© pro-micron GmbH - Alle Rechte vorbehalten. OPERATION MANUAL Software version 1.3.2791 Revision 1.0 – Issue date: February 2024 Imprint Support © Copyright pro-micron GmbH All rights reserved pro-micron GmbH Gottlieb-Daimler-Straße 6 87600 Kaufbeuren Tel: + 49 8341 9560 - 50 Fax: + 49 8341 9560 – 520 E-Mail: [email protected] Internet: www.pro-micron.de © pro-micron GmbH - Alle Rechte vorbehalten. TABLE OF CONTENTS 1 Introduction .......................................................................................................... 4 1.0 Safety notice ............................................................................................................. 5 1.1 Overall system ........................................................................................................... 6 1.2 Purpose of the system ................................................................................................ 6 1.3 target group .............................................................................................................. 6 2 installation ............................................................................................................ 7 2.1 System requirements for PC and IPC ............................................................................. 7 2.2 Installation process .................................................................................................... 8 2.2.1 Installing CodeMeter ...........................................................................................9 2.2.2 Installation of fusion ......................................................................................... 12 2.3 Main program location .............................................................................................. 15 2.4 Storage location of measurement data ......................................................................... 16 2.5 Licensing and Activation ........................................................................................... 16 3 Main functions ..................................................................................................... 19 3.1 Admin dashboard ..................................................................................................... 19 3.2 Screen display ......................................................................................................... 20 3.2.1 Overview ......................................................................................................... 20 3.2.2 Link to fusion dashboard.................................................................................... 21 3.2.3 menu .............................................................................................................. 21 3.2.4 Settings .......................................................................................................... 21 3.2.5 Features ......................................................................................................... 22 3.2.6 Live data ......................................................................................................... 23 3.2.7 history ............................................................................................................ 23 3.2.8 Advertisement ................................................................................................. 23 4 Step- by-step instructions ....................................................................................... 24 4.1 Connect a sensor ..................................................................................................... 24 4.2 Start a measurement ................................................................................................ 25 4.2.1 Start a measurement with spike®_Mobile ............................................................. 25 4.2.2 Start a measurement with spike_InSpindle ............................................................ 28 4.3 Analyze a measurement ............................................................................................ 29 4.4 Automate a measurement .......................................................................................... 31 4.4.1 Force command trigger ...................................................................................... 31 4.4.2 NC block trigger ............................................................................................... 32 4.4.3 M command trigger ........................................................................................... 33 4.4.4 Fieldbus trigger ................................................................................................ 33 Seite 3 von 67 © pro-micron GmbH - Alle Rechte vorbehalten. 4.5 Set tags and labels ................................................................................................... 34 4.6 Import measurement data .......................................................................................... 35 4.7 Export measurement data .......................................................................................... 37 4.8 spike®_map ............................................................................................................ 38 5 Parameters and self-test see .................................................................................. 39 5.1 Setting specific parameters with spike® mobile ............................................................ 39 5.2 Self-test with spike® mobile ...................................................................................... 41 5.3 Setting specific parameters with InSpindle ................................................................... 44 5.4 Self-test with InSpindle ............................................................................................. 45 5.4.1 Carry out self-test ............................................................................................ 46 5.…

Text truncated - open the document above for the full version.

Covered list attestation FCC application letter Kiwa Page 1 of 2 RF_755_02 15-02-2023 [PLACE COMPANY LOGO HERE OR PUT ON COMPANY LETTERHEAD] Certification Application Attestation Statements Pro-micron GmbH Gottlieb-Daimler-Str. 6 87600 Kaufbeuren Germany Subject: FCC ID: 2BN2JRFLX To Whom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) [pro-micron GmbH] certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) [pro-micron GmbH] (“the applicant”) certifies that, as of the date of the filing of this application, the applicant - is / - is not (3) identified on the Covered List as an entity producing “covered” equipment. Date: 14.11.2025 City: Kaufbeuren Name (2) : Michael Otto Function: Managing Director Telephone number: + 49 8341 9560 - 50 Email address: [email protected] Signature: 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . (2): For FCC it must be the Grantee Code “owner” or the authorized agent. (3): double click on the appropriate box and select ‘’checked” then “OK” Covered list attestation FCC application letter Kiwa Page 2 of 2 RF_755_02 15-02-2023 [PLACE COMPANY LOGO HERE OR PUT ON COMPANY LETTERHEAD] Revision Record Sheet: Revision Section number Page number Date Remark(s) issued by 01 07-02-2023 1 st version RvM 02 1 15-02-2023 Changed Applicant to Company and added “Subject: FCC ID: “ RvdM Issued/modified by : Richard van de Meer Function : Certification assessor Revision : 02 Date : 15-02-2023 Verified by : Willem Jan Jong Function : Team Lead Date : 16-02-2023 Released by : Axel Gase Function : Manager Quality Assurance Date of release: : 19-02-2023

Project Number: 327/24 1 Customer Manufacturer: pro-micron GmbH Street: Gottlieb-Daimler Str. 6 City: 87600 Kaufbeuren Phone: +49 8341 9560 50 Refer to: Mr Marco Lombardini 2 EQUIPMENT UNDER TEST (EUT) 2.1 EUT identification (declared under responsibility of the customer) EUT Description: WIFI Gateway Model: readFlex Code: 61000466 Serial N°: 0x0064 Software release: 69000112_connect_basic_v2.0.6088.hex Size: Ø100x40mm Manufacturer: pro-micron GmbH Supply voltage: 5Vdc USB Rated Electrical Power: 2.5 W Rated Input Current: 0.5 A EXTERNAL PHOTOGRAPHS

readFlex labeling The technical data and FCC ID label is attached to the bottom of the readFlex with a permanent sticker.

Project Number: 327/24 1 Customer Manufacturer: pro-micron GmbH Street: Gottlieb-Daimler Str. 6 City: 87600 Kaufbeuren Phone: +49 8341 9560 50 Refer to: Mr Marco Lombardini 2 EQUIPMENT UNDER TEST (EUT) 2.1 EUT identification (declared under responsibility of the customer) EUT Description: WIFI Gateway Model: readFlex Code: 61000466 Serial N°: 0x0064 Software release: 69000112_connect_basic_v2.0.6088.hex Size: Ø100x40mm Manufacturer: pro-micron GmbH Supply voltage: 5Vdc USB Rated Electrical Power: 2.5 W Rated Input Current: 0.5 A INTERNAL PHOTOGRAPHS

LAB N° 0259 L The test results in this Test Report are exclusively referred to the tested samples Without the written authorization of Kiwa Creiven, this document can be reproduced only integrally. I risultati del rapporto di prova si riferiscono esclusivamente ai campioni sotto test Senza l’autorizzazione scritta di Kiwa Creiven, questo documento può essere riprodotto solo integralmente. FORM Report – SR/RAP/01 R40_2023-09-25 Pag. 1/16 FCC Part 15B and ISED TEST REPORT Report Number 327/24/04335/FCC Rev. 00 Date of document 2024-07-18 Total number of pages Pag. 22 OBJECT FCC Part15B and ICES-003 Issue 7 and ICES-Gen Issue 1 CUSTOMER pro-micron GmbH EQUIPMENT UNDER TEST WIFI Gateway MODEL readFlex SUMMARY 1 OBJECTIVE OF THE TESTS 3 2 IDENTIFICATION 3 3 EQUIPMENT UNDER TEST (EUT) 3 4 REFERENCE STANDARDS 4 5 TEST METHODS 4 6 EUT OPERATING CONDITIONS DURING TESTS 5 7 Environmental test conditions 5 8 Test RESULT 6 9 EUT MODIFICATIONS 16 Annex B Test Instrumentations 02 pag Annex D Auxiliary Instrumentations 01 pag Annex F Judgment of compliance and measurements uncertainty 03 pag Tested by (Name + Signature) MARCO NICOLE’ Test engineer Verified by (Name + Signature) ANDREA CUPIDO Lab Manager Approved and issued by (Name + Signature) ALESSANDRO ZUCCATO Lab Director Report n° 327/24/04335/FCC LAB N° 0259 L FORM Report – SR/RAP/01 R40_2023-09-25 Pag. 2/16 History sheet of test Report Report Number Rev. Date Description of modification Report n° 327/24/04335/FCC LAB N° 0259 L FORM Report – SR/RAP/01 R40_2023-09-25 Pag. 3/16 1 OBJECTIVE OF THE TESTS The objective of the tests is the evaluation of the conformity of the EUT to the requirements of the standards and test methods specified on par. 4 & 5 of present Test Report. 2 IDENTIFICATION 2.1 Laboratory Name : Kiwa Creiven S.r.l. Street: Corso Spagna, 12 City : 35127 Padova - ITALY Phone : +39.049.8704036 Fax: +39.049.8707037 E-mail : [email protected] FCC Designation number: IT0016 ISED CAB Identifier: IT0007 2.2 Customer Manufacturer: pro-micron GmbH Street: Gottlieb-Daimler Str. 6 City: 87600 Kaufbeuren Phone: +49 8341 9560 50 Refer to: Mr Marco Lombardini 3 EQUIPMENT UNDER TEST (EUT) 3.1 EUT identification (declared under responsibility of the customer) EUT Description: WIFI Gateway Model: readFlex Code: 61000466 Serial N°: 0x0064 Software release: 69000112_connect_basic_v2.0.6088.hex Size: Ø100x40mm Manufacturer: pro-micron GmbH Supply voltage: 5Vdc USB Rated Electrical Power: 2.5 W Rated Input Current: 0.5 A 3.1.2 EUT additional information Object Descriptions Classification of installation and use Stand-alone Combined Equipment (Equipment where the radio part is fully integrated within another type of equipment) Plug-in radio device (Equipment intended for a variety of host systems) Other Means for connection to the supply: Supply cord fitted with a plug Supply cord without plug (for permanently connection to fixed wiring) Appliance inlet Appliance provided with a set of terminals allowing the connection of cables or fixed wiring Date of receipt of test item 2024-06-24 Date(s) of performance of tests See the data specified in test results details Report n° 327/24/04335/FCC LAB N° 0259 L FORM Report – SR/RAP/01 R40_2023-09-25 Pag. 4/16 3.2 EUT cables The EUT has been configured by the manufacturer with the following input / output cables: Classification Description Cable note Shielded Specified max. length DC power port d.c. input cable none ≤ 1m ≤ 3m ≤ 10m ≤ 30m type of power source: Internal Power Supply External Power Supply or AC/DC adapter Battery Other 3.3 EUT Auxiliary Equipments (AEs) To ensure the correct functioning of the EUT, it has been necessary to make use of the following auxiliary equipment (AE): Auxiliary Equipment AE01 Description : AC/DC adapter Model: S005AYB0500100 Manufacturer: I.T.E. 3.4 EUT Sampling and adopted criteria Equipment used for testing was selected by the customer. Sampling criteria adopted by the customer is unknown to Kiwa Creiven laboratory. 4 REFERENCE STANDARDS 4.1 Reference standards DOCUMENT DATE OBJECT FCC Title 47- Telecommunication part 15, subpart B 2022-10 CHAPTER I-FEDERAL COMMUNICATIONS COMMISSION PART 15--RADIO FREQUENCY DEVICES FCC part 15, subpart B, sez. 15.109 (Measurement of Radiated Emissions) FCC part 15, subpart B, sez. 15.107 (Measurement of AC power Line Conducted Emissions) ICES-003 Issue 7 Conducted limits Radiated emission limits ICES-Gen Issue 1 4.1.1 Emission summary The following table specifies the tests required by the reference standard and test performed on EUT. EUT PORT Requirement of reference standard Tested Note Results Enclosure Radiated Emissions YES --- Complies Ac. mains port AC Power Line Conducted Emissions YES --- Complies 5 TEST METHODS 5.1 Test methods DOCUMENT DATE METHOD ACCREDIA accreditation Test Sequence (See Note 1) FCC part 15, subpart B, sez. 15.109 ANSI C63.4 2022-10 Measurement of Radiated Emissions Yes 01 ICES-003 Issue 7 ICES-Gen Issue 1 FCC part 15, subpart B, sez. 15.107 ANSI C63.4 2022-10 Measurement of AC power Line Conducted Emissions Yes 02 ICES-003 Issue 7 ICES-Gen Issue 1 Note : 1) The tests have been carried out in the order specified in this column Report n° 327/24/04335/FCC LAB N° 0259 L FORM Report – SR/RAP/01 R40_2023-09-25 Pag. 5/16 5.2 Deviation from test methods None. 6 EUT OPERATING CONDITIONS DURING TESTS The EUT is set to function as indicated in Table below, in compliance with the manufacturer’s prescriptions and with that which is stated in the applied standards, test methods and procedures. OPERATING CONDITION DESCRIPTION OF FUNCTIONING DURING THE TEST OC01 EUT details : during the test the EUT • was in recharge mode (AE N°01 powered with 120V @60Hz) • AE details : during the test the Auxiliary Equipment (AE), connected to EUT, was : • EUT connected via USB to AE N°01 7 Environmental test conditions The climatic conditions during the tests are within the limits specified by the manufacturer for the operation of the EUT …

Text truncated - open the document above for the full version.

Project Number: 327/24 1 Customer Manufacturer: pro-micron GmbH Street: Gottlieb-Daimler Str. 6 City: 87600 Kaufbeuren Phone: +49 8341 9560 50 Refer to: Mr Marco Lombardini 2 EQUIPMENT UNDER TEST (EUT) 3.1 EUT identification (declared under responsibility of the customer) EUT Description: WIFI Gateway Model: readFlex Code: 61000466 Serial N°: 0x0064 Software release: 69000112_connect_basic_v2.0.6088.hex Size: Ø100x40mm Manufacturer: pro-micron GmbH Supply voltage: 5Vdc USB Rated Electrical Power: 2.5 W Rated Input Current: 0.5 A TEST SETUP PHOTOGRAPHS Test Setup – Radiated emission from 30 MHz to 1 GHz Test Setup – Radiated emission from 30 MHz to 1 GHz Test Setup – Radiated emission from 1 GHz to 12.75 GHz Test Setup – Radiated emission from 1 GHz to 12.75 GHz Test Setup – Measurement of disturbance voltage Test Setup – Measurement of disturbance voltage
