2BOAS-T20105Motor Control Unit for Vilpe roof fan connected via LoRa

VILPE Sense Basic Kit (NA) VILPE USA LLC 6402 Thornberry Ct, Mason OH 45040, USA Sales and technical support [email protected] Installation | l’installation | Instalación Quick Start Guide Guide de démarrage rapide Guía de inicio rápido This device is one component of a complete system. The complete system may require several additional components to function as intended. Refer to the full user documentation for detailed information on required components, installation instructions and system configuration. Cet appareil est un composant d’un système complet. Le sys- tème complet peut nécessiter plusieurs composants supplémentaires pour fonctionner comme prévu. Veuillez consulter la documentation utilisateur complète pour obtenir des informations détaillés sur les composants requis, les instructions d’installation et la configuration du système. Este dispositivo es un componente de un sistema completo. El sistema completo puede requerir varios componentes adicionales para funcionar como se espera. Consulte la documentación completa del usuario para obtener información detallada sobre los componentes necesarios, las instrucciones de instalación y la configuración del sistema. Sécurité et conformité Cet appareil est conforme à la partie 15 des règlements de la FCC. Son fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas provoquer d’in- terférences nuisibles, et (2) cet appareil doit accepter toute interférence reçue, y compris celles pouvant entraîner un fonctionnement indésirable. Partie responsible: VILPE USA LLC, 6402 Thornberry Court, 45040 Mason Ohio, Greater Cincinnati USA. Les modifications non autorisées peuvent annuler le droit de l’utilisa- teur d’utiliser cet appareil. Lors des travaux sur les toits, respectez toujours toutes les lois, régle- mentations et exigences de sécurité applica- bles. Faites preuve de prudence en manipu- lant des outils tranchants, des perceuses ou d’autres équipements de coupe. Unité de contrôle MCU-2 (NA) Seul un électricien autorisé et dûment qualifié peut installer les connexions électriques. Le couvercle du boîti- er est équipé d’un joint d’étanchéité qui protège contre la poussière et l’humidité. Assurez-vous que le joint est correctement positionné dans sa rainure avant de fixer le couvercle. Un mauvais positionnement du joint peut compromettre l’étanchéité et la protection de l’appareil. Capteur RHT-1 (NA) Risque d’incendie et de brûlures. Ne pas ouvrir, écraser, chauffer au- delà de 60 °C (140 °F) ou incinérer. Ne tentez pas d’ouvrir ni de remplacer la pile. Ne pas exposer à l’eau liq- uide ni à une humidité relative >95 % pendant plus de 30 jours. Retirez le cavalier rouge du capteur sans fil avant utilisation. Ce produit contient une pile au lithium. Seguridad y cumplimiento de la normativa Este dispositivo cumple con la parte 15 de las normas de la FCC. Su funcionamiento está sujeto a las siguientes dos condiciones: (1) este dispositivo no debe causar interferencia perjudicial, y (2) este dispositivo debe aceptar cualquier interferencia recibida, incluida la in- terferencia que pueda causar un funcionam- iento no deseado. Parte responsable: VILPE USA LLC, 6402 Thornberry Court, 45040 Mason Ohio, Greater Cincinnati USA. Las modificaciones no autor- izadas podrían anular la autoridad del usuario para operar este dispositivo. Al trabajar en techos, cumpla siempre con todas las leyes, normativas y requisitos de seguridad aplicables. Tenga cuidado al manejar herramientas afiladas, taladros u otros equipos de corte. Unidad de control MCU-2 (NA) Solo un electricista autoriza- do y debidamente calificado puede instalar las conexiones eléctricas. La tapa del gabinete está equipada con una junta de sellado para prote- ger contra el polvo y la humedad. Asegúrese de que la junta esté correctamente colocada en su ranura antes de asegurar la tapa. Una colocación incorrecta de la junta puede comprometer el sellado y la protección del dispositivo. Sensor RHT-1 (NA) Riesgo de incendio y quema- duras. No abra, aplaste, caliente por encima de 60 °C (140 °F) ni incinere. No intente abrir ni reemplazar la batería. No exponga al agua liquida ni a >95 % de humedad relativa durante más de 30 días. Retire la pestaña de segu- ridad roja del sensor inalámbrico antes de usarlo. Este producto contiene una batería de litio. T80425 ADVERTENCIA Safety & Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, includ- ing interference that may cause undesired operation. Responsible party: VILPE USA LLC, 6402 Thornberry Court, 45040 Mason Ohio, Greater Cincinnati USA. Unauthorized modifications may void the user’s authority to operate this device. When working on rooftops, always comply with all applicable laws, regu- lations, and safety requirements. Use caution when handling sharp tools, drills, or other cutting equipment. Control Unit MCU-2 (NA): Only an authorized and adequately qualified electrician may install the electrical connections. The enclosure cover is equipped with a sealing gasket to protect against dust and moisture. Make sure that the gasket is correctly seated in its groove before securing the cover. Improper gasket place- ment may compromise the device’s sealing and protection rating. Sensor RHT-1 (NA): Risk of fire and burns. Do not open, crush, heat above 140 °F (+60 °C), or incinerate. Do not attempt to open or replace the battery. Do not expose to liquid water or >95 % RH for > 30 days. Remove the red jumper from the wireless sensor before use. This product contains lithium battery. AVISO AVIS PRÉCAUTION AVERTISSEMENT WARNING WARNING CAUTION WARNING CAUTION AVERTISSEMENT AVERTISSEMENT PRÉCAUTION AVIS AVIS ADVERTENCIA PRECAUCIÓN ADVERTENCIA PRECAUCIÓN AVISO AVISO Read and understand all warnings and instruc- tions. Failure to do so may result in injury a…

Text truncated - open the document above for the full version.

VILPE Oy Kauppatie 9, FI-65610 Mustasaari Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA 2025-09-10 Attestation Statement according to 2.911(d)(5)(i) and 2.911(d)(5)(ii) FCC ID: 2BOAS-T20105 TO WHOM IT MAY CONCERN: Hereby we certify that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Further we certify that, as of the date of the filing of the application, VILPE Oy is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, _______________ (signature & company stamp) VILPE Oy 0036806073 Kauppatie 9, 65610 Mustasaari, Finland Kimmo Kujala +358 20 123 3263 [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 2025-09-23 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b) (4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2BOAS-T20105 VILPE MCU-2 (NA) For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Description The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device, which is planned for - If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name / Title: Kimmo Kujala / Product Manager Company: VILPE Oy Address: Kauppatie 9, 65610 Mustasaari, Finland Phone: +358 20 123 3263 Fax: - E-Mail: [email protected]

Annex A101 - Photographs No. 1-9457-25-02-01_TR1-A101-R01 October 13, 2025 DescriptionExternal photos of EUT This document is electronically signed and valid without handwritten signature. Public keys for verifcation of the electronic signatures can be requested at the testing laboratory. Hans-Joachim Wolsdorfer Lab Manager Radio Labs authorized by cetecom advanced GmbH Untertuerkheimer Str. 6-10, 66117 Saarbruecken Document No. 1-9457-25-02-01_TR1-A101-R01 Page 1 of 5 Photo 1 Photo 2 cetecom advanced GmbH Untertuerkheimer Str. 6-10, 66117 Saarbruecken Document No. 1-9457-25-02-01_TR1-A101-R01 Page 2 of 5 Photo 3 Photo 4 cetecom advanced GmbH Untertuerkheimer Str. 6-10, 66117 Saarbruecken Document No. 1-9457-25-02-01_TR1-A101-R01 Page 3 of 5 Photo 5 Photo 6 cetecom advanced GmbH Untertuerkheimer Str. 6-10, 66117 Saarbruecken Document No. 1-9457-25-02-01_TR1-A101-R01 Page 4 of 5 Document History End of document ReleaseApplied changesRelease date R01initial releaseOctober 13, 2025 cetecom advanced GmbH Untertuerkheimer Str. 6-10, 66117 Saarbruecken Document No. 1-9457-25-02-01_TR1-A101-R01 Page 5 of 5

art 22085 Vilpe Sense Control Unit MCU-2(NA) V2.2a Nokeval Oy / Marko Vuokko 2025-10-01 complete device – isometric view complete device front closed complete device left side complete device right side complete device back side complete device bottom side complete device top side

VILPE MCU-2 (NA) label Nokeval Oy / Juha Hämäläinen 2025-10-15 Artwork Version V2, dimensions 54x31 mm. Placement

art 22085 Vilpe Sense Control Unit MCU-2(NA) V2.2a Nokeval Oy / Marko Vuokko 2025-10-01 board top (For high resolution image see the last page of this document) board bottom complete device front open internal view to top internal view to bottom internal view to right side internal view to left side

Annex A102 - Photographs No. 1-9457-25-02-01_TR1-A102-R01 October 13, 2025 DescriptionInternal photos of EUT This document is electronically signed and valid without handwritten signature. Public keys for verifcation of the electronic signatures can be requested at the testing laboratory. Hans-Joachim Wolsdorfer Lab Manager Radio Labs authorized by cetecom advanced GmbH Untertuerkheimer Str. 6-10, 66117 Saarbruecken Document No. 1-9457-25-02-01_TR1-A102-R01 Page 1 of 4 Photo 1 Photo 2 cetecom advanced GmbH Untertuerkheimer Str. 6-10, 66117 Saarbruecken Document No. 1-9457-25-02-01_TR1-A102-R01 Page 2 of 4 Photo 3 Photo 4 cetecom advanced GmbH Untertuerkheimer Str. 6-10, 66117 Saarbruecken Document No. 1-9457-25-02-01_TR1-A102-R01 Page 3 of 4 Document History End of document ReleaseApplied changesRelease date R01initial releaseOctober 13, 2025 cetecom advanced GmbH Untertuerkheimer Str. 6-10, 66117 Saarbruecken Document No. 1-9457-25-02-01_TR1-A102-R01 Page 4 of 4

Page 1 (7) Test Report no.: 28112025_002 Date of report: 2.12.2025 FCC SAR ASSESSMENT REPORT Test report #: 28112025_002 Date of report: 2 nd of December 2025 Test laboratory: Etteplan Finland Oy Client: VILPE Oy Address: Aholaidantie 3 FI-40320 Jyväskylä Finland Kauppatie 9 65610 Mustasaari Finland Contact: Anssi Kauhanen Kimmo Kujala E-mail: [email protected] [email protected] Telephone: +358 10 3070 +358 20 1233263 Evaluation has been carried out in accordance with: ANSI/IEEE C95.1- 1992 ANSI/IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz OET Bulletin No. 65 Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields KDB 447498 D04 Interim General RF Exposure Guidance v01 KDB 447498 D01 General RF Exposure Guidance v06 Device description: VILPE The MCU-2 (NA) motor control unit is a small box mounted in the vertical pipe of a roof-installed ventilation fan and connected with a cable to the fan motor to control the fan speed intelligently. The MCU communicates wirelessly with some RHT-1 (NA) humidity sensors and with the CCU-2 (NA) gateway via its 918.9 MHz LoRa radio. The interface with the electronically controlled fan motor consists of a 10 V DC supply from the motor to the MCU with a limited current (1 or 10 mA), tachometer pulses from the motor, and a 0-10 V control signal from the MCU to the motor. Statement of Compliance: Compliant EUT tested by: Henry Sand Reported by: Henry Sand Date and signatures: Anssi Kauhanen Henry Sand Manager, EMC & RF Laboratory Operations Senior RF/EMC Designer Page 2 (7) Test Report no.: 28112025_002 Date of report: 2.12.2025 EQUIPMENT UNDER TEST (EUT) EUT type: MCU-2 (NA) EUT ID: MCU-2 (NA) HW version: V2.2a SW version: V2.0 FCC ID: 2BOAS-T20105 Product description: Internet gateway Device category: (Portable/Mobile/Fixed) Fixed Environment: General population/Uncontrolled Additional information: - ADDITIONAL NOTES The test results and statements apply only to the tested item(s) as received. EUT information is provided by manufacturer. Etteplan is not responsible for any further propositions of applicability on the basis of the test results in this report. This test report shall only be reproduced in full. No partial reproduction of the report is allowed without written approval of the test laboratory. This report is valid when digitally signed and protected by a strong password. Page 3 (7) Test Report no.: 28112025_002 Date of report: 2.12.2025 TABLE OF CONTENTS Equipment Under Test (EUT) ................................................................................................................................................. 2 Additional Notes ...................................................................................................................................................................... 2 1 General description ....................................................................................................................................................... 4 1.1 EUT Description ................................................................................................................................................... 4 1.2 Specification of the EUT .................................................................................................................................... 4 2 SAR Assessment ............................................................................................................................................................. 5 2.1 SAR Test Exclusion Limits .................................................................................................................................. 5 2.1.1 Equation ........................................................................................................................................................... 5 2.1.2 100 MHz – 6 GHz and ≤ 50 mm ................................................................................................................... 5 2.1.3 100 MHz – 6 GHz and > 50 mm ................................................................................................................... 6 2.1.4 < 100 MHz and < 200 mm ............................................................................................................................. 6 2.2 Assessment Result .............................................................................................................................................. 6 3 Antennas .......................................................................................................................................................................... 7 Page 4 (7) Test Report no.: 28112025_002 Date of report: 2.12.2025 1 General description 1.1 EUT Description The following EUT models were tested: Table 1 – Product details Brand Model Description VILPE MCU-2 (NA) The MCU communicates wirelessly with some RHT-1 (NA) humidity sensors and with the CCU-2 (NA) gateway via its 918.9 MHz LoRa radio. 1.2 Specification of the EUT Table 2 – Antenna details Antenna Antenna brand/model Antenna type Info Internal Custom antenna PCB 915 MHz LoRaWAN Details declared by the manufacturer. Table 3 – Lora details Operating band Frequency Max. Time Slots/Duty Cycle Max. conducted TX power Tune-Up Antenna Max. Gain Min. cable loss EIRP [MHz] [dBm] [mW] [dB] [dBi] [dB] [dBm] [mW] LoRa 915 MHz 902-928 10 % 4.5 1 7.2 12.7 18.3 Notes! • Only worst-case values reported • Details declared by the manufacturer. Page 5 (7) Test Report no.: 28112025_002 Date of report: 2.12.2025 2 SAR Assessment 2.1 SAR Test Exclusion Limits 2.1.1 Equation [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR 2.1.2 100 MHz – 6 GHz and ≤ 50 mm MHz 5 10 15 20 25 mm 150 39 77 116 155 194 SAR Test Exclusion …

Text truncated - open the document above for the full version.

TEST REPORT Test report no.: 1-9457-25-02-05_TR1-R02 Testing laboratory Applicant cetecom advanced GmbH Untertuerkheimer Strasse 6 – 10 66117 Saarbruecken / Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 Internet: https://cetecomadvanced.com e-mail: [email protected] Accredited Testing Laboratory: The testing laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 (2018-03) by the Deutsche Akkreditierungsstelle GmbH (DAkkS). The accreditation is valid for the scope of testing procedures as stated in the accreditation certificate with the registration number: D-PL-12047-01-00. ISED Testing Laboratory Recognized Listing Number: DE0001 FCC designation number: DE0002 VILPE Oy Kauppatie 9 65610 Mustasaari / FINLAND Phone: +358201233263 Contact: Kimmo Kujala e-mail: [email protected] Manufacturer VILPE Oy Kauppatie 9 65610 Mustasaari / FINLAND Test standard/s FCC - Title 47 CFR Part 15 FCC - Title 47 of the Code of Federal Regulations; Chapter I; Part 15 - Radio frequency devices For further applied test standards please refer to section 3 of this test report. Test Item Kind of test item: controller device for Vilpe roof fan connected via LoRa Model name: MCU-2 FCC ID: 2BOAS-T20105 Frequency: 902.0 – 928.0 MHz Technology tested: proprietary Antenna: Integrated antenna Power supply: 10 V to 10 V DC, by external power supply Temperature range: -30°C to +60°C This test report is electronically signed and valid without handwritten signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report authorized: Test performed: Christoph Schneider Hans-Joachim Wolsdorfer Lab Manager Lab Manager Radio Labs Radio Labs Test report no.: 1-9457-25-02-05_TR1-R02 © cetecom advanced GmbH Page 2 of 44 1 Table of contents 1 Table of contents .................................................................................................................................... 2 2 General information ................................................................................................................................ 3 2.1 Notes and disclaimer .................................................................................................................... 3 2.2 Application details ........................................................................................................................ 3 2.3 Test laboratories sub-contracted .................................................................................................. 3 3 Test standard/s, references and accreditations ....................................................................................... 4 4 Reporting statements of conformity – decision rule ................................................................................ 5 5 Test environment.................................................................................................................................... 6 6 Test item ................................................................................................................................................ 6 6.1 General description ...................................................................................................................... 6 6.2 Additional information .................................................................................................................. 6 7 Description of the test setup ................................................................................................................... 7 7.1 Shielded semi anechoic chamber .................................................................................................. 8 7.2 shielded fully anechoic chamber ................................................................................................. 10 7.3 Conducted measurements .......................................................................................................... 12 7.4 AC conducted ............................................................................................................................. 13 8 Sequence of testing .............................................................................................................................. 14 8.1 Sequence of testing radiated spurious 9 kHz to 30 MHz .............................................................. 14 8.2 Sequence of testing radiated spurious 30 MHz to 1 GHz ............................................................. 15 8.3 Sequence of testing radiated spurious 1 GHz to 10 GHz .............................................................. 16 9 Measurement uncertainty ..................................................................................................................... 17 10 Summary of measurement results ..................................................................................................... 18 11 RF measurements ............................................................................................................................. 19 11.1 Additional comments .............................................................................................................. 19 12 Measurement results ........................................................................................................................ 20 12.1 Maximum output power ........................................................................................................... 20 12.2 Antenna gain ........................................................................................................................... 22 12.3 Power spectral density ............................................................................................................ 23 12.4 Spectrum bandwidth – 6 dB bandwidth and 99% bandwidth ..................................................... 25 12.5 Detailed spurious emissions @ the band edge – conducted and…

Text truncated - open the document above for the full version.

Radientum project number: P4297 Prepared by: Matti Lahdenperä Nokeval, MCU-2, 916 MHz variant, 4-layer PCB Revision History Rev. Date Description 1.0 08.07.2025 Initial version Measurement Report CONFIDENTIAL Page 1 of 6 Radientum Oy | Visiokatu 4 | 33720 Tampere, Finland | [email protected] | www.radientum.com EXECUTIVE SUMMARY This measurement report details the antenna measurements for new 4-layer MCU-2 (LoRa 916 MHz). CONFIDENTIAL Page 2 of 6 Radientum Oy | Visiokatu 4 | 33720 Tampere, Finland | [email protected] | www.radientum.com TABLE OF CONTENT EXECUTIVE SUMMARY .................................................................................................................................................. 1 MEASUREMENT SETUP ................................................................................................................................................. 3 MEASUREMENT RESULTS ............................................................................................................................................ 4 MATCHING CIRCUIT ........................................................................................................................................................ 6 CONFIDENTIAL Page 3 of 6 Radientum Oy | Visiokatu 4 | 33720 Tampere, Finland | [email protected] | www.radientum.com MEASUREMENT SETUP The device was measured in free-space conditions. CONFIDENTIAL Page 4 of 6 Radientum Oy | Visiokatu 4 | 33720 Tampere, Finland | [email protected] | www.radientum.com MEASUREMENT RESULTS Figure 1: Return loss (S11) Figure 2: Total efficiency CONFIDENTIAL Page 5 of 6 Radientum Oy | Visiokatu 4 | 33720 Tampere, Finland | [email protected] | www.radientum.com Figure 3: Maximum gain Table 1. LoRa Maximum Gain Value MCU-2, maximum gain, LoRa 916 MHz (908-928 MHz) +2.1 dBi CONFIDENTIAL Page 6 of 6 Radientum Oy | Visiokatu 4 | 33720 Tampere, Finland | [email protected] | www.radientum.com MATCHING CIRCUIT Figure 4. New LoRa matching circuit Inductor, 4.7 nH: Murata LQW15AN4N7B00 Capacitor, 3.3 pF: Murata GJM1555C1H3R3BB01
