WG-06Airpurifier Thankyouforpurchasingourcompany'sproducts Pleasereadtheusermanualcarefullybeforeuse Pleasekeeptheinstructionmanualproperly Productparameters ： ProductName:AirPurifier Productmodel:WG-06 Productmaterial:ABS/pp/filterelement/circuitboard Voltageused:d.c5v Currentusage:2A Productsize:160*160*260mm Plasma:-4kv±0.5kv Ozoneconcentration:<0.05PPM Executionstandards:GB/T18801-2008QB/T4982-2016 ProductIntroduction WG-06airpurifierisasmallairpurifiersuitableforofficeandhome scenarios;Theproductadoptsatransparentdesignstyleandfeaturescool ambientnightlights;Althoughtheproductissmallinsize,ithaslargeair circulationbladesandstrongwindpower,whichcaneffectivelyabsorb pethair,filterPM2.5particlesandvirusesandbacteriaintheair;The producthasahigh-precisioninfraredsensorthatcanmonitortheair qualityinthehomeinrealtimeanddisplayitclearlythroughnumerical andlightingforms;Remotecontrolcanbeachievedthroughamobileapp, allowingyoutoconstantlymonitortheairqualityathome. IntroductiontoKeyFunctions Basicversion Displayscreenshows:gear,timing,filterusagetime; *Turnonthepower,thepowerbuttonflashes,clickthepowerbutton,themachinestartsup,and thedefaultfanisingear1; *Thereare5gearsavailableforadjustment,rangingfrom1to5; *Clickonsleepmodetoentersleepmode; *Thereare12modesforambientlighting.Inanymodeofambientlighting,longpressthe ambientlightingbuttontoturnofftheambientlighting; *Longpressthefanbuttontocheckthefilterusagetime; *Themachinehasbeeninusefor2000hours,andthefilterreplacementreminderlightison. Pressandholdthesleepmode,resetthefilterusagetime,andrestartthetimer; *Thereare6typesoftimingavailable,including2-4-6-8-10-12h; *Longpressthechildlockbuttontoactivatethechildlock,andthenlongpressthechildlock buttonagaintodeactivatethechildlock; *Gearindicatorlight,therotationspeedchangesaccordingtothegearposition; Upgradedversion/WiFiversion Displayscreenshows:gearposition,PM2.5value,timingtime,filterusagetime; *Connectthepower,thepowerbuttonflashes,clickthepowerbutton,themachinestartsup,the defaultfanisinautomaticmode,andthefanspeedchangeswiththeairquality; *Thereare5manualgearsavailableforadjustment,rangingfrom1to5; *Clickonsleepmodetoentersleepmode; Atmospherelight Sleepmode plasma WiFi display Fangear Bootkey Childlock Replacethefilterelement UV timing Gearindicatorlight *Thereare12modesforambientlighting.Inanymodeofambientlighting,longpressthe ambientlightingbuttontoturnofftheambientlighting; *Longpressthefanbuttontocheckthefilterusagetime; *Themachinehasbeeninusefor2000hours,andthefilterreplacementreminderlightison. Pressandholdthesleepmode,resetthefilterusagetime,andrestartthetimer; *Thereare6typesoftimingavailable,including2-4-6-8-10-12h; *ThedefaultdisplayscreenshowsthePM2.5value.Longpressthetimerbuttontocheckthe timertime; *Longpressthechildlockbuttontoactivatethechildlock,andthenlongpressthechildlock buttonagaintodeactivatethechildlock; *Gearindicatorlightspeed:changesaccordingtothespeedofthegearfan; *Gearindicatorlightcolors:greenforgoodairquality,yellowforgoodairquality,andredfor poorairquality; *Plasma:automaticallyturnsonwhenturnedon,automaticallyturnsoffwhenturnedoff; *UV:Afterturningon,pressandholdthepowerbuttontoturniton,andpressandholdthepower buttontoturnitoff; *Doubleclickthechildlockbuttontoenterthedistributionnetwork;Afterthelinkissuccessful, youcanuseyourphonetocontrolthemachine; Precautionsforairpurification Itisrecommendedtocleanthefilterelementofthisproducteverytwoweeksand replaceiteverythreemonths. Whencleaningthefilterelement,donotwashitwithwater.Youcanuseaclothto wipeit,oruseasoftbrushortoothbrushtocleanthedustattachedtothesurfaceof thefilter. Whencleaningthefilterelement,pleasedonotknockit,otherwiseitwilldamagethe internalstructureofthefilterelementandfailtoachievethefilteringeffect. Theapplicablerangeofthisproductis15-30squaremeters.Iftheusagespaceislarge, pleaseuseasuitableproduct. Thisproductproducesaverysmallamountofozoneduringoperation.Ifyoufeel difficultybreathing,pleaseturnoffthemachineandopenthewindowforventilation. 6Pleasedonotsprayessence,essentialoil,perfumeandothercorrosiveliquidsonthe filterscreen. 7.Whentheproductisnotusedforalongtime,pleaseplaceitinanenvironmentwith lowtemperatureandhumiditytoavoidadverseconditionsthatmaydamagethe product'sfunctionality. Filterreplacementmethod 1.Rotatethebottomcovercounterclockwiseandopenthebottomcover button 2.Removethebottomcoverandfilterelement,andinstallthenewfilter elementintothemachine 3.Coverthebottomcoverandtightenclockwise warrantycard Thismanualalsoservesasawarrantycard.Withinoneyearfromthedateofsale,ifthe productmalfunctionsduetoqualityissuescausedbythemanufacturer,freerepairswillbe providedbypresentingthepurchaseinvoiceorthiscardtoourfactoryorauthorizedrepair department.Malfunctionscausedbyimproperusebytheuser,ortheabsenceofa purchaseinvoiceorcard,willstillberepairedattheuser'sownexpense. User Information Evaluation: Productmodel: UserName: Useraddress: Phonenumber: Purchasedate: Evaluation: APPconnectionsteps 1.Scanyourphonetodownloadtheapp,registerandlogin;Alternatively,searchfor GraffitiSmartorSmartLifeappdownloadsintheappstore.(Bothappscanbeused) 2.TurnonthemachineandtheWiFiiconwillenterslowflashingmode;(Ensure thereisavailableWiFi). 3.Doubleclickthechildlockbutton,andtheWiFiiconwillenteraflashmode. 4.OpentheBluetoothonyourphone,entertheSmartLifeapp,andclickon"Add Device"onthehomepage;Thesystemautomaticallysearchesfordevices,andoncea deviceisfound,clickadd. 5.EnterWiFipasswordtoadddevice;Waitingforsuccessfuladdition. 6.Aftersuccessfuladdition,entertheoperationbackgroundandtheWiFiiconwill remainon,andyoucanuseit. 7.TheWiFinetworkwillremainunchangedinthefuture,andwhenthemachineis turnedon,itwillautomaticallyconnecttotheinternetwithouttheneedtoreconfigure thenetwork. Goodairisvisible Colorfulhorseracingambientlightwarmsyoueverynight FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide …
