2BMAM-JL02-E2Wireless remote control

Instructions PRODUCTIPICTURE: Productparameters: !.Workingvoltage:6V,standard:6V 2.Staticcurrent:DC6V,lessthan1μA,actually0uA 3.Workingemissioncurrent:DC6V,lessthan12mA,actuallyabout10mA 4.Workindicatorlight:LEDindication 5.Workingcenterfrequency:433.92MHz±0.2MHz 6.0Workingtemperature:-40°C+85°C 7.Numberofbuttons:1-4buttonstochoosefrom Application: Remotecontrolswitch,anti-theftalarm,remotedoorlock,electricshutter remotecontrol,automotiveandmotorcycleaccessories,industrialcontrol products,etc.(Specialreminder:Itisstrictlyprohibitedtointerferewithother remotecontrolsignalsandotherillegalpurposes.Violatorsshallbeheld responsible!) Productsizespecifications: Description JL02-E2isabrandnewappearancewithastylishdesign,2-buttondesign,and MCUcontrolcoderemotecontrol.Itismainlyusedforremotecontrolof wirelessdevicesorotherwirelessdevices. Regardingremotecontroldistance: Theremotecontroldistancewerefertoisthemaximumdecodabledistance measuredonastraightandopengroundunderratedconditionswhenthe transmitting/receivingmoduleworksseparatelyandisequippedwithametal antennaofaquarterwavelength.Astheelectromagneticwavepropagatesina straightlinewhenencounteringobstaclesintheUHFband,itwillsharply decayandtheremotecontroldistanceissignificantlyshortened.Therefore,try toavoidobstacleswhenusing,orashighaspossibleantenna. FCCCaution ： Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothe followingtwoconditions:(1)Thisdevicemaynotcauseharmfulinterference, and(2)thisdevicemustacceptanyinterferencereceived,including interferencethatmaycauseundesiredoperation. AnyChangesormodificationsnotexpresslyapprovedbythepartyresponsible forcompliancecouldvoidtheuser'sauthoritytooperatetheequipment. Note:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassB digitaldevice,pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovide reasonableprotectionagainstharmfulinterferenceinaresidentialinstallation.This equipmentgeneratesusesandcanradiateradiofrequencyenergyand,ifnotinstalled andusedinaccordancewiththeinstructions,maycauseharmfulinterferencetoradio communications.However,thereisnoguaranteethatinterferencewillnotoccurina particularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioor televisionreception,whichcanbedeterminedbyturningtheequipmentoffandon,the userisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowing measures: -Reorientorrelocatethereceivingantenna. -Increasetheseparationbetweentheequipmentandreceiver. -Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiver isconnected. -Consultthedealeroranexperiencedradio/TVtechnicianforhelp. ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement. Thedevicecanbeusedinportableexposureconditionwithoutrestriction.
