* the applicantmust designatea contactlocatedin the UnitedStatesfor purposesof actingas the applicant’s agent for serviceof process,regardlessof whetherthe applicantis a domesticor foreign entity.An applicantlocatedin the UnitedStatesmay designateitself as the agent for serviceof process. SC5102337 U.S. AgentDesignationfor Serviceof Process- CertificationAttestationLetter 11/13/2025 TO : FederalCommunicationsCommission 7435 OaklandMills Road Columbia,MD 21046 ATTN.: Reviewing Engineer FCC ID: 2BMIS-JMM6 FRN of applicant: 0036352367 Per section 2.911(d)(7) of the FCC rules, [Shenzhen Jimuyida Technology Co., Limited] (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company Name: Global Product Services and Consultation LLC FCC Registration Number (FRN): 0033406703 Physical U.S. Company Address: 328 W Palm Ave., Monrovia, CA 91016, United States Contact Person: Michael Chan Tel: +1 626 366 4358 Agent Email Address: [email protected] The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. ApplicantSigned:AgentSigned(if differentfromApplicant): Signed: Printedname:Zhangkai Title : Engineer CompanyName:ShenzhenJimuyida TechnologyCo., Limited Address:21CD,Li-NingCenter,Shennan Avenue,NanshanDistrict,Shenzhen Signed: Printed name: Michael Chan Title: Technical Director Company Name: Global Product Services and Consultation LLC Date: 11/17/2025 Date: 11/13/2025

Shenzhen Jimuyida Technology Co., Limited 2025-11-13 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2BMIS-JMM6) [Shenzhen Jimuyida Technology Co., Limited] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber-security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, Zhang kai Engineer Shenzhen Jimuyida Technology Co., Limited 21CD, Li-Ning Center, Shennan Avenue, Nanshan District, Shenzhen Shenzhen Jimuyida Technology Co., Limited 2025-11-13 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID: 2BMIS-JMM6) [Shenzhen Jimuyida Technology Co., Limited] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Zhang kai Engineer Shenzhen Jimuyida Technology Co., Limited 21CD, Li-Ning Center, Shennan Avenue, Nanshan District, Shenzhen

Shenzhen Jimuyida Technology Co., Limited 2025-11-13 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Guangdong Global Testing Technology Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Zhang kai Engineer Shenzhen Jimuyida Technology Co., Limited 21CD, Li-Ning Center, Shennan Avenue, Nanshan District, Shenzhen

Shenzhen Jimuyida Technology Co., Limited 2025-11-13 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (EUT Name: Toucan 3D Scanner /Model: JMM6/FCC ID: 2BMIS-JMM6) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (Block Diagram, Operational Description, Schematics) required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Zhang kai Engineer Shenzhen Jimuyida Technology Co., Limited 21CD, Li-Ning Center, Shennan Avenue, Nanshan District, Shenzhen

External Photographs View of EUT-1 View of EUT-2 Page 2 of 5 View of EUT-3 View of EUT-4 Page 3 of 5 View of EUT-5 View of EUT-6 Page 4 of 5 View of EUT-7 View of EUT-8 Page 5 of 5 View of EUT-9

Internal Photographs Internal View of EUT-1 Internal View of EUT-2 2.4GHz WiFi Antenna Page 2 of 22 Internal View of EUT-3 Internal View of EUT-4 Page 3 of 22 Internal View of EUT-5 Internal View of EUT-6 Page 4 of 22 Internal View of EUT-7 Internal View of EUT-8 Page 5 of 22 Internal View of EUT-9 Internal View of EUT-10 Page 6 of 22 Internal View of EUT-11 Internal View of EUT-12 Page 7 of 22 Internal View of EUT-13 Internal View of EUT-14 Page 8 of 22 Internal View of EUT-15 Internal View of EUT-16 Page 9 of 22 Internal View of EUT-17 Internal View of EUT-18 Page 10 of 22 Internal View of EUT-19 Internal View of EUT-20 Page 11 of 22 Internal View of EUT-21 Internal View of EUT-22 Page 12 of 22 Internal View of EUT-23 Internal View of EUT-24 Page 13 of 22 Internal View of EUT-25 Internal View of EUT-26

Page 14 of 22 Internal View of EUT-27 Internal View of EUT-28 Page 15 of 22 Internal View of EUT-29 Internal View of EUT-30 Page 16 of 22 Internal View of EUT-31 Internal View of EUT-32 Page 17 of 22 Internal View of EUT-33 Internal View of EUT-34 Page 18 of 22 Internal View of EUT-35 Internal View of EUT-36 Page 19 of 22 Internal View of EUT-37 Internal View of EUT-38 Page 20 of 22 Internal View of EUT-39 Internal View of EUT-40 Page 21 of 22 Internal View of EUT-41 Internal View of EUT-42 Page 22 of 22 Internal View of EUT-43 Internal View of EUT-44

RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in ß1.1307(b) FCC ID: 2BMIS-JMM6 EUT Specification EUT Toucan 3D Scanner Frequency band (Operating) BT: 2.402GHz ~ 2.480GHz BLE: 2.402GHz ~ 2.480GHz WIFI: 2.412GHz ~ 2.462GHz WIFI: 5.180GHz ~ 5.240GHz WIFI: 5.260GHz ~ 5.320GHz WIFI: 5.500GHz ~ 5.700GHz WIFI: 5.745GHz ~ 5.825GHz Device category Portable (<20cm separation) Mobile (>20cm separation) Exposure classification Occupational/Controlled exposure (S = 5mW/cm 2 ) General Population/Uncontrolled exposure (S=1mW/cm 2 ) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power IEEE 802.11b: 17.46 dBm IEEE 802.11g: 15.99 dBm IEEE 802.11n HT20: 17.75 dBm IEEE 802.11n HT40: 16.82 dBm IEEE 802.11ax HE20: 17.25 dBm IEEE 802.11ax HE40: 16.68 dBm Antenna gain (Max) Antenna 1/2: 1.89 dBi Evaluation applied MPE Evaluation SAR Evaluation Limits for Maximum Permissible Exposure(MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 2 / 3 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 Friis transmission formula: Pd=(Pout*G)\(4*pi*R2) Where P d = Power density in mW/cm 2 , P out =output power to antenna in mW. G= gain of antenna in linear scale, Pi=3.1416 R= distance between observation point and center of the radiator in cm=20cm P d the limit of MPE, 1mW/cm 2 . If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. For multiple RF sources: Multiple RF sources are exempt if: in the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation Evaluated k : the maximum reported SAR or MPE of fixed, mobile, or portable RF source k either in the device or at the transmitter site from an existing evaluation at the location of exposure. Exposure Limit k : either the general population/uncontrolled maximum permissible exposure (MPE) or specific Absorption rate (SAR) limit for each fixed, mobile, or portable RF source k. 3 / 3 Measurement Result 2.4G WIFI: Mode Max Measured Power (dBm) Tune up tolerance (dBm) Max tune up conducted power(dBm) Output Peak power (mW) Ant. Gain (dBi) Ant. Gain (numeric) Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/ cm 2 ) Results 802.11b 17.46 17±1 18 63.096 1.89 1.545 0.019396 1 PASS 802.11g 15.99 16±1 17 50.119 1.89 1.545 0.015407 1 PASS 802.11n HT20 17.75 18±1 19 79.433 1.89 1.545 0.024419 1 PASS 802.11n HT40 16.82 17±1 18 63.096 1.89 1.545 0.019396 1 PASS 802.11ax HE20 17.25 17±1 18 63.096 1.89 1.545 0.019396 1 PASS 802.11ax HE40 16.68 17±1 18 63.096 1.89 1.545 0.019396 1 PASS Signature: Shawn Wen Date: 2025-11-17

TEL：18576689668 E-mail:[email protected] Shenzhen Flairlink Technologies SHENZHEN Customer ： DESCRIPTION： WiFi Antenna PART NO. ： MXQ-2.4/5.8-FPC-0.81-L130-IPEX 4gen CUS PART NO.： 1021700002 D A T E： 2025-9-12 Supplier signment ENGINEERING DEPARTMENT Q C DEPARTMENT SALES DEPARTMENT Customer signment ENGINEERING DEPARTMENT Q C DEPARTMENT PURCHASING DEPARTMENT Phone：18576689668 ж ж Approval in duplicate, please signed by your company. APPROVAL SHEET TEL：18576689668 E-mail:[email protected] Shenzhen Flairlink Technologies SHENZHEN 1. Test item &equipment Test item equipment 1. （S-parameter） 1. Return Loss 2. VSWR Network analyzer: Agilent E5071B HP 8753D 2. Active 1. TRP 2. TIS 1. Anechoic Chamber： ETS 7x4x3 m (3D) Chamber ETS 5x3x3 m (3D) Chamber 2.Test Instrument: Agilent 8960 E5515B ◊2 StarPoint SP6011 Cmw500 3.Passive 1.Gain 2.Efficiency 1. Anechoic Chamber： ETS 7x4x3 m (3D) Chamber ETS 5x3x3 m (3D) Chamber 2. Network analyzer：Agilent E5071B HP 8753D TEL：18576689668 E-mail:[email protected] Shenzhen Flairlink Technologies SHENZHEN 2. Performance SWR TEL：18576689668 E-mail:[email protected] Shenzhen Flairlink Technologies SHENZHEN 3. Gain & Efficiency Passive Test For WIFI2.4 Freq Effi Gain (MHz) (%) (dBi) 2400 44.93 1.95 2410 44.09 1.79 2420 40.31 1.43 2430 40.26 1.36 2440 42.99 1.6 2450 46.49 1.89 2460 45.39 1.62 2470 48.07 1.77 2480 49.25 1.73 2490 52.8 1.81 2500 53.65 1.84 TEL：18576689668 E-mail:[email protected] Shenzhen Flairlink Technologies SHENZHEN Passive Test For WIFI5.8 Freq Effi Gain (MHz) (%) (dBi) 5150 57.65 1.29 5200 52.36 0.76 5250 46.79 0.16 5300 49.36 0.4 5350 58.05 1.13 5400 65.74 1.8 5450 58.96 1.53 5500 60.61 1.74 5550 63.45 2.28 5600 60.14 2.21 5650 56.98 2.02 5700 56.92 1.78 5750 59.28 2.02 5800 54.71 1.05 5850 47.4 0.66 TEL：18576689668 E-mail:[email protected] Shenzhen Flairlink Technologies SHENZHEN 4. Structure： TEL：18576689668 E-mail:[email protected] Shenzhen Flairlink Technologies SHENZHEN Technical parameters of electrical appliances Electrical Specifications Frequency Range 2400~2500/5150~5850MHz VSWR ≤2.0 Input Impedance 50 Ω Gain 2 DBI Mechanical Specifications Antenna Color BLACK Input connector IPEX 4 Cable length 100mm Working Temperature -40°C~+85°C Working Humidity 20~80% TEL：18576689668 E-mail:[email protected] Shenzhen Flairlink Technologies SHENZHEN （ Environment performance test ）: Project Test condition Test results Storage environment Test temperature, humidity, pressure without stated condition as follwings:1.Temperature: -30°C～ +80°C;2.Relative humidity: 45%-85%;3,Pressure: 86kpa-106kpa Electrical and mechanical performance normal High and low temperature test Having 5 times cycle between -40°C to 70°C,Then in common condition 1-2 hours test exterior quality. Measurement satisfied with electrical and mechanical performance normal. Resistance constant hot and humid test Relative humidity:95±3%,Test temperature: 40°C,last 2 hours ,put it after 5 min test the electrical function .Test products during common condition 1-2 hours ,Then test exterior quality. Measurement satisfied with electrical and mechanical performance normal. Vibration test Vibrate Frequency:10-55HZ; Distance :0.35mm;Acceleration :50.0m/s;Sweep frequency cycle:30 times Electrical and mechanical performance normal Fall test From 1m height fall down 3 times freely (vertical direction) Electrical and mechanical performance normal

TRF No.: 04-E001-0B TRF Originator: GTG TRF Date: 2023-12-13 Web: www.gtggroup.com E-mail: [email protected] Tel.: 86-400 755 8988 CFR 47 FCC PART 15 SUBPART C(DTS) TEST REPORT For Toucan 3D Scanner MODEL NUMBER: JMM6 REPORT NUMBER: E04A25090295F00401 ISSUE DATE: November 5, 2025 FCC ID: 2BMIS-JMM6 Prepared for Shenzhen Jimuyida Technology Co., Limited 21CD, Li-Ning Center, Shennan Avenue, Nanshan District, Shenzhen Prepared by Guangdong Global Testing Technology Co., Ltd. Room 101-105, 203-210, Building 1, No.2, Keji 8 Road, Songshan Lake Park, Dongguan city, Guangdong, People’s Republic of China, 523808 This report is based on a single evaluation of the submitted sample(s) of the above mentioned product, it does not imply an assessment of the production of the products. This report shall not be reproduced, except in full, without the written approval of Guangdong Global Testing Technology Co., Ltd. REPORT NO.: E04A25090295F00401 Page 2 of 186 TRF No.: 04-E001-0B Global Testing , Great Quality. Revision History Rev. Issue Date Revisions Revised By V0 November 5, 2025 Initial Issue REPORT NO.: E04A25090295F00401 Page 3 of 186 TRF No.: 04-E001-0B Global Testing , Great Quality. Summary of Test Results Test Item Clause Limit/Requirement Result Antenna Requirement ANSI C63.10-2020 FCC Part 15.203/15.247 (c) Pass AC Power Line Conducted Emission ANSI C63.10-2020 FCC Part 15.207 Pass Conducted Output Power ANSI C63.10-2020 FCC Part 15.247 (b)(3) Pass 6dB Bandwidth and 99% Occupied Bandwidth ANSI C63.10-2020 FCC Part 15.247 (a)(2) Pass Power Spectral Density ANSI C63.10-2020 FCC Part 15.247 (e) Pass Conducted Band edge and spurious emission ANSI C63.10-2020 FCC Part 15.247(d) Pass Radiated Band edge and Spurious Emission ANSI C63.10-2020 FCC Part 15.205/15.209 Pass Duty Cycle ANSI C63.10-2020 None; for reporting purposes only. Pass *This test report is only published to and used by the applicant, and it is not for evidence purpose in China. *The measurement result for the sample received is <Pass> according to <CFR 47 FCC PART 15 SUBPART C(DTS)> when <Accuracy Method> decision rule is applied. REPORT NO.: E04A25090295F00401 Page 4 of 186 TRF No.: 04-E001-0B Global Testing , Great Quality. CONTENTS 1. ATTESTATION OF TEST RESULTS ..................................................................................... 5 2. TEST METHODOLOGY ......................................................................................................... 6 3. FACILITIES AND ACCREDITATION ..................................................................................... 6 4. CALIBRATION AND UNCERTAINTY ................................................................................... 7 4.1. MEASURING INSTRUMENT CALIBRATION ........................................................... 7 4.2. MEASUREMENT UNCERTAINTY ............................................................................ 7 5. EQUIPMENT UNDER TEST .................................................................................................. 8 5.1. DESCRIPTION OF EUT ........................................................................................... 8 5.2. CHANNEL LIST ........................................................................................................ 8 5.3. MAXIMUM CONDUCTED OUTPUT POWER ........................................................... 9 5.4. TEST CHANNEL CONFIGURATION ........................................................................ 9 5.5. THE WORSE CASE POWER SETTING PARAMETER ............................................ 9 5.6. DESCRIPTION OF AVAILABLE ANTENNAS ......................................................... 10 5.7. EUT ACCESSORY ................................................................................................. 11 5.8. SUPPORT UNITS FOR SYSTEM TEST ................................................................. 11 5.9. SETUP DIAGRAM .................................................................................................. 12 6. MEASURING EQUIPMENT AND SOFTWARE USED......................................................... 13 7. ANTENNA PORT TEST RESULTS ..................................................................................... 15 7.1. Conducted Output Power ........................................................................................ 15 7.2. 6dB Bandwidth and 99% Occupied Bandwidth ....................................................... 16 7.3. Power Spectral Density ........................................................................................... 18 7.4. Conducted Band edge and spurious emission ........................................................ 19 7.5. Duty Cycle .............................................................................................................. 21 8. RADIATED TEST RESULTS ............................................................................................... 22 8.1. Radiated Band edge and Spurious Emission .......................................................... 28 9. ANTENNA REQUIREMENT ................................................................................................ 44 10. AC POWER LINE CONDUCTED EMISSION ......................................................... 45 11. TEST DATA - Appendix A ..................................................................................... 48 REPORT NO.: E04A25090295F00401 Page 5 of 186 TRF No.: 04-E001-0B Global Testing , Great Quality. 1. ATTESTATION OF TEST RESULTS Applicant Information Company Name: Shenzhen Jimuyida Technology Co., Limited Address: 21CD, Li-Ning Center, Shennan Avenue, Nanshan District, Shenzhen Manufacturer Information Company Name: Wuhan Ruler Technology Co., Ltd Address: Room 201, 2nd Floor, and Room 403, 4th Floor, Building D, Hairongji incubation Park, No.8 Changchengyuan Road, Donghu New technology Development Zone, Wuhan, Hubei, China EUT Information Product Description: Toucan 3D Scanner Model: JM…
