2BN2JSPK2sensory tool holders for machine tools

© pro-micron GmbH - Alle Rechte vorbehalten. OPERATION MANUAL Software version 1.3.2791 Revision 1.0 – Issue date: February 2024 Imprint Support © Copyright pro-micron GmbH All rights reserved pro-micron GmbH Gottlieb-Daimler-Straße 6 87600 Kaufbeuren Tel: + 49 8341 9560 - 50 Fax: + 49 8341 9560 – 520 E-Mail: [email protected] Internet: www.pro-micron.de © pro-micron GmbH - Alle Rechte vorbehalten. TABLE OF CONTENTS 1 Introduction .......................................................................................................... 4 1.0 Safety notice ............................................................................................................. 5 1.1 Overall system ........................................................................................................... 6 1.2 Purpose of the system ................................................................................................ 6 1.3 target group .............................................................................................................. 6 2 installation ............................................................................................................ 7 2.1 System requirements for PC and IPC ............................................................................. 7 2.2 Installation process .................................................................................................... 8 2.2.1 Installing CodeMeter ...........................................................................................9 2.2.2 Installation of fusion ......................................................................................... 12 2.3 Main program location .............................................................................................. 15 2.4 Storage location of measurement data ......................................................................... 16 2.5 Licensing and Activation ........................................................................................... 16 3 Main functions ..................................................................................................... 19 3.1 Admin dashboard ..................................................................................................... 19 3.2 Screen display ......................................................................................................... 20 3.2.1 Overview ......................................................................................................... 20 3.2.2 Link to fusion dashboard.................................................................................... 21 3.2.3 menu .............................................................................................................. 21 3.2.4 Settings .......................................................................................................... 21 3.2.5 Features ......................................................................................................... 22 3.2.6 Live data ......................................................................................................... 23 3.2.7 history ............................................................................................................ 23 3.2.8 Advertisement ................................................................................................. 23 4 Step- by-step instructions ....................................................................................... 24 4.1 Connect a sensor ..................................................................................................... 24 4.2 Start a measurement ................................................................................................ 25 4.2.1 Start a measurement with spike®_Mobile ............................................................. 25 4.2.2 Start a measurement with spike_InSpindle ............................................................ 28 4.3 Analyze a measurement ............................................................................................ 29 4.4 Automate a measurement .......................................................................................... 31 4.4.1 Force command trigger ...................................................................................... 31 4.4.2 NC block trigger ............................................................................................... 32 4.4.3 M command trigger ........................................................................................... 33 4.4.4 Fieldbus trigger ................................................................................................ 33 Seite 3 von 67 © pro-micron GmbH - Alle Rechte vorbehalten. 4.5 Set tags and labels ................................................................................................... 34 4.6 Import measurement data .......................................................................................... 35 4.7 Export measurement data .......................................................................................... 37 4.8 spike®_map ............................................................................................................ 38 5 Parameters and self-test see .................................................................................. 39 5.1 Setting specific parameters with spike® mobile ............................................................ 39 5.2 Self-test with spike® mobile ...................................................................................... 41 5.3 Setting specific parameters with InSpindle ................................................................... 44 5.4 Self-test with InSpindle ............................................................................................. 45 5.4.1 Carry out self-test ............................................................................................ 46 5.…

Text truncated - open the document above for the full version.

Covered list attestation FCC application letter Kiwa Page 1 of 2 RF_755_02 15-02-2023 [PLACE COMPANY LOGO HERE OR PUT ON COMPANY LETTERHEAD] Certification Application Attestation Statements Pro-micron GmbH Gottlieb-Daimler-Str. 6 87600 Kaufbeuren Germany Subject: FCC ID: 2BN2JSPK2 To Whom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) [pro-micron GmbH] certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) [pro-micron GmbH] (“the applicant”) certifies that, as of the date of the filing of this application, the applicant - is / - is not (3) identified on the Covered List as an entity producing “covered” equipment. Date: 14.11.2025 City: Kaufbeuren Name (2) : Michael Otto Function: Managing Director Telephone number: + 49 8341 9560 - 50 Email address: [email protected] Signature: 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . (2): For FCC it must be the Grantee Code “owner” or the authorized agent. (3): double click on the appropriate box and select ‘’checked” then “OK” Covered list attestation FCC application letter Kiwa Page 2 of 2 RF_755_02 15-02-2023 [PLACE COMPANY LOGO HERE OR PUT ON COMPANY LETTERHEAD] Revision Record Sheet: Revision Section number Page number Date Remark(s) issued by 01 07-02-2023 1 st version RvM 02 1 15-02-2023 Changed Applicant to Company and added “Subject: FCC ID: “ RvdM Issued/modified by : Richard van de Meer Function : Certification assessor Revision : 02 Date : 15-02-2023 Verified by : Willem Jan Jong Function : Team Lead Date : 16-02-2023 Released by : Axel Gase Function : Manager Quality Assurance Date of release: : 19-02-2023

FCC, Request for non-disclosure Date: 23-06-2023 RF_501, Issue 11 Page 1 of 2 Company Name: pro-micron GmbH Address: Gottlieb-Daimler-Str. 6 City: 87600 Kaufbeuren Country: Germany To: Kiwa Netherlands B.V., Dept. FCC TCB Wilmersdorf 50 7327 AC Apeldoorn The Netherlands Subject: Request for confidentiality FCC ID: 2BN2JSPK2 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, applicant hereby requests Short-Term Confidential treatment of the following materials (See notes below): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Date: 14.11.2025 Name and signature of applicant: Michael Otto Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! The planned date should state in the RF731 application form. 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Kiwa NL B.V. at least 7 days before date of actual marketing or before expiration of the STC period FCC, Request for non-disclosure Date: 23-06-2023 RF_501, Issue 11 Page 2 of 2 Revision Record Sheet: Revision Section number Page number Date Remark(s) issued by 10 1 02-01-2023 History sheet added AG 11 1 & 2 23-06-2023 Corrected date and page# WJJ Issued/modified by : Willem Jan Jong Function : Team Lead Revision : 11 Date : 23-06-2023 Verified by : Axel Gase Function : Manager Quality Assurance Date : 23-06-2023 Released by : Axel Gase Function : Manager Quality Assurance Date of release: : 23-06-2023

Project Number: KC0000555_FCC_0001 1 Customer Manufacturer: pro-micron GmbH Street: Gottlieb-Daimler Str. 6 City: 87600 Kaufbeuren Phone: +49 8341 9560 50 Refer to: Mr Marco Lombardini 2 EQUIPMENT UNDER TEST (EUT) 2.1 EUT identification (declared under responsibility of the customer) EUT Description: Transmitter Model: spike2 Code: 42000808 Serial N°: 0xA4CC; 0xA4CD; 0xA4CE; 0xA4CF Software release: WEPO41120A00_sha256.hex Size: Ø63x136mm Manufacturer: pro-micron GmbH Supply voltage: 5V USB loaded / battery inside Rated Electrical Power: 2.5 W Rated Input Current: 0.5 A FCC ID: 2BN2JSPK2 EXTERNAL PHOTOGRAPHS

Y| The labeling of the technical data and the FCC ID is applied to the circumference of the spike2 with a laser marking. spike2 labeling

Project Number: KC0000555_FCC_0001 1 Customer Manufacturer: pro-micron GmbH Street: Gottlieb-Daimler Str. 6 City: 87600 Kaufbeuren Phone: +49 8341 9560 50 Refer to: Mr Marco Lombardini 2 EQUIPMENT UNDER TEST (EUT) 2.1 EUT identification (declared under responsibility of the customer) EUT Description: Transmitter Model: spike2 Code: 42000808 Serial N°: 0xA4CC; 0xA4CD; 0xA4CE; 0xA4CF Software release: WEPO41120A00_sha256.hex Size: Ø63x136mm Manufacturer: pro-micron GmbH Supply voltage: 5V USB loaded / battery inside Rated Electrical Power: 2.5 W Rated Input Current: 0.5 A FCC ID: 2BN2JSPK2 INTERNAL PHOTOGRAPHS

00233 The test results in this Test Report are exclusively referred to the tested samples as received by the customer; Without the written authorization of Kiwa Cermet Italia S.p.A.., this document can be reproduced only integrally. I risultati di test si riferiscono esclusivamente ai campioni testati così come ricevuti dal cliente; Senza l’autorizzazione scritta di Kiwa Cermet Italia S.p.A., questo documento può essere riprodotto solo integralmente. FORM Report – SR/RAP/168 R03 del 11/12/2025 Pag. 1/18 TEST REPORT nr. KC0000555_FCC_0001 R00 Testing Location Kiwa Cermet Italia S.p.A. Corso Spagna, 12 35127 Padova – Italy Customer pro-micron GmbH Issuing date 2026-02-10 Project nr. KC0000555 Test sample description Transmitter Model Spike2 Id sample 0xA4CC; 0xA4CD; 0xA4CE; 0xA4CF Method / Reference standard See par. 4 Tested by Marco Nicolè (Test Engineer) Verified and Approved by Andrea Cupido (Lab manager) Remarks: This report may only be reproduced in full, while partial reproduction must be explicitly authorized by the Laboratory. Test results relate only to the sample/s tested as received. Kiwa Cermet Italia S.p.A. – Single-member company subject to management and coordination by Kiwa Italia Holding S.r.l. - NB 0476Headquarters: Via Cadriano 23, 40057 - Granarolo dell’Emilia (BO), Italy – Registered at the Chamber of Commerce of Bologna with registration number and Fiscal code: 03502820370, REA: BO-295316, VAT n. 00627711203 - Share capital: € 1.000.000,00 paid-upTel. +39.051.4593.111 - Fax +39.051.763.382 – [email protected] - PEC: [email protected] - www.kiwa.it Report n° KC0000555_FCC_0001 00233 FORM Report – SR/RAP/168 R03 del 11/12/2025 Pag. 2/18 History sheet of test Report Report Number Rev. Date Description of modification -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- Report n° KC0000555_FCC_0001 00233 FORM Report – SR/RAP/168 R03 del 11/12/2025 Pag. 3/18 Total number of pages Pag. 22 OBJECT FCC Part15C and ISED RSS-247 Issue 4 SUMMARY 1 OBJECT OF THE TESTS 4 2 IDENTIFICATION 4 3 EQUIPMENT UNDER TEST (EUT) 4 4 STANDARDS AND TEST METHODS 5 5 EUT OPERATING CONDITIONS DURING TESTS 7 6 TEST RESULTS 8 7 EUT MODIFICATIONS 17 Annex B Test Instrumentations 02 pag Annex D Auxiliary Instrumentations 01 pag Annex F Judgment of compliance and measurements uncertainty 01 pag Report n° KC0000555_FCC_0001 00233 FORM Report – SR/RAP/168 R03 del 11/12/2025 Pag. 4/18 1 OBJECT OF THE TESTS The objective of the tests is the evaluation of the conformity of the EUT to the requirements of the standards and test methods specified on par. 4 of present Test Report. 2 IDENTIFICATION 2.1 Laboratory Name : Kiwa Cermet Italia S.p.A. Street: Corso Spagna, 12 City : 35127 Padova - ITALY Phone : +39 0514593111 www.Kiwa.com FCC Designation number: IT0016 ISED CAB Identifier: IT0007 2.2 Customer Manufacturer: pro-micron GmbH Street: Gottlieb-Daimler Str. 6 City: 87600 Kaufbeuren - Germany Phone: +49 8341 9560 50 Refer to: Mr Marco Lombardini 3 EQUIPMENT UNDER TEST (EUT) 3.1 EUT identification (declared under responsibility of the customer) EUT Description: Transmitter Model: spike2 Code: 42000808 Serial N°: 0xA4CC; 0xA4CD; 0xA4CE; 0xA4CF Software release: WEPO41120A00_sha256.hex Size: Ø63x136mm Manufacturer: pro-micron GmbH Supply voltage: 5V USB loaded / battery inside Rated Electrical Power: 2.5 W Rated Input Current: 0.5 A FCC ID: 2BN2JSPK2 3.2 EUT classifications The manufacture declared the following classification: Object Descriptions Operating frequency range 2405 – 2480 MHz Equipment type IEEE 802.15.4 (ZigBee) Modulation O-QPSK Nominal Channel Bandwidth 2 MHz Frequency Hopping Spread Spectrum NO Listen Before Talk NO Adaptive NO Number of Channels 16 Antenna Type Integrated antenna Extreme Temperature Range -10°C ÷ +60°C Report n° KC0000555_FCC_0001 00233 FORM Report – SR/RAP/168 R03 del 11/12/2025 Pag. 5/18 3.3 EUT additional information Object Descriptions Classification of installation and use Stand-alone Combined Equipment (Equipment where the radio part is fully integrated within another type of equipment) Plug-in radio device (Equipment intended for a variety of host systems) Other Means for connection to the supply: Supply cord fitted with a plug Supply cord without plug (for permanently connection to fixed wiring) Battery Appliance provided with a set of terminals allowing the connection of cables or fixed wiring Date of receipt of test item 2026-01-12 Date(s) of performance of tests See the data specified in test results details 3.4 EUT cables The EUT has been configured by the manufacturer with the following input / output cables: Classification Description Cable note Shielded Specified max. length DC power port (used only for the recharge) d.c. input cable none ≤ 1m ≤ 3m ≤ 10m ≤ 30m type of power source: Internal Power Supply External Power Supply or AC/DC adapter Battery Other 3.5 EUT Auxiliary Equipments (AEs) To ensure the correct functioning of the EUT, it has been necessary to make use of the following auxiliary equipment (AE): Auxiliary Equipment AE N°01 Description: Laptop Model: L13 Yoga Manufacturer: THINKPAD Auxiliary Equipment AE N°02 Description: Receiver Model: readFlex Manufacturer: pro-micron GmbH 3.6 Sampling and adopted criteria Equipment used for testing was selected by the customer. Sampling criteria adopted by the customer is unknown to Kiwa Cermet Italia S.p.A. laboratory that is not liable for that. 3.7 EUT documents The following documentations have been provided by the customer Descriptions Annex E customer’s declaration 4 STANDARDS AND TEST METHODS 4.1 Reference standards DOCUMENT DATE OBJECT ANSI C63.10 2020 American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Devices ANSI C63.10 Cor.1 2023 Report n° KC0000555_FCC_0001 00233 FORM Report – SR/RAP/168 R03 del 11/12/2025 Pag. 6/18 4.1.1 Test summary The following table specifies the tests required by the reference standard and test performed on EUT. TEST FCC Rule ISED Rule Note…

Text truncated - open the document above for the full version.

LAB N° 0259 L The test results in this Test Report are exclusively referred to the tested samples Without the written authorization of Kiwa Creiven, this document can be reproduced only integrally. I risultati del rapporto di prova si riferiscono esclusivamente ai campioni sotto test Senza l’autorizzazione scritta di Kiwa Creiven, questo documento può essere riprodotto solo integralmente. FORM Report – SR/RAP/01 R39_2021-07-23 Pag. 1/8 FCC Part 1.1310, 2,1091 and ISED TEST REPORT Report Number 326/24/04412/FCC Rev. 00 Date of document 2024-09-18 Total number of pages Pag. 8 OBJECT Compliance to FCC Part 1.1310, 2,1091 and ISED RSS-102 Issue 6 CUSTOMER pro-micron GmbH EQUIPMENT UNDER TEST transmitter MODEL spike2 SUMMARY 1 OBJECT OF THE TESTS 3 2 IDENTIFICATION 3 3 EQUIPMENT UNDER TEST (EUT) 3 4 REFERENCE STANDARDS 4 5 Test method & Test RESULT – MPE Requirements 5 Verified by (Name + Signature) ANDREA CUPIDO Lab Manager Approved and issued by (Name + Signature) ALESSANDRO ZUCCATO Lab Director Report n° 326/24/04412/FCC LAB N° 0259 L FORM Report – SR/RAP/01 R39_2021-07-23 Pag. 2/8 History sheet of test Report Report Number Rev. Date Description of modification -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- Report n° 326/24/04412/FCC LAB N° 0259 L FORM Report – SR/RAP/01 R39_2021-07-23 Pag. 3/8 1 OBJECT OF THE TESTS The objective of the tests is prepared, in accordance with FCC Part 1.1310, 2,1091 and ISED RSS-102 Issue 6 , to evaluate RF exposure compliance of radiocommunication apparatus. 2 IDENTIFICATION 2.1 Laboratory Name : Kiwa Creiven S.r.l. Street: Corso Spagna, 12 City : 35127 Padova - ITALY Phone : +39.049.8704036 Fax: +39.049.8707037 E-mail : [email protected] FCC Designation number: IT0016 ISED CAB Identifier: IT0007 2.2 Customer Manufacturer: pro-micron GmbH Street: Gottlieb-Daimler Str. 6 City: 87600 Kaufbeuren Phone: +49 8341 9560 50 Refer to: Mr Marco Lombardini 3 EQUIPMENT UNDER TEST (EUT) 3.1 EUT identification (declared under responsibility of the customer) EUT Description: transmitter Model: spike2 Code: 42000808 Serial N°: 0xA4CC; 0xA4CD; 0xA4CE; 0xA4CF Software release: WEPO41120A00_sha256.hex Size: Ø63x136mm Manufacturer: pro-micron GmbH Supply voltage: 5V USB loaded / battery inside Frequency: 2,4 GHz (ZigBee) Rated Electrical Power: 2,5W Rated Input Current: 0,5A 3.1.1 EUT classifications The manufacturer declared the following classification: Object Descriptions Operating frequency range 2400 – 2484 MHz Equipment type ZigBee (IEEE 802.15.4) Nominal Channel Bandwidth 162 MHz Frequency Hopping Spread Spectrum NO Listen Before Talk NO Adaptive NO Number of Channels 16 (CH11 – 26) Antenna Type Integrated antenna Extreme Temperature Range -10°C ÷ 60°C Report n° 326/24/04412/FCC LAB N° 0259 L FORM Report – SR/RAP/01 R39_2021-07-23 Pag. 4/8 3.1.2 EUT additional information Object Descriptions Classification of installation and use Stand-alone Combined Equipment (Equipment where the radio part is fully integrated within another type of equipment) Plug-in radio device (Equipment intended for a variety of host systems) Other Means for connection to the supply: Supply cord fitted with a plug Supply cord without plug (for permanently connection to fixed wiring) Appliance inlet Appliance provided with a set of terminals allowing the connection of cables or fixed wiring Date of receipt of test item 2024-06-24 Date(s) of performance of tests See the data specified in test results details 3.2 EUT cables Classification Description Cable note Shielded Specified max. length DC power port (used only for the recharge) d.c. input cable none ≤ 1m ≤ 3m ≤ 10m ≤ 30m type of power source: Internal Power Supply External Power Supply or AC/DC adapter Battery Other 3.3 EUT Auxiliary Equipments (AEs) To ensure the correct functioning of the EUT, it has been necessary to make use of the following auxiliary equipment (AE): Auxiliary Equipment AE01 Description : AC/DC adapter Model: S005AYB0500100 Manufacturer: I.T.E. 3.4 EUT Sampling and adopted criteria Equipment used for testing was selected by the customer. Sampling criteria adopted by the customer is unknown to Kiwa Creiven laboratory. 3.5 EUT documents The following documentations have been provide by the customer Kiwa Creiven document reference Descriptions 326/24/04320/FCC Reference test report 4 REFERENCE STANDARDS 4.1 Reference standards DOCUMENT OBJECT FCC CFR47 Rule Parts 1.1310, 2,1091 ISED Rule RSS-102 Issue 6 Report n° 326/24/04412/FCC LAB N° 0259 L FORM Report – SR/RAP/01 R39_2021-07-23 Pag. 5/8 5 TEST METHOD & TEST RESULT – MPE REQUIREMENTS 5.1 FCC MPE Requirements The FCC MPE limits from CFR 47 Part 1.1310, 2,1091 are shown in the table below. Report n° 326/24/04412/FCC LAB N° 0259 L FORM Report – SR/RAP/01 R39_2021-07-23 Pag. 6/8 5.2 ISED MPE Requirements The ISED MPE limits from RSS-102 Issue 6 are shown in the table below. Remark: If the operating frequency of the device is between two frequencies located in Table, linear interpolation is applied for the applicable separation distance. Report n° 326/24/04412/FCC LAB N° 0259 L FORM Report – SR/RAP/01 R39_2021-07-23 Pag. 7/8 5.3 Calculation FCC ISED Report n° 326/24/04412/FCC LAB N° 0259 L FORM Report – SR/RAP/01 R39_2021-07-23 Pag. 8/8 5.3 Test result FCC RF Exposure RF Mode Frequency Evaluation Distance Antenna Gain Duty Cycle EIRP EIRP Power density Limit for uncontrolled Exposure Distance require to meet uncontrolled Exposure Limit Result MHz (cm) (dBi) (%) (dBm) (W) (mW/cm 2 ) (mW/cm 2 ) (cm) ZigBee (IEEE 802.15.4) 2400-2484 20 4 100 3,61 0,0023 0.00115 1 20 Pass ISED RF Exposure RF Mode Frequency Evaluation Distance Antenna Gain Duty Cycle EIRP EIRP Power density Limit for uncontrolled Exposure Distance require to meet uncontrolled Exposure Limit Result MHz (cm) (dBi) (%) (dBm) (W) (W/m2) (W/m2) (cm) ZigBee (IEEE 802.15.4) 2400-2484 20 4 100 3,61 0,0023 0.0115 5,35 20 Pass PASS= SAR evaluation is not required because the output power value is less than exemption limit…

Text truncated - open the document above for the full version.

LAB N° 0259 L The test results in this Test Report are exclusively referred to the tested samples Without the written authorization of Kiwa Creiven, this document can be reproduced only integrally. I risultati del rapporto di prova si riferiscono esclusivamente ai campioni sotto test Senza l’autorizzazione scritta di Kiwa Creiven, questo documento può essere riprodotto solo integralmente. FORM Report – SR/RAP/168 R00 del 17/06/2021 Pag. 1/24 FCC Part 15C and ISED TEST REPORT Report Number 326/24/04320/FCC Rev. 01 Date of document 2025-08-29 Total number of pages Pag. 30 OBJECT FCC Part15C and ISED RSS-247 Issue 3 CUSTOMER pro-micron GmbH EQUIPMENT UNDER TEST - DESCRIPTION transmitter MODEL spike2 SUMMARY 1 OBJECT OF THE TESTS 3 2 IDENTIFICATION 3 3 EQUIPMENT UNDER TEST (EUT) 3 4 STANDARDS AND TEST METHODS 4 5 EUT OPERATING CONDITIONS DURING TESTS 5 6 TEST RESULTS 6 7 EUT MODIFICATIONS 23 Annex B Test Instrumentations 02 pag Annex D Auxiliary Instrumentations 01 pag Annex F Judgment of compliance and measurements uncertainty 03 pag Tested by (Name + Signature) MARCO NICOLE’ Test engineer Verified by (Name + Signature) ANDREA CUPIDO Lab Manager Approved and issued by (Name + Signature) ALESSANDRO ZUCCATO Lab Director Code 326/24/04320/FCC R01 LAB N° 0259 L FORM Report – SR/RAP/168 R00 del 17/06/2021 Pag. 2/24 History sheet of test Report Report Number Rev. Date Description of modification 326/24/04320/FCC 00 2024-07-17 Initial Issue 326/24/04320/FCC 01 2025-08-29 This document replaces and revokes Kiwa Creiven document number 326/24/04320/FCC: Correction of information at paragraph 3.2. -- -- -- -- -- -- -- -- Code 326/24/04320/FCC R01 LAB N° 0259 L FORM Report – SR/RAP/168 R00 del 17/06/2021 Pag. 3/24 1 OBJECT OF THE TESTS The objective of the tests is the evaluation of the conformity of the EUT to the requirements of the standards and test methods specified on par. 4 of present Test Report. 2 IDENTIFICATION 2.1 Laboratory Name : Kiwa Creiven S.r.l. Street: Corso Spagna, 12 City : 35127 Padova - ITALY Phone : +39.049.8704036 Fax: +39.049.8707037 E-mail :[email protected] FCC Designation number: IT0016 ISED CAB Identifier: IT0007 2.2 Customer Manufacturer: pro-micron GmbH Street: Gottlieb-Daimler Str. 6 City: 87600 Kaufbeuren Phone: +49 8341 9560 50 Refer to: Mr Marco Lombardini 3 EQUIPMENT UNDER TEST (EUT) 3.1 EUT identification (declared under responsibility of the customer) EUT Description: transmitter Model: spike2 Code: 42000808 Serial N°: 0xA4CC; 0xA4CD; 0xA4CE; 0xA4CF Software release: WEPO41120A00_sha256.hex Size: Ø63x136mm Manufacturer: pro-micron GmbH Supply voltage: 5V USB loaded / battery inside Frequency: 2,4 GHz (ZigBee) Rated Electrical Power: 2,5W Rated Input Current: 0,5A 3.2 EUT classifications The manufacture declared the following classification: Object Descriptions Operating frequency range 2405 MHz – 2480 MHz Equipment type IEEE 802.15.4 (ZigBee) Nominal Channel Bandwidth 2 MHz Modulation O-QPSK Frequency Hopping Spread Spectrum NO Listen Before Talk NO Adaptive NO Number of Channels16 Antenna Type Integrated antenna Extreme Temperature Range -10°C ÷ 60°C Code 326/24/04320/FCC R01 LAB N° 0259 L FORM Report – SR/RAP/168 R00 del 17/06/2021 Pag. 4/24 3.3 EUT additional information Object Descriptions Classification of installation and use Stand-alone Combined Equipment (Equipment where the radio part is fully integrated within another type of equipment) Plug-in radio device (Equipment intended for a variety of host systems) Other Means for connection to the supply: Supply cord fitted with a plug Supply cord without plug (for permanently connection to fixed wiring) Appliance inlet Appliance provided with a set of terminals allowing the connection of cables or fixed wiring Date of receipt of test item 2024-06-24 Date(s) of performance of tests See the data specified in test results details 3.3 EUT cables The EUT has been configured by the manufacturer with the following input / output cables: Classification Description Cable note Shielded Specified max. length DC power port (used only for the recharge) d.c. input cable none ≤ 1m ≤ 3m ≤ 10m ≤ 30m type of power source: Internal Power Supply External Power Supply or AC/DC adapter Battery Other 3.5 EUT Auxiliary Equipments (AEs) To ensure the correct functioning of the EUT, it has been necessary to make use of the following auxiliary equipment (AE): Auxiliary Equipment AE01 Description : AC/DC adapter Model: S005AYB0500100 Manufacturer: I.T.E. 3.6 Sampling and adopted criteria Equipment used for testing was selected by the customer. Sampling criteria adopted by the customer is unknown to Kiwa Creiven laboratory. 3.7 EUT documents The following documentations have been provided by the customer Kiwa Creiven document reference Descriptions Annex E _04290LP Annex E customer’s declaration 4 STANDARDS AND TEST METHODS 4.1 Reference standards DOCUMENT DATE OBJECT ANSI C63.10 2013 American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Devices 4.1.1 Test summary The following table specifies the tests required by the reference standard and test performed on EUT. TEST FCC Rule ISED Rule Note Results Channel Separation §15.247 (a)(1) RSS-247 Issue 3 Not tested as required by the customer --- Minimum Hopping Channel §15.247 (a)(1)(iii) RSS-247 Issue 3 Not tested as required by the customer --- 6 dB (DTS) & 20 dB Bandwidth & 99% of power §15.247 (a)(2) §15.215 (c) RSS-247 Issue 3 Not tested as required by the customer --- Code 326/24/04320/FCC R01 LAB N° 0259 L FORM Report – SR/RAP/168 R00 del 17/06/2021 Pa…

Text truncated - open the document above for the full version.
