FCC §15.247 (i), §2.1091 – RF Exposure FCC ID: 2BNGM-JOY-W006 Applied procedures / limit According to FCC §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Note: ƒ is frequency in MHz * = Power density limit is applicable at frequencies greater than 100 MHz Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density MPE PREDICTION Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna,R=20cm Test Result of RF Exposure Evaluation Modes& Channel Freq. (MHz) Tune up Produce power Maximu m peak output power (dBm) Output power to antenna (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm2) Limit (mW / cm2 ) Result BT-EDR 8DPSK&M CH 3±1 4 2.5119 1.6181 (2.09dBi) 0.00081 1 Pass

Page - 1 - APPROVAL SHEET FOR BT （ PCB antenna） Issued byChecked by Confirmed byDate2024-10-28 Customer Confirm Page - 2 - Revision History DateRevisionDescription of Changes 2024-10-28R:AAntenna performance approved by customer 1 SUMMARY 2 GENERAL DESCRIPTION 2.1 Definitions 3 MECHANICAL DESCRIPTION 4 ELECTRICAL PERFORMANCE 4.1 Set-up 4.1.1 VSWR and return loss 4.1.2 Efficiency, Gain and TRP/TIS 4.1.3 Matching Circuit Description 4.2 Measurement Data 4.2.1 VSWR 4.2.2 Active result 5 MECHANICAL DRAWING 6 CONCLUSION Page 3 - 1 Summary This report summarizes the electrical results of the proposed antenna to support the BT program. We test the antenna with the latest version handset . 2 General Description 2.1 Definitions VSWR: Voltage Standing Wave Rate 3 Mechanical Description 4 Electrical Performance 4.1 Set-up 4.1.1 VSWR and return loss VSWR measurements (S 11 ) were performed using an Agilent E5070B Network Analyzer and the previously described test fixture. Coaxial chokes were used to mitigate surface currents on the outside of the cabling. The testing was performed in free space. 4.1.2 Efficiency, Gain and TRP/TIS The gain of the antenna was measured in Dong Xin’s 3D anechoic chamber in Shenzhen. The chamber is capable of doing tests from 380MHz to 6GHz. Coaxial chokes on the feed cable were used to mitigate surface currents. The measurement results are calibrated using dipole standards. For TRP and TIS the chamber uses a Agilent 8960 to establish the connection with the mobile device. During TRP tests the 8960 reads the power received through the chamber probes whilst during TIS tests the 8960 transmits through the probe. All data is afterwards corrected by a calibration table. 4.1.3 Antenna object This report summarizes the electrical performance results of the proposed Internal antenna to support the F12（BT） program. The antenna is an assembly BT 2.4G. Page 4 - 4.2 Measurement Data Test Point IDFreq. (MHz)Gain (dBi)Directivity (dBi)Efficiency (%) 12400.0-0.912.4611.0% 22410.0-0.432.8011.0% 32420.0-0.273.0411.4% 42430.0-0.122.9911.9% 52440.00.723.2411.9% 62450.00.902.6111.9% 72460.01.273.4511.7% 82470.01.462.2112.1% 92480.02.092.4312.5% 102490.02.142.3712.8% 112500.02.374.2012.3% Page 5 - ANTENNA SPECIFICATION0

Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 53 TEST REPORT Compiled by: Reviewed by: Approved by: Zhou Kui Arron Liu Bin Mei / Director Note: If there is any objection to the inspection results in this report, please submit a written report to the company within 15 days from the date of receiving the report. The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen CTB Testing Technology Co., Ltd. this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. “*” indicates the testing items were fulfilled by subcontracted lab. “#” indicates the items are not in CNAS accreditation scope. Product Name: Car Stereo FCC ID: 2BNGM-JOY-W006 Trademark: Model Number: JOY-W006, JOY-W008, JOY-W022, JOY-W018, JOY-W019 Prepared For: shenzhenshihekexindianzikejiyouxiangongsi Address: shen zhen shi bao an qu xi xiang jie dao qian jin er lu chen tian she qu 4 hao lou feng heng yuan 1 dan yuan liu ceng A2 shi ban gong chang suo Manufacturer: shenzhenshihekexindianzikejiyouxiangongsi Address: shen zhen shi bao an qu xi xiang jie dao qian jin er lu chen tian she qu 4 hao lou feng heng yuan 1 dan yuan liu ceng A2 shi ban gong chang suo Prepared By: Shenzhen CTB Testing Technology Co., Ltd. Address: 1&2/F., Building A, No.26, Xinhe Road, Xinqiao, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: Dec. 09, 2025 Sample tested Date: Dec. 09, 2025 to Dec. 13, 2025 Issue Date: Dec. 13, 2025 Report No.: CTB25010906101RF01 Test Standards FCC CFR Title 47 Part 15 Subpart C Section 15.247 ANSI C63.10:2013 Test Results PASS Remark: This is Bluetooth radio test report. Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB25010906101RF01 Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 53 TABLE OF CONTENT Test Report Declaration Page 1. VERSION ........................................................................................................................................ 4 2. TEST SUMMARY ........................................................................................................................... 5 3. MEASUREMENT UNCERTAINTY ................................................................................................. 6 4. PRODUCT INFORMATION AND TEST SETUP ............................................................................ 7 4.1 Product Information .......................................................................................................................... 7 4.2 Test Setup Configuration .................................................................................................................. 7 4.3 Support Equipment........................................................................................................................... 7 4.4 Channel List ..................................................................................................................................... 8 4.5 Test Mode ........................................................................................................................................ 8 4.6 Test Environment ............................................................................................................................. 8 5. TEST FACILITY AND TEST INSTRUMENT USED ....................................................................... 9 5.1 Test Facility ...................................................................................................................................... 9 5.2 Test Instrument Used ....................................................................................................................... 9 6. AC POWER LINE CONDUCTED EMISSION ................................................................................ 11 6.1 Block Diagram Of Test Setup ......................................................................................................... 11 6.2 Limit ................................................................................................................................................ 11 6.3 Test procedure ............................................................................................................................... 11 6.4 Test Result ..................................................................................................................................... 13 7. RADIATED SPURIOUS EMISSION ............................................................................................. 14 7.1 Block Diagram Of Test Setup ......................................................................................................... 14 7.2 Limit ................................................................................................................................................ 14 7.3 Test procedure ............................................................................................................................... 15 7.4 Test Result ..................................................................................................................................... 16 8. BAND EDGE AND RF COUNDUCTED SPURIOUS EMISSIONS ............................................... 25 8.1 Block Diagram Of Test Setup ......................................................................................................... 25 8.2 Limit ................................................................................................................................................ 25 8.3 Test procedure ............................................................................................................................... 25 8.4 Test Result ..................................................................................................................................... 26 9. COUD…
