2BMOF-CP13Security camera

clock camera Key Function Description Long press the power button to turn the device on/off. Note: Time display and camera are turned on/off together. Short-press the Alarm button : It will show current alarm time. 1. power button 3. Alarm button Power button Time button "+" and "-" buttons Alarm button Night light button Reset button SD card slot (Supports up to 128G) (Long press for 5-8 seconds to reset) Battery level light 7 Alarm clock Icon PM icon Time Lens • Short-press Alarm button Minutes blink: Press the "+" or "-" button to adjust the minutes. • Short-press Alarm button again the minutes will flash, allowing you to adjust the snooze time. Press the "+" or "-" button to adjust the minutes (you can set it to 5-60 minutes). • Short-press Alarm button saves settings and exits, or Waiting for 15 seconds will automatically end the setting. • Long press the alarm button to turn on the alarm directly and enter the alarm time setting Hours blink: Press the "+" or "-" button to adjust the hour. (Note:If there is no PM icon on the left side of the screen, it is morning time by default, and if there is a PM icon on the screen, it is afternoon time) 4. snooze mode • Long press Time button to enter setup mode 2. Time button Battery Specifications Charging Time: • Press again: Turn alarm ON (Note: the clock icon will light up in the lower left corner of the screen). • Press a third time: Turn alarm OFF. • Press the Time button to exit setup,or Waiting for 5 seconds will automatically end the setting. • Press "+" or "-" to switch between 12-hour or 24-hour system. • Press Time button once more Minutes blink (Press the "+" or "-" button to adjust the minute.) • Short-press the time button again to save the setting. • Press the Time button again: Hours blink (Press the "+" or "-" button to adjust the hour.) (Note that if there is no PM icon on the left side of the screen, it is morning time by default, and if there is a PM icon on the screen, it is afternoon time) • Press "+" or "-" Activates snooze mode (Alarm icon blinks ▼ left side of screen) ▶Short-press Alarm button Stops alarm sound immediately. 5. "-" button In normal mode, press the "-" button to adjust the brightness of the time display light. Low brightnessHigh brightnessDisplay OFF (Repeated press cycle through all three states) 6. Night Light button Short-press the Night Light button to switch brightness levels: Low High Night Light OFF (Repeated taps rotate through all three states) Usage time: When device operates while charging: Battery Level Indicators: Important Notes: Power Source Transition Battery Maintenance Email: [email protected] This manual is suitable for various types of cameras. (The appearance may be different due to different batches. The details are subject to the receipt.This manual is only for the installation instructions of this series of equipment) Input: 5V/2A charger (lf you do not see the pop-up device box, please click "scan to add" to scan the QR code on the camera body) Users can search"Wesecuu" on APP store or Google Play, or scan the QR code below to install the APP. Note: For iOS system, it requires iOS 9.0 version or above.For Android,Android 5.1 or above. If you are prompted to open certain permissions (such as location, message notification, etc.) during APP installation, click Allow (agree). Log in the App Clickon“Register" the app logininterface. Sign up and follow theonscreen instructions to complete the *"Before adding a camera, please make sure that the Bluetooth function of the mobile phone has been turned on, and do not turn off the Bluetooth during the adding process.lf a prompt box pops up during the adding process to enable Bluetooth or Bluetooth authorization please follow the steps in the prompt to enable it; Wesecuu APP Download and installation Q1: Why is the pairing network unsuccessful? Please make sure that the distance among the camera, the router and the mobile phone should be close enough when configuring the network. Please make sure that the WlFl signal connected to the mobile phone 2.4G Wifi and 5G WiFi are both ok. 2. 1. More of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from thatto which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. lf this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment of fand on, the user is encouraged to try to correct the interference by one or. Q3: Why is the camera offline? Q2:Why is there no playback? It may caused by router WlFl signal interference or network reasons. Power off and restart the optical modem, router or camera. 1. The camera maybe too far away from the WlFl router, try to get the camera next to the WFl router. 2. Whether the WlFl password has been changed, try to reset the camera and try pairing again. 3. Make sure that the TF card has been inserted into the camera and try to turn on/off the camera. 1. Enter the camera settings menu to check the storage status 'in good condition' (if the status is abnormal click to "Format the memory card".) 2. 10 11 1213 Capacity: 5200mAh ▶ Approximately 10 hours (0% 100%) ▶ Charges battery simultaneously ▶ ~12 hours when fully charged (With night light OFF + display at low brightness) When di…

Text truncated - open the document above for the full version.

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong RF Exposure evaluation Report Reference No. .................... : FCC ID. ............................................ : GTS20241125007-1-04 2BMOF-CP13 Compiled by ( position+printed name+signature) .. : File administrators Peter Xiao Supervised by ( position+printed name+signature) .. : Test Engineer Evan Ouyang Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : Nov.25, 2025 Representative Laboratory Name : Shenzhen Global Test Service Co.,Ltd. Address ............................................. : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong,China Applicant’s name ............................ : Shenzhen JuXingGongChuang Technology Co., Ltd. Address ............................................. : 801, Block A, Gang Zhi Long Business Center, Longhua District, Shenzhen, China Test specification .......................... : Standard ........................................... : 47CFR §1.1310 47CFR §2.1093 KDB447498 D01 General RF Exposure Guidance v06 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Security camera Trade Mark ....................................... : N/A Manufacturer ..................................... : Tianjian Group Co.,Ltd. Model/Type reference ....................... : CP13 Listed Models ................................... : CP20, CP21, CP22, CP23, CP24, CP25, CP26, CP27, CP28, CP29, CP50, CP51, CP52, CP53, CP54, CP55, CP56, CP57, CP58, CP59, CP60, CP61, CP62, CP63, CP64, CP65, CP66, CP67, CP68, CP69, CQ30, CQ31, CQ32, CQ33, CQ34, CQ35, CQ36, CQ37, CQ38, CQ39, CQ80, CQ81, CQ82, CQ83, CQ84, CQ85, CQ86, CQ87, CQ88, CQ89 Exposure category ............................ : General population/uncontrolled environment EUT Type .......................................... : Portable Hardware Version ............................ : N/A Software Version .............................. : N/A Rating ............................................... : DC 3.7V by battery Recharged by DC 5.0V Result ................................................ : PASS Report No.: GTS20241125007-1-04 Page 2 of 12 T E S T R E P O R T Test Report No. : GTS20241125007-1-04 Nov.25, 2025 ______________________________________________________________________________________________ Date of issue Equipment under Test : Security camera Model /Type : CP13 Listed model : CP20, CP21, CP22, CP23, CP24, CP25, CP26, CP27, CP28, CP29, CP50, CP51, CP52, CP53, CP54, CP55, CP56, CP57, CP58, CP59, CP60, CP61, CP62, CP63, CP64, CP65, CP66, CP67, CP68, CP69, CQ30, CQ31, CQ32, CQ33, CQ34, CQ35, CQ36, CQ37, CQ38, CQ39, CQ80, CQ81, CQ82, CQ83, CQ84, CQ85, CQ86, CQ87, CQ88, CQ89 Applicant : Shenzhen JuXingGongChuang Technology Co., Ltd. Address : 801, Block A, Gang Zhi Long Business Center, Longhua District, Shenzhen, China Manufacturer : Tianjian Group Co.,Ltd. Address : 501, No. 9, Nuclear Power Industrial Park, Fumin Community, Fucheng Street, Longhua District, Shenzhen, Guangdong, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20241125007-1-04 Page 3 of 12 Contents 1. S U M M A R Y .................................................................................. 4 1.1. Product Description .................................................................................................................................... 4 2. T E S T E N V I R O N M E N T ................................................................... 5 2.1. Address of the test laboratory ................................................................................................................... 5 2.2. Test Facility .................................................................................................................................................. 5 2.3. Environmental conditions .......................................................................................................................... 5 2.4. Statement of the measurement uncertainty ............................................................................................. 5 3 . M E T H O D O F M E A S U R EM E N T ......................................................... 6 3.1. Applicable Standard .................................................................................................................................... 6 3.2. Evaluation Method and Limit...................................................................................................................... 6 4. C O N D U C T E D P O W E R R E S U L T S ...................................................... 7 5. M A N U F A C T U R I N G T O L E R ANCE ...................................................... 8 6 . E V A L U A T I O N R E S U L TS ............................................................... 10 6.1. Standalone Evaluation .....................................................................................…

Text truncated - open the document above for the full version.

FCC ID: 2BMOF-CP13 _______________________________________________________________________________________________ Page 1 of 2 1. TEST SETUP PHOTOGRAPHS Photo of Radiated Emissions Measurement Fig. 1 Fig. 2 FCC ID: 2BMOF-CP13 _______________________________________________________________________________________________ Page 2 of 2 Photo of Conducted Emission Measurement Fig. 4 Fig. 5

TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2450-FPC361BX ProductName:Antenna Page 1 SpecificationFor Approval Date:2025.5.6 Version:1.0 客 户 名 称 Customer： 天健 客 户 料 号 CustomerP/N： 腾 祥 料 号 T X P/N：AN2450-FPC361BX 规 格 描 述 Description:2.4G /5G FPC天线1.13 mm黑色线L=50mm +IPEX TengxiangCheckedBy: 腾 祥 审 核 CustomerApprovedBy: 客 户 审 核 DRAWN 制 作 路婷 TESTEDBY 检 测 CHECKEDBY 审 核 胡超 CHECKEDBY 审 核 Q.C.DEPT. 品 管 周志红 Q.C.DEPT. 品 管 APPROVEDBY 核 准 韦佳 APPROVEDBY 核 准 NO. 53 ShatouSha ChongRoad,ChangAn Town,Guangdongprovince,China 中国广东省东莞市长安镇沙头区沙涌路53号 TEL:86-769-81873082FAX:86-769-82663788 http://www.tenxiang.cn TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2450-FPC361BX ProductName:Antenna Page2 Index: 1.Specification(规格) 2.CharacteristicsandReliabilityTest(产品特性和可靠性测试标准) 3.Antenna-SParameterTestData(样品测试数据) 4.Antenna-RadiationPatternTestData(辐射模式测试数据) 5.MechanicalandPackingDrawing(图纸包装规范) RevisionHistory（变更履历） RevisionDateChangeNotificationDescription 1.02025.5.6 初版 TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2450-FPC361BX ProductName:Antenna Page3 1.Specification SamplePhoto A.ElectricalCharacteristics Frequency频率2400-2500MHz/5150-5850MHz S.W.R.驻波比<=2.0 AntennaGain增益2.95dBi/4.16dBi Polarization 极化方式Linear Impedance 阻抗50Ohm B.Material&MechanicalCharacteristics CableType线材规格OD1.13mm,BIack ConnectorType连接器规格I-PEX C.Environmental StorageTemperature 存储温度 -40 ̊C~+80 ̊C OperationTemperature 工作温度 -40 ̊C~+80 ̊C TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2450-FPC361BX ProductName:Antenna Page4 2.CharacteristicsandReliabilityTest TestItems 测试 项目 TestConditionandProcedure 测试方法 Requirements 要求Result 结果 1V.S.W.R. 电压驻波比 SetDUTonNetworkAnalyzer;makeindividual calibrationtotest设置网络分析仪参数进行测试 DirectiveDUTspecification 符合待测物规范 PASS 2Insertion Loss插入损 失 SetDUTonNetworkAnalyzer;makeindividual calibrationtotest设置网络分析仪参数进行测试 DirectiveDUTspecification 符合待测物规范 PASS 3Antenna Gain 天线增益 SetDUTonAntennaChamber;makeindividual calibrationtotest设置天线暗室参数进行测试 DirectiveDUTspecification 符合待测物规范 PASS 4Solderability 可焊性 GB/T2423.28-2005 Temp:260±5°C;Duration:5seconds温度260± 5°C;持续5秒 Tinevenlyonfull 上锡均匀饱满 PASS 5PullTest 拉力 Holdingwithindividualspecification;force appliedtoaxisofterminal.单独定义产品端子拉力 1.DirectiveDUTspecification 2.FrequencyTol.≤5% 符合待测物规范;频率偏移≤5% PASS 6Dimension 尺寸 Inspectionofdimension,color,material,package, surfaceprocess.检查尺寸,颜色,材料,包装,表面处理 DirectiveDUTspecification 符合待测物规范 PASS 7RoHSWithReferencetoIEC62321:2008withflowchart 参考IEC62321测试流程 DirectiveRoHS2015/863/EU 符合RoHS2015/863/EU标准 PASS TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2450-FPC361BX ProductName:Antenna Page5 3.Antenna-SParameterTestData 4.Antenna-RadiationPatternTestData TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2450-FPC361BX ProductName:Antenna Page6 XZYZXY 2400MHz 2450MHz 2500MHz 5150MHz TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2450-FPC361BX ProductName:Antenna Page7 5550MHz 5850MHz 5.MechanicalDrawingSeeattachedfiles B C D AN2450-FPC361BX / Antenna 1/1 ±0.2±0.1±1 OD1.13 Part Number Name CB-113BS Coaxial Cable 1 No. 2 1 1 Q'ty 1 Material Finish A SYY 2025.05.06 DES BY Note: 1.Mark is important dimension;"Cpk "Identify for process control(CpK 1.33). 2.Tolerance:Unmarked tolerance refer to the standard tolerance please. 3.Pay attention to the direction of the connector. APPROVER DATE SIGN DESCRIPTION SCALE: APP BY Tolerance X.XX X.X X° TITLE: PART NO.: CUSTOMER P/N: CHK BY RF BY UNITS: mm REVISION: HFREACHRoHS2.0 CONFIDENTIAL AN2450-FPC1132 FPC Black CR-113-ZP-A 3 Cu I-PEX Au Plated AN2450-FPC1132 Black 1 2 3 端子朝向如图所示 WJ 2025.05.06 HC 2025.05.06 YCX 2025.05.06 100pcs/ PE bag Revision : A Customer : ALL APPROVED BY CHECKED BY DESIGNED BY Name: Page: 1 of 1 Date: Part Number : 产品包装规范 PACKING CRITERION 8000pcs/Carton 3. SEALING 。 MEAS G W: KGS N W: KGS QTY: PCS ITEM NO: C/NO MADE IN CHINA SIDE FRONT 2.PACKING 1 . Enter PE bag。 2025.05.06 AN2450-FPC361BX Antenna AN2450-FPC1132

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. .....................: FCC ID. ............................................ : GTS20241125007-1-03 2BMOF-CP13 Compiled by ( position+printed name+signature) .. : File administrators Peter Xiao Supervised by ( position+printed name+signature) .. : Test Engineer Evan Ouyang Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : Nov.25, 2025 Representative Laboratory Name .: Shenzhen Global Test Service Co.,Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong,China Applicant’s name ............................ : Shenzhen JuXingGongChuang Technology Co., Ltd. Address ............................................ : 801, Block A, Gang Zhi Long Business Center, Longhua District, Shenzhen, China Test specification ...........................: Standard ........................................... : FCC Part 15.247: Operation within the bands 902-928 MHz, 2400- 2483.5 MHz and 5725-5850 MHz TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Security camera Trade Mark ....................................... : N/A Manufacturer .................................... : Tianjian Group Co.,Ltd. Model/Type reference....................... : CP13 Listed Models .................................. : CP20, CP21, CP22, CP23, CP24, CP25, CP26, CP27, CP28, CP29, CP50, CP51, CP52, CP53, CP54, CP55, CP56, CP57, CP58, CP59, CP60, CP61, CP62, CP63, CP64, CP65, CP66, CP67, CP68, CP69, CQ30, CQ31, CQ32, CQ33, CQ34, CQ35, CQ36, CQ37, CQ38, CQ39, CQ80, CQ81, CQ82, CQ83, CQ84, CQ85, CQ86, CQ87, CQ88, CQ89 Operation Frequency ........................ : From 2412MHz to 2462MHz Hardware Version ............................ : N/A Software Version .............................. : N/A Rating ............................................... : DC 3.7V by battery Recharged by DC 5.0V Result................................................ : PASS Report No.: GTS20241125007-1-03 Page 2 of 25 T E S T R E P O R T Test Report No. : GTS20241125007-1-03 Nov.25, 2025 ____________________________________________________________________________________ Date of issue Equipment under Test : Security camera Model /Type : CP13 Listed model : CP20, CP21, CP22, CP23, CP24, CP25, CP26, CP27, CP28, CP29, CP50, CP51, CP52, CP53, CP54, CP55, CP56, CP57, CP58, CP59, CP60, CP61, CP62, CP63, CP64, CP65, CP66, CP67, CP68, CP69, CQ30, CQ31, CQ32, CQ33, CQ34, CQ35, CQ36, CQ37, CQ38, CQ39, CQ80, CQ81, CQ82, CQ83, CQ84, CQ85, CQ86, CQ87, CQ88, CQ89 Applicant : Shenzhen JuXingGongChuang Technology Co., Ltd. Address : 801, Block A, Gang Zhi Long Business Center, Longhua District, Shenzhen, China Manufacturer : Tianjian Group Co.,Ltd. Address : 501, No. 9, Nuclear Power Industrial Park, Fumin Community, Fucheng Street, Longhua District, Shenzhen, Guangdong, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20241125007-1-03 Page 3 of 25 Contents 1. TEST STANDARDS ......................................................................................................................................... 4 2. SUMMARY ....................................................................................................................................................... 5 2.1. General Remarks ................................................................................................................................... 5 2.2. Product Description ................................................................................................................................ 5 2.3. Equipment Under Test ........................................................................................................................... 6 2.4. Short description of the Equipment under Test (EUT) ........................................................................... 6 2.5. EUT operation mode .............................................................................................................................. 6 2.6. Block Diagram of Test Setup ................................................................................................................. 6 2.7. Related Submittal(s) / Grant (s) ............................................................................................................. 7 2.8. EUT Exercise Software .......................................................................................................................... 7 2.9. Special Accessories ............................................................................................................................... 7 2.10. External I/O Cable ................................................................................................................................ 7 2.11. Modifications .................…

Text truncated - open the document above for the full version.

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID............................................. : GTS20241125007-1-01 2BMOF-CP13 Compiled by ( position+printed name+signature) . : File administrators Peter Xiao Supervised by ( position+printed name+signature) . : Test Engineer Evan Ouyang Approved by ( position+printed name+signature) . : Manager Jason Hu Date of issue .................................... : Nov.25, 2025 Representative Laboratory Name . : Shenzhen Global Test Service Co.,Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong,China Applicant’s name ............................ : Shenzhen JuXingGongChuang Technology Co., Ltd. Address ............................................ : 801, Block A, Gang Zhi Long Business Center, Longhua District, Shenzhen, China Test specification ........................... : Standard ........................................... : FCC Part 15.247 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ...................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Security camera Trade Mark ....................................... : N/A Manufacturer .................................... : Tianjian Group Co.,Ltd. Model/Type reference ...................... : CP13 Listed Models .................................. : CP20, CP21, CP22, CP23, CP24, CP25, CP26, CP27, CP28, CP29, CP50, CP51, CP52, CP53, CP54, CP55, CP56, CP57, CP58, CP59, CP60, CP61, CP62, CP63, CP64, CP65, CP66, CP67, CP68, CP69, CQ30, CQ31, CQ32, CQ33, CQ34, CQ35, CQ36, CQ37, CQ38, CQ39, CQ80, CQ81, CQ82, CQ83, CQ84, CQ85, CQ86, CQ87, CQ88, CQ89 Modulation Type ............................... : GFSK Operation Frequency ........................ : From 2402MHz to 2480MHz Hardware Version ............................ : N/A Software Version .............................. : N/A Rating ............................................... : DC 3.7V by battery Recharged by DC 5.0V Result ............................................... : PASS Report No.: GTS20241125007-1-01 Page 2 of 42 T E S T R E P O R T Test Report No. : GTS20241125007-1-01 Nov.25, 2025 ____________________________________________________________________________________________ Date of issue Equipment under Test : Security camera Model /Type : CP13 Listed model : CP20, CP21, CP22, CP23, CP24, CP25, CP26, CP27, CP28, CP29, CP50, CP51, CP52, CP53, CP54, CP55, CP56, CP57, CP58, CP59, CP60, CP61, CP62, CP63, CP64, CP65, CP66, CP67, CP68, CP69, CQ30, CQ31, CQ32, CQ33, CQ34, CQ35, CQ36, CQ37, CQ38, CQ39, CQ80, CQ81, CQ82, CQ83, CQ84, CQ85, CQ86, CQ87, CQ88, CQ89 Applicant : Shenzhen JuXingGongChuang Technology Co., Ltd. Address : 801, Block A, Gang Zhi Long Business Center, Longhua District, Shenzhen, China Manufacturer : Tianjian Group Co.,Ltd. Address : 501, No. 9, Nuclear Power Industrial Park, Fumin Community, Fucheng Street, Longhua District, Shenzhen, Guangdong, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20241125007-1-01 Page 3 of 42 Contents 1. TEST STANDARDS ......................................................................................................................................... 4 2. SUMMARY ....................................................................................................................................................... 5 2.1. General Remarks ................................................................................................................................... 5 2.2. Product Description ................................................................................................................................ 5 2.3. Equipment Under Test ........................................................................................................................... 7 2.4. Short description of the Equipment under Test (EUT) ........................................................................... 7 2.5. EUT operation mode .............................................................................................................................. 7 2.6. Block Diagram of Test Setup ................................................................................................................. 7 2.7. EUT Exercise Software .......................................................................................................................... 8 2.8. Special Accessories ............................................................................................................................... 8 2.9. External I/O Cable .................................................................................................................................. 8 2.10. Related Submittal(s) / Grant (s) ........................................................................................................... 8 2.11. Modifications ................................…

Text truncated - open the document above for the full version.

FCC ID: 2BMOF-CP13 25 AppendixB.6:Conducted Spurious Emission Test Result TestMode Antenna Frequency[MHz] FreqRange [Mhz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict 11B Ant1 2412 Reference -5.42 -5.42 --- PASS 30~1000 -5.42 -59.78 ≤-25.42 PASS 1000~26500 -5.42 -47.94 ≤-25.42 PASS 2437 Reference -5.28 -5.28 --- PASS 30~1000 -5.28 -60.04 ≤-25.28 PASS 1000~26500 -5.28 -48 ≤-25.28 PASS 2462 Reference -6.28 -6.28 --- PASS 30~1000 -6.28 -60.3 ≤-26.28 PASS 1000~26500 -6.28 -48.18 ≤-26.28 PASS 11G Ant1 2412 Reference -7.37 -7.37 --- PASS 30~1000 -7.37 -60.66 ≤-27.37 PASS 1000~26500 -7.37 -47.56 ≤-27.37 PASS 2437 Reference -6.29 -6.29 --- PASS 30~1000 -6.29 -60.27 ≤-26.29 PASS 1000~26500 -6.29 -48.12 ≤-26.29 PASS 2462 Reference -11.03 -11.03 --- PASS 30~1000 -11.03 -60.92 ≤-31.03 PASS 1000~26500 -11.03 -47.99 ≤-31.03 PASS 11N20SISO Ant1 2412 Reference -8.32 -8.32 --- PASS 30~1000 -8.32 -61.06 ≤-28.32 PASS 1000~26500 -8.32 -47.81 ≤-28.32 PASS 2437 Reference -8.83 -8.83 --- PASS 30~1000 -8.83 -60.57 ≤-28.83 PASS 1000~26500 -8.83 -47.83 ≤-28.83 PASS 2462 Reference -9.22 -9.22 --- PASS 30~1000 -9.22 -59.74 ≤-29.22 PASS 1000~26500 -9.22 -47.45 ≤-29.22 PASS 11N40SISO Ant1 2422 Reference -11.58 -11.58 --- PASS 30~1000 -11.58 -61.06 ≤-31.58 PASS 1000~26500 -11.58 -47.64 ≤-31.58 PASS 2437 Reference -11.51 -11.51 --- PASS 30~1000 -11.51 -59.89 ≤-31.51 PASS 1000~26500 -11.51 -47.96 ≤-31.51 PASS 2452 Reference -10.16 -10.16 --- PASS 30~1000 -10.16 -60.49 ≤-30.16 PASS 1000~26500 -10.16 -47.51 ≤-30.16 PASS FCC ID: 2BMOF-CP13 26 Test Graphs 11B_Ant1_2412_0~Reference 11B_Ant1_2412_30~1000 11B_Ant1_2412_1000~26500 FCC ID: 2BMOF-CP13 27 11B_Ant1_2437_0~Reference 11B_Ant1_2437_30~1000 FCC …

Text truncated - open the document above for the full version.
