*OEPPS $BNFSB User Manual App:O-KAM Pro -1--2--3--4--5- -6- Blue light: waiting for Wi-Fi connec- tion--flashslowly, during Wi-Fi connection-flash quickly.Wi-Fi connection successfully--always Built-in battery. Support DC 5V/1A power supply. The device has two working modes: AP hotspotmode and Wi-Firemote mode. How to factory reset: When the camera is turnedon, press and hold the reset button for about 5seconds until the blue light and the red lightflash alternately.the red lightflash alternately. bright. Indicator Status Yellow light: charging-always bright Device Description fully charged-off R Step 2: APP Download and Please place the camera within 2 meters rangeof the router when connecting to Wi-Fi. Connect your phone to Wi-Fi and clear theWi-Fi password. (Only support 2.4GHz Low -power alarm: The blue light and the Factory reset:The blue light and the red POP
TXJUDI NFNPSZ
DBSE SFTFU
LFZ 5ZQFD light(red light) flash alternately. red light (red light) flash at the same time. Turn on the camera. Restore the camera to the factory settings. Wi-Fi) Step 1:Pre-Setup Registration Search for “O-KAM Pro" in APP Store orGooglePlay, or scan the QR cord above to download the APP 1 Click “Register now" and register your account according to the prompts. 2 Turn on the Bluetooth function of the phone 2 Turn on the camera and restore it to the factory settings. 1 Step 3: Add Devices to the APP Method One: Bluetooth Connection Open the APP, wait for the searched device toappear at the top of the page, and then click"Connect".(lf no device is searched, please click"Add" to search again, or directly scan the QRcode on the camera) 3 Installation steps: base mounting to tear open the 3M adhesive and stick it on the wall or on top of other objects, the minimum distance to be used is more than 20cm. -7--8--9--10--11- -12- -13- Confirm the Wi-Fi youwant to connect and enterthe correct password.(5G Hz Wi-Fi is not supported) 4 Wait for the camera tobind to the APP. 5 Click "Get started" in turn. 6 Click the icon in the upperright corner and select“Hotspot Configuration” 2 Click “To connect” 3 Method Two: AP Connection Turn on the camera and restore it to the factory settings. 1 Enter the network settingsof your phone, select the signal of “@ MC -***"andconnect. 4 Back to the APP to automatically add the device, click the play button to watch. 5 Wi-Fi Configuration Device Share Click “settings” 1 Slect “Device Settings” 2 Click “Wi-Fi network” 3 Select the Wi-Fi you want to connect and enter the correct password. 4 Enter the “System settings" of the camera andselect “Share" to generate the device sharing QRcode. Other users can open the APP and scan thisQR code to add the device. FCC Caution. This device complies with part �� of the FCC Rules. Operation is subject to the following two conditions: (�) This device may not cause harmful interference, and (�) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part �� of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance ��cm between the radiator & your body.

承 認 書 SPECIFICATION FOR APPROVAL 客戶名稱 CUSTOMER ： 客戶料號 CUSTOMER’S P/N ： 料號 PART NUMBER ： WAN097030JD251SN03 規格 DESCRIPTION ： Chip Antenna 7030 M-Ant 2.45G +5G Type 03 版本 VERSION ： V1.0 日期 ISSUE DATE ： 2023/12/7 客 戶 承 認 CUSTOMER APPROVED 工 程 部 R&D CENTER 承 認 APPROVAL 確 認 CHECKED 製 作 DRAWN Ray Snow Jerry 萬誠科技股份有限公司 OneWave Electronic Co., Ltd. 112台北市北投區立功街151號1樓 1F, No. 151, Li Gong Street, Beitou District, Taipei City 112, Taiwan 電話: (02) 2898-2220 TEL: +886 2 2898-2220 傳真: (02) 2898-5055 FAX: +886 2 2898-5055 2/12 ONEWAVE TECHNOLOGY CO., LTD. 7030 Chip antenna For WLAN Dual-Band Applications Dimension (mm) L 7.00 ± 0.20 W 3.00 ± 0.20 T 1.15 ± 0.20 P/N: WAN097030JD251SN03 3/12 ONEWAVE TECHNOLOGY CO., LTD. Part Number Information WAN 09 7030 J D25 1S N 03 A G B C D H E F A Product Series Antenna B Dimension L x W 7.0X3.0mm (+-0.2mm) C Material High K material D Working Frequency 2.4 ~ 2.5GHz + 5.15~5.85GHz E Feeding mode Monopole & Single Feeding F Antenna type Type = 03 G、H Internal Code 1. Electrical Specification Remark : Bandwidth & Peak Gain was measured under evaluation board of next page Specification Part Number WAN097030JD251SN03 Central Frequency 2450 / 5500 MHz Bandwidth 100 / 800 (Min.) MHz Return Loss -10 (Max) dB Peak Gain 2.95 / 5.40 dBi Impedance 50 Ohm Operating Temperature -40～+110 °C Maximum Power 4 W Resistance to Soldering Heats 10 ( @ 260°C) sec. Polarization Linear Azimuth Beamwidth Omni-directional Termination Cu / Sn (Leadless) 4/12 ONEWAVE TECHNOLOGY CO., LTD. 2. Recommended PCB Pattern Evaluation Board Dimension Unit : mm Suggested Matching Circuit : ±0.1~0.3nH±0.1pF 5/12 ONEWAVE TECHNOLOGY CO., LTD. ◆ Layout Dimensions in Clearance area( Size=27.0*7.0mm) 50 ohm transmission Line FootPrint (Unit : mm) Matching circuit 6/12 ONEWAVE TECHNOLOGY CO., LTD. 3. Measurement Results Return Loss 7/12 ONEWAVE TECHNOLOGY CO., LTD. Radiation Pattern Efficiency Peak Gain Directivity 2400MHz 70.69 % 2.83 dBi 4.33 dBi 2450MHz 72.86 % 2.95 dBi 4.32 dBi 2500MHz 71.46 % 2.89 dBi 4.34 dBi Efficiency Peak Gain Directivity 5150MHz 75.83 % 5.28 dBi 6.48 dBi 5500MHz 78.80 % 5.40 dBi 6.43 dBi 5850MHz 76.44 % 5.34 dBi 6.50 dBi X Z Y X Z Y 8/12 ONEWAVE TECHNOLOGY CO., LTD. Chamber Coordinate System 9/12 ONEWAVE TECHNOLOGY CO., LTD. 4.Reliability and Test Condictions ITEM REQUIREMENTS TEST CONDITION Solderability 1. Wetting shall exceed 90% coverage 2. No visible mechanical damage Pre-heating temperature:150°C/60sec. Solder temperature:230±5°C Duration:4±1sec. Solder:Sn-Ag3.0-Cu0.5 Flux for lead free: rosin Solder heat Resistance 1. No visible mechanical damage 2. Central Freq. change :within ± 6% 10±0.5 sec. 60sec .. TEMP (°C) 150°C 260°C Pre-heating temperature:150°C/60sec. Solder temperature:260±5°C Duration:10±0.5sec. Solder:Sn-Ag3.0-Cu0.5 Flux for lead free: rosin Component Adhesion (Push test) 1. No visible mechanical damage The device should be reflow soldered(230±5°C for 10sec.) to a tinned copper substrate A dynometer force gauge should be applied the side of the component. The device must with-ST-F 0.5 Kg without failure of the termination attached to component. Component Adhesion (Pull test) 1. No visible mechanical damage Insert 10cm wire into the remaining open eye bend ,the ends of even wire lengths upward and wind together. Terminal shall not be remarkably damaged. Thermal shock 1. No visible mechanical damage 2. Central Freq. change :within ±6% Phase Temperature(°C) Time(min) 1 +110±5°C 30±3 2 Room Temperature Within 3sec 3 -40±2°C 30±3 4 Room Temperature Within 3sec +110°C=>30±3min -40°C=>30±3min Test cycle:10 cycles The chip shall be stabilized at normal condition for 2~3 hours before measuring. Resistance to High Temperature 1. No visible mechanical damage 2. Central Freq. change :within ±6% 3. No disconnection or short circuit. Temperature: +110±5°C Duration: 1000±12hrs The chip shall be stabilized at normal condition for 2~3 hours before measuring. Resistance to Low Temperature 1. No visible mechanical damage 2. Central Freq. change :within ±6% 3. No disconnection or short circuit. Temperature:-40±5°C Duration: 1000±12hrs The chip shall be stabilized at normal condition for 2~3 hours before measuring. Humidity 1. No visible mechanical damage 2. Central Freq. change :within ±6% 3. No disconnection or short circuit. Temperature: 40±2°C Humidity: 90% to 95% RH Duration: 1000±12hrs The chip shall be stabilized at normal condition for 2~3 hours before measuring. 4±1 sec. 60sec TEMP (°C) 150°C 230°C 10/12 ONEWAVE TECHNOLOGY CO., LTD. 5.Soldering and Mounting Mildly activated rosin fluxes are preferred. The minimum amount of solder can lead to damage from the stresses caused by the difference in coefficients of expansion between solder, chip and substrate. The terminations are suitable for all wave and re-flow soldering systems. If hand soldering cannot be avoided, the preferred technique is the utilization of hot air soldering tools. Recommended temperature profiles for re-flow soldering in Figure 1. Products attachment with a soldering iron is discouraged due to the inherent process control limitations. In the event that a soldering iron must be employed the following precautions are recommended. ‧Preheat circuit and products to 150°C ‧Never contact the ceramic with the iron tip ‧Use a 20 watt soldering iron with tip diameter of 1.0mm ‧280°C tip temperature (max) ‧1.0mm tip diameter (max) ‧Limit soldering time to 3 sec. SOLDERING COOLING NATURAL PRE-HEATING TEMPERATURE(°C) 60~120 s 10s max. 30~60s 250~260 230 180 150 TIME(sec.) Reflow Soldering SOLDERING COOLING NATURAL PRE-HEATING TEMPERATURE(°C) within 3s Gradualcooling 150 TIME(sec.) Iron Soldering Over 60s 350 300 11/12 ONEWAVE TECHNOLOGY CO., LTD. 6.Packaging Information ◆ Tape Specification: Reel Specification: (7’’, Φ180 mm) Tape Width(mm) A(mm) B(mm) C(mm) D(mm) Chip/Reel(pcs) 16 16±1.0 60±2 13.5±0.5 178±2 2000 12/12 ONEWAVE TECHNOLOGY CO., LTD. 7.Storage and Transportation Information Storage Conditions To maintain t…
