2BMR6-K10INDOOR CAMERA

MEGA MULTIMEDIA Al, INC. Applicant as U.S. Agent Letter of Attestation Date: 03.18.2025 To: Feder al Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Attestation Statement – Part2.911(d)(7) filing FCC ID: 2BMR6-K10 MEGA MULTIMEDIA Al, I NC. (“the applicant”)as required by secti on 2.911(d)(7), will also serve as the agent for service of p rocess for the above referenced FCC ID. The applicant acknowledges that they will maintain an agent for no les s t han one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is l ater. The applicant further acknowledges their responsibility to inform the FCC whenever the agent information changes. Designated U.S. Agent from Applicant Company Company Name: MEGA MULTIMEDIA Al, I NC. Contact Person: YY Feng Address: 6565 Sunset Blvd Ste 402, Los Angeles, California 90028, United States Tel.: +16266000333 Email: [email protected] Sincerely yours, Signature Printed Name: YY Feng Title: QAE Email: [email protected]

MEGA MULTIMEDIA Al, INC. 6565 Sunset Blvd Ste 402, Los Angeles, California 90028, United States Attestation Statements Not Covered EntityApplicant &Not Covered Equipment To: Federal Communications Commission Date: Mar. 18, 25 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Information Required by Section 2.911(d)(5)(i)& (ii) FCC ID: 2BMR6-K10 MEGA MULTIMEDIA Al, INC.(“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List, established pursuant to§ 1.50002 of reference chapter, as an entity producing “covered” communication equipment. The equipment for which authorization is sought is not “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List that prohibited from receiving an equipment authorization pursuant to section§ 2.903 of the FCC rules. Sincerely yours, Applicant Signature Printed Name: YY Feng Title: QAE Address: 6565 Sunset Blvd Ste 402, Los Angeles, California 90028, United States Tel.: +16266000333 Email: [email protected]

F CC Software Configuration Control Declaration Rev1 MEGA MULTIMEDIA Al, INC. 6565 Sunset Blvd Ste 402, Los Angeles, California 90028, United States FCC Software Configuration Control Declaration Date: March 18, 2025 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Attn: OET Dept. Product/ Model Number: INDOOR CAMERA /K10, K30, K50, A-CW1303B, A- CW1303B-H, CW1303B Regarding FCC Country Code Selection guidelines identified in KDB 594280. “All applications for equipment authorization for transmitters that can have radio parameters, or other technical parameters, reported to the Commission set by software must have an attestation indicating that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified.” We declare that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified. Signature: Name:YY FengDate: Mar. 18, 2025 Title: QAE Tel: +16266000333 Fax: +16266000333 Email: [email protected]

MEGA MULTIMEDIA Al, INC. 6565 Sunset Blvd Ste 402, Los Angeles, California 90028, United States Statement Product: INDOOR CAMERA Model: K10 Additional Model: K30, K50, A-CW1303B, A-CW1303B-H, CW1303B Trademark: Alaga We hereby state that K10 is tested model, other models are derivative models. The models are identical in circuit and PCB layout, different on the model names, image pixel and product appearance color. So the test data of K10 can represent the remaining models. Your assistance on this matter is highly appreciated. Yours since rely, Signature: Date: 2025-03-18 Name: YY Feng Company Name: MEGA MULTIMEDIA Al, INC. Address: 6565 Sunset Blvd Ste 402, Los Angeles, California 90028, United States Tel / Fax: +16266000333/+16266000333 E-Mail: [email protected]

MEGA MULTIMEDIA Al, INC. 6565 Sunset Blvd Ste 402, Los Angeles, California 90028, United States 1| Page Attestation Statements To: Federal Communications Commission Date: Apr. 8, 25 7435 Oakland Mills Road, Columbia, MD 21046, USA Subject: Attestation of Compliance with FCC Covered List Software Requirements FCC ID: 2BMR6-K10 Product Name: INDOOR CAMERA This letter serves as an attestation that the equipment identified above ☐ is / ☒ is not (select one) "covered" software as defined under the Federal Communications Commission (FCC) Covered List requirements, as outlined in FCC 22-84 and KDB 986446. Specifically, the undersigned certifies that the equipment for which authorization is sought: 1. Does not contain cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors, assignees, parents, subsidiaries, affiliates, or any entity that has rebranded or relabeled software produced by the aforementioned entities. 2. Does not have the capability to store, run, or deliver any software identified on the FCC Covered List, including but not limited to cybersecurity and anti-virus software. To support this attestation, the appendixevaluation documentation has been prepared and is included in the certification filing. This attestation is based on a thorough evaluation of the device's design, functionality, and software environment. The undersigned affirms that the information provided is accurate and complete to the best of their knowledge. Sincerely yours, Applicant Signature Printed Name: YY Feng Title: QAE Address: 6565 Sunset Blvd Ste 402, Los Angeles, California 90028, United States Tel.: +16266000333 Email: [email protected] MEGA MULTIMEDIA Al, INC. 6565 Sunset Blvd Ste 402, Los Angeles, California 90028, United States 2| Page Evaluation regarding to the Covered List Software: Compliance Methodology Evaluation Process Results Device is Inherent compliance ☒ The Chipset(s) used is limited to run the Cybersecurity or anti-virus software. The MCU “ XC V30“, The RF chip “ AIC8800“ don’t support the mentioned function. ☒ The Memory used is limited to run the Cybersecurity or anti-virus software. The memory size is 128M, so don’t support the mentioned function. ☒ There is storage capacitylimitation for store or install the Cybersecurity or anti-virus software. The storage capacity is 256GB, so don’t support the mentioned function. ☒ Operatingsystem used is limited to run, install or deliver the Cybersecurity or anti-virus software. The Operatingsystem “ linux“ don’t support the mentioned function. Device is not Inherent compliance ☐ Evaluation Based on Software Bill of Materials (SBoM) See attached “SBoM“ Note:The SBoM content is limited to the scope of covered list software (e.g. antivirus and cybersecurity software). ☐ Evaluation Based on Scan for Software on the device ☐ Evaluation Based on Filesystem scan ☐ Evaluation Based on Running software check SBOM (Software Bill of Materials) [For Device is not Inherent compliance] Section Component Name Version Supplier 1 2 3

MEGA MULTIMEDIA Al, INC. 6565 Sunset Blvd Ste 402, Los Angeles, California 90028, United States March 18, 2025 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request for: FCC ID: 2BMR6-K10 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby requestpermanent confidential treatment of the exhibits accompanying thiscertification application as outlined below :  Block Diagram Schematics  Operational Description The above exhibits contain trade secrets and/or proprietary information that are not publicly available and materials that the Applicant has spent considerable efforts in developing. Public disclosure of these may be harmful to the Applicant and give an unfair advantage to competitors on the market. Pursuant to DA 04-1705, the applicant also requests temporary confidential treatment of the exhibits outlined below for a period of (up to 180)days from the date of equipment authorization and prior to marketing in the United States to prevent the premature release of any sensitive information. Applicant is aware of their responsibility to notify DERYCOMin the event information regarding the product or the product is made available to the public before the requested period has expired. User Manual  Internal Photos External Photos  Test Setup Photos Sincerely, (Signature) Printed Name: YY Feng Title: QAE Address: 6565 Sunset Blvd Ste 402, Los Angeles, California 90028, United States Tel.: +16266000333 Email: [email protected]

MEGA MULTIMEDIA Al, INC. 6565 Sunset Blvd Ste 402, Los Angeles, California 90028, United States (03.18.2025) Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization for FCC ID: 2BMR6-K10 I, the undersigned, hereby authorize (SHENZHEN TONGCE TESTING LAB) to act on our behalfin all matters relating to this application for equipment certification. Any act carried out by (SHENZHEN TONGCE TESTING LAB) shall have the same effect as our own and I acknowledge that all responsibility for complying with the terms and conditions of certification, as specified by DERYCOM CERTIFICATION SERVICES, INC., still resides with (MEGA MULTIMEDIA Al, INC.). We certify that we are not subject to a denial of federal benefits that includes FCC benefitspursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862, and that no partyto the application, as defined in 47 CFR §1.2002(b), is subject to a denial of federal benefits that includes FCC benefits pursuant to that section. Sincerely, (Signature) Name: YY Feng Title: QAE Tel.: +16266000333 Fax: +16266000333 Email: [email protected]

Report No.: TCT250227E014-B Page 1 of 4 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Appendix- External Photographs of EUT Product: INDOOR CAMERA Model: K10 Report No.: TCT250227E014-B Page 2 of 4 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Report No.: TCT250227E014-B Page 3 of 4 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Report No.: TCT250227E014-B Page 4 of 4 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com

Label Artwork and Location Model: K10 Label: Size: L*W= 50*20 mm Location

Report No.: TCT250227E014-C Page 1 of 4 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Appendix- Internal Photographs of EUT Product: INDOOR CAMERA Model: K10 BLE/2.4G WIFI/ 5G WIFI ANT Report No.: TCT250227E014-C Page 2 of 4 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Report No.: TCT250227E014-C Page 3 of 4 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Report No.: TCT250227E014-C Page 4 of 4 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : 2BMR6-K10 Test Report No. ............... : TCT250227E034 Date of issue ................... : Mar. 11, 2025 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: 2101 & 2201, Zhenchang Factory, Renshan Industrial Zone, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : MEGA MULTIMEDIA Al, INC. Address ........................... : 6565 Sunset Blvd Ste 402, Los Angeles, California 90028, United States Manufacturer's name ... : MEGA MULTIMEDIA Al, INC. Address ........................... : 6565 Sunset Blvd Ste 402, Los Angeles, California 90028, United States Standard(s) ..................... : FCC CFR Title 47 Part 1.1307 Product Name ................. : INDOOR CAMERA Trade Mark ...................... : Alaga Model/Type reference ..... : K10, K30, K50, A-CW1303B, A-CW1303B-H, CW1303B Rating(s) ......................... : Input: DC 5 V, 1 A Adapter Information 1/2: MODEL: BS05A-0501000US INPUT: AC 100-240 V, 50/60 Hz, 0.25 A Max OUTPUT: DC 5 V, 1000 mA Date of receipt of test item ......................................... : Feb. 27, 2025 Date (s) of performance of test ................................... : Feb. 27, 2025 ~ Mar. 11, 2025 Tested by (+signature) ... : Aaron MO Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT250227E034 Page 2 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information ................................................................... 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list............................................................................................................ 3 2. General Information .................................................................................. 4 2.1. Test environment and mode ................................................................................. 4 2.2. Description of Support Units ................................................................................ 4 3. Facilities and Accreditations ................................................................... 5 3.1. Facilities ................................................................................................................. 5 3.2. Location ................................................................................................................. 5 4. Test Results and Measurement Data ...................................................... 6 Report No.: TCT250227E034 Page 3 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Product Name ....................... : INDOOR CAMERA Model/Type reference ........... : K10 Sample Number....................: TCT250227E014-0101 Operation Frequency ........... : For BLE: 2402MHz~2480MHz For 2.4G WIFI: 2412MHz~2462MHz (802.11b/802.11g/802.11n(HT20)/802.11ax(HE20)) 2422MHz~2452MHz (802.11n(HT40)/802.11ax(HE40)) For 5G WIFI: Band 1: 5180 MHz ~ 5240 MHz Band 3: 5745 MHz ~ 5825 MHz Modulation Type ................... : For BLE: GFSK For 2.4G WIFI: 802.11b: Direct Sequence Spread Spectrum (DSSS) 802.11g/802.11n: Orthogonal Frequency Division Multiplexing(OFDM) For 5G WIFI: 256QAM, 64QAM, 16QAM, BPSK, QPSK Antenna Type ........................ : FPC Antenna Antenna Gain ........................ : For BLE/2.4G WIFI: 1.04dBi For 5G WIFI: Band 1: 0.47dBi Band 3: 1.32dBi Rating(s) ............................... : Input: DC 5 V, 1 A Adapter Information 1/2: MODEL: BS05A-0501000US INPUT: AC 100-240 V, 50/60 Hz, 0.25 A Max OUTPUT: DC 5 V, 1000 mA Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list No. Model No. Tested with 1 K10 Other models K30, K50, A-CW1303B, A-CW1303B-H, CW1303B Note: K10 is tested model, other models are derivative models. The models are identical in circuit and PCB layout, different on the model names, image pixel and product appearance color. So the test data of K10 can represent the remaining models. Report No.: TCT250227E034 Page 4 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. General Information 2.1. Test environment and mode Item Normal condition Temperature +25ºC Voltage AC 120V Humidity 56% Atmospheric Pressure: 1008 mbar Test Mode: Transmitting Mode: Keep the EUT in continuous transmitting by select channel 2.2. Description of Support Units The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. Equipment Model No. Serial No. FCC ID Trade Name / / / / / Note: 1. All the equipment/cables were placed in the worst-case configuration to maximize the emission during the test. 2. Grounding was established in accordance with the manufacturer’s requirements and conditions for the intended use. 3. For conducted measurements (Output Power, 20dB Occupied Bandwidth, Carrier Frequencies Separation, Hopping Channel Number, Dwell Time, Spurious Emissions), the antenna of EUT is connected to the test equipment via temporary antenna connector, the antenna connector is soldered on the antenna port o…

Text truncated - open the document above for the full version.

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : 2BMR6-K10 Test Report No. ............... : TCT250227E033 Date of issue ................... : Mar. 11, 2025 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: 2101 & 2201, Zhenchang Factory, Renshan Industrial Zone, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : MEGA MULTIMEDIA Al, INC. Address ........................... : 6565 Sunset Blvd Ste 402, Los Angeles, California 90028, United States Manufacturer's name ... : MEGA MULTIMEDIA Al, INC. Address ........................... : 6565 Sunset Blvd Ste 402, Los Angeles, California 90028, United States Standard(s) ..................... : FCC CFR Title 47 Part 15 Subpart E Section 15.407 KDB 662911 D01 Multiple Transmitter Output v02r01 KDB 789033 D02 General U-NII Test Procedures New Rules v02r01 Product Name ................. : INDOOR CAMERA Trade Mark ...................... : Alaga Model/Type reference ..... : K10, K30, K50, A-CW1303B, A-CW1303B-H, CW1303B Rating(s) ......................... : Input: DC 5 V, 1 A Adapter Information 1/2: MODEL: BS05A-0501000US INPUT: AC 100-240 V, 50/60 Hz, 0.25 A Max OUTPUT: DC 5 V, 1000 mA Date of receipt of test item ......................................... : Feb. 27, 2025 Date (s) of performance of test ................................... : Feb. 27, 2025 ~ Mar. 11, 2025 Tested by (+signature) ... : Aaron MO Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT250227E033 Page 2 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TABLE OF CONTENTS 1. General Product Information ................................................................... 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list............................................................................................................ 3 1.3. Test Frequency ...................................................................................................... 4 2. Test Result Summary ............................................................................... 5 3. General Information .................................................................................. 6 3.1. Test environment and mode ................................................................................. 6 3.2. Description of Support Units ................................................................................ 7 4. Facilities and Accreditations ................................................................... 8 4.1. Facilities ................................................................................................................. 8 4.2. Location ................................................................................................................. 8 4.3. Measurement Uncertainty ..................................................................................... 8 5. Test Results and Measurement Data ...................................................... 9 5.1. Antenna requirement ............................................................................................ 9 5.2. Conducted Emission ........................................................................................... 10 5.3. Maximum Conducted Output Power .................................................................. 14 5.4. 6dB Emission Bandwidth ................................................................................... 16 5.5. 26dB Bandwidth and 99% Occupied Bandwidth .............................................. 17 5.6. Power Spectral Density ....................................................................................... 18 5.7. Band edge ............................................................................................................ 19 5.8. Unwanted Emissions .......................................................................................... 30 5.9. Frequency Stability Measurement ..................................................................... 45 Appendix A: Test Result of Conducted Test Appendix B: Photographs of Test Setup Appendix C: Photographs of EUT Report No.: TCT250227E033 Page 3 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Product Name ....................... : INDOOR CAMERA Model/Type reference ........... : K10 Sample Number....................: TCT250227E014-0101 Operation Frequency ........... : Band 1: 5180 MHz ~ 5240 MHz Band 3: 5745 MHz ~ 5825 MHz Channel Bandwidth .............. : 802.11a: 20MHz 802.11n: 20MHz, 40MHz 802.11ac: 20MHz, 40MHz 802.11ax: 20MHz, 40MHz Modulation Technology ....... : Orthogonal Frequency Division Multiplexing(OFDM) Modulation Type ................... : 256QAM, 64QAM, 16QAM, BPSK, QPSK Antenna Type ........................ : Chip Antenna Antenna Gain ........................ : Band 1: 0.47dBi Band 3: 1.32dBi Rating(s) ............................... : Input: DC 5 V, 1 A Adapter Information 1/2: MODEL: BS05A-0501000US INPUT: AC 100-240 V, 50/60 Hz, 0.25 A Max OUTPUT: DC 5 V, 1000 mA Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list No. Model No. Tested with 1 K10 Other models K30, K50, A-CW1303B, A-CW1303B-H, CW1303B N…

Text truncated - open the document above for the full version.

Report No.: TCT250227E033 Page 81 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Power NVNT a 5825MHz Power NVNT n20 5745MHz Report No.: TCT250227E033 Page 82 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Power NVNT n20 5785MHz Power NVNT n20 5825MHz Report No.: TCT250227E033 Page 83 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Power NVNT n40 5755MHz Power NVNT n40 5795MHz Report No.: TCT250227E033 Page 84 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Power NVNT ac20 5745MHz Power NVNT ac20 5785MHz Report No.: TCT250227E033 Page 85 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Power NVNT ac20 5825MHz Power NVNT ac40 5755MHz Report No.: TCT250227E033 Page 86 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Power NVNT ac40 5795MHz Power NVNT ax20 5745MHz Report No.: TCT250227E033 Page 87 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Power NVNT ax20 5785MHz Power NVNT ax20 5825MHz Report No.: TCT250227E033 Page 88 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Power NVNT ax40 5755MHz Power NVNT ax40 5795MHz Report No.: TCT250227E033 Page 89 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com -26dB Bandwidth Condition Mode Frequency (MHz) -26 dB Bandwidth (MHz) Verdict NVNT a 5180 27.829 Pass NVNT a 5200 26.893 Pass NVNT a 5240 26.669 Pass NVNT n20 5180 28.340 Pass NVNT n20 5200 28.519 Pass NVNT n20 5240 27.916 Pass NVNT n40 5190 47.376 Pass NVNT n40 5230 47.350 Pass NVNT ac20 5180 28.361 Pass NVNT ac20 5200 28.650 Pass NVNT ac20 5240 28.595 Pass NVNT ac40 5190 47.779 Pass NVNT ac40 5230 48.084 Pass NVNT ax20 5180 27.351 Pass NVNT ax20 5200 27.096 Pass NVNT ax20 5240 25.845 Pass NVNT ax40 5190 45.393 Pass NVNT ax40 5230 46.219 Pass Report No.: TCT250227E033 Page 90 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Test Graphs -26dB Bandwidth NVNT a 5180MHz -26dB Bandwidth NVNT a 5200MHz Report No.: TCT250227E033 Page 91 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com -26dB Bandwidth NVNT a 5240MHz -26dB Bandwidth NVNT n20 5180MHz Report No.: TCT250227E033 Page 92 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com -26dB Bandwidth NVNT n20 5200MHz -26dB Bandwidth NVNT n20 5240MHz Report No.: TCT250227E033 Page 93 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com -26dB Bandwidth NVNT n40 5190MHz -26dB Bandwidth NVNT n40 5230MHz Report No.: TCT250227E033 Page 94 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com -26dB Bandwidth NVNT ac20 5180MHz -26dB Bandwidth NVNT ac20 5200MHz Report No.: TCT250227E033 Page 95 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com -26dB Bandwidth NVNT ac20 5240MHz -26dB Bandwidth NVNT ac40 5190MHz Report No.: TCT250227E033 Page 96 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com -26dB Bandwidth NVNT ac40 5230MHz -26dB Bandwidth NVNT ax20 5180MHz Report No.: TCT250227E033 Page 97 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com -26dB Bandwidth NVNT ax20 5200MHz -26dB Bandwidth NVNT ax20 5240MHz Report No.: TCT250227E033 Page 98 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com -26dB Bandwidth NVNT ax40 5190MHz -26dB Bandwidth NVNT ax40 5230MHz Report No.: TCT250227E033 Page 99 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com -6dB Bandwidth Condition Mode Frequency (MHz) -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT a 5745 16.379 0.5 Pass NVNT a 5785 16.373 0.5 Pass NVNT a 5825 16.397 0.5 Pass NVNT n20 5745 17.609 0.5 Pass NVNT n20 5785 17.621 0.5 Pass NVNT n20 5825 17.621 0.5 Pass NVNT n40 5755 36.386 0.5 Pass NVNT n40 5795 36.378 0.5 Pass NVNT ac20 5745 17.639 0.5 Pass NVNT ac20 5785 17.618 0.5 Pass NVNT ac20 5825 17.605 0.5 Pass NVNT ac40 5755 36.364 0.5 Pass NVNT ac40 5795 36.401 0.5 Pass NVNT ax20 5745 18.962 0.5 Pass NVNT ax20 5785 18.981 0.5 Pass NVNT ax20 5825 19.084 0.5 Pass NVNT ax40 5755 38.011 0.5 Pass NVNT ax40 5795 38.023 0.5 Pass Report No.: TCT250227E033 Page 100 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Test Graphs -6dB Bandwidth NVNT a 5745MHz -6dB Bandwidth NVNT a 5785MHz Report No.: TCT250227E033 Page 101 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com -6dB Bandwidth NVNT a 5825MHz -6dB Bandwidth NVNT n20 5745MHz Report No.: TCT250227E033 Page 102 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com -6dB Bandwidth NVNT n20 5785MHz -6dB Bandwidth NVNT n20 5825MHz Report No.: TCT250227E033 Page 103 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com -6dB Bandwidth NVNT n40 5755MHz -6dB Bandwidth NVNT n40 5795MHz Report No.: TCT250227E033 Page 104 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com -6dB Bandwidth NVNT ac20 5745MHz -6dB Bandwidth NVNT ac20 5785MHz Report No.: TCT250227E033 Page 105 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com -6dB Bandwidth NVNT ac20 5825MHz -6dB Bandwidth NVNT ac40 5755MHz Report No.: TCT250227E033 Page 106 of 147 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com -6dB Bandwidth NVNT ac40 5795MHz -6dB Bandwidth NVNT ax20 5745MHz Report No.: TCT250227…

Text truncated - open the document above for the full version.

SPECIFICATION FOR APPROVAL CUSTOMER ： CUSTOMER’S P/N ： PART NUMBER ： WAN0921007DD252SH01 DESCRIPTION ： Chip Antenna 1007 M Ant 2.45G +5G Type H01 V1. VERSION ： 2 ISSUE DATE ： 2023/12/12 CUSTOMER APPROVED R&D CENTER APPROVAL CHECKED DRAWN Ray Snow Jerry 1F, No. 151, Li Gong Street, Beitou District, Taipei City 112, Taiwan TEL: +886 2 2898-2220 FAX: +886 2 2898- :(02) 2898-2220 :(02) 2898- OneWaveElectronic Co., Ltd. 50555055 2/12 ONEWAVE TECHNOLOGY CO., LTD. 1007 Side-standing Antenna For WLAN Dual-Band Applications Dimension (mm) L 10.0 ± 0.20 W 1.65 ± 0.20 T 7.00 ± 0.20 P/N: WAN0921007DD252SH01 3/12 ONEWAVE TECHNOLOGY CO., LTD. Part Number Information WAN 09 2 1007 D D25 2S H 01 A G H B C D I E F A Product Series Antenna B Dimensi…

Text truncated - open the document above for the full version.
