edgeRX Pro rev.1 Copyright © TDK SensEI; All Rights Reserved ►1 User Manual edgeRX Pro Model: SE3116308G-01 Edge AI Multi-Sensor Node for Advanced Condition Monitoring Before using this product, please read this user manual carefully and keep it in a safe place for future reference. edgeRX Pro rev.1 Copyright © TDK SensEI; All Rights Reserved ►2 Contents 1. SAFETY INFORMATION ............................................................................... 3 2. REGULATORY COMPLIANCE ....................................................................... 5 3. PRODUCT OVERVIEW .................................................................................. 7 4. SYSTEM ARCHITECTURE ............................................................................. 8 5. PARTS DESCRIPTION ................................................................................. 10 6. INSTALLATION GUIDE ............................................................................... 13 7. POWER & BATTERY HANDLING ................................................................ 15 8. COMMUNICATION & CONNECTIVITY ...................................................... 17 9. OPERATING BEHAVIOR ............................................................................. 19 10. BUTTON OPERATION ................................................................................ 21 11. LED STATUS ................................................................................................ 23 12. MAINTENANCE & DISPOSAL .................................................................... 25 13. SPECIFICATIONS ........................................................................................ 28 14. OUTLINE DIMENSIONS ............................................................................. 29 15. TROUBLESHOOTING ................................................................................. 30 16. LEGAL & DISCLAIMER ............................................................................... 32 17. SERVICE CONTACT ..................................................................................... 34 18. COMPANY INFORMATION ........................................................................ 34 19. Revision History ......................................................................................... 35 edgeRX Pro rev.1 Copyright © TDK SensEI; All Rights Reserved ►3 1. SAFETY INFORMATION Please read this section carefully before using the product. 1.1. WARNING Failure to follow these instructions may result in serious injury, fire, explosion, or device damage.  This product contains a built-in lithium battery. Do not recharge, disassemble, crush, puncture, incinerate, or expose the product to fire.  Do not expose the product to water, open flames, or temperatures above 85°C.  Do not expose the product to extremely low-pressure environments that may cause battery rupture.  Do not short-circuit battery terminals.  Do not modify, repair, or disassemble the product yourself. Contact authorized service personnel for support.  If the product becomes deformed, abnormally hot, emits smoke, unusual odor, or shows any abnormal condition, immediately stop using it and contact after-sales service.  If battery leakage occurs and comes into contact with skin or eyes, rinse immediately with clean water and seek medical attention.  Do not use this product in environments containing explosive, flammable, or corrosive gases.  Do not expose the product to magnetic fields beyond the specified range.  Keep this product out of reach of children and infants. 1.2. CAUTION The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Failure to follow these instructions may result in minor injury or product malfunction.  Operate and store this product within the specified temperature range.  Avoid prolonged exposure to high humidity, condensation, direct sunlight, or rapid temperature changes.  Do not drop, strike, or apply excessive force to the product or its connectors.  Do not install or use any unit that has been dropped, as internal damage may not be visible. Safety and performance of dropped units are not guaranteed.  Do not open the enclosure or remove screws during operation.  The battery may only be replaced by authorized service personnel.  Use only manufacturer-approved accessories and cables. Use of non-approved accessories may void warranty and violate local regulations.  When powered via USB or AC adapter, use certified power supplies that comply with applicable safety standards.  The external connector is not waterproof unless a cable or protective cap is properly attached.  Secure the product using M6 screws with the specified tightening torque. Improper installation may result in device malfunction or detachment. edgeRX Pro rev.1 Copyright © TDK SensEI; All Rights Reserved ►4 1.3. RF AND WIRELESS SAFETY  Do not use wireless communication in locations where radio equipment is prohibited (e.g., aircraft or hospitals).  Maintain at least 20 cm distance between this product and implantable medical devices such as pacemakers.  This product operates in the 2.4 GHz ISM band, which is also used by Wi-Fi, microwave ovens, and other industrial, scientific, and medical devices.  Wireless performance may be affected by radio interference, installation location, or environmental conditions. 1.4. INSTALLATION AND USAGE PRECAUTIONS  This product is designed for industrial condition monitoring applications. It is not intended for consumer use.  Install only on compatible machinery. Contact technical support for compatibility confirmation.  Deployment location and mounting method directly affect measurement accuracy.  Do not relocate or reinstall the device without proper evaluation.  Avoid installation in environments with heavy oil exposure, organic solvents, strong acids, strong …
