2BLVV-QW16Q2Smart camera

FCC ID LABEL: Ca. 6mm x 20mm Label Location FCC ID: 2BLVV-QW16Q2

MPE ESTIMATION FCC ID: 2BLVV-QW16Q2 1,Per FCC Part 2.1091 Radiofrequency radiation exposure evaluation: mobile devices, the limit for General Population/ Uncontrolled Exposures Frequency Power density (mW/ cm 2 ) Averaging time(minutes) 300MHz----1.5GHz F/1500 30 1.5GHz---100GHz 1.0 30 Note: F= Frequency in MHz 2, Estimation Result When the minimum test separation distance is >20 cm, a distance of 20 cm is applied to determine RF Exposure test exclusion. The test exclusion threshold is 0.01083 mW/cm² which is< 1.0mW/cm², RF Exposure testing is not required. -------The End------- Mode Frequency (MHz) Max PK Output power(dBm) Tune Up Power(dBm) Max Tune Up power(mW) Antenna Gain(dBi) Antenna Gain (linear) MPE (mW/cm²) 2.4g WIFI 2462 14.56 14±1(15) 31.62 2.35 1.72 0.01083 BLE 2402 7.33 7±1(8) 6.31 2.35 1.72 0.00216 Note: Note: The estimation distance is 20cm Note: PK Output power= conducted power in mW. G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna in cm Conducted power see the test report HK2509055086-1E/2E, antenna gain=2.35dBi The device could not transmit simultaneously in BT and WIFI.

ANTENNASOLUTIONMANUFACTURER Co：ShenzhenAnweiWirelessTechnologyCo.,Ltd Add ： 2/F,EastBlock,Building5,YifenghuaInnovationIndustrialPark,DalanghuaningRoad,LonghuaDistrict,Shenzhen 第 1 页 ShenzhenAnweiWirelessTechnologyCo.,Ltd SPECIFICATION CustomerweipaiSpecsQW16-2 PartNumber AW006-QW16-2-WIFI-021 -A0 FrequencyBand2.4G/5G-WIFI ColorBalckEditionREV:A SalespersonXulongDesignHuanghe StructureQinyunlinConfirmSong Date2025/9/5SigningDate Customerconfirmation: Joinhandstocreatethefuture ANTENNASOLUTIONMANUFACTURER Co：ShenzhenAnweiWirelessTechnologyCo.,Ltd Add ： 2/F,EastBlock,Building5,YifenghuaInnovationIndustrialPark,DalanghuaningRoad,LonghuaDistrict,Shenzhen 第 2 页 CATALOGUE 1、Productspecification ················································································ 1 2、Electricalperformance ·············································································· 2 2.1Specificationsandstandards ·································································· 3 2.2ProductPhotograph ············································································ 4 2.3Antennamatchingcircuit ······································································ 5 3、Testofpassiveparameters ········································································· 6 3.1Testresult ························································································ 7 4、Settingofactivetest ················································································· 8 4.1Testresult ························································································ 9 5、Recommendationsandconclusions ······························································· 10 6、Antennastructuredrawing ········································································· 11 ANTENNA SOLUTION MANUFACTURER Co：Shenzhen Anwei Wireless Technology Co., Ltd Add ： 2/F, East Block, Building 5, Yifenghua Innovation Industrial Park, Dalanghuaning Road, Longhua District, Shenzhen 第 3 页 1、Product specification The report mainly provides parameter test of QW16-2 antenna performance. Silk screen modelFrequency+RangeImpendenceAntenna GainV.S.W.R QW16-2 2400～2500MHz50Ω 2.35dBi 1.6 5100～580050Ω 7.84dBi 1.4 2、Electrical performance 2.1 Specifications and standards QW16-2 antenna operates at 2400~2500/5100~5800MHZ, and resonance occurs at this frequency band. 2.2Product Photograph ANTENNASOLUTIONMANUFACTURER Co：ShenzhenAnweiWirelessTechnologyCo.,Ltd Add ： 2/F,EastBlock,Building5,YifenghuaInnovationIndustrialPark,DalanghuaningRoad,LonghuaDistrict,Shenzhen 第 4 页 2.3Antennamatchingcircuit Antennastructure:FPC+2generationterminal60mmcopperaxis 3、Testofpassiveparameters 3.1Testresult Thefollowingareantennapassiveparameterdata: ANTENNASOLUTIONMANUFACTURER Co：ShenzhenAnweiWirelessTechnologyCo.,Ltd Add ： 2/F,EastBlock,Building5,YifenghuaInnovationIndustrialPark,DalanghuaningRoad,LonghuaDistrict,Shenzhen 第 5 页 Efficiencyandgain ANTENNASOLUTIONMANUFACTURER Co：ShenzhenAnweiWirelessTechnologyCo.,Ltd Add ： 2/F,EastBlock,Building5,YifenghuaInnovationIndustrialPark,DalanghuaningRoad,LonghuaDistrict,Shenzhen 第 6 页 ANTENNASOLUTIONMANUFACTURER Co：ShenzhenAnweiWirelessTechnologyCo.,Ltd Add ： 2/F,EastBlock,Building5,YifenghuaInnovationIndustrialPark,DalanghuaningRoad,LonghuaDistrict,Shenzhen 第 7 页 4 、 SettingofOTAactivetest 4.1Testresult Themaximumradiationpowerandmaximumreceptionsensitivityreflectthemaximum powerradiationvalueandthebestreceptionperformanceoftheantennainthewhole radiationspace.TRPandTISreflecttheaverageradiationpowerandaveragereception sensitivityoftheantenna,thatis,theoverallreceptionperformanceoftheantenna. ThefollowingistheactivetestresultsofthebrightscreenofQW16-22.4Gdual-band WIFIantenna: ANTENNASOLUTIONMANUFACTURER Co：ShenzhenAnweiWirelessTechnologyCo.,Ltd Add ： 2/F,EastBlock,Building5,YifenghuaInnovationIndustrialPark,DalanghuaningRoad,LonghuaDistrict,Shenzhen 第 8 页 ANTENNASOLUTIONMANUFACTURER Co：ShenzhenAnweiWirelessTechnologyCo.,Ltd Add ： 2/F,EastBlock,Building5,YifenghuaInnovationIndustrialPark,DalanghuaningRoad,LonghuaDistrict,Shenzhen 第 9 页 4.2Environmentaltreatment 5.Recommendationsandconclusions Thisreportisbasedontheantennaelectricalperformancemeasuredbytheproductprovided bythecustomer.Pleasecheckitcarefully. 6.Antennastructuredrawing ANTENNASOLUTIONMANUFACTURER Co：ShenzhenAnweiWirelessTechnologyCo.,Ltd Add ： 2/F,EastBlock,Building5,YifenghuaInnovationIndustrialPark,DalanghuaningRoad,LonghuaDistrict,Shenzhen 第 10 页

Page 1 of 43 Report No.: HK2509055086-1E FCC Test Report Test Report On Behalf of Shenzhen EagletVision Intelligence Technology Co., Ltd. For Smart camera Model No.: QW16Q2, TH4, VP087, WP-B6S7-D16B1-2V3-R12W12-W, TP-BQ09, WPC19, HY-DWY02-2, D9 FCC ID: 2BLVV-QW16Q2 Prepared For: Shenzhen EagletVision Intelligence Technology Co., Ltd. VStarcan Industrial Park, No. 8 Bao Tian Rd, Shuitian Community, Shiyan Town, Bao’an District, Shenzhen City, Guangdong Province, China Prepared By: Shenzhen HUAK Testing Technology Co., Ltd. 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Date of Test: Sept. 05, 2025 ~ Oct. 30, 2025 Date of Report: Oct. 30, 2025 Report Number: HK2509055086-1E Page 2 of 43 Report No.: HK2509055086-1E Test Result Certification Applicant’s Name ................... : Shenzhen EagletVision Intelligence Technology Co., Ltd. Address .................................... : VStarcan Industrial Park, No. 8 Bao Tian Rd, Shuitian Community, Shiyan Town, Bao’an District, Shenzhen City, Guangdong Province, China Manufacturer's Name ............. : Shenzhen EagletVision Intelligence Technology Co., Ltd. Address .................................... : VStarcan Industrial Park, No. 8 Bao Tian Rd, Shuitian Community, Shiyan Town, Bao’an District, Shenzhen City, Guangdong Province, China Product Description Trade Mark ................................. : N/A Product Name ............................ : Smart camera Model and/or Type Reference .. : QW16Q2, TH4, VP087, WP-B6S7-D16B1-2V3-R12W12-W, TP-BQ09, WPC19, HY-DWY02-2, D9 Standards ................................ : 47 CFR FCC Part 15 Subpart C 15.247 KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10: 2020 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test .............................................. : Date (s) of Performance of Tests ............... : Sept. 05, 2025 ~ Oct. 30, 2025 Date of Issue ............................................. : Oct. 30, 2025 Test Result ................................................. : Pass Testing Engineer Len Liao Technical Manager Sliver Wan Authorized Signatory Jason Zhou Page 3 of 43 Report No.: HK2509055086-1E Contents Page 1 Test Summary ................................................................................................................................................ 5 1.1 Test Description ......................................................................................................................................... 5 1.2 Measurement Uncertainty ......................................................................................................................... 6 1.3 Information of the Test Laboratory ............................................................................................................ 6 2 General Information ....................................................................................................................................... 7 2.1 General Description of EUT ...................................................................................................................... 7 2.2 Description of Test Conditions .................................................................................................................. 9 2.3 Description of Test Setup ........................................................................................................................ 10 2.4 Description of Support Units .................................................................................................................... 11 3 Equipments List for All Test Items ............................................................................................................. 12 4 Test Result .................................................................................................................................................... 13 4.1 Antenna Requirement.............................................................................................................................. 13 4.2 AC Conduction Emissions Measurement ................................................................................................ 14 4.3 Radiated Emissions Measurement .......................................................................................................... 18 4.4 Maximum Output Power Measurement ................................................................................................... 27 4.5 Power Spectral Density ........................................................................................................................... 28 4.6 6dB Bandwidth ........................................................................................................................................ 31 4.7 Occupied Bandwidth ................................................................................................................................ 34 4.8 Band Edge ............................................................................................................................................... 35 4.9 Conducted Spurious Emissions .............................................................................................................. 37 5 Test Setup Photos ....................................................................................................................................... 41 6 Photos of the EUT ........................................................................................................................................ 4…

Text truncated - open the document above for the full version.

Page 1 of 97 Report No.: HK2509055086-2E FCC Test Report Test report On Behalf of Shenzhen EagletVision Intelligence Technology Co., Ltd. For Smart camera Model No.: QW16Q2, TH4, VP087, WP-B6S7-D16B1-2V3-R12W12-W, TP-BQ09, WPC19, HY-DWY02-2, D9 FCC ID: 2BLVV-QW16Q2 Prepared For : Shenzhen EagletVision Intelligence Technology Co., Ltd. VStarcan Industrial Park, No. 8 Bao Tian Rd, Shuitian Community, Shiyan Town, Bao’an District, Shenzhen City, Guangdong Province, China Prepared By : Shenzhen HUAK Testing Technology Co., Ltd. 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Date of Test: Sept. 05, 2025 ~ Dec. 03, 2025 Date of Report: Dec. 03, 2025 Report Number: HK2509055086-2E Page 2 of 97 Report No.: HK2509055086-2E Test Result Certification Applicant’s name .................. : Shenzhen EagletVision Intelligence Technology Co., Ltd. Address .................................. : VStarcan Industrial Park, No. 8 Bao Tian Rd, Shuitian Community, Shiyan Town, Bao’an District, Shenzhen City, Guangdong Province, China Manufacturer's Name ........... : Shenzhen EagletVision Intelligence Technology Co., Ltd. Address .................................. : VStarcan Industrial Park, No. 8 Bao Tian Rd, Shuitian Community, Shiyan Town, Bao’an District, Shenzhen City, Guangdong Province, China Product description Trade Mark: N/A Product name ............................ : Smart camera Model and/or type reference . : QW16Q2,TH4, VP087, WP-B6S7-D16B1-2V3-R12W12-W, TP-BQ09, WPC19, HY-DWY02-2, D9 Standards .............................. : FCC Rules and Regulations Part 15 Subpart C Section 15.247 ANSI C63.10: 2020 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test ............................................ : Date (s) of performance of tests ............. : Sept. 05, 2025 ~ Dec. 03, 2025 Date of Issue ........................................... : Dec. 03, 2025 Test Result ............................................... : Pass Testing Engineer Len Liao Technical Manager Sliver Wan Authorized Signatory Jason Zhou Page 3 of 97 Report No.: HK2509055086-2E Table of Contents 1. Test Result Summary ............................................................................... 5 1.1. Test Procedures and Results ........................................................................................................... 5 1.2. Information of the Test Laboratory ................................................................................................. 5 1.3. Measurement Uncertainty ................................................................................................................ 6 2. EUT Description ........................................................................................ 7 2.1. General Description of EUT ............................................................................................................. 7 2.2. Carrier Frequency of Channels ........................................................................................................ 8 2.3. Operation of EUT During Testing .................................................................................................... 8 2.4. Description of Test Setup ................................................................................................................. 9 2.5. Description of Support Units ......................................................................................................... 10 3. Genera Information ................................................................................. 11 3.1. Test Environment and Mode .......................................................................................................... 11 4. Test Results and Measurement Data .................................................... 15 4.1. AC Power Line Conducted Emission ............................................................................................ 15 4.2. Test Result ....................................................................................................................................... 17 4.3. Maximum Peak Conducted Output Power .................................................................................... 19 4.4. Emission Bandwidth ....................................................................................................................... 21 4.5. Power Spectral Density .................................................................................................................. 29 4.6. Conducted Band Edge and Spurious Emission Measurement .................................................. 38 4.7. Radiated Spurious Emission Measurement ................................................................................. 58 4.8. Antenna Requirement ..................................................................................................................... 94 5. Test Setup Photos of the EUT ............................................................... 95 6. Photos of the EUT ................................................................................... 97 Page 4 of 97 Report No.: HK2509055086-2E ** Modified History ** Revision Description Issued Data Remark Revision 1.0 Initial Test Report Release Dec. 03, 2025 Jason Zhou Page 5 of 97 Report No.: HK2509055086-2E 1. Test Result Summary 1.1. Test Procedures and Results Requirement CFR 47 Section Result Antenna requirement §15.203/§15.247(b)(4) PASS AC Power Line Conducted Emission §15.207 PASS Conducted Peak Output Power §15.247(b)(3) PASS 6dB…

Text truncated - open the document above for the full version.

Page 58 of 97 Report No.: HK2509055086-2E 4.7. Radiated Spurious Emission Measurement Test Specification Test Requirement: FCC Part15 C Section 15.209 Test Method: ANSI C63.10: 2020 Frequency Range: 9 kHz to 25 GHz Measurement Distance: 3 m Antenna Polarization: Horizontal & Vertical Operation mode: Transmitting mode with modulation Receiver Setup: Frequency Detector RBW VBW Remark 9kHz- 150kHzQuasi-peak200Hz 1kHz Quasi-peak Value 150kHz- 30MHz Quasi-peak9kHz 30kHz Quasi-peak Value 30MHz-1GHzQuasi-peak120KHz300KHz Quasi-peak Value Above 1GHz Peak 1MHz 3MHz Peak Value Peak 1MHz 10Hz Average Value Limit: Frequency Field Strength (microvolts/meter) Measurement Distance (meters) 0.009-0.490 2400/F(KHz) 300 0.490-1.705 24000/F(KHz) 30 1.705-30 30 30 30-88 100 3 88-216 150 3 216-960 200 3 Above 960 500 3 Frequency Field Strength (microvolts/meter) Measurement Distance (meters) Detector Above 1GHz 500 3 Average 5000 3 Peak Test setup: For radiated emissions below 30MHz 30MHz to 1GHz Page 59 of 97 Report No.: HK2509055086-2E Above 1GHz Test Procedure: 1. For the radiated emission test below 1GHz: The EUT was placed on a turntable with 0.8 meter above ground. The EUT was set 3 meters from the interference receiving antenna, which was mounted on the top of a variable height antenna tower. The EUT was arranged to its worst case and then tune the antenna tower (from 1 m to 4 m) and turntable (from 0 degree to 360 degrees) to find the maximum reading. A pre-amp and a high PASS filter are used for the test in order to get better signal level. 2. For the radiated emission test above 1GHz: Place the measurement antenna on a turntable with 1.5 meter above ground, which is away from each area of the EUT determined to be a source of emissions at the specified measurement distance, while keeping the measurement antenna aimed at the source of emissions at each frequency of significant emissions, with polarization oriented for maximum response. The measurement antenna may have to be higher or lower than the EUT, depending on the radiation pattern of the emission and staying aimed at the emission source for receiving the maximum signal. Page 60 of 97 Report No.: HK2509055086-2E The final measurement antenna elevation shall be that which maximizes the emissions. The measurement antenna elevation for maximum emissions shall be restricted to a range of heights of from 1 m to 4 m above the ground or reference ground plane. 3. Corrected Reading: Antenna Factor + Cable Loss + Read Level - Preamp Factor = Level 4. For measurement below 1GHz, If the emission level of the EUT measured by the peak detector is 3 dB lower than the applicable limit, the peak emission level will be reported. Otherwise, the emission measurement will be repeated using the quasi-peak detector and reported. 5. Use the following spectrum analyzer settings: (1) Span shall wide enough to fully capture the emission being measured; (2) Set RBW=120 kHz for f < 1 GHz; VBW ≥RBW; Sweep = auto; Detector function = peak; Trace = max hold; (3) Set RBW = 1 MHz, VBW= 3MHz for f > 1 GHz for peak measurement. 6.For average measurement: VBW = 10 Hz, when duty cycle is no less than 98 percent.VBW ≥ 1/T, when duty cycle is less than 98 percent where T is the minimum transmission duration over which the transmitter is on and is transmitting at its maximum power control level for the tested mode of operation. Test results: PASS Page 61 of 97 Report No.: HK2509055086-2E Test Instruments Radiated Emission Test Site (966) Name of Equipment Manufacturer Model Serial Number Calibration Date Calibration Due Spectrum analyzer Agilent N9020A HKE-025 Feb. 19, 2025 Feb. 18, 2026 Spectrum analyzer Agilent N9020A HKE-117 Feb. 19, 2025 Feb. 18, 2026 Spectrum analyzer R&S FSV3044 HKE-126 Feb. 19, 2025 Feb. 18, 2026 Preamplifier EMCI EMC051845SHKE-006 Feb. 19, 2025 Feb. 18, 2026 Preamplifier Schwarzbeck BBV 9743 HKE-016 Feb. 19, 2025 Feb. 18, 2026 Preamplifier A.H. Systems SAS-574 HKE-182 Feb. 19, 2025 Feb. 18, 2026 6dB Attenuator Pasternack 6db HKE-184 Feb. 19, 2025 Feb. 18, 2026 EMI Test Receiver Rohde & Schwarz ESR-7 HKE-010 Feb. 19, 2025 Feb. 18, 2026 Broadband Antenna Schwarzbeck VULB9168 HKE-167 Feb. 21, 2024 Feb. 20, 2026 Loop Antenna COM-POWER AL-130R HKE-014 Feb. 21, 2024 Feb. 20, 2026 Horn Antenna Schwarzbeck 9120D HKE-013 Feb. 21, 2024 Feb. 20, 2026 EMI Test Software Tonscend JS32-RE 5.0.0HKE-082 N/A N/A RSE Test Software Tonscend JS36-RSE 5.0 .0 HKE-184 N/A N/A Note: The calibration interval of the above test instruments is 12 months and the calibrations are traceable to international system unit (SI). Page 62 of 97 Report No.: HK2509055086-2E Test Data All the test modes completed for test. only the worst result of (802.11b at 2412MHz) was reported as below: Below 1GHz Test Results Antenna polarity: Horizontal Remark: Factor = Cable loss + Antenna factor + Attenuator – Preamplifier; Level = Reading + Factor; Margin = Limit – Level Page 63 of 97 Report No.: HK2509055086-2E Antenna polarity: Vertical Remark: Factor = Cable loss + Antenna factor + Attenuator – Preamplifier; Level = Reading + Factor; Margin = Limit – Level Harmonics and Spurious Emissions Frequency Range (9kHz-30MHz) Frequency (MHz) Level@3m (dBμV/m) Limit@3m (dBμV/m) -- -- -- -- -- -- -- -- -- -- -- -- Note:1. Emission Level=Reading+ Cable loss-Antenna factor-Amp factor. 2. The emission levels are 20 dB below the limit value, which are not reported. It is deemed to comply with the requirement. Page 64 of 97 Report No.: HK2509055086-2E Above 1GHz Radiated Emission Test LOW CH1 (802.11b Mode)/2412 Horizontal: Frequency Reading ResultFactorEmission LevelLimitsMargin (MHz)(dBμV)(dB)(dBμV/m)(dBμV/m)(dB) 482452.85-3.6449.217424.79peak 482438.46-3.6434.825419.18AVG 723652.96-0.9552.017421.99peak 723641.13-0.9540.185413.82AVG Remark: Factor = Cable loss + Antenna factor + Attenuator – Preamplifier; Level = Reading + Factor; Margin = Limit-Level. Detector Type Vertical: FrequencyReading ResultFactorEmission Leve…

Text truncated - open the document above for the full version.

Test Model：QW16Q2 Radiated Emission AC Conducted Emission RF Conducted Emission
