2BMSD-C25Smartphone
Shenzhen Baitai Network Technology Co., Ltd
Click to zoom
Application Details
- Equipment Class
- PCE - PCS Licensed Transmitter held to ear
- Date of Grant
- Jan 21, 2026
- Application Purpose
- Original Equipment
- Equipment Note
- Smartphone
- Frequency Range
- 699.70000000 - 715.30000000
- Country
- China
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Test Report
Report 1 Conducted output power Band Bandwidth (MHz) UL Channel RB Size RB Position Modulation Power (dBm) Gain (dB) ERP (dBm) ERP (mW) ERP Limit (mW) Verdict Band12 1.4 23017 1 #0 QPSK 23.25 -0.1 21.00 125.89 3000 PASS Band12 1.4 23017 1 #Mid QPSK 23.36 -0.1 21.11 129.12 3000 PASS Band12 1.4 23017 1 #Max QPSK 23.26 -0.1 21.01 126.18 3000 PASS Band12 1.4 23017 3 #0 QPSK 23.28 -0.1 21.03 126.77 3000 PASS Band12 1.4 23017 3 #Max QPSK 23.28 -0.1 21.03 126.77 3000 PASS Band12 1.4 23017 6 #0 QPSK 22.16 -0.1 19.91 97.95 3000 PASS Band12 1.4 23017 1 #0 QAM16 22.21 -0.1 19.96 99.08 3000 PASS Band12 1.4 23017 1 #Mid QAM16 22.37 -0.1 20.12 102.80 3000 PASS Band12 1.4 23017 1 #Max QAM16 22.25 -0.1 20.00 100.00 3000 PASS Band12 1.4 23017 3 #0 QAM16 22.45 -0.1 20.20 104.71 3000 PASS Band12 1.4 23017 3 #Max QAM16 22.45 -0.1 20.20 104.71 3000 PASS Band12 1.4 23017 6 #0 QAM16 21.18 -0.1 18.93 78.16 3000 PASS Band12 1.4 23095 1 #0 QPSK 23.07 -0.1 20.82 120.78 3000 PASS Band12 1.4 23095 1 #Mid QPSK 23.19 -0.1 20.94 124.17 3000 PASS Band12 1.4 23095 1 #Max QPSK 23.05 -0.1 20.80 120.23 3000 PASS Band12 1.4 23095 3 #0 QPSK 23.15 -0.1 20.90 123.03 3000 PASS Band12 1.4 23095 3 #Max QPSK 23.15 -0.1 20.90 123.03 3000 PASS Band12 1.4 23095 6 #0 QPSK 22.07 -0.1 19.82 95.94 3000 PASS Band12 1.4 23095 1 #0 QAM16 22.25 -0.1 20.00 100.00 3000 PASS Band12 1.4 23095 1 #Mid QAM16 22.36 -0.1 20.11 102.57 3000 PASS Band12 1.4 23095 1 #Max QAM16 22.26 -0.1 20.01 100.23 3000 PASS Band12 1.4 23095 3 #0 QAM16 22.23 -0.1 19.98 99.54 3000 PASS Band12 1.4 23095 3 #Max QAM16 22.23 -0.1 19.98 99.54 3000 PASS Band12 1.4 23095 6 #0 QAM16 20.99 -0.1 18.74 74.82 3000 PASS Band12 1.4 23173 1 #0 QPSK 23.03 -0.1 20.78 119.67 3000 PASS Band12 1.4 23173 1 #Mid QPSK 23.09 -0.1 20.84 121.34 3000 PASS Band12 1.4 23173 1 #Max QPSK 23.01 -0.1 20.76 119.12 3000 PASS Band12 1.4 23173 3 #0 QPSK 23.06 -0.1 20.81 120.50 3000 PASS Band12 1.4 23173 3 #Max QPSK 23.03 -0.1 20.78 119.67 3000 PASS Band12 1.4 23173 6 #0 QPSK 21.95 -0.1 19.70 93.33 3000 PASS Band12 1.4 23173 1 #0 QAM16 21.90 -0.1 19.65 92.26 3000 PASS Band12 1.4 23173 1 #Mid QAM16 21.96 -0.1 19.71 93.54 3000 PASS Band12 1.4 23173 1 #Max QAM16 21.89 -0.1 19.64 92.04 3000 PASS Band12 1.4 23173 3 #0 QAM16 22.03 -0.1 19.78 95.06 3000 PASS Band12 1.4 23173 3 #Max QAM16 22.01 -0.1 19.76 94.62 3000 PASS Band12 1.4 23173 6 #0 QAM16 20.93 -0.1 18.68 73.79 3000 PASS Band12 3 23025 1 #0 QPSK 23.17 -0.1 20.92 123.59 3000 PASS Band12 3 23025 1 #Mid QPSK 23.19 -0.1 20.94 124.17 3000 PASS Band12 3 23025 1 #Max QPSK 23.15 -0.1 20.90 123.03 3000 PASS Report Band12 3 23025 8 #0 QPSK 22.28 -0.1 20.03 100.69 3000 PASS Band12 3 23025 8 #Max QPSK 22.27 -0.1 20.02 100.46 3000 PASS Band12 3 23025 15 #0 QPSK 22.25 -0.1 20.00 100.00 3000 PASS Band12 3 23025 1 #0 QAM16 22.46 -0.1 20.21 104.95 3000 PASS Band12 3 23025 1 #Mid QAM16 22.49 -0.1 20.24 105.68 3000 PASS Band12 3 23025 1 #Max QAM16 22.44 -0.1 20.19 104.47 3000 PASS Band12 3 23025 8 #0 QAM16 21.27 -0.1 19.02 79.80 3000 PASS Band12 3 23025 8 #Max QAM16 21.27 -0.1 19.02 79.80 3000 PASS Band12 3 23025 15 #0 QAM16 21.19 -0.1 18.94 78.34 3000 PASS Band12 3 23095 1 #0 QPSK 23.08 -0.1 20.83 121.06 3000 PASS Band12 3 23095 1 #Mid QPSK 23.07 -0.1 20.82 120.78 3000 PASS Band12 3 23095 1 #Max QPSK 23.01 -0.1 20.76 119.12 3000 PASS Band12 3 23095 8 #0 QPSK 22.19 -0.1 19.94 98.63 3000 PASS Band12 3 23095 8 #Max QPSK 22.15 -0.1 19.90 97.72 3000 PASS Band12 3 23095 15 #0 QPSK 22.14 -0.1 19.89 97.50 3000 PASS Band12 3 23095 1 #0 QAM16 22.29 -0.1 20.04 100.93 3000 PASS Band12 3 23095 1 #Mid QAM16 22.25 -0.1 20.00 100.00 3000 PASS Band12 3 23095 1 #Max QAM16 22.20 -0.1 19.95 98.86 3000 PASS Band12 3 23095 8 #0 QAM16 21.17 -0.1 18.92 77.98 3000 PASS Band12 3 23095 8 #Max QAM16 21.10 -0.1 18.85 76.74 3000 PASS Band12 3 23095 15 #0 QAM16 21.02 -0.1 18.77 75.34 3000 PASS Band12 3 23165 1 #0 QPSK 22.98 -0.1 20.73 118.30 3000 PASS Band12 3 23165 1 #Mid QPSK 23.01 -0.1 20.76 119.12 3000 PASS Band12 3 23165 1 #Max QPSK 22.98 -0.1 20.73 118.30 3000 PASS Band12 3 23165 8 #0 QPSK 22.04 -0.1 19.79 95.28 3000 PASS Band12 3 23165 8 #Max QPSK 22.00 -0.1 19.75 94.41 3000 PASS Band12 3 23165 15 #0 QPSK 21.98 -0.1 19.73 93.97 3000 PASS Band12 3 23165 1 #0 QAM16 21.86 -0.1 19.61 91.41 3000 PASS Band12 3 23165 1 #Mid QAM16 21.86 -0.1 19.61 91.41 3000 PASS Band12 3 23165 1 #Max QAM16 21.84 -0.1 19.59 90.99 3000 PASS Band12 3 23165 8 #0 QAM16 21.03 -0.1 18.78 75.51 3000 PASS Band12 3 23165 8 #Max QAM16 20.99 -0.1 18.74 74.82 3000 PASS Band12 3 23165 15 #0 QAM16 20.99 -0.1 18.74 74.82 3000 PASS Band12 5 23035 1 #0 QPSK 23.24 -0.1 20.99 125.60 3000 PASS Band12 5 23035 1 #Mid QPSK 23.24 -0.1 20.99 125.60 3000 PASS Band12 5 23035 1 #Max QPSK 23.18 -0.1 20.93 123.88 3000 PASS Band12 5 23035 12 #0 QPSK 22.30 -0.1 20.05 101.16 3000 PASS Band12 5 23035 12 #Max QPSK 22.27 -0.1 20.02 100.46 3000 PASS Band12 5 23035 25 #0 QPSK 22.23 -0.1 19.98 99.54 3000 PASS Band12 5 23035 1 #0 QAM16 22.53 -0.1 20.28 106.66 3000 PASS Band12 5 23035 1 #Mid QAM16 22.54 -0.1 20.29 106.91 3000 PASS Band12 5 23035 1 #Max QAM16 22.49 -0.1 20.24 105.68 3000 PASS Band12 5 23035 12 #0 QAM16 21.26 -0.1 19.01 79.62 3000 PASS Band12 5 23035 12 #Max QAM16 21.23 -0.1 18.98 79.07 3000 PASS Report Band12 5 23035 25 #0 QAM16 21.21 -0.1 18.96 78.70 3000 PASS Band12 5 23095 1 #0 QPSK 23.19 -0.1 20.94 124.17 3000 PASS Band12 5 23095 1 #Mid QPSK 23.12 -0.1 20.87 122.18 3000 PASS Band12 5 23095 1 #Max QPSK 23.06 -0.1 20.81 120.50 3000 PASS Band12 5 23095 12 #0 QPSK 22.22 -0.1 19.97 99.31 3000 PASS Band12 5 23095 12 #Max QPSK 22.19 -0.1 19.94 98.63 3000 PASS Band12 5 23095 25 #0 QPSK 22.13 -0.1 19.88 97.27 3000 PASS Band12 5 23095 1 #0 QAM16 22.39 -0.1 20.14 103.28 3000 PASS Band12 5 23095 1 #Mid QAM16 22.36 -0.1 20.11 102.57 3000 PASS Band12 5 23095 1 #Max QAM16 22.29 -0.1 20.04 100.93 3000 PASS Band12 5 23095 12 #0 QAM16 21.18 -0.1 18.93 78.16 3000 PASS Band12 5 23095 12 #Max QAM16 21.12 -0.1 18.87 77.09 3000 PASS Band12 5 23095 25 #0 QAM16 21.09…
Text truncated - open the document above for the full version.
Test Setup Photos
Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 2 Model: C25 Ultra Radiated Emission Below 1G Above 1G Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 2 Conducted emissions
Test Setup Photos
Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 2 Model: C25 Ultra Right Head Cheek Right Head Tilt Left Head Cheek Left Head Tilt Body/ Hotspot (Front Side) Body/ Hotspot (Back Side) 0.5cm separation 0.5cm separation Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 2 Body/Hotspot (Right Edge) Body/Hotspot (Left Edge) Body/Hotspot (Top Edge) Body/Hotspot (Bottom Edge) 0.5cm separation 0.5cm separation 0.5cm separation 0.5cm separation
Test Report
Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 48 TEST REPORT Compiled by: Reviewed by: Approved by: Kai Chen Martin Feng Bin Mei / Director Note: If there is any objection to the inspection results in this report, please submit a written report to the company within 15 days from the date of receiving the report. The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen CTB Testing Technology Co., Ltd. this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. “*” indicates the testing items were fulfilled by subcontracted lab. “#” indicates the items are not in CNAS accreditation scope. Test item description: Smartphone FCC ID: 2BMSD-C25 Trademark(s): N/A Model/Type reference: C25 Ultra, C24 Ultra, S25 Ultra, A16 Pro Max, A17Pro Max, S26 Ultra, C26 Ultra, A56, A57 Applicant’s name: Shenzhen Baitai Network Technology Co., Ltd Address: Room 1901, 19th Floor, City Shanhaipingji Center, No. 51 Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen Manufacturer: Shenzhen Baitai Network Technology Co., Ltd Address: Room 1901, 19th Floor, City Shanhaipingji Center, No. 51 Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen Prepared By: Shenzhen CTB Testing Technology Co., Ltd. Address: 1&2/F., Building A, No.26, Xinhe Road, Xinqiao, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: Nov. 27, 2025 Sample tested Date: Nov. 27, 2025 to Dec. 15, 2025 Issue Date: Dec. 15, 2025 Report No.: CTB25112705603RF04 Test Standards FCC Part 2, 22, 24E, 27 Test Results PASS Remark: This is LTE radio test report. Shenzhen CTB Testing Technology Co., Ltd. Report No.:CTB25112705603RF04 Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 48 TABLE OF CONTENT Test Report Declaration Page 1. VERSION ............................................................ 3 2. TEST SUMMARY ..................................................... 4 3. MEASUREMENT UNCERTAINTY ....................................... 5 4. PRODUCT INFORMATION AND TEST SETUP ........................... 6 4.1 Product Information ..................................................... 6 4.2 Test Setup Configuration ................................................ 7 4.3 Support Equipment ..................................................... 7 4.4 Test Mode ............................................................. 7 4.5 Test Environment ...................................................... 10 5. TEST FACILITY AND TEST INSTRUMENT USED ........................ 11 5.1 Test Facility ........................................................... 11 5.2 Test Instrument Used .................................................. 11 6. RF EXPOSURE ...................................................... 13 6.1 Standard Applicable ................................................... 13 6.2 Test Result ........................................................... 13 7. RF OUTPUT POWER ................................................. 14 7.1 Standard Applicable ................................................... 14 7.2 Test Procedure ........................................................ 14 7.3 Summary of Test Results/Plots .......................................... 14 8. PEAK-TO-AVERAGE RATIO (PAR) OF TRANSMITTER .................. 15 8.1 Standard Applicable ................................................... 15 8.2 Test Procedure ........................................................ 15 8.3 Summary of Test Results ............................................... 15 9. EMISSION BANDWIDTH .............................................. 16 9.1 Standard Applicable ................................................... 16 9.2 Test Procedure ........................................................ 16 9.3 Summary of Test Results/Plots .......................................... 16 10. OUT OF BAND EMISSIONS AT ANTENNA TERMINAL ................... 17 10.1 Standard Applicable .................................................. 17 10.2 Test Procedure ....................................................... 17 10.3 Summary of Test Results/Plots ......................................... 18 11. SPURIOUS RADIATED EMISSIONS ................................... 19 11.1 Standard Applicable .................................................. 19 11.2 Test Procedure ....................................................... 20 11.3 Summary of Test Results/Plots ......................................... 20 12. FREQUENCY STABILITY ............................................. 48 12.1 Standard Applicable .................................................. 48 12.2 Test Procedure ....................................................... 48 12.3 Summary of Test Results/Plots ......................................... 48 (Note: N/A means not applicable) Shenzhen CTB Testing Technology Co., Ltd. Report No.:CTB25112705603RF04 Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 3 of 48 1. VERSION Report No. Issue Date Description Approved CTB25112705603RF04 Dec. 15, 2025 Original Valid Shenzhen CTB Testing Technology Co., Ltd. Report No.:CTB25112705603RF04 Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 4 of 48 2. TEST SUMMARY The Product has been tested according to the following specifications: Test Item Test Requirement Test method Result Conducted output power Part 2.1046(a) TIA-603-E-2016 & KDB 971168 D01v03r01 PASS Effective Radiated Power of Transmitter(EIRP) Part 22.913(a)(5)/Part27.50(h)(2) TIA-603-E-2016 & KDB 971168 D01v03r01 PASS peak-to-average ratio Part 27.50(d) KDB 971168 D01v03r01 PASS 99% & 26dB Occupied Bandwidth Part 2.1049(h) KDB 971168 D01v03r01 PASS Band Edge at antenna terminals Part 2.1051/ Part 22.917(a)/Part 27.53(m) (4) KDB 971168 D01v03r01 PASS Spurious emissions at an…
Text truncated - open the document above for the full version.
Test Report
Report Band5 QPSK BW=3MHz Channel=20635 RB Size=15 Position=#0 Band5 QAM16 BW=3MHz Channel=20635 RB Size=15 Position=#0 Report Band5 QAM16 BW=5MHz Channel=20425 RB Size=25 Position=#0 Band5 QPSK BW=5MHz Channel=20425 RB Size=25 Position=#0 Report Band5 QPSK BW=5MHz Channel=20625 RB Size=25 Position=#0 Band5 QAM16 BW=5MHz Channel=20625 RB Size=25 Position=#0 Report Band5 QPSK BW=10MHz Channel=20450 RB Size=50 Position=#0 Band5 QAM16 BW=10MHz Channel=20450 RB Size=50 Position=#0 Report Band5 QAM16 BW=10MHz Channel=20600 RB Size=50 Position=#0 Band5 QPSK BW=10MHz Channel=20600 RB Size=50 Position=#0 Report Band7 QPSK BW=5MHz Channel=20775 RB Size=25 Position=#0 Band7 QAM16 BW=5MHz Channel=20775 RB Size=25 Position=#0 Report Band7 QPSK BW=5MHz Channel=21425 RB Size=25 Position=#0 Band7 QAM16 BW=5MHz Channel=21425 RB Size=25 Position=#0 Report Band7 QAM16 BW=10MHz Channel=20800 RB Size=50 Position=#0 Band7 QPSK BW=10MHz Channel=20800 RB Size=50 Position=#0 Report Band7 QPSK BW=10MHz Channel=21400 RB Size=50 Position=#0 Band7 QAM16 BW=10MHz Channel=21400 RB Size=50 Position=#0 Report Band7 QAM16 BW=15MHz Channel=20825 RB Size=75 Position=#0 Band7 QPSK BW=15MHz Channel=20825 RB Size=75 Position=#0 Report Band7 QPSK BW=15MHz Channel=21375 RB Size=75 Position=#0 Band7 QAM16 BW=15MHz Channel=21375 RB Size=75 Position=#0 Report Band7 QPSK BW=20MHz Channel=20850 RB Size=100 Position=#0 Band7 QAM16 BW=20MHz Channel=20850 RB Size=100 Position=#0 Report Band7 QPSK BW=20MHz Channel=21350 RB Size=100 Position=#0 Band7 QAM16 BW=20MHz Channel=21350 RB Size=100 Position=#0 Report
Test Report
Report Band41(2535-2675) QAM16 BW=15MHz Channel=40115 RB Size=75 Position=#0 Band41(2535-2675) QAM16 BW=15MHz Channel=41365 RB Size=75 Position=#0 Report Band41(2535-2675) QPSK BW=15MHz Channel=41365 RB Size=75 Position=#0 Band41(2535-2675) QPSK BW=20MHz Channel=40140 RB Size=100 Position=#0 Report Band41(2535-2675) QAM16 BW=20MHz Channel=40140 RB Size=100 Position=#0 Band41(2535-2675) QPSK BW=20MHz Channel=41340 RB Size=100 Position=#0 Report Band41(2535-2675) QAM16 BW=20MHz Channel=41340 RB Size=100 Position=#0 Band5 QAM16 BW=1.4MHz Channel=20407 RB Size=6 Position=#0 Report Band5 QPSK BW=1.4MHz Channel=20407 RB Size=6 Position=#0 Band5 QPSK BW=1.4MHz Channel=20643 RB Size=6 Position=#0 Report Band5 QAM16 BW=1.4MHz Channel=20643 RB Size=6 Position=#0 Band5 QPSK BW=3MHz Channel=20415 RB Size=15 Position=#0 Report Band5 QAM16 BW=3MHz Channel=20415 RB Size=15 Position=#0 Band5 QPSK BW=3MHz Channel=20635 RB Size=15 Position=#0 Report Band5 QAM16 BW=3MHz Channel=20635 RB Size=15 Position=#0 Band5 QPSK BW=5MHz Channel=20425 RB Size=25 Position=#0 Report Band5 QAM16 BW=5MHz Channel=20425 RB Size=25 Position=#0 Band5 QAM16 BW=5MHz Channel=20625 RB Size=25 Position=#0 Report Band5 QPSK BW=5MHz Channel=20625 RB Size=25 Position=#0 Band5 QPSK BW=10MHz Channel=20450 RB Size=50 Position=#0 Report Band5 QAM16 BW=10MHz Channel=20450 RB Size=50 Position=#0 Band5 QPSK BW=10MHz Channel=20600 RB Size=50 Position=#0 Report Band5 QAM16 BW=10MHz Channel=20600 RB Size=50 Position=#0 Band7 QAM16 BW=5MHz Channel=20775 RB Size=25 Position=#0 Report Band7 QPSK BW=5MHz Channel=20775 RB Size=25 Position=#0 Band7 QPSK BW=5MHz Channel=21425 RB Size=25 Position=#0 Report Band7 QAM16 BW=5MHz Channel=21425 RB Size=25 Position=#0 Band7 QAM16 BW=10MHz Channel=20800 RB Size=50 Position=#0 Report Band7 QPSK BW=10MHz Channel=20800 RB Size=50 Position=#0 Band7 QPSK BW=10MHz Channel=21400 RB Size=50 Position=#0 Report Band7 QAM16 BW=10MHz Channel=21400 RB Size=50 Position=#0 Band7 QPSK BW=15MHz Channel=20825 RB Size=75 Position=#0 Report Band7 QAM16 BW=15MHz Channel=20825 RB Size=75 Position=#0 Band7 QAM16 BW=15MHz Channel=21375 RB Size=75 Position=#0 Report Band7 QPSK BW=15MHz Channel=21375 RB Size=75 Position=#0 Band7 QPSK BW=20MHz Channel=20850 RB Size=100 Position=#0 Report Band7 QAM16 BW=20MHz Channel=20850 RB Size=100 Position=#0 Band7 QAM16 BW=20MHz Channel=21350 RB Size=100 Position=#0 Report Band7 QPSK BW=20MHz Channel=21350 RB Size=100 Position=#0 6 Out-of-band emissions Report Band Bandwidth (MHz) UL Channel RB Size RB Position Modulation Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict Band12 1.4 23017 6 #0 QPSK 1400.00 -31.91 -13 PASS Band12 1.4 23017 6 #0 QAM16 25799.38 -32.52 -13 PASS Band12 1.4 23173 6 #0 QPSK 1431.25 -31.64 -13 PASS Band12 1.4 23173 6 #0 QAM16 25794.38 -31.84 -13 PASS Band12 3 23025 15 #0 QPSK 25778.13 -32.02 -13 PASS Band12 3 23025 15 #0 QAM16 25776.25 -32.37 -13 PASS Band12 3 23165 15 #0 QPSK 25818.13 -32.33 -13 PASS Band12 3 23165 15 #0 QAM16 25633.13 -32.11 -13 PASS Band12 5 23035 25 #0 QPSK 25457.50 -32.86 -13 PASS Band12 5 23035 25 #0 QAM16 25378.75 -32.71 -13 PASS Band12 5 23155 25 #0 QPSK 25767.50 -32.08 -13 PASS Band12 5 23155 25 #0 QAM16 25821.88 -32.38 -13 PASS Band12 10 23060 50 #0 QPSK 25805.00 -31.51 -13 PASS Band12 10 23060 50 #0 QAM16 25730.63 -32.64 -13 PASS Band12 10 23130 50 #0 QPSK 25686.88 -32.55 -13 PASS Band12 10 23130 50 #0 QAM16 25454.38 -32.40 -13 PASS Band2 1.4 18607 6 #0 QPSK 25813.75 -30.20 -13 PASS Band2 1.4 18607 6 #0 QAM16 25764.38 -29.68 -13 PASS Band2 1.4 19193 6 #0 QPSK 25793.13 -30.51 -13 PASS Band2 1.4 19193 6 #0 QAM16 25808.13 -30.14 -13 PASS Band2 3 18615 15 #0 QPSK 25634.38 -30.36 -13 PASS Band2 3 18615 15 #0 QAM16 25801.25 -30.47 -13 PASS Band2 3 19185 15 #0 QPSK 25813.75 -30.71 -13 PASS Band2 3 19185 15 #0 QAM16 25830.00 -30.79 -13 PASS Band2 5 18625 25 #0 QPSK 25706.25 -30.24 -13 PASS Band2 5 18625 25 #0 QAM16 25810.63 -30.38 -13 PASS Band2 5 19175 25 #0 QPSK 25742.50 -30.60 -13 PASS Band2 5 19175 25 #0 QAM16 25792.50 -31.18 -13 PASS Band2 10 18650 50 #0 QPSK 25695.63 -29.77 -13 PASS Band2 10 18650 50 #0 QAM16 25784.38 -30.16 -13 PASS Band2 10 19150 50 #0 QPSK 25603.13 -31.00 -13 PASS Band2 10 19150 50 #0 QAM16 25804.38 -29.26 -13 PASS Band2 15 18675 75 #0 QPSK 25813.13 -28.98 -13 PASS Band2 15 18675 75 #0 QAM16 25850.63 -30.48 -13 PASS Band2 15 19125 75 #0 QPSK 25420.00 -31.19 -13 PASS Band2 15 19125 75 #0 QAM16 25814.38 -30.93 -13 PASS Band2 20 18700 100 #0 QPSK 25829.38 -30.28 -13 PASS Band2 20 18700 100 #0 QAM16 25753.13 -29.84 -13 PASS Band2 20 19100 100 #0 QPSK 25673.13 -30.80 -13 PASS Band2 20 19100 100 #0 QAM16 25620.00 -30.37 -13 PASS Band38 5 37775 25 #0 QPSK 25816.88 -30.93 -25 PASS Band38 5 37775 25 #0 QAM16 25646.88 -30.54 -25 PASS Report Band38 5 38225 25 #0 QPSK 25793.13 -30.88 -25 PASS Band38 5 38225 25 #0 QAM16 25770.00 -30.39 -25 PASS Band38 10 37800 50 #0 QPSK 25604.38 -31.03 -25 PASS Band38 10 37800 50 #0 QAM16 25861.25 -31.22 -25 PASS Band38 10 38200 50 #0 QPSK 25721.88 -30.17 -25 PASS Band38 10 38200 50 #0 QAM16 25720.00 -30.63 -25 PASS Band38 15 37825 75 #0 QPSK 25866.25 -30.40 -25 PASS Band38 15 37825 75 #0 QAM16 25811.25 -30.38 -25 PASS Band38 15 38175 75 #0 QPSK 2682.50 -29.33 -25 PASS Band38 15 38175 75 #0 QAM16 25813.75 -30.81 -25 PASS Band38 20 37850 100 #0 QPSK 25436.25 -30.49 -25 PASS Band38 20 37850 100 #0 QAM16 25796.25 -30.79 -25 PASS Band38 20 38150 100 #0 QPSK 25823.75 -31.19 -25 PASS Band38 20 38150 100 #0 QAM16 25683.75 -30.94 -25 PASS Band4 1.4 19957 6 #0 QPSK 25737.50 -28.47 -13 PASS Band4 1.4 19957 6 #0 QAM16 25756.25 -29.10 -13 PASS Band4 1.4 20393 6 #0 QPSK 25507.50 -28.28 -13 PASS Band4 1.4 20393 6 #0 QAM16 25370.63 -28.94 -13 PASS Band4 3 19965 15 #0 QPSK 25701.88 -28.91 -13 PASS Band4 3 19965 15 #0 QAM16 25623.75 -29.19 -13 PASS Band4 3 20385 15 #0 QPSK 25809.38 -28.22 -13 PASS Band4 3 20385 15 #0 QAM16 25793.13 -28.69 -13 PASS Band4 5 19975 25 #0 QPSK 25801.88 -28.97 -13 PASS Band4 5 19975 25 #0 QAM1…
Text truncated - open the document above for the full version.
Test Report
Report Band38 QPSK BW=20MHz Channel=38000 RB Size=100 Position=#0 Band38 QAM16 BW=20MHz Channel=38000 RB Size=100 Position=#0 Report Band4 QPSK BW=1.4MHz Channel=20175 RB Size=6 Position=#0 Band4 QAM16 BW=1.4MHz Channel=20175 RB Size=6 Position=#0 Report Band4 QAM16 BW=3MHz Channel=20175 RB Size=15 Position=#0 Band4 QPSK BW=3MHz Channel=20175 RB Size=15 Position=#0 Report Band4 QPSK BW=5MHz Channel=20175 RB Size=25 Position=#0 Band4 QAM16 BW=5MHz Channel=20175 RB Size=25 Position=#0 Report Band4 QPSK BW=10MHz Channel=20175 RB Size=50 Position=#0 Band4 QAM16 BW=10MHz Channel=20175 RB Size=50 Position=#0 Report Band4 QPSK BW=15MHz Channel=20175 RB Size=75 Position=#0 Band4 QAM16 BW=15MHz Channel=20175 RB Size=75 Position=#0 Report Band4 QPSK BW=20MHz Channel=20175 RB Size=100 Position=#0 Band4 QAM16 BW=20MHz Channel=20175 RB Size=100 Position=#0 Report Band40a QAM16 BW=5MHz Channel=38750 RB Size=25 Position=#0 Band40a QPSK BW=5MHz Channel=38750 RB Size=25 Position=#0 Report Band40a QPSK BW=10MHz Channel=38750 RB Size=50 Position=#0 Band40a QAM16 BW=10MHz Channel=38750 RB Size=50 Position=#0 Report Band40b QPSK BW=5MHz Channel=39200 RB Size=25 Position=#0 Band40b QAM16 BW=5MHz Channel=39200 RB Size=25 Position=#0 Report Band40b QPSK BW=10MHz Channel=39200 RB Size=50 Position=#0 Band40b QAM16 BW=10MHz Channel=39200 RB Size=50 Position=#0 Report Band41(2535-2675) QAM16 BW=5MHz Channel=40740 RB Size=25 Position=#0 Band41(2535-2675) QPSK BW=5MHz Channel=40740 RB Size=25 Position=#0 Report Band41(2535-2675) QAM16 BW=10MHz Channel=40740 RB Size=50 Position=#0 Band41(2535-2675) QPSK BW=10MHz Channel=40740 RB Size=50 Position=#0 Report Band41(2535-2675) QPSK BW=15MHz Channel=40740 RB Size=75 Position=#0 Band41(2535-2675) QAM16 BW=15MHz Channel=40740 RB Size=75 Position=#0 Report Band41(2535-2675) QPSK BW=20MHz Channel=40740 RB Size=100 Position=#0 Band41(2535-2675) QAM16 BW=20MHz Channel=40740 RB Size=100 Position=#0 Report Band5 QPSK BW=1.4MHz Channel=20525 RB Size=6 Position=#0 Band5 QAM16 BW=1.4MHz Channel=20525 RB Size=6 Position=#0 Report Band5 QAM16 BW=3MHz Channel=20525 RB Size=15 Position=#0 Band5 QPSK BW=3MHz Channel=20525 RB Size=15 Position=#0 Report Band5 QPSK BW=5MHz Channel=20525 RB Size=25 Position=#0 Band5 QAM16 BW=5MHz Channel=20525 RB Size=25 Position=#0 Report Band5 QPSK BW=10MHz Channel=20525 RB Size=50 Position=#0 Band5 QAM16 BW=10MHz Channel=20525 RB Size=50 Position=#0 Report Band7 QPSK BW=5MHz Channel=21100 RB Size=25 Position=#0 Band7 QAM16 BW=5MHz Channel=21100 RB Size=25 Position=#0 Report Band7 QAM16 BW=10MHz Channel=21100 RB Size=50 Position=#0 Band7 QPSK BW=10MHz Channel=21100 RB Size=50 Position=#0 Report Band7 QPSK BW=15MHz Channel=21100 RB Size=75 Position=#0 Band7 QAM16 BW=15MHz Channel=21100 RB Size=75 Position=#0 Report Band7 QPSK BW=20MHz Channel=21100 RB Size=100 Position=#0 Band7 QAM16 BW=20MHz Channel=21100 RB Size=100 Position=#0 Report 5 Band edge Band Bandwidth (MHz) UL Channel RB Size RB Position Modulation Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict Band12 1.4 23017 6 #0 QPSK 698.81 -29.26 -13 PASS Band12 1.4 23017 6 #0 QAM16 698.88 -28.30 -13 PASS Band12 1.4 23173 6 #0 QPSK 716.00 -35.97 -13 PASS Band12 1.4 23173 6 #0 QAM16 716.11 -35.34 -13 PASS Band12 3 23025 15 #0 QPSK 699.00 -28.81 -13 PASS Band12 3 23025 15 #0 QAM16 699.00 -30.17 -13 PASS Band12 3 23165 15 #0 QPSK 716.01 -31.27 -13 PASS Band12 3 23165 15 #0 QAM16 716.00 -32.05 -13 PASS Band12 5 23035 25 #0 QPSK 698.98 -29.82 -13 PASS Band12 5 23035 25 #0 QAM16 698.99 -29.24 -13 PASS Band12 5 23155 25 #0 QPSK 716.01 -31.02 -13 PASS Band12 5 23155 25 #0 QAM16 716.00 -31.42 -13 PASS Band12 10 23060 50 #0 QPSK 698.83 -36.27 -13 PASS Band12 10 23060 50 #0 QAM16 698.90 -36.29 -13 PASS Band12 10 23130 50 #0 QPSK 716.11 -40.43 -13 PASS Band12 10 23130 50 #0 QAM16 716.11 -37.63 -13 PASS Band2 1.4 18607 6 #0 QPSK 1849.92 -30.56 -13 PASS Band2 1.4 18607 6 #0 QAM16 1849.96 -32.34 -13 PASS Band2 1.4 19193 6 #0 QPSK 1910.03 -18.40 -13 PASS Band2 1.4 19193 6 #0 QAM16 1910.01 -23.30 -13 PASS Report Band2 3 18615 15 #0 QPSK 1850.00 -27.47 -13 PASS Band2 3 18615 15 #0 QAM16 1850.00 -30.63 -13 PASS Band2 3 19185 15 #0 QPSK 1910.00 -20.78 -13 PASS Band2 3 19185 15 #0 QAM16 1910.00 -24.19 -13 PASS Band2 5 18625 25 #0 QPSK 1850.00 -25.76 -13 PASS Band2 5 18625 25 #0 QAM16 1850.00 -26.20 -13 PASS Band2 5 19175 25 #0 QPSK 1910.03 -21.96 -13 PASS Band2 5 19175 25 #0 QAM16 1910.00 -25.05 -13 PASS Band2 10 18650 50 #0 QPSK 1849.98 -32.98 -13 PASS Band2 10 18650 50 #0 QAM16 1850.00 -33.32 -13 PASS Band2 10 19150 50 #0 QPSK 1910.14 -27.21 -13 PASS Band2 10 19150 50 #0 QAM16 1910.06 -29.90 -13 PASS Band2 15 18675 75 #0 QPSK 1850.00 -33.48 -13 PASS Band2 15 18675 75 #0 QAM16 1849.97 -34.81 -13 PASS Band2 15 19125 75 #0 QPSK 1910.63 -27.28 -13 PASS Band2 15 19125 75 #0 QAM16 1910.00 -29.68 -13 PASS Band2 20 18700 100 #0 QPSK 1849.32 -35.40 -13 PASS Band2 20 18700 100 #0 QAM16 1849.92 -35.64 -13 PASS Band2 20 19100 100 #0 QPSK 1910.24 -28.48 -13 PASS Band2 20 19100 100 #0 QAM16 1910.00 -31.51 -13 PASS Band38 5 37775 25 #0 QPSK 2569.00 -15.48 -10 PASS Band38 5 37775 25 #0 QAM16 2568.99 -17.66 -10 PASS Band38 5 38225 25 #0 QPSK 2621.01 -17.12 -10 PASS Band38 5 38225 25 #0 QAM16 2621.00 -18.70 -10 PASS Band38 10 37800 50 #0 QPSK 2558.40 -33.21 -25 PASS Band38 10 37800 50 #0 QAM16 2559.65 -38.10 -25 PASS Band38 10 38200 50 #0 QPSK 2630.35 -34.71 -25 PASS Band38 10 38200 50 #0 QAM16 2630.28 -33.70 -25 PASS Band38 15 37825 75 #0 QPSK 2554.98 -37.16 -25 PASS Band38 15 37825 75 #0 QAM16 2554.70 -39.07 -25 PASS Band38 15 38175 75 #0 QPSK 2635.39 -33.55 -25 PASS Band38 15 38175 75 #0 QAM16 2635.05 -33.75 -25 PASS Band38 20 37850 100 #0 QPSK 2549.85 -39.33 -25 PASS Band38 20 37850 100 #0 QAM16 2549.73 -40.38 -25 PASS Band38 20 38150 100 #0 QPSK 2640.53 -34.60 -25 PASS Band38 20 38150 100 #0 QAM16 2641.35 -35.50 -25 PASS Band4 1.4 19957 6 #0 QPSK 1709.96 -20.77 -13 PASS Band4 1.4 19957 6 #0 QAM16 1709.97 -24.59 -13 PASS Band4 1.4 203…
Text truncated - open the document above for the full version.
Test Report
Report Band4 20 20300 100 #0 QAM16 NV -30 1.90 0.001 ±2.5 PASS Band40a 10 38750 50 #0 QPSK VL NT -8.94 -0.00 4 ±2.5 PASS Band40a 10 38750 50 #0 QPSK VN NT -6.06 -0.00 3 ±2.5 PASS Band40a 10 38750 50 #0 QPSK VH NT -5.66 -0.00 2 ±2.5 PASS Band40a 10 38750 50 #0 QPSK NV 50 -6.17 -0.00 3 ±2.5 PASS Band40a 10 38750 50 #0 QPSK NV 40 -6.27 -0.00 3 ±2.5 PASS Band40a 10 38750 50 #0 QPSK NV 30 -5.00 -0.00 2 ±2.5 PASS Band40a 10 38750 50 #0 QPSK NV 20 -6.79 -0.00 3 ±2.5 PASS Band40a 10 38750 50 #0 QPSK NV 10 1.18 0.001 ±2.5 PASS Band40a 10 38750 50 #0 QPSK NV 0 1.58 0.001 ±2.5 PASS Band40a 10 38750 50 #0 QPSK NV -10 -1.85 -0.00 1 ±2.5 PASS Band40a 10 38750 50 #0 QPSK NV -20 -1.01 0.000 ±2.5 PASS Band40a 10 38750 50 #0 QPSK NV -30 -2.05 -0.00 1 ±2.5 PASS Band40a 10 38750 50 #0 QAM16 VL NT -2.93 -0.00 1 ±2.5 PASS Band40a 10 38750 50 #0 QAM16 VN NT -0.25 0.000 ±2.5 PASS Band40a 10 38750 50 #0 QAM16 VH NT 0.82 0.000 ±2.5 PASS Band40a 10 38750 50 #0 QAM16 NV 50 -0.87 0.000 ±2.5 PASS Band40a 10 38750 50 #0 QAM16 NV 40 -0.22 0.000 ±2.5 PASS Band40a 10 38750 50 #0 QAM16 NV 30 -0.41 0.000 ±2.5 PASS Band40a 10 38750 50 #0 QAM16 NV 20 -0.81 0.000 ±2.5 PASS Band40a 10 38750 50 #0 QAM16 NV 10 0.94 0.000 ±2.5 PASS Band40a 10 38750 50 #0 QAM16 NV 0 -2.17 -0.00 1 ±2.5 PASS Band40a 10 38750 50 #0 QAM16 NV -10 0.57 0.000 ±2.5 PASS Band40a 10 38750 50 #0 QAM16 NV -20 1.87 0.001 ±2.5 PASS Band40a 10 38750 50 #0 QAM16 NV -30 -1.54 -0.00 1 ±2.5 PASS Band40b 10 39200 50 #0 QPSK VL NT -8.85 -0.00 4 ±2.5 PASS Band40b 10 39200 50 #0 QPSK VN NT -5.97 -0.00 3 ±2.5 PASS Band40b 10 39200 50 #0 QPSK VH NT -6.27 -0.00 3 ±2.5 PASS Band40b 10 39200 50 #0 QPSK NV 50 -6.43 -0.00±2.5 PASS Report 3 Band40b 10 39200 50 #0 QPSK NV 40 -6.59 -0.00 3 ±2.5 PASS Band40b 10 39200 50 #0 QPSK NV 30 -4.27 -0.00 2 ±2.5 PASS Band40b 10 39200 50 #0 QPSK NV 20 -3.84 -0.00 2 ±2.5 PASS Band40b 10 39200 50 #0 QPSK NV 10 1.47 0.001 ±2.5 PASS Band40b 10 39200 50 #0 QPSK NV 0 2.68 0.001 ±2.5 PASS Band40b 10 39200 50 #0 QPSK NV -10 0.21 0.000 ±2.5 PASS Band40b 10 39200 50 #0 QPSK NV -20 2.67 0.001 ±2.5 PASS Band40b 10 39200 50 #0 QPSK NV -30 0.47 0.000 ±2.5 PASS Band40b 10 39200 50 #0 QAM16 VL NT 0.34 0.000 ±2.5 PASS Band40b 10 39200 50 #0 QAM16 VN NT 0.71 0.000 ±2.5 PASS Band40b 10 39200 50 #0 QAM16 VH NT 2.16 0.001 ±2.5 PASS Band40b 10 39200 50 #0 QAM16 NV 50 -0.80 0.000 ±2.5 PASS Band40b 10 39200 50 #0 QAM16 NV 40 1.73 0.001 ±2.5 PASS Band40b 10 39200 50 #0 QAM16 NV 30 2.84 0.001 ±2.5 PASS Band40b 10 39200 50 #0 QAM16 NV 20 0.07 0.000 ±2.5 PASS Band40b 10 39200 50 #0 QAM16 NV 10 1.95 0.001 ±2.5 PASS Band40b 10 39200 50 #0 QAM16 NV 0 3.21 0.001 ±2.5 PASS Band40b 10 39200 50 #0 QAM16 NV -10 1.83 0.001 ±2.5 PASS Band40b 10 39200 50 #0 QAM16 NV -20 1.30 0.001 ±2.5 PASS Band40b 10 39200 50 #0 QAM16 NV -30 1.73 0.001 ±2.5 PASS Band41(2535-267 5) 20 40140 100 #0 QPSK VL NT -10.75 -0.00 4 ±2.5 PASS Band41(2535-267 5) 20 40140 100 #0 QPSK VN NT -10.27 -0.00 4 ±2.5 PASS Band41(2535-267 5) 20 40140 100 #0 QPSK VH NT -7.83 -0.00 3 ±2.5 PASS Band41(2535-267 5) 20 40140 100 #0 QPSK NV 50 -10.64 -0.00 4 ±2.5 PASS Band41(2535-267 5) 20 40140 100 #0 QPSK NV 40 -7.42 -0.00 3 ±2.5 PASS Band41(2535-267 5) 20 40140 100 #0 QPSK NV 30 1.88 0.001 ±2.5 PASS Band41(2535-267 5) 20 40140 100 #0 QPSK NV 20 -2.97 -0.00 1 ±2.5 PASS Band41(2535-267 5) 20 40140 100 #0 QPSK NV 10 -1.08 0.000 ±2.5 PASS Band41(2535-267 5) 20 40140 100 #0 QPSK NV 0 -2.24 -0.00 1 ±2.5 PASS Band41(2535-267 5) 20 40140 100 #0 QPSK NV -10 -2.30 -0.00 1 ±2.5 PASS Report Band41(2535-267 5) 20 40140 100 #0 QPSK NV -20 -1.80 -0.00 1 ±2.5 P…
Text truncated - open the document above for the full version.
Contact Information
Applicant
Wenchang Liu
[email protected]Fax: 13538214502
Test Firm
Shenzhen CTB Testing Technology Co., Ltd.Rita Xiao
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 1 | 24E | 1.86 GHz - 1.90 GHz | 226.99 mW | 18M1G7D | 2.5ppm |
| 2 | 24E | 1.86 GHz - 1.90 GHz | 184.93 mW | 18M0W7D | 2.5ppm |
| 3 | 24E | 1.85 GHz - 1.91 GHz | 228.03 mW | 1M12G7D | 2.5ppm |
| 4 | 24E | 1.86 GHz - 1.90 GHz | 189.67 mW | 13M5W7D | 2.5ppm |
| 5 | 27 | 1.72 GHz - 1.75 GHz | 233.35 mW | 17M9G7D | 2.5ppm |
| 6 | 27 | 1.72 GHz - 1.75 GHz | 181.13 mW | 18M0W7D | 2.5ppm |
| 7 | 27 | 1.72 GHz - 1.75 GHz | 186.21 mW | 13M5W7D | 2.5ppm |
| 8 | 22H | 829 MHz - 844 MHz | 143.22 mW | 8M99G7D | 2.5ppm |
| 9 | 22H | 829 MHz - 844 MHz | 116.41 mW | 9M00W7D | 2.5ppm |
| 1 | 22H | 826.5 MHz - 826.5 MHz | 117.49 mW | 4M53W7D | 2.5ppm |
| 11 | 27 | 2.51 GHz - 2.56 GHz | 231.21 mW | 18M0G7D | 2.5ppm |
| 12 | 27 | 2.51 GHz - 2.56 GHz | 180.30 mW | 18M0W7D | 2.5ppm |
| 13 | 27 | 2.50 GHz - 2.57 GHz | 232.81 mW | 4M56G7D | 2.5ppm |
| 14 | 27 | 704 MHz - 711 MHz | 126.18 mW | 9M02G7D | 2.5ppm |
| 15 | 27 | 704 MHz - 711 MHz | 107.15 mW | 9M01W7D | 2.5ppm |
| 16 | 27 | 699.7 MHz - 715.3 MHz | 129.12 mW | 1M10G7D | 2.5ppm |
| 17 | 27 | 2.58 GHz - 2.61 GHz | 193.20 mW | 17M9G7D | 2.5ppm |
| 18 | 27 | 2.58 GHz - 2.61 GHz | 156.31 mW | 18M0W7D | 2.5ppm |
| 19 | 27 | 2.58 GHz - 2.61 GHz | 161.44 mW | 13M5W7D | 2.5ppm |
| 2 | 27 | 2.31 GHz - 2.31 GHz | 187.50 mW | 8M97G7D | 2.5ppm |
| 21 | 27 | 2.31 GHz - 2.31 GHz | 160.69 mW | 8M99W7D | 2.5ppm |
| 22 | 27 | 2.31 GHz - 2.31 GHz | 188.36 mW | 4M51G7D | 2.5ppm |
| 23 | 27 | 2.35 GHz - 2.35 GHz | 181.97 mW | 9M00G7D | 2.5ppm |
| 24 | 27 | 2.35 GHz - 2.35 GHz | 152.76 mW | 9M00W7D | 2.5ppm |
| 25 | 27 | 2.35 GHz - 2.36 GHz | 182.81 mW | 4M52G7D | 2.5ppm |
| 26 | 27 | 2.54 GHz - 2.67 GHz | 217.27 mW | 18M0G7D | 2.5ppm |
| 27 | 27 | 2.54 GHz - 2.67 GHz | 178.24 mW | 17M9W7D | 2.5ppm |
| 28 | 27 | 2.54 GHz - 2.67 GHz | 183.23 mW | 4M52W7D | 2.5ppm |
