 14.29in Weight5.07 lb Technical Specifications TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK OR PERSONAL INJURY WHEN USING ELECTRICAL APPLIANCES, YOU SHOULD ALWAYS FOLLOW BASIC MEASURES PRECAUTIONS, INCLUDING THE FOLLOWING: General safety guidelines: ● Before using the device, please read this entire user manual carefully. Please keep this manual in a safe place in case you need to refer to its content in the future. ● This air humidifier is int ended for home use; do not use it for commercial or industrial purposes. 1 ● After removing the packaging, check the device for damage or evidence that may indicate a defect/failure. If in doubt, refrain from using the device and contact the supplier to proceed with inspection/repair. ● Keep the package away from small children, as it may be a danger to them! ● The humidifier should always be placed in a vertical position on a solid, flat, stable, and horizontal surface (i. e. never on a bed, sofa, thick carpet, etc.). Do not leave the device on a wooden floor for a long time; moisture can penetrate the wood and cause distortion! For the same reason, you shouldn't direct the outlet s of the moisture management system toward the furniture or items that should be handled with care. ● Access to the power source and, for best results, keep a distance of at least 10 cm from walls, large furniture, etc. Make sure the air inlet is not directly facing a wall or other large object. Do not place the humidifier near heat sources such as (gas) boilers, radiators, microwave ovens, hot plates, open fires, etc. ● Only use original supplied power adaptor. ● Please ensure prior to start-up operation that the voltage information corresponds to the local mains voltage. ● The power plug must be connected in such a way as to avoid risks if the humidifier is tipped over or liquid is spilled. ● Do not operate the device if the power plug or power cord is defective. ● Do not use the humidifier near heaters, fireplaces, or gas-powered devices. 2 ● The electric cable has a safe length. If necessary, you can use an extension cord with a power rating at least equal to that of the humidifier. Make sure that the electric cable is not exposed to high temperatures; keep it away from boilers, radiators, etc., and do not run it under carpets, etc., or in passageways. This could cause tripping and unintentional repositioning of the position of the humidifier. Prevent the cable from twisting and keep it out of the reach of children, animals, etc. ● Before connecting the humidifier, check that the data on the nameplate corresponds to the mains power supply and the technical data of the socket to which the humidifier is to be connected. Use only approved sockets with a 30 mA ground fault circuit int errupter. ● If the electrical socket used to power the humidifier is not properly connected, the plug of the appliance will get hot. Make sure that the humidifier is powered from a properly connected socket. ● The plug of the power cable must be connected in such a way as to ● Do not add water through the air outlets on the top side of humidifer. ● Bacteria and mould can form on the wick filter if the humidifer is not used for a longer time. Inspect the wick flter before using humidifier again. The wick filter should be changed if it has stains. ● Clean the water basin and wick filter every week to ensure optimum hygiene. ● Fill the water basin only with water. ● Do not stand on the device. ● NEVER tilt, move, or attempt to empty unit while it is operating. avoid danger if the humidifier is knocked over or spills. 3 ● The device should be used in accordance with its int ended purpose (i. e. for air humidification) and in accordance with the guidelines in the manual. You should never experiment with alt ernative uses of the ai r humidifier – regardless of its effectiveness – and make any changes to it. Any changes made to the humidifier and/or non-standard use of the humidifier will make the warranty null and void and release the manufacturer or importer from any liability. ● Please keep the humidifier clean and make sure that the inlet and outlet openings of the device (inner, side, and top) are not blocked. Never cover the humidifier with anything! Do not place any objects on the humidifier. Do not sit or stand on the device. ● Please make sure the device is under close supervision if used in the ● Shut off and unplug before removing the upper housing and moving the unit.DO NOT attempt to repair or adjust any electrical or mechanical functions on this unit. ● Doing so will void your warranty. The inside of the unit contains no user serviceable parts. ● All servicing should be performed by qualified personnel only. presence of children, disabled people, or pets. The device can be used by children over the age of 8 and people with limited physical, sensory, and int ellectual abilities, or lacking the necessary experience and knowledge – if they are supervised, or given instructions on the safe use of the device and the associated dangers. Cleaning and maintenance of the device must not be carried out by unsupervised children. Children should not play with the device. 4 ● You should turn off the humidifier and unplug it from the socket before: ○ Removing the water tank from the device, in order to refill it ○ Removing the top of the device ○ Cleaning and maintenance ○ Moving the device (be sure to empty the water tank first) ● Never pour water through the vents/outlet air (upper part of the housing); Otherwise, the device may be damaged! ● Fill th…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 1 of 4 Appendix External Photos for GZCR2409001034HS SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 2 of 4 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 3 of 4 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 4 of 4 - End of the Appendix -

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 1 of 8 Appendix Internal Photos for GZCR2409001034HS SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 2 of 8 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 3 of 8 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 4 of 8 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 5 of 8 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 6 of 8 ANT SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 7 of 8 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 8 of 8 - End of the Appendix -

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR240900103404 Page: 1 of 9 FCC ID: 2BLTM-KLHUMEA Ricky Liu Manager RF EXPOSURE EVALUATION REPORT Application No.: GZCR2409001034HS Applicant:KLARTA POLAND EU LTD Address of Applicant:Mickiewicza 37/58 01-625, Warsaw Poland Manufacturer:Comefresh(Xiamen) Electronic Co., Ltd. Address of Manufacturer:F2-4, No.35, Xiangyue Road, Xiang'an District, Xiamen, Fujian, P.R. China Factory:Comefresh(Xiamen) Electronic Co., Ltd. Address of Factory:F2-4, No.35, Xiangyue Road, Xiang'an District, Xiamen, Fujian, P.R. China Product Name:Evaporative humidifer Model No.: HUMEA WIFI Trade Mark:KLARTA Standard(s) : KDB 447498 D01 V06 47 CFR Part 1.1310 Date of Receipt: 2024-09-02 Date of Evaluation: 2024-09-19 to 2024-09-19 Date of Issue: 2024-11-07 Evaluation Result: Pass* * In the configuration evaluated, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR240900103404 Page: 2 of 9 Revision Record VersionReport No.DateRemark 01GZCR2409001034042024-11-07Original Authorized for issue by: Pank Feng/Project Engineer Vico Cui/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR240900103404 Page: 3 of 9 2Evaluation Summary ItemStandardMethodRequirementResult RF Exposure KDB 447498 D01 V06 KDB 447498 D01 V0647 CFR Part 1.1310Pass Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR240900103404 Page: 4 of 9 3Contents Page 1Cover Page...............................................................................................................................................1 2Evaluation Summary................................................................................................................................3 3Contents....................................................................................................................................................4 4General Information.................................................................................................................................5 4.1Details of E.U.T.................................................................................................................................5 4.2Evaluating Location...........................................................................................................................5 4.3Facility...............................................................................................................................................6 4.4Deviation from Standards..................................................................................................................6 4.5Abnormalities from Standard Conditions...........................................................................................6 5Technical Requirements Specification..................................................................................................7 5.1General Description of Applied Standards........................................................................................7 5.2RF Exposure Evaluation....................................................................................................................7 5.2.1Limit & Test Method......................................................................................................................7 5.2.2Conclusion....................................................................................................................................8 6EUT Constructional Details (EUT Photos).............................................................................................9 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR240900103404 Page: 5 of 9 4General Information 4.1Details of E.U.T. Power supply:AC/DC adapter: Model: XH1200-1000W Input: AC 100-240V 50/60Hz Output: DC 12V 1A Cable(s):DC cable from adaptor: about 1.8m unshielded For BLE Operation Frequency:2402MHz to 2480MHz Modulation Type:GFSK Number of Channels:40 Channel Spacing:2MHz Antenna Type:PCB Antenna Antenna Gain:2.54 dBi according to antenna specification Antenna Number:1 For 2.4GHz Wi-Fi Operation Frequency:802.11b/g/n(HT20): 2412MHz to 2462MHz Modulation Type: 802.11b: DSSS (CCK, DQPSK, DBPSK);802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) Number of Channels:802.11b/g/n(HT20):11 Channel Spacing:5MHz Antenna Type:PCB Antenna Antenna Gain:2.54 dBi according to antenna specification Antenna Number:1 Remark: The information in this section is provided by the applicant or manufacturer, SGS is not liable to the accuracy, suitability, reliability or/and integrity of the information. 4.2Evaluating Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd., Guangzhou Branch EMC Laboratory, No.198, Kezhu Road, Science City, Economic & Technological Development Area, Guangzhou, Guangdong, China 510663 Tel: +86 20 82155555 No tests were sub-contracted. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR240900103404 Page: 6 of 9 4.3Facility The facility is recognized, certified, or accredited by the following organizations: ● ACMA SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory can also perform testing for the Australian/New Zealand Regulatory Compliance Mark (RCM). ● SGS UK(Certificate No.: 32), SGS-TUV SAARLAND and SGS-FIMKO Have approved SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory as a supplier of EMC TESTING SERVICES and SAFETY TESTING SERVICES. ● FCC Recognized Accredited Test Firm(Registration No.: 486818) SGS-CSTC Standards Tec…

Text truncated - open the document above for the full version.

AntennaSpecification Manufacture：TUYA ProductName：WBR3Antenna AntennaType：PCB TestDate：2021.05.20 Testedby：LongWang Approvedby：Licco Content 1.GeneralDescription.................................................................................1 2.TestConfigurations...................................................................................2 2.1TestEnvironment............................................................................2 2.2TestEquipment...............................................................................2 2.3TestPrinciple...................................................................................2 3.TestResults..............................................................................................3 3.1GainandEfficiency..........................................................................3 3.2RadiationPattern............................................................................4 4.AntennaDimensions................................................................................6 5.EUTPhoto................................................................................................6 6.TestSetupPhoto......................................................................................7 1 1.GeneralDescription ManufacturerHangzhouTuyaInformationTechnologyCo.,Ltd Address Room701,Building3,MoreCenter,No.87GuDunRoad, Hangzhou,Zhejiang,China TestLocation Room106,Building3,LetongSciencePark,No.500, QiuyiRoad,BinjiangDistrict,Hangzhou ProductNameWBR3Antenna Productmodel WBR3 AntennaType PCBAntenna TestItems Gain;Efficiency;RadiationPattern TestFrequency 2400-2500MHz TestStandard ANSI/IEEEStd149-1979 2 2.TestConfigurations 2.1TestEnvironment Temperature(°C)25 Humidity(%RH)60 AtmosphericPressure(kPa)100.5 2.2TestEquipment TestSystemTEM24Multi-probeMicrowaveChamber TestInstrumentAgilentE5071B 2.3TestPrinciple 3 3.TestResults 3.1GainandEfficiency Frequency(MHz)PeakGain(dBi)Efficiency(%) 2400 1.6252.29 2410 1.7152.17 2420 1.9353.14 2430 1.9854.16 2440 2.0057.62 2450 2.1759.64 2460 2.4561.55 2470 2.3860.64 2480 2.5462.86 2490 2.3059.85 2500 2.4960.41 4 3.2RadiationPattern Phi02D Phi902D 5 Theta902D 2480MHz3D 6 4.AntennaDimensions 5.EUTPhoto 7 6.TestSetupPhoto

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240900103402 Page: 1 of 56 FCC ID: 2BLTM-KLHUMEA Ricky Liu Manager TEST REPORT Application No.: GZCR2409001034HS Applicant:KLARTA POLAND EU LTD Address of Applicant:Mickiewicza 37/58 01-625, Warsaw Poland Manufacturer:Comefresh(Xiamen) Electronic Co., Ltd. Address of Manufacturer:F2-4, No.35, Xiangyue Road, Xiang'an District, Xiamen, Fujian, P.R. China Factory:Comefresh(Xiamen) Electronic Co., Ltd. Address of Factory:F2-4, No.35, Xiangyue Road, Xiang'an District, Xiamen, Fujian, P.R. China Product Name:Evaporative humidifer Model No.: HUMEA WIFI Trade Mark:KLARTA Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2024-09-02 Date of Test: 2024-09-05 to 2024-09-19 Date of Issue: 2024-11-07 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240900103402 Page: 2 of 56 Revision Record VersionReport No.DateRemark 01GZCR2409001034022024-11-07Original Authorized for issue by: Pank Feng/Project Engineer Vico Cui/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240900103402 Page: 3 of 56 2Test Summary Radio Spectrum Technical Requirement ItemStandardMethodRequirementResult Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part ItemStandardMethodRequirementResult Conducted Emissions at AC Power Line (150kHz-30MHz) ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 11.12 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2013) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2013) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Conducted Peak Output Power ANSI C63.10 (2013) Section 11.9.1 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240900103402 Page: 4 of 56 3Contents Page 1Cover Page.................................................................................................................................................1 2Test Summary............................................................................................................................................3 3Contents.....................................................................................................................................................4 4General Information...................................................................................................................................6 4.1Details of E.U.T...................................................................................................................................6 4.2Description of Support Units................................................................................................................6 4.3Measurement Uncertainty...................................................................................................................7 4.4Test Location.......................................................................................................................................7 4.5Test Facility.........................................................................................................................................8 4.6Deviation from Standards....................................................................................................................8 4.7Abnormalities from Standard Conditions.............................................................................................8 5Equipment List...........................................................................................................................................9 6Radio Spectrum Technical Requirement...............................................................................................11 6.1Antenna Requirement.......................................................................................................................11 6.1.1Test Requirement:........................................................................................................................11 6.1.2Conclusion....................................................................................................................................11 7Radio Spectrum Matter Test Results.....................................................................................................12 7.1Conducted Emissions at AC Power Line (150kHz-30MHz)..............................................................12 7.1.1E.U.T. Operation...........................................................................................................................12 7.1.2Test Mode Description..................................................................................................................12 7.1.3Test Setup Diagram....................................................................................................…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240900103403 Page: 1 of 86 FCC ID: 2BLTM-KLHUMEA Ricky Liu Manager TEST REPORT Application No.: GZCR2409001034HS Applicant: KLARTA POLAND EU LTD Address of Applicant: Mickiewicza 37/58 01-625, Warsaw Poland Manufacturer: Comefresh(Xiamen) Electronic Co., Ltd. Address of Manufacturer: F2-4, No.35, Xiangyue Road, Xiang'an District, Xiamen, Fujian, P.R. China Factory: Comefresh(Xiamen) Electronic Co., Ltd. Address of Factory: F2-4, No.35, Xiangyue Road, Xiang'an District, Xiamen, Fujian, P.R. China Product Name: Evaporative humidifer Model No.: HUMEA WIFI Trade Mark: KLARTA Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2024-09-02 Date of Test: 2024-09-05 to 2024-09-19 Date of Issue: 2024-11-07 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240900103403 Page: 2 of 86 Revision Record Version Report No. Date Remark 01 GZCR240900103403 2024-11-07 Original Authorized for issue by: Pank Feng/Project Engineer Vico Cui/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240900103403 Page: 3 of 86 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 11.12 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2013) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2013) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Conducted Peak Output Power ANSI C63.10 (2013) Section 11.9.2 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240900103403 Page: 4 of 86 3 Contents Page 1 Cover Page .............................................................................................................................................. 1 2 Test Summary ......................................................................................................................................... 3 3 Contents .................................................................................................................................................. 4 4 General Information................................................................................................................................ 6 4.1 Details of E.U.T. ............................................................................................................................... 6 4.2 Description of Support Units ............................................................................................................. 6 4.3 Measurement Uncertainty ................................................................................................................ 7 4.4 Test Location.................................................................................................................................... 7 4.5 Test Facility ...................................................................................................................................... 8 4.6 Deviation from Standards ................................................................................................................. 8 4.7 Abnormalities from Standard Conditions .......................................................................................... 8 5 Equipment List........................................................................................................................................ 9 6 Radio Spectrum Technical Requirement ............................................................................................ 11 6.1 Antenna Requirement .................................................................................................................... 11 6.1.1 Test Requirement: ..................................................................................................................... 11 6.1.2 Conclusion ................................................................................................................................. 11 7 Radio Spectrum Matter Test Results................................................................................................... 12 7.1 Conducted Emissions at AC Power Line (150kHz-30MHz)............................................................. 12 7.1.1 E.U.T. Operation ........................................................................................................................ 12 7.1.2 Test Mode Description ............................................................................................................... 12 7.1.3 Test Setup Diagram ............................................................................…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-04 Rev 1.1 Page: 1 of 5 Appendix Test Setup Photo for GZCR240900103402 & GZCR240900103403 Test Model No.: HUMEA WIFI SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-04 Rev 1.1 Page: 2 of 5 Test Setup Photo Conducted Emissions at AC Power Line (150kHz-30MHz) SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-04 Rev 1.1 Page: 3 of 5 Radiated Emissions which fall in the restricted bands & Radiated Spurious Emissions Above 1GHz SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-04 Rev 1.1 Page: 4 of 5 Radiated Spurious Emissions Below 1GHz SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-04 Rev 1.1 Page: 5 of 5 - End of the Appendix -
