2BOHY-800S1WIFI6+BLE 5.2 Module

V0.1-Feb.2025 TR6A800S1datasheet SPECIFICATION TR6A800S1 IEEE802.11b/g/n/axSDIO1T1R+BLE5.2 ComboModule IfonereceivesthisdocumentfromTrulyElectronicsCo.,Ltd.(hereinafterreferredtoas"TrulyElectronics"),itindicatesthatonehasagreed tothefollowingterms.Ifonedoesnotconsenttothefollowingterms,pleaseceasetheuseofthisdocument. ThecopyrightofthisdocumentisownedbyTrulyElectronicsCo.,Ltd.,andanyrightsnotexplicitlygrantedhereinarereserved.This documentinvolvestheproprietaryinformationofTrulyElectronics.WithoutthepriorwrittenpermissionofTrulyElectronics,noentityor individualmayduplicate,disseminate,distribute,utilizeordisclosethisdocument,aswellasanypictures,tables,dataandother informationcontainedtherein. Thisproductconformstothedesignrequirementsregardingenvironmentalprotectionandpersonalsafety.Thestorage,useanddisposal oftheproductshouldcomplywiththerequirementsstipulatedintheproductmanual,relevantcontractsorrelevantnationallawsand regulations. Thecompanyreservestherighttomodifyandimprovetheproductsdescribedinthismanualwithoutpriornotification;meanwhile,it reservestherighttoreviseorwithdrawthismanualatanytime. Ifthereisanyambiguityorobscurityinthetextofthisusermanual,pleaseconsultthecompanyorthedistributorpromptly. Address:NorthOfTheDongChongRoad,TrulyIndustrialArea,ShanweiCity,GuangdongProvince,China. Website:https://www.truly.com.hk TRULY TRULY TRULY TRULY TRULY TRULY TRULY TRULY TRULY TRULY V0.1-Feb.2025 Page 2 of17 TR6A800S1datasheet Contents 1.DeviceOverview...........................................................................................................................................3 1.1Descriptions...........................................................................................................................................3 1.2Features.................................................................................................................................................3 1.2.1GeneralFeatures............................................................................................................................3 1.2.2Wi-FiKeyFeatures.........................................................................................................................3 1.2.3BluetoothKeyFeatures..................................................................................................................4 1.3FunctionalBlockDiagram......................................................................................................................5 2.PinConfigurationandFunctions..................................................................................................................5 2.1ModulePinDiagram...............................................................................................................................5 2.2PinFunctions.........................................................................................................................................6 3.Specifications...............................................................................................................................................8 3.1GeneralCharacteristics.........................................................................................................................8 3.2RFCharacteristics..................................................................................................................................9 3.2.1ReceiverRFSpecifications............................................................................................................9 3.2.2TransmitterRFSpecifications......................................................................................................11 3.2.3BluetoothRFSpecifications.........................................................................................................13 4.ApplicationandImplementation.................................................................................................................14 4.1ApplicationDiagram.............................................................................................................................14 5.MechanicalandPackage...........................................................................................................................15 5.1MechanicalSize...................................................................................................................................15 5.2RecommendedLandPattern...............................................................................................................15 5.3PackageInformation............................................................................................................................16 6.ThermalReflow..........................................................................................................................................16 7.OrderingInformation..................................................................................................................................17 8.RevisionHistory..........................................................................................................................................17 TRULY TRULY TRULY TRULY TRULY TRULY TRULY TRULY TRULY TRULY V0.1-Feb.2025 Page 3 of17 TR6A800S1datasheet 1.DeviceOverview 1.1Descriptions TheTR6A800S1isahighlyintegratedmodulethatsupports1T1R802.11b/g/n/axwithWireless LAN(WLAN)SDIO(SDIO1.1/2.0/3.0)interfacecontrollerand BLE5.2forwirelessapplication , combinedwithBPSK,QPSK,16QAM,64QAM、256QAMandupto1024QAMmodulationofthe individualsubcarriers,andcompatiblecodingrateof1/2,2/3,3/4,5/6,provideupto286MbpsforIEEE 802.11ax.TheTR6A800S1MACsupports802.11eformultimediaapplications,802.11iandWAPIfor security.TheTR6A800S1providesacompletesolutionforahigh-performanceintegratedwirelessand Bluetoothdevice.ItsuitableforSTB,TVs,tablets,phones,IPCandotherfieldssuchasconsumer electronicdevices,andcanalsobeappliedtothefieldswithhighreliabilityrequirements,suchas industrialintercon…

Text truncated - open the document above for the full version.

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Report No.:STS2603049W03 Issued for TRULY ELECTRONICS MFG., LTD Truly industry city, shanwei guangdong，P.R.C Product Name: WIFI6+BLE 5.2 Module Brand Name: N/A Model Name: TR6A800S1-C Series Model(s): TR6A800S1, TR6A800S1-C1 FCC ID: 2BOHY-800S1 Test Standards: FCC Part15.247 Page 2 of 99 Report No.: STS2603049W03 TEST REPORT Applicant’s Name ................. : TRULY ELECTRONICS MFG., LTD Address ................................. : Truly industry city, shanwei guangdong，P.R.C Manufacturer's Name ........... : TRULY ELECTRONICS MFG., LTD Address ................................. : Truly industry city, shanwei guangdong，P.R.C Product Description Product Name ........................ : WIFI6+BLE 5.2 Module Brand Name ........................... : N/A Model Name .......................... : TR6A800S1-C Series Model(s) .................... : TR6A800S1, TR6A800S1-C1 Standards ............................. : FCC Part 15.247 Test Procedure........................: ANSI C63.10-2020 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ...................... : 06 Mar. 2026 Date (s) of performance of tests ............. : 06 Mar. 2026~17 Mar. 2026 Date of Issue .......................................... : 17 Mar. 2026 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 99 Report No.: STS2603049W03 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 TEST SOFTWARE AND POWER LEVEL 11 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 12 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 13 3. EMC EMISSION TEST 14 3.1 CONDUCTED EMISSION MEASUREMENT 14 3.2 RADIATED EMISSION MEASUREMENT 18 4. DUTY CYCLE 30 4.1 TEST STANDARD 30 4.2 TEST PROCEDURE 30 4.3 DEVIATION FROM STANDARD 30 4.4 TEST SETUP 30 4.6 TEST RESULTS 30 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 31 5.1 LIMIT 31 5.2 TEST PROCEDURE 31 5.3 DEVIATION FROM STANDARD 31 5.4 TEST SETUP 31 5.5 EUT OPERATION CONDITIONS 31 5.6 TEST RESULTS 31 6. POWER SPECTRAL DENSITY TEST 32 6.1 LIMIT 32 6.2 TEST PROCEDURE 32 6.3 DEVIATION FROM STANDARD 32 6.4 TEST SETUP 32 6.5 EUT OPERATION CONDITIONS 32 6.6 TEST RESULTS 32 Page 4 of 99 Report No.: STS2603049W03 Table of Contents Page 7. BANDWIDTH TEST 33 7.1 LIMIT 33 7.2 TEST PROCEDURE 33 7.3 DEVIATION FROM STANDARD 33 7.4 TEST SETUP 33 7.5 EUT OPERATION CONDITIONS 33 7.6 TEST RESULTS 33 8. PEAK OUTPUT POWER TEST 34 7.1 LIMIT 34 8.2 TEST PROCEDURE 34 8.3 DEVIATION FROM STANDARD 34 8.4 TEST SETUP 34 8.5 EUT OPERATION CONDITIONS 34 8.6 TEST RESULTS 34 9. ANTENNA REQUIREMENT 35 9.1 STANDARD REQUIREMENT 35 9.2 EUT ANTENNA 35 APPENDIX 1-TEST DATA 36 DUTY CYCLE 36 MAXIMUM PEAK CONDUCTED OUTPUT POWER 46 -6DB BANDWIDTH 47 MAXIMUM POWER SPECTRAL DENSITY LEVEL 57 BAND EDGE 67 CONDUCTED RF SPURIOUS EMISSION 80 APPENDIX 2-PHOTOS OF TEST SETUP 99 Page 5 of 99 Report No.: STS2603049W03 Revision History Rev. Issue Date Report No. Effect Page Contents 00 17 Mar. 2026 STS2603049W03 ALL Initial Issue Page 6 of 99 Report No.: STS2603049W03 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted Band Edge Emission PASS -- Part 15.247(d)/ part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. Page 7 of 99 Report No.: STS2603049W03 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.751dB 2 Unwanted Emissions, conducted ±2.888dB 3 All emissions, radiated 9K-30MHz ±2.48dB 4 All emissions, radiated 30M-1GHz ±2.52dB 5 All emissions, radiated 1G-18GHz ±3.48dB 6 All emissions, radiated>18GHz ±4.18dB 7 Conducted Emission (9KHz-150KHz) ±2.48dB 8 Conducted Emission (150KHz-30MHz) ±2.52dB 9 Occupied Channel Bandwidth ±3.6% 10 Power Spectral Density, conducted ±1.214dB 11 Duty Cycle ±3.2% Page 8 of 99 Report No.: STS2603049W03 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name WIFI6+BLE 5.2 Module Brand Name N/A Model Name TR6A800S1-C Series Model(s) TR6A800S1, TR6A800S1-C1 Model Difference Only the model names are different Product Description Operation Frequ…

Text truncated - open the document above for the full version.

Page 1 of 2 FCC ID: 2BOHY-800S1 Setup photo AC Conduction RF Conduction Page 2 of 2 FCC ID: 2BOHY-800S1 RE (Below 1GHz) RE (Above 1GHz)

4321 P A R T N o . C U S R E V : A B C S C A L E : D W N : C H K : A P P D : S I Z E : D R A W I N G A P P R O V A L A N G U L A R D I M E N S I O N ( E N G ) H O L E D I A . V A R I A T I O N . X X T H R E E P L A C E D E C I M A L . X X X T W O P L A C E D E C I M A L . X X O N E P L A C E D E C I M A L . X T O L E R A N C E S U N L E S S O T H E R W I S E S P E C I F I E D D N / A N / A N / A N / A N / A T H I R D A N G L E P R O J E C T I O N C U S : S H E E T : I T E M : E U N I T : : A 4 - m m - O F 1 1 A B C D EE E X C R E V : F D R A W I N G R E C E I V E D 0 1 R E V F D E S C R I P T I O N M a y . 2 9 , 2 0 2 2 M E M O N / A 0 1 2 . 4 G H z / 5 . 8 G H z A N T E N N A T P E , C O L O R ; B L A C K 4 3 C O V E R 2 1 G R O U N D T U S E Ø 5 . 2 x 2 3 . 0 m m C O P P E R P I P E , M A T E R I A L : B R A S S , I N C K E L P L A T E D . I T E M N o . Q T Y 1 P C 1 P C 1 P C D E S C R I P T I O N B I L L O F M A T E R I A L C A B L E 2 P C R I V E T 8 2 . 5 ± 2 . 0 Ф 7 . 8 Ф 9 . 3 5 ± 0 . 1 0 N O T E S : 2 . 2 V S W R : ≤ 2 . 0 R G - 1 7 8 / U R F C O A X I A L C A B L E , F E P J A C K E T , T R A N S P A R E N T B R O W N , L = 8 3 m m B R A S S , B L A C K N I C K E L P L A T E D A N T E N N A B A S E 5 P C , C O L O R ; B L A C K 1 P C 9 0 ° 1 P C 6 A N T E N N A B A S E P A + 3 0 % G F , C O L O R ; B L A C K 1 . A L L M A T E R I A L S M U S T M E E T R o H S . 2 . E L E C T R I C A L C H A R A C T E R I S T I C S : 2 . 1 F R E Q U E N C Y R A N G E : 2 . 4 G H z - 2 . 5 G H z / 4 . 9 - 5 . 8 G H Z 2 . 3 N O R M I N A L I M P E D A N C E : 5 0 O H M 2 . 4 P O L A R I Z A T I O N : V E R T I C A L 3 . E N V I R O N M E N T : 3 . 1 O P E R A T I O N T E M P E R A T U R E : - 3 0 ° C T O + 7 0 ° C 2 5 . 6 1 P C S M A R E V E R S E S T R A I G H T P L U G F O R R G - 1 7 8 C A B L E , B L A C K . C O N N E C T O R 7 1 3 5 2 6 7 4 2 . 5 G A I N : 2 d B i 1 0 8 ± 2 L I J I E A 2 5 4 5 8 1 0 1 双频胶棒天线测试报告 胶棒天线图片： 小胶棒天线S11数据： 频率（MHz） 2400 2450 2500 5150 5350 5700 5900 ReturnLoss -27.36 -17.27 -13.04 -5.19 -8.83 -12.56 -26.25 VSWR 1.16 1.42 1.68 3.50 2.17 1.53 1.14 TRULY ELECTRONICS MFG., LTD Truly industry city, shanwei guangdongÿP.R.C 小胶棒天线增益效率和方向图： Fq（MHz） 2400 2410 2420 2430 2440 2450 2460 2470 2480 2490 2500 Gain（dBi） 1.40 1.78 2.02 2.15 2.40 2.50 2.48 2.29 1.95 1.72 1.75 Efficie（%） 57.2 59.1 59.7 60.6 62.1 64.4 66.2 67.1 65.6 64.2 63.2 Fq（MHz） 5150 5200 5250 5300 5350 5700 5750 5800 5850 Gain（dBi） 1.07 1.83 1.87 1.28 2.11 2.93 3.16 2.67 2.27 Efficie（%） 50.2 50.6 51.5 50.8 51.4 57.3 58.2 54.1 52.7 TRULY ELECTRONICS MFG., LTD Truly industry city, shanwei guangdongÿP.R.C 2450MHz方向图： 5250MHz方向图： TRULY ELECTRONICS MFG., LTD Truly industry city, shanwei guangdongÿP.R.C 5800MHz方向图： TRULY ELECTRONICS MFG., LTD Truly industry city, shanwei guangdongÿP.R.C

Page 52 of 69 Report No.: STS2603049W04 -6dB Bandwidth NVNT BLE 2M 2440MHz -6dB Bandwidth NVNT BLE 2M 2480MHz Page 53 of 69 Report No.: STS2603049W04 Maximum Power Spectral Density Level Condition Mode Frequency (MHz) PSD (dBm/3kHz) Limit (dBm/3kHz) Verdict NVNT BLE 1M 2402 -12.83 <=8 Pass NVNT BLE 1M 2440 -14.74 <=8 Pass NVNT BLE 1M 2480 -13.63 <=8 Pass NVNT BLE 2M 2402 -15.01 <=8 Pass NVNT BLE 2M 2440 -15.47 <=8 Pass NVNT BLE 2M 2480 -17.35 <=8 Pass Page 54 of 69 Report No.: STS2603049W04 Test Graphs PSD NVNT BLE 1M 2402MHz PSD NVNT BLE 1M 2440MHz Page 55 of 69 Report No.: STS2603049W04 PSD NVNT BLE 1M 2480MHz PSD NVNT BLE 2M 2402MHz Page 56 of 69 Report No.: STS2603049W04 PSD NVNT BLE 2M 2440MHz PSD NVNT BLE 2M 2480MHz Page 57 of 69 Report No.: STS2603049W04 Band Edge Condition Mode Frequency (MHz) Max Value (dBc) Limit (dBc) Verdict NVNT BLE 1M 2402 -57.03 <=-20 Pass NVNT BLE 1M 2480 -56.62 <=-20 Pass NVNT BLE 2M 2402 -32.7 <=-20 Pass NVNT BLE 2M 2480 -49.22 <=-20 Pass Page 58 of 69 Report No.: STS2603049W04 Test Graphs Band Edge NVNT BLE 1M 2402MHz Ref Band Edge NVNT BLE 1M 2402MHz Emission Page 59 of 69 Report No.: STS2603049W04 Band Edge NVNT BLE 1M 2480MHz Ref Band Edge NVNT BLE 1M 2480MHz Emission Page 60 of 69 Report No.: STS2603049W04 Band Edge NVNT BLE 2M 2402MHz Ref Band Edge NVNT BLE 2M 2402MHz Emission Page 61 of 69 Report No.: STS2603049W04 Band Edge NVNT BLE 2M 2480MHz Ref Band Edge NVNT BLE 2M 2480MHz Emission Page 62 of 69 Report No.: STS2603049W04 Conducted RF Spurious Emission Condition Mode Frequency (MHz) Max Value (dBc) Limit (dBc) Verdict NVNT BLE 1M 2402 -45.42 <=-20 Pass NVNT BLE 1M 2440 -44.8 <=-20 Pass NVNT BLE 1M 2480 -44.31 <=-20 Pass NVNT BLE 2M 2402 -38.96 <=-20 Pass NVNT BLE 2M 2440 -38.75 <=-20 Pass NVNT BLE 2M 2480 -36.81 <=-20 Pass Page 63 of 69 Report No.: STS2603049W04 Test Graphs Tx. Spurious NVNT BLE 1M 2402MHz Ref Tx. Spurious NVNT BLE 1M 2402MHz Emission Page 64 of 69 Report No.: STS2603049W04 Tx. Spurious NVNT BLE 1M 2440MHz Ref Tx. Spurious NVNT BLE 1M 2440MHz Emission Page 65 of 69 Report No.: STS2603049W04 Tx. Spurious NVNT BLE 1M 2480MHz Ref Tx. Spurious NVNT BLE 1M 2480MHz Emission Page 66 of 69 Report No.: STS2603049W04 Tx. Spurious NVNT BLE 2M 2402MHz Ref Tx. Spurious NVNT BLE 2M 2402MHz Emission Page 67 of 69 Report No.: STS2603049W04 Tx. Spurious NVNT BLE 2M 2440MHz Ref Tx. Spurious NVNT BLE 2M 2440MHz Emission Page 68 of 69 Report No.: STS2603049W04 Tx. Spurious NVNT BLE 2M 2480MHz Ref Tx. Spurious NVNT BLE 2M 2480MHz Emission Page 69 of 69 Report No.: STS2603049W04 APPENDIX 2- EUT TEST PHOTO Note: See test photos in setup photo document for the actual connections between Product and support equipment. ※※※※※END OF THE REPORT※※※※※

Page 27 of 69 Report No.: STS2603049W04 (1GHz-25GHz) Spurious emission Requirements 1M PHY GFSK Frequency Meter Reading Amplifier Loss Antenna Factor Corrected Factor Emission Level Limits Margin Detector Comment (MHz) (dBμV) (dB) (dB) (dB/m) (dB) (dBμV/m) (dBμV/m) (dB) Type Low Channel (GFSK/2402 MHz) 3264.80 61.63 44.70 6.70 28.20 -9.80 51.83 74.00 -22.17 PK Vertical 3264.80 50.65 44.70 6.70 28.20 -9.80 40.85 54.00 -13.15 AV Vertical 3264.57 61.64 44.70 6.70 28.20 -9.80 51.84 74.00 -22.16 PK Horizontal 3264.57 50.65 44.70 6.70 28.20 -9.80 40.85 54.00 -13.15 AV Horizontal 4804.33 58.23 44.20 9.04 31.60 -3.56 54.67 74.00 -19.33 PK Vertical 4804.33 49.88 44.20 9.04 31.60 -3.56 46.32 54.00 -7.68 AV Vertical 4804.44 59.01 44.20 9.04 31.60 -3.56 55.45 74.00 -18.55 PK Horizontal 4804.44 49.55 44.20 9.04 31.60 -3.56 45.99 54.00 -8.01 AV Horizontal 5359.64 48.39 44.20 9.86 32.00 -2.34 46.05 74.00 -27.95 PK Vertical 5359.64 39.25 44.20 9.86 32.00 -2.34 36.90 54.00 -17.10 AV Vertical 5359.79 47.72 44.20 9.86 32.00 -2.34 45.37 74.00 -28.63 PK Horizontal 5359.79 38.16 44.20 9.86 32.00 -2.34 35.82 54.00 -18.18 AV Horizontal 7205.81 54.64 43.50 11.40 35.50 3.40 58.04 74.00 -15.96 PK Vertical 7205.81 44.60 43.50 11.40 35.50 3.40 48.00 54.00 -6.00 AV Vertical 7205.72 53.83 43.50 11.40 35.50 3.40 57.23 74.00 -16.77 PK Horizontal 7205.72 44.40 43.50 11.40 35.50 3.40 47.80 54.00 -6.20 AV Horizontal Middle Channel (GFSK/2440 MHz) 3262.99 61.70 44.70 6.70 28.20 -9.80 51.90 74.00 -22.10 PK Vertical 3262.99 49.85 44.70 6.70 28.20 -9.80 40.05 54.00 -13.95 AV Vertical 3263.00 61.61 44.70 6.70 28.20 -9.80 51.81 74.00 -22.19 PK Horizontal 3263.00 50.01 44.70 6.70 28.20 -9.80 40.21 54.00 -13.79 AV Horizontal 4879.89 59.14 44.20 9.04 31.60 -3.56 55.58 74.00 -18.42 PK Vertical 4879.89 50.22 44.20 9.04 31.60 -3.56 46.66 54.00 -7.34 AV Vertical 4879.90 58.26 44.20 9.04 31.60 -3.56 54.70 74.00 -19.30 PK Horizontal 4879.90 50.55 44.20 9.04 31.60 -3.56 46.99 54.00 -7.01 AV Horizontal 5357.14 49.36 44.20 9.86 32.00 -2.34 47.01 74.00 -26.99 PK Vertical 5357.14 40.32 44.20 9.86 32.00 -2.34 37.98 54.00 -16.02 AV Vertical 5357.39 47.76 44.20 9.86 32.00 -2.34 45.42 74.00 -28.58 PK Horizontal 5357.12 38.90 44.20 9.86 32.00 -2.34 36.56 54.00 -17.44 AV Horizontal 7320.85 54.67 43.50 11.40 35.50 3.40 58.07 74.00 -15.93 PK Vertical 7320.85 44.61 43.50 11.40 35.50 3.40 48.01 54.00 -5.99 AV Vertical 7320.36 54.09 43.50 11.40 35.50 3.40 57.49 74.00 -16.51 PK Horizontal 7320.36 43.92 43.50 11.40 35.50 3.40 47.32 54.00 -6.68 AV Horizontal Page 28 of 69 Report No.: STS2603049W04 High Channel (GFSK/2480 MHz) 3264.68 61.67 44.70 6.70 28.20 -9.80 51.87 74.00 -22.13 PK Vertical 3264.68 50.15 44.70 6.70 28.20 -9.80 40.35 54.00 -13.65 AV Vertical 3264.81 62.16 44.70 6.70 28.20 -9.80 52.36 74.00 -21.64 PK Horizontal 3264.81 50.78 44.70 6.70 28.20 -9.80 40.98 54.00 -13.02 AV Horizontal 4960.55 58.25 44.20 9.04 31.60 -3.56 54.69 74.00 -19.31 PK Vertical 4960.55 49.27 44.20 9.04 31.60 -3.56 45.71 54.00 -8.29 AV Vertical 4960.51 59.55 44.20 9.04 31.60 -3.56 55.99 74.00 -18.01 PK Horizontal 4960.51 49.28 44.20 9.04 31.60 -3.56 45.72 54.00 -8.28 AV Horizontal 5359.86 49.33 44.20 9.86 32.00 -2.34 46.98 74.00 -27.02 PK Vertical 5359.86 39.82 44.20 9.86 32.00 -2.34 37.48 54.00 -16.52 AV Vertical 5359.62 47.50 44.20 9.86 32.00 -2.34 45.16 74.00 -28.84 PK Horizontal 5359.62 38.85 44.20 9.86 32.00 -2.34 36.51 54.00 -17.49 AV Horizontal 7439.88 54.30 43.50 11.40 35.50 3.40 57.70 74.00 -16.30 PK Vertical 7439.88 43.80 43.50 11.40 35.50 3.40 47.20 54.00 -6.80 AV Vertical 7439.67 54.51 43.50 11.40 35.50 3.40 57.91 74.00 -16.09 PK Horizontal 7439.67 44.76 43.50 11.40 35.50 3.40 48.16 54.00 -5.84 AV Horizontal Note: 1) Factor = Antenna Factor + Cable Loss – Pre-amplifier. Emission Level = Reading + Factor. 2) The frequency emission of peak points that did not show above the forms are at least 20dB below the limit, the frequency emission is mainly from the environment noise. Page 29 of 69 Report No.: STS2603049W04 2M PHY GFSK Frequency Meter Reading Amplifier Loss Antenna Factor Corrected Factor Emission Level Limits Margin Detector Comment (MHz) (dBμV) (dB) (dB) (dB/m) (dB) (dBμV/m) (dBμV/m) (dB) Type Low Channel (GFSK/2402 MHz) 3264.63 60.89 44.70 6.70 28.20 -9.80 51.09 74.00 -22.91 PK Vertical 3264.63 50.32 44.70 6.70 28.20 -9.80 40.52 54.00 -13.48 AV Vertical 3264.74 61.88 44.70 6.70 28.20 -9.80 52.08 74.00 -21.92 PK Horizontal 3264.74 50.67 44.70 6.70 28.20 -9.80 40.87 54.00 -13.13 AV Horizontal 4804.40 59.54 44.20 9.04 31.60 -3.56 55.98 74.00 -18.02 PK Vertical 4804.40 49.22 44.20 9.04 31.60 -3.56 45.66 54.00 -8.34 AV Vertical 4804.38 59.40 44.20 9.04 31.60 -3.56 55.84 74.00 -18.16 PK Horizontal 4804.38 49.86 44.20 9.04 31.60 -3.56 46.30 54.00 -7.70 AV Horizontal 5359.85 48.08 44.20 9.86 32.00 -2.34 45.74 74.00 -28.26 PK Vertical 5359.85 39.89 44.20 9.86 32.00 -2.34 37.55 54.00 -16.45 AV Vertical 5359.83 48.57 44.20 9.86 32.00 -2.34 46.22 74.00 -27.78 PK Horizontal 5359.83 38.24 44.20 9.86 32.00 -2.34 35.90 54.00 -18.10 AV Horizontal 7205.89 55.00 43.50 11.40 35.50 3.40 58.40 74.00 -15.60 PK Vertical 7205.89 43.69 43.50 11.40 35.50 3.40 47.09 54.00 -6.91 AV Vertical 7205.66 53.95 43.50 11.40 35.50 3.40 57.35 74.00 -16.65 PK Horizontal 7205.66 44.15 43.50 11.40 35.50 3.40 47.55 54.00 -6.45 AV Horizontal Middle Channel (GFSK/2440 MHz) 3263.10 61.95 44.70 6.70 28.20 -9.80 52.15 74.00 -21.85 PK Vertical 3263.10 51.65 44.70 6.70 28.20 -9.80 41.85 54.00 -12.15 AV Vertical 3263.17 61.25 44.70 6.70 28.20 -9.80 51.45 74.00 -22.55 PK Horizontal 3263.17 50.58 44.70 6.70 28.20 -9.80 40.78 54.00 -13.22 AV Horizontal 4880.14 59.52 44.20 9.04 31.60 -3.56 55.96 74.00 -18.04 PK Vertical 4880.14 49.28 44.20 9.04 31.60 -3.56 45.72 54.00 -8.28 AV Vertical 4880.00 58.60 44.20 9.04 31.60 -3.56 55.04 74.00 -18.96 PK Horizontal 4880.00 49.26 44.20 9.04 31.60 -3.56 45.70 54.00 -8.30 AV Horizontal 5357.31 48.44 44.20 9.86 32.00 -2.34 46.10 74.00 -27.90 PK Vertical 5357.31 39.58 44.2…

Text truncated - open the document above for the full version.

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Report No.:STS2603049W04 Issued for TRULY ELECTRONICS MFG., LTD Truly industry city, shanwei guangdong，P.R.C Product Name: WIFI6+BLE 5.2 Module Brand Name: N/A Model Name: TR6A800S1-C Series Model(s): TR6A800S1, TR6A800S1-C1 FCC ID: 2BOHY-800S1 Test Standards: FCC Part15.247 Page 2 of 69 Report No.: STS2603049W04 TEST REPORT Applicant’s Name ................. : TRULY ELECTRONICS MFG., LTD Address ................................. : Truly industry city, shanwei guangdong，P.R.C Manufacturer's Name .......... : TRULY ELECTRONICS MFG., LTD Address ................................. : Truly industry city, shanwei guangdong，P.R.C Product Description Product Name ....................... : WIFI6+BLE 5.2 Module Brand Name .......................... : N/A Model Name .......................... : ... : TR6A800S1-C Series Model(s) .................... : TR6A800S1, TR6A800S1-C1 Test Standards ..................... : FCC Part15.247 Test Procedure ...................... : ANSI C63.10-2020 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the IC requirements. And it is applicable only to the tested sample identified in the report. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ..................... : 06 Mar. 2026 Date (s) of performance of tests ............. : 06 Mar. 2026~17 Mar. 2026 Date of Issue .......................................... : 17 Mar. 2026 Test Result.............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 69 Report No.: STS2603049W04 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 11 2.6 EQUIPMENTS LIST 12 3. EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.2 TEST PROCEDURE 14 3.3 TEST SETUP 14 3.4 EUT OPERATING CONDITIONS 14 3.5 TEST RESULTS 15 4. RADIATED EMISSION MEASUREMENT 17 4.1 RADIATED EMISSION LIMITS 17 4.2 TEST PROCEDURE 19 4.3 TEST SETUP 20 4.4 EUT OPERATING CONDITIONS 20 4.5 FIELD STRENGTH CALCULATION 21 4.6 TEST RESULTS 22 5. DUTY CYCLE 35 5.1 TEST STANDARD 35 5.2 TEST PROCEDURE 35 5.3 DEVIATION FROM STANDARD 35 5.4 TEST SETUP 35 5.6 TEST RESULTS 35 6. CONDUCTED SPURIOUS & BAND EDGE EMISSION 36 6.1 LIMIT 36 6.2 TEST PROCEDURE 36 6.3 TEST SETUP 36 Page 4 of 69 Report No.: STS2603049W04 Table of Contents Page 6.4 EUT OPERATION CONDITIONS 36 6.5 TEST RESULTS 36 7. POWER SPECTRAL DENSITY TEST 37 7.1 LIMIT 37 7.2 TEST PROCEDURE 37 7.3 TEST SETUP 37 7.4 EUT OPERATION CONDITIONS 37 7.5 TEST RESULTS 37 8. BANDWIDTH TEST 38 8.1 LIMIT 38 8.2 TEST PROCEDURE 38 8.3 TEST SETUP 38 8.4 EUT OPERATION CONDITIONS 38 8.5 TEST RESULTS 38 9. PEAK OUTPUT POWER TEST 39 9.1 LIMIT 39 9.2 TEST PROCEDURE 39 9.3 TEST SETUP 39 9.4 EUT OPERATION CONDITIONS 39 9.5 TEST RESULTS 39 10. ANTENNA REQUIREMENT 40 10.1 STANDARD REQUIREMENT 40 10.2 EUT ANTENNA 40 APPENDIX 1-TEST DATA 41 DUTY CYCLE 41 MAXIMUM PEAK CONDUCTED OUTPUT POWER 45 -6DB BANDWIDTH 49 MAXIMUM POWER SPECTRAL DENSITY LEVEL 53 BAND EDGE 57 CONDUCTED RF SPURIOUS EMISSION 62 APPENDIX 2- EUT TEST PHOTO 69 Page 5 of 69 Report No.: STS2603049W04 Revision History Rev. Issue Date Report No. Effect Page Contents 00 17 Mar. 2026 STS2603049W04 ALL Initial Issue Page 6 of 69 Report No.: STS2603049W04 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted bands of operation PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- Note: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. Page 7 of 69 Report No.: STS2603049W04 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.751dB 2 Unwanted Emissions, conducted ±2.888dB 3 All emissions, radiated 9K-30MHz ±2.48dB 4 All emissions, radiated 30M-1GHz ±2.52dB 5 All emissions, radiated 1G-18GHz ±3.48dB 6 All emissions, radiated>18GHz ±4.18dB 7 Conducted Emission (9KHz-150KHz) ±2.48dB 8 Conducted Emission (150KHz-30MHz) ±2.52dB 9 Occupied Channel Bandwidth ±3.6% 10 Power Spectral Density, conducted ±1.214dB 11 Duty Cycle ±3.2% Page 8 of 69 Report No.: STS2603049W04 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name WIFI6+BLE 5.2 Module Brand Name N/A Model Name TR6A800S1-C Series Model(s) TR6A800S1, …

Text truncated - open the document above for the full version.

Page 79 of 99 Report No.: STS2603049W03 Band Edge NVNT ax40 2452MHz Ref Band Edge NVNT ax40 2452MHz Emission Page 80 of 99 Report No.: STS2603049W03 Conducted RF Spurious Emission Condition Mode Frequency (MHz) Max Value (dBc) Limit (dBc) Verdict NVNT b 2412 -45.83 <=-20 Pass NVNT b 2437 -45.95 <=-20 Pass NVNT b 2462 -46.5 <=-20 P…
