QL14R5YGW8256 Quick User Manual COMPAQ and the COMPAQ logo are trademarks or registered trademarks of HP Development Company, L.P. and are used under licenseby M&M Electronics, S. A. All other trademarks are the property of their respective owners © 2018 HPDC, L. P. Made in China. 2 1 1 2 6 9 10 11 4 3 7 5 8 Seria number123456 789 1011 USB 3.2 Camera Camera praivacy switch HDMI Seria nu De cri n mber Type-C(Data Only) DC in Micro SD card Headphone jack USB 3.2 USB 3.2 File Explorer SettingsPower ° ° ° ° ° ° ° ° ° ° 19V, 3.42A La operación está sujeta a las siguientes dos condiciones: recibida, incluidas las interferencias que puedan provocar un funcionamiento no deseado o Cambios o modificaciones no aprobadas expresamente por la parte responsable del cumplimiento, pueden anular la autoridad del usuario para operar el equipo. Exposición a radiofrecuencia Ce cahier répond aux exigences du gouvernement en matière d’exposition aux ondes radio. Les lignes directrices sont fondées sur des normes élaborées par des organismes scientifiques indépendants à la suite d’une évaluation périodique et approfondie d’études scientifiques. Les normes comportent une marge de sécurité importante conçue pour assurer la sécurité de toutes les personnes, quel que soit leur âge ou leur état de santé. Énoncé et Information sur l’exposition aux RF de la FCC la limite du das corporel des États-Unis (FCC) est de 1,6 W/kg en moyenne sur un gramme de tissu, et la limite du das des membres des États-Unis (FCC) est de 4,0 W/kg en moyenne sur un gramme de tissu. Types d’appareils: Notebook a également été testé par rapport à cette limite de das. Cet appareil a été testé pour des opérations typiques portant le corps avec le dos du carnet à 0mm du corps. Pour respecter les exigences de la FCC en matière d’exposition aux RF, utilisez des accessoires qui maintiennent une distance de séparation de 0 mm entre le corps de l’utilisateur et le dos de l’ordinateur portable. L’utilisation de clips de ceinture, de étuis et d’accessoires similaires ne doit pas contenir de composants métalliques dans son assemblage. L’utilisation d’accessoires qui ne satisfont pas à ces exigences peut ne pas être conforme aux exigences de la FCC en matière d’exposition aux RF et devrait être évitée. Precaución de la FCC: Cualquier cambio o modificación no aprobado expresamente por la parte responsable del cumplimiento podría anular la autoridad del usuario para operar el equipo. interferencias que puedan causar un funcionamiento no deseado. NOTA IMPORTANTE: Clase B, de conformidad con la parte 15 de las reglas de la FCC. Estos límites están diseñados para proporcionar una protección razonable contra interferencias dañinas en una instalación residencial. Este equipo genera, usa y puede irradiar energía de radiofrecuencia y, si no se instala y usa de acuerdo con las instrucciones, puede causar interferencias dañinas en la recepción de radio o televisión, lo cual se puede determinar encendiendo y apagando el equipo, se recomienda al usuario que intente corregir la interferencia mediante una o más de las siguientes medidas: —Reoriente o reubique la antena receptora. —Aumentar la separación entre el equipo y el receptor. —Conecte el equipo a una toma de corriente de un circuito diferente al que está conectado el receptor. —Consulte al distribuidor o a un técnico experimentado en radio/TV para obtener ayuda. Declaración de exposición a la radiación de la FCC: compliance could void the user's authority to operate the equipment. (2) this device must accept any interference received, including interference that IMPORTANT NOTE: Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to This equipment generates, uses and can radiate radio frequency energy and, if not turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. The device has been tested and complies with FCC SAR limits. This device complies with part 15 of the FCC rules. (1) This device may not cause harmful interference, and either (2) this device must accept any interference received, responsible for compliance may void the user's authority to operate the equipment. RF Exposure This Notebook meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health. FCC RF Exposure Information and Statement the Body SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue, and the Limb SAR limit of USA (FCC) is 4.0 W/kg averaged over one gram of tissue. Device types: Notebook has also been tested against this SAR limit. This device was tested for typical body-worn operations with the back of the Notebook kept 0mm from the body. To maintain compliance with FCC RF exposure requirements, use accessories that maintain an 0 mm separation distance between the user's body and the back of the Notebook. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided. 9

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R10515E-SA TR-EM-SA005 Page 1 of 37 Version 3.0 APPENDIX D CALIBRATION CERTIFICATES Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R10515E-SA TR-EM-SA005 Page 2 of 37 Version 3.0 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R10515E-SA TR-EM-SA005 Page 3 of 37 Version 3.0 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R10515E-SA TR-EM-SA005 Page 4 of 37 Version 3.0 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R10515E-SA TR-EM-SA005 Page 5 of 37 Version 3.0 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R10515E-SA TR-EM-SA005 Page 6 of 37 Version 3.0 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R10515E-SA TR-EM-SA005 Page 7 of 37 Version 3.0 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R10515E-SA TR-EM-SA005 Page 8 of 37 Version 3.0 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R10515E-SA TR-EM-SA005 Page 9 of 37 Version 3.0 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R10515E-SA TR-EM-SA005 Page 10 of 37 Version 3.0 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R10515E-SA TR-EM-SA005 Page 11 of 37 Version 3.0 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R10515E-SA TR-EM-SA005 Page 12 of 37 Version 3.0 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R10515E-SA TR-EM-SA005 Page 13 of 37 Version 3.0 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R10515E-SA TR-EM-SA005 Page 14 of 37 Version 3.0 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R10515E-SA TR-EM-SA005 Page 15 of 37 Version 3.0 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R10515E-SA TR-EM-SA005 Page 16 of 37 Version 3.0 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R10515E-SA TR-EM-SA005 Page 17 of 37 Version 3.0 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R10515E-SA TR-EM-SA005 Page 18 of 37 Version 3.0

FCC ID: 2BLU9-QL14R5Y _______________________________________________________________________________________________ Page 1 of 2 1. TEST SETUP PHOTOGRAPHS 1.1. Photo of Radiated Emissions Measurement Fig. 1 Fig. 2 FCC ID: 2BLU9-QL14R5Y _______________________________________________________________________________________________ Page 2 of 2 Photo of Conducted Emission Measurement Fig. 3 Fig. 4

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. .....................: FCC ID. ............................................ : GTS20260115008-1-03 2BLU9-QL14R5Y Compiled by ( position+printed name+signature) .. : File administrators Peter Xiao Supervised by ( position+printed name+signature) .. : Test Engineer Evan Ouyang Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : Mar.17, 2026 Representative Laboratory Name .: Shenzhen Global Test Service Co.,Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong,China Applicant’s name ............................ : M&M ELECTRONICS ,S.A. Address ............................................ : Cocosolito, Colon Free Zone, Main Entrance Warehouse 10D and 11D, Colon, Panama Test specification ...........................: Standard ........................................... : FCC Part 15.247: Operation within the bands 902-928 MHz, 2400- 2483.5 MHz and 5725-5850 MHz TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Notebook Trade Mark ....................................... : COMPAQ Manufacturer .................................... : M&M ELECTRONICS ,S.A. Model/Type reference....................... : QL14R5YGW8256 Listed Models .................................. : N/A Operation Frequency ........................ : From 2412MHz to 2462MHz Hardware Version ............................ : N/A Software Version .............................. : N/A Rating ............................................... : DC 11.4V by battery Recharged by DC 19.0V Result................................................ : PASS Report No.: GTS20260115008-1-03 Page 2 of 27 T E S T R E P O R T Test Report No. : GTS20260115008-1-03 Mar.17, 2026 ____________________________________________________________________________________ __________ Date of issue Equipment under Test : Notebook Model /Type : QL14R5YGW8256 Listed model : N/A Applicant : M&M ELECTRONICS ,S.A. Address : Cocosolito, Colon Free Zone, Main Entrance Warehouse 10D and 11D, Colon, Panama Manufacturer : M&M ELECTRONICS ,S.A. Address : Cocosolito, Colon Free Zone, Main Entrance Warehouse 10D and 11D, Colon, Panama Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20260115008-1-03 Page 3 of 27 Contents 1. TEST STANDARDS ......................................................................................................................................... 4 2. SUMMARY ....................................................................................................................................................... 5 2.1. General Remarks ................................................................................................................................... 5 2.2. Product Description ................................................................................................................................ 5 2.3. Equipment Under Test ........................................................................................................................... 7 2.4. Short description of the Equipment under Test (EUT) ........................................................................... 7 2.5. EUT operation mode .............................................................................................................................. 7 2.6. Block Diagram of Test Setup ................................................................................................................. 7 2.7. Related Submittal(s) / Grant (s) ............................................................................................................. 7 2.8. EUT Exercise Software .......................................................................................................................... 8 2.9. Special Accessories ............................................................................................................................... 8 2.10. External I/O Cable ................................................................................................................................ 8 2.11. Modifications ........................................................................................................................................ 8 3. TEST ENVIRONMENT ..................................................................................................................................... 9 3.1. Address of the test laboratory ................................................................................................................ 9 3.2. Test Facility ............................................................................................................................................ 9 3.3. Environmental conditions .......................................…

Text truncated - open the document above for the full version.

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID............................................. : GTS20260115008-1-02 2BLU9-QL14R5Y Compiled by ( position+printed name+signature) . : File administrators Peter Xiao Supervised by ( position+printed name+signature) . : Test Engineer Evan Ouyang Approved by ( position+printed name+signature) . : Manager Jason Hu Date of issue .................................... : Mar.17, 2026 Representative Laboratory Name . : Shenzhen Global Test Service Co.,Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong,China Applicant’s name ............................ : M&M ELECTRONICS ,S.A. Address ............................................ : Cocosolito, Colon Free Zone, Main Entrance Warehouse 10D and 11D, Colon, Panama Test specification ........................... : Standard ........................................... : FCC Part 15.247 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ...................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Notebook Trade Mark ....................................... : COMPAQ Manufacturer .................................... : M&M ELECTRONICS ,S.A. Model/Type reference ...................... : QL14R5YGW8256 Listed Models .................................. : N/A Modulation Type ............................... : GFSK Operation Frequency ........................ : From 2402MHz to 2480MHz Hardware Version ............................ : N/A Software Version .............................. : N/A Rating ............................................... : DC 11.4V by battery Recharged by DC 19.0V Result ............................................... : PASS Report No.: GTS20260115008-1-02 Page 2 of 26 T E S T R E P O R T Test Report No. : GTS20260115008-1-02 Mar.17, 2026 ______________________________________________________________________________________________ Date of issue Equipment under Test : Notebook Model /Type : QL14R5YGW8256 Listed model : N/A Applicant : M&M ELECTRONICS ,S.A. Address : Cocosolito, Colon Free Zone, Main Entrance Warehouse 10D and 11D, Colon, Panama Manufacturer : M&M ELECTRONICS ,S.A. Address : Cocosolito, Colon Free Zone, Main Entrance Warehouse 10D and 11D, Colon, Panama Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20260115008-1-02 Page 3 of 26 Contents 1. TEST STANDARDS ......................................................................................................................................... 4 2. SUMMARY ....................................................................................................................................................... 5 2.1. General Remarks ................................................................................................................................... 5 2.2. Product Description ................................................................................................................................ 5 2.3. Equipment Under Test ........................................................................................................................... 7 2.4. Short description of the Equipment under Test (EUT) ........................................................................... 7 2.5. EUT operation mode .............................................................................................................................. 7 2.6. Block Diagram of Test Setup ................................................................................................................. 8 2.7. EUT Exercise Software .......................................................................................................................... 8 2.8. Special Accessories ............................................................................................................................... 8 2.9. External I/O Cable .................................................................................................................................. 8 2.10. Related Submittal(s) / Grant (s) ........................................................................................................... 8 2.11. Modifications ........................................................................................................................................ 8 3. TEST ENVIRONMENT ..................................................................................................................................... 9 3.1. Address of the test laboratory ................................................................................................................ 9 3.2. Test Facility ............................................................................................................................................ 9 3.3. Environmental conditions ...............................................................…

Text truncated - open the document above for the full version.

FCC ID:2BLU9-QL14R5Y 1 Case No. : GTS20260115008-1-03 Ambient Condition: 23°C,54%RH, Test Date:2026.2.25-2026.3.16Test Engineer:Evan ouyang Appendix C.1: DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant2 2412 10.320 2406.840 2417.160 0.5 PASS 2437 10.320 2431.840 2442.160 0.5 PASS 2462 10.320 2456.840 2467.160 0.5 PASS 11G Ant2 2412 16.360 2403.800 2420.160 0.5 PASS 2437 16.360 2428.880 2445.240 0.5 PASS 2462 16.320 2453.840 2470.160 0.5 PASS 11N20SISO Ant2 2412 17.560 2403.200 2420.760 0.5 PASS 2437 17.480 2428.240 2445.720 0.5 PASS 2462 17.360 2453.280 2470.640 0.5 PASS 11N40SISO Ant2 2422 36.160 2404.000 2440.160 0.5 PASS 2437 36.080 2419.080 2455.160 0.5 PASS 2452 36.080 2434.000 2470.080 0.5 PASS FCC ID:2BLU9-QL14R5Y 2 Test Graphs 11B_Ant2_2412 11B_Ant2_2437 11B_Ant2_2462 FCC ID:2BLU9-QL14R5Y 3 11G_Ant2_2412 11G_Ant2_2437 FCC ID:2BLU9-QL14R5Y 4 11G_Ant2_2462 11N20SISO_Ant2_2412 11N20SISO_Ant2_2437 FCC ID:2BLU9-QL14R5Y 5 11N20SISO_Ant2_2462 11N40SISO_Ant2_2422 FCC ID:2BLU9-QL14R5Y 6 11N40SISO_Ant2_2437 11N40SISO_Ant2_2452 FCC ID:2BLU9-QL14R5Y 7 Appendix C.2: Occupied Channel Bandwidth Test Result TestMode Antenna Channel Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant2 2412 14.935 2404.4910 2419.4260 --- --- 2437 14.900 2429.5697 2444.4697 --- --- 2462 14.902 2454.5065 2469.4085 --- --- 11G Ant2 2412 16.865 2403.4869 2420.3519 --- --- 2437 16.784 2428.5770 2445.3610 --- --- 2462 16.791 2453.5517 2470.3427 --- --- 11N20SISO Ant2 2412 17.820 2403.0749 2420.8949 --- --- 2437 17.807 2428.0826 2445.8896 --- --- 2462 17.804 2453.0680 2470.8720 --- --- 11N40SISO Ant2 2422 36.278 2403.9276 2440.2056 --- --- 2437 36.125 2419.0228 2455.1478 --- --- 2452 36.120 2433.9779 2470.0979 --- --- FCC ID:2BLU9-QL14R5Y 8 Test Graphs 11B_Ant2_2412 11B_Ant2_2437 11B_Ant2_2462 FCC ID:2BLU9-QL14R5Y 9 11G_Ant2_2412 11G_Ant2_2437 FCC ID:2BLU9-QL14R5Y 10 11G_Ant2_2462 11N20SISO_Ant2_2412 11N20SISO_Ant2_2437 FCC ID:2BLU9-QL14R5Y 11 11N20SISO_Ant2_2462 11N40SISO_Ant2_2422 FCC ID:2BLU9-QL14R5Y 12 11N40SISO_Ant2_2437 11N40SISO_Ant2_2452 FCC ID:2BLU9-QL14R5Y 13 Appendix C.3: Maximum conducted output power Test Result -CHP Test Mode Antenna Frequency [MHz] Peak power [dBm] AV power [dBm] Limit [dBm] Verdict 11B Ant2 2412 17.24 15.12 ≤30.00 PASS 2437 18.04 15.99 ≤30.00 PASS 2462 18.53 15.77 ≤30.00 PASS 11G Ant2 2412 18.63 15.01 ≤30.00 PASS 2437 19.57 16.07 ≤30.00 PASS 2462 20.46 17.34 ≤30.00 PASS 11N20SISO Ant2 2412 17.05 12.77 ≤30.00 PASS 2437 17.98 13.04 ≤30.00 PASS 2462 19.80 14.91 ≤30.00 PASS 11N40SISO Ant2 2422 17.11 11.21 ≤30.00 PASS 2437 17.73 12.13 ≤30.00 PASS 2452 18.05 13.02 ≤30.00 PASS FCC ID:2BLU9-QL14R5Y 14 Appendix C.4: Maximum power spectral density Test Result TestMode Antenna Frequency[MHz] Result[dBm/3-100kHz] Limit[dBm/3kHz] Verdict 11B Ant2 2412 -15.91 ≤8.00 PASS 2437 -15.08 ≤8.00 PASS 2462 -14.53 ≤8.00 PASS 11G Ant2 2412 -16.23 ≤8.00 PASS 2437 -15.60 ≤8.00 PASS 2462 -14.88 ≤8.00 PASS 11N20SISO Ant2 2412 -17.67 ≤8.00 PASS 2437 -17.05 ≤8.00 PASS 2462 -15.24 ≤8.00 PASS 11N40SISO Ant2 2422 -19.43 ≤8.00 PASS 2437 -17.79 ≤8.00 PASS 2452 -18.96 ≤8.00 PASS FCC ID:2BLU9-QL14R5Y 15 Test Graphs 11B_Ant2_2412 11B_Ant2_2437 11B_Ant2_2462 FCC ID:2BLU9-QL14R5Y 16 11G_Ant2_2412 11G_Ant2_2437 FCC ID:2BLU9-QL14R5Y 17 11G_Ant2_2462 11N20SISO_Ant2_2412 11N20SISO_Ant2_2437 FCC ID:2BLU9-QL14R5Y 18 11N20SISO_Ant2_2462 11N40SISO_Ant2_2422 FCC ID:2BLU9-QL14R5Y 19 11N40SISO_Ant2_2437 11N40SISO_Ant2_2452 FCC ID:2BLU9-QL14R5Y 20 Appendix C.5:Band edge measurements Test Result TestMode Antenna ChName Frequency [MHz] RefLevel[dBm] Result[dBm] Limit[dBm] Verdict 11B Ant2 Low 2412 3.98 -39.95 ≤-16.02 PASS High 2462 5.37 -46.64 ≤-14.63 PASS 11G Ant2 Low 2412 -2.53 -38.11 ≤-22.53 PASS High 2462 -0.65 -47.49 ≤-20.65 PASS 11N20SISO Ant2 Low 2412 -4.19 -41.17 ≤-24.19 PASS High 2462 -1.39 -46.98 ≤-21.39 PASS 11N40SISO Ant2 Low 2422 -6.93 -43.07 ≤-26.93 PASS High 2452 -5.71 -47.14 ≤-25.71 PASS FCC ID:2BLU9-QL14R5Y 21 Test Graphs 11B_Ant2_Low_2412 11B_Ant2_High_2462 11G_Ant2_Low_2412 FCC ID:2BLU9-QL14R5Y 22 11G_Ant2_High_2462 11N20SISO_Ant2_Low_2412 FCC ID:2BLU9-QL14R5Y 23 11N20SISO_Ant2_High_2462 11N40SISO_Ant2_Low_2422 11N40SISO_Ant2_High_2452 FCC ID:2BLU9-QL14R5Y 24 FCC ID:2BLU9-QL14R5Y 25 Appendix C.6:Conducted Spurious Emission Test Result TestMode Antenna Frequency[MHz] FreqRange [Mhz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict 11B Ant2 2412 Reference 3.41 3.41 --- PASS 30~1000 3.41 -61.1 ≤-16.59 PASS 1000~26500 3.41 -47.93 ≤-16.59 PASS 2437 Reference 4.57 4.57 --- PASS 30~1000 4.57 -60.66 ≤-15.43 PASS 1000~26500 4.57 -47.87 ≤-15.43 PASS 2462 Reference 5.14 5.14 --- PASS 30~1000 5.14 -60.47 ≤-14.86 PASS 1000~26500 5.14 -47.61 ≤-14.86 PASS 11G Ant2 2412 Reference -2.69 -2.69 --- PASS 30~1000 -2.69 -59.88 ≤-22.69 PASS 1000~26500 -2.69 -47.61 ≤-22.69 PASS 2437 Reference -1.78 -1.78 --- PASS 30~1000 -1.78 -60.67 ≤-21.78 PASS 1000~26500 -1.78 -46.8 ≤-21.78 PASS 2462 Reference -0.70 -0.70 --- PASS 30~1000 -0.70 -60.65 ≤-20.7 PASS 1000~26500 -0.70 -47.7 ≤-20.7 PASS 11N20SISO Ant2 2412 Reference -5.19 -5.19 --- PASS 30~1000 -5.19 -60.28 ≤-25.19 PASS 1000~26500 -5.19 -46.83 ≤-25.19 PASS 2437 Reference -3.80 -3.80 --- PASS 30~1000 -3.80 -60.24 ≤-23.8 PASS 1000~26500 -3.80 -47.21 ≤-23.8 PASS 2462 Reference -1.94 -1.94 --- PASS 30~1000 -1.94 -60.01 ≤-21.94 PASS 1000~26500 -1.94 -47.6 ≤-21.94 PASS 11N40SISO Ant2 2422 Reference -7.43 -7.43 --- PASS 30~1000 -7.43 -59.83 ≤-27.43 PASS 1000~26500 -7.43 -47.73 ≤-27.43 PASS 2437 Reference -6.66 -6.66 --- PASS 30~1000 -6.66 -60.59 ≤-26.66 PASS 1000~26500 -6.66 -47.49 ≤-26.66 PASS 2452 Reference -6.85 -6.85 --- PASS 30~1000 -6.85 -60.67 ≤-26.85 PASS 1000~26500 -6.85 -47.86 ≤-26.85 PASS FCC ID:2BLU9-QL14R5Y 26 Test Graphs 11B_Ant2_2412_0~Reference 11B_Ant2_2412_30~1000 11B_Ant2_2412_1000~26500 FCC ID:2BLU9-QL14R5Y 27 11B_Ant2_2437_0~Reference 11B_Ant2_2437_30~1000 FCC ID:2BLU9-QL14R5Y 28 11B_Ant2_2437_1000~26500 11…

Text truncated - open the document above for the full version.

FCC ID:2BLU9-QL14R5Y 1 Case No. : GTS20260115008-1-03 Ambient Condition: 21°C,56%RH, Test Date:2026.2.25-2026.3.16Test Engineer:Evan ouyang Appendix C.1: DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 10.320 2406.840 2417.160 0.5 PASS 2437 10.320 2431.840 2442.160 0.5 PASS 2462 10.320 2456.840 2467.160 0.5 PASS 11G Ant1 2412 16.280 2403.840 2420.120 0.5 PASS 2437 16.280 2428.920 2445.200 0.5 PASS 2462 16.360 2453.800 2470.160 0.5 PASS 11N20SISO Ant1 2412 17.440 2403.240 2420.680 0.5 PASS 2437 17.520 2428.240 2445.760 0.5 PASS 2462 17.400 2453.320 2470.720 0.5 PASS 11N40SISO Ant1 2422 36.000 2404.080 2440.080 0.5 PASS 2437 35.920 2419.160 2455.080 0.5 PASS 2452 35.920 2434.080 2470.000 0.5 PASS FCC ID:2BLU9-QL14R5Y 2 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 FCC ID:2BLU9-QL14R5Y 3 11G_Ant1_2412 11G_Ant1_2437 FCC ID:2BLU9-QL14R5Y 4 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 FCC ID:2BLU9-QL14R5Y 5 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 FCC ID:2BLU9-QL14R5Y 6 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 FCC ID:2BLU9-QL14R5Y 7 Appendix C.2: Occupied Channel Bandwidth Test Result TestMode Antenna Channel Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 14.956 2404.5096 2419.4656 --- --- 2437 14.905 2429.5817 2444.4867 --- --- 2462 14.930 2454.4869 2469.4169 --- --- 11G Ant1 2412 16.858 2403.5081 2420.3661 --- --- 2437 16.840 2428.5304 2445.3704 --- --- 2462 16.776 2453.5426 2470.3186 --- --- 11N20SISO Ant1 2412 17.811 2403.0600 2420.8710 --- --- 2437 17.822 2428.0821 2445.9041 --- --- 2462 17.766 2453.0861 2470.8521 --- --- 11N40SISO Ant1 2422 36.301 2403.9574 2440.2584 --- --- 2437 36.158 2419.0272 2455.1852 --- --- 2452 36.088 2434.0203 2470.1083 --- --- FCC ID:2BLU9-QL14R5Y 8 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 FCC ID:2BLU9-QL14R5Y 9 11G_Ant1_2412 11G_Ant1_2437 FCC ID:2BLU9-QL14R5Y 10 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 FCC ID:2BLU9-QL14R5Y 11 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 FCC ID:2BLU9-QL14R5Y 12 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 FCC ID:2BLU9-QL14R5Y 13 Appendix C.3: Maximum conducted output power Test Result -CHP Test Mode Antenna Frequency [MHz] Peak power [dBm] AV power [dBm] Limit [dBm] Verdict 11B Ant1 2412 17.80 14.99 ≤30.00 PASS 2437 18.74 16.00 ≤30.00 PASS 2462 19.20 16.95 ≤30.00 PASS 11G Ant1 2412 16.96 13.87 ≤30.00 PASS 2437 18.24 14.35 ≤30.00 PASS 2462 19.01 15.53 ≤30.00 PASS 11N20SISO Ant1 2412 17.58 12.89 ≤30.00 PASS 2437 18.67 13.68 ≤30.00 PASS 2462 19.69 15.30 ≤30.00 PASS 11N40SISO Ant1 2422 18.37 12.97 ≤30.00 PASS 2437 18.11 12.19 ≤30.00 PASS 2452 18.87 13.37 ≤30.00 PASS FCC ID:2BLU9-QL14R5Y 14 Appendix C.4: Maximum power spectral density Test Result TestMode Antenna Frequency[MHz] Result[dBm/3-100kHz] Limit[dBm/3kHz] Verdict 11B Ant1 2412 -15.32 ≤8.00 PASS 2437 -14.30 ≤8.00 PASS 2462 -14.04 ≤8.00 PASS 11G Ant1 2412 -17.92 ≤8.00 PASS 2437 -16.76 ≤8.00 PASS 2462 -16.41 ≤8.00 PASS 11N20SISO Ant1 2412 -16.91 ≤8.00 PASS 2437 -15.50 ≤8.00 PASS 2462 -15.00 ≤8.00 PASS 11N40SISO Ant1 2422 -17.15 ≤8.00 PASS 2437 -17.91 ≤8.00 PASS 2452 -16.53 ≤8.00 PASS FCC ID:2BLU9-QL14R5Y 15 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 FCC ID:2BLU9-QL14R5Y 16 11G_Ant1_2412 11G_Ant1_2437 FCC ID:2BLU9-QL14R5Y 17 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 FCC ID:2BLU9-QL14R5Y 18 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 FCC ID:2BLU9-QL14R5Y 19 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 FCC ID:2BLU9-QL14R5Y 20 Appendix C.5:Band edge measurements Test Result TestMode Antenna ChName Frequency [MHz] RefLevel[dBm] Result[dBm] Limit[dBm] Verdict 11B Ant1 Low 2412 4.40 -38.75 ≤-15.6 PASS High 2462 5.98 -45.18 ≤-14.02 PASS 11G Ant1 Low 2412 -4.16 -39.95 ≤-24.16 P…
